Chatillon DG-200 User manual

DG Series User Manual 1
Part No. NC002737
May 2012
DG Series
Mechanical Force Gauges
User Manual
www. .com [e-mail]1.800.561.8187

2 DG Series User Manual
WARRANTY
This instrument is warranted against defects in workmanship, material and design for two (2) years
from date of delivery to the extent that AMETEK will, at its sole option, repair or replace the instrument
or any part thereof which is defective, provided, however, that this warranty shall not apply to instru-
ments subjected to tampering or, abuse, or exposed to highly corrosive conditions.
THIS WARRANTY IS IN LIEU OF ALL OTHER WARRANTIES WHETHER EXPRESS OR IMPLIED AND
AMETEK HEREBY DISCLAIMS ALL OTHER WARRANTIES, INCLUDING, WITHOUT LIMITATION, ANY
WARRANTY OF FITNESS FOR A PARTICULAR PURPOSE OR MERCHANTABILITY. AMETEK SHALL
NOT BE LIABLE FOR ANY INCIDENTAL OR CONSEQUENTIAL DAMAGES, INCLUDING, BUT NOT
LIMITED TO, ANY ANTICIPATED OR LOST PROFITS.
This warranty is voidable if the purchaser fails to follow any and all instructions, warnings or cautions
in the instrument’s Instruction Manual.
If a manufacturing defect is found, AMETEK will replace or repair the instrument or replace any defective
part thereof without charge; however, AMETEK’s obligation hereunder does not include the cost of trans-
portation, which must be borne by the customer. AMETEK assumes no responsibility for damage in transit,
and any claims for such damage should be presented to the carrier by the purchaser.
TRADEMARKS
AMETEK is a registered trademarks of AMETEK, Inc.
CHATILLON is a registered trademark of AMETEK, Inc.
Other trademarks are the property of their respective owners.
www. .com [e-mail]1.800.561.8187

DG Series User Manual 3
ICONS
WARNING
The raised hand icon warns of a situation or condition that may lead to personal injury
or death. Do not proceed until the warning is read and thoroughly understood.
Warning messages are shown in bold type.
DANGEROUS VOLTAGE
The lightning icon warns of the presence of an uninsulated dangerous voltage within
theproductenclosurethatmightbeofsufcientmagnitudetocauseseriousshocks
ordeath.Neveropentheenclosuresunlessyouareanauthorizedandqualied
CHATILLON service personnel. Never open any enclosure when power is connected
to the system or its components.
CAUTION
The exclamation point icon indicates a situation or condition that may lead to equip-
ment malfunction or damage. Do not proceed until the caution message is read and
thoroughly understood. Caution messages are shown in bold type.
NOTE
The note icon indicates additional or supplementary information about the action,
activity or concept. Notes are shown in bold type.
CAUTION
HIGH FORCES ARE OFTEN INVOLVED WITH THE
MATERIAL TESTING PROCESSES.
IF THE EQUIPMENT IS USED IN A MANOR NOT
SPECIFIED BY THE MANUFACTURER, THE
PROTECTION PROVIDED BY THE EQUIPMENT MAY
BE IMPAIRED.
TO MAINTAIN ALL ASPECTS OF THE SPECIFICATION,
ONLY AMETEK APPROVED ACCESSORIES,
CONNECTIONS AND COMPONENTS SHOULD BE
USED.
STRICTLY ADHERE TO ALL SPECIFIED SAFETY
PROCEDURES
READ THIS MANUAL BEFORE USING THIS PRODUCT.
General Safety
General safety precautions must be followed when
using this CHATILLON product. Failure to observe
precautions and warnings may result in damage to
the equipment, or injury to personnel.
It is understood that safety rules within companies
vary.Ifaconictexistsbetweenthematerial
contained in all CHATILLON User’s Guides and the
rules of a company using a CHATILLON product,
the more stringent rules should take precedence.
Safety Considerations
The DG Series is completely enclosed and pro-
vides no potentially hazardous outputs.
Mechanical components housed within the DG
Series covers are to be serviced by authorized
CHATILLON representatives only.
Whendesigningacustomxtureensure
theloadratingofthecustomxtureex-
ceeds the load rating of the force gauge.
i.e. If the load rating of the force gauge
is500LBFthecustomxtureshouldhaveaload
rating greater than 500 LBF
www. .com [e-mail]1.800.561.8187

4 DG Series User Manual
INTRODUCTION
The DG Series mechanical force gauge is ideal for a wide range of force testing applications. Based on
our popular DPPH Series force gauge, the DG Series features a 2.25-inch dial for improved resolution and
readability, peak hold button, ergonomic shape and improved accuracy of +0.5% of full scale. The DG
gauge is an excellent, economical solution for tensile or compression testing.
The DG series gauge can be used as a hand held device with a handle adapter assembly that can be
purchased separately. Gauges may be mounted to a test stand for even greater control and consistent
results in repetitive testing applications. Easy to read concentric dial measures clockwise direction only.
Dial rotates 360-degrees for taring. A peak hold button captures peak readings. Available in lbf, kgf or N
units of measure. DG Series gauges come complete with protective carrying case and a set of stainless
steelattachments.ACerticateofCalibrationwithDataissuppliedstandard.
OPERATION
The zero point of the gauge may not always be in the 12 o’clock position due to gravity effects and the
weightofxturesorgripsontheforcegaugeshaft.Tozerothegauge,rotatethebezelonthedialindicator
so that the indicator pointer lines up with the zero on the dial face.
Gauges are designed for axial loading. Ensure the load is not applied at an angle or an error can be
introducedintheforcereadings.Thegaugesaredesignedtohavea10%tareforxturesandgrips.If
this 10% tare is exceeded, the force gauge may not measure up to full scale.
COMPRESSION TESTING
For compression testing, assemble the appropriate
attachment or grip to the bottom shaft of the force
gauge. For compression testing the shaft should
be pushed into the gauge, causing the indicator
to rotate in the clockwise direction. Attachments
shouldbeapplied“nger-tight”.
Do NOT overtighten.
TENSILE TESTING
For tension testing, assemble the appropriate
hook, attachment or grip to the top shaft of the
force gauge. For tension testing the shaft should
be pulled out of the top of the force gauge, causing
the indicator to rotate in the clockwise direction.
Attachmentsshouldbeapplied“nger-tight”.
Do NOT overtighten.
CAUTION: The DG Series is a unidirectional force gauge. When applying a load to the
instrument the dial indicator MUST rotate in the clockwise direction.
CAUTION: NEVER apply a load to the DG Series force gauge so the indicator rotates in the
counterclockwise direction. If excessive loads are applied in the counterclockwise direction,
damage may occur to the force gauge.
www. .com [e-mail]1.800.561.8187

DG Series User Manual 5
PEAK HOLD
The DG Series force gauge has a maximum hold
feature. This allows the peak force to be held after
the load is removed.
ACTIVATE PEAK HOLD
To activate this feature, rotate the knob to “MAX
ON”position.
RESET PEAK HOLD
To reset the reading, simply rotate the switch to
“MAXOFF”andthenreturnbackto“MAXON”
position. To deactivate this feature, rotate the knob
tothe“MAXOFF”position.
TEST STAND MOUNTING
The DG Series force gauge has four #10-32 female
threads for mounting to CHATILLON test stands.
Ensure the #10-32 screws are not too long, other-
wise it may bind and damage the force gauge.
The screw thread length going into the back of the
gauge should not exceed 3/8 inch.
MAINTENANCE
Gauge accuracy should be checked periodically
to ensure the gauge is within its calibration limits.
Thecalibrationcanbeveriedbyapplyingknown
weights (adjusted for local gravity) to the extension
hook. If adjustment is required, the gauge should
be returned to AMETEK for calibration.
Test Stand Adapters
Item No. Fits Tester
SPK-MT-0005 MT150, MT500
SPK-DG-TT TT Testers
www. .com [e-mail]1.800.561.8187

6 DG Series User Manual
SPECIFICATIONS
Accuracy: +0.5% of Full Scale
Overload Capacity: 110% of Rated Capacity
Maximum Overload: 150% of Rated Capacity
Tare Capacity: 10% of Rated Capacity
Dial Resolution: 0.5% of Full Scale
Deection: 10mm(.394inches)atFullScale
OperatingTemperature: +40°Fto+110°F(+5°Cto+45°C)
InstrumentWeight: 4.7lbs(2.12kg)
ShippingWeightwithcase: 8.4lbs(3.80kg)
Warranty: 2 Years
ORDERING
Dial Style - LBF
Model Capacity
DG-200 200 x 1 lbf
DG-300 300 x 1.5 lbf
DG-400 400x2lbf
DG-500 500 x 2.5 lbf
Dial Style - KGF
Model Capacity
DG-100KG 100 x 0.5 kgf
DG-250KG 250 x 1.25 kgf
Dial Style - N
Model Capacity
DG-1000N 1000 x 5N
DG-2500N 2500 x 12.5N
Accessories
Item No. Description Standard
SPK-FMG-008B Adapter, Chisel Point Yes
SPK-FMG-009B Adapter, Point Yes
SPK-FMG-010B Adapter, Notch Yes
SPK-FMG-011B Adapter, Flat Yes
SPK-FMG-012C Hook Yes
SPK-FMG-013B ExtensionRod,6” Yes
NC002728 Carrying Case Yes
NC002500 Hook, Snap Clip Option
NC00721 V-Notch, Small Option
NC00725 V-Notch, Large Option
NC002844  GraspingCable Option
SPK-DG-HANDLE Handle Assembly Option
SPK-FMG-142 CurvedCompressionPlate Option
SPK-FMG-143 CompressionPlate,Circle Option
SPK-FMG-144 PalmFixture Option
SPK-FMG-145 RectanglePlate,large Option
SPK-FMG-146 RectanglePlate,small Option
NC002845  SoftCarryingCase Option
Note:Threadedxturesare5/16-18.
www. .com [e-mail]1.800.561.8187

DG Series User Manual 7
DIMENSION
1.75 in
(44.5 mm)
#10-32 UNF
Mounting Holes
(4 Locations)
3.85 in
(97.8 mm)
9.5 in
(241.3 mm)
4.45 in
(113.0 mm)
2.7 in
(68.6 mm)
5.0 in
(127.0 mm)
11.0 in
(279.4 mm)
5/16-18 UNC
0.38” Long
1.0 in
(25.4 mm)
E96-331
1.0 in
(25.4 mm)
0.6 in
(15.2 mm)
2.7 in
(68.6 mm)
2.2 in
(55.9 mm)
www. .com [e-mail]1.800.561.8187

8 DG Series User Manual
SPARE PARTS
www. .com [e-mail]1.800.561.8187

DG Series User Manual 9
1 NC002689 Plate, Upper Support
2 NC002690 Plate, Lower Support
3 NC002681 Frame, Upper Support
4 NC002680 Frame, Lower Support
5 910-04-001 Ball Bushing
6 900-46-010 Retaining Ring
7 21047 Screw, #10-32 x 1/2 Flat Head
8 7970 Nut, 1/4-20 Hex
9 NC002685 Main Shaft
10 NC002684 Calibrator
11 NC002663 Support, Spring, Medium
12 NC002682 Support, Spring, Large
13 3168 Nut, #6 Hex
14 10390 Washer, #6 Lock
15 NC002683 Bearing Support
16 NC002668 Ball Bearing, Radial
17 E08-250 Screw, #1/4-20 x 1/2 Pan Head
18 NC002692 Spring Support, Calibrator
19 3127 Set Screw, #10-32 x 1/4
20 NC000124 Screw, #6-32 x 1 SHC
21 NC002688 Taper Pin, #2 x 1
22 E08-256 Screw, 1/4-28 x 1 SHC
23 900-30-021 Washer, 1/4 Flat
24 900-08-023 Set Screw, #6-32 x 1/4
25 NC002677-09 Dial Indicator, 200 lbf (DG-200)
NC002677-10 Dial Indicator, 300 lbf (DG-300)
NC002677-11 Dial Indicator, 400 lbf (DG-400)
NC002677-12 Dial Indicator, 500 lbf (DG-500)
NC002677-21 Dial Indicator, 100kgf (DG-100KG)
NC002677-22 Dial Indicator, 250 kgf (DG-250KG)
NC002677-32 Dial Indicator, 1000N (DG-1000N)
NC002677-33 Dial Indicator, 2500N (DG-2500N)
26 NC002674 Spring, Compression
27 NC002672 Bracket, Maximum Capture
28 NC002673 Plate, Maximum Capture
29 E08-241 Screw, #4-40 x 3/16 Pan Head
30 E08-252 Screw, #4-40 x 5/16 Round Head
31 NC002691 Threaded Bushing
32 9766 Washer, Lock 1/4 ID
33 NC002730 Top Housing
34 NC002731 Bottom Housing
35 03-90041 Screw, #6-32 x 5/16 Pan Head
36 E08-251 Screw, #6-32 x 3/4 Pan Head
38 NC002734-1 Main Spring, 200 lbf (DG-200
NC002734-2 Main Spring, 300 lbf (DG-300
NC002734-3 Main Spring, 400 lbf (DG-400
NC002734-4 Main Spring, 500 lbf (DG-500
NC002734-5 Main Spring, 100 kgf (DG-100KG
NC002734-6 Main Spring, 250 kgf (DG-250KG)
NC002734-7 Main Spring, 1000N (DG-1000N)
NC002734-8 Main Spring, 2500N DG-2500N)
39 SPK-DG-200 Trim Spring Set, 200 lbf (DG-200)
SPK-DG-300 Trim Spring Set, 300 lbf (DG-300)
SPK-DG-400 Trim Spring Set, 400 lbf (DG-400)
SPK-DG-500 Trim Spring Set, 500 lbf (DG-500
SPK-DG-100KG Trim Spring Set, 100 kgf (DG-100KG
SPK-DG-250KG Trim Spring Set, 250 kgf (DG-250KG
SPK-DG-1000N Trim Spring Set, 1000N (DG-1000N)
SPK-DG-2500N Trim Spring Set, 2500N (DG-2500N)
45 NC002621 Label, Capacity
53 NC002678 Latch, Pawl Assembly
54 E02-235 Split Lock Washer, #4
55 E02-236 Washer, Flat, #5
Ref. Item No. Description
Ref. Item No. Description
SPARE PARTS LIST
www. .com [e-mail]1.800.561.8187
