Chauvet Professional Ovation B-2805FC User manual

Quick Reference Guide
English EN
Español ES
Français FR
Nederlands NL

Ovation B-2805FC QRG EN
2
About This
Guide
The Ovation B-2805FC Quick Reference Guide (QRG) has basic product
information such as connection, mounting, menu options, and DMX values.
Download the User Manual from www.chauvetprofessional.com for more details.
Disclaimer
The information and specifications contained in this QRG are subject to change
without notice.
Safety Notes
•DO NOT open this product. It contains no user-serviceable parts.
•DO NOT look at the light source when the product is on.
•To eliminate unnecessary wear and improve its lifespan, during periods of
non-use completely disconnect the product from power via breaker or by
unplugging it.
•CAUTION: When transferring product from extreme temperature
environments, (e.g. cold truck to warm humid ballroom) condensation may
form on the internal electronics of the product. To avoid causing a failure,
allow product to fully acclimate to the surrounding environment before
connecting it to power.
•CAUTION: This product’s housing may be hot when lights are operating.
•Mount this product in a location with adequate ventilation, at least
20 in (50 cm) from adjacent surfaces.
•DO NOT leave any flammable material within 50 cm of this product while
operating or connected to power.
•USE a safety cable when mounting this product overhead.
•DO NOT operate this product outdoors or in any location where dust,
excessive heat, water, or humidity may affect it. (IP20)
•DO NOT operate this product if the housing, lenses, or cables appear
damaged.
•DO NOT connect this product to a dimmer or rheostat.
•ONLY connect this product to a grounded and protected circuit.
•ONLY use the hanging/mounting bracket or the handles to carry this product.
•In the event of a serious operating problem, stop using immediately.
•The maximum ambient temperature is 113 °F (45 °C). Do not operate this
product at higher temperatures.
Contact
Outside the U.S., United Kingdom, Ireland, Mexico, or Benelux, contact your
distributor to request support or return a product. From inside the U.S., UK, Ireland,
Mexico, or Benelux, use the information in Contact Us at the end of this QRG.
What Is
Included
•Ovation B-2805FC
•Neutrik powerCON power cord
•Wall Washing Filter
•Warranty Card
•Quick Reference Guide
AC Power
This product has an auto-ranging power supply that can work with an input voltage
range of 100–240 VAC, 50/60 Hz.
To eliminate unnecessary wear and improve its lifespan, during periods of non-
use completely disconnect the product from power via breaker or by
unplugging it.
Power Linking
You can link up to 2 Ovation B-2805FC products at 120 V, 3 products at 208 V, or
4
products at 230 V. Never exceed this number. Power linking cords can be
purchased separately.

Ovation B-2805FC QRG EN
3
AC Plug
Connection
Wire (U.S.)
Wire (Europe)
Screw Color
AC Live
Black
Brown
Yellow/Brass
AC Neutral
White
Blue
Silver
AC Ground
Green/Yellow
Green/Yellow
Green
Replacing The
Fuse
1. Disconnect this product from power.
2. Using a flat head screwdriver, unscrew the fuse holder cap from the housing.
3. Remove blown fuse and replace with a good fuse of the same type and rating.
4. Screw the fuse holder cap back in place and reconnect power.
Signal
Connections
You can link the Ovation B-2805FC to a controller or controller software using a
DMX connection or an Ethernet connection. If using other Art-Net™ or sACN-
compatible products with the Ovation B-
2805FC, you can control each individually
on a single network. See the User Manual for information about how to connect and
configure the product for these signals.
Control
Personalities
The Ovation B-2805FC uses DMX, Art-Net™, and sACN for its 33 control
personalities, ranging from 3CH to 135CH in 1-cell modes, 2-cell modes, 5-cell
modes, and 10-cell modes:
Mode
1-Cell
2-Cell
5-Cell
10-Cell
DMX-VCW-CCT
3CH
N/A
N/A
N/A
RGB
3CH
6CH
15CH
30CH
RGBA
4CH
8CH
20CH
40CH
RGBAL
5CH
10CH
25CH
50CH
RGB EXT
8CH
15CH
33CH
63CH
RGBA EXT
9CH
17CH
38CH
73CH
RGBAL EXT
10CH
19CH
43CH
83CH
RGBAL Fine
10CH
20CH
50CH
100CH
RGBAL FULL
17CH
31CH
70CH
135CH
DMX Connection
The Ovation B-2805FC will work with a DMX controller using a 3- or 5-pin DMX
data connection. A DMX Primer is available from www.chauvetprofessional.com.
Art-Net™
Connection
Art-Net™ is an Ethernet protocol that uses TCP/IP which transfers a large amount
of DMX512 data using an Neutrik® etherCON® RJ45 connection over a large
network. An Art-
Net™ protocol document is available from
www.chauvetprofessional.com.
Chauvet Professional recommends using unicast
Art-Net™ for best results.
Art-Net™ designed by and copyright Artistic Licence Holdings Ltd.
sACN
Connection
Also known as ANSI E1.31, Streaming-ACN is an Ethernet protocol that uses the
layering and
formatting of Architecture for Control Networks to transport DMX512
data over IP or any other ACN compatible network. ACN is maintained by the
Professional Lighting and Sound Association (PLASA).

Ovation B-2805FC QRG EN
4
Master/Slave
Connection
The Ovation B-2805FC uses the DMX data connection for its Master/Slave mode.
See the User Manual for information about connect and configure the product for
master/slave operation.
RDM
(Remote Device
Management)
Remote Device Management, or RDM, is a standard for allowing DMX-enabled
devices to communicate bi-
directionally along existing DMX cabling. The
Ovation B-
2805FC supports RDM protocol that allows feedback to monitor
temperature and changes to DMX Address and DMX Channel
menu map options.
Download the User Manual from www.chauvetprofessional.com for more details.
Mounting
Before mounting this product, read the Safety Notes. Use at least two mounting
points
per product. Make sure the mounting clamps are capable of supporting the
weight of the product. For our CHAUVET Professional line of mounting clamps, g
o
to http://trusst.com/products/.
Product
Mounting
Diagram
Web Server
The Ovation B-2805FC Web Server can be accessed by any computer on the same
network as the product. It
allows network access to system information, settings
such as control protocol and
starting address, color output testing, and the ability to
change the Web Server password.
To access the Web Server:
1. Set the IP address of the network to have the same first
digit as the IP address of
the product.
2. Enter the IP address of the product into the URL bar of a web browser
application.
3. Enter both the user name and password as admin to log in.
Control Panel
Description
Button
Function
<MENU>
Exits from the current menu or function
<ENTER>
Enables the currently displayed menu or sets the currently
selected value into the selected function
<UP>
Navigates upwards through the menu list or increases the
numeric value when in a function
<DOWN>
Navigates downwards through the menu list or decreases the
numeric value when in a function
Overhead Mounting
Mounting Clamps
Safety Cables

Ovation B-2805FC QRG EN
5
Virtual
Color Wheel
The Ovation B-2805FC includes a feature called the Virtual Color Wheel (VCW). This
feature is available as a stand-alone control mode for manual use and also as a
control
channel in each of the products’ DMX personalities. Over thirty pre-
mixed colors based on
popular gel colors from Rosco are available to call up for easier programming. When
manually selecting the colors on the Virtual Color Wheel, the referenced
gel number
appears on the LED display for convenient selection and ease-of-use.
These formulas were developed to match a gelled tungsten lamp. When developing the
above formulas, the master dimmer on the Ovation B-2805FC
was adjusted to match
the gelled output of the t
ungsten fixture. Please note that due to the efficacy of the light
source, Virtual Color Wheel output may look different from the gelled equivalent on a
tungsten source at full intensity. The master dimmer v
alues may need to be adjusted to
match the tungsten fixture in the most saturated colors.
Virtual Color
Wheel Chart
DMX Channel
Value
Display Readout
Red
Value
Green
Value
Blue
Value
Amber
Value
Lime
Value
000005
000
000
000
000
000
006013
R4590-Cal90 Yellow
150
125
2
255
43
014021
R11-Light Straw
235
108
5
255
76
022028
R312-Canary
171
36
0
120
255
029035
R03-Dark B Amber
255
15
17
255
170
036043
R18-Flame
255
0
10
255
143
044051
R20-Medium Amber
255
0
3
255
75
052059
R21-Golden Amber
188
0
2
255
44
060067
R26-Light Red
255
0
2
21
2
068075
R27-Medium Red
255
0
2
0
0
076083
R33-No Color Pink
255
130
25
255
27
084091
R337-True Pink
255
13
41
235
182
092099
R38-Light Rose
255
15
27
30
255
100107
R41-Salmon
255
0
4
115
9
108115
R42-Deep Salmon
255
0
4
11
8
116121
R44-Middle Rose
255
0
22
81
39
122130
R349-Fisher Fuchsia
160
0
25
0
4
131138
R54-Special Lavender
255
162
43
255
140
139146
R64-Light Steel Blue
12
255
70
76
115
147154
R364-Blue Bell
30
187
85
215
255
155162
R65-Daylight Blue
4
255
62
93
49
163170
R80-Primary Blue
5
255
190
3
12
171178
R81-Urban Blue
8
250
145
5
88
179186
R82-Surprise Blue
5
209
255
15
74
187194
R382-Congo Blue
5
0
200
13
3
195202
R83-Medium Blue
7
112
255
5
7
203210
R383-Sapphire Blue
4
108
255
3
4
211218
R90-Dk Yellow Green
4
255
0
5
3
219226
R91-Primary Green
27
255
6
0
20
227234
R92-Turquoise
7
255
21
70
76
235242
R93-Blue Green
7
255
31
85
115
243250
R393-Emerald Green
2
255
17
2
20
251255
000
000
000
000
000
Note: The colors above are simulated renditions of the color output produced as
compared to other similar incandescent products. Chauvet makes no guarantee of the
color output accuracy.

Ovation B-2805FC QRG EN
6
Preset Color
Temperature
Chart
DMX Channel
Value
Display Readout Red
Value
Green
Value
Blue
Value
Amber
Value
Lime
Value
000005
000
000
000
000
000
006025
2800K
255
51
18
255
255
026050
3200K
179
82
25
185
220
051075
3500K
255
130
33
255
240
076100
4000K
255
219
45
198
255
101125
4500K
140
255
55
255
255
126150
5000K
107
255
63
200
255
151175
5600K
82
255
72
190
230
176200
6000K
74
255
78
167
255
201225
6500K
65
255
84
140
255
226255
000
000
000
000
000
Note: The color temperatures above are simulated renditions of the color output
produced as compared to a tungsten lamp at the specified color temperature
. Chauvet
makes no guarantee of the color output accuracy.
Menu Map
Main Level
Programming Levels
Description
Protocol
DMX512
Selects the control protocol
ArtNet
sACN
Start Address 001–512*
Selects starting address (*highest
channel restricted to personality chosen)
Personality
1 Cell
DMX-VCW-CCT 3CH
3-channel: dimmer, virtual color wheel,
color temperature
RGB 3CH
3-channel: RGB
RGBA 4CH
4-channel: RGBA
RGBAL 5CH
5-channel: RGBAL
RGB EXT 8CH
8-channel: 16-bit dimmer, RGB, virtual
color wheel, color temperature, strobe
RGBA EXT 9CH
9-channel: 16-bit dimmer, RGBA, virtual
color wheel, color temperature, strobe
RGBAL EXT 10CH
10-channel: 16-bit dimmer, RGBAL,
virtual color wheel, color temperature,
strobe
RGBAL Fine 10CH
10-channel: 16-bit RGBAL
RGBAL FULL 17CH
17-channel: 16-bit dimmer, 16-bit
RGBAL, virtual color wheel, color
temperature, strobe, color macros,
dimmer mode
2 Cell
RGB 6CH
6-channel: RGB (per cell)
RGBA 8CH
8-channel: RGBA (per cell)
RGBAL 10CH
10-channel: RGBAL (per cell)
RGB EXT 15CH
15-channel: 16-bit dimmer, RGB (per
cell), virtual color wheel (per cell), color
temperature (per cell), strobe (per cell)

Ovation B-2805FC QRG EN
7
Main Level
Programming Levels
Description
Personality
(cont.)
2 Cell (cont.)
RGBA EXT 17CH
17-channel: 16-bit dimmer, RGBA (per
cell), virtual color wheel (per cell), color
temperature (per cell), strobe (per cell)
RGBAL EXT 19CH
19-channel: 16-bit dimmer, RGBAL (per
cell), virtual color wheel (per cell), color
temperature (per cell), strobe (per cell)
RGBAL Fine 20CH
20-channel: 16-bit RGBAL (per cell)
RGBAL FULL 31CH
31-channel: 16-bit dimmer, 16-bit
RGBAL (per cell), virtual color wheel
(per cell), color temperature (per cell),
strobe (per cell), color macros, dimmer
mode
5 Cell
RGB 15CH
15-channel: RGB (per cell)
RGBA 20CH
20-channel: RGBA (per cell)
RGBAL 25CH
25-channel: RGBAL (per cell)
RGB EXT 33CH
33-channel: 16-bit dimmer, RGB (per
cell), virtual color wheel (per cell), color
temperature (per cell), strobe (per cell)
RGBA EXT 38CH
38-channel: 16-bit dimmer, RGBA (per
cell), virtual color wheel (per cell), color
temperature (per cell), strobe (per cell)
RGBAL EXT 43CH
43-channel: 16-bit dimmer, RGBAL (per
cell), virtual color wheel (per cell), color
temperature (per cell), strobe (per cell)
RGBAL Fine 50CH
50-channel: 16-bit RGBAL (per cell)
RGBAL FULL 70CH
70-channel: 16-bit dimmer, 16-bit
RGBAL (per cell), virtual color wheel
(per cell), color temperature (per cell),
strobe (per cell), color macros, dimmer
mode
10 Cell
RGB 30CH
30-channel: RGB (per cell)
RGBA 40CH
40-channel: RGBA (per cell)
RGBAL 50CH
50-channel: RGBAL (per cell)
RGB EXT 63CH
63-channel: 16-bit dimmer, RGB (per
cell), virtual color wheel (per cell), color
temperature (per cell), strobe (per cell)
RGBA EXT 73CH
73-channel: 16-bit dimmer, RGBA (per
cell), virtual color wheel (per cell), color
temperature (per cell), strobe (per cell)
RGBAL EXT 83CH
83-channel: 16-bit dimmer, RGBAL (per
cell), virtual color wheel (per cell), color
temperature (per cell), strobe (per cell)

Ovation B-2805FC QRG EN
8
Main Level
Programming Levels
Description
Personality
(cont.) 10 Cell (cont.)
RGBAL Fine 100CH
100-channel: 16-bit RGBAL (per cell)
RGBAL FULL 135CH
135-channel: 16-bit dimmer, 16-bit
RGBAL (per cell), virtual color wheel
(per cell),
color temperature (per cell),
strobe (per cell), color macros,
dimmer mode
Virtual
Color
Wheel
Virtual
Color
Wheel
R4590-Cal90 Yellow
Dimmer <000–255>
Virtual Color Wheel simulates the
output of each gel color from Rosco.
Refer to the Virtual Color Wheel
Chart section for specific values.
R11-Light Straw
R312-Canary
R03-Dark BAmber
R18-Flame
R20-Medium Amber
R21-Golden Amber
R26-Light Red
R27-Medium Red
R33-NoColor Pink
R337-True Pink
R38-Light Rose
R41-Salmon
R42-Deep Salmon
R44-Middle Rose
R349-Fisher Fuchsia
R54-Special Lavender
R64-Light Steel Blue
R364-Blue Bell
R65-Daylight Blue
R80-Primary Blue
R81-Urban Blue
R82-Surprise Blue
R382-Congo Blue
R83-Medium Blue
R383-Sapphire Blue
R90-Dk Yellow Green
R91-Primary Green
R92-Turquoise
R93-Blue Green
R393-Emerald Green
Color
Temperature
2800K
Dimmer <000–255>
Preset white color temperatures.
Emulates a tungsten lamp at the
specified color temperature. Refer to
the Preset Color Temperature Chart
section for specific values.
3200K
3500K
4000K

Ovation B-2805FC QRG EN
9
Main Level
Programming Levels
Description
Virtual
Color Wheel
(cont.)
Color
Temperature
(cont.)
4500K
Dimmer <000–255>
Preset white color temperatures.
Emulates a tungsten lamp at the
specified color temperature. Refer to the
Preset Color Temperature Chart section
for specific values.
5000K
5600K
6000K
6500K
Manual Color Mixer
Red
<0–255> Combine red, green, blue, amber, and
lime to make a custom color (0–100%)
Green
Blue
Amber
Lime
Auto Show
Auto 1
Speed 1–100 Selects automatic programs and auto
program speed
Auto 2
Auto 3
Auto 4
Auto 5
Auto 6
Auto 7
Auto 8
Auto 9
Fade
Master/Slave
Master
Master mode
Slave
Slave mode
Dimmer
Mode
Off
Linear dimmer
Dimmer 1
Fast dimmer curve
Dimmer 2
Medium dimmer curve
Dimmer 3
Slow dimmer curve
White
Balance
Off
Uses factory default white setting
Manual
Red
125–255
Sets red LED maximum value
Green
Sets green LED maximum value
Blue
Sets blue LED maximum value
Amber
Sets amber LED maximum value
Lime
Sets lime LED maximum value
LED
Frequency
600Hz
Selects the PWM output frequency
1200Hz
2000Hz
4000Hz
25KHz
Fan Mode
Auto Speed
Sets the fan to auto mode
On
Sets the fan to always on

Ovation B-2805FC QRG EN
10
Main Level
Programming Levels
Description
Display
Normal
Normal display orientation
Inverse
Inverted display
Back Light
On
Display backlight always on
10S
Turns off display backlight after 10 sec
of inactivity
20S
Turns off display backlight after 20 sec
of inactivity
30S
Turns off display backlight after 30 sec
of inactivity
Ethernet
Setting
Universe
1(DMX)
Sets universe for Art-Net™ or sACN
0–255 (Art-Net™)
1-256(sACN)
IP Address
_ _ _._ _ _._ _ _._ _ _
Sets IP address
Information
Fixture Hours
_ _ _ _
Shows total product hours
Version
V_._-V_ _
Shows installed software version
Device ID
_ _ _ _ _ _ _ _ _
Shows product device ID
UID:
_ _ _ _ _ _ _ _ _ _ _ _
Shows product UID
Factory
Setting
No
Reset to factory defaults
Yes

Ovation B-2805FC QRG EN
11
DMX Values
10-Cell Personalities
10-Cell
RGBAL
FULL
135CH
Channel
Function
Value
Percent/Setting
1
Dimmer
000255
0–100%
2
Dimmer Fine
000255
0–100%
3
Red 1
000255
0–100%
4
Red Fine 1
000255
0–100%
5
Green 1
000255
0–100%
6
Green Fine 1
000255
0–100%
7
Blue 1
000255
0–100%
8
Blue Fine 1
000255
0–100%
9
Amber 1
000255
0–100%
10
Amber Fine 1
000255
0–100%
11
Lime 1
000255
0–100%
12
Lime Fine 1
000255
0–100%
13
Virtual Color Wheel
1
000255
Refer to the Virtual Color Wheel Chart section
for specific values
14
Color Temperature
1
000255
Refer to the Preset Color Temperature Chart
section for specific values
15 Strobe 1
000010
No function
011255
Strobe, slow to fast
16
Red 2
000255
0–100%
17
Red Fine 2
000255
0–100%
18
Green 2
000255
0–100%
19
Green Fine 2
000255
0–100%
20
Blue 2
000255
0–100%
21
Blue Fine 2
000255
0–100%
22
Amber 2
000255
0–100%
23
Amber Fine 2
000255
0–100%
24
Lime 2
000255
0–100%
25
Lime Fine 2
000255
0–100%
26
Virtual Color Wheel
2
000255
Refer to the Virtual Color Wheel Chart section
for specific values
27
Color Temperature
2
000255
Refer to the Preset Color Temperature Chart
section for specific values
28 Strobe 2
000010
No function
011255
Strobe, slow to fast
29
Red 3
000255
0–100%
30
Red Fine 3
000255
0–100%
31
Green 3
000255
0–100%
32
Green Fine 3
000255
0–100%
33
Blue 3
000255
0–100%
34
Blue Fine 3
000255
0–100%
35
Amber 3
000255
0–100%
36
Amber Fine 3
000255
0–100%
37
Lime 3
000255
0–100%
38
Lime Fine 3
000255
0–100%

Ovation B-2805FC QRG EN
12
10-Cell
RGBAL
FULL
135CH
(cont.)
Channel
Function
Value
Percent/Setting
39
Virtual Color Wheel
3
000255
Refer to the Virtual Color Wheel Chart section
for specific values
40
Color Temperature
3
000255
Refer to the Preset Color Temperature Chart
section for specific values
41 Strobe 3
000010
No function
011255
Strobe, slow to fast
42
Red 4
000255
0–100%
43
Red Fine 4
000255
0–100%
44
Green 4
000255
0–100%
45
Green Fine 4
000255
0–100%
46
Blue 4
000255
0–100%
47
Blue Fine 4
000255
0–100%
48
Amber 4
000255
0–100%
49
Amber Fine 4
000255
0–100%
50
Lime 4
000255
0–100%
51
Lime Fine 4
000255
0–100%
52
Virtual Color Wheel
4
000255
Refer to the Virtual Color Wheel Chart section
for specific values
53
Color Temperature
4
000255
Refer to the Preset Color Temperature Chart
section for specific values
54 Strobe 4
000010
No function
011255
Strobe, slow to fast
55
Red 5
000255
0–100%
56
Red Fine 5
000255
0–100%
57
Green 5
000255
0–100%
58
Green Fine 5
000255
0–100%
59
Blue 5
000255
0–100%
60
Blue Fine 5
000255
0–100%
61
Amber 5
000255
0–100%
62
Amber Fine 5
000255
0–100%
63
Lime 5
000255
0–100%
64
Lime Fine 5
000255
0–100%
65
Virtual Color Wheel
5
000255
Refer to the Virtual Color Wheel Chart section
for specific values
66
Color Temperature
5
000255
Refer to the Preset Color Temperature Chart
section for specific values
67 Strobe 5
000010
No function
011255
Strobe, slow to fast
68
Red 6
000255
0–100%
69
Red Fine 6
000255
0–100%
70
Green 6
000255
0–100%
71
Green Fine 6
000255
0–100%
72
Blue 6
000255
0–100%
73
Blue Fine 6
000255
0–100%
74
Amber 6
000255
0–100%
75
Amber Fine 6
000255
0–100%
76
Lime 6
000255
0–100%

Ovation B-2805FC QRG EN
13
10-Cell
RGBAL
FULL
135CH
(cont.)
Channel
Function
Value
Percent/Setting
77
Lime Fine 6
000255
0–100%
78
Virtual Color Wheel
6
000255
Refer to the Virtual Color Wheel Chart section
for specific values
79
Color Temperature
6
000255
Refer to the Preset Color Temperature Chart
section for specific values
80 Strobe 6
000010
No function
011255
Strobe, slow to fast
81
Red 7
000255
0–100%
82
Red Fine 7
000255
0–100%
83
Green 7
000255
0–100%
84
Green Fine 7
000255
0–100%
85
Blue 7
000255
0–100%
86
Blue Fine 7
000255
0–100%
87
Amber 7
000255
0–100%
88
Amber Fine 7
000255
0–100%
89
Lime 7
000255
0–100%
90
Lime Fine 7
000255
0–100%
91
Virtual Color Wheel
7
000255
Refer to the Virtual Color Wheel Chart section
for specific values
92
Color Temperature
7
000255
Refer to the Preset Color Temperature Chart
section for specific values
93 Strobe 7
000010
No function
011255
Strobe, slow to fast
94
Red 8
000255
0–100%
95
Red Fine 8
000255
0–100%
96
Green 8
000255
0–100%
97
Green Fine 8
000255
0–100%
98
Blue 8
000255
0–100%
99
Blue Fine 8
000255
0–100%
100
Amber 8
000255
0–100%
101
Amber Fine 8
000255
0–100%
102
Lime 8
000255
0–100%
103
Lime Fine 8
000255
0–100%
104
Virtual Color Wheel
8
000255
Refer to the Virtual Color Wheel Chart section
for specific values
105
Color Temperature
8
000255
Refer to the Preset Color Temperature Chart
section for specific values
106 Strobe 8
000010
No function
011255
Strobe, slow to fast
107
Red 9
000255
0–100%
108
Red Fine 9
000255
0–100%
109
Green 9
000255
0–100%
110
Green Fine 9
000255
0–100%
111
Blue 9
000255
0–100%
112
Blue Fine 9
000255
0–100%
113
Amber 9
000255
0–100%
114
Amber Fine 9
000255
0–100%

Ovation B-2805FC QRG EN
14
10-Cell
RGBAL
FULL
135CH
(cont.)
Channel
Function
Value
Percent/Setting
115
Lime 9
000255
0–100%
116
Lime Fine 9
000255
0–100%
117
Virtual Color Wheel
9
000255
Refer to the Virtual Color Wheel Chart section
for specific values
118
Color Temperature
9
000255
Refer to the Preset Color Temperature Chart
section for specific values
119 Strobe 9
000010
No function
011255
Strobe, slow to fast
120
Red 10
000255
0–100%
121
Red Fine 10
000255
0–100%
122
Green 10
000255
0–100%
123
Green Fine 10
000255
0–100%
124
Blue 10
000255
0–100%
125
Blue Fine 10
000255
0–100%
126
Amber 10
000255
0–100%
127
Amber Fine 10
000255
0–100%
128
Lime 10
000255
0–100%
129
Lime Fine 10
000255
0–100%
130
Virtual Color Wheel
10
000255
Refer to the Virtual Color Wheel Chart section
for specific values
131
Color Temperature
10
000255
Refer to the Preset Color Temperature Chart
section for specific values
132 Strobe 10
000010
No function
011255
Strobe, slow to fast
133 Strobe All
000010
No function
011255
Strobe, slow to fast
134 Color Macros
000015
No function
016255
Color macros
135 Dimmer Speed
000051
Preset dimmer speed from display menu
052101
Dimmer speed mode off
102152
Dimmer speed mode 1 (fastest)
153203
Dimmer speed mode 2
204255
Dimmer speed mode 3 (slowest)
10-Cell
RGBAL
Fine
100CH
Channel
Function
Value
Percent/Setting
1
Red 1
000255
0–100%
2
Red Fine 1
000255
0–100%
3
Green 1
000255
0–100%
4
Green Fine 1
000255
0–100%
5
Blue 1
000255
0–100%
6
Blue Fine 1
000255
0–100%
7
Amber 1
000255
0–100%
8
Amber Fine 1
000255
0–100%
9
Lime 1
000255
0–100%
10
Lime Fine 1
000255
0–100%
11
Red 2
000255
0–100%

Ovation B-2805FC QRG EN
15
10-Cell
RGBAL
Fine
100CH
(cont.)
Channel
Function
Value
Percent/Setting
12
Red Fine 2
000255
0–100%
13
Green 2
000255
0–100%
14
Green Fine 2
000255
0–100%
15
Blue 2
000255
0–100%
16
Blue Fine 2
000255
0–100%
17
Amber 2
000255
0–100%
18
Amber Fine 2
000255
0–100%
19
Lime 2
000255
0–100%
20
Lime Fine 2
000255
0–100%
21
Red 3
000255
0–100%
22
Red Fine 3
000255
0–100%
23
Green 3
000255
0–100%
24
Green Fine 3
000255
0–100%
25
Blue 3
000255
0–100%
26
Blue Fine 3
000255
0–100%
27
Amber 3
000255
0–100%
28
Amber Fine 3
000255
0–100%
29
Lime 3
000255
0–100%
30
Lime Fine 3
000255
0–100%
31
Red 4
000255
0–100%
32
Red Fine 4
000255
0–100%
33
Green 4
000255
0–100%
34
Green Fine 4
000255
0–100%
35
Blue 4
000255
0–100%
36
Blue Fine 4
000255
0–100%
37
Amber 4
000255
0–100%
38
Amber Fine 4
000255
0–100%
39
Lime 4
000255
0–100%
40
Lime Fine 4
000255
0–100%
41
Red 5
000255
0–100%
42
Red Fine 5
000255
0–100%
43
Green 5
000255
0–100%
44
Green Fine 5
000255
0–100%
45
Blue 5
000255
0–100%
46
Blue Fine 5
000255
0–100%
47
Amber 5
000255
0–100%
48
Amber Fine 5
000255
0–100%
49
Lime 5
000255
0–100%
50
Lime Fine 5
000255
0–100%
51
Red 6
000255
0–100%
52
Red Fine 6
000255
0–100%
53
Green 6
000255
0–100%
54
Green Fine 6
000255
0–100%
55
Blue 6
000255
0–100%
56
Blue Fine 6
000255
0–100%
57
Amber 6
000255
0–100%

Ovation B-2805FC QRG EN
16
10-Cell
RGBAL
Fine
100CH
(cont.)
Channel
Function
Value
Percent/Setting
58
Amber Fine 6
000255
0–100%
59
Lime 6
000255
0–100%
60
Lime Fine 6
000255
0–100%
61
Red 7
000255
0–100%
62
Red Fine 7
000255
0–100%
63
Green 7
000255
0–100%
64
Green Fine 7
000255
0–100%
65
Blue 7
000255
0–100%
66
Blue Fine 7
000255
0–100%
67
Amber 7
000255
0–100%
68
Amber Fine 7
000255
0–100%
69
Lime 7
000255
0–100%
70
Lime Fine 7
000255
0–100%
71
Red 8
000255
0–100%
72
Red Fine 8
000255
0–100%
73
Green 8
000255
0–100%
74
Green Fine 8
000255
0–100%
75
Blue 8
000255
0–100%
76
Blue Fine 8
000255
0–100%
77
Amber 8
000255
0–100%
78
Amber Fine 8
000255
0–100%
79
Lime 8
000255
0–100%
80
Lime Fine 8
000255
0–100%
81
Red 9
000255
0–100%
82
Red Fine 9
000255
0–100%
83
Green 9
000255
0–100%
84
Green Fine 9
000255
0–100%
85
Blue 9
000255
0–100%
86
Blue Fine 9
000255
0–100%
87
Amber 9
000255
0–100%
88
Amber Fine 9
000255
0–100%
89
Lime 9
000255
0–100%
90
Lime Fine 9
000255
0–100%
91
Red 10
000255
0–100%
92
Red Fine 10
000255
0–100%
93
Green 10
000255
0–100%
94
Green Fine 10
000255
0–100%
95
Blue 10
000255
0–100%
96
Blue Fine 10
000255
0–100%
97
Amber 10
000255
0–100%
98
Amber Fine 10
000255
0–100%
99
Lime 10
000255
0–100%
100
Lime Fine 10
000255
0–100%

Ovation B-2805FC QRG EN
17
10-Cell
RGBAL
EXT
83CH
Channel
Function
Value
Percent/Setting
1
Dimmer
000255
0–100%
2
Dimmer Fine
000255
0–100%
3
Red 1
000255
0–100%
4
Green 1
000255
0–100%
5
Blue 1
000255
0–100%
6
Amber 1
000255
0–100%
7
Lime 1
000255
0–100%
8
Virtual Color Wheel
1
000255
Refer to the Virtual Color Wheel Chart section
for specific values
9
Color Temperature
1
000255
Refer to the Preset Color Temperature Chart
section for specific values
10 Strobe 1
000010
No function
011255
Strobe, slow to fast
11
Red 2
000255
0–100%
12
Green 2
000255
0–100%
13
Blue 2
000255
0–100%
14
Amber 2
000255
0–100%
15
Lime 2
000255
0–100%
16
Virtual Color Wheel
2
000255
Refer to the Virtual Color Wheel Chart section
for specific values
17
Color Temperature
2
000255
Refer to the Preset Color Temperature Chart
section for specific values
18 Strobe 2
000010
No function
011255
Strobe, slow to fast
19
Red 3
000255
0–100%
20
Green 3
000255
0–100%
21
Blue 3
000255
0–100%
22
Amber 3
000255
0–100%
23
Lime 3
000255
0–100%
24
Virtual Color Wheel
3
000255
Refer to the Virtual Color Wheel Chart section
for specific values
25
Color Temperature
3
000255
Refer to the Preset Color Temperature Chart
section for specific values
26 Strobe 3
000010
No function
011255
Strobe, slow to fast
27
Red 4
000255
0–100%
28
Green 4
000255
0–100%
29
Blue 4
000255
0–100%
30
Amber 4
000255
0–100%
31
Lime 4
000255
0–100%
32
Virtual Color Wheel
4
000255
Refer to the Virtual Color Wheel Chart section
for specific values
33
Color Temperature
4
000255
Refer to the Preset Color Temperature Chart
section for specific values
34 Strobe 4
000010
No function
011255
Strobe, slow to fast

Ovation B-2805FC QRG EN
18
10-Cell
RGBAL
EXT
83CH
(cont.)
Channel
Function
Value
Percent/Setting
35
Red 5
000255
0–100%
36
Green 5
000255
0–100%
37
Blue 5
000255
0–100%
38
Amber 5
000255
0–100%
39
Lime 5
000255
0–100%
40
Virtual Color Wheel
5
000255
Refer to the Virtual Color Wheel Chart section
for specific values
41
Color Temperature
5
000255
Refer to the Preset Color Temperature Chart
section for specific values
42 Strobe 5
000010
No function
011255
Strobe, slow to fast
43
Red 6
000255
0–100%
44
Green 6
000255
0–100%
48
Blue 6
000255
0–100%
46
Amber 6
000255
0–100%
47
Lime 6
000255
0–100%
48
Virtual Color Wheel
6
000255
Refer to the Virtual Color Wheel Chart section
for specific values
49
Color Temperature
6
000255
Refer to the Preset Color Temperature Chart
section for specific values
50 Strobe 6
000010
No function
011255
Strobe, slow to fast
51
Red 7
000255
0–100%
52
Green 7
000255
0–100%
53
Blue 7
000255
0–100%
54
Amber 7
000255
0–100%
55
Lime 7
000255
0–100%
56
Virtual Color Wheel
7
000255
Refer to the Virtual Color Wheel Chart section
for specific values
57
Color Temperature
7
000255
Refer to the Preset Color Temperature Chart
section for specific values
58 Strobe 7
000010
No function
011255
Strobe, slow to fast
59
Red 8
000255
0–100%
60
Green 8
000255
0–100%
61
Blue 8
000255
0–100%
62
Amber 8
000255
0–100%
63
Lime 8
000255
0–100%
64
Virtual Color Wheel
8
000255
Refer to the Virtual Color Wheel Chart section
for specific values
65
Color Temperature
8
000255
Refer to the Preset Color Temperature Chart
section for specific values
66 Strobe 8
000010
No function
011255
Strobe, slow to fast
67
Red 9
000255
0–100%
68
Green 9
000255
0–100%
69
Blue 9
000255
0–100%

Ovation B-2805FC QRG EN
19
10-Cell
RGBAL
EXT
83CH
(cont.)
Channel
Function
Value
Percent/Setting
70
Amber 9
000255
0–100%
71
Lime 9
000255
0–100%
72
Virtual Color Wheel
9
000255
Refer to the Virtual Color Wheel Chart section
for specific values
73
Color Temperature
9
000255
Refer to the Preset Color Temperature Chart
section for specific values
74 Strobe 9
000010
No function
011255
Strobe, slow to fast
75
Red 10
000255
0–100%
76
Green 10
000255
0–100%
77
Blue 10
000255
0–100%
78
Amber 10
000255
0–100%
79
Lime 10
000255
0–100%
80
Virtual Color Wheel
10
000255
Refer to the Virtual Color Wheel Chart section
for specific values
81
Color Temperature
10
000255
Refer to the Preset Color Temperature Chart
section for specific values
82 Strobe 10
000010
No function
011255
Strobe, slow to fast
83 Strobe All
000010
No function
011255
Strobe, slow to fast
10-Cell
RGBA
EXT
73CH
Channel
Function
Value
Percent/Setting
1
Dimmer
000255
0–100%
2
Dimmer Fine
000255
0–100%
3
Red 1
000255
0–100%
4
Green 1
000255
0–100%
5
Blue 1
000255
0–100%
6
Amber 1
000255
0–100%
7
Virtual Color Wheel
1
000255
Refer to the Virtual Color Wheel Chart section
for specific values
8
Color Temperature
1
000255
Refer to the Preset Color Temperature Chart
section for specific values
9 Strobe 1
000010
No function
011255
Strobe, slow to fast
10
Red 2
000255
0–100%
11
Green 2
000255
0–100%
12
Blue 2
000255
0–100%
13
Amber 2
000255
0–100%
14
Virtual Color Wheel
2
000255
Refer to the Virtual Color Wheel Chart section
for specific values
15
Color Temperature
2
000255
Refer to the Preset Color Temperature Chart
section for specific values
16 Strobe 2
000010
No function
011255
Strobe, slow to fast
17
Red 3
000255
0–100%
18
Green 3
000255
0–100%

Ovation B-2805FC QRG EN
20
10-Cell
RGBA
EXT
73CH
(cont.)
Channel
Function
Value
Percent/Setting
19
Blue 3
000255
0–100%
20
Amber 3
000255
0–100%
21
Virtual Color Wheel
3
000255
Refer to the Virtual Color Wheel Chart section
for specific values
22
Color Temperature
3
000255
Refer to the Preset Color Temperature Chart
section for specific values
23 Strobe 3
000010
No function
011255
Strobe, slow to fast
24
Red 4
000255
0–100%
25
Green 4
000255
0–100%
26
Blue 4
000255
0–100%
27
Amber 4
000255
0–100%
28
Virtual Color Wheel
4
000255
Refer to the Virtual Color Wheel Chart section
for specific values
29
Color Temperature
4
000255
Refer to the Preset Color Temperature Chart
section for specific values
30 Strobe 4
000010
No function
011255
Strobe, slow to fast
31
Red 5
000255
0–100%
32
Green 5
000255
0–100%
33
Blue 5
000255
0–100%
34
Amber 5
000255
0–100%
35
Virtual Color Wheel
5
000255
Refer to the Virtual Color Wheel Chart section
for specific values
36
Color Temperature
5
000255
Refer to the Preset Color Temperature Chart
section for specific values
37 Strobe 5
000010
No function
011255
Strobe, slow to fast
38
Red 6
000255
0–100%
39
Green 6
000255
0–100%
40
Blue 6
000255
0–100%
41
Amber 6
000255
0–100%
42
Virtual Color Wheel
6
000255
Refer to the Virtual Color Wheel Chart section
for specific values
43
Color Temperature
6
000255
Refer to the Preset Color Temperature Chart
section for specific values
44 Strobe 6
000010
No function
011255
Strobe, slow to fast
45
Red 7
000255
0–100%
46
Green 7
000255
0–100%
47
Blue 7
000255
0–100%
48
Amber 7
000255
0–100%
49
Virtual Color Wheel
7
000255
Refer to the Virtual Color Wheel Chart section
for specific values
50
Color Temperature
7
000255
Refer to the Preset Color Temperature Chart
section for specific values
