Chauvet Professional STRIKE Array 4C User manual

Model ID: STRIKEARRAY4C
User Manual

STRIKE Array 4C User Manual Rev. 1
Edition Notes
The STRIKE Array 4C User Manual includes a description, safety precautions, installation, programming,
operation, and maintenance instructions for the STRIKE Array 4C as of the release date of this edition.
Trademarks
Chauvet, Chauvet Professional, the Chauvet logo, and STRIKE are registered trademarks or trademarks
of Chauvet & Sons, LLC (d/b/a Chauvet and Chauvet Lighting) in the United States and other countries.
Other company and product names and logos referred to herein may be trademarks of their respective
companies.
Copyright Notice
The works of authorship contained in this manual, including, but not limited to, all designs, text, and images
are owned by Chauvet.
© Copyright 2024 Chauvet & Sons, LLC. All rights reserved.
Electronically published by Chauvet in the United States of America.
Manual Use
Chauvet authorizes its customers to download and print this manual for professional information purposes
only. Chauvet expressly prohibits the usage, copy, storage, distribution, modification, or printing of this
manual or its content for any other purpose without written consent from Chauvet.
Document Printing
For best results, print this document in color, on letter size paper (8.5 x 11 in), double-sided. If using A4
paper (210 x 297 mm), configure the printer to scale the content accordingly.
Intended Audience
Any person installing, operating, and/or maintaining this product should completely read through the guide
that shipped with the product, as well as this manual, before installing, operating, or maintaining this
product.
Disclaimer
Chauvet believes that the information contained in this manual is accurate in all respects. However,
Chauvet assumes no responsibility and specifically disclaims any and all liability to any party for any loss,
damage or disruption caused by any errors or omissions in this document, whether such errors or
omissions result from negligence, accident, or any other cause. Chauvet reserves the right to revise the
content of this document without any obligation to notify any person or company of such revision, however,
Chauvet has no obligation to make, and does not commit to make, any such revisions. Download the latest
version from www.chauvetprofessional.com.
Document Revision
Go to www.chauvetprofessional.com for the latest version.
Revision Date Description
1 01/2024 Initial release.

STRIKE Array 4C User Manual Rev. 1
Table of Contents
i
TABLE OF CONTENTS
1. Before You Begin ....................................................................... 1
What Is Included ........................................................................................... 1
Claims ........................................................................................................... 1
Text Conventions .......................................................................................... 1
Symbols ........................................................................................................ 1
Safety Notes.................................................................................................. 2
FCC Statement of Compliance ..................................................................... 3
Expected LED Lifespan................................................................................. 3
2. Introduction ................................................................................ 4
Description .................................................................................................... 4
Features........................................................................................................ 4
Product Overview.......................................................................................... 4
Product Dimensions ...................................................................................... 5
3. Setup ........................................................................................... 6
AC Power...................................................................................................... 6
AC Plug .............................................................................................................. 6
USB Software Update ................................................................................... 6
Signal Connections ....................................................................................... 7
Control Personalities .......................................................................................... 7
DMX Linking....................................................................................................... 7
Remote Device Management .................................................................................. 7
Art-Net™ Connection ......................................................................................... 7
sACN Connection............................................................................................... 7
Ethernet Connection Diagram............................................................................ 7
Mounting ....................................................................................................... 8
Orientation.......................................................................................................... 8
Rigging ............................................................................................................... 8
Procedure........................................................................................................... 8
Mounting Diagram.............................................................................................. 8
Multi-Product Mounting ...................................................................................... 9
Multi-Product Mounting Diagram ............................................................................. 9
Mounting Products Attached in Series .................................................................... 10
Vertical Mounting Stability ....................................................................................... 11
4. Operation .................................................................................... 12
Control Panel Description ............................................................................. 12
Programming................................................................................................. 12
Passcode ...................................................................................................... 12
Menu Map ..................................................................................................... 12
Control Configuration .................................................................................... 15
Control Mode...................................................................................................... 15
Control Personalities .......................................................................................... 15
Starting Address................................................................................................. 16
Ethernet Settings................................................................................................ 16
IP Mode ................................................................................................................... 16
Universe .................................................................................................................. 16
Start Channel........................................................................................................... 16
IP Address ............................................................................................................... 16

Table of Contents
STRIKE Array 4C User Manual Rev. 1
ii
Ethernet to DMX ...................................................................................................... 16
Virtual Color Wheel ....................................................................................... 17
Virtual Color Wheel Chart .................................................................................. 17
Color Temperature Chart ................................................................................... 18
DMX Channel Assignments and Values ....................................................... 18
Control Chart...................................................................................................... 18
22Ch................................................................................................................... 18
16Ch / 13Ch / 12Ch / 10Ch / 7Ch / 5Ch / 3Ch ................................................... 19
HSV.................................................................................................................... 19
1Ch..................................................................................................................... 19
Standalone Configuration.............................................................................. 20
Static Mode ........................................................................................................ 20
Virtual Color Wheel.................................................................................................. 20
Color Temperature .................................................................................................. 20
Manual Color Mixer ................................................................................................. 20
Color X-Fade Speed .......................................................................................... 20
Auto Show.......................................................................................................... 20
Settings Configuration................................................................................... 20
Red Shift ............................................................................................................ 20
Master/Slave ...................................................................................................... 20
Dimmer Curve .................................................................................................... 20
Dimmer Speed Mode ......................................................................................... 21
Color Calibration ................................................................................................ 21
Pulse Width Modulation ..................................................................................... 21
Display Invert ..................................................................................................... 21
Fan Mode ........................................................................................................... 21
Display Backlight................................................................................................ 21
Key Lock ............................................................................................................ 21
Information ......................................................................................................... 21
Temperature....................................................................................................... 21
Factory Reset..................................................................................................... 21
Web Server ................................................................................................... 22
Home.................................................................................................................. 22
Settings .............................................................................................................. 22
Output ................................................................................................................ 22
Security .............................................................................................................. 22
5. Maintenance................................................................................ 23
Product Maintenance .................................................................................... 23
Torque Measurements.................................................................................. 23
Vacuum Test Measurements ........................................................................ 23
6. Technical Specifications ........................................................... 24
Contact Us ...................................................................................... 25
Warranty & Returns....................................................................................... 25

1
STRIKE Array 4C User Manual Rev. 1
Before You Begin
1. Before You Begin
What Is Included
Claims
Carefully unpack the product immediately and check the container to make sure all the parts are in the
package and are in good condition.
If the box or the contents (the product and included accessories) appear damaged from shipping, or show
signs of mishandling, notify the carrier immediately, not Chauvet. Failure to report damage to the carrier
immediately may invalidate a claim. In addition, keep the box and contents for inspection.
For other issues, such as missing components or parts, damage not related to shipping, or concealed
damage, file a claim with Chauvet within 7 days of delivery.
Text Conventions
Symbols
• STRIKE Array 4C
• Seetronic Powerkon IP65 power cable
• Omega bracket with mounting hardware
• Quick Reference Guide
Convention Meaning
1–512 A range of values
50/60 A set of values of which only one can be chosen
Settings A menu option not to be modified
<ENTER> A key to be pressed on the product’s control panel
Symbol Meaning
Critical installation, configuration, or operation information. Not following these
instructions may make the product not work, cause damage to the product, or cause
harm to the operator.
Important installation or configuration information. The product may not function correctly
if this information is not used.
Useful information.
Any reference to data or power connections in this manual assumes the use of Seetronic
IP rated cables.
The term “DMX” used throughout this manual refers to the USITT DMX512-A digital data
transmission protocol.

2
Before You Begin
STRIKE Array 4C User Manual Rev. 1
Safety Notes
Read all the following safety notes before working with this product. These notes contain important
information about the installation, usage, and maintenance of this product.
• The luminaire is intended for professional use only.
• The luminaire should be positioned so that prolonged staring into the luminaire at a distance closer
than 7.5 ft (2.3 m) is not expected.
• If the external flexible cable or cord of this luminaire is damaged, it shall be replaced by a special
cord or cord exclusively available from the manufacturer or its service agent.
• The light source contained in this luminaire shall only be replaced by the manufacturer or its service
agent or a similar qualified person.
• CAUTION:
• This product’s housing may be hot when operating. Mount this product in a location with
adequate ventilation, at least 20 in (50 cm) from adjacent surfaces.
• When transferring the product from extreme temperature environments, (e.g., cold truck to
warm humid ballroom) condensation may form on the internal electronics of the product. To
avoid causing a failure, allow the product to fully acclimate to the surrounding environment
before connecting it to power.
• Flashing light is known to trigger epileptic seizures. User must comply with local laws regarding
notification of strobe use.
• ALWAYS:
• Disconnect from power before cleaning the product.
• When using an IP65-rated product in an outdoor environment, use IP65- (or higher) rated power
and data cable.
• Replace and secure IP-rated protective covers to all power, data, USB, or other ports when not
in use.
• Use a safety cable when mounting this product overhead.
• Connect this product to a grounded and protected circuit.
•DONOT:
• Open this product. It contains no user-serviceable parts.
• Look at the light source when the product is on.
• Leave any flammable material within 1 m of this product while operating or connected to power.
• Connect this product to a dimmer or rheostat.
• Operate this product if the housing, lenses, or cables appear damaged.
• Submerge this product (adhere to standards for the published IP rating). Regular outdoor
operation is fine.
• Permanently install outdoors in locations with extreme environmental conditions. This includes,
but is not limited to:
• Exposure to a marine/saline environment (within 3 miles of a saltwater body of water).
• Locations where normal temperatures exceed the temperature ranges in this manual.
• Locations that are prone to flooding or being buried in snow.
• Other areas where the product will be subject to extreme radiation or caustic substances.
• ONLY use the hanging/mounting bracket to carry this product.
• The maximum ambient temperature is 113 °F (45 °C). Do not operate this product at higher temperatures.
• The minimum startup temperature is -4°F (-20°C). Do not start the product at lower temperatures.
• The minimum ambient temperature is -22°F (-30°C). Do not operate the product at lower temperatures.
• To eliminate unnecessary wear and improve its lifespan, during periods of non-use completely
disconnect the product from power via breaker or by unplugging it.
• In the event of a serious operating problem, stop using immediately.
This product contains no user-serviceable parts. Any reference to servicing in this User
Manual will only apply to properly trained, certified technicians. Do not open the housing
or attempt any repairs.
All applicable local codes and regulations apply to proper installation of this product.
If this Chauvet product requires service, contact Chauvet Technical Support.

3
STRIKE Array 4C User Manual Rev. 1
Before You Begin
FCC Statement of Compliance
This device complies with Part 15 Part B of the FCC rules. Operation is subject to the following two conditions:
1. This device may not cause harmful interference, and
2. This device must accept any interference received, including interference that may cause
undesired operation.
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant
to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the interference by
one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Any changes or modifications not expressly approved by the party responsible for compliance could void
the user’s authority to operate the equipment.
Expected LED Lifespan
Over time, use and heat will gradually reduce LED brightness. Clustered LEDs produce more heat than
single LEDs, contributing to shorter lifespans if always used at full intensity. The average LED lifespan is
40,000 to 50,000 hours. To extend LED lifespan, maintain proper ventilation around the product, and limit
the overall intensity.

4
Introduction
STRIKE Array 4C User Manual Rev. 1
2. Introduction
Description
The STRIKE Array 4C is an IP65-rated audience blinder with four independently focusable pods. Intense
RGBA-WW LED output delivers a full range of color as well as a wide choice of white color temperatures
with exceptional color rendering. Industry leading low end dimming performance includes Red Shift which
warms the color temperature of the output as it dims to emulate a classic tungsten look. Variable PWM and
high CRI make the product ideal for broadcast applications. A proprietary Tool-Free interlocking system
enables the STRIKE Array 4C to be interconnected easily with other STRIKE Array-series products for
scalable configurations. Omega-Bracket locks installed on both the yoke and the rear of the product
streamline the truss mounting process.
Features
• Intense 4 pod color blinder/strobe rated IP65 for all-weather use
• Full range of color and excellent rendition of any color temperature of white
• Emulated “red shift” to mimic incandescent fixtures perfectly
• Individual pan (or tilt depending on mount orientation) of each head to allow for directional
adjustment of light output
• Innovative interlocking system to connect multiple Strike Array family fixtures together
• Multiple mounting locations and re-positionable yoke with ¼ turn adapters for creative and
convenient rigging options
• Independent pod control and strobe functionality for high-impact effects on the fly
Product Overview
2
1
7
45
6
3
#Name
1Display
2Menu buttons
3Condensation valve
4Power in
5USB-C port
6Ethernet ports
7DMX in/out

5
STRIKE Array 4C User Manual Rev. 1
Introduction
Product Dimensions
0.51 in
13 mm
15.09 in
383.3 mm
16.70 in
424.21 mm
6.45 in
163.84 mm
8.10 in
205.84 mm
15.09 in
383.3 mm
19.17 in
487.2 mm
4.55 in
115.6 mm
16.65 in
423 mm
2.17 in
55 mm

6
Setup
STRIKE Array 4C User Manual Rev. 1
3. Setup
AC Power
The STRIKE Array 4C has an auto-ranging power supply and it can work with an input voltage range of
100 to 240 VAC, 50/60 Hz.
To determine the product’s power requirements (circuit breaker, power outlet, and wiring), use the current
value listed on the label affixed to the product’s back panel, or refer to the product’s specifications chart.
The listed current rating indicates the product’s average current draw under normal conditions.
AC Plug
The STRIKE Array 4C comes with a power input cable terminated with a Seetronic Powerkon A connector
on one end and an Edison plug on the other end (U.S. market). If the power cable which came with the
product has no plug, or if it is necessary to change the plug, use the table below to wire a plug.
USB Software Update
The STRIKE Array 4C allows for software update through USB using the built-in USB port. To update the
software using a USB flash drive, do the following:
1. Power on the product and plug the flash drive into the USB port.
2. Once the flash drive has been detected, the message “Upgrade Firmware” will be displayed.
Press <ENTER>. If a different message appears on the display, search for the updated software in
the menu (Update Firmware) and select from Only This Fixture, Multiple Fixture, or Other
Fixture Type. A list of the updated software files will be displayed.
3. Select the file that needs to be uploaded.
4. If the selected file is correct, the update will start. DO NOT turn off power or disconnect the USB
during the process. The USB update can take several minutes to complete.
5. When the update is complete, the product will automatically reboot.
6. Go to the Information level of the product main menu and confirm the firmware revision.
7. When the boot-up process is finished, restart the product manually.
• Always connect the product to a protected circuit (a circuit breaker or fuse). Ensure the
product has an appropriate electrical ground to avoid the risk of electrocution or fire.
• To eliminate unnecessary wear and improve its lifespan, during periods of non-use
completely disconnect the product from power via breaker or by unplugging it.
Never connect the product to a rheostat (variable resistor) or dimmer circuit, even if the
rheostat or dimmer channel serves only as a 0 to 100% switch.
Connection Wire (U.S.) Wire (Europe) Screw Color
AC Live Black Brown Yellow or Brass
AC Neutral White Blue Silver
AC Ground Green/Yellow Green/Yellow Green
• Be sure to select the correct file before pressing <ENTER>. DO NOT turn off the power or
disconnect the USB during the process. The USB update can take several minutes to
complete.
• If the selected file is incorrect, the upgrade will fail, and the display will go back to the
main interface. Repeat steps 1–3 using the correct file.
• Place the .chl file in the root directory of the USB drive.
• The product's USB port supports up to 32GB capacity and only works with FAT32 file
format.
Turning off the power, removing the USB, or not setting the fixture to the correct protocol
during the update can cause partial or total firmware failure in the targeted fixture(s).
Please refer to the Upload 25 Instructions to fix firmware failure issues.

7
STRIKE Array 4C User Manual Rev. 1
Setup
Signal Connections
The STRIKE Array 4C can receive a DMX, Art-Net™, or sACN signal. The product has 2 Seetronic
Etherkon through ports and 5-pin DMX in and out ports. If using other compatible products with this
product, it is possible to control each individually with a single controller.
Control Personalities
The STRIKE Array 4C uses a 5-pin DMX data connection, Art-Net™, or sACN for its 10 control
personalities, ranging from 1Ch to 22Ch.
• Refer to the Operation chapter to learn how to configure the STRIKE Array 4C to work in these
personalities.
•TheDMX Channel Assignments and Values section provides detailed information regarding the
control personalities.
DMX Linking
It is possible to link the STRIKE Array 4C to a DMX controller using a 5-pin DMX connection. For more
information about DMX, read the DMX primer at: https://www.chauvetprofessional.com/wp-content/
uploads/2016/06/DMX_Primer.pdf.
Remote Device Management
Remote Device Management, or RDM, is a standard for allowing DMX-enabled devices to communicate
bi-directionally along existing DMX cabling. Check the DMX controller’s User Manual or with the
manufacturer as not all DMX controllers have this capability. The STRIKE Array 4C supports RDM protocol
that allows feedback to make changes to menu map options.
Art-Net™ Connection
Art-Net™ is an Ethernet protocol that uses TCP/IP which transfers a large amount of DMX512 data using
an ethernet connection over a large network. An Art-Net™ protocol document is available from
www.chauvetprofessional.com.
Art-Net™ designed by and copyright Artistic Licence Holdings Ltd.
sACN Connection
Also known as ANSI E1.31, streaming ACN is an Ethernet protocol that uses the layering and formatting of
Architecture for Control Networks to transport DMX512 data over IP or any other ACN compatible network.
Ethernet Connection Diagram
For more information about DMX standards or the DMX cables needed to link this product
to a DMX controller, download the DMX Primer from the Chauvet website:
www.chauvetprofessional.com.
Computer/
controller
(running Art-Net™
or sACN protocol)
Switch or router
STRIKE Array 4C
To other Art-Net™
or sACN devices

8
Setup
STRIKE Array 4C User Manual Rev. 1
Mounting
Before mounting the product, read and follow the safety recommendations indicated in the Safety Notes.
Orientation
Always mount this product in a safe position, making sure there is adequate room for ventilation,
configuration, and maintenance.
Rigging
Chauvet recommends using the following general guidelines when mounting this product.
• Before deciding on a location for the product, make sure there is easy access to the product for
maintenance and programming purposes.
• Make sure that the structure and attachment points can support the weight before hanging the
product. See the Technical Specifications for weight information.
• When mounting the product overhead, always use a safety cable. Mount the product securely to a
rigging point, whether an elevated platform or a truss.
• When rigging the product onto a truss, use a mounting clamp of appropriate weight capacity.
Procedure
The STRIKE Array 4C comes with an Omega bracket. The user can directly attach a mounting clamp to
this Omega bracket. Make sure the clamp is capable of supporting the weight of this product. For the
Chauvet Professional line of mounting clamps, go to http://www.trusst.com/products.
Mounting Diagram
Safety
cable
Mounting
clamp
Omega
bracket
Mounting
clamp
Mounting
clamp
Omega
bracket
Safety
cable
Safety
cable

9
STRIKE Array 4C User Manual Rev. 1
Setup
Multi-Product Mounting
The STRIKE Array 4C has an interlocking system to connect multiple STRIKE Array 4C or
STRIKE Array 2C products together, vertically or horizontally.
Multi-Product Mounting Diagram
Latch button
Remove the retaining pins
to release the integrated
hanging hardware
Insert the retaining
pins to lock the
fixtures together
Insert the integrated
hanging hardware into the
opening of the next fixture
(vertically or horizontally)
Press and hold the latch
button to remove or
insert the retaining pins

10
Setup
STRIKE Array 4C User Manual Rev. 1
Mounting Products Attached in Series
• When using the omega bracket, never hang more than 16 cells vertically from a single
mounting point.
• When not using the omega bracket, never hang more than 8 cells vertically from a single
mounting point.
With Omega Bracket Without Omega Bracket
Attach the
safety cable
of the first
product to the
mounting
point
Each
STRIKE Array 4C
product is 4 cells
Up to
16 cells
Up to
8 cells
Attach the
safety cables
of the following
products to the
preceding
product

11
STRIKE Array 4C User Manual Rev. 1
Setup
Vertical Mounting Stability
When mounting products attached in series, use omega brackets in the back position to create a spine.
This will prevent any motion which may damage the products.
Omega
brackets
Mounting
clamps
Pole or pipe
for stability

12
Operation
STRIKE Array 4C User Manual Rev. 1
4. Operation
Control Panel Description
Programming
Refer to the Menu Map to understand the menu options. The menu map shows the main level and a
variable number of programming levels for each option.
• To go to the desired main level, press <MENU> repeatedly until the option shows on the display.
Press <ENTER> to select. This will enter the first programming level for that option.
• To select an option or value within the current programming level, press <UP> or <DOWN> until the
option shows on the display. Press <ENTER> to select. In this case, if there is another programming
level, that first option or the selected value will show on the display.
• Press <MENU> repeatedly to exit to the previous main level.
Passcode
After being prompted to enter the passcode, press <UP>, <DOWN>, <UP>, <DOWN>, <ENTER>.
Menu Map
Refer to the STRIKE Array 4C product page on www.chauvetprofessional.com for the latest menu map.
Button/Knob Function
<MENU> Exits from the current menu or function
<ENTER> Enables the currently displayed menu or sets the currently selected value into the
selected function
<UP> Navigates upwards through the menu list or increases the numeric value when in a
function
<DOWN> Navigates downwards through the menu list or decreases the numeric value when
in a function
Main Menu Programming Levels Description
Protocol
