User Manual

Ovation B-2805FC User Manual Rev. 10
EDITION NOTES
The Ovation B-2805FC User Manual includes a description, safety precautions, installation, programming,
operation and maintenance instructions for the Ovation B-2805FC as of the release date of this edition.
Trademarks
CHAUVET, the Chauvet logo and Ovation B-2805FC are registered trademarks or trademarks of Chauvet
& Sons, LLC (d/b/a Chauvet and Chauvet Lighting) in the United States and other countries. Other
company and product names and logos referred to herein may be trademarks of their respective
companies.
Copyright Notice
The works of authorship contained in this manual, including, but not limited to, all design, text and images
are owned by Chauvet.
© Copyright 2019 Chauvet & Sons, LLC. All rights reserved.
Electronically published by Chauvet in the United States of America.
Manual Use
Chauvet authorizes its customers to download and print this manual for professional information purposes
only. Chauvet expressly prohibits the usage, copy, storage, distribution, modification, or printing of this
manual or its content for any other purpose without written consent from Chauvet.
Document Printing
For best results, print this document in color, on letter size paper (8.5 x 11 in), double-sided. If using A4
paper (210 x 297 mm), configure the printer to scale the content accordingly.
Intended Audience
Any person installing, operating, and/or maintaining this product should completely read through the guide
that shipped with the product, as well as this manual, before installing, operating, or maintaining this
product.
Disclaimer
Chauvet believes that the information contained in this manual is accurate in all respects. However,
Chauvet assumes no responsibility and specifically disclaims any and all liability to any party for any loss,
damage or disruption caused by any errors or omissions in this document, whether such errors or
omissions result from negligence, accident or any other cause. Chauvet reserves the right to revise the
content of this document without any obligation to notify any person or company of such revision, however,
Chauvet has no obligation to make, and does not commit to make, any such revisions. Download the latest
version from www.chauvetprofessional.com.
FCC Compliance
This device complies with Part 15 Part B of the FCC Rules. Operation is subject to the following two
conditions:
1. This device may not cause harmful interference, and
2. This device must accept any interference received, including interference that may cause
undesired operation.
Any changes or modifications not expressly approved by the party responsible for compliance could void
the user's authority to operate the equipment.
Document Revision
This Ovation B-2805FC User Manual is the 10th edition of this document. Go to
www.chauvetprofessional.com for the latest version.

Ovation B-2805FC User Manual Rev. 10
TABLE OF CONTENTS
i
TABLE OF CONTENTS
1. Before You Begin ....................................................................... 1
What Is Included ........................................................................................... 1
Claims ........................................................................................................... 1
Manual Conventions ..................................................................................... 1
Symbols ........................................................................................................ 1
Safety Notes.................................................................................................. 2
Personal Safety.............................................................................................................. 2
Mounting and Rigging .................................................................................................... 2
Power and Wiring........................................................................................................... 2
Operation ...................................................................................................... 2
Expected LED Lifespan................................................................................. 2
2. Introduction ................................................................................ 3
Description .................................................................................................... 3
Features........................................................................................................ 3
Product Overview.......................................................................................... 3
Product Dimensions ...................................................................................... 4
3. Setup ........................................................................................... 5
AC Power...................................................................................................... 5
AC Plug .......................................................................................................................... 5
Power Linking................................................................................................................. 5
Signal Connections ....................................................................................... 5
DMX Connection ............................................................................................................ 5
Art-Net™ Connection ..................................................................................................... 5
sACN Connection........................................................................................................... 5
Connection Diagram ...................................................................................................... 6
Remote Device Management (RDM) ............................................................ 6
Master/Slave Connectivity............................................................................. 6
Mounting ....................................................................................................... 7
Orientation...................................................................................................................... 7
Rigging ........................................................................................................................... 7
Procedure....................................................................................................................... 7
Mounting diagram .................................................................................................... 7
4. Operation .................................................................................... 8
Control Panel Operation................................................................................ 8
Programming................................................................................................. 8
Menu Map ..................................................................................................... 8
Starting Address............................................................................................................. 12
DMX Values .................................................................................................. 13
10-Cell Personalities ...................................................................................................... 13
10-Cell RGBAL FULL 135CH .................................................................................. 13
10-Cell RGBAL Fine 100CH .................................................................................... 17
10-Cell RGBAL EXT 83CH ...................................................................................... 19
110-Cell RGBA EXT 73CH ...................................................................................... 21
10-Cell RGB EXT 63CH .......................................................................................... 23
10-Cell RGBAL 50CH .............................................................................................. 24
10-Cell RGBA 40CH ................................................................................................ 26
10-Cell RGB 30CH .................................................................................................. 27
10-Cell HSV 30CH................................................................................................... 28
5-Cell Personalities ........................................................................................................ 29
5-Cell RGBAL FULL 70CH ...................................................................................... 29

TABLE OF CONTENTS
Ovation B-2805FC User Manual Rev. 10
ii
5-Cell RGBAL Fine 50CH ........................................................................................ 31
5-Cell RGBAL EXT 43CH ........................................................................................ 32
5-Cell RGBA EXT 38CH .......................................................................................... 33
5-Cell RGB EXT 33CH ............................................................................................ 34
5-Cell RGBAL 25CH ............................................................................................... 35
5-Cell RGBA 20CH .................................................................................................. 35
5-Cell RGB 15CH .................................................................................................... 36
5-Cell HSV 15CH .................................................................................................... 36
2-Cell Personalities ........................................................................................................ 37
2-Cell RGBAL FULL 31CH ...................................................................................... 37
2-Cell RGBAL Fine 20CH ........................................................................................ 37
2-Cell RGBAL EXT 19CH ........................................................................................ 38
2-Cell RGBA EXT 17CH .......................................................................................... 39
2-Cell RGB EXT 15CH ............................................................................................ 39
2-Cell RGBAL 10CH ................................................................................................ 40
2-Cell RGBA 8CH .................................................................................................... 40
2-Cell RGB 6CH ...................................................................................................... 40
2-Cell HSV 6CH....................................................................................................... 40
1-Cell Personalities ........................................................................................................ 41
1-Cell RGBAL FULL 17CH ...................................................................................... 41
1-Cell RGBAL Fine 10CH ........................................................................................ 41
1-Cell RGBAL EXT 10CH ........................................................................................ 42
1-Cell RGBA EXT 9CH ............................................................................................ 42
1-Cell RGB EXT 8CH .............................................................................................. 42
1-Cell RGBAL 5CH .................................................................................................. 42
1-Cell RGBA 4CH .................................................................................................... 43
1-Cell RGB 3CH ...................................................................................................... 43
1-Cell DMX-VCW-CCT 3CH .................................................................................... 43
1-Cell HSV 3CH....................................................................................................... 43
Virtual Color Wheel ........................................................................................................ 44
Virtual color wheel chart .......................................................................................... 44
Preset color temperature chart ................................................................................ 44
Configuration (DMX/Art-Net™/sACN) ........................................................... 45
Control Protocol ............................................................................................................. 45
Ethernet Setting ............................................................................................................. 45
Universe .................................................................................................................. 45
IP Address ............................................................................................................... 45
Control Personalities ...................................................................................................... 45
Configuration (Standalone) ........................................................................... 46
Static Mode .................................................................................................................... 46
Virtual Color Wheel.................................................................................................. 46
Color Temperature .................................................................................................. 46
Manual Color Mixer ................................................................................................. 46
Auto Programs ............................................................................................................... 46
Configuration (Settings) ................................................................................ 47
Master/Slave .................................................................................................................. 47
Dimmer Profiles.............................................................................................................. 47
White Balance ................................................................................................................ 47
LED Frequency .............................................................................................................. 47
Fan Mode ....................................................................................................................... 47
Display Orientation......................................................................................................... 48
Back Light ...................................................................................................................... 48
System Information ........................................................................................................ 48
Factory Reset................................................................................................................. 48

Ovation B-2805FC User Manual Rev. 10
TABLE OF CONTENTS
iii
Web Server ................................................................................................... 48
Home.............................................................................................................................. 48
Settings .......................................................................................................................... 48
Output ............................................................................................................................ 48
Security .......................................................................................................................... 48
5. Technical Information ................................................................ 49
Product Maintenance .................................................................................... 49
6. Technical Specifications ........................................................... 50
Photometrics Chart ...................................................................................... 51
Returns............................................................................................ 52
Contact Us ...................................................................................... 53

Page 1 of 53
BEFORE YOU BEGIN
Ovation B-2805FC User Manual Rev. 10
1. Before You Begin
What Is Included
Claims
Carefully unpack the product immediately and check the container to make sure all the parts are in the
package and are in good condition.
If the box or the contents (the product and included accessories) appear damaged from shipping, or show
signs of mishandling, notify the carrier immediately, not Chauvet. Failure to report damage to the carrier
immediately may invalidate your claim. In addition, keep the box and contents for inspection.
For other issues, such as missing components or parts, damage not related to shipping, or concealed
damage, file a claim with Chauvet within 7 days of delivery.
Manual Conventions
Symbols
• Ovation B-2805FC
• Neutrik® powerCON® power cord
• Wall washing filter
• Quick Reference Guide
CONVENTION MEANING
1–512 A range of values
50/60 A set of values of which only one can be chosen
<SET> A button on the product’s control panel
Settings A product function or a menu option
SYMBOL MEANING
Electrical warning. Not following these instructions may cause electrical damage to
the product, accessories, or the user.
Critical installation, configuration, or operation information. Not following these
instructions may make the product not work, cause damage to the product, or cause
harm to the operator.
Important installation or configuration information. The product may not function
correctly if this information is not used.
Useful information.
Any reference to power connections in this manual assumes the use of Neutrik®
powerCON® cables.
The term “DMX” used throughout this manual refers to the USITT DMX512-A
digital data transmission protocol.
!
!

Page 2 of 53
Ovation B-2805FC User Manual Rev. 10
BEFORE YOU BEGIN
Safety Notes
Read all the following safety notes before working with this product. These notes contain important
information about the installation, usage, and maintenance of this product.
Personal Safety
• Avoid direct eye exposure to the light source while the product is on.
• Always disconnect the product from the power source before cleaning or replacing the fuse.
• Always connect the product to a grounded circuit to avoid the risk of electrocution.
• Do not touch the product’s housing when operating because it may be very hot.
Mounting and Rigging
• This product is not intended for permanent installation.
• This product is for indoor use only! To prevent risk of fire or shock, do not expose this product to
rain or moisture. (IP20)
• CAUTION: When transferring product from extreme temperature environments, (e.g. cold truck to
warm humid ballroom) condensation may form on the internal electronics of the product. To avoid
causing a failure, allow product to fully acclimate to the surrounding environment before connecting
it to power.
• Mount this product in a location with adequate ventilation, at least 20 in (50 cm) from adjacent
surfaces.
• Make sure there are no flammable materials close to this product while it is operating.
• When hanging this product, always secure to a fastening device using a safety cable.
• Never carry the product by the power cord.
Power and Wiring
• Make sure the power cord is not crimped or damaged.
• Always make sure you are connecting this product to the proper voltage in accordance with the
specifications in this manual or on the product’s specification label.
• To eliminate unnecessary wear and improve its lifespan, during periods of non-use completely
disconnect the product from power via breaker or by unplugging it.
• Never connect this product to a dimmer pack or rheostat.
• Make sure to replace the fuse with another of the same type and rating.
• Never disconnect this product by pulling or tugging on the power cable.
Operation
• Do not operate this product if there is damage on the housing, lenses, or cables. Have the damaged
parts replaced by an authorized technician at once.
• Do not cover the ventilation slots when operating to avoid internal overheating.
• The maximum ambient temperature is 113 °F (45 °C). Do not operate the product at higher temperatures.
• In the event of a serious operation problem, stop using this product immediately!
Expected LED Lifespan
LEDs gradually decline in brightness over time, primarily because of heat. LEDs that are arranged in
clusters experience higher operating temperatures than single LEDs. For this reason, operating clustered
LEDs at their fullest intensity significantly reduces the LEDs’ lifespan. Under normal conditions, this
lifespan is 40,000 to 50,000 hours. If extending this lifespan is vital, lower the operating temperature by
improving the ventilation around the product, thus reducing the ambient temperature. In addition, limiting
the overall projection intensity may extend the LEDs’ lifespan.
This product contains no user-serviceable parts. Any reference to servicing in
this User Manual will only apply to properly trained, certified technicians. Do not
open the housing or attempt any repairs.
All applicable local codes and regulations apply to proper installation of this
product.
If your Chauvet product requires service, contact Chauvet Technical Support.
!

Page 3 of 53
INTRODUCTION
Ovation B-2805FC User Manual Rev. 10
2. Introduction
Description
The Ovation B-2805FC is the first batten-style fixture to take advantage of the extended color capabilities of
the RGBA-Lime color mixing system. Control is easier than ever thanks to the incorporation of RDM,
Art-Net™, and sACN in addition to standard DMX control. For maximum flexibility, up to 10 sections can be
controlled individually whereas its easily accessible Virtual Color Wheel and Color Temperature presets make
programming a breeze. An included holographic filter locks into place for enhanced wall/cyc grazing ability.
Features
• Full-color LED (RGBAL) batten fixture for theatre, film, and production
• Theatre-ready lighting with 16-bit dimming of master dimmer and individual colors
• Multiple control personalities for complex programming schemes up to 10 sections of control
• Included holographic filter for use in cyc lighting or wall-grazing applications for ultra-smooth
color mixing
• Virtual Color Wheel with color matched to popular gel colors
• Art-Net™, sACN, 3- and 5-pin DMX, and RDM (Remote Device Management) for added
control flexibility
• Neutrik® powerCON®- and Amphenol etherCON®-compatible connections for power and
data linking
• Adjustable PWM (Pulse Width Modulation) to avoid flickering on camera
• Nearly silent operation for use in studio and theatre applications
Product Overview
DMX
in
Neutrik® powerCON® In
Menu buttonsFuse Display
Neutrik® powerCON® outAmphenol etherCON® through
DMX
out

Page 4 of 53
Ovation B-2805FC User Manual Rev. 10
INTRODUCTION
Product Dimensions
24.57 in
624 mm
54.84 in
1393 mm
50.91 in
1293 mm
7.2 in
183 mm
8.13 in
206.6 mm
26.94 in
684.4 mm
2.39 in
60.6 mm
53.27 in
1353 mm
5.06 in
128.6 mm
8.13 in
206.6 mm
8.26 in
210 mm
5.04 in
128 mm
69 in
1753 mm
1.85 in
47 mm
3.57 in
90.8 mm

Page 5 of 53
SETUP
Ovation B-2805FC User Manual Rev. 10
3. Setup
AC Power
Each Ovation B-2805FC has an auto-ranging power supply that works with an input voltage range of 100
to 240 VAC, 50/60 Hz. To determine the power requirements for each Ovation B-2805FC, refer to the label
affixed to the product. You can also refer to the Technical Specifications chart in this manual.
The listed current rating indicates the maximum current draw during normal operation. For more
information, download Sizing Circuit Breakers from the Chauvet website: www.chauvetprofessional.com..
AC Plug
The Ovation B-2805FC comes with a power input cord terminated with a Seetronic Powerkon A connector
on one end and an Edison plug on the other end (U.S. market). If the power input cord that came with your
product has no plug, or if you need the change the plug, use the table below to wire the new plug.
Power Linking
The product supports power linking. You can power link up to 2 products at 120 V; up to 3 at 208 V; or up
to 4 at 230 V. This product comes with a power input cord. Power linking cables are available from Chauvet
for purchase.
Signal Connections
The Ovation B-2805FC uses DMX, Art-Net™, or sACN for the 32 control personalities, ranging from 3-
channel to 135-channel. The Ovation B-2805FC has 2 Amphenol etherCON® through ports and both 3-
and 5-pin DMX in and out ports.
• Refer to the Operation chapter to learn how to configure the Ovation B-2805FC to work in these
personalities.
• The DMX Values section provides detailed information regarding the control personalities.
DMX Connection
You can link the Ovation B-2805FC to a DMX controller using a 3- or 5-pin DMX connection. If using other
DMX-compatible products with this product, you can control each individually with a single DMX controller.
Art-Net™ Connection
Art-Net™ is an Ethernet protocol that uses TCP/IP, which transfers a large amount of DMX512 data using
a Neutrik® etherCON® RJ45 connection over a large network. An Art-Net™ protocol document is
available from www.chauvetprofessional.com.
Art-Net™ designed by and copyright Artistic Licence Holdings Ltd.
sACN Connection
Also known as ANSI E1.31, streaming ACN is an Ethernet protocol that uses the layering and formatting of
Architecture for Control Networks to transport DMX512 data over IP or any other ACN compatible network.
ACN is maintained by the Professional Lighting and Sound Association (PLASA).
• Always connect the product to a protected circuit (circuit breaker or fuse). Make
sure the product has an appropriate electrical ground to avoid the risk of
electrocution or fire.
• To eliminate unnecessary wear and improve its lifespan, during periods of non-use
completely disconnect the product from power via breaker or by unplugging it.
Never connect the product to a rheostat (variable resistor) or dimmer circuit, even if
the rheostat or dimmer channel serves only as a 0 to 100% switch.
CONNECTION WIRE (U.S.) WIRE (EUROPE) SCREW COLOR
AC Live Black Brown Yellow or Brass
AC Neutral White Blue Silver
AC Ground Green/Yellow Green/Yellow Green
If you are not familiar with or need more information about DMX standards, Master/
Slave connectivity, or the DMX cables needed to link this product to a DMX
controller, download the DMX Primer from the Chauvet website:
www.chauvetprofessional.com.
!

Page 6 of 53
Ovation B-2805FC User Manual Rev. 10
SETUP
Connection Diagram
Remote Device Management (RDM)
Remote Device Management, or RDM, is a standard for allowing DMX-enabled devices to communicate
bi-directionally along existing DMX cabling. Check the DMX controller’s User Manual or with the
manufacturer as not all DMX controllers have this capability. The Ovation B-2805FC supports RDM
protocol that allows feedback to make changes to menu map options.
Master/Slave Connectivity
The Master/Slave mode allows an Ovation B-2805FC (the master) to control one or more Ovation B-
2805FC products (the slaves) without a DMX controller. One Ovation B-2805FC becomes the master
when running an auto program, or by being in Static mode.
You must configure each slave’s control panel to operate in Slave mode. During Master/Slave operation,
the slaves will operate in unison with the master.
DO NOT connect a DMX controller to products operating in Master/Slave mode. The
DMX controller signals may interfere with the signals from the master.
•The Operation section of this manual provides detailed instructions on how to
configure the master and slaves.
• If you are not familiar with or need more information about DMX standards, or the
DMX cables needed to link this product to a DMX controller, download the DMX
Primer from the Chauvet website: www.chauvetprofessional.com.
Switch or Router
(such as the NET-Switch
from CHAUVET Professional)
Computer/Controller
(running Art-Net™ or sACN
protocol)
To other Art-Net™ or
sACN devices
Ovation B-2805FC

Page 7 of 53
SETUP
Ovation B-2805FC User Manual Rev. 10
Mounting
Before mounting the product, read and follow the safety recommendations indicated in the Safety Notes.
For our CHAUVET Professional line of mounting clamps, go to http://trusst.com/products/.
Orientation
Always mount this product in a safe position, making sure there is adequate room for ventilation,
configuration, and maintenance.
Rigging
Chauvet recommends using the following general guidelines when mounting this product.
• Before deciding on a location for the product, make sure there is easy access to the product for
maintenance and programming purposes.
• Make sure that the structure onto which you are mounting the product can support the product’s
weight. See the Technical Specifications for weight information.
• When mounting the product overhead, always use a safety cable. Mount the product securely to a
rigging point, whether an elevated platform or a truss.
• When rigging the product onto a truss, use a mounting clamp of appropriate weight capacity.
• When power linking multiple products, mount the products close enough for power linking cables
to reach.
• The bracket adjustment knobs allow for directional adjustment when aiming the product to the desired
angle. Only loosen or tighten the bracket knobs manually. Using tools could damage the knobs.
Procedure
The Ovation B-2805FC has two threaded holes for mounting. You must supply the mounting clamps. Make
sure the clamps are capable of supporting the weight of this product. Use at least one mounting point per
product. For the CHAUVET Professional line of mounting clamps, go to http://www.trusst.com/products.
Mounting diagram
Mounting clamps
Threaded mounting hole
Safety cables
Floor stand

Page 8 of 53
Ovation B-2805FC User Manual Rev. 10
OPERATION
4. Operation
Control Panel Operation
Programming
Refer to the Menu Map to understand the menu options. The menu map shows the main level and a
variable number of programming levels for each option.
• To go to the desired main level, press <MENU> repeatedly until the option shows on the display.
Press <ENTER> to select. This will take you to the first programming level for that option.
• To select an option or value within the current programming level, press <UP> or <DOWN> until the
option shows on the display. Press <ENTER> to select. In this case, if there is another programming
level, you will see that first option, or you will see the selected value.
• Press <MENU> repeatedly to exit to the previous main level.
Menu Map
Button Function
<MENU> Exits from the current menu or function
<ENTER> Enables the currently displayed menu or sets the currently selected value in to the current
function
<UP> Navigates upward through the menu list or increases the numeric value when in a function
<DOWN> Navigates downward through the menu list or decreases the numeric value when in a function
Main Level Programming Levels Description
Protocol
DMX512
Selects the control protocol ArtNet
sACN
Start Address 001–512*
Selects starting address (*highest channel
restricted by selected personality)
Personality
1 Cell
DMX-VCW-CCT 3CH
3-channel: dimmer, virtual color wheel, color
temperature
HSV 3CH 3-channel: HSV
RGB 3CH 3-channel: RGB
RGBA 4CH 4-channel: RGBA
RGBAL 5CH 5-channel: RGBAL
RGB EXT 8CH
8-channel: 16-bit dimmer, RGB, virtual color
wheel, color temperature, strobe
RGBA EXT 9CH
9-channel: 16-bit dimmer, RGBA, virtual
color wheel, color temperature, strobe
RGBAL EXT 10CH
10-channel: 16-bit dimmer, RGBAL, virtual
color wheel, color temperature, strobe
RGBAL Fine 10CH 10-channel: 16-bit RGBAL
RGBAL FULL 17CH
17-channel: 16-bit dimmer, 16-bit RGBAL,
virtual color wheel, color temperature,
strobe, color macros, dimmer mode

Page 9 of 53
OPERATION
Ovation B-2805FC User Manual Rev. 10
Personality
(cont.)
2 Cell
RGB 6CH
6-channel: RGB (per cell)
HSV 6CH 6-channel: HSV (per cell)
RGBA 8CH 8-channel: RGBA (per cell)
RGBAL 10CH 10-channel: RGBAL (per cell)
RGB EXT 15CH
15-channel: 16-bit dimmer, RGB (per cell),
virtual color wheel (per cell),
color temperature (per cell), strobe (per cell)
RGBA EXT 17CH
17-channel: 16-bit dimmer, RGBA (per cell),
virtual color wheel (per cell),
color temperature (per cell), strobe (per cell)
RGBAL EXT 19CH
19-channel: 16-bit dimmer, RGBAL (per
cell), virtual color wheel (per cell),
color temperature (per cell), strobe (per cell)
RGBAL Fine 20CH 20-channel: 16-bit RGBAL (per cell)
RGBAL FULL 31CH
31-channel: 16-bit dimmer, 16-bit RGBAL
(per cell), virtual color wheel (per cell),
color temperature (per cell), strobe (per cell),
color macros, dimmer mode
5 Cell
RGB 15CH
15-channel: RGB (per cell)
HSV 15CH 15-channel: HSV (per cell)
RGBA 20CH 20-channel: RGBA (per cell)
RGBAL 25CH 25-channel: RGBAL (per cell)
RGB EXT 33CH
33-channel: 16-bit dimmer, RGB (per cell),
virtual color wheel (per cell),
color temperature (per cell), strobe (per cell)
RGBA EXT 38CH
38-channel: 16-bit dimmer, RGBA (per cell),
virtual color wheel (per cell),
color temperature (per cell), strobe (per cell)
RGBAL EXT 43CH
43-channel: 16-bit dimmer, RGBAL (per
cell), virtual color wheel (per cell),
color temperature (per cell), strobe (per cell)
RGBAL Fine 50CH 50-channel: 16-bit RGBAL (per cell)
RGBAL FULL 70CH
70-channel: 16-bit dimmer, 16-bit RGBAL
(per cell), virtual color wheel (per cell),
color temperature (per cell), strobe (per cell),
color macros, dimmer mode
10 Cell
RGB 30CH
30-channel: RGB (per cell)
HSV 30CH 30-channel: HSV (per cell)
RGBA 40CH 40-channel: RGBA (per cell)
RGBAL 50CH 50-channel: RGBAL (per cell)
RGB EXT 63CH
63-channel: 16-bit dimmer, RGB (per cell),
virtual color wheel (per cell), color
temperature (per cell), strobe (per cell)
RGBA EXT 73CH
73-channel: 16-bit dimmer, RGBA (per cell),
virtual color wheel (per cell), color
temperature (per cell), strobe (per cell)
RGBAL EXT 83CH
83-channel: 16-bit dimmer, RGBAL (per
cell), virtual color wheel (per cell),
color temperature (per cell), strobe (per cell)
RGBAL Fine 100CH 100-channel: 16-bit RGBAL (per cell)
RGBAL FULL 135CH
135-channel: 16-bit dimmer, 16-bit RGBAL
(per cell), virtual color wheel (per cell),
color temperature (per cell), strobe (per cell),
color macros, dimmer mode
Main Level Programming Levels Description

Page 10 of 53
Ovation B-2805FC User Manual Rev. 10
OPERATION
Main Level Programming Levels Description
Virtual Color
Wheel
Virtual Color
Wheel
C3050 - Md Yellow
Dimmer <000–255>
Virtual Color Wheel
simulates the output of
each gel color from
Rosco. Refer to the
Virtual color wheel
chart section for
specific values.
C3040 - Lt Yellow
C3240 - Amb Yellow
C2340 - VLt Amber
C2040 - Lt Amber
C2050 - Md Amber
C2060 - Dk Amber
C1050 - Lt Red
C1080 - Md Red
C1020 - NC Pink
C1030 - Md Pink
C1630 - Dk Pink
C1250 - Md Red Amber
C1060 - Dk Red Amber
C1650 - Magenta
C6170 - Dk Magenta
C6020 - Lt Lavender
C5030 - Lt Blue
C5020 - VLt Blue
C5430 - Lt Blue 2
C5070 - Blue
C5050 - Md Blue
C5060 - Dk Blue
C5690 - Indigo
C5080 - VDk Blue
C5081 - VDk Blue 2
C4370 - Yel Green
C4070 - Green
C4550 - Turquoise
C4560 - Aqua
C4570 - Blue Green
Color
Temperature
2800K
Dimmer <000–255>
Preset white color
temperatures.
Emulates a tungsten
lamp at the specified
color temperature.
Refer to the Preset
color temperature chart
section for specific
values.
3000K
3200K
3500K
4000K
4500K
5000K
5600K
6000K
6500K
Manual Color
Mixer
Red
<000–255>
Combine red, green,
blue, amber, and lime
to make a custom color
(0–100%)
Green
Blue
Amber
Lime

Page 11 of 53
OPERATION
Ovation B-2805FC User Manual Rev. 10
Main Level Programming Levels Description
Auto Show
Auto 1
Speed 1–100
Selects automatic programs and auto program
speed
Auto 2
Auto 3
Auto 4
Auto 5
Auto 6
Auto 7
Auto 8
Auto 9
Fade
Master/Slave Master
Master mode
Slave Slave mode
Dimmer Mode
Off
Linear dimmer
Dimmer 1 Fast dimmer curve
Dimmer 2 Medium dimmer curve
Dimmer 3 Slow dimmer curve
White Balance
Off
Uses factory default white setting
Manual
Red
125–255
Sets red LED maximum value
Green Sets green LED maximum value
Blue Sets blue LED maximum value
Amber Sets amber LED maximum value
Lime Sets lime LED maximum value
LED
Frequency
600Hz
Selects the PWM output frequency
1200Hz
2000Hz
4000Hz
6000Hz
25KHz
Fan Mode
Auto
Sets the fan to auto mode
On Sets the fan to always on
Off Sets the fan to always off
Silent Sets the fan to silent
Display Normal
Normal display orientation
Inverse Inverted display
Back Light
10S
Turns off display after 10 seconds of inactivity
30S Turns off display after 30 seconds of inactivity
2Min Turns off display after 2 minutes of inactivity
On Display backlight always on
Ethernet
Setting
Universe
1
(DMX)
Sets universe for Art-Net™ or sACN 0–255 (Art-Net™)
1-256 (sACN)
IP Address _ _ _._ _ _._ _ _._ _ _ Sets IP address
Information
Fixture Hours _ _ _ _
Shows total hour product has been powered
Version V_._-V_._ Shows installed software version
Device ID _ _ _ _ _ _ _ _ _ Shows product device ID
UID _ _ _ _ _ _ _ _ _ _ _ _ Shows product UID

Page 12 of 53
Ovation B-2805FC User Manual Rev. 10
OPERATION
Starting Address
Each product will respond to a unique starting address from the controller. All products with the same
starting address will respond in unison.
1. Go to the Start Address main level.
2. Select the starting address (001–512).
The highest recommended starting address for each DMX mode is as follows:
Factory
Setting
No
Reset to factory defaults
Yes
Personality Address Personality Address
1 Cell DMX-VCW-CCT 3CH 510 5 Cell RGB 15CH 498
1 Cell HSV 3CH 510 5 Cell HSV 15CH 498
1 Cell RGB 3CH 510 5 Cell RGBA 20CH 493
1 Cell RGBA 4CH 509 5 Cell RGBAL 25CH 488
1 Cell RGBAL 5CH 508 5 Cell RGB EXT 33CH 480
1 Cell RGB EXT 8CH 505 5 Cell RGBA EXT 38CH 475
1 Cell RGBA EXT 9CH 504 5 Cell RGBAL EXT 43CH 470
1 Cell RGBAL EXT 10CH 503 5 Cell RGBAL Fine 50CH 463
1 Cell RGBAL Fine 10CH 503 5 Cell RGBAL FULL 70CH 443
1 Cell RGBAL FULL 17CH 496 10 Cell RGB 30CH 483
2 Cell RGB 6CH 507 10 Cell HSV 30CH 483
2 Cell HSV 6CH 507 10 Cell RGBA 40CH 473
2 Cell RGBA 8CH 505 10 Cell RGBAL 50CH 463
2 Cell RGBAL 10CH 503 10 Cell RGB EXT 63CH 450
2 Cell RGB EXT 15CH 498 10 Cell RGBA EXT 73CH 440
2 Cell RGBA EXT 17CH 496 10 Cell RGBAL EXT 83CH 430
2 Cell RGBAL EXT 19CH 494 10 Cell RGBAL Fine 100CH 413
2 Cell RGBAL Fine 20CH 493
2 Cell RGBAL FULL 31CH 482
Main Level Programming Levels Description

Page 13 of 53
OPERATION
Ovation B-2805FC User Manual Rev. 10
DMX Values
10-Cell Personalities
10-Cell RGBAL FULL 135CH
Channel Function Value Percent/Setting
1 Dimmer 000  255 0–100%
2 Dimmer fine 000  255 0–100%
3 Red 1 000  255 0–100%
4 Red fine 1 000  255 0–100%
5 Green 1 000  255 0–100%
6 Green fine 1 000  255 0–100%
7 Blue 1 000  255 0–100%
8 Blue fine 1 000  255 0–100%
9 Amber 1 000  255 0–100%
10 Amber fine 1 000  255 0–100%
11 Lime 1 000  255 0–100%
12 Lime fine 1 000  255 0–100%
13 Virtual Color Wheel 1 000  255 Refer to the Virtual color wheel chart for specific values
14 Color Temperature 1 000  255 Refer to the Preset color temperature chart for specific values
15 Strobe 1 000
 010
011  255
No function
Strobe, slow to fast
16 Red 2 000  255 0–100%
17 Red fine 2 000  255 0–100%
18 Green 2 000  255 0–100%
19 Green fine 2 000  255 0–100%
20 Blue 2 000  255 0–100%
21 Blue fine 2 000  255 0–100%
22 Amber 2 000  255 0–100%
23 Amber fine 2 000  255 0–100%
24 Lime 2 000  255 0–100%
25 Lime fine 2 000  255 0–100%
26 Virtual Color Wheel 2 000  255 Refer to the Virtual color wheel chart for specific values
27 Color Temperature 2 000  255 Refer to the Preset color temperature chart for specific values
28 Strobe 2 000
 010
011  255
No function
Strobe, slow to fast
29 Red 3 000  255 0–100%
30 Red fine 3 000  255 0–100%
31 Green 3 000  255 0–100%
32 Green fine 3 000  255 0–100%
33 Blue 3 000  255 0–100%
34 Blue fine 3 000  255 0–100%
35 Amber 3 000  255 0–100%
36 Amber fine 3 000  255 0–100%
37 Lime 3 000  255 0–100%
38 Lime fine 3 000  255 0–100%
39 Virtual Color Wheel 3 000  255 Refer to the Virtual color wheel chart for specific values
40 Color Temperature 3 000  255 Refer to the Preset color temperature chart for specific values
41 Strobe 3 000
 010
011
 255
No function
Strobe, slow to fast

Page 14 of 53
Ovation B-2805FC User Manual Rev. 10
OPERATION
42 Red 4 000  255 0–100%
43 Red fine 4 000  255 0–100%
44 Green 4 000  255 0–100%
45 Green fine 4 000  255 0–100%
46 Blue 4 000  255 0–100%
47 Blue fine 4 000  255 0–100%
48 Amber 4 000  255 0–100%
49 Amber fine 4 000  255 0–100%
50 Lime 4 000  255 0–100%
51 Lime fine 4 000  255 0–100%
52 Virtual Color Wheel 4 000  255 Refer to the Virtual color wheel chart for specific values
53 Color Temperature 4 000  255 Refer to the Preset color temperature chart for specific values
54 Strobe 4 000
 010
011  255
No function
Strobe, slow to fast
55 Red 5 000  255 0–100%
56 Red fine 5 000  255 0–100%
57 Green 5 000  255 0–100%
58 Green fine 5 000  255 0–100%
59 Blue 5 000  255 0–100%
60 Blue fine 5 000  255 0–100%
61 Amber 5 000  255 0–100%
62 Amber fine 5 000  255 0–100%
63 Lime 5 000  255 0–100%
64 Lime fine 5 000  255 0–100%
65 Virtual Color Wheel 5 000  255 Refer to the Virtual color wheel chart for specific values
66 Color Temperature 5 000  255 Refer to the Preset color temperature chart for specific values
67 Strobe 5 000
 010
011
 255
No function
Strobe, slow to fast
68 Red 6 000  255 0–100%
69 Red fine 6 000  255 0–100%
70 Green 6 000  255 0–100%
71 Green fine 6 000  255 0–100%
72 Blue 6 000  255 0–100%
73 Blue fine 6 000  255 0–100%
74 Amber 6 000  255 0–100%
75 Amber fine 6 000  255 0–100%
76 Lime 6 000  255 0–100%
77 Lime fine 6 000  255 0–100%
78 Virtual Color Wheel 6 000  255 Refer to the Virtual color wheel chart for specific values
79 Color Temperature 6 000  255 Refer to the Preset color temperature chart for specific values
80 Strobe 6 000
 010
011  255
No function
Strobe, slow to fast
81 Red 7 000  255 0–100%
82 Red fine 7 000  255 0–100%
83 Green 7 000  255 0–100%
84 Green fine 7 000  255 0–100%
85 Blue 7 000  255 0–100%
Channel Function Value Percent/Setting

Page 15 of 53
OPERATION
Ovation B-2805FC User Manual Rev. 10
86 Blue fine 7 000  255 0–100%
87 Amber 7 000  255 0–100%
88 Amber fine 7 000  255 0–100%
89 Lime 7 000  255 0–100%
90 Lime fne 7 000  255 0–100%
91 Virtual Color Wheel 7 000  255 Refer to the Virtual color wheel chart for specific values
92 Color Temperature 7 000  255 Refer to the Preset color temperature chart for specific values
93 Strobe 7 000
 010 No function
011  255 Strobe, slow to fast
94 Red 8 000  255 0–100%
95 Red fine 8 000  255 0–100%
96 Green 8 000  255 0–100%
97 Green fine 8 000  255 0–100%
98 Blue 8 000  255 0–100%
99 Blue fine 8 000  255 0–100%
100 Amber 8 000  255 0–100%
101 Amber fine 8 000  255 0–100%
102 Lime 8 000  255 0–100%
103 Lime fine 8 000  255 0–100%
104 Virtual Color Wheel 8 000  255 Refer to the Virtual color wheel chart for specific values
105 Color Temperature 8 000  255 Refer to the Preset color temperature chart for specific values
106 Strobe 8 000
 010
011  255
No function
Strobe, slow to fast
107 Red 9 000  255 0–100%
108 Red fine 9 000  255 0–100%
109 Green 9 000  255 0–100%
110 Green fine 9 000  255 0–100%
111 Blue 9 000  255 0–100%
112 Blue fine 9 000  255 0–100%
113 Amber 9 000  255 0–100%
114 Amber fine 9 000  255 0–100%
115 Lime 9 000  255 0–100%
116 Lime fine 9 000  255 0–100%
117 Virtual Color Wheel 9 000  255 Refer to the Virtual color wheel chart for specific values
118 Color Temperature 9 000  255 Refer to the Preset color temperature chart for specific values
119 Strobe 9 000
 010
011
 255
No function
Strobe, slow to fast
120 Red 10 000  255 0–100%
121 Red fine 10 000  255 0–100%
122 Green 10 000  255 0–100%
123 Green fine 10 000  255 0–100%
124 Blue 10 000  255 0–100%
125 Blue fine 10 000  255 0–100%
126 Amber 10 000  255 0–100%
127 Amber fine 10 000  255 0–100%
128 Lime 10 000  255 0–100%
129 Lime fine 10 000  255 0–100%
Channel Function Value Percent/Setting
