QUICK REFERENCE GUIDE
Ovation B-1965FC QRG Rev. 3
About This Guide
The Ovation B-1965FC Quick Reference Guide (QRG) has basic product information such as connection, mounting,
menu options, and DMX values. Download the User Manual from www.chauvetprofessional.com for more details.
Disclaimer
The information and specifications contained in this QRG are subject to change without notice.
Safety Notes
These Safety Notes include important information about installation, use, and maintenance.
• DO NOT open this product. It contains no user-serviceable parts.
• DO NOT look at the light source when the product is on.
• To eliminate unnecessary wear and improve its lifespan, during periods of non-use completely disconnect the
product from power via breaker or by unplugging it.
• CAUTION: When transferring product from extreme temperature environments, (e.g. cold truck to warm humid
ballroom) condensation may form on the internal electronics of the product. To avoid causing a failure, allow
product to fully acclimate to the surrounding environment before connecting it to power.
• CAUTION: This product’s housing may be hot when lights are operating.
• Mount this product in a location with adequate ventilation, at least 20 in (50 cm) from adjacent surfaces.
• DO NOT leave any flammable material within 50 cm of this product while operating or connected to power.
• USE a safety cable when mounting this product overhead.
• DONOToperatethisproductoutdoorsorinanylocationwheredust,excessiveheat,water,orhumiditymayaffect
it. (IP20)
• DO NOT operate this product if the housing, lenses, or cables appear damaged.
• DO NOT connect this product to a dimmer or rheostat.
• ONLY connect this product to a grounded and protected circuit.
• ONLY use the hanging/mounting bracket or the handles to carry this product.
• In the event of a serious operating problem, stop using immediately.
• The maximum ambient temperature is 113 °F (45 °C). Do not operate this product at higher temperatures.
Contact
Outside the U.S., United Kingdom, Ireland, Mexico, or Benelux contact your distributor to request support or return a
product. Visit www.chauvetprofessional.com for contact information.
What is Included
• Ovation B-1965FC
• Neutrik® powerCON® power cord
• Wall Washing Filter
• Warranty Card
• Quick Reference Guide
AC Power
This product has an auto-ranging power supply that can work with an input voltage range of 100–240 VAC, 50/60 Hz.
Power Linking
You can link up to 3 Ovation B-1965FC products at 120 V, 6 products at 208 V, or 7 products at 230 V. Never exceed this
number. Power linking cords can be purchased separately.
AC Plug
Connection Wire (U.S.) Wire (Europe) Screw Color
AC Live Black Brown Yellow/Brass
AC Neutral White Blue Silver
AC Ground Green/Yellow Green/Yellow Green
To eliminate wear and improve its lifespan, during periods of non-use completely disconnect the
product from power via breaker or by unplugging it.
!

EN
2
Ovation B-1965FC QRG Rev. 3
QUICK REFERENCE GUIDE
Replacing the Fuse
1. Disconnect this product from power.
2. Using a Phillips #2 head screwdriver, unscrew the fuse holder cap from the housing.
3. Remove blown fuse and replace with a good fuse of the same type and rating.
4. Screw the fuse holder cap back in place and reconnect power.
Signal Connections
You can link the Ovation B-1965FC to a controller or controller software using a DMX connection or an Ethernet
connection. If using other Art-Net™ or sACN-compatible products with the Ovation B-1965FC, you can control each
individually on a single network. See the User Manual for information about how to connect and configure the product for
these signals.
Control Personalities
The Ovation B-1965FC uses DMX, Art-Net™, and sACN for its 17 control personalities, ranging from 3CH to 96CH in
1-cell modes and 7-cell modes:
DMX Connection
The Ovation B-1965FC will work with a DMX controller using a 3- or 5-pin DMX data connection. A DMX Primer is
available from www.chauvetprofessional.com.
Art-Net™ Connection
Art-Net™ is an Ethernet protocol that uses TCP/IP which transfers a large amount of DMX512 data using an Neutrik®
etherCON® RJ45 connection over a large network. An Art-Net™ protocol document is available from
www.chauvetprofessional.com. Chauvet Professional recommends using unicast Art-Net™ for best results.
Art-Net™ designed by and copyright Artistic Licence Holdings Ltd.
sACN Connection
Also known as ANSI E1.31, Streaming-ACN is an Ethernet protocol that uses the layering and formatting of Architecture
for Control Networks to transport DMX512 data over IP or any otherACN compatible network. ACN is maintained by the
Professional Lighting and Sound Association (PLASA).
Master/Slave Connection
The Ovation B-1965FC uses the DMX data connection for its Master/Slave mode. See the User Manual for information
about connect and configure the product for master/slave operation.
Mode 1-Cell 7-Cell
DMX-VCW-CCT 3 N/A
RGB 3 21
RGBA 4 28
RGBAL 5 35
RGB EXT 8 45
RGBA EXT 9 52
RGBAL EXT 10 59
RGBAL Fine 10 70
RGBAL FULL 17 96

3
EN
QUICK REFERENCE GUIDE
Ovation B-1965FC QRG Rev. 3
RDM (Remote Device Management)
Remote Device Management, or RDM, is a standard for allowing DMX-enabled devices to communicate bi-directionally
along existing DMX cabling. The Ovation B-1965FC supports RDM protocol that allows feedback to monitor temperature
and changes to DMX Address and DMX Channel menu options. Download the User Manual from
www.chauvetprofessional.com for more details.
Mounting
Before mounting this product, read the Safety Notes. Use at least two mounting points per product. Make sure the
mounting clamps are capable of supporting the weight of the product. For our CHAUVET Professional line of mounting
clamps, go to http://trusst.com/products.
Mounting Diagram
Web Server
The Ovation B-1965FC Web Server can be accessed by any computer on the same network as the product. It allows
network access to system information, settings such as control protocol and starting address, color output testing, and
the ability to change the Web Server password.
To access the Web Server:
1. Set the IP address of the network to have the same first digit as the IP address of the product.
2. Enter the IP address of the product into the URL bar of a web browser application.
3. Enter both the user name and password as admin to log in.
Control Panel Description
Button Function
<MENU> Exits from the current menu or function
<ENTER> Enables the currently displayed menu or sets the currently selected value into the selected function
<UP> Navigates upwards through the menu list and increases the numeric value when in a function
<DOWN> Navigates downwards through the menu list and decreases the numeric value when in a function
Safety Cable
Mounting Clamps
Secure the safety
cable using the
passageway on
the back of the
product

EN
4
Ovation B-1965FC QRG Rev. 3
QUICK REFERENCE GUIDE
Virtual Color Wheel
The Ovation B-1965FC includes a feature called the Virtual Color Wheel (VCW). This feature is available as a stand-
alone control mode for manual use and also as a control channel in select DMX personalities. Over 30 pre-mixed colors,
custom blended by our engineers, are available to call up for easier programming.
The DMX values used to mix these colors are provided below. You may adjust the overall intensity of the Ovation fixture
in order to more closely replicate colors you are familiar with. A chart is available on our website
www.chauvetprofessional.com to compare our pre-mixed colors with popular gel colors. This chart is for comparison
purposes only and is not a representation that our pre-mixed colors match any of the gel colors listed.
.Virtual Color Wheel Chart
DMX Channel Value Display Readout Red Value Green Value Blue Value Amber Value Lime Value
000 005
006 013
014 021
022 028
029 035
036 043
044 051
052 059
060 067
068 075
076 083
084 091
092 099
100 107
108 115
116 121
122 130
131 138
139 146
147 154
155 162
163 170
171 178
179 186
187 194
195 202
203 210
211 218
219 226
227 234
235 242
243 250
251 255
--
C3050 - Md Yellow
C3040 - Lt Yellow
C3240 - Amb Yellow
C2340 - VLt Amber
C2040 - Lt Amber
C2050 - Md Amber
C2060 - Dk Amber
C1050 - Lt Red
C1080 - Md Red
C1020 - NC Pink
C1030 - Md Pink
C1630 - Dk Pink
C1250 - Md Red Amber
C1060 - Dk Red Amber
C1650 - Magenta
C6170 - Dk Magenta
C6020 - Lt Lavender
C5030 - Lt Blue
C5020 - VLt Blue
C5430 - Lt Blue 2
C5070 - Blue
C5050 - Md Blue
C5060 - Dk Blue
C5690 - Indigo
C5080 - VDk Blue
C5081 - VDk Blue 2
C4370 - Yel Green
C4070 - Green
C4550 - Turquoise
C4560 - Aqua
C4570 - Blue Green
--
000
150
235
171
255
255
255
188
255
255
255
255
255
255
255
255
160
255
012
030
004
005
008
005
005
007
004
004
027
007
007
002
000
000
125
108
036
015
000
000
000
000
000
130
013
015
000
000
000
000
162
255
187
255
255
250
209
000
112
108
255
255
255
255
255
000
000
002
005
000
017
010
003
002
002
002
025
041
027
004
004
022
025
043
070
085
062
190
145
255
200
255
255
000
006
021
031
017
000
000
255
255
120
255
255
255
255
021
000
255
235
030
115
011
081
000
255
076
215
093
003
005
015
013
005
003
005
000
070
085
002
000
000
043
076
255
170
143
075
044
002
000
027
182
255
009
008
039
004
140
115
255
049
012
088
074
003
007
004
003
020
076
115
020
000
Note: The colors above are simulated renditions of the color output produced as compared to
other similar incandescent products. Chauvet makes no guarantee of the color output accuracy.

5
EN
QUICK REFERENCE GUIDE
Ovation B-1965FC QRG Rev. 3
Color Temperature Chart
Menu Map
DMX Channel Value Display Readout Red Value Green Value Blue Value Amber Value Lime Value
000 005
006 025
026 050
051 075
076 100
101 125
126 150
151 175
176 200
201 225
226 255
--
2800K
3200K
3500K
4000K
4500K
5000K
5600K
6000K
6500K
--
000
255
179
255
255
140
107
82
74
65
000
000
51
82
130
219
255
255
255
255
255
000
000
18
25
33
45
55
63
72
78
84
000
000
255
185
255
198
255
200
190
167
140
000
000
255
220
240
255
255
255
230
255
255
000
Note: The color temperatures above are simulated renditions of the color output produced as
compared to a tungsten lamp at the specified color temperature. Chauvet makes no guarantee of
the color output accuracy.
Main Level Programming Levels Description
Protocol DMX512 Selects the control protocolArtNet
sACN
Start Address 001–510* Selects starting address (*highest channel
restricted to personality chosen)
Personality
1-Cell
DMX-VCW-CCT 3CH 3-channel: dimmer, virtual color wheel, color
temperature
RGB 3CH 3-channel: RGB
RGBA 4CH 4-channel: RGBA
RGBAL 5CH 5-channel: RGBAL
RGB EXT 8CH 8-channel: 16-bit dimmer, RGB, virtual color
wheel, color temperature, strobe
RGBA EXT 9CH 9-channel: 16-bit dimmer, RGBA, virtual color
wheel, color temperature, strobe
RGBAL EXT 10CH 10-channel: 16-bit dimmer, RGBAL, virtual
color wheel, color temperature, strobe
RGBAL Fine 10CH 10-channel: 16-bit RGBAL
RGBAL FULL 17CH 17-channel: 16-bit dimmer, 16-bit RGBAL, virtual color wheel, color temperature, strobe,
color macros, dimmer mode
7-Cell
RGB 21CH 21-channel: RGB (per cell)
RGBA 28CH 28-channel: RGBA (per cell)
RGBAL 35CH 35-channel: RGBAL (per cell)
RGB EXT 45CH 45-channel: 16-bit dimmer, RGB (per cell), virtual color wheel (per cell), color
temperature (per cell), strobe (per cell)
RGBA EXT 52CH 52-channel: 16-bit dimmer, RGBA (per cell), virtual color wheel (per cell), color
temperature (per cell), strobe (per cell)
RGBAL EXT 59CH 59-channel: 16-bit dimmer, RGBAL (per cell), virtual color wheel (per cell), color
temperature (per cell), strobe (per cell)
RGBAL Fine 70CH 70-channel: 16-bit RGBAL (per cell)
RGBAL FULL 96CH 96-channel: 16-bit dimmer, 16-bit RGBAL
(per cell), virtual color wheel (per cell), color
temperature (per cell), strobe (per cell), color
macros, dimmer mode

EN
6
Ovation B-1965FC QRG Rev. 3
QUICK REFERENCE GUIDE
Main Level Programming Levels Description
Virtual Color
Wheel
Virtual
Color
Wheel
C3050 - Md Yellow
Dimmer
<000–255>
Virtual Color Wheel simulates the
output of each gel color. Refer to
the .Virtual Color Wheel Chart
section for specific values.
C3040 - Lt Yellow
C3240 - Amb Yellow
C2340 - VLt Amber
C2040 - Lt Amber
C2050 - Md Amber
C2060 - Dk Amber
C1050 - Lt Red
C1080 - Md Red
C1020 - NC Pink
C1030 - Md Pink
C1630 - Dk Pink
C1250 - Md Red Amber
C1060 - Dk Red Amber
C1650 - Magenta
C6170 - Dk Magenta
C6020 - Lt Lavender
C5030 - Lt Blue
C5020 - VLt Blue
C5430 - Lt Blue 2
C5070 - Blue
C5050 - Md Blue
C5060 - Dk Blue
C5690 - Indigo
C5080 - VDk Blue
C5081 - VDk Blue 2
C4370 - Yel Green
C4070 - Green
C4550 - Turquoise
C4560 - Aqua
C4570 - Blue Green
Color
Temperature
2800K
Preset white color temperatures.
Emulates a tungsten lamp at the
specified color temperature. Refer
to the Color Temperature Chart
section for specific values.
3200K
3500K
4000K
4500K
5000K
5600K
6000K
6500K
Manual Color Mixer
Red Combine red, green, blue, amber,
and lime to make a custom color
(0–100%)
Green
Blue
Amber
Lime
Auto Show
Auto 1
Speed 1–100 Selects automatic programs and
auto program speed
Auto 2
Auto 3
Auto 4
Auto 5
Auto 6
Auto 7
Auto 8
Auto 9
Fade

7
EN
QUICK REFERENCE GUIDE
Ovation B-1965FC QRG Rev. 3
Main Level Programming Levels Description
Master/Slave Master Master mode
Slave Slave mode
Dimmer Mode
Off Linear dimmer
Dimmer 1 Fast dimmer curve
Dimmer 2 Medium dimmer curve
Dimmer 3 Slow dimmer curve
White Balance
Off Uses factory default white setting
Manual
Red
125–255
Sets red LED maximum value
Green Sets green LED maximum value
Blue Sets blue LED maximum value
Amber Sets amber LED maximum value
Lime Sets lime LED maximum value
LED Frequency
600Hz
Selects the PWM output frequency
1200Hz
2000Hz
4000Hz
6000Hz
25KHz
Fan Mode Auto Speed Sets the fan to auto mode On Sets the fan to always on
Off Sets the fan to always off
Display Normal Normal display orientation
Inverted Inverted display
Back Light
On Display backlight always on
10S Turns off display backlight after 10 sec of
inactivity
20S Turns off display backlight after 20 sec of
inactivity
30S Turns off display backlight after 30 sec of
inactivity
Ethernet
Setting Universe 1 (DMX) Sets universe for Art-Net™ or sACN0–255 (Art-Net™)
1–256 (sACN)
IP Address _ _ _._ _ _._ _ _._ _ _ Sets IP address
Information
Fixture Hours _ _ _ _ Shows total product hours
Version V_._-V_ _ Shows installed software version
Device ID _ _ _ _ _ _ _ _ _ Shows product device ID
UID: _ _ _ _ _ _ _ _ _ _ _ _ Shows product UID
Factory Setting No Reset to factory defaults
Yes

EN
8
Ovation B-1965FC QRG Rev. 3
QUICK REFERENCE GUIDE
DMX Values
7-Cell Personalities
7-Cell RGBAL FULL 96CH
Channel Function Value Percent/Setting
1 Dimmer 000 255 0–100%
2 Dimmer Fine 000 255 0–100%
3 Red 1 000 255 0–100%
4 Red Fine 1 000 255 0–100%
5 Green 1 000 255 0–100%
6 Green Fine 1 000 255 0–100%
7 Blue 1 000 255 0–100%
8 Blue Fine 1 000 255 0–100%
9 Amber 1 000 255 0–100%
10 Amber Fine 1 000 255 0–100%
11 Lime 1 000 255 0–100%
12 Lime Fine 1 000 255 0–100%
13 Virtual Color Wheel 1 000 255 Refer to the .Virtual Color Wheel Chart section for
specific values
14 Color Temperature 1 000 255 Refer to the Color Temperature Chart section for
specific values
15 Strobe 1 000 010 No function
011 255 Strobe, slow to fast
16 Red 2 000 255 0–100%
17 Red Fine 2 000 255 0–100%
18 Green 2 000 255 0–100%
19 Green Fine 2 000 255 0–100%
20 Blue 2 000 255 0–100%
21 Blue Fine 2 000 255 0–100%
22 Amber 2 000 255 0–100%
23 Amber Fine 2 000 255 0–100%
24 Lime 2 000 255 0–100%
25 Lime Fine 2 000 255 0–100%
26 Virtual Color Wheel 2 000 255 Refer to the .Virtual Color Wheel Chart section for
specific values
27 Color Temperature 2 000 255 Refer to the Color Temperature Chart section for
specific values
28 Strobe 2 000 010 No function
011 255 Strobe, slow to fast
29 Red 3 000 255 0–100%
30 Red Fine 3 000 255 0–100%
31 Green 3 000 255 0–100%
32 Green Fine 3 000 255 0–100%
33 Blue 3 000 255 0–100%
34 Blue Fine 3 000 255 0–100%
35 Amber 3 000 255 0–100%
36 Amber Fine 3 000 255 0–100%
37 Lime 3 000 255 0–100%
38 Lime Fine 3 000 255 0–100%
39 Virtual Color Wheel 3 000 255 Refer to the .Virtual Color Wheel Chart section for
specific values
40 Color Temperature 3 000 255 Refer to the Color Temperature Chart section for
specific values
41 Strobe 3 000 010 No function
011 255 Strobe, slow to fast

9
EN
QUICK REFERENCE GUIDE
Ovation B-1965FC QRG Rev. 3
7-Cell RGBAL FULL 96CH (cont.)
Channel Function Value Percent/Setting
42 Red 4 000 255 0–100%
43 Red Fine 4 000 255 0–100%
44 Green 4 000 255 0–100%
45 Green Fine 4 000 255 0–100%
46 Blue 4 000 255 0–100%
47 Blue Fine 4 000 255 0–100%
48 Amber 4 000 255 0–100%
49 Amber Fine 4 000 255 0–100%
50 Lime 4 000 255 0–100%
51 Lime Fine 4 000 255 0–100%
52 Virtual Color Wheel 4 000 255 Refer to the .Virtual Color Wheel Chart section for
specific values
53 Color Temperature 4 000 255 Refer to the Color Temperature Chart section for
specific values
54 Strobe 4 000 010 No function
011 255 Strobe, slow to fast
55 Red 5 000 255 0–100%
56 Red Fine 5 000 255 0–100%
57 Green 5 000 255 0–100%
58 Green Fine 5 000 255 0–100%
59 Blue 5 000 255 0–100%
60 Blue Fine 5 000 255 0–100%
61 Amber 5 000 255 0–100%
62 Amber Fine 5 000 255 0–100%
63 Lime 5 000 255 0–100%
64 Lime Fine 5 000 255 0–100%
65 Virtual Color Wheel 5 000 255 Refer to the .Virtual Color Wheel Chart section for
specific values
66 Color Temperature 5 000 255 Refer to the Color Temperature Chart section for
specific values
67 Strobe 5 000 010 No function
011 255 Strobe, slow to fast
68 Red 6 000 255 0–100%
69 Red Fine 6 000 255 0–100%
70 Green 6 000 255 0–100%
71 Green Fine 6 000 255 0–100%
72 Blue 6 000 255 0–100%
73 Blue Fine 6 000 255 0–100%
74 Amber 6 000 255 0–100%
75 Amber Fine 6 000 255 0–100%
76 Lime 6 000 255 0–100%
77 Lime Fine 6 000 255 0–100%
78 Virtual Color Wheel 6 000 255 Refer to the .Virtual Color Wheel Chart section for
specific values
79 Color Temperature 6 000 255 Refer to the Color Temperature Chart section for
specific values
80 Strobe 6 000 010 No function
011 255 Strobe, slow to fast

EN
10
Ovation B-1965FC QRG Rev. 3
QUICK REFERENCE GUIDE
7-Cell RGBAL FULL 96CH (cont.)
Channel Function Value Percent/Setting
81 Red 7 000 255 0–100%
82 Red Fine 7 000 255 0–100%
83 Green 7 000 255 0–100%
84 Green Fine 7 000 255 0–100%
85 Blue 7 000 255 0–100%
86 Blue Fine 7 000 255 0–100%
87 Amber 7 000 255 0–100%
88 Amber Fine 7 000 255 0–100%
89 Lime 7 000 255 0–100%
90 Lime Fine 7 000 255 0–100%
91 Virtual Color Wheel 7 000 255 Refer to the .Virtual Color Wheel Chart section for
specific values
92 Color Temperature 7 000 255 Refer to the Color Temperature Chart section for
specific values
93 Strobe 7 000 010 No function
011 255 Strobe, slow to fast
94 Strobe All 000 010 No function
011 255 Strobe, slow to fast
95 Color Macros 000 015 No function
016 255 Color macros
96 Dimmer Speed
000 051 Preset dimmer speed from display menu
052 101 Dimmer speed mode off
102 152 Dimmer speed mode 1 (fastest)
153 203 Dimmer speed mode 2
204 255 Dimmer speed mode 3 (slowest)

11
EN
QUICK REFERENCE GUIDE
Ovation B-1965FC QRG Rev. 3
7-Cell RGBAL Fine 70CH
Channel Function Value Percent/Setting
1 Red 1 000 255 0–100%
2 Red Fine 1 000 255 0–100%
3 Green 1 000 255 0–100%
4 Green Fine 1 000 255 0–100%
5 Blue 1 000 255 0–100%
6 Blue Fine 1 000 255 0–100%
7 Amber 1 000 255 0–100%
8 Amber Fine 1 000 255 0–100%
9 Lime 1 000 255 0–100%
10 Lime Fine 1 000 255 0–100%
11 Red 2 000 255 0–100%
12 Red Fine 2 000 255 0–100%
13 Green 2 000 255 0–100%
14 Green Fine 2 000 255 0–100%
15 Blue 2 000 255 0–100%
16 Blue Fine 2 000 255 0–100%
17 Amber 2 000 255 0–100%
18 Amber Fine 2 000 255 0–100%
19 Lime 2 000 255 0–100%
20 Lime Fine 2 000 255 0–100%
21 Red 3 000 255 0–100%
22 Red Fine 3 000 255 0–100%
23 Green 3 000 255 0–100%
24 Green Fine 3 000 255 0–100%
25 Blue 3 000 255 0–100%
26 Blue Fine 3 000 255 0–100%
27 Amber 3 000 255 0–100%
28 Amber Fine 3 000 255 0–100%
29 Lime 3 000 255 0–100%
30 Lime Fine 3 000 255 0–100%
31 Red 4 000 255 0–100%
32 Red Fine 4 000 255 0–100%
33 Green 4 000 255 0–100%
34 Green Fine 4 000 255 0–100%
35 Blue 4 000 255 0–100%
36 Blue Fine 4 000 255 0–100%
37 Amber 4 000 255 0–100%
38 Amber Fine 4 000 255 0–100%
39 Lime 4 000 255 0–100%
40 Lime Fine 4 000 255 0–100%
41 Red 5 000 255 0–100%
42 Red Fine 5 000 255 0–100%
43 Green 5 000 255 0–100%
44 Green Fine 5 000 255 0–100%
45 Blue 5 000 255 0–100%
46 Blue Fine 5 000 255 0–100%
47 Amber 5 000 255 0–100%
48 Amber Fine 5 000 255 0–100%
49 Lime 5 000 255 0–100%
50 Lime Fine 5 000 255 0–100%

EN
12
Ovation B-1965FC QRG Rev. 3
QUICK REFERENCE GUIDE
7-Cell RGBAL Fine 70CH (cont.)
7-Cell RGBAL EXT 59CH
Channel Function Value Percent/Setting
51 Red 6 000 255 0–100%
52 Red Fine 6 000 255 0–100%
53 Green 6 000 255 0–100%
54 Green Fine 6 000 255 0–100%
55 Blue 6 000 255 0–100%
56 Blue Fine 6 000 255 0–100%
57 Amber 6 000 255 0–100%
58 Amber Fine 6 000 255 0–100%
59 Lime 6 000 255 0–100%
60 Lime Fine 6 000 255 0–100%
61 Red 7 000 255 0–100%
62 Red Fine 7 000 255 0–100%
63 Green 7 000 255 0–100%
64 Green Fine 7 000 255 0–100%
65 Blue 7 000 255 0–100%
66 Blue Fine 7 000 255 0–100%
67 Amber 7 000 255 0–100%
68 Amber Fine 7 000 255 0–100%
69 Lime 7 000 255 0–100%
70 Lime Fine 7 000 255 0–100%
Channel Function Value Percent/Setting
1 Dimmer 000 255 0–100%
2 Dimmer Fine 000 255 0–100%
3 Red 1 000 255 0–100%
4 Green 1 000 255 0–100%
5 Blue 1 000 255 0–100%
6 Amber 1 000 255 0–100%
7 Lime 1 000 255 0–100%
8 Virtual Color Wheel 1 000 255 Refer to the .Virtual Color Wheel Chart section for
specific values
9 Color Temperature 1 000 255 Refer to the Color Temperature Chart section for
specific values
10 Strobe 1 000 010 No function
011 255 Strobe, slow to fast
11 Red 2 000 255 0–100%
12 Green 2 000 255 0–100%
13 Blue 2 000 255 0–100%
14 Amber 2 000 255 0–100%
15 Lime 2 000 255 0–100%
16 Virtual Color Wheel 2 000 255 Refer to the .Virtual Color Wheel Chart section for
specific values
17 Color Temperature 2 000 255 Refer to the Color Temperature Chart section for
specific values
18 Strobe 2 000 010 No function
011 255 Strobe, slow to fast
19 Red 3 000 255 0–100%
20 Green 3 000 255 0–100%
21 Blue 3 000 255 0–100%
22 Amber 3 000 255 0–100%
23 Lime 3 000 255 0–100%

13
EN
QUICK REFERENCE GUIDE
Ovation B-1965FC QRG Rev. 3
7-Cell RGBAL EXT 59CH (cont.)
Channel Function Value Percent/Setting
24 Virtual Color Wheel 3 000 255 Refer to the .Virtual Color Wheel Chart section for
specific values
25 Color Temperature 3 000 255 Refer to the Color Temperature Chart section for
specific values
26 Strobe 3 000 010 No function
011 255 Strobe, slow to fast
27 Red 4 000 255 0–100%
28 Green 4 000 255 0–100%
29 Blue 4 000 255 0–100%
30 Amber 4 000 255 0–100%
31 Lime 4 000 255 0–100%
32 Virtual Color Wheel 4 000 255 Refer to the .Virtual Color Wheel Chart section for
specific values
33 Color Temperature 4 000 255 Refer to the Color Temperature Chart section for
specific values
34 Strobe 4 000 010 No function
011 255 Strobe, slow to fast
35 Red 5 000 255 0–100%
36 Green 5 000 255 0–100%
37 Blue 5 000 255 0–100%
38 Amber 5 000 255 0–100%
39 Lime 5 000 255 0–100%
40 Virtual Color Wheel 5 000 255 Refer to the .Virtual Color Wheel Chart section for
specific values
41 Color Temperature 5 000 255 Refer to the Color Temperature Chart section for
specific values
42 Strobe 5 000 010 No function
011 255 Strobe, slow to fast
43 Red 6 000 255 0–100%
44 Green 6 000 255 0–100%
45 Blue 6 000 255 0–100%
46 Amber 6 000 255 0–100%
47 Lime 6 000 255 0–100%
48 Virtual Color Wheel 6 000 255 Refer to the .Virtual Color Wheel Chart section for
specific values
49 Color Temperature 6 000 255 Refer to the Color Temperature Chart section for
specific values
50 Strobe 6 000 010 No function
011 255 Strobe, slow to fast
51 Red 7 000 255 0–100%
52 Green 7 000 255 0–100%
53 Blue 7 000 255 0–100%
54 Amber 7 000 255 0–100%
55 Lime 7 000 255 0–100%
56 Virtual Color Wheel 7 000 255 Refer to the .Virtual Color Wheel Chart section for
specific values
57 Color Temperature 7 000 255 Refer to the Color Temperature Chart section for
specific values
58 Strobe 7 000 010 No function
011 255 Strobe, slow to fast
59 Strobe All 000 010 No function
011 255 Strobe, slow to fast

EN
14
Ovation B-1965FC QRG Rev. 3
QUICK REFERENCE GUIDE
7-Cell RGBA EXT 52CH
Channel Function Value Percent/Setting
1 Dimmer 000 255 0–100%
2 Dimmer Fine 000 255 0–100%
3 Red 1 000 255 0–100%
4 Green 1 000 255 0–100%
5 Blue 1 000 255 0–100%
6 Amber 1 000 255 0–100%
7 Virtual Color Wheel 1 000 255 Refer to the .Virtual Color Wheel Chart section for
specific values
8 Color Temperature 1 000 255 Refer to the Color Temperature Chart section for
specific values
9 Strobe 1 000 010 No function
011 255 Strobe, slow to fast
10 Red 2 000 255 0–100%
11 Green 2 000 255 0–100%
12 Blue 2 000 255 0–100%
13 Amber 2 000 255 0–100%
14 Virtual Color Wheel 2 000 255 Refer to the .Virtual Color Wheel Chart section for
specific values
15 Color Temperature 2 000 255 Refer to the Color Temperature Chart section for
specific values
16 Strobe 2 000 010 No function
011 255 Strobe, slow to fast
17 Red 3 000 255 0–100%
18 Green 3 000 255 0–100%
19 Blue 3 000 255 0–100%
20 Amber 3 000 255 0–100%
21 Virtual Color Wheel 3 000 255 Refer to the .Virtual Color Wheel Chart section for
specific values
22 Color Temperature 3 000 255 Refer to the Color Temperature Chart section for
specific values
23 Strobe 3 000 010 No function
011 255 Strobe, slow to fast
24 Red 4 000 255 0–100%
25 Green 4 000 255 0–100%
26 Blue 4 000 255 0–100%
27 Amber 4 000 255 0–100%
28 Virtual Color Wheel 4 000 255 Refer to the .Virtual Color Wheel Chart section for
specific values
29 Color Temperature 4 000 255 Refer to the Color Temperature Chart section for
specific values
30 Strobe 4 000 010 No function
011 255 Strobe, slow to fast
31 Red 5 000 255 0–100%
32 Green 5 000 255 0–100%
33 Blue 5 000 255 0–100%
34 Amber 5 000 255 0–100%
35 Virtual Color Wheel 5 000 255 Refer to the .Virtual Color Wheel Chart section for
specific values
36 Color Temperature 5 000 255 Refer to the Color Temperature Chart section for
specific values
37 Strobe 5 000 010 No function
011 255 Strobe, slow to fast
38 Red 6 000 255 0–100%
39 Green 6 000 255 0–100%
40 Blue 6 000 255 0–100%
41 Amber 6 000 255 0–100%

15
EN
QUICK REFERENCE GUIDE
Ovation B-1965FC QRG Rev. 3
7-Cell RGBA EXT 52CH (cont.)
7-Cell RGB EXT 45CH
Channel Function Value Percent/Setting
42 Virtual Color Wheel 6 000 255 Refer to the .Virtual Color Wheel Chart section for
specific values
43 Color Temperature 6 000 255 Refer to the Color Temperature Chart section for
specific values
44 Strobe 6 000 010 No function
011 255 Strobe, slow to fast
45 Red 7 000 255 0–100%
46 Green 7 000 255 0–100%
47 Blue 7 000 255 0–100%
48 Amber 7 000 255 0–100%
49 Virtual Color Wheel 7 000 255 Refer to the .Virtual Color Wheel Chart section for
specific values
50 Color Temperature 7 000 255 Refer to the Color Temperature Chart section for
specific values
51 Strobe 7 000 010 No function
011 255 Strobe, slow to fast
52 Strobe All 000 010 No function
011 255 Strobe, slow to fast
Channel Function Value Percent/Setting
1 Dimmer 000 255 0–100%
2 Dimmer Fine 000 255 0–100%
3 Red 1 000 255 0–100%
4 Green 1 000 255 0–100%
5 Blue 1 000 255 0–100%
6 Virtual Color Wheel 1 000 255 Refer to the .Virtual Color Wheel Chart section for
specific values
7 Color Temperature 1 000 255 Refer to the Color Temperature Chart section for
specific values
8 Strobe 1 000 010 No function
011 255 Strobe, slow to fast
9 Red 2 000 255 0–100%
10 Green 2 000 255 0–100%
11 Blue 2 000 255 0–100%
12 Virtual Color Wheel 2 000 255 Refer to the .Virtual Color Wheel Chart section for
specific values
13 Color Temperature 2 000 255 Refer to the Color Temperature Chart section for
specific values
14 Strobe 2 000 010 No function
011 255 Strobe, slow to fast
15 Red 3 000 255 0–100%
16 Green 3 000 255 0–100%
17 Blue 3 000 255 0–100%
18 Virtual Color Wheel 3 000 255 Refer to the .Virtual Color Wheel Chart section for
specific values
19 Color Temperature 3 000 255 Refer to the Color Temperature Chart section for
specific values
20 Strobe 3 000 010 No function
011 255 Strobe, slow to fast
21 Red 4 000 255 0–100%
22 Green 4 000 255 0–100%
23 Blue 4 000 255 0–100%

EN
16
Ovation B-1965FC QRG Rev. 3
QUICK REFERENCE GUIDE
7-Cell RGB EXT 45CH
Channel Function Value Percent/Setting
24 Virtual Color Wheel 4 000 255 Refer to the .Virtual Color Wheel Chart section for
specific values
25 Color Temperature 4 000 255 Refer to the Color Temperature Chart section for
specific values
26 Strobe 4 000 010 No function
011 255 Strobe, slow to fast
27 Red 5 000 255 0–100%
28 Green 5 000 255 0–100%
29 Blue 5 000 255 0–100%
30 Virtual Color Wheel 5 000 255 Refer to the .Virtual Color Wheel Chart section for
specific values
31 Color Temperature 5 000 255 Refer to the Color Temperature Chart section for
specific values
32 Strobe 5 000 010 No function
011 255 Strobe, slow to fast
33 Red 6 000 255 0–100%
34 Green 6 000 255 0–100%
35 Blue 6 000 255 0–100%
36 Virtual Color Wheel 6 000 255 Refer to the .Virtual Color Wheel Chart section for
specific values
37 Color Temperature 6 000 255 Refer to the Color Temperature Chart section for
specific values
38 Strobe 6 000 010 No function
011 255 Strobe, slow to fast
39 Red 7 000 255 0–100%
40 Green 7 000 255 0–100%
41 Blue 7 000 255 0–100%
42 Virtual Color Wheel 7 000 255 Refer to the .Virtual Color Wheel Chart section for
specific values
43 Color Temperature 7 000 255 Refer to the Color Temperature Chart section for
specific values
44 Strobe 7 000 010 No function
011 255 Strobe, slow to fast
45 Strobe All 000 010 No function
011 255 Strobe, slow to fast

17
EN
QUICK REFERENCE GUIDE
Ovation B-1965FC QRG Rev. 3
7-Cell RGBAL 35CH
Channel Function Value Percent/Setting
1 Red 1 000 255 0–100%
2 Green 1 000 255 0–100%
3 Blue 1 000 255 0–100%
4 Amber 1 000 255 0–100%
5 Lime 1 000 255 0–100%
6 Red 2 000 255 0–100%
7 Green 2 000 255 0–100%
8 Blue 2 000 255 0–100%
9 Amber 2 000 255 0–100%
10 Lime 2 000 255 0–100%
11 Red 3 000 255 0–100%
12 Green 3 000 255 0–100%
13 Blue 3 000 255 0–100%
14 Amber 3 000 255 0–100%
15 Lime 3 000 255 0–100%
16 Red 4 000 255 0–100%
17 Green 4 000 255 0–100%
18 Blue 4 000 255 0–100%
19 Amber 4 000 255 0–100%
20 Lime 4 000 255 0–100%
21 Red 5 000 255 0–100%
22 Green 5 000 255 0–100%
23 Blue 5 000 255 0–100%
24 Amber 5 000 255 0–100%
25 Lime 5 000 255 0–100%
26 Red 6 000 255 0–100%
27 Green 6 000 255 0–100%
28 Blue 6 000 255 0–100%
29 Amber 6 000 255 0–100%
30 Lime 6 000 255 0–100%
31 Red 7 000 255 0–100%
32 Green 7 000 255 0–100%
33 Blue 7 000 255 0–100%
34 Amber 7 000 255 0–100%
35 Lime 7 000 255 0–100%

EN
18
Ovation B-1965FC QRG Rev. 3
QUICK REFERENCE GUIDE
7-Cell RGBA 28CH
7-Cell RGB 21CH
Channel Function Value Percent/Setting
1 Red 1 000 255 0–100%
2 Green 1 000 255 0–100%
3 Blue 1 000 255 0–100%
4 Amber 1 000 255 0–100%
5 Red 2 000 255 0–100%
6 Green 2 000 255 0–100%
7 Blue 2 000 255 0–100%
8 Amber 2 000 255 0–100%
9 Red 3 000 255 0–100%
10 Green 3 000 255 0–100%
11 Blue 3 000 255 0–100%
12 Amber 3 000 255 0–100%
13 Red 4 000 255 0–100%
14 Green 4 000 255 0–100%
15 Blue 4 000 255 0–100%
16 Amber 4 000 255 0–100%
17 Red 5 000 255 0–100%
18 Green 5 000 255 0–100%
19 Blue 5 000 255 0–100%
20 Amber 5 000 255 0–100%
21 Red 6 000 255 0–100%
22 Green 6 000 255 0–100%
23 Blue 6 000 255 0–100%
24 Amber 6 000 255 0–100%
25 Red 7 000 255 0–100%
26 Green 7 000 255 0–100%
27 Blue 7 000 255 0–100%
28 Amber 7 000 255 0–100%
Channel Function Value Percent/Setting
1 Red 1 000 255 0–100%
2 Green 1 000 255 0–100%
3 Blue 1 000 255 0–100%
4 Red 2 000 255 0–100%
5 Green 2 000 255 0–100%
6 Blue 2 000 255 0–100%
7 Red 3 000 255 0–100%
8 Green 3 000 255 0–100%
9 Blue 3 000 255 0–100%
10 Red 4 000 255 0–100%
11 Green 4 000 255 0–100%
12 Blue 4 000 255 0–100%
13 Red 5 000 255 0–100%
14 Green 5 000 255 0–100%
15 Blue 5 000 255 0–100%
16 Red 6 000 255 0–100%
17 Green 6 000 255 0–100%
18 Blue 6 000 255 0–100%
19 Red 7 000 255 0–100%
20 Green 7 000 255 0–100%
21 Blue 7 000 255 0–100%

19
EN
QUICK REFERENCE GUIDE
Ovation B-1965FC QRG Rev. 3
1-Cell Personalities
1-Cell RGBAL FULL 17CH
1-Cell RGBAL Fine 10CH
Channel Function Value Percent/Setting
1 Dimmer 000 255 0–100%
2 Dimmer Fine 000 255 0–100%
3 Red 000 255 0–100%
4 Red Fine 000 255 0–100%
5 Green 000 255 0–100%
6 Green Fine 000 255 0–100%
7 Blue 000 255 0–100%
8 Blue Fine 000 255 0–100%
9 Amber 000 255 0–100%
10 Amber Fine 000 255 0–100%
11 Lime 000 255 0–100%
12 Lime Fine 000 255 0–100%
13 Virtual Color Wheel 000 255 Refer to the .Virtual Color Wheel Chart section for
specific values
14 Color Temperature 000 255 Refer to the Color Temperature Chart section for
specific values
15 Strobe 000 010 No function
011 255 Strobe, slow to fast
16 Color Macros 000 015 No function
016 255 Color macros
17 Dimmer Speed
000 051 Preset dimmer speed from display menu
052 101 Dimmer speed mode off
102 152 Dimmer speed mode 1 (fastest)
153 203 Dimmer speed mode 2
204 255 Dimmer speed mode 3 (slowest)
Channel Function Value Percent/Setting
1 Red 000 255 0–100%
2 Red Fine 000 255 0–100%
3 Green 000 255 0–100%
4 Green Fine 000 255 0–100%
5 Blue 000 255 0–100%
6 Blue Fine 000 255 0–100%
7 Amber 000 255 0–100%
8 Amber Fine 000 255 0–100%
9 Lime 000 255 0–100%
10 Lime Fine 000 255 0–100%
