BEFORE YOU BEGIN
What is included
Q-Scan™250 with MSD250 bulb
or
Q-Roll™250 with MSD250bulb
Removable feet
Power cord with plug
Manual
Warranty Card
Unpacking Instructions
Immediately upon receiving a fixture, carefully unpack the carton, check the contents to ensure that
all parts are present, and have been received in good condition. Notify the shipper immediately and
retain packing material for inspection if any parts appear damaged from shipping or the carton itself
shows signs of mishandling. Save the carton and all packing materials. In the event that a fixture
must be returned to the factory, it is important that the fixture be returned in the original factory box
and packing.
AC Power
To determine the power requirements for a particular fixture, see the label affixed to the back plate of
the fixture or refer to the fixture’s specifications chart. A fixture’s listed current rating is its average
current draw under normal conditions. All fixtures must be powered directly off a switched circuit and
cannot be run off a rheostat (variable resistor) or dimmer circuit, even if the rheostat or dimmer
channel is used solely for a 0% to 100% switch. Before applying power to a
fixture, check that the source voltage matches the fixture’s requirement.
Check the fixture or device carefully to make sure that if a voltage selection
switch exists that it is set to the correct line voltage you will use.
Warning! Verify that the power select switch on your unit matches the
line voltage applied. All fixtures must be connected to circuits
with a suitable Earth Ground.
Safety Instructions
Please keep this User Guide for future consultation. If you
sell the unit to another user, be sure that they also receive
this instruction booklet.
Always make sure that you are connecting to the proper
voltage and that the line voltage you are connecting to is
not higher than that stated on decal or rear panel of the
fixture.
This product is intended for indoor use only!
To prevent risk of fire or shock, do not expose fixture to
rain or moisture. Make sure there are no flammable
materials close to the unit while operating.
The unit must be installed in a location with adequate
ventilation, at least 50cm from adjacent surfaces. Be sure
that no ventilation slots are blocked.
Always disconnect from power source before servicing or
replacing lamp or fuse and be sure to replace with same
lamp source.
Secure fixture to fastening device using a safety chain.
Never carry the fixture solely by its head. Use its carrying
handles.
Maximum ambient temperature is Ta: 40°. Do not operate
fixture at temperatures higher than this.
In the event of serious operating problem, stop using the
unit immediately. Never try to repair the unit by yourself.
Repairs carried out by unskilled people can lead to
damage or malfunction. Please contact the nearest
authorized technical assistance center. Always use the
same type spare parts.
Don’t connect the device to a dimmer pack.
Make sure power cord is never crimped or damaged.
Never disconnect power cord by pulling or tugging on the
cord.
Avoid direct eye exposure to lamp while it is on.
Caution! There are no user serviceable parts inside the unit. Do not open the housing or
attempt any repairs yourself. In the unlikely event your unit may require service,
please contact CHAUVET.
Please read these instructions carefully, which includes important
information about the installation, usage and maintenance?

Q-Scan 250 & Q-Roll 250 User Manual 4 2005-11-15/13:24
INTRODUCTION
Technical Features
Q-Scan™250 Q-Roll™250
Control Features
6-7 channel DMX Intelligent Scanner
Pan: 180°
Tilt: 70°
Mechanical Dimmer/Shutter/Strobe
Rotating Gobos
- 8 interchangeable rotating gobos
- 6 metal, 2 glass, 2 Free gobos
- Gobo Bounce™
- Gobo wheel spin
- in both directions, at variable speeds
Color Wheel
- 11 colors plus open
- includes 1 quad and 1 tri-color split
- Rainbow color spin
- in both directions, at variable speeds
Gobo rotation control channel
Pan/Tilt speed & reset control channel
Features
Built in beat activated and automatic programs
(stand-alone)
LED display menu with invert
Pan/Tilt Invert option
Removable foot stands
Micro-stepping motors
Thermal switch
Fan cooled
Control Features
6-7 channel DMX Intelligent Barrel Scanner
Pan: 180°
Barrel Rotation: 360°
Mechanical Dimmer/Shutter/Strobe
Rotating Gobos
- 8 interchangeable rotating gobos
- 6 metal, 2 glass, 2 Free gobos
- Gobo Bounce™
- Gobo wheel spin
- in both directions, at variable speeds
Color Wheel
- 11 colors plus open
- includes 1 quad and 1 tri-color split
- Rainbow color spin
- in both directions, at variable speeds
Gobo rotation control channel
Pan speed & reset control channel
Features
Built in beat activated and automatic programs
(stand-alone)
LED display menu with invert
Pan/Tilt Invert option
Removable foot stands
Micro-stepping motors
Thermal switch
Fan cooled
DMX Channel Summary
CHANNEL FUNCTION
1 Pan
2 Tilt or Barrel Roll
3 Shutter, Strobe, Dimmer
4 Rotating Gobos
5 Colors
6 Gobo rotation
7 Pan/Tilt Speed & Reset
with (P7-n) setting

Introduction
Q-Scan 250 & Q-Roll 250 User Manual 5 2005-11-15/13:24
Product Overview
Control Board
Enter Choose
Up Down




SEGMENT BUTTONS I/O PANEL OVERVIEW
BUTTONS I/O PANEL
Choose Toggles menu functions DMX Out & In DMX-512 connectors
Down Steps backward through menu
functions Power AC input IEC 60320 C14 and fuse holder
Up Steps forward through menu
functions
Enter Confirms selected menu
function
1 1. Scanner head
2. Projector
3. Base
4. Carrying handles and
removable floor stands
5. Fan (bottom rear)
6. LED power indicator
7. LED display
8. [Enter] button
9. [Choose] button
10. [Up] button
11. [Down] button
12. DMX output
13. DMX input
14. Internal microphone
15. AC input IEC 60320 C14
16. Fuse holder
17. Power switch
18. Voltage switch
19. Music Sensitivity Knob
20. Lamp access plate
21. Lamp optimizing
22. Barrel scanner
2
3
4
12 13 20 21
19
17
6
7
8 9 10 11
5
14
15
16
18
4
22

Q-Scan 250 & Q-Roll 250 User Manual 6 2005-11-15/13:24
S1
S2
S1
SETUP
Lamp
You will need to install a lamp prior to the initial operation of the fixture. An MSD250 high intensity
discharge lamp is included.
Warning! When replacing the lamp, please wait 15 minutes after powering down to allow the
unit to cool down! Always disconnect from main power prior to lamp replacement.
Do not touch the envelope (glass area) of the bulb with bare hands. If this happens, clean the lamp
with alcohol and wipe it with a lint free cloth before installation.
Lamp Installation
1. Remove screws labeled (S1) and pull out lamp socket plate.
2. If replacing the lamp, remove old lamp first.
3. Holding the new lamp by its base, align the pins on the lamp
with the small hole in the socket and insert the lamp squarely
until the retaining clips on the lamp socket secure the lamp
tightly.
4. Clean the glass/envelope of the bulb with an alcohol wipe or
equivalent.
5. Holding the lamp socket plate, insert the tip of the lamp into the
fixture with extreme care. Navigate the lamp all the way until it
reaches the reflector and the lamp base plate touches the
bottom plate of the fixture.
6. Align the screw holes and fasten the screws back onto the
lamp socket plate.
7. If you are replacing the lamp, you may want to log the fixture
hours in order to track the lamps use. Navigate to the H000 on
the menu display to obtain this information. Please note that it
is normal for the fixture to have logged a few hours of testing
prior to your use.
8. Turn the fixture on and adjust the lamp alignment screws (S2)
until the brightest most even area of the beam is in the center of your spot. It may be necessary
for you to use a controller in order to command the fixture to display a white beam on a flat surface
with no colors.
Maximizing the life of your lamp
To ensure the longest and most efficient use of the lamp always wait
between 10 and 15 minutes before re-applying power after a shutdown.
Failure to do so could result in premature aging of the lamp and failure to
the electronics that drive it.

Introduction
Q-Scan 250 & Q-Roll 250 User Manual 7 2005-11-15/13:24
Slide switch up or down
depending on your line voltage.
Lamp Alignment Screws are
accessible via the rear plate.
S2
Lamp Alignment How-To
Often, after a new installation of a lamp, you will find that there
is an uneven field of light or what is referred to as a hot spot.
This is due to the most intense point of the lamp source not
being positioned optimally within the reflector.
There are three lamp alignment screws provided at the base of
the projector head. Turning these screws allow you to optimize
the projection quality of the spot as well as the overall intensity
of the beam.
1. Project a white spot against any flat surface. Preferably the
surface should be white or pastel in color.
2. Turning the lamp alignment screws, try to position the hot spot in the
center of the beam as best as possible. This could require many
attempts on your part.
3. Once the hot spot is in the center of the spot, do your best to turn all
screws equally as to affect movement up or down within the reflector.
4. As you move in and out of optimum lamp focus, you will see the hot spot either gets wider or
narrower. The goal is to either totally diminish the hot spot by having it widen and spread across
the entire spot or moving the hot spot so that it covers as much of the beam spot area as possible.
Power Your product is equipped with switch-selectable AC power setting.
Warning! Verify that the power select switch on your unit
matches the line voltage applied. All fixtures must
be connected to circuits with a suitable Earth
Ground.
To determine the power requirements for a particular fixture,
see the label affixed to the back plate of the fixture or refer to the fixture’s specifications chart.
A fixture’s listed current rating is its average current draw under normal conditions.
All fixtures must be powered directly off a switched circuit and cannot be run off a rheostat
(variable resistor) or dimmer circuit, even if the rheostat or dimmer channel is used solely for a 0%
to 100% switch.
Before applying power to a fixture, check that the source voltage matches the fixture’s
requirement.
All fixtures must be connected to circuits with a suitable Earth Ground.
Power Cable Configuration
CABLE PIN INTERNATIONAL
BROWN Live L
BLUE Neutral N
YELLOW/GREEN Earth EG (Ground)
Exchanging gobos
1. Press both tips of the gobo tension ring together and remove from aperture.
2. Push the gobo with your finger from the back side following the same direction
that the tension ring was removed.

Introduction
Q-Scan 250 & Q-Roll 250 User Manual 8 2005-11-15/13:24
Mounting
Orientation
Both fixtures can sit on stage or be mounted on a truss using a clamp in any position, provided, there
is adequate room for ventilation.
Warning
It is important never to obstruct the fan or vents pathway.
When selecting installation location, take into consideration lamp replacement access and routine
maintenance.
Safety cables should always be used.
Never mount in places where the fixture will be exposed to rain, high humidity, extreme
temperature changes or restricted ventilation.
The fixture must have a minimum of 1 meter distance from combustible materials.
Rigging
The fixture includes a mounting yoke to which 1 rigging clamp can be bolted.
1. Align the clamp screw with the center hole on the yoke and tighten.
2. Verify the structure can hold 10 times the weight of all to-be installed fixtures.
3. Adjust the angle on the yoke arm as necessary.
1. Clamp
2. Fixture Yoke
3. Angle Adjustment
1
2
3

Q-Scan 250 & Q-Roll 250 User Manual 9 2005-11-15/13:24
OPERATING INSTRUCTIONS
Control Panel
On the control panel you can set the DMX address, set the fixture to Master/Slave mode, reset the
fixture and change fixture personality traits.
Control Panel Functions
FUNCTION OPTIONS NOTES
 / Pan invert
 / Tilt invert
 / Fixture reset
 / Stand Alone (Sound-Active)
 / Stand Alone (Auto Run)
 / Reserved
 / (-n) to Enable Channel 7
Pan/Tilt Speed)
 / Display invert


~ DMX channel addressing
-y: Activates setting
-n: Disables, skips or selects alternative setting
Applying changes to Functions (Quick Instructions)
Unless other wise stated changes in the control panel can be applied in the following manner.
1. Press [Choose] button repeatedly until the display reads the menu function you wish to change as
illustrated in the table above in section “Control Panel Functions”
2. The display will read the previously stored settings for the desired function, for example, either
with a “-y”or a “-n”as in “P1-y or P1-n”.
3. Press the [Up] or [Down] button to toggle between either the “-y”or “-n”selection for that
particular menu function.
4. Press the [Enter] button to store your selection. The display will read “PASS”to confirm your
selection
[Enter] Confirms selection
[Choose] Access to main menu
[Up] Toggle menu items in a forward direction
[Down] Toggle menu items in a reverse direction
Control Board
Enter Choose
Up Down





Q-Scan 250 & Q-Roll 250 User Manual 10 2005-11-15/13:24
Note!
If the fixture is connected to a
controller, please disconnect it.
The display will read the previously
selected setting.
Only one fixture can be the Master
assigned fixture. However, 16 units
can be slaved to the master unit.
Operating Modes
A stand-alone mode will listen to sound and run through its diverse range of built in programs.
Master/Slave mode will allow the command of up to as many units you want in a synchronized
light show to the sound.
DMX control mode will provide the greatest flexibility and creativity. Each fixture trait can be
controlled individually using any universal DMX-512 controller.
Master & Stand Alone (P6)
In order to create the correct environment for Stand Alone
operation, several parameters have to be set in the control
panel. Please make the changes to the functions as listed in
the table below.
FUNCTION SET TONOTES
P6 -y Master mode (one Master only)
P4 -y Sound activated
A 001 Channel address
P1 Any Pan invert
P2 Any Tilt invert
Setting Slave Fixtures
The Master/Slave mode will allow you to link multiple units in a daisy chain fashion. In this mode, the
first unit in the daisy chain, the master, will automatically command all other units following. The first
unit will operate in a Stand/Alone mode and all units following will synchronize to the first unit. Up to
16 fixtures can be daisy chained in Master/Slave mode.
MENU SET TO NOTES
P6 -n Master mode
P4 -n Sound activated
A 001 Channel address
P1 Any Pan invert
P2 Any Tilt invert
You can change the Pan and Tilt settings freely.
Sound-active (P4) or Auto-run (P5)
In Master/Slave mode you can choose whether the fixture will run in a sound-active state where the
movement is triggered by sound or in auto-run where the speed is pre-programmed.
MENU SET TO NOTES
P4 -n Sound Activated
or
P5 -n Auto-run

Operating Instructions
Q-Scan 250 & Q-Roll 250 User Manual 11 2005-11-15/13:24
Daisy Chain
Connection
DMX Mode
Operating in a DMX Control mode environment gives the user the greatest flexibility when it comes to
customizing or creating a show. You can tailor your programming to suit a specific event. Whether it
is a wedding where a spot light may be required or a lead singer requiring a color solo, the
opportunities are endless. In this mode you will be able to control each individual trait of the fixture
independently.
Daisy Chain Connection
1. Connect the (male) 3 pin connector side of the DMX cable to the output (female) 3 pin connector
of the first fixture.
2. Connect the end of the cable coming from the first fixture which will have a (female) 3 pin
connector to the input connector of the next fixture consisting of a (male) 3 pin connector. Then,
proceed to connect from the output as stated above to the input of the following fixture and so on.
Menu Functions
DMX-512 addressing
This mode enables the use of a universal DMX controller device. Each fixture requires a "start
address" from 1 to 511. A fixture requiring one or more channels for control begins to read the data
on the channel indicated by the start address. For example, a fixture that occupies or uses 6 channels
of DMX and was addressed to start on DMX channel 100, would read data from channels: 100, 101,
102, 103, 104, and 105. Choose start addresses so that the channels used do not overlap and notate
the start address selected for future reference.
If this is your first time addressing a fixture using the DMX-512 control protocol than I suggest jumping
to the Appendix Section and read the heading “DMX Primer”. It contains very useful information that
will help you understand its use.
Setting the starting address
1. Press the [Choose] button until the display reads “ANNN”where N represents a number from 0 to
9.
2. Press the [Up] and [Down] buttons to increase or decrease values until the desired value is
achieved.
3. Press the [Enter] button to activate selection.

Q-Scan 250 & Q-Roll 250 User Manual 12 2005-11-15/13:24
User Configurations
P1 - Pan Invert / P2- Tilt Invert
It is possible to invert the pan and tilt mirror movement from within the fixture itself. This could be
helpful in situations where the positioning or rigging of a fixture led to a reverse orientation of the
fixture in relation to all or most other fixtures installed. When choosing to command the pan or tilt of
all fixtures at the same time you will notice that the fixtures whose orientation is different from the
others will most likely move opposite of the rest. You can apply a pan and tilt Invert by following the
settings in the table below.
FUNCTION SET TONOTES
P1 -y Pan Invert
P2 -y Tilt Invert
P1 & P2 -n Return to normal
Segment Display Configurations
The display can be inverted making it easier to read the menu depending on the orientation of your
fixture.
P8 - Display Invert
FUNCTION SET TONOTES
P8 -y Invert display
P8 -n Return to normal
Service Functions
P3 - Fixture Reset (all motors)
This function will re-initialize the fixture by returning all motors to its startup positions or otherwise
known as (home position).
FUNCTION SET TONOTES
P3 -y Reset fixture
P3 -n Skip function

Q-Scan 250 & Q-Roll 250 User Manual 13 2005-11-15/13:24
APPENDIX
DMX Primer
There are 512 channels in a DMX-512 connection. Channels may be assigned in any manner. A
fixture capable of receiving DMX-512 will require one or a number of sequential channels. The user
must assign a starting address on the fixture that indicates the first channel reserved in the controller.
There are many different types of DMX controllable fixtures and they all may vary in the total number
of channels required. Choosing a start address should be planned in advance. Channels should
never overlap. If they do, this will result in erratic operation of the fixtures whose starting address is
set incorrectly. You can however, control multiple fixtures of the same type using the same starting
address as long as the intended result is that of unison movement or operation. In other words, the
fixtures will be slaved together and all respond exactly the same.
DMX fixtures are designed to receive data through a serial Daisy Chain. A Daisy Chain connection is
where the DATA OUT of one fixture connects to the DATA IN of the next fixture. The order in which
the fixtures are connected is not important and has no effect on how a controller communicates to
each fixture. Use an order that provides for the easiest and most direct cabling. Connect fixtures
using shielded two conductor twisted pair cable with three pin XLR male to female connectors. The
shield connection is pin 1, while pin 2 is Data Negative (S-) and pin 3 is Data positive (S+). CHAUVET
carries 3-pin XLR DMX compliant cables, DMX-10 (33’), DMX-4.5 (15’) and DMX-1.5 (5’)
Fixture Linking
Note! If you use a controller with a 5 pin DMX output connector, you will need to use a 5
pin to 3 pin adapter. CHAUVET Model No: DMX5M.
The chart below details a proper cable conversion:
3PIN TO 5PIN CONVERSION CHART
Conductor 3 Pin Female (output) 5 Pin Male (Input)
Ground/Shield Pin 1 Pin 1
Data ( - )signal Pin 2 Pin 2
Data ( + ) signal Pin 3 Pin 3
Do not use Do not use
Do not use Do not use
COMMON
DMX +
DMX
-
INPUT OUTPUT
1
3
2
1
3
2
1
3
2
Resistance 120
ohm 1/4w between
pin 2 (DMX -) and
pin 3 (DMX +) of
the last fixture.
Termination reduces signal errors and to
avoid signal transmission problems and
interference, it is always advisable to
connect a DMX signal terminator.
Figure 2 - DMX connector configuration

Appendix
Q-Scan 250 & Q-Roll 250 User Manual 14 2005-11-15/13:24
DMX Channel Values (16 Bit)
DEFAULT VALUE FUNCTION
1
000 255 Pan Left > Right ( 128 = center)
000 255 Tilt (Q-Scan 250) Up > Down (128 = center)
2
000 005
006 120
121 140
141 255
Barrel Spin (Q-Roll 250)
Stop
Rotation: Fast > Slow (clockwise)
Stop
Rotation: Slow > Fast (counter-clockwise)
3
000 005
006 063
064 095
096 127
128 159
160 191
192 223
224 255
Shutter/Strobe/Dimmer
Blackout
Dimmer: Closed > Open (0-100%)
Variable strobe: Slow > Fast
Open
(no function)
Pulse strobe in sequence: Slow > Fast | (Close > Open)
Pulse strobe in sequence: Fast > Slow | (Open > Close)
Open
4
000 013
014 027
028 041
042 055
056 069
070 083
084 097
098 111
112 126
127 136
137 146
147 156
157 166
167 176
177 186
187 196
197 206
207 217
218 219
220 255
Rotating Gobo Wheel
Open
Gobo 1
Gobo 2
Gobo 3
Gobo 4
Gobo 5
Gobo 6
Gobo 7
Gobo 8
Open
Gobo 1 (variable bounce): Slow > Fast
Gobo 2 (variable bounce): Slow > Fast
Gobo 3 (variable bounce): Slow > Fast
Gobo 4 (variable bounce): Slow > Fast
Gobo 5 (variable bounce): Slow > Fast
Gobo 6 (variable bounce): Slow > Fast
Gobo 7 (variable bounce): Slow > Fast
Gobo 8 (variable bounce): Slow > Fast
Open
Gobo spin: Slow > Fast
5
000 009
010 020
021 031
032 041
042 052
053 063
064 073
074 084
085 095
096 105
106 116
117 128
129 190
191 220
221 222
223 255
Color Wheel
White (Open)
Red
Blue
Yellow
Light Green
Magenta
UV
Light Blue or Cyan
Orange
Pink
Tri-color: Red –White - Blue
Quad-color: Blue –Pink –Purple - Yellow
Linear progression of color wheel (color-splits)
Rainbow effect: Fast > Slow (clockwise)
Stop
Rainbow effect: Slow > Fast (counter-clockwise)
6
000 127
128 189
190 193
194 255
Gobo Rotation
Gobo incremental rotation
Clockwise gobo rotation: Fast > Slow
No Rotation
Counter clockwise gobo rotation: Slow > Fast
7
000 000
001 200
201 204
205 255
Pan/Tilt Speed (P7-n setting)
Tracking control: Maximum
Vector control: Maximum > Slowest
Fixture Reset
Tracking control: Maximum

Q-Scan 250 & Q-Roll 250 User Manual 15 2005-11-15/13:24
Maintenance
To maintain optimum performance and minimize wear fixtures should be cleaned frequently. Usage
and environment are contributing factors in determining frequency. As a general rule, fixtures should
be cleaned at least twice a month. Dust build up reduces light output performance and can cause
overheating. This can lead to reduced lamp life and increased mechanical wear. Be sure to power off
fixture before conducting maintenance.
Unplug fixture from power. Use a vacuum or air compressor and a soft brush to remove dust
collected on external vents and internal components. Clean all glass when the fixture is cold with a
mild solution of glass cleaner or Isopropyl Alcohol and a soft lint free cotton cloth or lens tissue. Apply
solution to the cloth or tissue and drag dirt and grime to the outside of the lens. Gently polish optical
surfaces until they are free of haze and lint. Do not to touch the lamp glass when cleaning fixture. Oil
and dirt can cause damage and premature aging of the lamp. In the event that the lamp is touched or
becomes dirty, clean the lamps with an alcohol wipe.
The cleaning of internal and external optical lenses and/or mirrors must be carried out periodically to
optimize light output. Cleaning frequency depends on the environment in which the fixture operates:
damp, smoky or particularly dirty surrounding can cause greater accumulation of dirt on the unit’s
optics. Clean with soft cloth using normal glass cleaning fluid. - Always dry the parts carefully. - Clean
the external optics at least every 20 days. Clean the internal optics at least every 30/60 days.
Returns Procedure
Returned merchandise must be sent prepaid and in the original packing, call tags will not be issued.
Package must be clearly labeled with a Return Merchandise Authorization Number (RA #). Products
returned without an RA # will be refused. Call CHAUVET and request RA # prior to shipping the
fixture. Be prepared to provide the model number, serial number and a brief description of the cause
for the return. Be sure to properly pack fixture, any shipping damage resulting from inadequate
packaging is the customer’s responsibility. CHAUVET reserves the right to use its own discretion to
repair or replace product(s). As a suggestion, proper UPS packing or double-boxing is always a safe
method to use.
Claims Damage incurred in shipping is the responsibility of the shipper; therefore the damage must be
reported to the carrier upon receipt of merchandise. It is the customer's responsibility to notify and
submit claims with the shipper in the event that a fixture is damaged due to shipping. Any other claim
for items such as missing component/part, damage not related to shipping, and concealed damage,
must be made within seven (7) days of receiving merchandise.

Appendix
Q-Scan 250 & Q-Roll 250 User Manual 16 2005-11-15/13:24
General Troubleshooting Applies to
Symptom Solution(s) Lights
Foggers
& Snow Controllers
Dimmers
& Chaser
Auto shut off Check fan thermal switch reset 
Beam is very dim or not
bright Clean optical system or replace lamp Check 220/110v switch for proper setting 
Breaker/Fuse keeps
blowing Check total load placed on device 
Chase is too slow Check users manual for speed adjustment 
Device has no power Check for power on Mains.
Check device’s fuse. (internal and/or external) 
Fixture is not responding Check DMX Dip switch settings for correct addressing
Check DMX cables
Check polarity switch settings

Fixture is on but there is
no movement to the
audio
Make sure you have the correct audio mode on the control
switches. If audio provided via ¼”jack, make sure a live audio
signal exists
Adjust sound sensitivity knob
 
Lamps cuts off
sporadically Possible bad lamp or fixture is overheating. Lamp may be at end of its life. 
Light will not come on
after power failure Some discharge lamps require a cooling off period before the electronics in the fixture can kick start it again, wait 5 to 10
minutes before powering up

Loss of signal Use only DMX cables
Install terminator
Note: Keep DMX cables separated from power cables or black
lights.

Motor movements are
jerky or jumpy Possible bad motor driver or sensors Check polarity switch on controller 
Moves slow Check 220/110v switch for proper setting 
No flash Re-install bulb, may have shifted in shipping 
No light output Check slip ring & brushes for contact
Install bulb
Call service technician

Relay will not work Check reset switch
Check cable connections 
Remote does not work Make sure connector is firmly connected to device 
Stand alone mode All CHAUVET lighting fixtures featuring stand-alone functions
do not require additional settings, simply power the fixture and
it will automatically enter into this mode

Unit wobbles when
rotating Check for damages possibly incurred during shipping 

Appendix
Q-Scan 250 & Q-Roll 250 User Manual 17 2005-11-15/13:24
Technical Specifications
WEIGHT & DIMENSIONS
Length........................................................................................................................292 mm (11.5 in)
Width.............................................................................................................................305 mm (12 in)
Height ...........................................................................................................................736 mm (29 in)
Weight......................................................................................................................14.52 Kgs (32 lbs)
POWER
Switch-selectable power settings.................................................................115V 60 Hz or 230V 50 Hz
AC input.........................................................................................................3 prongs IEC 60320 C14
European version...............................................................................................................240V 50 Hz
Current draw 110V................................................................................... (peak 240W), (inrush 610W)
Current draw 230V................................................................................... (peak 264W), (inrush 670W)
LAMPS
HSD250 or MSD250 .........................................................................................3000 hr, 6500K, 250W
PHOTO OPTIC
Beam Angle ....................................................................................................................................16°
Pan...............................................................................................................................................180°
Tilt...................................................................................................................................................70°
GOBOS
Outside diameter....................................................................................................................27.69mm
Image diameter........................................................................................................................21.5mm
Thickness......................................................................................................................................3mm
THERMAL
Maximum ambient temperature......................................................................................... 40° (104° F)
FUSE
Main (115V) .............................................................................................20mm Glass 6.3A Fast Blow
Internal PCB................................................................................................20mm Glass 5A Fast Blow
CONTROL & PROGRAMMING
Data input .............................................................................................locking 3-pin XLR male socket
Data output........................................................................................ locking 3-pin XLR female socket
Data pin configuration............................................................................pin 1 shield, pin 2 (-), pin 3 (+)
Protocols.....................................................................................................................DMX-512 USITT
DMX Channels.............................................................................................................................6 or 7
ORDERING INFORMATION
Q-Spot 250 Intelligent Scanner ...........................................................................................Q-Spot 250
Q-Roll 250 Intelligent Barrel Scanner...................................................................................Q-Roll 250
Fuse 6.3A .....................................................................................................................P170FUSE006
Fuse 5A ........................................................................................................................P170FUSE005
Technical Support
Address: Service Dept.
3000 N 29th Ct, Hollywood, FL 33020 (U.S.A.)
Support (Email): [e-mail]
Telephone: [phone] - (Press 4)
Fax: [phone] - (Attention: Service)
Website:...............................................................................................http://www.chauvetlighting.com
