ChemChek Aqua Dual Mate ADM Series Installation and operating instructions

Trouble Shooting
Action only to be performed by a
qualified person.
SYMPTOM CAUSES ACTION
No water
Water supply turned off Check mains supply
No not hot
Faulty element
No power supply
Replace element
Check & test power
supply
Water overflowing
from tap spout
Expansion chamber full
Low inlet pressure
Run tap for 5-10 min
Contact manufacturer
Excessive steam
from tap
Faulty element Replace element
N.B. These units are designed to have no less than
100ml of boiling water taken off at a time.
45 Rennie Drive, Airport Oaks, Mangere 2022
PO Bo x 43-047, Mangere, Manukau 2153
P n: 09 275-5019 Fax: [phone]
Email: sales@c emc ek.co.nz Web: www.c emc ek.co.nz
To our valued customer...
A very special thank you for choosing to purchase and install our
ADM Series Aqua Dual Mate
INSTALLATION & MAINTENANCE INSTRUCTIONS
IMPORTANT...PLEASE READ
The Aqua Dual Mate dispenses boiling water – please treat with care.
This unit is fitted with a computerised element and boil dry protection.
The computer is set at 97°C, altitude will alter temperature (refer to
manufacture).
.
Do not switch on power without water running
out from the tap
•
••
• Unit to be connected in accordance with AS3500.4.1 or AS/NZS
3500.4.2
•
••
• If fitted with filter we recommend changing the cartridge every 6
months
•
••
• The manufacturer recommends the cleaning and service of the
unit every 12 months
•
••
• IF SUPPLIED CORD IS DAMAGED IT MUST BE REPLACED
BY AN AUTHORISED SERVICE AGENT (ELECTRICIAN).
Please leave these instructions with the owner
INSTALLATION INSTRUCTIONS

1. Position heater unit underneath the sink as close as possible to
its outlet tap.
2. Position the tap in the desired location. Drill 36mm O hole
3. Observing the attached labels
a) Measure and cut pipes to desired length.
b) Connect the ¼” pipe from the tap to the inlet of the
heater.
c) Connect the 5/16” pipe from the tap to the outlet of the
heater.
d) Connect the ¼” pipe from the tap to the water supply via
pressure limiting valve and one of the tee pieces to the
cold port of the mixing valve. Connect hot tap and top coil
connection to mixing valve.
4. Connect the cold tap (basin set) and the expansion control valve
to the other tee connections. Connect from the remaining tee to
the bottom coil connection. Connect drain from the expansion
control valve to drain facility at a lower level.
5. Open tap until water is flowing from the boiling water port, also
open hot and cold taps in basin set until water flows.
6. Plug unit into power point and switch on and allow 30 minutes
before use.
MATERIALS SUPPLIED
•
••
• Adjustable Tempering Valve (TVA)
•
••
• Pressure Limiting Valve (PLV) 350KPA
•
••
• 1.8 Metre Flexible Cord & Plug
•
••
• Expansion Control Valve H50 (ECV)
MATERIALS NOT SUPPLIED
•
••
• Tundish
