Chenbro ES34069 User manual

www.chenbro.com
1
ES34069 Chassis User’s Manual Rev. A1
Chenbro
ES34069
Chassis
User Manual
December / 22 / 2009

www.chenbro.com
2
ES34069 Chassis User’s Manual Rev. A1
Copyright
Copyright © 2007 Chenbro Micom Co., Ltd.. All rights reserved.
Unless otherwise indicated, all materials in this manual are copyrighted by Chenbro Micom
Co., Ltd.. All rights reserved. No part of this manual, either text or image may be used for any
purpose other than internal use within purchasing company. Therefore, reproduction,
modification in any form or by any means, electronic, mechanical or otherwise, for reasons
other than internal use, is strictly prohibited without prior written permission.
Chenbro Micom Co., Ltd. reserves the right to make improvement and modification to the
products indicated in this manual at any time. Specifications are therefore subject to change
without prior notice.
Information provided in this manual is intended to be accurate and reliable. However,
Chenbro Micom Co., Ltd., assumes no responsibility for its use, nor for any infringements upon
the rights of third parties, which may result from its use.
Technical Support
Chenbro works hard to offer our customers maximum performance from our chassis.
But in case you have any problem with our product you can find supports from the
following resources.
Web Support
Detail information of our products is in our website. You can find technical updates, installation
guides, FAQs, Technical specifications and more. Our web address is: www.chenbro.com.
Email Support
You can also fill out the technical support form at our Technical Support page. Your technical
issue inquiries will be sent directly to our support professionals.
Phone Support
You can also contact Chenbro HQ or branch office for immediate support; contact
Information is as following:
ChenbroHQ Chenbro Europe B.V. Chenbro Micom (USA) Inc.
Tel: [phone] Tel: [phone] Tel: [phone]
Fax: [phone] Fax: [phone] Fax : [phone]

www.chenbro.com
3
ES34069 Chassis User’s Manual Rev. A1
Content
Packing List................................................................................................................4
ES34069 Chassis...............................................................................................4
Power Adaptor Kit.............................................................................................4
Accessory Pack.................................................................................................5
Optional Kits.......................................................................................................5
Features.......................................................................................................................6
Technical Specifications.........................................................................................6
Opening the Chassis................................................................................................7
Side Panel Removal..........................................................................................8
Front Bezel Removal........................................................................................8
Motherboard Cage Removal ..........................................................................9
Devices Installation................................................................................................10
Installing Mini-ITX or Mini-DTX M/B ...........................................................10
Installing Slim Optical Drive.........................................................................10
Installing 3.5” SATA-II Hard Drive...............................................................11
Installing Card Reader...................................................................................12
Installing Dedicated AMD / Intel Heatsink ................................................13
Installing Riser Card.......................................................................................14
Installing 2.5” HDD..........................................................................................14
Connecting Devices...............................................................................................15
Connecting SATA-II Cables ..........................................................................15
Connecting the Power...................................................................................15
Connecting Front Panel I/O and LEDs ......................................................16
Power Adaptor and Backplane............................................................................18
Power Distribution Board.............................................................................19
2-port SATA-II Backplane Introduction......................................................20
Hardware Specification:................................................................................20
Backplane Connectors..................................................................................20

www.chenbro.com
4
ES34069 Chassis User’s Manual Rev. A1
Packing List
ES34069 Chassis
70mm fans (2) SATA-II/SAS
Backplane (2)
USB 2.0
Cables (1)
SATA 7-pin Cable,
260mm (2)
Power Distribution
Board (1)
Hot-swap HDD
Carrier (4)
Slim-CDROM
Carrier (1)
SATA 7-pin Cable,
360mm (2)
Intrusion Switch (1) Split Power Cable,
Type-I (1)
Split Power Cable,
Type-II (1)
Split Power Cable,
Type-III (1)
Power Adaptor Kit
120W or 180W Power Adaptor (1) Power Cord (1)

www.chenbro.com
5
ES34069 Chassis User’s Manual Rev. A1
Accessory Pack
Cable Tie (1) Screw Pack for
M/B (1)
IDE / SATA Slim ODD
Adaptor (1) Front Bezel Key (1)
Power Cable, Big 4P
to Small 4P (1)
Screw Pack for
HDD (1)
Active Heatsink for
AMD/Intel LV CPU (1)
PCI Add-on Card
Bracket (1)
Optional Kits
PCI 32-bit Riser Card (1) 4-in-1 Card Reader (1)

www.chenbro.com
6
ES34069 Chassis User’s Manual Rev. A1
Features
zIdeal for high storage capacity (Hot-swap HDDs) with RAID-5 functionality
zAvailable for multi-media platform
z9.5 liters small form factor with Mini-ITX M/B
zRemovable M/B carrier for excellent thermal performance & easy cabling
zExternal adapter reduces noise level
zOptional remote control & riser card
Technical Specifications
Model Name
◆ ES34069
M/B Form Factor
◆ Mini-ITX, Mini-DTX
Dimension (DxWxH)
◆ 260mm x140mm x260mm ◆ 10.24" x 5.51" x 10.24"
Drive Bay
◆ Hot-swap: 3.5" x4 ◆ Internal: 2.5" x1 (optional)
◆ Slim ODD: 1 (optional)
PSU
◆ Form Factor: External Adapter 120W / 180W
Indicator LEDs
◆ Power, HDD Activity, LAN x2, Fault
Front Control
◆ Power, Reset & Alarm Mute Switches
Front Access
◆ USB 2.0 x2 ◆ SD/Mini-SD/MMC/MS Card Reader (optional)
Security
◆ Kensington Lock & Padlock Loop
Cooling Fan
◆ Front: 60mm (optional) ◆ Rear: 70x20mm x2
Slot Opening
◆ Low Profile x1 (optional)
Material
◆ SECC
Plastic Material Type
◆ ABS-HB
Sheet Metal Thickness
◆ 0.8mm
Net Weight
◆ 4.5 Kgs
Gross Weight
◆ 7.0 Kgs
Backplane
◆ SATA-II / SAS
20' 40' 40'H
Container Info.
◆ Single Packing
672 1344 1512

www.chenbro.com
7
ES34069 Chassis User’s Manual Rev. A1
Opening the Chassis
Front
Back
Overview Slim CD-ROM Carrier
(Optional)
Motherboard Cage
Main Cable Through Hole
w/Rubber pad
Front Bezel
(w/Key Lock)
USB & Front
Control Cables
Intrusion
Switch
Card Reader (Optional)
-- Support MS,SD,Mini-SD,MMC
USB 2.0 ports x2Slim CD-ROM Cover
Front Control Display:
Power Status LED (Blue)
HDD Access LED (Amber)
LAN#1 Activities LED (Green)
LAN#2 Activities LED (Green)
Global Failure LED (Red)
Front Control Switches:
Power On Switch
System Reset
Alarm Mute
IR Receiver Lens
4x 3.5” HDD Carrier
I/O Gasket
(Provided by M/B)
Pad Lock Rear 70mm fans (x2)
Power Adaptor Input
Side Panel Screws
Side Panel w/Venting
Kensington

www.chenbro.com
8
ES34069 Chassis User’s Manual Rev. A1
To open the chassis for assembly of internal parts, users need to:
zRemove the side panel
zRemove the front bezel
Side Panel Removal
Front Bezel Removal
1 2
1 2
■Release the side panel thumb screw on the rear
■Push and slide the side panel toward rear to open the
chassis
3 4
■Lift up the latch along the side to detach the bezel ■Detach the bezel from Slim ODD side gently
■Angle the latch until it is 15 degree away from the
chassis
■gently pull the bezel to make it detach

www.chenbro.com
9
ES34069 Chassis User’s Manual Rev. A1
Motherboard Cage Removal
1 2
3 4
5 6
■Release two secure screws on the M/B cage ■Release two screws around the rear fans
■Remove the motherboard cage ■Disconnect the extension fan cables
■Detach the motherboard cage with System Cables
(SATA, Power, Fan cables) through the cable routing hole
■Finish detaching the M/B cage and make sure all the
connection on backplane and PDB are still tight before
assembly back the M/B cage

www.chenbro.com
10
ES34069 Chassis User’s Manual Rev. A1
Devices Installation
Other optional devices for ES34069 including:
zMini-ITX or Mini-DTX M/B
zSlim Optical Drive
zStandard SATA-II Hard Drive
z4-in-1 Card Reader
zDedicated Universal Heatsink for AMD / Intel CPU
Installing Mini-ITX or Mini-DTX M/B
Installing Slim Optical Drive
Before install the slim CD-ROM, the front bezel must be removed. And the slim CD-ROM
carrier should be apart from the chassis.
1 2
1 2
■Attach the motherboard I/O gasket (provided by M/B) ■Attach screws to fix the motherboard.
■Assemble the Slim CD-ROM adapter with attached
screws to the Slim CD-ROM
■Make sure the Slim CD-ROM is fully seated with
holder clip on the side.

www.chenbro.com
11
ES34069 Chassis User’s Manual Rev. A1
Installing 3.5” SATA-II Hard Drive
1 2
3 4
3 4
■Remove the HDD Carrier from the chassis and place
the SATA-II HDD into it.
■Attach the HDD screws on both sides
■Slide in the assembled HDD into the chassis, suggest
install by the ID definition on the front panel
(No need to remove the front bezel)
■Make sure the carrier is fully seated
■Slide the assembled CD-ROM into the chassis ■Make sure the holder latch is secured when fully
seated

www.chenbro.com
12
ES34069 Chassis User’s Manual Rev. A1
Installing Card Reader
1 2
3 4
5 6
■Detach the front screw of Card Reader holder ■Pull out the Card Reader holder
■Remove the seal on the holder and make sure the
sockets is right to the opening
■Attach screws to fix the Card Reader
■Connect the short end of USB split cable to Card
Reader
■Install the assembled Card Reader back to the
chassis with screw

www.chenbro.com
13
ES34069 Chassis User’s Manual Rev. A1
Installing Dedicated AMD / Intel Heatsink
The Chenbro heatsink for ES34069 is designed specifically to support Intel and AMD
desktop LV (Low Voltage) CPU in universally. Note the CPU power rating should not
over 65W as maximum.
1 2
3 4
■Attach the heatsink retainer on to M/B before install M/B
into the chassis (Note: AMD M/B are preinstalled it)
■After installing CPU with heat spread, gently clip the
heatsink with metal clipper in one end.
■Secure the heatsink clipper in other end ■Connect the heatsink fan to the M/B

www.chenbro.com
14
ES34069 Chassis User’s Manual Rev. A1
Installing Riser Card
Installing 2.5” HDD
Note: To install 2.5” HDD, the M/B cage is required to disassemble.
1 2
1 2
3 4
■Place the 2.5” HDD underneath the Slim ODD ■Fix the 2.5” HDD with attached screws
■The PCI card mounting bracket must be detach and
use special one for mounting, (Ex. PCI RAID card)
■Install the PCI card with riser into the slot gently.
(Please pay attention to the cable arrangement)
■Attach screws on the rear side to secure the PCI card
■Connect the cables before install.

www.chenbro.com
15
ES34069 Chassis User’s Manual Rev. A1
Connecting Devices
ES34069 is pre-installed with several cables inside as factory default,
which includes:
zSATA-II cable for Hot-swap hard drive
zPower cable for M/B
zFront panel I/O cables
USB 2.0 cable
4-in-1 card reader
Connecting SATA-II Cables
Note: If there is no enough SATA port on M/B, users can either remove or keep the
bundled P3/P4 SATA cable.
Connecting the Power
1 2
1 2
■Check the bundled cable with number tag ■Connect the SATA cables to the M/B properly
■The DC harness comes with 20+4 pin as main
connection for different M/B requirement.
■Install and secure the DC harness cable to the M/B
properly
■Secure the heatsink clipper in another end

www.chenbro.com
16
ES34069 Chassis User’s Manual Rev. A1
Connecting Front Panel I/O and LEDs
a. USB 2.0 cable connection
b. Front display cable connection
c. Card reader cable connection
1
1 2
1
■Front USB cable should be connected to on-board USB
header properly depends on different M/B.
■The fan-out cable with different connection for:
Power on, HDD, LAN, FAIL and the front switch
■Connect to the M/B according to the M/B pin header
definition properly.
■After installing the assembled Card Reader, the
shorter USB cable should be connected to the M/B

www.chenbro.com
17
ES34069 Chassis User’s Manual Rev. A1
d. Slim ODD cable connection
e. Cable management
1 2
■Use power split cable in accessory pack for conversion
of DC harness, small 4P is connected to the Slim
ODD adaptor board
■Use either standard IDE / SATA cable from 3rd party
M/B, or use optional cable from Chenbro to connect
to the Slim ODD adaptor board
1 2
■Due to limited space inside the chassis, make sure all
cable are connected properly and use the cable tie
through the bridge land on side wall
■Tie up the cable so the cables are fixed in certain
space.

www.chenbro.com
18
ES34069 Chassis User’s Manual Rev. A1
Power Adaptor and Backplane
Power Adaptor Specification:
For electrical specification:
Input Characteristics Output Characteristics
Item Spec Item Spec
Rated Input Voltage 100V / 240V Output Raged Voltage 19V
Input Voltage Range 90VAC to 264VAC Output Current 6.32A
Input Frequency Range 47Hz to 63Hz Output Voltage Setting 18.05V~19.95V
Efficiency 86%
In regards of the protection characteristics, this power adaptor will act as power
shut-down automatically base on:
zOver Current Protection
zOver Voltage Protection
zOver Temperature Protection
For the environment operation:
zTemperature: 0 ~ 40 degC @ Operating and -20 ~ +80 @ Storage
zHumidity: 20% ~ 80% @ Operating and 10% ~ 90% @ Storage
zMTBF: > 100,000 hrs
Mechanical characteristics:
zDimension: 167mm * 65mm * 37mm
zInput AC socket type:
zOutput DC cable length: 14#AWG, L=1.8m

www.chenbro.com
19
ES34069 Chassis User’s Manual Rev. A1
Power Distribution Board
The PDB (Power Distribution Board) inside the ES34069 is a specific DC to DC adaptor,
which only provides the converting from DC19V to multiple voltages include +5V, +3.3V
and +12V for all the devices and boards usage scale up to 180W Power Adaptor. As the
warning message on the back side, any improper 3rd party Power Adaptor may cause
damage to the PDB or internal components.
Connection of DC harness:
Note: Do not plug the DC cable in reverse direction, it will cause serious system and
power adaptor damage.
Connect backplane cables:
1 2
■When doing the PDB maintenance, please make sure
the cables are plugged properly
■The single ATX 20-pin connector should be connected
to PDB, another side with split 20+4 pin are for M/B.
1 2
■The SATA cables (tagged P1~P4) are strongly
recommended to connect following the port orders
indicated as picture.
■Connect the Big 4-Pin power to the backplane
P1
P2
P3
P4
20Pin
4Pin
6Pin

www.chenbro.com
20
ES34069 Chassis User’s Manual Rev. A1
2-port SATA-II Backplane Introduction
ES34069 is integrated with two SATA-II backplanes to support four 3.5” HDD
hot-swap feature. With dedicate backplane bracket assembled, users can directly
attach the HDD on the tray and plug into the HDD slot.
Hardware Specification:
Part Number 80H104534-001 Rev. A1
Host Interface SATA 7-pin compatible
HDD Interface SAS (22+7), SATA-II compatible
Hot-Swap Yes, allows user to on line replace Hard Disk Drive
Connectors
1. SATA-II x2 (to Host)
2. SAS (22+7) x2 (for HDD)
3. Standard 4P Power connector x 1 for +5V, +12V from
power supply
Dimension 232(L) x 27.4(W) x 1.6(T) mm
Backplane Connectors
(1) [CN11/CN21] : “22+7”pin SAS Connectors to HDD
(2) [CN22/CN12] : SATA Connectors to Host
(3) [CN1] : 4-pin Power Connector
(4) [CN3] : HDD Access LED Signal Pin Header
(5) [CN4] : HDD Failure LED Signal Pin Header
Connecting Pin 1 & 2 to the CATHODE of the HDD failure connector on RAID
card. Refer to the RAID card’s user manual for the detail pin definition.
CN4
CN22
CN1
CN11 (HDD 1)
CN12
CN21 (HDD 2)
CN3
HDD
1
HDD
1
HDD
2
HDD
2
