Cheviot 5160 User manual

Tel : [phone]
www.cheviotproducts.com
Model # 5160
INSTRUCTIONS
1. Attach the S-Union to the tub or wall
with flat metal washer and 1/2” lock nut.
Make sure that the escutcheon is tight
against S-Union arm (hand tighten only).
2. Attach faucet to S-Unions (3/4“
washers must be installed) and adjust
faucet so that it sits level. Now tighten
faucet nuts and then 1/2” lock nuts on
the back of the S-Unions. (Use a cloth
between the wrench and any finished
part of the faucet to prevent any
damage)
3. Next connect the water supply lines.
Must have hot going to hot side & cold
to the cold side. If using 1/2“ OD
decorative supply line connect the hex
nuts at the top of the supply lines to the
back of the S-Unions. If installing inside
the wall use copper fittings.
4. Attach diverter mechanism to the top
of the faucet body using 1/2” to 3/4”
cradle on to the lower portion of the riser
tube. Attach lower portion of the riser
tube to the add on diverter device.
adaptor supplied. Slide the hand shower
CARE AND MAINTENANCE
Minimum Maintenance is required to maintain product finish. With proper
maintenance your CHEVIOT Faucet will continually look like new. Special care
should be taken when cleaning your faucet and the following suggestions should help
extend your faucet life.
a) Cleaning should be done regularly using a soft cotton cloth and warm water, then
towel dry.
b) Do not use cleaners that contain abrasives or harsh chemicals; Care should be
taken in selecting cleaning supplies. Many cleaners contain detergents, ammonia, or
other corrosive solvents that could damage your faucet finish.
c) occasionally clean with a non-abrasive wax polish.
rubber
5. Next slide the wall support ring on to
the upper portion of the riser and attach
to bottom tube. Make sure that the
rubber gasket is inside the coupling nut
and position the curve part of tube such
that it is facing down in tub. Adjust wall
support ring to desired height and
tighten set screw.
Attach wall rod (cut non-threaded end for
desired length). Shower riser tube
should be parallel to the wall.
C
5"
4.5”
23
_
4
"
33
_
4
"
47
_
8
"
21
_
2
"
37
_
8
"
21
_
4
"
6"
61
_
2
"
62”
12" MAX
15
_
8
"
65 3
_
4
"

Tel : [phone]
www.cheviotproducts.com
CARE AND MAINTENANCE
Minimum Maintenance is required to maintain product finish. With proper
maintenance your CHEVIOT Faucet will continually look like new. Special care
should be taken when cleaning your faucet and the following suggestions should help
extend your faucet life.
a) Cleaning should be done regularly using a soft cotton cloth and warm water, then
towel dry.
b) Do not use cleaners that contain abrasives or harsh chemicals; Care should be
taken in selecting cleaning supplies. Many cleaners contain detergents, ammonia, or
other corrosive solvents that could damage your faucet finish.
c) occasionally clean with a non-abrasive wax polish.
8"
23
_
4
"
6"
6. Adjust hand shower cradle to desired
height and tighten by hex wrench
supplied.
7. Attached shower hose and hand
shower to diverter mechanism.
Model # 5160
INSTRUCTIONS
8. Once installed, remove aerator and
flush faucet and lines. This will remove
any debris that may be trapped. Then
attach shower head and aerator.
C
Backflow prevention device
6"
3"
23
_
4
"
21
_
2
"
