Chiltern Invadex TRT1 User manual

User Guide
TRT1 Height Adjustable - Hydraulic
TRT2 Static Height
TRT3 Paediatric Height Adjustable - Hydraulic
TRT4 Height Adjustable - Electric
ShowerTrolley
This user guide contains essential information in relation to safe use and maintenance and should
be retained with the shower trolley for reference

Issue 2.0
Contents
These products have been designed to the highest standards with safety, strength and quality in mind.
Follow the recommendations in this guide to ensure maximum benet from your shower trolley.
Your Chiltern Invadex shower trolley has been designed and tested to meet the highest standards of safety.
Read the safety section of this guide prior to use, this is contained on page 1.
Safety Considerations ................................. 1
Operating Instruction ................................... 2
Applying the Brakes..................................... 3
Latch Operation & Adjustment..................... 4
Cleaning & Maintenance ............................. 5
Charging the TRT4 ...................................... 5
Spare Parts.................................................. 6-7
Troubleshooting........................................... 8
Warranty ...................................................... 9
ShowerTrolley

Page 1
Issue 2.0 Issue 2.0 May 2018
Shower Trolleys
• Ensure that all users read this guide before operating the shower trolley.
• Maximum user weight of 190kg (30 stone) must not be exceeded.
• Prior to each use, inspect the shower trolley sides and brackets for signs of distortion or damage.
The trolley must not be used if any damage is observed.
• Under no circumstances should a client be left alone in the shower trolley.
• Although tted with castors, these are to enable ease of movement of the trolley the device is not
intended to be used for patient transportation.
• The trolley is a showering aid and is not intended for use as a bath. The shower trolley must not be
lled with water, as such no plug is provided and one should not be sourced elsewhere.
• Where the trolley is to be used by multiple bathers, cleaning with a medical disinfectant to prevent
cross contamination is strongly recommended. (follow the maintenance schedule on page 5).
• The lift/transfer of the client should be assessed and planned by a trained person.
• Any damage to the TRT4 electric actuator or charger should be reported immediately and the trolley
removed from use until repaired.
• The TRT4 should be subjected to a PAT test at least annually.
• It is recommended that shower trolleys are serviced by a qualied engineer at least annually, six
monthly in areas of high use (eg nursing homes).
Where there is any doubt as to the safety of the trolley it should be removed from use
pending inspection by a competent person.
Safety Considerations
This section should be read and understood prior to use of the shower trolley. Failure to adhere
to the below can lead to serious injury. Should clarification of any point be required, please
call Chiltern Invadex on 01869 365500 prior to use.

Shower Trolleys
Page 2
Issue 2.0
May 2018
Operating Instruction
1. Position the shower trolley near to the showering facility and locate the outlet pipe into a suitable
waste.
2. Prior to use, inspect the shower trolley for signs of distortion on the cot sides or latches. If the item
is damaged it should be considered unsafe and replaced. The shower trolley itself must not be
used if there is any sign of damage.
3. The trolley is designed to be angled to allow water run o󰀨 through the outlet pipe. To ensure that
water does not congregate around the users head, ensure that the liner is inserted correctly. (ie
that the outlet pipe is located at the lower end of the trolley when the trolley is raised.)
4. Ensure that the brakes are in the ON position prior to attempting any transfer and remain ON
whilst the trolley is occupied. (see page 3)
5. Position the trolley bed to its lowest position by depressing the down foot pedal or the down button
on the hand control for the electric (TRT4) model.
Note: the lower speed has been carefully set to provide a safe and controlled lower speed. Ap-
plication of force to the top of the cot side in an attempt to increase the speed can result in serious
damage to the cot side and the actuator.
6. Pull the latch lever down to release the cot side.
Note: cot sides lower on both sides of the trolley, where one side of the trolley is unattended the
latch must be checked prior to use to ensure that it is secure and will not release during use (see
page 4).
7. Unclip the poppers on the corners of the liner and lay the liner at.
8. Position the bather onto the shower liner.
Note: prior to attempting any transfer the action should be planned and prepared.
9. Rex the shower liner corners and reposition the cot side.
Note: ensure that latch locks securely into place. (see page 4)
10. Raise the trolley to a suitable height by depressing the up pedal or the up button on the hand
control for the electric (TRT4) model.
11. Proceed with bathing.
12. When bathing is complete remove the bather by repeating operations 5-7 in reverse. Brakes must
be applied.
13. Where the shower trolley is to be used by multiple bathers it is strongly recommended that the
trolley is cleaned after each use using a medical disinfectant (see page 5)
14. The TRT4 electric actuator should be charged in accordance with the instructions on page 5.
Never leave a user unattended in the shower trolley
A wall poster showing user instruction is available upon request to
[email protected].

Page 3
Issue 2.0 Issue 2.0 May 2018
Shower Trolleys
Applying the Brakes
To ensure the safety of both the end user and the carers, the braked castors should be checked for
damage prior to each use and applied during transfer and when in use.
As standard, shower trolleys have 4 braked castors. Braked castors are indicated by a GREY locking
lever.
Where requested at manufacturer , 3 braked and 1 directional lock castor. A directional lock castor is
indicated by a GREEN locking lever.
The brakes are applied/release as shown below;
The directional lock castor is indicated by a GREEN locking lever.
When applied (in the same manner as shown above) it is important to note that the directional lock is not
a brake it will lock the trolley into a straight steering position but will not prevent movement.
Please note: only one directional locking castor should be tted to the trolley, should more than one be
observed this should be reported to the service/maintenance contractor.
Applying wheel brake
Releasing wheel brake

Shower Trolleys
Page 4
Issue 2.0
May 2018
As the side rail of the trolley is lifted, the latch
makes contact with the locating pin. As you
continue to lift the latch opens and nally
clicks over the pin. As shown in A & B.
There should be no reason to open the latch
manually to achieve closure.
1.
If the latch is only partially engaged, the adjust-
ing screw is too far out.
If the latch does not open automatically the
screw needs adjusting outwards. A small
amount of silicone grease on the top of the
latch will assist with the automatic action.
When any adjustment is made the lock nut
must be fully tightened.
See gure D.
C
2.
When the side rail is vertical, the latch should
be fully engaged as shown in C.
3.
A
B
D
10mm
Latch pin
Latch lever
Lock nut
Side rail latch
adjustment screw
Latch Operation & Adjustment

Page 5
Issue 2.0 Issue 2.0 May 2018
Shower Trolleys
Prior to Use
Check cot sides and latches are secure and undamaged.
After Use
Rinse the unit, particularly the bathing area with warm clean water. Use a non abrasive cleaner if soiled.
For institutional use where the device is to be used by multiple bathers it is strongly recommended that
a medical disinfectant is used. Contact your infection control o󰀩cer for details of disinfectants approved
for this use by your institution.
Weekly
Thoroughly clean the unit, particularly the bathing area with warm clean water and a non abrasive cleaner.
For institutional use where the device is to be used by multiple bathers it is strongly recommended that
a medical disinfectant is used. Contact your infection control o󰀩cer for details of disinfectants approved
for this use by your institution.
Monthly
Flush the waste pipe with a disinfectant to help avoid cross contamination.
Yearly
It is recommended that the device is serviced at least annually by a qualied engineer.
The TRT4 electric trolley should be PAT tested on an annual basis.
Re-issue
Where a trolley is owned by a loan store or other authority where it is likely to be re-issued. It is recom-
mended that the item is fully disinfected (or a new liner obtained) and subjected to a full service prior
to issue.
For details of qualied service engineers please contact Chiltern Invadex.
Cleaning & Maintenance
Charging the TRT4
It is recommended that the battery pack is fully charged prior to
rst use. Charging time from at to full is approx 4 hrs.
The batteries are charged through the handset by connecting
the power lead to the handset as shown.
Whilst charging the LED on the charger will ash orange and will
change to green once fully charged.
It is recommended that the battery pack is charged at least
weekly in domestic use, or daily in institutional use.
When the battery is running low an audible bleep will sound as a warning that the trolley should be
recharged.
The handset is IP51 rated, however to prevent damage it should be protected from
water ingress and should not be submersed in water.
The trolley should not be charged whilst in the bathroom or any other wet environment.

Shower Trolleys
Page 6
Issue 2.0
May 2018
Item Description Part number Model
1a *Plastic top - Standard length (1930mm) TRTS012 T1, T2 & T4
1b *Plastic top - Paediatric (1600mm) TRTS015 T3
1c *Plastic top - Bespoke TRTS013 T1, 2, 3 & 4 SPEC
2a *Cot side - Standard length TRTS032 T1, T2 & T4
2b *Cot side - Paediatric TRTS038 T3
3 **Wedge cushion TRTS003 All
4a **Trolley liner - Standard length TRTS001V T1, T2 & T4
4b **Trolley liner - Paediatric TRTS009V T3
4c **Trolley liner - Bespoke TRTS002V T1, 2, 3 & 4 SPEC
5a *Cot end - Waste pipe end TRTS033 All
5b *Cot end - Head end TRTS036 All
2
8
10
6
5
a
4
1
11
3
9
7
5b
id3060640 pdfMachine by Broadgun Software - a great PDF writer! - a great PDF creator! - http://www.pdfmachine.com http://www.broadgun.com
Spare Parts
12

Page 7
Issue 2.0 Issue 2.0 May 2018
Shower Trolleys
In the interests of user safety it is recommended that parts indicated * should be installed by a qualied
engineer
**Part numbers supplied are for standard Grey fabric, if your fabric is any other colour please call as
this would indicate a special item.
6a Waste outlet pipe - standard length (1m) TRTS010 All
6b Waste outlet pipe - Bespoke TRTS014 All
6c Backnut (waste hose) CH0400 All
7 *5” Braked castor 202-00031 All
8 *5” Straight steering castor 202-00030 All
9 *Foot pedal assembly TRTS004 T1 & T3
10 Foot pedal rubber CH0181 T1 & T3
11 *Hydraulic ram TRTS006 T1 & T3
12 *Cot side latch assembly TRA017 All
Electric model only
*Electric actuator TRTS026 T4
Control/battery box TRTS027 T4
Charger TRTS029 T4
Handcontrol CH0653 T4

Shower Trolleys
Page 8
Issue 2.0
May 2018
Troubleshooting
Symptom Suggested Cause Solution
Hydraulic Models
Shower trolley will not raise Hydraulic unit failure Call out required
Shower trolley will not lower Obstruction
Hydraulic unit failure
Clear obstruction
Call out required
Shower trolley will not stay at
desired height
Pedal is sticking
Hydraulic unit failure
Clean pedal and check for free
movement
Call out required
Electric Model
Shower trolley will not raise
or lower
Battery power is low Charge batteries, see page 5
Shower trolley will not raise Handset or actuator failure Call out required
Shower trolley will not lower Obstruction
Handset or actuator failure
Clear obstruction
Call out required
Shower trolley will not stay at
desired height
Actuator fault Call out required
All Models
Cot side will not move Weight against cot side or
hinges jammed
Push cot side inwards before
trying to release the catch.
Lubricate the hinges
Cot sides will not lock into
position
Latch screw requires adjust-
ment
Cot sides are damaged
Refer to page 4
Call out required
Water leaks Liner or waste hose are
damaged
Waste hose is not in waste
outlet
Check for damage and replace
Check that the hose is secure-
ly tted into the outlet
For further advice and guidance please contact Chiltern Invadex on 01869 365500 or at
[email protected].
To arrange a service call out please contact our service department on 01869 365500 Opt 3 or at
[email protected].
If there is any doubt about the condition of the trolley it must be discontinued from use until a
service call has been completed.

Page 9
Issue 2.0 Issue 2.0 May 2018
Shower Trolleys
The below space can be used to store details of your maintenance contractor, if the
equipment has been provided by a third party for example the Local Authority loan store,
this information will be available from them.
Your Chiltern Invadex Shower Trolley carries a 12 month warranty from the
date of purchase, subject to the following conditions;
1. Should you experience any problems with our workmanship or materials within the rst
12 month period please contact your point of purchase.
2. Repairs made during the warranty period will be carried out free of charge, provided the
product has been used strictly in accordance with the guidelines set out in this user guide.
3. Our warranty does not cover replacements, adjustments or repairs which may be required
as a result of normal wear and tear, wilful or accidental damage, misuse, neglect or any
other cause which is beyond the control of Chiltern Invadex.
4. Modications and repairs made to this product by unauthorised persons will render the
warranty void.
5. Only parts manufactured or approved by Chiltern Invadex shall be used to repair this
product. Use of unauthorised parts will invalidate all warranties and remove all liability
from Chiltern Invadex for the safety of this product.
6. Chiltern Invadex shall in no event be liable for any damages, costs or expenses arising
from any claim made under this warranty (save for any legal liability of Chiltern Invadex for
death or personal injury resulting from the company’s negligence in respect of its products).
7. This warranty does not a󰀨ect your statutory consumer rights.
Warranty
Contractor name:
Contact number:
Account number:
Serial number:

FM553189
To request a copy of this guide in large print
please contact
customer services on 01869 365500 opt 1 or
email: [email protected]
Copyright © C h i l t e r n Invadex (UK) Ltd The design of the product shown in this guide is vested in Chiltern Invadex (UK) Ltd and should not be copied or reproduced in anyway
whatsoever without the express permission in writing of Chiltern Invadex (UK) Ltd.
Registered in England No: 04704248 CH0004 Issue 2.1
July 2019
ShowerTrolley
Chiltern Invadex (UK) Limited
Unit 6C
Thorpe Drive
Banbury
OX16 4UZ
UK
[phone]
[email protected]
www.chilterninvadex.co.uk
