VITACON VitaScan LT Troubleshooting guide

VitaScan LT
USB Ultrasound Bladder Scanner
Version 4.5.4.14 | Date: 7th of January 2020
User and Service Manual
www.vitacon.com

VitaScan LT
User and Service Manual
Ver/Rel.
No
Release
Date
Mod. By
Mod. Date
Rev. By
Relevant
Stakeholders
Rev. Dt.
Auth. By
Auth. Date Remark/Revision Details Page revised
4.5.4 23rd-June-17
MW MW MW Added Manual Contour Correction,
start from INI le, Annual calibration
update, Manufacturer and US o󰀩ce
23rd-June-17 23rd-June-17 23rd-June-17
4.5.4 24th-Nov-17
MW MW MW Added Easy-mode,
Setup GUI update.
24th-Nov-17 24th-Nov-17 24th-Nov-17
4.5.4 17th-Jan-18
MW MW MW
Included Probe ID in INI le 29,30,31
17th-Jan-18 17th-Jan-18 17th-Jan-18
4.5.4 8th-Feb-18
MW MW MW Amended Warranty
policy for US market. 32
8th-Feb-18 8th-Feb-18 8th-Feb-18
4.5.4 9th- Oct-18
MW MW MW Added Acer Switch 3 as tablet option
Added Discard Pubic bone feature
5, 12
9th-Oct-18 9th-Oct-18 9th- Oct-18
4.5.4 4th-Jul-19
MW MW MW Updated text and images to
VitaScan v2 probe
4th-Jul-19 4th-Jul-19 4th-Jul-19
4.5.4 25th-Oct-19
MW MW MW Updated text and images to
VitaScan v2 probe
19,20,28
25th-Oct-19 25th-Oct-19 25th-Oct-19
4.5.4.14 7th-Jan-20
MW MW MW Updated Accuracy on Phantom
Specs, and required software 4, 11
7th-Jan-20 7th-Jan-20 7th-Jan-20
The Information contained in this user and service manual is proprietary to Vitacon. It is only used for convenience of
our customers. It may be changed in whole or in part without written notice. Any service work performed by persons who
are not authorized by Vitacon may void your warranty.
www.vitacon.com

Vitacon provides this publication as
is without warranty of any kind, either
expressed or implied, including but
not limited to the implied warranties of
merchantability or tness for any particular
purpose. Further, Vitacon reserves the
right to revise this publication and to make
changes from time to time to the content
hereof, without obligation to Vitacon or its
local representatives to notify any person
of such revisions or changes. Some
jurisdictions do not allow disclaimers of
expressed or implied warranties in certain
transactions; therefore, this statement
may not apply to you.
In Europe:
Oce Address:
Vitacon AS
Vegamot 8B
7049 Trondheim, Norway
E-mail: [email protected]
http://www.vitacon.com
In North America:
Vitacon US
600 Twelve Oaks Center
Drive Suite 685, Wayzata
MN 55391, USA
E-mail: [email protected]
http://www.vitacon.us
Manufacturer:
UAB Vitacon LT
Naujoji g. 12-525
Alytus 63250
Lithuania
Copyright 2020.
All rights reserved.
PN: 6100-500
Vitacon warrants that the VitaScan
LT Ultrasound Bladder Scanner will
substantially conform to published
specications and to the documentation,
provided that it is used for the purpose
for which it was designed. Vitacon will,
for a period of sixty (60) months from
date of purchase, replace or repair any
defective device, if the fault is due to
a manufacturing defect. In no event
will Vitacon or its local representatives
be liable for direct, indirect, special,
incidental, or consequential damages
arising out of the use of or inability to
use the VitaScan LT Ultrasound Bladder
Scanner, even if advised of the possibility
of such damages. Vitacon or its local
representatives are not responsible for
any costs, loss of prots, loss of data,
or claims by third parties due to use
of, or inability to use the VitaScan LT
Ultrasound Bladder Scanner. Neither
Vitacon nor its local representatives will
accept, nor be bound by any other form
of guarantee concerning the VitaScan
LT Ultrasound Bladder Scanner other
than this guarantee. Some jurisdictions
do not allow disclaimers of expressed or
implied warranties in certain transactions;
therefore, this statement may not apply to
you.
VitaScan LT
User and Service Manual
Disclaimer
Contacting Vitacon:
Limited Warranty
www.vitacon.com

VitaScan LT
User and Service Manual
Table of Contents
Tables of Contents ................................................................................................................1
Introduction............................................................................................................................2
Important Information ...........................................................................................................2
Indications for Use ................................................................................................................3
Product Featues....................................................................................................................3
Unpacking and Inspection ....................................................................................................3
Content of the packaging: .....................................................................................................4
Storage .................................................................................................................................4
Technical Specications .......................................................................................................4
Product Upgrades and Updates ...........................................................................................5
About the System Software .................................................................................................. 5
About the Ultrasound System ............................................................................................... 5
Electrical Safety ....................................................................................................................6
Equipment Safety .................................................................................................................7
Safety and Performance Summary ......................................................................................7
Labeling Symbols .................................................................................................................8
Applicable Standards/Approvals............................................................................................9
Applying the Ultrasound Gel ...............................................................................................10
Measuring Bladder Volume ................................................................................................ 10
Regular Inspections and Maintenance ................................................................................11
Care, Cleaning and Disinfecting .........................................................................................12
VitaScan LTApplication Software Installation .....................................................................13
System Requirements ........................................................................................................13
Installation of the VitaScan LT application ..........................................................................13
USB driver Installation ........................................................................................................16
User Guide .........................................................................................................................19
PC Software Application Key Features ...............................................................................19
Application Features ...........................................................................................................19
Run VitaScan LT application................................................................................................20
Scanning on Vitacon Phantom............................................................................................29
How to run VitaScan LT application remote from INI le .....................................................30
Application – Troubleshooting ............................................................................................. 32
Warranty and Disclaimer Information.................................................................................. 33
Service.................................................................................................................................34
Manufacturer: ......................................................................................................................37
1
PAGE www.vitacon.com

VitaScan LT
User and Service Manual
VitaScan LT Ultrasound Bladder Scanner
Real-time bladder scanning is a safe and
easy, non-invasive method to measure
bladder volume. Bladder scanning
measures ultrasonic reections within
a patient’s body and di󰀨erentiates the
urinary bladder from the surrounding
tissues.
The VitaScan LT is a B-mode ultrasonic
instrument, portable and battery
operated, intended for the non-invasive
measurement of urinary bladder volume.
A mechanical sector scanning transducer
provides cross-sectional images of the
bladder from up to twenty four scan
planes. Based on these images the
VitaScan LT automatically calculates the
estimated bladder volume in milliliters and
displays it on a screen.
VitaScan LT is applicable in many clinical
areas to determine bladder volume, time
for bladder emptying and detection of post
void residual volume (PVR).
A real-time image of the bladder during
pre-scan makes it easier to detect the
bladder before scanning.
Noce To All Operators:
The VitaScan LT should be used only by
individuals who have been trained and
authorized by a physician or the institution
providing patient care. All operators
should read this manual prior to using
the VitaScan LT. Failure to comply with
these instructions may compromise the
performance of the instrument and the
safety of the patient.
Biological Safety:
To date, exposure to pulsed diagnostic
ultrasound has not been shown to
produce adverse physiological e󰀨ects.
However, ultrasound should be used only
by a medical professionals when clinically
indicated, using the lowest exposure
times possible commensurate with clinical
utility.
The ultrasonic output power of the
VitaScan LT is not user-adjustable and is
limited to the minimum level necessary for
e󰀨ective performance. Data on acoustic
output levels can be found in the section
titled, “Technical Specications” in this
manual.
It is recommended that users read the
Health Canada Guidelines for the Safe
Use of Diagnostic Ultrasound before
using this, or any other diagnostic
ultrasonic device. (http://www.hc-sc.gc.ca/
ewh-semt/alt_formats/hecs-sesc/pdf/
pubs/radiation/01hecs-secs255/01hecs-
secs255-eng.pdf , note this link may
change over time).
Statement of Intended Use:
The VitaScan LT projects ultrasound
energy through the lower abdomen of the
patient to obtain an image of the bladder.
This image is used to determine bladder
volume noninvasively.
Contraindicaons
The VitaScan LT is not intended for fetal
use or pregnant patients.
Warning: Exposure of low power
diagnostic ultrasound has not been
shown to produce adverse e󰀨ects.
However, medical professionals
should use ultrasound only when
clinically indicated.
Introduction
Important Information
!
2
PAGE
www.vitacon.com

VitaScan LT
User and Service Manual
Warning:
There is the hazard of possible explosion
if the VitaScan LT instrument is used in the
presence of ammable anesthetics.
First Time Users:
We advise new operators to use the
VitaScan LT on patients with moderately full
bladders, rather than initially attempting to
locate nearly empty bladders.
Cauon:
The VitaScan LT should not be used on
a patient with open skin or wounds in the
suprapubic region.
• The manual measurement function
should be used on patients with
catheters, as catheter can reect
ultrasound signals that can lead to
inaccurate volume measurement.
• User care with suprapubic/pelvic
surgery patients, Scar tissue, incisions,
sutures and staples a󰀨ect ultrasound
transmission and reection.
• Accuracy may be a󰀨ected for patients
with ascites or free oating uid in the
peritoneum.
Cauon:
It is recommended to operate this equipment
only on battery power if you are using the
software on a non-medical grade computer.
Indicaons for Use
This manual is directed toward the reader
who is familiar with Ultrasound techniques.
Sonography training and clinical procedures
are not included here. This manual is
not intended as training material for the
principles of ultrasound, anatomy, scanning
techniques, or applications. You should be
familiar with all of these before attempting to
read this manual or using the device.
Product Features
• Real-time Ultrasound Bladder Scanner.
• 3D ultrasound scanner & PC running
Windows 10 OS
• USB ultrasound probe connection
• Bladder volume calculations in large
digits
• Storage of ultrasound images
Unpacking and Inspecon
• There are no special unpacking
instructions, but be careful not to
damage the instrument when unpacking
it. When unpacking the VitaScan LT to
check for damage during shipment:
• Inspect the shipping carton for damage.
If the shipping carton is damaged,
carefully continue unpacking the
instrument and note any dents and
scratches on the VitaScan LT. Save the
damaged shipping carton and packing
material for the carrier’s inspection and
contact the respective carrier. If there is
any damage on the scanner equipment,
contact Vitacon.
• If there is no shipping damage,
continue removing the VitaScan LT
from the shipping case. Save the box
and packing materials; they will be
needed when returning the VitaScan
LT to Vitacon for recalibration or future
service.
• Verify that all items listed on the packing
list have been received and are in good
condition.
!
!
!
Note:
This box contains specically designed foam inserts to ensure safe shipment of the
VitaScan LT. Save these for future shipment of the unit for service or calibration.
3
PAGE www.vitacon.com

VitaScan LT
User and Service Manual
!
Content of the packaging:
• VitaScan v.2 probe
• USB Memory stick with Application Software and User & Service Manual
• VitaScan v.2 probe holder
• Installation guide in English
Storage
If the system is to be stored, pack it in the original soft case container, and keep it in an
environment free of corrosive material, uctuations in temperature and humidity, and vibration
and shock.
Warning:
Do not have VitaScan LT connected to any device while stored in the original soft case container.
Storage Requirements:
Storage temperature from -30°C to 50°C
Relative humidity of 20% to 90% @ 30°C, non-condensing
Atmospheric pressure from 700 hPa to 1060 hPa
As with most electronic equipment, the unit should be operated in a dry area within normal
temperature limits (+10°C to +45°C, 10% - 80% humidity).
Dispose electronic waste:
VitaScan LT complies with the WEEE Directive (2002/96/EC) marking requirements. The a󰀩xed
label indicates that you must not discard this Medical Electric Equipment in domestic household
waste. Product category: With reference to the equipment types in WEEE directive annex IA,
this product is classed as category 8 “Medical Devices”. To return unwanted products, contact
Vitacon at the address mentioned at the front of this manual or your local VitaScan distributor.
Technical Specicaons - Vitascan v.2
• Volume range:..............................................................................................0 – 1000 ml
• Accuracy....................................................... ± 7.5% on volumes greater than 100 ml¹
.........................................................................± 7.5 ml on volumes less than 100 ml¹
• Frequency:......................................................................................................3.40 MHz
• Acoustic Output:.....................................................MI max: 0.38, Power: 0.25 mW/cm²
• Thermal Index – TI...............................................................................................< 0.02
• Scanning method:..........................................................................Sector, 180 degrees
• Rotation positions: ............................................................6, 12 or 24 rotating positions
• Sweep angle:............................................................................................. 130 degrees
• Max detection depth:......................................................................100, 160 or 230 mm
• Max probe temperature:......................................... 35°C @ 22°C ambient temperature
• Dimension...................................... (L x W x H) 18.5 x 4.5 x 4.5 cm (7.3 x 1.8 x 1.8 in.)
• Weight incl. cable:.................................................................................. 0.36kg (0.79lb)
• IP rating:..................................................................................................................IPX7
• Power Supplied by ........................................................................USB port: 0.5A @ 5V
• Operating conditions:...........................+10°C to + 45°C, 10 % - 80 % relative humidity
• Storage temperature:.............................................................................-30°C to +50°C
• PC requirements:..................................................................................Windows 10 OS
• PC Input method:....................................................Mouse, keyboard and touchscreen
¹ Accuracy specications in accordance with stated instructions, scanning on Vitacon phantom
and using software version 4.5.4.14 and above.
4
PAGE
www.vitacon.com

VitaScan LT
User and Service Manual
Product Upgrades and Updates
Vitacon may o󰀨er software upgrades and new features that may improve system
performance. User and Service Manual updates, explaining the e󰀨ects of upgrades and
new features on system performance, will accompany the upgrades.
About the System Soware
The VitaScan LT system contains software that controls its operation. Vitacon will provide
you with a USB Memory stick containing the software. Typically new software provides new
capabilities.
About the Ultrasound System
The VitaScan LT System includes: USB Probe, and tablet computer Lamina T-1022. For
electrical safety reasons you should always power tablet with only battery power.
PC UBM Applicaon
Block
Device Driver /
API Interface
VitaScan LT System
Number Features Specicaons
1 USB Scanner VitaScan v.2
2Tablet/Computer Lamina T-1022
3 Software version 4.5.4 or higher VitaScan LT
4 USB Memory stick With Software &
Documentation
5
PAGE www.vitacon.com

VitaScan LT
User and Service Manual
Warning:
To avoid the risk of electrical shock
or injury, do not open the system
enclosure.
All internal replacements must be
made by a qualied technician.
To avoid the risk of injury, do not
operate the system in the presence
of ammable gasses or anesthetics.
To avoid the risk of electrical
shock, use only properly grounded
equipment.
Shock hazards exist if the power
supply is not properly grounded.
Grounding reliability can only
be achieved when equipment is
connected to a receptacle marked
“Hospital Only” or “Hospital Grade”
or the equivalent. The grounding
wire must not be removed or
defeated. Run Tablet on battery
(internal electrical source) whenever
integrity of the external protective
earth conductor arrangement is in
doubt.
To avoid the risk of electrical shock,
before using the VitaScan LT,
inspect the housing and USB cable.
Do not use the VitaScan LT if these
are damaged.
To avoid the risk of electrical shock,
always disconnect the USB Cable
from the PC before cleaning the
system.
To avoid the risk of electrical shock,
do not use any transducer that has
been accidentally immersed in any
liquid, or has been immersed in
any liquid for cleaning or any other
purpose.
To avoid the risk of electrical shock,
do not touch Tablet/Computer
output connector (like USB port and
others) and the patient at the same
time.
! ! Cauon:
Although your system has been
manufactured in compliance with
existing EMC/EMI requirements
(EN60601-1-2), use of the system in
the presence of an electromagnetic
eld can cause degradation of the
ultrasound image. If this occurs
often, Vitacon suggests a review of
the system environment. Identify
and remove the possible sources of
the emissions or move your system.
Medical Electric Equipment can be
a󰀨ected by portable or mobile RF
communication devices. Turn OFF
any portable or mobile RF device
before operating your system.
Electrostatic discharge (ESD), or
static shock, is a naturally occurring
phenomenon. ESD is common in
conditions of low humidity, which
can be caused by heating or air
conditioning.
Static shock is a discharge of
electrical energy from a charged
body to a lesser or non-charged
body. The degree of discharge can
be signicant enough to cause
damage to a transducer or an
ultrasound system. The following
precautions can help reduce ESD:
anti-static spray on carpets, anti-
static spray on linoleum, and anti-
static mats.
Do not use the system if an error
message appears on the display:
note the error code; call Vitacon or
your local representative; turn o󰀨
the system.
Electrical Safety
This system meets EN60601-1, Class I and Type BF isolated patient-applied parts safety
requirements. This system complies with the applicable medical equipment requirements
published in the European Norm Harmonized Standards, Underwriters Laboratories (UL)
and the Canadian Standards Association (CSA).
For maximum safety observe the following warnings and cautions:
6
PAGE
www.vitacon.com

VitaScan LT
User and Service Manual
Cauon:
• Use the system on with only battery
power, do not use while charging.
• To avoid the risk of excessive heating or
damage to the system, use the system
in a well ventilated environment.
• If the operating environmental
temperature exceeds 25°C, limit scans
to 5 minutes and allow a 10-minute
cooling period between scans.
• Excessive bending or twisting of cables
can cause a failure or intermittent
operation.
• Do not submerge the VitaScan LT in any
solution, follow the cleaning instructions.
• To avoid damaging the power supply,
verify the power supply input is within
the correct voltage range.
• Do not short the battery terminals.
• Always charge the tablet battery before
using the system, to avoid the risk of the
system turning o󰀨 while in use.
• Incorrect cleaning or disinfecting of any
part of the system can cause permanent
damage.
• Do not use solvents such as thinner or
benzene, or abrasive cleaners on any
part of the system.
• Do not spill liquid on the system.
• Do not use the system if it exhibits
erratic or inconsistent behaviour. Turn
O󰀨 the power of the system and call
Customer Service.
• Do not dispose of the battery in re.
• Immediately discontinue use of the
battery if, while using, charging or
storing the battery, the battery emits an
unusual smell, feels hot, changes colour
or shape, or appears abnormal in any
other way. Contact a customer service
representative if any of these problems
are observed.
• Do not use the VitaScan LT if its head or
cable is damaged.
• Do not use the VitaScan LT if there is
evidence of leakage of internal liquids.
Wash hands immediately in warm,
soapy water. Consult the MSDS on
Polypropylene Glycol for additional
information/precautions.
• To avoid the risk of electrical shock, do
not use any VitaScan LT that has been
immersed in liquid.
!
Equipment Safety
To protect your ultrasound system, scanner, and accessories, follows these precautions.
Safety and Performance Summary
The VitaScan LT computes the volume of the urinary bladder based upon twenty four cross-
sectional ultrasound images (or less). For maximum accuracy, be sure to hold the Scan
head motionless while scanning.
The most accurate measurements are obtained when the patient rests quietly in the supine
position.
Accuracy is compromised if the user does not obtain an optimal, repeatable image.
Errors in usage tend to result in the underestimation of bladder volume, except in cases
where the Scan head is moved during scanning. In this case, the measurement may
overestimate the patient’s bladder volume.
The patient being scanned should not have a catheter in his/her bladder. This could create
micro bubbles in the bladder, which a󰀨ect the accuracy of the measurement.
Do not use the VitaScan LT on patients with open skin or wounds in the suprapubic region.
Use care when scanning suprapubic and pelvic surgery patients. Scar tissue, surgical
incisions, sutures, and staples can a󰀨ect ultrasound transmission and reection.
7
PAGE www.vitacon.com

VitaScan LT
User and Service Manual
Warning
There is the possible hazard of explosion if the VitaScan LT is used in the presence of
ammable anesthetics.
Labeling Symbols
!
!
CE mark – Noed body no.2274 Warning, consult
accompanying documents
Read the documentaon
Ultrasound radiaon
Water submersion
Test Agency Cercaon Mark –
North America
BF type (Body Floang)
WEEE - Waste Electrical and
Electronic Equipment
8
PAGE
www.vitacon.com

VitaScan LT
User and Service Manual
Applicable Standards/Approvals
93/42/EEC Council Directive concerning medical devices
EN ISO 13485:2012+ AC:2012 Medical devices- Quality management systems-
Requirements for regulatory purposes
EN ISO 14971:2012 Medical devices –Application of risk management to medical
devices
EN ISO 14155:2011 Clinical investigation of medical devices for human subjects — Good
clinical practice
EN 60601-1:2006+ AC:2010 + A1:2013 Medical electrical equipment -- Part 1: General
requirements for basic safety and essential performance
EN 60601-1-1:2001 Medical electrical equipment. Part 1-1: General requirements for
safety. Collateral standard: Safety requirements for medical electrical systems (IEC 60601-
1- 1:2000)
EN 60601-1-2:2015 Medical electrical equipment Part 1: General requirements for
safety 2.Collateral Standard: Electromagnetic compatibility - Requirements and tests
EN 60601-1-4: 1996+ A1:1999 Medical electrical equipment-Part 1-4 General
requirements for safety- Collateral Standard: Programmable electrical medical systems
EN 60601-1-6:2010 Medical electrical equipment-Part 1-6: General requirements for
safety- Collateral Standard: Usability
EN 60601-2-37:2008+A11:2011 Medical electrical equipment-Part 2-37: Particular
requirements for the safety of ultrasonic medical diagnostic and monitoring equipment)
EN 62304:2006+АС:2008 Medical device software – Software life-cycle processes
EN 62366:2008 Medical Devices. Application of usability engineering to medical devices
EN 60529:1991+A1:2000 Degrees of protection provided by enclosures (IP code)
9
PAGE www.vitacon.com

VitaScan LT
User and Service Manual
Applying the Ultrasound Gel
Palpate the patient’s symphysis pubis (pubic bone) and apply the Gel immediately superior
to the patient’s symphysis pubis, as shown in images below. Or apply the Gel around the
dome of the Scanhead. Smooth the gel out and remove any air bubbles, which may block
ultrasound transmission.
Using Ultrasound Gel Pad:
Sometimes it may be convenient to use ultrasound transmission Gel pad. The Gel pad is an
easy-to-use coupling medium.
To apply the ultrasound Gel Pad, peel back the foil lid of the individual gel pad package,
exposing the gel pad.
Measuring Bladder Volume
Palpate the patient’s symphysis pubis and place the Scanhead midline on the patient’s
abdomen, approximately 4 cm (1.5 inches) superior to the symphysis pubis, as shown in
images below.
10
PAGE
www.vitacon.com

VitaScan LT
User and Service Manual
Note:
While scanning, avoid making any changes in the position, angle or pressure of the
Scanhead.
Regular Inspecons and Maintenance
VitaScan LT is a Medical Electric Equipment and therefore needs special precautions
regarding EMC. VitaScan LT needs to be installed and put into service according to the
EMC information provided in the accompanying documents.
Weekly Inspecons:
Once a week, you should inspect the Scanhead and cable for physical faults or cracks.
Cracks that allow the leakage or ingress of uid may a󰀨ect the safety and/or the
performance of the instrument. Any apparent faults or cracks must be referred to your
authorized VitaScan Service Center or your local VitaScan distributor.
Monthly Accuracy Check:
Cauon:
In the event of changes in the performance of the instrument, discontinue use and contact
your authorized VitaScan LT Service Center or your local VitaScan LT distributor.
Each month, or whenever accuracy assessment is desired or in question, the accuracy of
the VitaScan LT should be tested using the following procedure:
• Take a Pre-void measurement of bladder volume.
• Void or catheterize into a measuring beaker.
• Take a post-void measurement of bladder volume to check for post-void residual (PVR)
• Subtract the post-void measurement form the pre-void measurement and compare to
the voided volume.
• Take a measurement on a Vitacon Phantom.
• The measured volume should be within a range ± 7.5% on volumes greater than 100
ml¹
• or ± 7.5 ml on volumes less than 100 ml¹
¹Accuracy specicaons in accordance with stated instrucons, scanning on Vitacon
phantom.
• Aim the Scanhead so the ultrasound is
projected toward the expected location
of the bladder. For most patients, this
means aiming the tip of the Scanhead
toward the patient’s coccyx.
• Press and release the scan button,
located on the Scanhead.
• Locate the bladder.
• Press and release the scan button and
hold the Scanhead steady throughout
the scan.
11
PAGE www.vitacon.com
!

VitaScan LT
User and Service Manual
No annual Inspection and Maintenance is required on your VitaScan LT. If the Monthly
Accuracy Check fails, you should:
• Perform an online integrity and calibration service using a Calibration Test Tool; or
• Perform an o󰀨-line verication test using a Verication Test Tool; or
• Contact your local dealer to learn about options for sending in the device for
manufacturer calibration.
Care, Cleaning and Disinfecng
Clean the VitaScan LT with a so cloth soaked in a mild liquid detergent soluon. Rinse with
clean water and carefully dry with a clean so cloth. Dampen a so cloth with 70% ethanol.
Wipe the probe with the dampened so cloth and let the ethanol evaporate.
If the VitaScan probe needs to be disinfected, we recommend CIDEX® OPA Soluon, PDI
Sani-Cloth AF3 Germicidal Disposable Wipes, or other comparable disposable wipe designed
for use on non-porous plasc surfaces. You may also use any glutaraldehyde based hospital
disinfecon soluon or Clorox Healthcare bleach products. Dampen a so cloth and wipe the
instrument thoroughly. To remove all traces of disinfecon soluon, wipe the VitaScan with a
clean so cloth dampened with sterile water or cleaning soluon. Carefully dry the VitaScan
with a clean so cloth before use. Use appropriate hand protecon according to the labeling
on the disinfectant to avoid skin reacons.
Warning:
• Do not subject any part of the VitaScan LT to steam sterilization or ethylene oxide
sterilization.
• Do not immerse the instrument in any cleaning or disinfecting solution.
!
12
PAGE
www.vitacon.com

VitaScan LT
User and Service Manual
VitaScan LT Applicaon Soware Installaon
Before use on patient:
Read the User Manual which is on the USB Memory stick, and follow user instructions for
the scan-procedure.
System Requirements :
• Windows 10 Operating System, 32 or 64 bit.
• The minimum recommended system conguration is 1GB RAM & 1.3 GHz processor
speed.
• VitaScan USB Probe (Firmware version 4.04 or higher)
• Tablet/Computer type: Lamina T-1022.
• USB 2.0 port to source 500mA @ 5V
• Medical Isolation Device – e.g. Tripp Lite IS150HG (N/A) or Noratel IMEDe 150 (Int’l)
Note:
Installing VitaScan LTApplication Software on Windows 10 Operating System requires the
operator is logged in as “Administrator”.
Installaon of the VitaScan LT applicaon
• Open the folder to view the “VitaScan_LT_Installer” les on the USB Memory stick
• Run the VitaScan_LT_Installer.exe le
• Press Next.
13
PAGE www.vitacon.com

VitaScan LT
User and Service Manual
• The “Next” button gets enabled when user chooses to accept the license agreement
terms and conditions.
• Press Next, (It is recommended to install in the default director)
14
PAGE
www.vitacon.com

VitaScan LT
User and Service Manual
• Press Start.
• Press Next.
• Finish the installation by pressing Exit.
• After a successful installation a VitaScan LT icon will appear on your desktop.
15
PAGE www.vitacon.com

VitaScan LT
User and Service Manual
USB driver Installaon
• VitaScan LT installation requires installation of the USB driver for the VitaScan LT.
• Press ‘OK’.
• Connect the probe in the USB-port and press ‘OK’.
• Press ‘Start’ to start the installation process.
16
PAGE
www.vitacon.com

VitaScan LT
User and Service Manual
• Disconnect the probe from the USB-port and press ‘OK’.
• Press ‘Install’ to proceed the installation process.
• Press ‘OK’, to nish the installation process.
17
PAGE www.vitacon.com
