Handicare Micro Pilot Joystick User manual

Description Article number
Micro Pilot Joystick - Mounting on worktop 1016512
Micro Guide Joystick - Mounting on worktop 1016672
9009447-Micro Pilot-Micro guide - Fixed on worktop-EN_NO-B
ASSEMBLY INSTRUCTION
Micro Pilot Joystick /
Micro Guide Joystick

Torx 30 mm
Dril
Included in kit 00355.0477 00355.0471 1016679 1016681 1016729 1016677 1016716
1016512 111 111
1016672 11 1111
EN
1. Monter bordbraketten på armlenet. Skyv bordrøret inn i braketten og stram til låserattet.
2. Monter Omni-skjermbraketten
3. Monter den utsvingbare styreboksbraketten.
4. Monter joysticken på bordplaten og juster joystickens høyde.
5. Bor hull i bordplaten til Buddy-knappene (gjøres med brukeren i rullestolen). Monter joysticken på
bordplaten og sett opp kablingen.
Se den tekniske manualen for R-net Omni for oppsett av systemet.
NO
1. Fit the worktop bracket to the armrest. Slide the worktop tube into the bracket and tighten the
locking knob.
2. Assemble the Omni screen bracket.
3. Assemble the swing-away controller bracket.
4. Mount the joystick in the worktop and adjust the height of the joystick.
5. Drill holes in the worktop for the buddy buttons (to be done with user in the wheelchair). Mount the
joystick to the worktop and set up the cabling.
In order to set up the system, see R-net Omni technical manual.
2

1
4
3
5
2
1
1
3
3
2
41
2
3
4
2
1
1
3
1
2
1 2
3
4
3

www.handicare.com
BUS
system
5
www.handicare.com
