Chino IR-FA Series User manual

RX-MEFA0416-P1
IR-FA Series
Communications (Options)
Always keep this instruction with your unit.
Please be sure to deliver this instruction manual with the unit to a final user.

RX-MEFA0416-P1
-CONTENTS-
CONTENTS
1. General ···············································································································1
2. Communications specifications·················································································1
3. Connections···········································································································1
4. Communications procedures ····················································································2
4.1 Basic communications format ·············································································2
4.2 Procedure multi-drop connection·········································································3
4.3 Data expression································································································3
4.4 Control code ·····································································································3
5. Details of format ····································································································4
5.1 Data commands································································································4
5.1.1 Measured data (1st data: 1 byte, 2st data: 6 bytes) ················································4
5.1.2 Alarm status (Data:2 bytes) ·············································································4
5.1.3 Thermometer inside temperature (Data: 4 bytes) ···············································4
5.2 Parameter settings····························································································5
5.2.1 Alarm set point temperature (Data:4 bytes)························································5
5.2.2 Analog output scaling (1st data: 4 bytes, 2st data: 4 bytes) ·····································5
5.2.3 Alarm temperature mode (Data: 1 byte)·····························································5
5.2.4 Emissivity (Data: 5 bytes)················································································6
5.2.5 Sample hold/peak hold (Data: 1 byte) ································································6
5.2.6 Peak hold reset system (Data: 1 byte)································································6
5.2.7 Peak hold reset time (Data: 4 bytes)··································································7
5.2.8 Signal modulation mode (Data: 1 byte) ······························································7
5.2.9 Modulation ratio (Data: 4 bytes) ·······································································7
5.2.10 Damping factor at peak (Data: 1 byte) ·····························································8
5.2.11 Laser sighting (Data: 1 byte) ··········································································8
5.2.12 Contact output (Data: 1 byte) ·········································································8
5.2.13 Measurement unit (Data: 1 byte) ····································································8
6. Error codes············································································································9
■Symbols in this instruction manual
The symbols shown below are used depending on important degrees for
using the communications safely and avoiding unexpected situations.
Important
degree Symbols Contents
1This symbol is indicated with a title for a
n explanation
with .
2
For avoiding the risk of a fire or electric shock or other dangers that may
result in serious injury or death ofpersonnel or malfunctions/damage to this
product
3For avoidinginjuryorinphysical damage to thecommunications.
4Information that you can use as a reference.
Warning
Caution
War ni ng
Reference
!

RX-MEFA0416-P1
-1-
This optional communications is for monitoring measuring condition by communications and for
setting and reading parameters of IR-FA series fiber optic thermometers (Model: IR-FAIS,
IR-FASS, IR-FAQHS, IR-FACRS) through a personal computer.
In this communications, the transmission speed is variable but other parameters are fixed.
Also, for the connection with multiple thermometers, it is necessary to set an address to each
thermometer. For the setting of the address, refer to the separate instruction manual IR-FA series Fiber
type radiation thermometer (INST.No.INE-378-P) and IR-FACR series Fiber type radiation
thermometer (INST.No.INE-414-P).
Start-stop synchronizing system
Half-duplex communications system
Transmission speed 19200, 9600, 4800bps selectable
Start bit 1 bit
Data length 7 bits
Parity bit Even
Stop bit 1 bit
Character code ASCII
BCC (Block check code) None
Data transmission procedure None
1. General
2. Communicati
ons
specifications
3. Connections
M
ake sure that all mains power is turned off to
prevent an electric shock,
w
hen
connecting power to the power terminals.
Warning
(1)
Insert a driver to the concave part at
the upper side of the terminal board.
(2)
Lift the driver shank up and push up the
metal hook with the tip of the driver.
(3)
Insert a lead wire to the opening of the
lower side of the terminal board.
(4)
The lead wire is fixed by removing the
driver.
Caution
When connecting the optical connector of the fiber
optic assembly to the optical connector of the
thermometer, make sure to turn it with your hand.
(Never turn it by using a tool like as pliers.)
！
Wire insertion
(2)
Driver
(1)
(2)
(3)
Lead wire (4)
＋ －
4 to 20mA
P+ P- S+ S- D0 D1 COM
24VDC OUT
24V DC
SASB
Wire insertion
Power
Contact
signal
RS-485
Communications
terminal
Fiber optics
Key slit
Optical connector
Ground

RX-MEFA0416-P1
-2-
4.1 Basic communications format
1) Commands
STX Command Sub-command Data ETX CR LF
Command (1 character)
Sub command
Type Data No.
(2 characters) (2 characters)
Type :PV…Data
SV…Parameter
Data No.: 01 to 09
2) Positive answer to reading
STX A Sub-command = Data ETX CR LF
3) Negative answer to reading/writing
STX A Errorcode : ErrordataNo. ETX CR LF
4) Positive answer to writing
STX A 0000 : 0000 ETX CR LF
4. Communications procedures
R:
Reading
W: Writing
A: Answer
Reference
A sub-command in the "Reading" command returns as the sub-command in the
answer.
Reference
Error data No.: First data position (the position counted from the position next to
"STX") where an error was detected

RX-MEFA0416-P1
-3-
4.2 Procedure for multi-drop connection
The followings are the formats for the connection of 2 sets of IR-FA or more (applicable to 1-set
connection, too.).
1) Command
ENQ ** STX Command Sub-command Data ETX CR LF
2) Positive answer to reading
ACK ** STX A Sub-command = Data ETX CR LF
3) Negative answer to reading/writing, positive answer to writing
ACK ** STX A Errorcode : ErrordataNo. ETX CR LF
4.3 Data expression
Numeric data
Data is characters with fixed length and right justified.
Sign
At receiving: “ + ” or “space ( )” is acceptable
At transmitting: “ – ” is placed just left to a numeric figure. “ + ” is expressed by “space ( )”
“0” at higher digits
At receiving: “0” (zero) or “space ( ) ” is acceptable.
At transmitting: “0” (zero) is suppressed except specified parameters.
4.4 Control code
ASCII
commands
ASCII codes
STX 02h
ETX 03h
ENQ 05h
ACK 06h
LF 0Ah
CR 0Dh
The following data are not acceptable as numeric figures.
"12 3", "- 123", "-.123", "123 ", "123. " etc. (" " mark means a space.)
Caution
4. Communications procedures
Reference
“** in “ENQ **” shows an instrument address.
Make sure to set it by 2 digits (** or *).
Reference
“** in “ACK **” shows an instrument address.
Make sure to transmit it by 2 digits (** or *).
Reference
“** in “ACK **” shows an instrument address.
Make sure to transmit it by 2 digits (** or *).

RX-MEFA0416-P1
-4-
This followings are the descriptions of the "Command", "Sub-command" and "Data".
5.1 Data commands
5.1.1 Measured data (1st data: 1 byte, 2nd data: 6 bytes)
Reading
RPV01
APV01= ,
1st data: Data status
0: Normal
1: Overflow
2: Underflow
3: Cramp (For 2-color type IR-FAQH)
4: Hardware abnormal
(Element abnormal, parameter abnormal)
2nd data: Temperature data
5.1.2 Alarm status (Data: 2 bytes)
Reading
RPV02
APV02=  
Self-diagnosis
0: Not activated
1: Activated
Temperature alarm
0: Not activated
1: Activated
5.1.3 Thermometer inside temperature (Data: 4 bytes)
Reading
RPV51
APV51= 
Thermometer inside temperature
5. Details of format
Reference
Temperature data: Integer: 4 digits, Decimal: 1 digit
Reference
Temperature data: Integer: 2 digits, Decimal: 1 digit

RX-MEFA0416-P1
-5-
5.2 Parameter settings
5.2.1 Alarm setpoint temperature (Data: 4 bytes)
Reading
RSV02
ASV02= 
Writing
WSV02=
Alarm temperature
5.2.2 Analog output scaling (1st data: 4 bytes, 2nd data: 4 bytes)
Reading
RSV23
ASV23= ,
Writing
WSV23=,
1st data: Analog output low limit value
2nd data: Analog output high limit value
5.2.3 Alarm temperature mode (Data: 1 byte)
Reading
RSV30
ASV30= 
Writing
WSV30=
Alarm temperature mode
0: Alarm disable
1: High alarm
2: Low alarm
5. Details of format
Reference
Alarm temperature setting range: 0 to 6280ºC
Integer: 4 digits, No decimal digit
Reference
Setting range of analog output high and low limit value: 0 to 6280ºC
Integer: 4 digits, No decimal digit

RX-MEFA0416-P1
-6-
5.2.4 Emissivity (Data: 5 bytes)
Reading
RSV51
ASV51= 
Writing
WSV51=
Emmisivity
5.2.5 Sample hold/peak hold (Data: 1 byte)
Reading
RSV53
ASV53= 
Writing
WSV53=
Sample hold/peak hold
0: Disable
1: Peak hold
2: Sample hold
5.2.6 Peak hold reset system (Data: 1 byte)
Reading
RSV54
ASV54= 
Writing
WSV54=
Peak hold reset system
0: No reset
1: Internal reset (Time reset)
2: External reset (Remote contacts input)
5. Details of format
Reference
Emissivity setting range: 1.999 to 0.050
Integer: 1 digit, Decimal: 3 digits

RX-MEFA0416-P1
-7-
5.2.7 Peak hold reset time (Data: 4 bytes)
Reading
RSV55
ASV55= 
Writing
WSV55=
Reset time
5.2.8 Signal modulation mode (Data: 1 byte)
Reading
RSV61
ASV61= 
Writing
WSV61=
Signal modulation mode
0: Delay
1: Peak
5.2.9 Modulation ratio (Data: 4 bytes)
Reading
RSV62
ASV62= 
Writing
WSV62=
Modulation ratio
Reference
Reset time setting range: 0.0 to 99.9 (seconds)
Integer: 2 digits, Decimal: 1 digit
5. Details of format
Reference
Modulation ratio setting range: 0.0 to 99.9
Integer: 2 digits, Decimal: 1 digit

RX-MEFA0416-P1
-8-
5.2.10 Damping factor at peak (Data: 1 byte)
Reading
RSV63
ASV63= 
Writing
WSV63=
Damping factor at peak
0: 0ºC/sec
1: 2ºC/sec
2: 5ºC/sec
3: 10ºC/sec
5.2.11 Laser sighting (Data: 1 byte)
Reading
RSV67
ASV67= 
Writing
WSV67=
Laser sighting enable/disable
0: Laser sighting disable
1: Laser sighting enable
5.2.12 Contact output type (Data: 1 byte)
Reading
RSV85
ASV85= 
Writing
WSV85=
Contact output type
0: No contact output
1: Alarm output
2: Self-diagnosis abnormal
5.2.13 Measurement unit (Data: 1 byte)
Reading
RSV91
ASV91= 
Writing
WSV91=
Measurement unit
0: ºC
1: ºF
5. Details of format

RX-MEFA0416-P1
-9-
Error No.
Error contents
Er
ror answer
Error code:
Error data
No.
1
Framing error A0001 :0000
2
Overrun error A0002 :0000
3
Parity error A0003 :0000
4
Checksum error A0004 :
0000
10
Command error
(Undefined numbers other than R, W, PV, SV, MV, not specified
number)
A0010 :
****
12
Text format error
(Checking after “=”: “=“missing, data missing after “=”, etc.) A0012 :
****
13
"STX" missing (Not placed at specified position) A0013 :0000
14
“ETX” missing A0014 :
0000
15
Receiving buffer overflow A0015 :0000
20
Numeric figure out of range A0020 :
****
22
Not specified character or numeric figure received A0022 :
****
9999
Other errors A9999 :0000
Reference
Asterisks "****" are filled with an error data position (the position counted from the
position next to "STX").
6. Error codes

32-8,KUMANO-CHO,ITABASHI-KU,TOKYO173-8632
Telephone: [phone]
Facsimile: [phone]
Website http://www.chino.co.jp/
