Chipolino VISION 360 User manual

This high chair has been manufactured in accordance
with the requirements of Directive 2001/95/EC of the European Parliament
and of the Council and complies with European Standard EN 14988 Children’s
high chairs. Safety requirements and regulations of the national legislation,
as well as the Consumer Protection Law.
IMPORTANT! READ CAREFULLY AND KEEP THIS USER’S
MANUAL IN A SAFE PLACE FOR FUTURE REFERENCE!
INSTRUCTION MANUAL
FOR HIGH CHAIR
„VISION 360”

1
ATTENTION! YOUR CHILD WILL BE MOST SECURE IF YOU FOLLOW
THE INSTRUCTIONS AND RECOMMENDATIONS GIVEN IN THIS USER’S MANUAL!
CAUTION! NEVER LEAVE YOUR CHILD UNATTENDED!
WARNING! THIS PRODUCT IS SUITABLE FOR CHILDREN, WHO CAN SIT ALONE UNAIDED,
AGED UP TO 3 YEARS AND WEIGHING NO MORE THAN 15 KG.
WARNING! ALWAYS USE THE SAFETY BELTS, WHEN THE CHILD IS IN THE CHAIR! ALWAYS
CHECK IF THEY ARE SECURELY FIXED TO THE HIGH CHAIR’S FRAME!
WARNING! DANGER OF FALLING: DO NOT LET THE CHILD CLIMB ON THE PRODUCT!
DO NOT USE THE HIGH CHAIR BEFORE HAVING MADE SURE THAT ALL PARTS ARE IN GOOD
ORDER AND ARE SET IN THE CORRECT POSITION!
WARNING! KEEP THIS PRODUCT AWAY FROM FIRE! BE AWARE OF THE RISK OF OPEN FIRE
AND OTHER SOURCE OF STRONG HEAT IN THE NEAR VICINITY OF THE HIGH CHAIR!
WARNING! OBSERVE THE RISK OF THE PRODUCT TILTING IF THE CHILD REACHES AND
PUSHES WITH ITS FEET SOLD BASE SUCH AS A TABLE.
Assembly of the product to be done only by adult!
This high chair is not suitable and must not be used by children, who cannot sit unaided
(minimum 6 months) !
This high chair must not be used for children weighing more than 15 kg!
The high chair has a single seat, intended for one child only.
Do not lift the chair by the food tray!
 Discontinueusingtheproductifyoundanymissingordamagedparts!
Do not let your child stand in the high chair!
Never lift, move, make any setting or repair to the chair, while there is a child in it!
Do not place the chair on elevated and/or uneven surfaces, while there is a child in it!
Do not place the chair near stairs, pools or other hazardous areas!
Use the high chair only by its purpose.
Do not use any spare parts or other components, which are not approved by the producer!
The producer does not take any responsibility for the safety of the child when you have not used the
proper and original spare parts, approved and provided by him!
 Donotapplyanychangesormodicationstothehighchair'sconstruction!Contactthedealeroran
authorized repair service for advice and/or repair instead!
Do not allow children younger than 3 years near the high chair during the assembly or disassembly,
in order to prevent the risk of injury or swallowing of small parts!
The packaging of the product must be kept out of the reach of children to avoid the risk of
strangulation!

2
MAIN FEATURES
MAIN PARTS DIAGRAM
High chair is suitable for one child, who can sit alone unaided
High chair is suitable for one child aged up to 3 years and weighing not more than 15 kg.
3-point safety harness system
Tray can be adjusted in 2 poitions
Double tray (Upper part of the tray is detachable)
 Seatrotatesat360°andcanbexedin4positions
Removable eco leather seat, easy for cleaning
Base – 1 pc
Supporting
(upper) tubes
– 4pcs
Foot rest
– 2pcs
Guard rail
– 1pc
Food tray
– 1 pc
Supporting legs
(lower tubes)
– 4 pcs
Seat – 1pc
Storage basket
rods – 2pcs
Storage basket
– 1pc

3
ASSEMBLY INSTRUCTIONS. FUNCTIONS
ATTENTION!Followexactlytheinstructionsgivenandtheorderforassemblyandusage,describedin
textsandpictures.Youwillnotneedanytoolsfortheassembly.
ATTENTION! CHECK THE STABILITY OF FIXING AFTER EACH OPERATION!
1. ASSEMBLY OF SUPPORTING (UPPER) TUBES TO THE FOOT RESTS AND SEAT
1-1 – Position the footrest with the ribbed part up.
1-2–Inserttheuppertubethroughthehole,asshown(g.1-1).Pressandholdthepinandtheninsert
the tube in the hole.
WARNING! THE UPPER TUBE MUST NOT BE FIXED TO THE FOOTREST BEFORE THE SEAT
IS INSTALLED! (the pin should not click in the small hole inside the footrest, in order to allow the
movement of the tube up and down).
Perform the described actions, in order to install the other tubes WITHOUT FIXING.
1-3–Placetheseatontheuppertubes.Inserteachtubeintheseatandmoveituntilitiswellxed.
The seat is installed when all tubes are inserted in the seat openings.
1-4–Nowwhentheseatisinstalled,youcantwistthetubessothatthepinscanshowthroughthe
holes.Youmustheara„click“,whichshowsthattheuppertubesarexedtothefootrest.
1-5 – Installed supporting (upper) tubes to the seat and foot rests.
2. INSTALLATION OF STORAGE BASKET
2-1 and 2-2 – Insert the basket rods in the openings on the storage basket, as shown in the pictures;
2-3and2-4–Installthebasketbyinsertingtherodsintheopeningsofthefootrests,asshowninthe
pictures.
3. ASSEMBLY OF SUPPORTING (LOWER) LEGS
3-1 and 3-2 – Press the pins on the legs and insert them in the openings in the foot rests. Twist the legs
until you hear a click and the pins protrude through the holes.
3-3 – Adjust the footrests so that the footrests are in full contact with the ground and the high chair is
stable.
3-4–Correctpositionofthefootrests.
4. ASSEMBLY AND REMOVAL OF SEAT
Align the seat to the base and push until you hear a “click” sound and the seat locks into place.
To disassemble, press the disassembly buttons and remove the seat from the base.
5. INSTALLATION OF GUARD RAIL
Insert the guard rail in the grooves on both sides of the seat.
To remove it – lift the rail up.

4
6. INSTALLING THE FOD TRAY
6-1 – Pull out the two levers under the tray.
6-2–Insertthetrayintheseatandreleasetheleversuntilitisxed.
ATTENTION!Makesurethetrayisxedbytryingtopullitoutformtheseat.
6-3 – The tray may be adjusted in 2 positions (forward and backward). Pull the two levers and move the
trayindesiredposition,thenreleaseuntilthetrayisxed.
The top tray can be removed for easy cleaning.
7. BACKREST ADJUSTMENT
The seat can be reclined in 3 positions.
7-1 – Press simultaneously the two buttons on both sides.
7-2–Movetheseattodesiredposition.Whenthepositionisxedyouwillhearaclick.
8. ROTATING THE SEAT AT 360° (in 4 positions)
Pullupthebuttonandrotatetheseat.Releasetheleverandcontinuetorotateuntiltheseatisxed
and you hear a click.
WARNING!Beforeusemakesuretheseatisxedinonepositionandisnotrotating!
9. SAFETY HARNESS SYSTEM
9-1 - Press the central button of the buckle and split the belts.
9-2 - The belts length may be adjusted by sliding the plastic buckles.
ATTENTION! Safety harnesses must not be worn out or torn and buckles must be strong, without any
damages and provide secure connection!
IMPORTANT!Beltsshouldnotbetwisted,theymusttthebabywellandtheirlengthshouldnotbe
adjusted while they are fastened!
pin
upper tube
upper tube
Upper ribbed part
of foot rest
1-1 1-2

5
1-3
1-4
2-1
2-3 2-4
2-2
1-5
Correct angle for inserting the tubes
pin
Opening
Storage basket rod
“click” “click”

6
3-1
3-3
6-1 6-2
4 5
3-4
3-2
pin
Anti-slip
Removal
button
Pull out upper
removable
tray
Anti-slip
levers
pin
“click”
“click”

7
6-3 7-1
7-2
8
Position 2 Position 1
Position 1 Position 2
lever
Position 3
recline button
“click” “click”
“click” “click”

8
CARE AND MAINTENANCE
Clean the fabrics, plastic parts and metal parts with damp cotton cloth or sponge and mild soap.
Do not use abrasive, bleach or other aggressive detergents.
Always after cleaning leave the high chair fully dry and after that use it or store it. It may appear mold
to your high chair if you keep it moist.
Do not put any objects and things in high chair or on the top of it to avoid damages of the structure.
 Alwaysstore yourhighchair indoors.Donot exposetodirect environmentinuence- sun,rain,
moisture and high temperature intervals.
Fabric composition:
Outer: 100% eco leather
Filling: 100% polyester
STHVI023ххх
9-1 9-2

1 Goliamokonarsko shosse, Plovdiv, BULGARIA
www.chipolino.com
