Chiroform MT Series User manual

ECR ECRA ECB ECBA
ECC ECCA ECT ECTA
ECI ECIA ECS ECSA
MT
Instruction
EN
W14114
series

Warnings
0201
Section I : Specification
MT-Russell+A
Lifting Capacity: 440 lbs/ 200 kg
Length：78"/198cm
Width：27"/68cm or 29"/73cm
Height Range：18"/45cm ~ 37"/95cm
Weight：116kg - 119kg
MT-Russell
Lifting Capacity: 440 lbs/ 200 kg
Length：78"/198cm
Width：22"/55cm or 25"/63cm or
27"/68cm or 29"/73cm
Height Range：18"/45cm ~ 37"/95cm
Weight：116kg - 119kg
MT-Basic+A
Lifting Capacity: 440 lbs/ 200 kg
Length：78"/198cm
Width：27"/68cm or 29"/73cm
Height Range：18"/45cm ~ 37"/95cm
Weight：116kg - 119kg
Check all connections on a yearly base.
Unauthorized modification or alteration of this product is prohibited and will void the warranty.
Safety Instructions
Risk of injury may cause by improper setup, operation or maintenance of the equipment.
Please read this instruction manual before operating this equipment.
Use this equipment only for its intended purpose or as described in this manual.
For your safety, please do not try to disassemble the Foot Pedal, Control Box or Actuator.
Do not put any items underneath the back-rest or leg-rest.
Do not expose the equipment to the extreme temperature or humidity.
Do not lay the table on its side without taking any protective measures as the tables weigh up to
198lbs / 90kg.
Please check the padding and upholstery when unpacking the table. Do not use if there is any sign of
damage. (Our warranty does not cover the damages caused by improper set-up, accident or abuse)
Follow these safeguards and use the equipment properly to
prevent injury , death , and material damage.
3-year warranty on the table frame, and accessories.
5-year warranty on the foam and vinyl.
All warranties are limited to factory-provided replacement parts, factory repair or replacement.
All warranties are set forth above. There is no other warranty or guarantee, expressed or implied.
Warranty Statement
MT-Basic
Lifting Capacity: 440 lbs/ 200 kg
Length：78"/198cm
Width：22"/55cm or 25"/63cm or 27"/68cm
or 29"/73cm
Height Range：18"/45cm ~ 37"/95cm
Weight：116kg - 119kg

0403
MT-Infinity
Lifting Capacity: 440 lbs/ 200 kg
Length：78"/198cm
Width：22"/55cm or 25"/63cm or 27"/68cm
or 29"/73cm
Height Range：18"/45cm ~ 37"/95cm
Weight：116kg - 119kg
Lifting Capacity: 440 lbs/ 200 kg
Length：78"/198cm
Width：25"/63cm or 27"/68cm or 29"/73cm
Height Range：18"/45cm ~ 37"/95cm
Weight：116kg - 119kg
Acorn-Treatment
MT-Scissors
Lifting Capacity: 440 lbs/ 200 kg
Length：78"/198cm
Width：27"/68cm or 29"/73cm
Height Range：18"/45cm ~ 37"/95cm
Weight：116kg - 119kg
MT-Infinity+A
Lifting Capacity: 440 lbs/ 200 kg
Length：78"/198cm
Width：27"/68cm or 29"/73cm
Height Range：18"/45cm ~ 37"/95cm
Weight：116kg - 119kg
MT-Cabell
Lifting Capacity: 440 lbs/ 200 kg
Length：78"/198cm
Width：22"/55cm or 25"/63cm or 27"/68cm
or 29"/73cm
Height Range：18"/45cm ~ 37"/95cm
Weight：116kg - 119kg
MT-Treatment+A
Lifting Capacity: 440 lbs/ 200 kg
Length：78"/198cm
Width：27"/68cm or 29"/73cm
Height Range：18"/45cm ~ 37"/95cm
Weight：116kg - 119kg
MT-Treatment
Lifting Capacity: 440 lbs/ 200 kg
Length：78"/198cm
Width：22"/55cm or 25"/63cm or 27"/68cm
or 29"/73cm
Height Range：18"/45cm ~ 37"/95cm
Weight：116kg - 119kg
MT-Cabell+A
Lifting Capacity: 440 lbs/ 200 kg
Length：78"/198cm
Width：27"/68cm or 29"/73cm
Height Range：18"/45cm ~ 37"/95cm
Weight：116kg - 119kg

UP DOWN UP DOWN
0605
Foot pedal control
UP DOWN UP
DOWN
UP DOWN
4FDUJPOŘ*OTUSVDUJPOT How to adjust Waist Stretch
How to adjust the Height
Operate the foot-control as
shown to raise or lower the
height of the table.
For the two pedals model, just simply operate
the foot-control as shown to raise or lower the
height of the table.
UP DOWN UP DOWN
Foot pedal control
DOWN
UP
Waist stretch control is on the right of the
foot controller, just simply operate the
foot-pedal as shown to raise or lower the
waist stretch. When the table reached
your desire position, stop operate the foot
controller.
Side panel control
Hand controler
Walking-free foot control
Hand control
The walk free foot controller system is very easy and convenient to use, just simply step on to it,
the table will raise. To lower the table, just simply lift the controller up, the table will getting lower.
Using the hand control as shown on the top to adjust height of the table. Press left
button to raise the table. Press the right button to lower the table.
Using the hand control as shown on the right to
adjust waist part of the table. Press bottom left
button to raise the waist part. Press the bottom
right button to lower the waist part. Stop pressing
the button when the table surface reaches your
desire position.
If you add side controller option to your product, just simply press the left button
shown on top to arch the waist part，press the right button to lower the waist part.
Stop pressing the button when the table surface reaches your desire position.
UP DOWN
DOWNUP
UP
DOWN
UP
DOWN
UP
DOWN

4FDUJPOř5SPVCMFTIPPUJOH
Before doing any work on the unit, disconnect the power cord from the power outlet.
Foot Control Replacement Instruction
Rapid diagnosis:
1.Tables that are equipped with double actuators:
If no actuators work when operating the foot, hand, or side controls, it is possible that the control box
is broken.
If one of the actuators doesn’t work, it is more possible that this actuator is broken.
2.Tables that are equipped with a hand-control:
If the function LED on the hand control glows all the time, it may be possible that the hand control is
broken.
If the function LED on the hand-control doesn’t glow when a key is pressed, it is more possible that
the hand-control or the control box is broken.
blue yellow black red
)PXUPBEKVTUMFHSFTUBOECBDLSFTU
How to adjust the head-rest
How to adjust the front arm-rest
0807
Our Pneumatic system in charge of rise or lower the back-rest or the leg-rest depends
on model.
To adjust the head-rest, slightly hold the
head-rest and pull the lever upwards to
adjust the head-rest until the desired angle is
reached, release the lever and the head-rest
will lock automatically in position.
How to adjust the Pneumatic system
To adjust the angle of the back-rest / leg-rest just simply grasp it firmly and slightly
pull the lever upwards. being careful to maintain a firm hold on the back-rest /
leg-rest as you adjust it. Release the lever when you have the back-rest / leg-rest
at the required level and the back-rest / leg-rest will lock automatically in position.
To adjust the front arm-rest, slightly hold the
front arm-rest and pull the lever upwards to
adjust the front arm-rest until the desired
angle is reached, release the lever when you
have the front arm-rest at the required level
and the front arm-rest will lock automatically
in position.
No need to pull the lever when you only
need to raise the head-rest

1009
If you find the actuator suddenly cannot move
SET2:
If all the cables are firmly connected correctly, the
table still doesn’t work, then open the shielded cable
cover and unplug the actuator cables from the control
box. Keep on pressing the foot-control, and measure
the output voltage of the socket on the control-box
using a multi-meter. If the meter reading is 29 volts, it
means the actuator is defective, and you need to
replace the defective actuator. If the multi-meter does
not read 29 volts DC, the control box or the foot-pedal
may be defective.
blue yellow black red
1.
multi-meter
Disconnect the main power.
Check all the cables and reinsert them if needed.
Remove any weight that may be on the table.
Allow the system to rest for 20 to 30 minutes with the main power unplugged.
Section IV : How to Care for Your Upholstery
Avoid storing your table in extreme cold temperatures as excessive cold will cause cracking.
Avoid storing your table in extreme hot temperatures as excessive heat will cause the upholstery to
stretch and pucker. Be sure to keep your table away from heaters, electrical appliances and direct
sunlight.
Protect your table and accessories with sheets and fleece.
We recommend our three-piece Flannel Sheet Set and Fleece Sheet Set.
We recommend a mild mixture of anti-bacterial dish soap with water in a spray bottle. Spray the
table with the solution and wipe down the table with a clean damp towel.
Use both ends of the table. Occasionally, switch the face cushion/head extention from one end
of the table to the other to avoid uneven use.
Protect your table from general abrasions, cuts and punctures.
5IFVTFPGBMDPIPMXJMMESZPVUUIFWJOZMBOEDBVTFJUUPDSBDL
2. Prolonged exposure to extreme temperatures may cause damage to vinyl
In an effort to ensure your products' quality and to help you maintain the life of
your table, we have tested several preventative steps in order to advise you how
to protect the upholstery on your table and accessories:
Step1: Disconnect the power, and take off the shield cover from the control box using a slotted
screwdriver.
Step 2: Pull out the broken foot-control plug from the control box and insert the plug of new
foot-control.
Step 3: Try the new foot control, if it works, replace shield cover.
Check the outlet to ensure it has power
and the cable is plugged in on both ends.
Check the control box to ensure the cables for actuator,
foot-control is firmly connected to the control box.
blue brown pink
SET1:
*The blue label port in charge of height control
*The brown label port in charge of chest part control
*The pink label port in charge of control paddle
If this doesn’USFTPMWFUIFQSPCMFNUIFOUIFDPOUSPMCPY
NBZCFEFGFDUJWF
If you happen to have another electric table, you may diagnose the problems by
interchanging the actuators, control box and foot pedal to help with the diagnosis.
Please note! The plugs for foot-pedals are interchangeable. This means you may replace the
pedal that doesn’t work with another pedal to help with the diagnosis.
You will have a 2 year warranty for the Motor Actuator and the Control box from the
date of purchase. Please contact the retailer or wholesaler to apply for a new part for
replacement if the table does not work after the above diagnosis.
