This document provides information and procedures for using serial commands (ASCII text messages) to control the
product.
The RS232 IN port has several communication parameters.
Parameter
Value
Default baud rate
—
Parity
None
Data bits
8
Stop bits
1
Flow control
—
Use an RS232 connection to remotely access display controls and image setups, issue commands or queries, and
receive replies.
1. Connect one end of a null standard 9-pin female to female modem cable to the projectorRS232 port.
2. Connect the other end of the null standard 9-pin female to female modem cable to a computer.
Configure the settings for your terminal programs for proper echoing.
1. For TeraTerm, select Setup > Terminal and set the following:
• Local echo: Checked
• Transmit: CR+LF
2. For HyperTerm, select Select File > Properties > ASCII setup and set the following:
• Send line ends with line feeds: Checked
• Echo typed characters locally: Checked
Learn the format for request and acknowledge data packages.
The following provides information about the request data package.

Introduction
E510 LED Display Controller Technical Reference 5
020-001940-01 Rev. 1 (07-2021)
Copyright © 2021 Christie Digital Systems USA, Inc. All rights reserved.
#
Byte
counts
Length
(byte)
Content
1
2
—
Head
2
1
—
ACK
3
1
—
Serial number
4
1
—
Source address
5
1
—
Destination address
6
—
1
Device type
7
—
1
Port address
8
—
2
Board address [7:0]
Board address [15:8]
9
—
1
Code
10
—
1
Reserved
11
—
4
Register unit address
[7:0]
Register unit address
[15:8]
Register unit address
[23:16]
Register unit
address [31:24]
12
—
2
Valid data length
[7:0]
Valid data length [15:8]
13
—
N
Write data [0:N]
14
—
2
Checkout [7:0]
Checkout [15:8]
#
Content
Meaning
Remark
1
Head
Data package head
55H, AAH
2
ACK
Not used for the Request command.
00H
3
Serial number
Serial number of a command. Do not use again
until the command with this serial number has
finished.
—
4
Source Address
Address of the computer or sending card that
generates and starts the command.
The computer address is set to
FEH.
5
Destination address
Address of the computer or sending card the
command is to be sent to.
The computer address is set to FEH.
The first device connected to the COM port with
COM port properties has the address of 0, the
second device has the address of 1, and so on.
Devices connected in a
daisychain to a computer serial
port must be the same type.
6
Device type
00H
Devices with control port properties,
such as sending cards, TV cards.
—
01H
Receiving card

Introduction
E510 LED Display Controller Technical Reference 6
020-001940-01 Rev. 1 (07-2021)
Copyright © 2021 Christie Digital Systems USA, Inc. All rights reserved.
7
Port address
RJ45 output port address of the sending card.
SDI output port address set as 00.
[0,1,2,3]
8
Board address [7:0]
Low 8 bits of the address of a device connected in
daisychain on a CAT5 data cable or SDI cable.
The first device connected on
the cable has the address of 0,
the second device has the
address of 1, and so on.
Note: Different types of
devices are assigned the
address respectively.
Board address [15:8]
High 8 bits of the address of a device connected in
daisychain on a CAT5 data cable or SDI cable.
9
Code
00H
Read data package (command)
Both read and write are defined
by the device that starts the
command.
01H
Write data package (command)
02H-FFH
Reserved
10
Reserved
Reserved
—
11
Register unit address [7:0]
The first byte (low) of the address of the register
unit on a device.
The registered unit address is
four bytes long. Low at the
front and high at the end.
Register unit address [15:8]
The second byte of the address of the register unit
on a device.
Register unit address [23:16]
The third byte of the address of the register unit
on a device.
Register unit address [31:24]
The fourth byte (high) of the address of the
register unit on a device.
12
Valid data length [7:0]
Low 8 bits of the length of valid data.
• Code is 01H—Length of
the data to be written to
the destination device.
• Code is 00H—Length of
the data to be read from
the destination device.
Valid data length [15:8]
High 8 bits of the length of valid data.
13
Write data [0:N]
Data to be written to the destination device. The
length N is given by Valid Data Length.
• Code is 01H—Section the
data is written to.
• Code is 00H—Section does
not exist.
14
Checkout [7:0]
Low 8 bits of the checksum.
The sum of all data in byte
except the packet head and
then plus 0x5555.
Checkout [15:8]
High 8 bits of the checksum.
The following is an example of a valid data package command:
1
2
3
4
5
6
7
8
9
10
11
12
14
Note the following:
• The numbers under the command correspond to the table above.
• Number 13 does not exist because the Code is 0 and the write data does not exist.
• Checksum = 32 + FE + 01 + 0A + 01 + 5555 = 5961, so checkout[7:0]=61, checkout[15:8]=59

Introduction
