Chungho A200 User manual

CHA-R300A
• Read the user's manual thoroughly before using the unit.
• Design and color may differ from the picture.
• Unit appearance, specification, etc. are subject to change without prior notice
if necessary for improving unit performance.
• The rated voltage of this unit is 220-240 V~ / 50 Hz only.
User's Manual
ChungHo Air Purifier A200

1. Product features 03
2. Safety precautions 04~07
3. Name of each part 08
4. Display and operation function 09
4-1. Display function 09
4-2. Operation function 09
5. Filter function 10
6. Usage 11~ 12
6-1. Power button 11
6-2. Speed button 11
6-3. Timer button 12
6-4. Particle sensor (Sensitivity control) 12
6-5. Filter change indicator 12
7. Filters 13 ~ 14
7-1. Filter cleaning and replacement 13
7-2. Filter service life 13
7-3. Cleaning of particle sensor 14
8. Troubleshooting 15
Greetings
Table of Contents
02
It is a promise of ChungHo Nais for the health of our customers.
There are also levels in technology for home appliance. As organic vegetables without pesticides protect the
health of our families with better quality, better home appliance technology of ChungHo Nais opens up a
world of healthy home appliances of different category. High technology with reason, ChungHo Nais! We will
reward you with great happiness for your precious investment for health.
Please read the instruction manual thoroughly and keep it for a future reference.

1
2
3
4
5
03
1. Product features
Superior air cleaning capacity
3 stages air cleaning system equipped with Pre filter, Integrated-type filter(HEPA filter + Deodorization
filter) eliminates fine dust and odor substance.
Auto operation by detecting the pollution level
It displays the indoor air pollution level detected by particle sensor and enables user to know
pollution level easily, and “Auto” mode controls the airflow speed automatically in accordance with
the air pollution level and conveniently keeps pleasant air in the room.
Enhanced deodorization function
Using activated carbon increases odor removal efficiency and capacity by eliminating formaldehyde
and VOCs (Volatile Organic Compounds), which are well known for Sick House Sundrome along with
ammonia, acetaldehyde, acetic acid.
Sleep mode by using BLDC motor
It continues to remove the indoor air pollutants very quietly while operating in “SLEEP” mode by
using BLDC motor.
Filter change indicator
This function informs users of right timing to change filters by displaying on the front.

Cautions are divided into 2 categories: ''DDaannggeerr''and ''CCaauuttiioonn..''
Use the designated power rating.
•Inappropriate voltage may cause a fire or
electric shock as well as product failure.
Do not operate any appliance with damgaged
cord or plug.
•Electric shock or fire may occur.
Keep the cord out of heavy traffic areas.
•This can lead overheating to outlet.
Put the cord all the way to the end.
•Unstable connection may
cause fire.
•Electric shock may occur.
04
2. Safety precautions
Associated with the possibility for serious injury or death.
Danger
Do not touch the power plug with wet hands.
•Electric shock may occur.
Always unplug the air cleaner before moving or
cleaning the unit and changing filters.
This appliance is not intended for use by persons
(including children) with reduced physical, sensory or
mental capabilities, or lack of experience and
knowledge, unless they have been given supervision
or instruction concerning use of the appliance by a
person responsible for their safety.
If the supply cord is damaged, it must be replaced
by the manufacturer, its service agent or similarly
qualified persons in order to avoid a hazard.
Children should be supervised to ensure that they
do not play with the appliance.

If dust or water is on power plug,
wipe it off well with dry cloth.
•Dust or water on power
plug can cause electric
shock or fire.
Do not put foreign substance like pin, bar,
coin and etc into airflow inlet and outlet.
•Electric shock and malfunction
may occur.
05
2. Safety precautions
Associated with the possibility for serious injury or death.
Danger
•Malfunction and fire
may occur.
To disconnect the unit, be sure to pull by the plug
and not the cord.
•Malfunction and fire
may occur.
Do not sprinkle flamable spray or insecticide
over the product.
Do not bend the power cord nor allow it
to be pressed under heavy object.
•Electric shock or fire
may occur.
Do not block airflow inlet and outlet with laundry or
curtain.
•Blocking ventilation holes may
raise inside temperatures and
cause system malfunction
or fire.
•Earthquake, fire or abnormal
sound or smell is found,
stop using and unplug.
Stop using in the event of abnormal sound or smell.
•Explosion and fire may occur.
Do not install the product nearby
largely flammables (Spray, butane, etc)
and heater.

06
2. Safety precautions
Associated with the possibility for serious injury or death.
Danger
Do not place the product in damp place or at the
place exposed to rain or snow.
Do not attempt to repair or adjust any electrical or
mechanical functions on this unit.
•A fire or electric
shock may occur.
•This is a danger of
electric shock and fire.
Be careful not to step on and fall over the cord.
•An injury and electric shock
may occur.
Do not sprinkle water onto the product.
•Malfunction and electric
shock may occur.
Do not place medicines, metals, a bowl of water, etc.
on the product.
Do not prick display window or buttons with
something sharp.
•An electric shock and fire
may occur if the foreign
substance drops into the
product.
Keep unit away from heated surfaces and
open flames.
•A fire may occur.
•Electric shock or malfunc-
tioning may occur.
•Damaged product may cause
overheating and fire.
Do not place anything on top of unit or give a
shock on it.

07
2. Safety precautions
Associated with the possibility of injury, property damage and reduced
performance of product.
Caution
Use the product according to
guideline in user’s manual.
•If the product is not used in
accordance with introduction
in the manual, it can cause
injury and electric shock.
Do not install the product in a sloped or unstable
position.
This product is for indoor usage only.
41F (5°C) ~ 86F (30°C)
•It can cause injury and damage.
•On the unstable ground, fine shake may occur.
This is not a problem. Place it on flat ground.
•Using outdoor can cause
deformation and discoloration.
Close supervision is necessary when any
appliance is used by or near children.
Do not use the unit in places such as restaurants or
kitchen where is filled with oil and dusty area caused
by construction site as well as in places with lots of
animal gas or toxic gas.
•An injury may occur.
•Shortened service life of filter
and less air purifying efficiency
may occur.
•Malfunction can occur by
sensor contamination. .
Keep it unplugged during when the unit is
not in use.
This is for purifying air indoor only.
•This is for preventing
negligence accident.
Do not allow you to expose cool air directly for
long period of time.
•Body temperature may fall.
•Other purpose than this including
use as a ventilation system can
bring out shortened service life of
filter and less air purifying efficiency.

08
3. Name of each part
Particle
sensor cover
Front cover
Handle
Pollution level display lamp
Operation controller
Operation display
Display window
Inlet
Inlet
Inlet
Outlet
Particle sensor

1
2
31 2
3
4
5
6
Speed : Display of fan speed.
Timer : Display of time setting.
Sleep mode ( ) : Display of sleep mode.
Auto : Display of automatic operation.
Filter change : Filter change indicator informs the right time to change filter.
1
2
3
4
5
Pollution level display lamp : Display of indoor dust level.
6
POWER : Power on/off
SPEED : Setting the level of fan speed.
TIMER : Setting the operation time.
1
2
3
09
4-1. Display function
4-2. Operation Function
4. Display and operation function

10
5. Filter function
Pre-filter
Eliminate visible particles such as dust, lint, pet hair, etc.
Integrated-type
filter
(HEPA filter +
Deodorization
filter)
HEPA filter removes fine dust (bacteria, cigarette smoke included)
as small as 0.3㎛which is potential causes of respiratory problems.
Made of activated carbon which is powerful enough to remove
VOCs, formaldehyde, ammonia, acetaldehyde, acetic acid etc.
Front Cover
Pre filter
Integrated-type filter
(HEPA filter +
Deodorization filter)

• Plug in the power before using the product.
• The product is automatically set level 1.
Operation
display
Level 1 Level 2 Level 3 Level 4
Auto Sleep
①Setting of ON/OFF.
①Plug in the power
•The product is set level 1 as flickering LED window two times. (Setting sound : Ding~dong~daeng~)
•Display lamp changes its color for 30 seconds and display a color to the pollution level.
②Press “SPEED” Button
• As you press “SPEED” button, speed is changed as follows “level 1 - level 2 - level 3 - level 4 – Auto – Sleep – level 1.”
③AUTO
•
If the speed is set “AUTO”, the particle sensor controls fan speed in line with indoor dust level.
④Sleep Mode ( )
•
In sleep mode, the brightness of the display will be reduced and the LED indicator will be turned off completely.
The product will be operated quietly at Level 1, so that it doesn’t interfere during the sleep.
Speed level
Pollution level
display Blue Green Purple Red
Level 1 Level 2 Level 4
Air quality Clean Low
Level 3
Medium High
11
6. Usage
6-1. Power button
6-2. Speed button

High Standard Low Lowest
12
6. Usage
Operation
display
Continuation (∞) 8hrs 4hrs 2hrs
① Initial setting is programmed for continuation ( ).
②Press timer button.
• As you press timer button, timer is changed as follows continuation( ) – 8 hrs – 4 hrs – 2 hrs-continuation ( ).
Operation
display
Sensitivity
Level -2
Highest
-1 0+1 +2
• Default setting has been set at the factory with the standard sensitivity. If the pollution indicator lamp is in "Red" for
more than 2 hours, or in "Blue" for more than 1 hour, even though the indoor pollution is severe, then you must first
process by cleaning the particle sensor. (See page 14.) If the above symptom continues even after the particle sensor
cleaning then adjust the default particle sensor sensitivity level as follows:
1. While the unit is running, press "SPEED" for 2 seconds. The buzzer sound will notify that the particle sensor settings
has been activated. (Setting sound : Ding~ding~ding)
2.
Standard speed is set level 2. (2 bars are on.)
3. While particle sensor gets activated, as you press “SPEED” button, sensitivity gets high and as you press "TIMER"
button, the sensitivity gets low.
4. If the setting is set and press “SPEED” button for 2 seconds, then function is released as the sensitivity is
set. but, if there is no button is pressed for 10 seconds, sensor sensitivity is set as it is automatically.
6-3. Timer button
6-4. Particle sensor (Sensitivity control)
6-5. Filter change indicator
The filter change indicator will light up to indicate when to replace the filter.
The filter life may vary depending on the degree of contamination.
Integrated-type filter (HEPA filter+
Deodorization filter)
1. Press “Timer” button for 5 seconds.
• The timer will be is initialized and the light will be turned off.

13
7. Filters
7-1. Filter cleaning and replacement
7-2. Filter service life
①Turn off and unplug the unit.
• If not, electric shock may occur.
• Pre filter needs cleaning work with vacuum cleaner
or running water once a month.
③ Pull out forward the pre filter as pulling two holders.
⑥ Insert pre filter to the hole of lower and upper of main
body respectively.
⑦ Insert front cover and plug the power.
②Pull out the front cover as holding upper side of the
product.
④ Replace Integrated-type filter(HEPA filter + Deodorization filter)
with new one.
⑤ Put the filters into the filter case in a reverse order.
(Front cover – pre filter – Integrated-type filter )
※ Service life and period of cleaning can be different depending on circumstances.
(HEPA filter +
Deodorization filter)
Process
Reuse after cleaning
Change
Filter Service life & Cleaning
Integrated-type filter
12 months
Pre filter 3months

14
•Particle sensor is…
Particle sensor detects fine dust going around from carpet, cigarette smoke and blanket etc. and send signal to the
controller to indicate how polluted indoor air is. Pollution is displayed by lamp color.
※ Cleaning work is recommended every two months.
7. Filters
7-3. Cleaning of particle sensor
※Be careful of damage of particle sensor while cleaning.
①Plug out the power.
※Do not touch with wet hands.
②Detach front cover.
③ Remove cover of particle sensor.
④ Wipe off lens with wet cotton ball and remove liquid with dry cotton ball.
※Do not allow moisture to come in contact with the sensor.
⑤ Assemble in a reverse way.

15
8. Troubleshooting
Issue Checking point Yes No
Is the power plug
inserted properly?
When the display is
turned off and the
product does not work.
Is designated cleaning/
replacement period of Pre filter,
Integrated-type filter over?
Is it installed on
uneven place?
Is designated cleaning/
replacement period of Pre filter,
Integrated-type filter over?
Are you using the
product where the smell and
smoke keep rising?
Replace filters with new ones and
clean up pre filter.
Continuous smell and smoke can
cause reduced performance.
Does the lamp keep lighting red
(pollution level is high)?
Decreased air flow.
The product is
shaking over.
Bad smell coming out
from air outlet.
Request follow-up service.
Replace filters with new ones and
clean up pre filter.
Install it on flat surface.
Is designated replacement period of
Integrated-type filter over?
Decreased
deodorization.
Replace filters with new one.
Set the level of detection sensitivity
“Low” or “standard”.
Does the lamp keep lighting blue
(Pollution level is low)?
Set the level of detection sensitivity
“High” or “standard”.
Make sure unit is properly
plugged in.
Request follow-up
service.
Is there any dust stuck onto lens
of particle sensor?
Clean up lens of particle sensor.
Is the sleep mode set?
Does display button
fades out?
If you still have a problem, request follow-up service. Others
If sleep mode is set, LED
window gets fading out.
Pollution level
display lamp
does not change
its color.

Rev,No.00
ChungHo Malaysia, 10TH FL, FABER IMPERIAL COURT, JALAN SULTAN ISMAIL, 50250 KUALA LUMPUR, MALAYSIA
TEL:[phone] / E-MAIL: [email protected] / HOMPAGE: www.chunghomy.com.my
MANUAL DOWNLOAD: http://www.chunghomy.com.my/base/download
Product name
ChungHo Air Purifier A200
Model name
CHA-R300A
Power consumption
19 W
Applicable area
23
㎡
Noise
Net weight
Less than 45 dB
5 kg
Dimension
326W X 162D X 512H(㎜)
Installation
Indoor
