Cino FuzzyScan F400 Series User manual

© Copyright Cino Group
© Copyright PC Worth Int’l Co., Ltd
PC Worth makes no warranty of any kind with regard to this publication,
including, but not limited to, the implied warranty of merchantability and
fitness for any particular purpose. PC Worth shall not be liable for errors
contained herein or for incidental consequential damages in connection with
the furnishing, performance, or use of this publication. This publication
contains proprietary information that is protected by copyright. All rights are
reserved. No part of this publication may be photocopied, reproduced or
translated into any language, in any forms, in an electronic retrieval system or
otherwise, without prior written permission of PC Worth.
Warranty
PC Worth warrants its products against defects in workmanship and materials
from the date of shipment, provided that the product is operated under
normal and proper conditions. The warranty provisions and durations are
furnished by different warranty programs. The above warranty does not apply
to any product which has been (i) misused; (ii) damaged by accident or
negligence; (iii) modified or altered by the purchaser or other party; (iv)
repaired or tampered by unauthorized representatives; (v) operated or stored
beyond the specified operational and environmental parameters; (vi) applied
software, accessories or parts are not supplied by PC Worth; (vii) damaged
by circumstances out of PC Worth’s control, such as, but not limited to,
lightning or fluctuation in electrical power. Any defective product must follow
the warranty program and RMA procedures to return PC Worth for inspection.
Regulatory
FCC part 15B
EN55022, EN55024, EN61000-3-2, EN61000-3-3
CNS13438
Industry Canada ICES-003
LED Eye Safety IEC60825-1
1

Getting familiar with your FuzzyScan
Thank you for choosing Cino FuzzyScan Imager. The all FuzzyScan Imagers
deliver world-class performance for a broad range of market applications to
unleash your productivity.
This document provides an easy reference for installing and operating
FuzzyScan Imagers. A complete documentation for FuzzyScan Imagers is
provided by the FuzzyScan User’s Guide available on the Internet at
http://www.cino.com.tw
F400 Series
F700 Series
1. Power Indicator
2. Status Indicator
3. Trigger
4. Scan Window
5. Beeper
6. Cable Release Hole
FBC6000 Series
2

Connecting/Disconnecting cable
FuzzyScan imagers provide PS/2(DOS/V) Keyboard Wedge, RS-232 Serial,
USB interfaces capability. To disconnect the cable, please straighten one end
of a paper clip, then insert it into the cable release hole and press in. After
that, you can release the cable and pull the cable out easily.
F400 Series
F700 Series
FBC6000 Series
3

Connecting host interface
FuzzyScan imagers have capability to connect different host devices by
PS/2(DOS/V) Keyboard Wedge, RS-232 Serial and USB interfaces. Please
choose one of the interface cables to connect your host device by referring to
the illustrations below.
PS/2(DOS/V) Keyboard Wedge
RS232 Serial
USB
4

Keyboard function code table
No. ANSI ASCII Key Function No. ANSI ASCII Key Function
00 NUL 00H RESERVED 16 DLE 10H F7
01 SOH 01H CTRL (Left) 17 DC1 11H F8
02 STX 02H ALT (Left) 18 DC2 12H F9
03 ETX 03H SHIFT 19 DC3 13H F10
04 EOT 04H CAPS LOCK 20 DC4 14H F11
05 ENQ 05H NUM LOCK 21 NAK 15H F12
06 ACK 06H ESC 22 SYN 16H INS (Insert) (Edit)
07 BEL 07H F1 23 ETB 17H DEL (Delete) (Edit)
08 BS 08H BACK SPACE 24 CAN 18H HOME (Edit)
09 HT 09H TAB 25 EM 19H END (Edit)
10 LF 0AH F2 26 SUB 1AH PAGE UP (Edit)
11 VT 0BH F3 27 ESC 1BH PAGE DOWN (Edit)
12 FF 0CH F4 28 FS 1CH UP (Edit)
13 CR 0DH ENTER (CR) 29 GS 1DH DOWN (Edit)
14 SO 0EH F5 30 RS 1EH LEFT (Edit)
15 SI 0FH F6 31 US 1FH RIGHT (Edit)
HEX/ASCII reference table
H
L 0 1 2 3 4 5 6 7
0 NUL DLE SPACE 0 @ P ` p
1 SOH DC1 ! 1 A Q a q
2 STX DC2 " 2 B R b r
3 ETX DC3 # 3 C S c s
4 EOT DC4 $ 4 D T d t
5 ENQ NAK % 5 E U e u
6 ACK SYN & 6 F V f v
7 BEL ETB ' 7 G W g w
8 BS CAN ( 8 H X h x
9 HT EM ) 9 I Y i y
A LF SUB * : J Z j z
B VT ESC + ; K [ k {
C FF FS , < L \ l |
D CR GS - = M ] m }
E SO RS . > N ^ n ~
F SI US / ? O _ o DEL
: High Byte of HEX Value : Low Byte of HEX Value
5

Host interface quick set
PS/2 (DOS/V) Keyboard Wedge
6
Keyboard Replacement
USB HID Interface
RS232 Serial Interface
USB COM Interface
Operation mode quick set
Low Power Mode
Trigger Mode
Presentation Mode
Alternative Mode
Flash Mode
Force Mode
Toggle Mode
Diagnostic Mode

Keyboard interface control
7
Command Parameter Selection Option Code
Keyboard Layout USA ◆
France
Germany
United Kingdom-UK
Canadian French
Spain
Sweden/Finland
Portugal
Norway
Latin America
Italy
Netherlands
Denmark
Belgium
Switzerland-Germany
Iceland
Japan
Universal
00
01
02
03
04
05
06
07
08
09
10
11
12
13
14
15
16
99
Record Suffix None
RETURN ◆
TAB
SPACE
ENTER
User define character
0
1
2
3
4
5
Preamble None ◆
1-15 characters
FIN
[00-7F], [FIN]
Postamble None ◆
1-15 characters
FIN
[00-7F], [FIN]
Character Frame Control None ◆
1-99 msec.
FIN
(2 digits)
Intermessage Delay None ◆
1-99 (x5) msec.
FIN
(2 digits)
Intercharacter Delay None ◆
1-99 (x5) msec.
FIN
(2 digits)
Interfunction Delay None ◆
1-99 (x5) msec.
FIN
(2 digits)
Caps Lock Control “Caps Lock Off” State ◆
“Caps Lock On” State
Auto Detect
0
1
2
Function Key Emulation Enable ASCII 00-31 as KB function code output ◆
Enable ASCII 00-31 as Ctrl-xx output
0
1
Key Pad Emulation Disable key pad emulation ◆
Enable numeric output as key pad output
0
1
Upper/Lower Case Normal case ◆
Inverse case
Upper case
Lower case
0
1
2
3

Serial interface control
Command Parameter Selection Option Code
STX/ETX Control
Disable STX/ETX transmission ◆
Enable STX/ETX transmission
0
1
Record Suffix None
CR ◆
LF
CRLF
TAB
SPACE
User define character
0
1
2
3
4
5
6
Preamble None ◆
1-15 characters
FIN
[00-7F], [FIN]
Postamble None ◆
1-15 characters
FIN
[00-7F], [FIN]
Handshaking Protocol None ◆
RTS/CTS
ACK/ NAK
Xon/Xoff
0
1
2
3
Intermessage Delay None ◆
1-99 (x5) msec.
FIN
(2 digits)
8
Intercharacter Delay None ◆
1-99 (x5) msec.
FIN
(2 digits)
Interfunction Delay None ◆
1-99 (x5) msec.
FIN
(2 digits)
Baud Rate (BPS)
38.4K
19.2K BPS
9600 BPS ◆
4800 BPS
2400 BPS
1200 BPS
600 BPS
300 BPS
0
1
2
3
4
5
6
7
Data Frame
8, None,1 ◆
8, Odd, 1
8, Even, 1
8, Space, 1
8, Mark, 1
8, None, 2
7, Odd, 1
7, Even, 1
7, Space, 1
7, Mark, 1
7, None, 2
7, Odd, 2
7, Even, 2
7, Space, 2
7, Mark, 2
0
1
2
3
4
5
6
7
8
9
A
B
C
D
E
Time Out Control
None
200 msec.
500 msec. ◆
1 sec.
2 sec.
5 sec.
User define value (sec.)
0
1
2
3
4
5
6

Operation and output control
Command Parameter Selection Option Code
Operation Mode
Low power mode (Low power triggering)
Trigger mode/Serial mode (External triggering) ◆
Presentation mode (Auto Detection)
Alternative mode (Periodic power off)
Flash mode (Pulse driven reading)
Force mode (Continued power on)
Toggle mode (Repeat reading)
Diagnostic mode (Test reading)
0
1
2
3
4
5
6
7
Inverse Reading
Disable ◆
Enable
0
1
9
Redundancy
None
1 time ◆
2 times
3 times
4 times
5 times
To prevent potential miss reading.
0
1
2
3
4
5
Power On Indicator Disable
Enable ◆
Unavailable for FBC6000 series.
0
1
Vibrator Disable ◆
Enable
Unavailable for FBC6000 series.
0
1
Symbology ID Transmission Disable all symbology ID ◆
Enable prefix CINO symbology ID
Enable suffix CINO symbology ID
Enable both prefix and suffix CINO symbology ID
Enable prefix AIM symbology ID
Enable suffix AIM symbology ID
Enable both prefix and suffix AIM symbology ID
0
1
2
3
4
5
6
Dollar Sign Output
Dollar sign output as “ $ “ ◆
Dollar sign output as “￥“
Dollar sign output as “ € “
0
1
2
Good Read Delay None ◆
200 msec.
500 msec.
1 sec.
1.5 sec.
2 sec.
3 sec.
0
1
2
3
4
5
6
Reread Delay
Disable
Immediate time out
Short time out ◆
Medium time out
Long time out
Force verification
0
1
2
3
4
5
Auto Power Off Duration
Short
Medium
Long
Extremely long ◆
0
1
2
3

Operation and output control (continued)
Command Parameter Selection Option Code
Good Read Duration Short
Medium ◆
Long
Extremely long
0
1
2
3
10
Hands Free Time-out Short ◆
Medium
Long
Extremely long
0
1
2
3
Buzzer Tone Adjust
Buzzer tone – mute
Buzzer tone – low
Buzzer tone – medium ◆
Buzzer tone – high
Buzzer tone – extremely high
Good–read beep before data transmission ◆
Good–read beep after data transmission
Power–on beep ◆
No Power–on beep
0
1
2
3
4
5
6
7
8
Message string breakdown
Keyboard interface output (PS/2, DOS/V, USB HID)
Preamble Data Length Prefix ID Scanned Data
Suffix ID Postamble Record Suffix
1-15 char. 2-3 digits 1 or 2 char. Variable 1 or 2 char. 1-15 char. 1 char.
Serial interface output (RS-232, USB COM)
STX Preamble Data Length Prefix ID Scanned Data Suffix ID Postamble ETX Record
Suffix
1 char. 1-15 char. 2-3 digits 1 or 2 char. Variable 1 or 2 char. 1-15 char. 1 char. 1 char.

Option codes
0
1
2
3
4
5
6
7
8
9
A
B
C
D
E
F
FIN (Finish)
END (Exit)
11

System commands
12
PROGRAM
(Enter Programming Mode)
END
(Exit Programming Mode)
System Information
Factory Default
PowerTool Host Link
Save User Default
User Default
