AXIOMTEK MANO871 Series User manual

MANO871 Series
Intel®Socket 1155 CoreTM i7 / CoreTM
i5 / CoreTM i3 / Celeron®Processor
All-In-One Mini ITX Board with HDMI
/ DVI-I / LVDS
User’s Manual

ii
Disclaimers
This manual has been carefully checked and believed to contain accurate information.
Axiomtek Co., Ltd. assumes no responsibility for any infringements of patents or any third
party’s rights, and any liability arising from such use.
Axiomtek does not warrant or assume any legal liability or responsibility for the accuracy,
completeness or usefulness of any information in this document. Axiomtek does not make any
commitment to update the information in this manual.
Axiomtek reserves the right to change or revise this document and/or product at any time
without notice.
No part of this document may be reproduced, stored in a retrieval system, or transmitted, in
any form or by any means, electronic, mechanical, photocopying, recording, or otherwise,
without the prior written permission of Axiomtek Co., Ltd.
CAUTION
If you replace wrong batteries, it causes the danger of explosion. It is recommended by the
manufacturer that you follow the manufacturer’s instructions to only replace the same or
equivalent type of battery, and dispose of used ones.
Copyright 2013 Axiomtek Co., Ltd.
All Rights Reserved
August 2013, Version A2
Printed in Taiwan

iii
ESD Precautions
Computer boards have integrated circuits sensitive to static electricity. To prevent chipsets
from electrostatic discharge damage, please take care of the following jobs with precautions:
Do not remove boards or integrated circuits from their anti-static packaging until you are
ready to install them.
Before holding the board or integrated circuit, touch an unpainted portion of the system
unit chassis for a few seconds. It discharges static electricity from your body.
Wear a wrist-grounding strap, available from most electronic component stores, when
handling boards and components.
Trademarks Acknowledgments
Axiomtek is a trademark of Axiomtek Co., Ltd.
Windows®is a trademark of Microsoft Corporation.
AMI is a trademark of American Megatrend Inc.
IBM, PC/AT, PS/2, VGA are trademarks of International Business Machines Corporation.
Intel®CoreTM i7 / CoreTM i5 / CoreTM i3 / Celeron®are trademarks of Intel Corporation.
Winbond is a trademark of Winbond Electronics Corp.
Realtek is a trademark of Realtek Semi-Conductor Co., Ltd.
Other brand names and trademarks are the properties and registered brands of their
respective owners.

iv
Table of Contents
Disclaimers.....................................................................................................ii
ESD Precautions...........................................................................................iii
Chapter 1 Introduction............................................. 1
1.1 Features...............................................................................................1
1.2 Specifications......................................................................................2
1.3 Utilities Supported ..............................................................................3
Chapter 2 Board and Pin Assignments.................... 5
2.1 Board Dimensions and Fixing Holes.................................................5
2.2 Board Layout.......................................................................................7
2.3 Jumper and Switch Settings ..............................................................9
2.3.1 Restore BIOS Optimal Defaults (JP1)....................................................... 10
2.3.2 LVDS Voltage Selection (JP2 and JP3) .................................................... 10
2.3.3 USB Port 4 and 5 Power Selection (JP4) ................................................. 10
2.3.4 SATA/SATADOM Selection (JP5).............................................................. 10
2.3.5 LVDS Backlight Control Mode Setting (JP7)............................................. 10
2.3.6 Auto Power On (JP8) .................................................................................11
2.3.7 COM1 Data/Power Selection (JP10)..........................................................11
2.3.8 COM1 RS-232/422/485 Mode Setting (JP11, JP12, JP14) .......................11
2.3.9 COM3 Data/Power Selection (JP13)..........................................................11
2.3.10 PCI-Express Bifurcation Setting (SW1) .................................................... 12
2.3.11 Mini Card Interface Selection (JP16) ........................................................ 12
2.4 Connectors ........................................................................................13
2.4.1 ATX Power Connectors (CN2 and ATX1).................................................. 14
2.4.2 Serial ATAConnectors (CN3, CN4, SATA1 and SATA2)........................... 15
2.4.3 LVDS Connector (CN6)............................................................................. 16
2.4.4 Inverter Connectors (CN7)........................................................................ 18
2.4.5 USB Connectors (CN8 and CN9).............................................................. 18
2.4.6 LAN and USB Connectors (CN10 and CN11)........................................... 19
2.4.7 DVI-I Connector (CN12)............................................................................ 20
2.4.8 COM Connectors (CN13, CN14 and CN15) ............................................. 21
2.4.9 HD Audio Jack (CN16).............................................................................. 21
2.4.10 Internal Audio Connector (CN17).............................................................. 22
2.4.11 HDMI Connector (CN18)........................................................................... 22
2.4.12 PCI-Express Mini Card and mSATA Connector (SCN2)........................... 23
2.4.13 FAN Connectors (FAN1 and FAN2) .......................................................... 24
2.4.14 Front Panel Connector (JP6) .................................................................... 24
2.4.15 Digital I/O Connector (JP9) ....................................................................... 25

v
Chapter 3 Hardware Installation ........................... 27
3.1 Installing the Processor....................................................................27
3.2 Installing the Memory .......................................................................33
Chapter 4 Hardware Description ........................... 35
4.1 Microprocessors ...............................................................................35
4.2 BIOS ...................................................................................................35
4.3 System Memory.................................................................................35
4.4 I/O Port Address Map........................................................................36
4.5 Interrupt Controller (IRQ) Map .........................................................38
4.6 Memory Map ......................................................................................39
Chapter 5 AMI BIOS Setup Utility .......................... 41
5.1 Starting...............................................................................................41
5.2 Navigation Keys ................................................................................41
5.3 Main Menu..........................................................................................42
5.4 Advanced Menu.................................................................................43
5.5 Chipset Menu.....................................................................................52
5.6 Boot Menu..........................................................................................56
5.7 Security Menu....................................................................................57
5.8 Save & Exit Menu ..............................................................................58
Appendix A Watchdog Timer................................... 61
About Watchdog Timer................................................................................61
How to Use Watchdog Timer.......................................................................61
Appendix B Digital I/O ............................................. 63
Using Digital Output Function ....................................................................63
Using Digital Input Function .......................................................................63
Appendix C Configuring SATA for RAID .................. 65
Configuring SATA Hard Drive(s) for RAID Function..................................65
Appendix D Intel®iAMT Settings ............................ 75
Entering MEBx .............................................................................................75
Set and Change Password..........................................................................76
Intel®iAMT Web Console ............................................................................78

vi
This page is intentionally left blank.

MANO871 Series All-In-One Mini ITX Board
Introduction 1
Chapter 1
Introduction
The MANO871 is a Mini ITX board with LGA1155 socket for Intel®CoreTM i7 / Intel®CoreTM i5 /
Intel®CoreTM i3 / Intel®Celeron®(G6950) desktop processor with 22nm technology. The board
integrates Intel®Q77 chipset that delivers outstanding system performance through
high-bandwidth interfaces, multiple I/O functions for interactive applications and various
embedded computing solutions. There are two 204-pin DDR3 SO-DIMM sockets for dual
channel DDR3 1333/1600MHz memory with maximum capacity up to 16GB; assuming dual
channel mode of two 8GB double-sided unbuffered, non-ECC SO-DIMM memory configuration.
The board also features Gigabit Ethernet, two SATA 3.0 ports (support SATA RAID 0/1/5/10 by
Q77) at maximum transfer rate up to 6Gb/s, two SATA 2.0 ports at maximum transfer rate up to
3Gb/s, four USB 3.0 and four USB 2.0 high speed compliant ports that can achieve the best
stability and reliability for industrial applications.
1.1 Features
LGA1155 socket 3rd Generation Intel®CoreTM i7 / i5 / i3 / Celeron® processors
2 DDR3 1333/1600MHz up to 16GB
PCI-Express Gen. 3 supported
2 SATA-600 with RAID 0, 1, 5 and 10 supported
2 SATA-300 with 1 SATADOM supported
4 USB 3.0 supported
iAMT 8.0 supported
TPM 1.2 supported
Dual view display

MANO871 Series All-In-One Mini ITX Board
2 Introduction
1.2 Specifications
CPU
Intel®CoreTM i7 desktop processor.
Intel® CoreTM i5 desktop processor.
Intel® CoreTM i3 desktop processor.
Intel®Celeron®desktop processors.
System Chipset
Intel®Q77.
CPU Socket
LGA1155.
DRAM Transfer Rate
1333/1600MHz.
BIOS
AMI BIOS via SPI interface with socket.
System Memory
Two 204-pin unbuffered DDR3 SO-DIMM sockets.
Maximum up to 16GB DDR3 1333/1600MHz memory with two SO-DIMMs using
8GB memory technology.
Onboard Multi I/O
Controller: Nuvoton NCT6627UD.
Serial ports: Three RS-232 ports (COM2/3/4) and one RS-232/422/485 port (COM1).
SATADOM (Optional)
One SATADOM supported; co-layout with a SATA-300 socket (according to SATA
2.0 signal).
Serial ATA
Supports SATA 3.0 and SATA 2.0.
Two SATA 3.0 ports (6Gb/s performance) with SATA RAID 0/1/5/10 by Q77 and two
SATA 2.0 ports (3Gb/s performance).
USB Interface
Four USB 3.0 ports with fuse protection.
Four USB 2.0 ports with fuse protection.
Display
One HDMI.
One LVDS 24-bit dual channel.
One DVI-I.
Note: Due to Intel design limitation and BIOS default option, under DOS only VGA display
is supported.

MANO871 Series All-In-One Mini ITX Board
Introduction 3
Watchdog Timer
1~255 seconds; up to 256 levels.
Expansion Interface
One PCI-Express x16 slot.
Ethernet
LAN1 –Intel®82579LM supports 10/100/1000Mbps.
LAN2 –Intel®82583V supports 10/100/1000Mbps.
Audio
HD audio compliant (with line/speaker-out and MIC-in) via ALC662.
Internal audio feature for speaker-out via wafer connector.
Power Management
ACPI (Advanced Configuration and Power Interface).
Form Factor
Mini ITX form factor.
Note: All specifications and images are subject to change without notice.
1.3 Utilities Supported
Chipset driver
Ethernet driver
Graphics driver
Audio driver

MANO871 Series All-In-One Mini ITX Board
4 Introduction
This page is intentionally left blank.

MANO871 Series All-In-One Mini ITX Board
Board and Pin Assignments 5
Chapter 2
Board and Pin Assignments
2.1 Board Dimensions and Fixing Holes
Top Side

MANO871 Series All-In-One Mini ITX Board
6 Board and Pin Assignments
Bottom Side

MANO871 Series All-In-One Mini ITX Board
Board and Pin Assignments 7
2.2 Board Layout
Top Side
I/O Bracket

MANO871 Series All-In-One Mini ITX Board
8 Board and Pin Assignments
Bottom Side

MANO871 Series All-In-One Mini ITX Board
Board and Pin Assignments 9
2.3 Jumper and Switch Settings
Jumper is a small component consisting of jumper clip and jumper pins. Install jumper clip on 2
jumper pins to close. And remove jumper clip from 2 jumper pins to open. The following
illustration shows how to set up jumper.
Before applying power to MANO871 Series, please make sure all of the jumpers and switch
are in factory default position. Below you can find a summary table and onboard default
settings.
Jumper and
Switch
Description
Setting
JP1
Restore BIOS Optimal Defaults
Default: Normal Operation
1-2 close
JP2
(Optional)
LVDS Voltage Selection
All open
JP3
LVDS Voltage Selection
Default: +3.3V
1-2 close
JP4
USB Port 4 and 5 Power Selection
Default: Standby Power +5V
1-2 close
JP5
SATA/SATADOM Selection
Default: SATA
2-3 close
JP7
LVDS Backlight Control Mode Setting
Default: PWM Mode
1-2 close
JP8
Auto Power On
Default: Disable
1-2 close
JP10
COM1 Data/Power Selection
Default: RS-232 Data
CN15A Pin 1: DCD
3-5 close
CN15A Pin 9: RI
4-6 close
JP11
COM1 RS-232/422/485 Mode Setting
Default: RS-232
3-5, 4-6 close
JP12
1-2 close
JP14
3-5, 4-6 close
JP13
COM3 Data/Power Selection
Default: RS-232 Data
CN13 Pin 1: DCD
3-5 close
CN13 Pin 8: RI
4-6 close
JP16
Mini Card Interface Selection
Default: PCI-Express Interface
1-2 Close
SW1
PCI-Express Bifurcation Setting
Default: One x16 PCI-Express
SW1-1 OFF
SW1-2 OFF

MANO871 Series All-In-One Mini ITX Board
10 Board and Pin Assignments
2.3.1 Restore BIOS Optimal Defaults (JP1)
Put jumper clip to pin 2-3 for a few seconds then move it back to pin 1-2. Doing this
procedure can restore BIOS optimal defaults.
2.3.2 LVDS Voltage Selection (JP2 and JP3)
The board supports voltage selection for flat panel displays. Use JP3 to set LVDS
connector (CN6) pin 1~6 VCCM to +3.3V or +5V voltage level. Use JP2 (optional) to set
LVDS connector (CN6) pin 1~6 VCCM to +12V voltage level. To prevent hardware
damage, before connecting please make sure that the input voltage of LVDS flat panel is
correct.
JP2 JP3
2.3.3 USB Port 4 and 5 Power Selection (JP4)
Use JP4 for setting USB power signal on connector CN9 to standby power or system
power.
2.3.4 SATA/SATADOM Selection (JP5)
Use JP5 for enabling connector CN4 to support SATA or SATADOM.
2.3.5 LVDS Backlight Control Mode Setting (JP7)
The JP7 is enabled to select PWM or DC control mode for inverter connector (CN7).
These two control modes are for adjusting LVDS brightness.
Function
Setting
Normal operation (Default)
1-2 close
Restore BIOS optimal defaults
2-3 close
Function
JP3 Setting
+3.3V level (Default)
1-2 close
+5V level
2-3 close
Function
JP2 Setting
+12V level (Optional)
1-2 close
Function
Setting
Standby power +5V level (Default)
1-2 close
System power +5V level
2-3 close
Function
Setting
SATADOM
1-2 close
SATA (Default)
2-3 close
Function
Setting
PWM mode (Default)
1-2 close
DC mode
3-4 close

MANO871 Series All-In-One Mini ITX Board
Board and Pin Assignments 11
2.3.6 Auto Power On (JP8)
If JP8 is enabled for AC power input, the system will be automatically power on without
pressing soft power button. If JP8 is disabled for AC power input, it is necessary to
manually press soft power button to power on the system.
2.3.7 COM1 Data/Power Selection (JP10)
The COM1 port has +5V level power capability on DCD and +12V level on RI by setting
this jumper. When COM1 is set to +5V or +12V level, please make sure the
communication mode is RS-232 (see section 2.3.8).
2.3.8 COM1 RS-232/422/485 Mode Setting (JP11, JP12, JP14)
Use these jumpers to set COM1 port to operate as RS-232, RS-422 or RS-485
communication mode. When these jumpers are set to operate as RS-422 or RS485
mode, please make sure COM1 is on data mode (see section 2.3.7)
JP11 JP12 JP14
2.3.9 COM3 Data/Power Selection (JP13)
The COM3 port has +5V level power capability on DCD and +12V level on RI by setting
this jumper.
Function
Setting
Disable auto power on (Default)
1-2 close
Enable auto power on
2-3 close
Function
Setting
Power: Set CN15A pin 1 to +5V level
1-3 close
Data: Set CN15A pin 1 to DCD (Default)
3-5 close
Power: Set CN15A pin 9 to +12V level
2-4 close
Data: Set CN15A pin 9 to RI (Default)
4-6 close
Function
Setting
RS-232 mode
(Default)
JP11 3-5, 4-6 close
JP12 1-2 close
JP14 3-5, 4-6 close
RS-422 mode
JP11 1-3, 2-4 close
JP12 3-4 close
JP14 1-3, 2-4 close
RS-485 mode
JP11 1-3, 2-4 close
JP12 5-6 close
JP14 1-3, 2-4 close
Function
Setting
Power: Set CN13 pin 1 to +5V level
1-3 close
Data: Set CN13 pin 1 to DCD (Default)
3-5 close
Power: Set CN13 pin 8 to +12V level
2-4 close
Data: Set CN13 pin 8 to RI (Default)
4-6 close

MANO871 Series All-In-One Mini ITX Board
12 Board and Pin Assignments
2.3.10 PCI-Express Bifurcation Setting (SW1)
SW1 is for PCI-Express bifurcation setting. See table below for detailed information.
SW1
2.3.11 Mini Card Interface Selection (JP16)
Use JP16 for setting Mini Card to PCI-Express or mSATA.
Function
Setting
One x16 PCI-Express (Default)
SW1-1 OFF
SW1-2 OFF
Two x8 PCI-Express
SW1-1 OFF
SW1-2 ON
One x8, two x4 PCI-Express
SW1-1 ON
SW1-2 ON
Reserved
SW1-1 ON
SW1-2 OFF
Function
Setting
PCI-Express Interface (Default)
1-2 close
mSATA Interface
2-3 close

MANO871 Series All-In-One Mini ITX Board
Board and Pin Assignments 13
2.4 Connectors
Signals go to other parts of the system through connectors. Loose or improper connection
might cause problems, please make sure all connectors are properly and firmly connected.
Here is a summary table which shows all connectors on the hardware.
Connector
Description
CN1
PCI-Express x16 Slot
CN2
24-pin ATX Power Connector
CN3
Serial ATA 2.0 port 2 Connector
CN4
Serial ATA 2.0 port 3 Connector (Optional for SATADOM)
CN6
LVDS Connector
CN7
Inverter Connector
CN8
USB 2.0 Port 6 and 7 Connector
CN9
USB 2.0 Port 4 and 5 Connector
CN10
LAN1 (WG82579LM), USB 3.0 Port 2 and 3 Connector
CN11
LAN2 (WG82583V), USB 3.0 Port 0 and 1 Connector
CN12
DVI-I Connector
CN13
COM3 Connector
CN14
COM4 Connector
CN15
COM1 and COM2 Connector
CN16
HD Audio Jack
CN17
Internal Audio Connector
CN18
HDMI Connector
SCN2
PCI-Express Mini Card and mSATA Connector
ATX1
4-pin +12V ATX Power Connector
FAN1
CPU Fan Connector
FAN2
System Fan Connector
JP6
Front Panel Connector
JP9
Digital I/O Connector
SATA1~2
Serial ATA 3.0 port 0 and 1 Connectors
DIMM1~2
DDRIII SO-DIMM Connectors

MANO871 Series All-In-One Mini ITX Board
14 Board and Pin Assignments
2.4.1 ATX Power Connectors (CN2 and ATX1)
Steady and sufficient power can be supplied to all components on the board by
connecting power connector. Please make sure all components and devices are
properly installed before connecting the power connector.
External power supply plug fits into this connector in only one orientation. Properly press
down power supply plug until it completely and firmly fits into this connector. Loose
connection may cause system instability.
The CN2 is a 24-pin ATX power connector. Its pin assignments are given in table below.
The ATX1 is a 4-pin +12V ATX power connector for connecting CPU core voltage, see
table below.
Pin
Signal
Pin
Signal
1
3.3V
13
3.3V
2
3.3V
14
-12V
3
GND
15
GND
4
+5V
16
PS_ON
5
GND
17
GND
6
+5V
18
GND
7
GND
19
GND
8
PWR OK
20
-5V
9
5VSB
21
+5V
10
+12V
22
+5V
11
+12V
23
+5V
12
3.3V
24
GND
Pin
Signal
Pin
Signal
1
GND
3
+12V
2
GND
4
+12V
