INTRODUCTION
1. COVERAGE
This Cirrus Design SR20 Airplane Maintenance Manual was prepared by Cirrus Design Technical Publica-
tions. This manual contains information necessary to enable a trained mechanic to inspect, service, clean,
trouble shoot, functionally test, and repair systems and equipment in the Cirrus Design SR20. It also
includes information necessary for the mechanic to perform maintenance or make minor repair to units in
the airplane normally requiring such action on the flight line or in the maintenance hangar. This manual
covers the as delivered airplane configuration.
The Cirrus Design SR20 Airplane Maintenance Manual was prepared using GAMA Specification No. 2
(Specification for Manufacturers Maintenance data), Revised September 1982 as a content model and for-
mat guide. However, as the specification is written to cover a whole class of aircraft rather than a particular
model, some deviations from the specification were made for clarity.
This Maintenance Manual does not reflect part numbers and cannot be used for ordering replacement
parts. Spares and replacement parts should be ordered using the current Cirrus Design SR20 Illustrated
Parts Catalog.
Wiring schematics within the description and operation sections of this manual are for general information
purposes only. Troubleshooting shall be performed using the Wiring Manual, and the optional avionics and
electrical wiring diagrams provided at delivery.
2. USING THE MAINTENANCE MANUAL
This Maintenance Manual is divided into four major sections, each of which is separated into chapters.
Each chapter contains its own list of effective pages and table of contents.
A. Page Numbering System
Page numbers used in this Maintenance Manual consist of two-element numbers separated by
dashes, under which the page number and date are printed.
Whenever the chapter/system element number is followed by zeros in the section/subsystem (32-00)
the information presented on the page is applicable to the entire system.
The section/subsystem number is used to identify information applicable to section or subsystems
within a chapter or system respectively. The subject/unit element number progresses from the number
‘10’ in accordance with GAMA Specification No. 2 and the number of section/subsystem units covered.
All system/subsystem data is page numbered separately.
3. WARNINGS, CAUTIONS, AND NOTES
Warnings, Cautions, and Notes are used to highlight or emphasize important points.
Warnings call attention to use of materials, processes, methods, procedures, or limits which must be fol-
lowed precisely to avoid bodily injury.
Cautions call attention to methods and procedures which must be followed to avoid damage to equipment.
Notes call attention to methods which make the procedure easier.
15 Jun 2010

AMM-Intro-
Page 2 All
EFFECTIVITY:
CIRRUS AIRPLANE MAINTENANCE MANUAL MODEL SR20
19 Sep 2017
4. AIRPLANE SERIAL NUMBER EFFECTIVITY
Airplane serial number effectivity references are used throughout the maintenance manual to distinguish
between different system designs and procedures. The effectivities are italicized and are displayed in the
same font weight as the adjacent text.
Effectivity references under the “General” or “Description” sections are handled in one of two ways. If effec-
tivity applies to entire paragraph, the effectivity reference will preface the paragraph with a colon. If effectiv-
ity applies to only a section of the paragraph, the affected content shall be followed by the effectivity
reference in parentheses.
Effectivity references under the “Troubleshooting” section are handled one of three ways. If effectivity
applies to the probable cause and/or remedy item in the table, the effectivity reference will preface the
paragraph followed by a colon and may share the table cell with one or more additional effectivity blocks. If
effectivity applies to the trouble item in the table, the effectivity reference will preface the paragraph fol-
lowed by a colon. All probable cause and remedy items in that table row will pertain only to the effectivity
defined for the trouble item. Alternately, a standalone table may be defined for a particular effectivity if trou-
bleshooting differs greatly due to varying model configurations.
Effectivity references under the “Maintenance Practices” section are handled in one of two ways. If effectiv-
ity applies to only a few steps in a procedure, the effectivity reference will preface the step followed by a
colon. If procedures differ greatly based on effectivity, the component and related procedures will be pre-
sented in blocks with an effectivity reference for each block.
Effectivity is also indicated in the effectivity block in the bottom corner of each page. On illustration pages,
the effectivity is on the face of the illustration and in the title block beneath the illustration.
Note: For content specified with serials followed by “and subsequent” or “& subs”, effectivity in this
AMM ends as follows:
A. Aircraft Equipped with G3 Wing
Airplane serial numbers 1878, 1886 and subsequent are equipped with a redesigned wing. Where
necessary, this document may use the terms “G3” or “G3 Wing” to identify this installation. The list
below shows the primary structural and system changes which accompany G3 Wing configuration:
• 1 degree increase in wing dihedral,
• Removal of the aileron-rudder interconnect,
• Increased fuel capacity and associated updates to sensing and indicating system,
• Main landing gear location moved slightly, strut angle increased, and strut lengthened,
• Redesigned main landing gear fairings,
• Redesigned nose landing gear fairings,
• Redesigned lightning protection plan,
• Relocation of stall warning port,
• RH lower engine cowling modified,
• Redesigned environmental control system,
• Redesigned wing root fairings,
• Modification of interior trim panels,
Model End Effectivity
SR20 2338

CIRRUS AIRPLANE MAINTENANCE MANUAL MODEL SR20
AMM-Intro-
Page 3
All
EFFECTIVITY:
• Redesigned bolster switch panel,
• Leading-edge wing tip recognition lights.
B. Special Conditions
New features are sometimes introduced on a “pilot” airplane before going into regular production. As a
result, certain parts or assemblies are installed on a range of airplanes with a “split” or a break in
affected serial number range.
For example, a split effectivity listing of “Serials 1878, 1886 & subs” indicates that a part or assembly
was installed on aircraft serial number 1878, then removed on serial numbers 1879 through 1885, and
then introduced as standard configuration on aircraft serial numbers 1886 and subsequent.
In many instances these split effectivities can result in difficult-to-interpret descriptions listing multiple
serial numbers. To avoid including these cumbersome descriptions throughout the length of this publi-
cation, see the following Special Conditions table for a list of affected aircraft serial numbers and
instruction on how to disposition the aircraft’s as-built configuration.
C. Service Bulletins
Note: When part effectivities are conditional to modifications, such as service bulletins, the air-
plane logbook should be checked to determine the proper replacement parts.
Installation of service bulletins are shown by notations in the maintenance procedure and figure. The
term “Before SB 20-XX-XX" indicates that the part effectivity is as written unless the subject Service
Bulletin was installed. The term “After SB 20-XX-XX” indicates that the part effectivity is as written
when the airplane has been modified in accordance with the subject Service Bulletin.
Serial Number Special Condition Disposition
1301 Aircraft installed with updated bulkhead 306. Unless otherwise noted, refer to
serial number 1307 for part identifi-
cation.
1633 Aircraft installed with Environmental Control
System with factory installed fan.
Unless otherwise noted, refer to
serial number 1639 for part identifi-
cation.
1878 Aircraft installed with G3 Wing and associ-
ated systems.
Aircraft installed with Aircraft Data Logger
(ADL) and associated systems.
Unless otherwise noted, refer to
serial number 1886 for part identifi-
cation of systems affected by G3
Wing and ADL installations.
1907 Aircraft installed with Perspective Avionics
and associated systems.
Unless otherwise noted, refer to
serial number 2016 for part identifi-
cation.
2058 Aircraft installed with Air Conditioning Sys-
tem.
Aircraft installed with Oleo Strut.
Unless otherwise noted, refer to
serial number 2065 for part identifi-
cation.
2220 Aircraft installed with Lycoming Engine.
Aircraft installed with Perspective+ Avionics.
Unless otherwise noted, refer to
serial number 2339 in AMM P/N
12137-002 for part identification.
19 Sep 2017

AMM-Intro-
Page 4 All
EFFECTIVITY:
CIRRUS AIRPLANE MAINTENANCE MANUAL MODEL SR20
19 Sep 2017
D. Avionics Configuration
Airplane serial effectivities shown in a maintenance procedure or figure may be further limited by the
airplane’s avionics configuration. Cirrus Design offers the SR20 with the avionic options listed in the
table below; therefore, the effectivity for a maintenance procedure or figure may also be limited by the
installed avionics.
Standard avionics suites are available in the following configurations:
Serials 1005 through 1267:
Configuration A
Moving Map Display (ARNAV ICDS 2000 MFD)
Single-Axis Autopilot (S-Tec System 20)
Integrated Audio System with Intercom (Garmin GMA 340)
Marker Beacon Receiver (Garmin GMA 340)
One IFR Approach-Certified GPS (Garmin GNS 430) and One VFR GPS (Garmin GNC 250XL)
Two VHF Communications (Garmin GNS 430 and Garmin GNC 250XL)
Single Navigation (VOR/LOC/GS) Receiver (Garmin GNS 430)
Mode C Transponder with Altitude Encoder (Serials 1005 thru 1099: Garmin GTX 320, Serials 1100
thru 1267: Garmin GTX 327)
Course Deviation Indicator (Serials 1005 thru 1047: Garmin GI 102, Serials 1048 thru 1267: Garmin
GI 102A)
Directional Gyro
Configuration B
Moving Map Display (ARNAV ICDS 2000 MFD)
Two-Axis Autopilot (S-Tec System 30)
Integrated Audio System with Intercom (Garmin GMA 340)
Marker Beacon Receiver (Garmin GMA 340)
Two IFR Approach-Certified GPS (Garmin GNS 430 and Garmin GNC 420)
Two VHF Communications Transceivers (Garmin GNS 430 and Garmin GNC 420)
Single Navigation (VOR/LOC/GS) Receiver (Garmin GNS 430)
Mode C Transponder with Altitude Encoder (Serials 1005 thru 1099: Garmin GTX 320, Serials 1100
thru 1267: Garmin GTX 327)
Horizontal Situation Indicator (Century NSD 360A)
Course Deviation Indicator (Serials 1005 thru 1047: Garmin GI 102, Serials 1048 thru 1267: Garmin
GI 102A)

CIRRUS AIRPLANE MAINTENANCE MANUAL MODEL SR20
AMM-Intro-
Page 5
All
EFFECTIVITY:
Serials 1268 thru 1336:
Configuration C
Moving Map Display (ARNAV ICDS 2000 MFD)
Two-Axis Autopilot (S-Tec System 55)
Integrated Audio System with Intercom (Garmin GMA 340)
Marker Beacon Receiver (Garmin GMA 340)
Two IFR Approach-Certified GPS (Garmin GNS 430)
Two VHF Communications Transceivers (Garmin GNS 430)
Two Navigation (VOR/LOC/GS) Receiver (Garmin GNS 430)
Mode C Transponder with Altitude Encoder (Garmin GTX 327)
Horizontal Situation Indicator (Century NSD 1000)
Course Deviation Indicator (Serials 1005 thru 1047: Garmin GI 106, Serials 1048 thru 1267: Garmin
GI 106A)
Configuration 2.0
Moving Map Display (Avidyne EX3000C MFD)
Single-Axis Autopilot (S-Tec System 20)
Integrated Audio System with Intercom (Garmin GMA 340)
Marker Beacon Receiver (Garmin GMA 340)
One IFR Approach-Certified GPS (Garmin GNS 430) and One VFR GPS (Garmin GNC 250XL)
Two VHF Communications (Garmin GNS 430 and Garmin GNC 250XL)
Single Navigation (VOR/LOC/GS) Receiver (Garmin GNS 430)
Mode C Transponder with Altitude Encoder (Garmin GTX 327)
Horizontal Situation Indicator (Century NSD 1000)
Course Deviation Indicator (Garmin GI 106)
Configuration 2.1
Moving Map Display (Avidyne EX5000C MFD)
Two-Axis Autopilot (S-Tec System 30)
Integrated Audio System with Intercom (Garmin GMA 340)
Marker Beacon Receiver (Garmin GMA 340)
Two IFR Approach-Certified GPS (Garmin GNS 430 and Garmin GNC 420)
Two VHF Communications Transceivers (Garmin GNS 430 and Garmin GNC 420)
Single Navigation (VOR/LOC/GS) Receiver (Garmin GNS 430)
Mode C Transponder with Altitude Encoder (Garmin GTX 327)
Horizontal Situation Indicator (Century NSD 1000)
Course Deviation Indicator (Garmin GI 102A)
19 Sep 2017

AMM-Intro-
Page 6 All
EFFECTIVITY:
CIRRUS AIRPLANE MAINTENANCE MANUAL MODEL SR20
19 Sep 2017
Serials 1337 and subsequent:
Serials 1359 and subsequent:
Configuration 2.2
Moving Map Display (Avidyne EX5000C MFD)
Two-Axis Autopilot (S-Tec System 55X)
Integrated Audio System with Intercom (Garmin GMA 340)
Marker Beacon Receiver (Garmin GMA 340)
Two IFR Approach-Certified GPS (Garmin GNS 430)
Two VHF Communications Transceivers (Garmin GNS 430)
Two Navigation (VOR/LOC/GS) Receiver (Garmin GNS 430)
Mode C Transponder with Altitude Encoder (Garmin GTX 327)
Electronic Navigation Display (Sandel SN3308)
Course Deviation Indicator (Garmin GI 106A)
Configuration PFD
Primary Flight Display (Avidyne FlightMax Entegra PFD)
Moving Map Display (Avidyne EX5000C MFD)
Two-Axis Autopilot (S-Tec System 55SR)
Integrated Audio System with Intercom (Garmin GMA 340)
Marker Beacon Receiver (Garmin GMA 340)
One IFR Approach-Certified GPS (Garmin GNS 430) and One VFR GPS (Garmin GNC 250XL)
Two VHF Communications (Garmin GNS 430 and Garmin GNC 250XL)
Single Navigation (VOR/LOC/GS) Receiver (Garmin GNS 430)
Mode C Transponder with Altitude Encoder (Garmin GTX 327)
Configuration SRV
Primary Flight Display (Avidyne FlightMax Entegra PFD)
Moving Map Display (Avidyne EX3000C MFD)
Integrated Audio System with Intercom (Garmin GMA 340)
Marker Beacon Receiver (Garmin GMA 340)
One IFR Certified GPS (Garmin GNC 420)
One VHF Communications (Garmin GNC 420)
Mode C Transponder with Altitude Encoder (Garmin GTX 327)

CIRRUS AIRPLANE MAINTENANCE MANUAL MODEL SR20
AMM-Intro-
Page 7
All
EFFECTIVITY:
Serials 2016 and subsequent:
Serials 2086, 2087, 2117, 2120, 2122 thru 2126, 2129 thru 2132, 2136 thru 2147 with Option
Installed:
Configuration Perspective
Multi-Function Display (Garmin MFD)
Primary Flight Display (Garmin PFD)
Two-Axis Autopilot (Garmin GFC 700)
Serials 2016 thru 2126: Integrated Audio System with Intercom (Garmin GMA 347)
Serials 2127 & subs: Integrated Audio System with Intercom (Garmin GMA 350)
Serials 2016 thru 2126: Marker Beacon Receiver (Garmin GMA 347)
Serials 2127 & subs: Marker Beacon Receiver (Garmin GMA 350)
Two IFR Approach-Certified GPS (Garmin GIA 63W)
Two VHF Communications Transceivers (Garmin GIA 63W)
Two Navigation (VOR/LOC/GS) Receiver (Garmin GIA 63W)
Mode C Transponder with Altitude Encoder (Garmin GTX 32)
Flight Management System Keyboard (Garmin GCU 478)
Attitude and Heading Reference System (Garmin GRS 77)
Air Data Computer (Garmin GDC 74A)
Engine Airframe Unit (Garmin GEA 71)
Configuration “S” United States Airforce Academy
Perspective Avionics Configuration with following options installed:
- 10-inch PFD Display
- 10-inch MFD Display
- Single Attitude and Heading Reference System (Garmin GRS 77)
- Single Air Data Computer (Garmin GDC 74A)
- Engine Airframe Unit (Garmin GEA 71)
- Integrated Audio System with Intercom (Garmin GMA 347)
- Marker Beacon Receiver (Garmin GMA 347)
- Two IFR Approach-Certified GPS (Garmin GIA 63W)
- Two VHF Communications Transceivers (Garmin GIA 63W)
- Two Navigation (VOR/LOC/GS) Receiver (Garmin GIA 63W)
- Flight Management System Keyboard (Garmin GCU 478)
- Mode C Transponder with Altitude Encoder (Garmin GTX 32)
- Garmin GTS 800 Traffic Advisory System
- No Automatic Flight Control System (ACFS)
- No Garmin Synthetic Vision (SynVis)
19 Sep 2017

AMM-Intro-
Page 8 All
EFFECTIVITY:
CIRRUS AIRPLANE MAINTENANCE MANUAL MODEL SR20
19 Sep 2017
E. Optional Equipment
Airplane serial effectivities shown in a maintenance procedure or figure may be further limited by
optional equipment installed in the airplane. Cirrus Design offers the SR20 with the optional equipment
listed in the table below; therefore, the effectivity for a maintenance procedure or figure may also be
limited by the installed optional equipment.
- No Weather System (WX)
- No Terrain Awareness & Warning (TAWS)
- No Terminal Procedure Chart System
Artex ME406 Emergency Locator Transmitter (ELT)
Vent-Only Environment Control System
Fabric Seats
2-Blade Propeller
No Wheel Pants
No Rear Seats
No Rear Seat Headset Plugs
No Ice Protection System
No Carbon Monoxide (CO) Detector
No Enhanced Vision System (EVS)
No Wing Recognition Lights
Optional Equipment
Serials 1005 through 1336: Century NSD 1000 Horizontal Situation Indicator
Serials 1148 & subs: L3 SkyWatch
Serials 1032 & subs: L3 Stormscope
Serials 1148 & subs: S-Tec System 55X
Serials 1148 through 1336: Sandel SN3308 Electronic Navigation Display
Serials 1179 & subs: Avidyne EX3000C and EX5000C MFD
Serials 1233 & subs: Avidyne EMax Engine Monitoring System
Serials 1425 & subs: Garmin Mode S Transponder
Serials 1441 & subs: Honeywell Terrain Awareness and Warning System
Serials 1473 & subs Avidyne XM Weather System
Serials 2127 & subs: Iridium Weather System
Serials 1494 & subs: Avidyne Flight Director
Serials 1533 & subs: XM Radio System
Serials 1633, 1639 & subs: Cabin Air Fan Assembly
Serials 2065 & subs w/ Perspective Avionics: Air Conditioning System
Serials 2065 & subs: Oleo Strut
Configuration “S” United States Airforce Academy (Continued)

CIRRUS AIRPLANE MAINTENANCE MANUAL MODEL SR20
AMM-Intro-
Page 9
All
EFFECTIVITY:
5. REVISIONS
This manual has been prepared in loose-leaf form for ease in inserting revisions. Tabbed dividers, through-
out the manual, are in standard GAMA format and numbering and allow quick reference to data in each
section. Logical and convenient Tables of Contents are located at the beginning of each chapter to aid in
locating specific data within that chapter.
Numbered revisions will be issued periodically. These revisions are printed on white paper and contain a
revision instruction sheet to assist the user in filing the change.
Upon receipt of a numbered revision, file it according to the provided instructions as soon as possible.
Additionally, a record of filing must be made on the following Log of Revisions page.
6. REVISION BARS
Changes to data in an existing section will be identified by a revision bar in the outer margin of the page.
Change bars are used in figures to indicate changes.
7. TEMPORARY REVISIONS
Temporary revisions are used to provide time sensitive information and changes as they become available.
Temporary revisions provide, with the least possible delay, new information which assists in maintaining
safe and efficient flight/ground operations.Temporary revisions are incorporated at the next regularly
scheduled revision and become a permanent part of the Maintenance Manual.
Upon receipt of a Temporary Revision, file the revision in the applicable chapter in accordance with filing
instructions that appear on the Temporary Revision. Additionally, a record of filing the Temporary Revision
must be made in the Log of Temporary Revisions for that AMM chapter. Typically, the Log Of Temporary
Revisions for a chapter will be replaced by a blank log when a numbered revision for that chapter is issued.
Temporary Revisions should be removed from this manual only when removal instructions are noted on the
regular revision summary sheet or by instructions noted on a superseding Temporary Revision.
8. PUBLICATION CHANGE REQUEST FORM
A Publication Change Request form can be found online at the following link:
http://www.cirrusdesign.com/serviceandupgrades/serviceloopform
Use the form to submit a Publications Change Request to our Engineering Department and/or to tell us
what you think of the quality of the publication. We will use the data you provide us to improve the quality of
our technical publications.
Serials 1639 & subs: Artex ME406 Emergency Locator Transmitter (ELT)
Serials 2016 & subs: Bendix/King Distance Measuring Equipment
Serials 2016 & subs: Bendix/King Automatic Direction Finder
Serials 2016 & subs: Garmin Synthetic Vision
Serials 2016 & subs: Enhanced Vision System
Serials 2127 & subs: 2+1 Rear Seat
Serials 2127 & subs: Three-Harness Shoulder Belt
Serials 2127 & subs: Cargo Net
Serials 2273 & subs: MD302 Standby Attitude Module
Optional Equipment (Continued)
19 Sep 2017

AMM-Intro-
Page 10 All
EFFECTIVITY:
CIRRUS AIRPLANE MAINTENANCE MANUAL MODEL SR20
31 May 2011
Intentionally Left Blank
