QUICK START GUIDE
Cisco Service Control Engine 2000 4xGBE QUICK START GUIDE,
RELEASE 3.8.X
1Preparing for Installation
2Rack-Mounting the SCE 2000 Chassis
3Connecting Power Supply Units
4Connecting Management Interfaces and Performing Initial System Configuration
5Cabling Line Ports
6Completing the Installation
7Troubleshooting
8Obtaining Documentation and Submitting a Service Request

2
Revised: September 17, 2012, OL-26789-01
Note This document supports all 3.8.x releases.
1 Preparing for Installation
This section contains warnings, tools and part information, and site preparation details.
Warning This warning symbol means danger. You are in a situation that could cause bodily injury. Before you work on any
equipment, be aware of the hazards involved with electrical circuitry and be familiar with standard practices for
preventing accidents.
Warning Only trained and qualified personnel should install, replace, or service this equipment.
Warning Read the installation instructions before you connect the system to its power source.
Warning This unit is intended for installation in restricted access areas. A restricted access area is where access can only
be gained by service personnel through the use of a special tool, lock and key, or other means of security, and is
controlled by the authority responsible for the location.
Warning Voltage is present on the backplane when the system is operating. To reduce risk of an electric shock, keep hands
and fingers out of the power supply bays and backplane areas.
Warning Do not work on the system or connect or disconnect cables during periods of lightning activity.
Warning Before you begin the installation of the SCE 2000 platform, read the Regulatory Compliance and Safety Information
for the Cisco Service Control Engines (SCE) document.
Site Preparation
•Print out and have accessible the “Cisco SCE 2000 GBE Installation Checklist”, found in the Cisco SCE 2000 GBE
Installation and Configuration Guide, to record information about this installation.
•Verify that the power service at the site is suitable for the SCE 2000 chassis.
•Verify that there is at least a two inch (5 cm) clearance on both sides of the SCE 2000 and five inches (12.7 cm) at the rear
for adequate airflow for the inlet and exhaust vents.

3
Tools and Parts
Use the following list of tools and parts as a checklist for preparing to install the SCE 2000 chassis:
•Number 1 and number 2 Phillips screwdrivers
•1/4-inch flat-blade screwdriver
•Tape measure and level
•Masking tape or some other method of marking the desired installation height in the rack
•1/4-inch hex wrench
•Grounding kit (shipped with SCE 2000)
•12 AWG or 2.5 mm copper installation wire with hex or loop connectors for DC power leads (DC power only) Ring
terminals must be UL approved and suitable for 12 AWG wire.
•AC power cords (AC power only, shipped with SCE 2000)
•Rack-mounting kit (shipped with SCE 2000)
– Spare screws for changing bracket position
Unpacking the Cisco SCE 2000
Tip When you unpack the Cisco SCE 2000, do not discard the shipping container. Flatten the shipping cartons and store
them with the pallet. You may need these containers if you move or ship the Cisco SCE 2000 in the future.
Check the contents of the shipping container:
•Check the contents of the accessories kit against the list of accessories in the “Cisco SCE 2000 Component List” in the Cisco
SCE 2000 Installation and Configuration Guide and the packing slip. Verify that you received all listed equipment, which
should include the following:
– Hardware and software documentation, if ordered
– Optional equipment that you ordered, such as network interface cables, transceivers, or special connectors
Installing the SCE 2000 on a Workbench or Tabletop
You can install the SCE 2000 platform on any flat surface (Figure 1) as long as the surface is large enough for the SCE 2000,
and allows for adequate airflow and ventilation around the sides of the SCE 2000. When installing the SCE 2000 on a
workbench or tabletop or in a rack, ensure that the surface is clean and in a safe location.
Figure 1 Installing the System on a Flat Surface
LINKRX
Cisco SCE 2000
Series
4xGBE
TX
RXMMT
X
LINKRXTX
RXMMTX
LINKRXTX
RXMMTX
LINKRXTX
RXMMTX
GBE-1
SUBLINENET
PWRB ST
A
TUS
PWRA BYP
ASS
10/100/
1000
LINK/
ACTIVE
10/100/
1000
LINK/
ACTIVE
GBE-2
SUBLINE/CASCADENET
AUX
CONSOLE
MNG 2
MNG 1
1
2
92782

4
Step 1 Remove the adhesive strips from the four rubber feet and affix the feet onto the four marked locations on the bottom
panel of the unit
Step 2 Place the SCE 2000 platform on the tabletop or workbench.

5
2 Rack-Mounting the SCE 2000 Chassis
This chapter provides information for rack-mounting the SCE 2000 chassis.
Warning Before you install, operate, or service the system, read the Regulatory Compliance and Safety Information for the
Cisco Service Control Engines (SCE). This guide contains important safety information you should know before
working with the system.
SCE 2000 Mounting Brackets
There are two standard types of equipment racks, and the appropriate brackets for each are provided in the enclosed kit.
•19” rack with front rack posts — the mounting kit includes two mounting brackets as illustrated below:
Figure 2 Mounting Brackets
•19” rack with front and back rack posts — in addition to the mounting brackets illustrated below, the mounting kit includes
two crossrail supports that the unit slides onto.
Figure 3 Crossrail Supports
The SCE 2000 mounts to the two front rack posts with brackets that attach to the front of the SCE 2000. The inside width
between the two posts or mounting strips (left and right) must be at least 17.3 inches (44 cm).
Note Remember to leave a two-inch (5 cm) clearance on both sides of the SCE 2000 and at the rear for adequate airflow for
the inlet and exhaust vents.
210429
210430

6
Attaching Brackets to the SCE 2000
Before installing the SCE 2000 in the rack, you must first install an appropriate rack-mount bracket on each side of the front
of the SCE 2000, as illustrated in the following figures.
Figure 4 Attaching the Mounting Brackets (4-post)
Figure 5 Attaching the Mounting Brackets (2-post)
Before installing the SCE 2000 in the rack, you must first install a rack-mount bracket on each side of the front of the SCE 2000.
To install the rack-mount brackets on the SCE 2000 chassis, complete the following steps:
Step 1 Align the rack-mount bracket to the side of the SCE 2000. Choose the proper bracket for your installation (2-post rack
or 4-post rack) as illustrated in SCE 2000 Mounting Brackets
Step 2 Insert and tighten three screws.
Step 3 Repeat steps 1 and 2 on the other side of the SCE 2000.
If mounting the SCE 2000 in a rack with only two posts, skip to Mounting the System to the Rack, page 8.
If mounting the SCE 2000 in a rack with four posts, proceed to the next step, Installing the Crossrail Supports (Four-post rack
only), page 7.
LINKRX
Cisco SCE 2000
Series
4xGBE
TX
RXMMTX
LINKRXTX
RXMMTX
LINKRXTX
RXMMTX
LINKRXTX
RXMMTX
GBE-1
SUBLINENET
PWRB ST
A
TUS
PWRA BYP
ASS
10/100/
1000
LINK/
ACTIVE
10/100/
1000
LINK/
ACTIVE
GBE-2
SUBLINE/CASCADENET
AUX
CONSOLE
MNG2
MNG1
1 2
92780
LINKRX
Cisco SCE 2000
Series
4xGBE
TX
RXMMTX
LINKRXTX
RXMMTX
LINKRXTX
RXMMTX
LINKRXTX
RXMMTX
GBE-1
SUBLINENET
PWRB ST
A
TUS
PWRA BYP
ASS
10/100/
1000
LINK/
ACTIVE
10/100/
1000
LINK/
ACTIVE
GBE-2
SUBLINE/CASCADENET
AUX
CONSOLE
MNG2
MNG1
1 2
210431

7
Installing the Crossrail Supports (Four-post rack only)
This section provides information for assembling the crossrail supports and attaching them to the rack.
When mounting in a rack with four posts (front and back) the two crossrail supports are mounted one on each side of the rack.
The SCE 2000 then slides into these crossrails, which support the weight of the unit.
Assembling the Crossrail Supports
Step 1 Assemble the two crossrail supports. Use three screws for each crossrail assembly.
Figure 6 Assembling the Slider Brackets
Step 2 Make sure that they are oriented so that both crossrails will support the SCE 2000 when they are attached to the rack.
Attaching the Crossrail Supports to the Rack
Step 1 Align the crossrail supports with the side of the rack, parallel to the floor.
Figure 7 Attaching the Crossrails to the Rack
Step 2 Insert and tighten two screws to the front posts or mounting strips of the rack
Step 3 Insert and tighten two screws to the back posts of the rack.
Step 4 Repeat steps 2 and 3 on the other side of the rack, keeping the brackets flush against the posts and parallel to the
supporting bracket on first side of the rack.
321
92777
321
92778

8
Mounting the System to the Rack
When the appropriate mounting brackets are securely installed, the SCE 2000 can be installed into the rack.
Caution Make sure that the rack brakes are locked or that the rack is otherwise stabilized.
Step 1 Slide the SCE 2000 into the rack, pushing it back until the brackets (installed at the front of the unit) meet the mounting
strips or posts on both sides of the rack.
Figure 8 Sliding the SCE Platform into the Rack
A rack with both front and back posts will have the crossrail supports installed. Slide the SCE 2000 onto these crossrails
and push it all the way back.
LINKRX
CiscoSCE2000
Series
4xGBE
TX
RXMMTX
LINKRXTX
RXMMTX
LINKRXTX
RXMMTX
LINKRXTX
RXMMTX
GBE-1
SUBLINENET
PWRBST
A
TUS
PWRABYP
ASS
10/100/
1000
LINK/
ACTIVE
10/100/
1000
LINK/
ACTIVE
GBE-2
SUBL
INE/CASCADENET
AUX
CONSOLE
MNG2
MNG1
LINKRX
Cisco SCE 2000
Series
4xGBE
TX
RXMMTX
LINKRXTX
RXMMTX
LINKRXTX
RXMMTX
LINKRXTX
RXMMTX
GBE-1
SUBL
INENET
PWRB ST
A
TUS
PWRA BYP
ASS
10/100/
1000
LINK/
ACTIVE
10/100/
1000
LINK/
ACTIVE
GBE-2
SUBLINE/CASCADENET
AUX
CONSOLE
MNG2
MNG1
1 2 3
92781

9
Step 2 While keeping the brackets flush against the posts or mounting strips, align the holes in the brackets with the holes on
the rack or mounting strip. Insert and tighten two appropriate screws to the rack for each bracket.
Figure 9 Securing the SCE Platform to the Rack
Note Since the brackets support the weight of the entire SCE 2000 chassis, be sure to use all four screws to fasten the
two rack-mount brackets to the rack posts.
LINKRX
Cisco SCE 2000
Series
4xGBE
TX
RXMMTX
LINKRXTX
RXMMTX
LINKRXTX
RXMMTX
LINKRXTX
RXMMTX
GBE-1
SUBLINENET
PWRB ST
A
TUS
PWRA BYP
ASS
10/100/
1000
LINK/
ACTIVE
10/100/
1000
LINK/
ACTIVE
GBE-2
SUBLINE/CASCADENET
AUX
CONSOLE
MNG2
MNG1
321
92779

10
3 Connecting Power Supply Units
The SCE 2000 platform is shipped with the power supplies (AC or DC) already installed. This section provides information for
grounding the SCE 2000 platform and connecting the AC or DC power supply units.
Connecting Chassis Ground
Figure 10 Grounding the Unit (AC)
Figure 11 Grounding the Unit (DC)
A grounding kit is provided with each SCE 2000. Use this grounding kit to properly ground the SCE 2000 chassis.
BYPASS 2
IN POWER B OK IN POWER A OK
BYPASS 1
92766
21
BYPASS 2
IN POWER B OK IN POWER A OK
BYPASS 1
210601
21

11
When installing the unit, the chassis ground connection must always be made first and disconnected last.
Step 1 Attach the grounding cable (green and yellow cable) to the chassis grounding connector located on the rear panel of the
SCE 2000, firmly fastening the (enclosed) hex nuts and spring washers with a #¼” hex wrench (refer to the appropriate
figure above for an AC- or DC-powered SCE 2000 platform).
The other side of the grounding cable must be connected to the site equivalent of the AC earth.
Connecting Power
Connecting DC-Input Power Supply Unit
Figure 12 Connecting the DC Power
Warning Before completing any of the following steps, and to prevent short-circuit or shock hazards, ensure that power is
removed from the DC circuit. To ensure that all power to the power supply unit is OFF, locate the circuit breaker
on the panel board that services the DC circuit, switch the circuit breaker to the OFF position, and tape the switch
handle of the circuit breaker in the OFF position.
Warning Wiring should be done by a professional in accordance with state and local electrical codes.
Step 1 Ensure that the DC power line input leads are disconnected from the power source.
Step 2 Using the number 2 Phillips screwdriver, remove the protective plate from the terminal block.
BYPASS 2
IN POWER BO
KIN POWER A OK
BYPASS 1
92769

12
Step 3 Insert one receptacle screw into the hex or loop connector on one power line input, insert the screw with the connector
into the corresponding lead receptacle and tighten the receptacle screw using the number 2 Phillips. Repeat for the
remaining power line input lead.
Note The color coding of the DC-input power supply leads depends on the color coding of the DC power source at your
site. Make certain the lead color coding you choose for the DC-input power supply matches lead color coding used
at the DC power source.
Note Use 12 AWG (2.5 mm) copper wire only with hex or loop connectors. Ring terminals must be UL approved and
suitable for 12 AWG wire.
Step 4 Using the number 2 Phillips screwdriver, securely fasten the protective plate to the terminal block.
Step 5 Connect the DC power line input leads to the DC power source through a fast 10A circuit breaker.
Step 6 Turn the on/off switch to the ON position.
Step 7 Look at the IN and OK LEDs on the power supply unit and the corresponding Power LED on the front panel. If the
DC-input power supply unit is operating properly, these LEDs will be glowing green.
Step 8 Ensure that the power supply is properly aligned and the installation screw is tightened.
Connecting AC-Input Power Supply Unit
Step 1 Plug the AC-input power cable into the AC-input power receptacle on the AC-input power supply.
For AC-input power, we recommend powering the SCE 2000 platform from a 120 VAC, 15A receptacle U.S. (240 VAC,
10A international) at the power source.
Figure 13 Connecting the AC Power
Step 2 Plug the AC power supply cable into the AC power source.
Step 3 Turn the on/off switch to the on position.
Step 4 Look at the IN and OK LEDs on the power supply unit and the corresponding Power LED on the front panel. If the
AC-input power supply unit is operating properly, these LEDs will be glowing green.
Step 5 Ensure that the power supply is properly aligned and the installation screw is tightened.
BYPASS 2
IN POWER B OK IN POWER A OK
BYPASS 1
92765

13
4 Connecting Management Interfaces and Performing Initial System
Configuration
This section explains how to connect the SCE 2000 platform to a local console and how to cable the 10/100/1000 Ethernet
management interface.
Connecting the Local Console
You must first connect the unit to a local console and configure the initial settings for the SCE 2000 to support remote
management.
Make sure that the terminal configuration is as follows:
•9600 baud
•8 data bits
•No Parity
•1 stop bits
•No flow control
The above Cisco SCE 2000 port parameters are fixed and are not configurable.
Step 1 Plug the RS-232 serial cable provided with the Cisco SCE 2000 into the Con port on the front panel of the SCE 2000
(#2 in Figure 14).
Figure 14 Connecting the Local Console to the SCE 2000 CON Port
Step 2 Connect the other end of the serial cable (with an attached DB-9 connector) to the VT100 compatible local (serial)
terminal.
Step 3 Make sure that the Cisco SCE 2000 is powered on and has completed booting (this process may take several minutes).
Step 4 Press Enter several times until the Cisco logo appears on the local terminal and the setup configuration dialog begins.
--- System Configuration Dialog ---
At any point you may enter a question mark ‘?’ followed by ‘Enter’ for help.
Use ctrl-C to abort configuration dialog at any prompt.
Use ctrl-Z to jump to the end of the configuration dialog at any prompt.
Default settings are in square brackets ‘[]’.
Would you like to continue with the System Configuration Dialog? [yes/no]: y
Step 5 Type yand press Enter.
Enters the system configuration dialog.
270976
SCE8000-SCM-E
10/100/
1000
LINK/
ACTIVE
OPTICAL
BYPASS1 CONSOLEPORT1
1
23

14
Setting Up Initial Parameters
Upon initial connection to the local terminal, as described above, the system configuration wizard automatically runs to guide
the user through the entire setup process. The wizard prompts for all necessary parameters, displaying default values, where
applicable. You may accept the default values or define other values.
When the dialog is complete, you may review the new configuration before applying it. The system displays the configuration,
including parameters that were not changed. The system also displays any errors that are detected in the configuration. When
the configuration is satisfactory, you may apply and save the new configuration.
The Setup Command
The following table lists all the parameters included in the initial configuration. It is recommended that you obtain values for
any parameters that you will configure at this time before beginning the setup.
Note For further information regarding any configuration step or specific parameter, refer to the relevant section in the Cisco
SCE 2000 and SCE 1000 Software Configuration Guide.
Table 1 Setup Command Parameters
Parameter Definition
IP address IP address of the SCE 2000.
subnet mask Subnet mask of the SCE 2000.
default gateway Default gateway.
hostname Character string used to identify the SCE 2000. Maximum 20 characters.
admin password Admin level password.
Character string from 4-100 characters beginning with an alpha character.
root password Root level password.
Character string from 4-100 characters beginning with an alpha character.
password encryption status Enable or disable password encryption?
Time Settings
time zone name and offset Standard time zone abbreviation and minutes offset from UTC.
local time and date Current local time and date. Use the format:
00:00:00 1 January 2002
SNTP Configuration
broadcast client status Set the status of the SNTP broadcast client.
If enabled, the SCE will synchronize its local time with updates received
from SNTP broadcast servers.
unicast query interval Interval in seconds between unicast requests for update (64 – 1024)
unicast server IP address IP address of the SNTP unicast server.
DNS Configuration
DNS lookup status Enable or disable IP DNS-based hostname translation.
default domain name Default domain name to be used for completing unqualified host names
IP address IP address of domain name server. (maximum of 3 servers)
TCP port number TCP port number of the RDR-formatter destination
Access Control Lists

15
Access Control List number How many ACLs will be necessary? What IP addresses will be
permitted/denied access for each management interface? You may want
ACLs for the following:
Any IP access
Telnet access
SNMP GET access
SNMP SET access
list entries (maximum 20 per list) IP address, and whether permitted or denied access.
IP access ACL ID number of the ACL controlling IP access.
telnet ACL ID number of the ACL controlling telnet access.
SNMP Configuration
SNMP agent status Enable or disable SNMP management.
GET community names Community strings to allow GET access and associated ACLs (maximum
20).
SET community names Community strings to allow SET access and associated ACLs (maximum
20).
trap managers (maximum 20) Trap manager IP address, community string, and SNMP version.
Authentication Failure trap status Sets the status of the Authentication Failure traps.
enterprise traps status Sets the status of the enterprise traps.
system administrator Name of the system administrator.
Topology Configuration
connection mode Is the SCE 2000 installed using inline topology or receive-only topology
using an optical splitter?
type of deployment Is this a cascade topology, with two SCE 2000 s connected via the cascade
ports? Or is this a single platform topology?
physically connected link
(cascade topology only)
In a cascade deployment this parameter sets the index for the link that this
SCE 2000 is deployed on. The options for SCE 2000 are link-0 or link-1.
In a single- SCE 2000 platform deployment this parameter is not relevant
since one SCE 2000 is deployed on both links. In this case the link
connected to port1-port2 is by default link-0 and the link connected to
port3-port4 is be default link-1.
priority
(cascade topology only)
If this is a cascaded topology, is this SCE 2000 the primary or secondary
SCE 2000?
on-failure behavior
(inline connection mode only)
If this SCE 2000 is deployed inline, should the failure behavior be bypass
or cutoff of the link?
Admin status of the SCE 2000 after abnormal
boot
After a reboot due to a failure, should the SCE 2000 remain in a Failure
status or move to operational status provided no other problem was
detected?
Table 1 Setup Command Parameters (continued)
Parameter Definition

16
Connecting the Management Interface
Figure 15 Cabling the Management Port
Note By default, the management port is configured to auto-negotiation enabled.
The SCE 2000 has two management ports, labeled Mng1 and Mng 2. Use the Mng 1 port.
Step 1 Plug the Ethernet cable provided (with attached RJ-45 connector) into the Mng 1 port on the front panel of the
SCE 2000.
Step 2 Connect the other end of the Ethernet cable into your management network. The Link LED on the SCE 2000
management port lights.
Step 3 Test connectivity. From the host that you intend to use for remote management, ping to the SCE 2000 by typing ping
and the SCE 2000 IP address, and pressing Enter.
This verifies that an active connection exists between the specified station and the management port.
LINK RX
Cisco SCE 2000
Series
4xGBE
TX
RX MM TX
LINK RX TX
RX MM TX
LINK RX TX
RX MM TX
LINK RX TX
RX MM TX
GBE-1
SUB LINE NET
PWRB ST
ATUS
PWRA BYP
ASS
10/100/
1000
LINK/
ACTIVE
10/100/
1000
LINK/
ACTIVE
GBE-2
SUB LINE/CASCADE NET
AUX
CONSOLE
MNG 2
MNG 1
92791
3
21

17
5 Cabling Line Ports
This chapter describes cabling the Gigabit Ethernet ports for both one and two SCE 2000 topologies, and for configuring
Gigabit Ethernet (GBE) interface parameters. In a topology utilizing two SCE 2000s (cascade), this includes the cascade ports
as well as the line ports.
Warning Class 1 laser. Avoid exposure to radiation and do not stare into open aperture.
Note When installing a cascaded system, it is extremely important to follow the sequence of procedures outlined in
“Installing a Cascaded System” section on page 19.
SCE 2000 Connectivity Summary
Table 2 through Table 4 summarize SCE 2000 connectivity for basic topologies.
General Guidelines
•The SCE 2000 can be installed either inline or receive-only.
•Receive-only topologies use only receive fibers.
Note You can implement receive-only topologies using either an optical splitter or a switch. If you use a switch, it must
support SPAN functionality that includes separation between ingress and egress traffic and multiple SPAN-port
destinations.
•Subscriber and Network sides are indicated on the front panel of the SCE 2000.
Table 2 Single Link Connectivity
Port Link
Either GBE-1 or GBE-2 Link 0
Table 3 Dual Link Connectivity
Port Link
GBE-1 Link 0
GBE-2 Link 1
Table 4 Cascade Connectivity
This port on SCE 2000 #1 Connects to this...
GBE-1 Subscriber and network side network elements as indicated on the front panel
GBE-2 SUB (cascade port) GBE-2 NET on SCE 2000 #2
GBE-2 NET (cascade port) GBE-2 SUB on SCE 2000 #2
This port on SCE 2000 #2 Connects to this....
GBE-1 Subscriber and network side network elements as indicated on the front panel
GBE-2 SUB (cascade port) GBE-2 NET on SCE 2000 #1
GBE-2 NET (cascade port) GBE-2 SUB on SCE 2000 #1

18
Note Cascade ports must be connected directly in Layer 1 (dark fibers).
Cabling GBE Line Interface Ports
Warning Class 1 laser. Avoid exposure to radiation and do not stare into open aperture.
The following table presents the fiber specifications. The SCE 2000 may be ordered with either Multimode or Single Mode
transceivers The transceiver type is indicated on the front panel under the ports. Note that both transceivers on any individual
SCE 2000 are the same, either 850nm Multimode OR 1310nm Single Mode.
Step 1 Obtain the appropriate fiber optic cable.
Step 2 Plus the fiber optic cable into the appropriate GBE port on the front panel of the SCE 2000 ().
Figure 16 Cabling the GBE Interface
The Link LED should be green.
SCE Model Transceiver Transmit Power Receive Power Typical (Max.) Distance
SCE 2000 4xGBE MM 850nm
Multimode
–9.5 to –3 dBm –17 to 0 dBm 750m for 50µm Core Diameter MMF
400m for 62.5µm Core Diameter MMF
SCE 2000 4xGBE SM 1310nm FRP laser
Single Mode
–9.5 to –3 dBm –20 to 3 dBm 10 km for 9.0µm Core Diameter SMF
LINK RX
Cisco SCE 2000
Series
4xGBE
TX
RX MM TX
LINK RX TX
RX MM TX
LINK RX TX
RX MM TX
LINK RX TX
RX MM TX
GBE-1
SUB LINE NET
PWRB ST
A
TUS
PWRA BYP
ASS
10/100/
1000
LINK/
ACTIVE
10/100/
1000
LINK/
ACTIVE
GBE-2
SUB LINE/CASCADE NET
AUX
CONSOLE
MNG 2
MNG 1
92783
321 4

19
Configuring GigabitEthernet Auto-Negotiation
By default, the SCE 2000 GBE line interface ports are configured with auto-negotiation disabled.
Note Auto-negotiation must be disabled when the SCE 2000 is deployed using an external optical splitter (receive-only
topology)
Note If you change any parameters, you must save the new configuration settings. Use the copy running-config startup-config
CLI command.
Step 1 At the SCE# prompt, type configure, and press Enter.
Enters the Global Configuration Mode.
Step 2 At the SCE (config)# prompt, type interface GigabitEthernet 0/portnumber, and press Enter.
- where portnumber is the number of the selected port (1-4).
Enters the GigabitEthernet Interface configuration mode for the specified GBE port.
Step 3 Type auto-negotiate and press Enter.
Enables auto-negotiation for the GBE interface.
Step 4 Type exit and press Enter.
Returns to Global Configuration Mode, from which you can enter the GigabitEthernet Interface configuration mode
for the remaining GBE ports.
Step 5 Repeat this procedure to configure auto-negotiation for the other GBE port interfaces.
Installing a Cascaded System
Step 1 Install both SCE 2000s, power them up, and perform the initial system configuration.
Step 2 Connect both SCE 2000s to the management station.
Step 3 Connect the cascade ports (see Table 4). The cascade ports must be connected directly in Layer 1 (dark fibers), not
through switches.
Step 4 Set topology configurations for each SCE 2000 using the connection-mode options.
Step 5 Make sure that the SCE 2000s have synchronized and active SCE 2000 was selected.
Step 6 If you want to start with bypass/sniffing, change the link mode to your required mode in both SCE 2000s on both links.
The bypass mode will be applied only to the active SCE 2000.
Step 7 Connect the traffic port of SCE 2000 #1. This will cause a momentary down time until the network elements from both
sides of the SCE 2000 auto-negotiate with it and start working.
Step 8 Connect the traffic port of SCE 2000 #2, this will cause a momentary down time until the network elements from both
sides of the SCE 2000 auto-negotiate with it and start working.
Step 9 When full control is needed, change the link mode on both SCE 2000s on both links to ‘forwarding’. It is recommended
to first configure the active SCE 2000 and then the standby.
Step 10 You can now start working with the Subscriber Manager.

20
6 Completing the Installation
This module explains how to verify link connectivity and how to install a Cisco service control application.
Examining the LEDs
•The GBE Link LED should be green. This indicates that an active connection exists.
•The GBE RX and TX LEDs (if flashing green) indicate that traffic is being received or transmitted by the SCE 2000 platform,
respectively.
Note In an inline topology, the RX and TX LEDs indicate that packets are being received and transmitted by the SCE
2000 platform.
•In optical splitter topologies, the RX LEDs are the sole indicators. The TX LEDs do not blink, because the TX is not
connected to the port in this topology.
Performing Final Installation Verification
Viewing Gigabit Ethernet Port Status
Step 1 At the SCE> prompt, type show interface GigabitEthernet 0/portnumber.
This displays the port link status.
The following example shows how to display a system response.
SCE>show interface GigabitEthernet 0/1
Auto negotiation configured: Enabled
Actual status:
Link is: ON
Auto negotiation: Enabled
Bandwidth (L1): 1000000 Kbps, Burst-size: 50000 bytes
Pseudo IP Address: Not Configured
physical mode : 0
Monitoring Traffic Using the Gigabit Ethernet Counters
In an inline topology, you can monitor traffic through the platform counters for both the RX and TX connections. As packets
flow through the Cisco SCE 2000 for both RX and TX, the counters increase.
However, in receive-only topologies, the counters for the TX do not increment because the SCE 2000 is only monitoring traffic,
and not re-transmitting traffic.
Step 1 At the SCE> prompt, type show interface GigabitEthernet 0/portnumber counters. The GigabitEthernet counters
appear.
Step 2 Use the output to verify that traffic is taking place. You can see that the counters increase, together with real-time packet
flow through the Cisco SCE 2000.
Remember, in bump-in-the-wire topology, both the RX and TX counters function as traffic monitors. For receive-only
topologies using an external splitter, only the RX counters apply.
