ASA 5505 Getting Started Guide
78-18003-02
4
Installing the ASA 5505
This chapter describes how to install the Cisco ASA 5505 adaptive security
appliance. This chapter includes the following sections:
•Verifying the Package Contents, page 4-1
•PoE Ports and Devices, page 4-3
•Installing the Chassis, page 4-4
•Connecting to Network Interfaces, page 4-4
•Powering on the Cisco ASA 5505, page 4-6
•Setting Up a PC for System Administration, page 4-6
•Optional Procedures, page 4-8
•Ports and LEDs, page 4-9
•What to Do Next, page 4-13
Verifying the Package Contents
Verify the contents of the packing box to ensure that you have received all items necessary to install your
Cisco Cisco ASA 5505 adaptive security appliance, as shown in Figure 4-1.

Chapter 4 Installing the ASA 5505
Verifying the Package Contents
4-2
ASA 5505 Getting Started Guide
78-18003-02
Figure 4-1 Contents of Cisco ASA 5505 Package
Cisco ASA 5505
Getting Started
Guide
Regulatory
Compliance
and Safety
Information
Cisco ASA 5505
Documentation
Cable
(US shown)
Power supply adapter
Blue console cable
Yellow Ethernet cable
Cisco ASA 5505
Firewall
Product CD
Security
Services
Card Slot
1
2
CONSOLE
RESET
POWER
48
VDC
7
POWER over ETHERNET
6
543
210

4-3
ASA 5505 Getting Started Guide
78-18003-02
Chapter 4 Installing the ASA 5505
PoE Ports and Devices
PoE Ports and Devices
On the Cisco ASA 5505, switch ports Ethernet 0/6 and Ethernet 0/7 support PoE
devices that are compliant with the IEEE 802.3af standard, such as IP phones and
wireless access points. If you install a non-PoE device or do not connect to these
switch ports, the adaptive security appliance does not supply power to the ports
and the device must be powered on its own.
These ports are the only ports that can provide power for IP phones or other PoE
devices. However, these ports are not restricted to that use. They can also be used
as Ethernet switch ports, like the Ethernet switch ports numbered 0 through 5. If
a PoE device is not attached, power is not supplied to the port.
When connecting PoE devices, use the following guidelines:
•Use straight-through cable only. Using crossover cable does not enable the
Cisco ASA 5505 to provide power to the PoE ports.
•Do not disable auto-negotiation (force speed and duplex) on E0/6 and E0/7
when using them to connect PoE devices. If auto-negotiation is disabled, the
Cisco ASA 5505 does not recognize that a PoE device is attached. In this
case, power is not provided to the port.
Note Be careful when connecting a Cisco PoE device to a non-PoE switch
port (E0/0 through E0/5). If auto-negotiation is disabled for that
switch port, a network loopback might occur with some Cisco
Powered Device (PD) models.
•The Cisco IP Phone 7970 is always in low-power mode when drawing power
from the Cisco ASA 5505.

Chapter 4 Installing the ASA 5505
Installing the Chassis
4-4
ASA 5505 Getting Started Guide
78-18003-02
Installing the Chassis
You can wall-mount or rack-mount the Cisco ASA 5505. The part number for
ordering a wall-mount kit for the Cisco ASA 5505 is ASA-5505-WALL-MNT= ,
the part number for ordering a rack-mount kit for the Cisco ASA 5505 is
ASA5505-RACK-MNT=. For information on wall-mounting or rack-mounting
the Cisco ASA 5505, see “Mounting the ASA 5505 Chassis” section in the
Cisco ASA 5500 Series Hardware Installation Guide.
To install the Cisco ASA 5505, perform the following steps:
Step 1 Place the chassis on a flat, stable surface.
Step 2 Connect Port 0 to the public network (that is, the Internet):
a. Use a yellow Ethernet cable to connect the device to a switch or hub.
b. Use one of the yellow Ethernet cables to connect the device to a
cable/DSL/ISDN modem.
Note By default, switch port 0 is the outside port.
Step 3 Connect your network devices with an Ethernet cable to one of the remaining
seven switched ports (numbered 1 through 7).
If you are connecting any Power over Ethernet (PoE) devices, connect them to one
of the switch ports that support PoE (ports numbered 6 and 7).
Connecting to Network Interfaces
To connect to a network interface, perform the following steps:
Step 1 Locate an RJ-45 to RJ-45 Ethernet cable.
Step 2 Connect one end of the Ethernet cable to an Ethernet port (ports 0 through 7), as
shown in Figure 4-2. (Typically Ethernet port 0 is used to connect to an Internet
router.)

4-5
ASA 5505 Getting Started Guide
78-18003-02
Chapter 4 Installing the ASA 5505
Connecting to Network Interfaces
Figure 4-2 Connecting to an Ethernet Interface
Step 3 Connect the other end of the Ethernet cable to a device, such as a router, desktop
computer, or printer.
Note When connecting a computer to an inside port on the rear panel of the
adaptive security appliance, use a straight through cable because ports 0
through 5 are switched ports and ports 6 and 7 are PoE ports and both
require that you connect a straight through cable.
1Ethernet switch ports 2Ethernet cable
Security
Services
Card Slot
1
2
POWER
48VDC
7 POWER over ETHERNET 6
5 4 321 0
1
153761
2
Console
RESET

Chapter 4 Installing the ASA 5505
Powering on the Cisco ASA 5505
4-6
ASA 5505 Getting Started Guide
78-18003-02
Powering on the Cisco ASA 5505
To power on the Cisco ASA 5505, perform the following steps:
Step 1 Connect the power supply with the power cable.
Step 2 Connect the small, rectangular connector of the power supply cable to the power
connector on the rear panel.
Step 3 Connect the AC power connector of the power supply input cable to an electrical
outlet.
Note The Cisco ASA 5505 does not have a power switch. Completing Step 3
powers on the device.
Step 4 Check the power LED; if it is solid green, then the device is powered on.
For more information, see the “Front Panel Components” section on page 4-10.
Setting Up a PC for System Administration
You can perform setup, configuration and management tasks from a PC using the
command-line interface or with the Adaptive Security Device Manager (ASDM)
application, which provides an intuitive graphical user interface (GUI).
In addition to configuration and management capability, ASDM also provides
configuration wizards for initial configuration, VPN configuration, and
high-availability configuration.
For more information about using ASDM for setup and configuration, see
Chapter 1, “Configuring the Adaptive Security Appliance.”
To set up a PC from which you can configure and manage the Cisco ASA 5505,
perform the following steps:
Step 1 Make sure that the speed of the PC interface to be connected to one of the Cisco
ASA 5505 inside ports is set to autonegotiate. This setting provides the best
performance.

4-7
ASA 5505 Getting Started Guide
78-18003-02
Chapter 4 Installing the ASA 5505
Setting Up a PC for System Administration
By default, the Cisco ASA 5505 automatically negotiates the inside interface speed.
If autonegotiate is not an option for the PC interface, set the speed to either 10 or
100 Mbps half duplex. Do not set the interface to full duplex; this causes a duplex
mismatch that significantly impacts the total throughput capabilities of the interface.
Step 2 Configure the PC to use DHCP (to receive an IP address automatically from the
Cisco ASA 5505), which enables the PC to communicate with the Cisco ASA
5505 and the Internet as well as to run ASDM for configuration and management
tasks.
Alternatively, you can assign a static IP address to your PC by selecting an address
in the 192.168.1.0 subnet. (Valid addresses are 192.168.1.2 through
192.168.1.254, with a mask of 255.255.255.0 and default route of 192.168.1.1.)
When you connect other devices to any of the inside ports, make sure that they do
not have the same IP address.
Note The MGMT interface of the adaptive security appliance is assigned
192.168.1.1 by default, so this address is unavailable.
Step 3 Use an Ethernet cable to connect the PC to a switched inside port on the rear panel
of the Cisco ASA 5505 (one of the ports numbered 1 through 7).
Step 4 Check the LINK LED to verify that the PC has basic connectivity to the Cisco
ASA 5505.
When connectivity is established, the LINK LED on the front panel of the Cisco
ASA 5505 lights up solid green.
You can now access the ASDM and the ASDM Startup Wizard. See Chapter 1,
“Configuring the Adaptive Security Appliance” for information about how to
perform initial setup and configuration of the Cisco ASA 5505.

Chapter 4 Installing the ASA 5505
Optional Procedures
4-8
ASA 5505 Getting Started Guide
78-18003-02
Optional Procedures
This section describes how to perform tasks that are not required for the initial
setup of the Cisco ASA 5505. This section includes the following topics:
•“Connecting to the Console” section on page 4-8
•“Installing a Cable Lock” section on page 4-9
Connecting to the Console
You can access the command line for administration using the console port on the
Cisco ASA 5505. To do so, you must run a serial terminal emulator on a PC or
workstation, as shown in Figure 4-3.
Figure 4-3 Connecting to the Console
To connect a console for local, command-line administrative access, perform the
following steps:
Security
Services
Card Slot
1
2
Console
RESET
POWER
48
VDC
7 POWER over ETHERNET 6
543210
153760
1
2
1Console port 2Console cable

4-9
ASA 5505 Getting Started Guide
78-18003-02
Chapter 4 Installing the ASA 5505
Ports and LEDs
Step 1 Plug one end (DB9) of the PC terminal adapter into a standard 9-pin PC serial port
on your PC.
Step 2 Plug the other end (RJ-45) of the blue console cable into the console port.
Step 3 Configure the PC terminal emulation software or terminal for 9600 baud, 8 data
bits, no parity, and 1 stop bit.
Installing a Cable Lock
The Cisco ASA 5505 includes a slot that accepts standard desktop cable locks to
provide physical security for small portable equipment, such as a laptop computer.
The cable lock is not included.
To install a cable lock, perform the following steps:
Step 1 Follow the directions from the manufacturer for attaching the other end of the
cable for securing the adaptive security appliance.
Step 2 Attach the cable lock to the lock slot on the back panel of the Cisco ASA 5505.
Ports and LEDs
This section describes the front and rear panels of the ASA 5505. This section
includes the following topics:
•Front Panel Components, page 4-10
•Rear Panel Components, page 4-12

Chapter 4 Installing the ASA 5505
Ports and LEDs
4-10
ASA 5505 Getting Started Guide
78-18003-02
Front Panel Components
The LINK/ACT indicators on the front panel of the Cisco ASA 5505 are normally
solid green when a link is established and flashing green when there is network
activity. Each Ethernet interface (numbered 0 through 7) has two LEDs: one to
indicate the operating speed and the other to indicate whether the physical link is
established.
Figure 4-4 illustrates the front panel of the Cisco ASA 5505.
Figure 4-4 ASA 5505 Front Panel
Port / LED Color State Description
1USB Port — — Reserved for future use.
2Speed Indicators Not lit — Network traffic is flowing at 10
Mbps.
Green On Network traffic is flowing at 100
Mbps.
3Link Activity
Indicators
Green Solid The physical link established.*
Green Flashing There is network activity.
4Power Green On The device is powered on.
Off — The device is powered off.
5Status Green Flashing The power-up diagnostics are
running or the system is booting.
Solid The system is operational.
Amber Solid The system has encountered a
problem.
153382
Cisco ASA 5505 series
Adaptive Security Appliance
0
0 0 0 0 0 0 0 0
LINK/ACT Power Status Active VPN SSC
3
100 MBPS
4 75 6 8
12

4-11
ASA 5505 Getting Started Guide
78-18003-02
Chapter 4 Installing the ASA 5505
Ports and LEDs
* If the LINK/ACT LED does not light up, the link could be down if there is a duplex mismatch.
You can fix the problem by changing the settings either on the Cisco ASA 5505 or on the other
end. If auto-negotiation is disabled (it is enabled by default), you might be using the wrong type
of cable.
6Active Green Solid The system is forwarding traffic.
If the system is part of a high
availability setup, a solid green
light indicates that the link is
forwarding traffic.
Amber Solid The system is on standby.
If the system is part of a high
availability setup, a solid amber
light indicates that this is the
standby unit.
7VPN Green Solid The VPN tunnel is established.
Flashing The system is initiating the VPN
tunnel.
Amber Solid The tunnel failed to initiate.
8SSC — — An SSC card is present in the SSC
slot.
Port / LED Color State Description

Chapter 4 Installing the ASA 5505
Ports and LEDs
4-12
ASA 5505 Getting Started Guide
78-18003-02
Rear Panel Components
Figure 4-5 illustrates the back panel of the Cisco ASA 5505.
Figure 4-5 ASA 5505 Rear Panel
153383
Security
Services
Card Slot
1
2
Console
RESET
power
48
VDC
7 POWER over ETHERNET 6
543210
23
6 5
8 7
14
Port or LED Purpose
1Power connector Attaching the power cord.
2Security service card slot Reserved for future use.
3Serial console port Managing the device using the CLI (command-line interface).
4Lock device Reserved for future use.
5RESET button Reserved for future use.
6Two USB v2.0 ports Reserved for future use.
7Ethernet switch ports 0–7 Layer 2 switch ports that provide flexible VLAN configuration.
Note Ethernet switch ports 6 and 7 also support PoE devices. If
a PoE device is not attached, power is not supplied to the
port and the device must be powered on its own.
8PoE switch ports 6–7 Can be used for PoE devices, that is, devices that can be powered by
the network interface, such as IP phones.
These ports are the only ports that can be used for IP phones or other
PoE devices. However, these ports are not restricted to that use.
They can also be used as Ethernet switch ports, as are the ports
numbered 0 through 5. If a PoE device is not attached, power is not
supplied to the port and the device must be powered on its own.

4-13
ASA 5505 Getting Started Guide
78-18003-02
Chapter 4 Installing the ASA 5505
What to Do Next
What to Do Next
Continue with Chapter 1, “Configuring the Adaptive Security Appliance.”

Chapter 4 Installing the ASA 5505
What to Do Next
4-14
ASA 5505 Getting Started Guide
78-18003-02
