Cisco M190 User manual

Cisco Systems, Inc.
www.cisco.com
Cisco M190 Content Security
Management Appliance 
Quick Start Guide
• Welcome
• Before You Begin
• Plan the Installation
• Document Required Settings
• Install the Appliance in a Rack
• Temporarily Change Your IP Address for Remote Access
• Connect to the Appliance
• Plug In and Power Up the Appliance
• Log In to the Appliance
• Run the System Setup Wizard
• Check for Available Upgrades
• Configure Network Settings
• Additional Configurations
• Where to Go From Here

2
• Cisco Notification Service
Welcome
Thank you for choosing the Cisco M190 Content Security Management
Appliance (Cisco M190).
The Cisco M190 Content Security Management Appliance centralizes reporting
and tracking, management of quarantined email messages, and web security
appliance configuration settings. It also allows automated data backups.
This guide describes the basic steps for setting up your appliance.
Before You Begin
Before you begin the installation, make sure that you have the items you need.
The following items are included with the Cisco M190 Content Security
Management Appliance:
• Rail kit
• Power cords
• Console cable
• A card listing the location of online documentation for your appliance.
You will need to provide the following items yourself:
• Rack cabinet enclosure (if rack-mounting the appliance)
• Phillips-head screwdriver for assembling rails
• 10/100 Gigabit Base-T TCP/IP LAN
• Ethernet cable for connecting the appliance to your network
• Desktop or laptop computer
• Web browser (or SSH and terminal software)
• Network and administrator information for the “Plan the Installation”
section on page 3

3
Plan the Installation
The Cisco M190 appliance is designed to sit within your inner DMZ and
communicate with Cisco C-Series and S-Series appliances in your outer DMZ.
Plan for your network configuration to look something like this:

4
Document Required Settings
Before you begin, write down the following information about your system,
network, and administrator settings.You will need this information when
running the System Setup Wizard.
System Settings
The default password will not work after you
enter this new password.
Your password must contain at least 8
characters, one number, one upper-case letter,
one lower-case letter, and one special
character.)
Network Settings
Email system alerts to:
Time Zone Information:
NTP Server:
Admin Password:
AutoSupport: Enable/Disable
Fully Qualified Appliance Hostname
IP Address (Data Port 1)
Network Mask:
Default Gateway (Router) IP Address:
DNS (Use the Internet’s root DNS servers or
specify your own):
Data Port 2
IP Address:
Network Mask:

5
Install the Appliance in a Rack
Install the Cisco M190 Content Security Management Appliance following the
instructions in the Cisco x90 Series Content Security Appliances Installation and
Maintenance Guide.
Appliance Placement
• Ambient Temperature—To prevent the appliance from overheating, do not
operate it in an area that exceeds an ambient temperature of 104°F (40°C).
• Air Flow—Be sure that there is adequate air flow around the appliance.
• Mechanical Loading—Be sure that the appliance is level and stable to avoid
any hazardous conditions.
Temporarily Change Your IP Address for Remote
Access
To remotely configure the Cisco M190 using the network connection, you must
temporarily change the IP address of your computer. Alternatively, you can use
the serial console to configure the Cisco M190, without changing the IP address.
If you use the serial console, proceed to section below.
Note Make a note of your current IP configuration settings as you will need
to revert to these settings after you finish the configuration.
For Windows
The exact steps depend on your operating system version.
Step 1 Go to the Start menu and choose Control Panel.
Step 2 Click Network and Internet, then Network and Sharing Center.
Step 3 Click the Change adapter settings link.

6
Step 4 Right-click Local Area Connection and choose Properties.
Step 5 Click Internet Protocol Version 4, then choose Properties.
Step 6 Note your current settings.
Step 7 Select Use the Following IP Address.
Step 8 Enter the following changes:
– IP Address: 192.168.42.43
– Subnet Mask: 255.255.255.0
– Default Gateway: 192.168.42.1
Step 9 Click OK and OK again to exit the dialog box.
For Mac
The exact steps depend on your operating system version.
Step 1 Launch the Apple menu and choose System Preferences.
Step 2 Click Network.
Step 3 Click the lock icon to allow changes.
Step 4 Select the network configuration with the green icon. This is your active
connection. Then click Advanced.
Step 5 Click the TCP/IP tab and from Ethernet settings, choose Manually from
the drop-down list.
Step 6 Enter the following changes:
• IP Address: 192.168.42.43
• Subnet Mask: 255.255.255.0
• Router: 192.168.42.1
Step 7 Click OK.

7
Connect to the Appliance
The Cisco M190 appliance has two gigabit network ports: 
Data 1 and Data 2.
For the purposes of setup, connect to Data 1 as your management interface and
configure incoming web traffic or email on the Data 2 interface. These settings
can be changed after the initial installation.
Item Port Description
1Remote
Power Cycle
The port that is used for Remote
Power Cycle (RPC).
2Console The console port that directly
connects a computer to the
appliance.
3Data 1 A Gigabit Ethernet customer data
interface. This port is used as a
management interface.
4Data 2 A Gigabit Ethernet customer data
interface.

8
Plug In and Power Up the Appliance
Plug in the appliance, then power up the appliance by pressing the On/Off
switch on the front panel of the Cisco M190. You must wait 10 minutes for the
system to initialize each time you power up the system.
After the machine powers up, solid green lights on the front of the appliance
indicate that the appliance is operational. The network activity light will be
green but may not be solid.
Caution If turned on quickly after connecting power to the appliance, the
appliance powers up, the fans spin and the LEDs turn on. Within
30-60 seconds, the fans stop and all LEDs turn off. The appliance
powers on 31 seconds later. This behavior is by design to allow the
system firmware and controller to synchronize. 

Wait at least 10 minutes for the system to complete the power up
sequence and the LEDs to turn green. If you turn the power off
before the initialization is complete, the appliance will NOT reach
an operational state and must be returned to Cisco.
Log In to the Appliance
You can log into the Cisco M190 using the web-based interface or the command
line interface.
Web-Based Interface
Step 1 For web browser access via the Ethernet port (see the “Connect to the
Appliance” section on page 7), log in to the Cisco M190 appliance by
entering the following URL in a web browser:
http://192.168.42.42
Step 2 Enter the following login information:
• Username: admin
• Password: ironport

9
Note The hostname parameter is assigned during system setup. Before you
can connect to the web interface using a hostname (http://hostname),
you must add the appliance hostname and IP address to your DNS
server.
Step 3 Click Login.
Command-Line Interface
Step 1 Access the command-line interface locally or remotely:
• To access the CLI locally, set up a terminal to connect to the serial
port using 9600 bits, 8 bits, no parity, 1 stop bit (9600, 8, N, 1) and
flow control set to Hardware. To physically connect the terminal,
see the “Connect to the Appliance” section on page 7).
• To access the CLI remotely, initiate an SSH session to the IP address
192.168.42.42.
Step 2 Log in as admin with the password ironport.
Step 3 At the prompt, run the systemsetup command.
Run the System Setup Wizard
Run the System Setup Wizard to configure basic settings and enable a set of
system defaults. The System Setup Wizard starts automatically when you access
the appliance via the web-based interface (or when you run the systemsetup
command from the command-line interface.)
Step 1 Accept the end user license agreement.
Step 2 Enter system and network information from the “Plan the Installation”
section on page 3.
If you need additional information about the settings, choose Help and
Support > Online Help.

10
Step 3 Review the configuration summary page.
Step 4 Click Install this Configuration.
The appliance may not appear to have accepted your configuration or
be performing the installation. This is because you have changed the IP
address, but the installation is underway.
Step 5 If you temporarily changed the IP address of your computer as
described above, change the IP address settings back to the original
values.
Step 6 Ensure that your laptop and the appliance are connected to the
network.
Step 7 Log in to the appliance again, at the hostname or IP address that you
noted in the “Plan the Installation” section on page 3. Use the username
admin and the new password that you entered in the wizard.
The Cisco M190 Content Security Management Appliance uses a
self-signed certificate that may trigger a warning from your web
browser. You can simply accept the certificate and ignore this warning.
Step 8 Be sure to keep your new administrator password in a safe place.
Check for Available Upgrades
After logging in to the appliance, look at the top of the web browser window for
an upgrade notification (or for a notice in the command-line interface.) If an
upgrade is available, evaluate whether you should install it.
For example, make sure that the new version is compatible with the AsyncOS
versions of managed email and web appliances in your environment.
Details about each release are available in the release notes for that Async OS
version.

11
Configure Network Settings
Verify that your firewall allows your appliance to communicate via the internet
using the following ports:
• DNS: port 53
• SMTP: port 25
• HTTP: port 80
• HTTPS: port 443
• SSH (for the command-line interface): port 22
• NTP: port 123
• FTP: port 21, data port TCP 1024 and higher
Note If you do not open port 443, you cannot download feature keys.
For details, and to open additional ports needed for the functionality you will
use, see firewall information in the online help or user guide for your AsyncOS
release.
Additional Configurations
Congratulations! You can now configure the following unique features of your
Cisco Content Security Management Appliance, as well as other useful
functionality:
• Centralized Email Reporting
• Centralized Message Tracking
• Centralized Quarantine Management
• Centralized Web Reporting and Tracking
• Centralized Configuration Management for Web Security Appliances
• Content Security Management Appliance Data Backups
For details, see the online help on your appliance or the User Guide for your
AsyncOS version.

12
Caution If you need to shut down your appliance for any reason, use the
System Administration > Shutdown/Reboot page to prevent
corruption of your queue and configuration files.
Where to Go From Here
Product Documentation
Cisco Content Security
Management
Appliance
Documentation
http://www.cisco.com/c/en/us/support/
security/content-security-management
-appliance/tsd-products-support-series
-home.html
Links from this page hold release notes, user guides, and
information about hardware and its installation, including:
• Cisco M190 Content Security Management Appliance
Quick Start Guide (This document)
• Cisco x90 Series Content Security Appliances Installation
and Maintenance Guide (Includes technical specifications
and information about LEDs)
• Safety and compliance information
Support
Cisco support
communities for email
and web security
(Includes Content
Security Management
Appliance support)
https://supportforums.cisco.com/com
munity/5756/email-security
https://supportforums.cisco.com/com
munity/5786/web-security
Cisco Support http://www.cisco.com/en/US/support/
tsd_cisco_worldwide_contacts.html

13
Cisco Notification Service
Sign up to receive notifications relevant to your Cisco Content Security
Appliances, such as Security Advisories, Field Notices, End of Sale and End of
Support statements, and information about software updates and known issues.
You can specify options such as notification frequency and types of information
to receive. You should sign up separately for notifications for each product that
you use.
To sign up, visit http://www.cisco.com/cisco/support/notifications.html
A Cisco.com account is required. If you do not have one, register at
https://tools.cisco.com/RPF/register/register.do.
Cisco and the Cisco logo are trademarks or registered trademarks of Cisco and/or its affiliates in the U.S. and other
countries. To view a list of Cisco trademarks, go to this URL: www.cisco.com/go/trademarks. Third-party trademarks
mentioned are the property of their respective owners. The use of the word partner does not imply a partnership
relationship between Cisco and any other company. (1110R)
Any Internet Protocol (IP) addresses used in this document are not intended to be actual addresses. Any examples,
command display output, and figures included in the document are shown for illustrative purposes only. Any use of
actual IP addresses in illustrative content is unintentional and coincidental.
© 2017 Cisco Systems, Inc. All rights reserved.

14
