Quick Start Guide
Cisco SRP500 Series Services Ready Platforms
(SRP520-U Models)
Package Contents
•Cisco SRP520-U Series Services Ready Platform
•RJ-45 Ethernet Cable
•RJ-11 Telephone Cable
•Power Clip and Adapter
•Quick Start Guide
•Product CD

2 Cisco SRP500 Services Ready Platforms Quick Start Guide (SRP520-U Models)
Welcome
Thank you for choosing Cisco SRP500 Series Services Ready Platforms.
The SRP520-U Series are flexible devices that enable small businesses to
connect to high quality data, hosted voice, and security services offered
by service providers.
This guide describes how to physically install the SRP and perform the
initial configuration.
Before You Begin
Minimum Requirements
•Computer running Microsoft Internet Explorer 7.0 or later, or Mozilla
Firefox 3.6. or later.
•Active Internet connection.
•(Optional) Analog phone line.
•(Optional) Telephone handset, fax machine, or PBX line for connecting
to the voice ports.
•Cables
– RJ-45 Ethernet cables (Category 5 or higher) for connecting
computers, WAN and LAN interfaces, phones, or other devices.
– RJ-11 telephone cable for analog line (FXO) and phone (FXS)
connections.
– ADSL splitter, if required by your Service Provider.
•(Optional) Mobile Broadband USB Modem.
1

Cisco SRP500 Services Ready Platforms Quick Start Guide (SRP520-U Models) 3
Default Settings
These are the default settings used when configuring your SRP for the first
time. See Getting Started with Device Configuration, page 12.
NOTE If you obtained your SRP from your Service Provider, you may not
have access to the Administrator account. If this is the case, please
contact your Service Provider for more information.
Getting to Know the Cisco SRP520-U Series
Services Ready Platforms
Model Numbers
Parameter Value
Device IP 192.168.15.1
Username admin
Password admin
DHCP Range 192.168.15.100 to 149
Model Description
SRP521W-U Fast Ethernet WAN
2 Phone (FXS) ports, 1 Line (FXO) port, 1 WAN (10/100) port,
4 LAN (10/100) ports, 1 USB 2.0 port, 802.11b/g/n, and WiFi
Protected Setup (WPS)
SRP526W-U ADSL2+ Annex B (ADSL over ISDN)
2 Phone (FXS) ports, 1 Line (FXO) port, 1 DSL port,
4 LAN (10/100) ports, 1 USB 2.0 port, 802.11b/g/n, and WiFi
Protected Setup (WPS)
SRP527W-U ADSL2+ Annex A/M (ADSL over POTS)
2 Phone (FXS) ports, 1 Line (FXO) port, 1 DSL port,
4 LAN (10/100) ports, 1 USB 2.0 port, 802.11b/g/n, and WiFi
Protected Setup (WPS)
2

4 Cisco SRP500 Services Ready Platforms Quick Start Guide (SRP520-U Models)
Front Panel
SRP521W-U Front Panel
SRP526W-U and SRP527W-U Front Panel
Front Panel Lights
The following table describes the lights on the front panel of the SRP.
These lights are used for monitoring system activity.
Lights Description
POWER/SYS Solid green when the SRP has successfully booted and is
ready to use. Flashes green when the SRP is booting.
LAN ports (1–4) Solid green when a link is established. Flashes green when
there is activity on the LAN port.
WAN port
(SRP521W-U only)
Solid green when an Ethernet link is established. Flashes
green when there is activity on the WAN port.
Phone (FXS) ports
(1–2)
Solid green when the port is connected to a phone or fax
machine and the SRP is able to make and receive calls.
Flashes green when a call is in progress on the port.
DSL CD
(SRP526W-U/527W-U)
Flashes green when a DSL service is detected. Lights solid
green when synchronized.

Cisco SRP500 Services Ready Platforms Quick Start Guide (SRP520-U Models) 5
Back Panel
Network devices are connected to the back panel. The ports on the panel
vary depending on the model.
SRP521W-U Back Panel
DSL Data Flashes green when there is DSL activity on the line.
WLAN Solid green when the radio is powered on and operational.
Flashes green when there is wireless activity on the WLAN
port.
USB port Solid green when the connected USB device is operational.
Flashes green if there is a device failure or unsupported
device.
WPS Solid green when WiFi Protected Setup (WPS) is
operational.
A slow green flash indicates that the setup is in progress. A
fast green flash indicates a setup error.
276375
12VDC
LAN (10/100)WAN (10/100)
21 1234
LINE (FXO)PHONE (FXS)
WAN
Port
On/Off
Switch
12 V DC
power
Line
(FXO)
Port
Phone
(FXS)
Ports
LAN
Ports

6 Cisco SRP500 Services Ready Platforms Quick Start Guide (SRP520-U Models)
SRP526W-U and SRP527W-U Back Panel
Back Panel Descriptions
Feature Description
DSL port
SRP526W-U/SRP527W-U only
Connect to a DSL connection.
Phone (FXS) ports (1–2) Connect directly to an analog telephone, fax machine,
or similar device.
If your analog phone requires a separate bell line, you
may need to connect a ring adapter between the SRP
and your phone so that the phone rings when calls are
presented.
Line (FXO) port Connect to an analog phone line.
WAN (10/100) port
SRP521W-U only
Connect to an Ethernet broadband Internet
connection.
LAN (10/100) ports (1–4) Connect to a wired computer and other network
devices.
Selectable WAN/LAN
(10/100) port
Port can be used as a WAN Ethernet port if the ADSL
interface is disabled. By default the ADSL port is
enabled, allowing this port to be used for LAN
connectivity. See the SRP500 Administration Guide
for further information.
On/Off Switch Powers the SRP on or off.
12V DC power Connect to the provided power adapter.
195211
LAN (10/100)LAN/WAN
21 1234
LINE (FXO)DSL PHONE (FXS)
On/Off
Switch
Line
(FXO)
Port
DSL
Port
Phone
(FXS)
Ports
LAN
Ports
12V DC
Power
Selectable
WAN/LAN
Port

Cisco SRP500 Services Ready Platforms Quick Start Guide (SRP520-U Models) 7
Side View
Feature Description
Reset button Press and hold for 5 seconds to reset the SRP. Press
and hold for 10 seconds to reset the SRP to its factory
defaults.
To press the button, insert a paper clip or similar
object into the opening.
CAUTION This will reset the device to its factory
default settings.
USB port Connect to a compatible USB Modem.
See Installing a Mobile Broadband USB Modem
(Optional), page 13.
WiFi Antenna Adjustable WiFi antenna.
276380
RESET
Reset
Button
USB
Connector
276381
WiFi Antenna

8 Cisco SRP500 Services Ready Platforms Quick Start Guide (SRP520-U Models)
Top View
Installing the SRP500 Services Ready
Platforms
You can install the SRP on a desktop or other flat horizontal surface or
mount it on a wall.
The SRP has an adjustable WiFi antenna located on the side panel of the
unit. If used on a desktop, orient the antenna straight up. If wall mounted,
orient the antenna perpendicular to the floor.
Feature Description
WPS Button Use to automatically configure wireless security for devices
that support WiFi Protected Setup (WPS).
To configure WPS, press and hold this button until the WPS
light flashes. Make sure that the device is located near the
SRP during setup.
276378
WPS Button
3

Cisco SRP500 Services Ready Platforms Quick Start Guide (SRP520-U Models) 9
Placement Tips
Make sure that you install the SRP in a location that meets these
environmental conditions:
•StorageTemperature(sea level) -22° F to 140° F (-30° C to +60° C)
•OperatingTemperature(sea level) 32° F to 104° F (0° C to 40° C)
• Relative Humidity (sea level) 5 to 95% RH (non-condensing)
CAUTION Do not stack or place anything on top of the SRP, or install it on
a hot surface.
Desk Placement
To mount the SRP on a desktop, place the device on a flat surface so it sits
on its four rubber feet.
Wall Mounting
When mounting the SRP horizontally, position it so that the back panel
faces upward. This reduces strain on the cable connections. When
mounting it vertically, position the SRP so the USB ports face downward.
STEP 1Secure two number-six pan-head tapping screws, 3/4-inch (19 mm)
in length, 150 mm apart into a wall for horizontal orientation or
108 mm for vertical orientation, with the space between the
underside of each screw head and the surface of the wall equal to
5/32 inch (4mm).
CAUTION For drywall installation, secure the screws by using two
hollow-wall anchors (1/8 inch with 5/16-inch drill bit, or M3
with 8-mm drill bit). Without proper anchoring, the strain of
the network cable connections could pull the SRP from
the wall.
STEP 2Locate the mounting screw slots on the bottom of the SRP, and
then hang it on the screws.

10 Cisco SRP500 Services Ready Platforms Quick Start Guide (SRP520-U Models)
Connecting the Equipment
STEP 1For Ethernet WAN connections, connect one end of the Ethernet
cable to your Internet access device (typically a modem), and
connect the other end of the cable to the WAN port.
For ADSL connections, connect your DSL cable directly to the DSL
port on your SRP526W-U or SRP527W-U. If required by your
Service Provider, make sure that you use an ADSL splitter.
SRP521W-U Ethernet WAN Connections
SRP526W-U / SRP527W-U ADSL Connections
STEP 2Connect wired computers and other network devices to the LAN
ports (1–4).
STEP 3(Optional) Connect an analog telephone, fax machine, or similar
device to the Phone (FXS) ports. Then connect the Line (FXO) ports
to the telephone line wall socket port(s).
STEP 4Connect the plug adaptor provided for your region to the power
supply. Only use the power adapter that was provided with the
unit.
STEP 5Connect the power adapter to the 12V DC port on your SRP.
4
195790
12VDC
LAN (10/100)WAN (10/100)
21 1234
LINE (FXO)PHONE (FXS)
WAN (10/100) Port
199989
LAN (10/100)LAN/WAN
21 1234
LINE (FXO)DSL PHONE (FXS)
DSL Port

Cisco SRP500 Services Ready Platforms Quick Start Guide (SRP520-U Models) 11
STEP 6Connect the AC power plug into an electrical outlet.
STEP 7Orient the antenna vertically.
STEP 8Press the On/Off switch to the On position.
The POWER/SYS light on the front panel flashes green while the
SRP boots. After booting, the light turns solid green.
The hardware installation is now complete.
Verifying the Hardware Installation
To verify the hardware installation, complete these tasks:
•Check the cable connections.
•Check the lights, as described in Front Panel Lights, page 4. Verify that
the POWER/SYS light is solid green.
If you encounter problems, go to the Cisco Small Business Support
Community website at www.cisco.com/go/smallbizsupport. For technical
documentation and other links, see Where to Go From Here, page 14.
195791
12VDC
LAN (10/100)WAN (10/100)
21 1234
LINE (FXO)PHONE (FXS)
5

12 Cisco SRP500 Services Ready Platforms Quick Start Guide (SRP520-U Models)
Getting Started with Device Configuration
To log in to the Services Ready Platform Configuration Utility, follow these
steps:
STEP 1Configure your computer to use DHCP for its LAN connection.
Using an Ethernet cable, connect your computer to an available
LAN port (1-4) on the SRP. Your computer will automatically obtain
an IP address in the 192.168.15.x range.
STEP 2Open your web browser.
In the address bar, enter the default IP address:
http://192.168.15.1
STEP 3When the login page appears, enter the username and password
(case sensitive).
The default username is admin.
The default password is admin.
NOTE If your SRP was provided by a service provider, they will
provide you with the appropriate login credentials.
STEP 4After you log in, the Services Ready Platform Configuration Utility
opens.
STEP 5From the Main menu, choose Quick Setup > Basic Configuration
Setup to configure the WAN, LAN, Wireless, and Remote
Provisioning settings for your SRP.
For detailed configuration information, click the Help link from the
configuration utility, or see the Cisco SRP500 Series Services
Ready Platforms Administration Guide at:
www.cisco.com/go/srp500resources.
6

Cisco SRP500 Services Ready Platforms Quick Start Guide (SRP520-U Models) 13
Installing a Mobile Broadband USB Modem
(Optional)
Optionally, you can connect a Mobile Broadband USB Modem to your SRP.
Before installing it, make sure that your modem is compatible. See the
Mobile Broadband USB Modem Compatibility Matrix at:
www.cisco.com/go/srp500resources.
NOTE Mobile Broadband USB Modems are for data services only.
STEP 1Make sure that your modem is activated with a data service, and
verify that it can be used on your computer.
STEP 2Connect the modem to the USB port on your SRP.
The modem is fully operational when the USB light turns
solid green.
To check the modem status and modify the settings for the mobile
network, connection recovery, and failover settings, refer to its
product documentation.
7

14 Cisco SRP500 Services Ready Platforms Quick Start Guide (SRP520-U Models)
Where to Go From Here
Support
Cisco Small Business Support
Community
www.cisco.com/go/smallbizsupport
For information about the SRP, click Small
Business Routers from the Community page.
Online Technical Support and
Documentation (Login
Required)
www.cisco.com/support
Cisco Small Business Support
and Resources
www.cisco.com/go/smallbizhelp
Phone Support Contacts www.cisco.com/go/sbsc
Software
Software Downloads
(Login Required)
www.cisco.com/go/srp500
Click the Download Software link.
Open Source Documentation www.cisco.com/en/US/products/ps10500/
prod_release_notes_list.html
Product Documentation
Cisco Services Ready
Platform 500 Series for Small
Business
www.cisco.com/go/srp500resources
Cisco Small Business
Cisco Partner Central for Small
Business (Partner Login
Required)
www.cisco.com/web/partners/sell/smb
Cisco Small Business Home www.cisco.com/smb
Marketplace www.cisco.com/go/marketplace
8

Cisco SRP500 Services Ready Platforms Quick Start Guide (SRP520-U Models) 15

Americas Headquarters
Cisco Systems, Inc.
170 West Tasman Drive
San Jose, CA 95134-1706
USA
www.cisco.com
Small Business Support US: 1-866-606-1866 (Toll Free, 24/7)
Small Business Support, Global: www.cisco.com/go/sbsc
Cisco and the Cisco Logo are trademarks of Cisco Systems, Inc. and/or its affiliates in the U.S.
and other countries. A listing of Cisco's trademarks can be found at www.cisco.com/go/
trademarks. Third party trademarks mentioned are the property of their respective owners.
The use of the word partner does not imply a partnership relationship between Cisco and any
other company. (1005R)
© 2012 Cisco Systems, Inc. All rights reserved.
78-19239-03
