Cisco uBR924 Installation manual

PREPARE FOR INSTALLATION
INSTALL THE ROUTER AND CONNECT CABLES
INITIALIZE THE ROUTER
VERIFY INSTALLATION
RECONFIGURE THE ROUTER
1
2
3
4
5
Quick Start Guide
CISCO UBR924 CABLE ACCESS ROUTER
INSTALLATION AND STARTUP
Cisco uBR924
Telephone
Fax
Machine
PC
PC
Power Adapter
Cable Provider
Internet Service Provider
Internet/IP Network
PC
PC

1
Prepare for Installation
Obtain Tools and Equipment
Items that Cisco Provides
The Cisco uBR924 cable access router is available in
differing bulk box and single packages:
• Bulk box packages include: five Cisco uBR924
cable access routers, five power supplies, five
power cords based on the country of operation,
five 10BaseT Ethernet straight-through cables,
five subscriber documentation sets, and one
service provider documentation set.
• Single packages include: one Cisco uBR924
cable access router, one power supply, one
10BaseT Ethernet straight-through cable, and
one service provider and subscriber
documentationset.Apowercordappropriateto
the country of operation can be purchased
together or separately from the router.
Caution Use only a Cisco-provided power
supply and cord. Using any other vendor’s
power supply and cord can cause loss of
data or permanent damage.
• A cable console kit and console cable can be
purchased separately.
The service provider documentation set includes:
•Regulatory Compliance and Safety Information
for the Cisco uBR924 Cable Access Router
publication.
• Warranty card, release note, and licensing
information.
Two additional hardware-related documents are
available via Cisco Connection Online (CCO):
Cisco uBR924 Cable Access Router Installation and
Configuration Guide and the Quick Start Guide,
Cisco uBR924 Cable Access Router Installation and
Startup—this document.
The subscriber documentation set includes the
Quick Start, Cisco uBR924 Cable Access Router
Subscriber Setup and the Regulatory Compliance
and Safety Information for the Cisco uBR924 Cable
Access Router publication.
Other Items Needed
• High-quality, shieldedRFcoaxialcables(withat
least 80% braid) to connect all Cisco uBR924
cable access routers to your HFC cable plant
• Additional 10BaseT Ethernet cables—
straight-through or crossover—to connect
Cisco uBR924 cable access routers to PCs or
Ethernet hubs as applicable
• FXS voice cables (RJ-11 connectors) and
adapter/connector assembly to connect
telephones or fax devices to the Cisco uBR924
for routers configured to support voice
• Backup POTS cables (RJ-11 connectors) to
connect the Cisco uBR924 cable access router to
astandard,analogPSTN line for subscriber sites
that support this
• 10BaseT Ethernet cable tester, telephone tester
(handset) to check the PSTN line, signal level
meter capable of digital measurements, and a
laptop PC with an RS-232 serial port and
communications software

2
Prepare for Installation (continued)
Verify the Following Before Going to a Subscriber Site:
Item Description
General
Coaxial cable is run from the CATV trunk to the subscriber building or residence.
Note: Cisco recommends that a dedicated (new) CATV cable drop be run from the grounding block
directly to the Cisco uBR924 cable access router. If such a drop is not available, careful qualification of
existing cable is often necessary. Cable ground should be connected to the grounding system of the
building or residence as close to the point of cable entry as practical. For the United States, refer to NEC
section 820-40 guidelines for proper grounding.
The site is characterized from the headend to support upstream transmission and meets DOCSIS upstream
and downstream RF requirements. Follow procedures in the NCTA Recommended Practises for
Measurements on Cable Television Systems.
All required headend routing and network interface equipment is installed, configured, and operational.
This includes all routers, servers (DHCP, TFTP, and TOD), network management systems, and/or other
configuration or billing systems.
DHCP, Cisco IOS images, and DOCSIS configuration files have been created and pushed to appropriate
servers such that each Cisco uBR924 cable access router, when initialized, can transmit a DHCP request,
receive an IP address, obtain TFTP and TOD server addresses, and download a DOCSIS configuration file
(and/or updated software image) in compliance with DOCSIS.
Note: The router’s cable MAC address found on a label at the bottom of the unit ensures each unit
downloads only the file(s) intended for that router.
PCs at each subscriber site meet the minimum computing requirements and that TCP/IP and DHCP
operating modes are enabled. Cisco recommends that the PC have a 486 DX 33 MHz processor minimum
configuration (a 75 MHz Pentium or greater processor is recommended); 16 MB of RAM; Windows for
Workgroups for 486-based PCs and Windows 95 (or higher) for Pentiums; an Internet browser; and a
pre-installed Ethernet Network Interface Card (NIC) with DHCP enabled.
Note: This recommendation is for Internet access in general. Other operating systems and hardware
platforms of comparable capability are also supported.
IP
Telephony
Telephones at each subscriber site support touch-tone dialing; rotary dialing is not supported.Wiring is in
place at subscriber sites supporting multiple telephones and fax devices per VoIP telephone line.
Fax devices—standard Group III and computer-based Group III machines up to 14,400 baud—are
supported in Cisco IOS Release 12.0(5)T or higher.
Note: In general, fax/modem cards are not supported over Voice over IP (VoIP) links. Contact your
network management, provisioning, or operations team to determine what your network supports.
A regular voice grade line and RJ-11 modular jack (USOC code) is installed near the location to install the
router for all sites that support backup PSTN connections.

3
Install the Router and Connect Cables
The Cisco uBR924 cable access router is DOCSIS-based and interoperates with any DOCSIS-qualified CMTS.
TherouterusesCiscoIOSRelease 12.0(4)XI,12.0(5)T,or highersoftware,andsupports manyadvancedrouting
features. The router can be configured to support data, voice, or a mixture of data and voice.
Note: The router ships from the Cisco factory with the console port enabled and a software image that
supports data only. Based on your licensing agreement, you can use Cisco Connection Online (CCO) to
download an image or images that support voice and/or other operating modes. Downloading a Cisco IOS
image disables the console port by default and erases all saved configurations.
Safety Information
Note: Before installing equipment, review the Regulatory Compliance and Safety Information for the
Cisco uBR924 Cable Access Router publication and follow all guidelines. Also refer to the Cisco uBR924
Cable Access Router Installation and Configuration Guide for more in-depth instructions.
Warning Only trained and qualified personnel should be allowed to install or replace this equipment.
Install the Router
Step 1 Place the router on a stable, flat surface close to the CATV drop connection and all devices to be
connected at the subscriber site.
Step 2 Make sure the bottom, sides, and rear of the router are clear and well-ventilated to prevent the unit
from overheating.
17647
Cable TV In Power
Reset
Console
Line
Phone
v1+v2 v2
X
Ethernet 0
XXX
1234
5V 3A
8V 0.65A
40V 7mA
Cisco uBR924
Cable F-connector
Lock
Reset switch
Power receptacle
Ethernet 10BaseT (RJ-45) Console (RJ-45)
Line (RJ-11)
Phone (RJ-11)

4
Install the Router and Connect Cables (continued)
To cable source
17648
Cable TV In Power
Reset
Console
Line
Phone
v1 v2
X
Ethernet 0
XXX
1234
5V 3A
8V 0.65A
40V 7mA
Cisco uBR924
F connector
(Cable TV In)
Step 3 Install the router in compliance with
national and local electrical codes:
• US NFPA 70
• Canadian Electrical Code, part I,
CC22.1
• IEC 364, part 1 through part 7
Warning This product relies on the
building’s installation for short-circuit
(overcurrent) protection. Ensure that a fuse
or circuit breaker no larger than 120 VAC,
15A US (240 VAC, 10A International) is
used on the phase conductors (all
current-carrying conductors).
Note: Therouter usesanexternal ACpowersupply
that allows the unit to operate in any country where
the input voltage is between 100 to 240 VAC, and
50 or 60 Hz. Different power cords are available to
suit the country of operation.
Connect to the Broadband
Network
Step 1 Locate the RF coaxial cable coming from
the CATV wall outlet.
Step 2 Connect the cable to the router’s rear
Cable TV In F connector. Hand tighten
the connector, making sure it is finger
tight; then give it a 1/6 turn.
Warning Do not overtighten the
connector. Overtightening can break off the
connector.

5
Install the Router and Connect Cables (continued)
Cable TV In Power
Reset
Console
Line
Phone
v1+v2 v2
X
Ethernet 0
XXX
1234
5V 3A
8V 0.65A
40V 7mA
Cisco uBR924
To computer
17649
X
Ethernet 0
XXX
1234
Ethernet 10BaseT
(RJ-45)
Ethernet cable
Step 3 Make sure all other coaxial cable
connectorsaresecurelytightenedfromthe
distribution tap to the Cisco uBR924
cable access router, following instructions
in step 2. This includes all intermediate
splitters, couplers, or ground blocks.
Note: Loose connectors inside the building or
residence can cause intermittent router operation.
Caution To ensure compliance with FCC
limits, connection to the cable system must
be made with a high-quality, shielded cable.
If the quality or general condition of the
coaxial cable at the subscriber site is in
question, replace the coaxial cable.
Connect PCs
Step 1 Locate all needed 10BaseT Ethernet
cables.
• Use straight-through Ethernet cables to
directly connect up to four PCs to the
router.
• Use crossover Ethernet cables to
connect the router to an Ethernet hub if
more than four PCs or other LAN
devices are to be connected at the site.
Connect all devices to the hub using
crossover Ethernet cables.
Step 2 Connect one end of the Ethernet cable to
oneof the router’sEthernet hub rear ports
(labeled 1X, 2X, 3X, or 4X).
Step 3 Press the cable end firmly into the router’s
Ethernet receptacle and connect the other
end to the computer or Ethernet hub as
appropriate.
Step 4 Repeat steps 2 and 3 for each Ethernet
connection from the Cisco uBR924
cable access router.

6
Install the Router and Connect Cables (continued)
17652
Cable TV In Power
Reset
Console
Line
Phone
v1+v2 v2
X
Ethernet 0
XXX
1234
5V 3A
8V 0.65A
40V 7mA
Cisco uBR924
Use either port
Connect Telephones or Fax
Devices
Step 1 Locate one RJ-11 to RJ-11 cable for each
device to directly connect to the two FXS
Cisco uBR924 cable access router VoIP
ports if voice is supported.
Step 2 Connect one end of the cable to one of the
Phone ports (labeled V1+V2 and V2) at
the rear of the router. Press the cable
firmly into the receptacle.
Step 3 Connect the other end to the telephone,
fax device, or adapter as appropriate.
Note: Use only a telephone with a pushbutton dial
set. Fax devices and fax/modem cards can be used in
CiscoIOSRelease12.0(5)Tandhigher;however,the
data mode of the fax/modem card cannot. Contact
your network management, provisioning or
operationsteam todetermineif fax/modemcardsare
supported across your VoIP network.
Caution Multiple telephones or fax
devices can be connected to the two VoIP
telephone lines, provided the sum of the
REN of all devices on the line does not
exceed five. A two-line telephone can be
plugged into the V1+V2 rear connector of
the router using a single cable if the cable
has four wires.
Step 4 Repeat steps 2 and 3 for other devices to
connect to the second VoIP telephone line.
Warning Install equipment using an
acceptable method of connection per your
country. This equipment contains a ring
signal generator (ringer), which is a source
of hazardous voltage. Do not touch the
RJ-11 (phone) port wires (conductors), the
conductors of a cable connected to the
RJ-11 port, or the associated circuit board
when the ringer is active.

7
Install the Router and Connect Cables (continued)
Establish Power
Step 1 Locate the power receptacle at the rear of the router.
Step 2 Plug the 7-pin end of the power supply cord into the power connector at the rear of the router and
connect the AC power cord to the power supply.
Caution Use only the Cisco-provided power supply and cord. Using any other vendor’s power supply
and cord can cause permanent damage. Ensure the power cord is appropriate to your country of
operation. Cisco uBR924 and Cisco uBR904 power supplies and cords are identical and
interchangeable, provided the power cords are applicable to the country of operation.
Step 3 Plug the 3-prong end of the power cord into a standard electrical power outlet at the site. Power is
immediately supplied to the router.
Step 4 Turn on the power for all other equipment and wait for the devices to complete their startup
processes.
Cable TV In Power
Reset
Console
Line
Phone
v1+v2 v2
X
Ethernet 0
XXX
1234
5V 3A
8V 0.65A
40V 7mA
Cisco uBR924
Power supply
To AC outlet
17651

8
Install the Router and Connect Cables (continued)
Cable TV In Power
Reset
Console
Line
Phone
v1+v2 v2
X
Ethernet 0
XXX
1234
5V 3A
8V 0.65A
40V 7mA
Cisco uBR924
To RJ-11 phone wall jack
18513
Connect the Backup POTS
Connection
Step 1 Locate the needed minimum 26 AWG
RJ-11to RJ-11cableto connecttherouter
to a backup POTS line.
Note: If the Cisco uBR924 cable access router has
a backup connection to the PSTN and the router
loses power while VoIP calls are in progress, the
subscriber can re-establish one of the two VoIP line
connections—dialing out over the PSTN.
Caution The backup POTS connection
enables only one of the two voice lines
connected to the router to function during a
power outage. Calls in progress prior to the
power outage will be disconnected.
If power is re-established while a cutover
call is in progress, the connection will
remain in place until the call is terminated.
When the cutover call is terminated, the
router automatically reboots.
Warning This equipment is to be installed
andmaintainedbypersonnelonlyas defined
by AS/NZS 3260 Clause 1.2.14.3 Service
Personnel.
Step 2 Connect one end of the cable to the
backup POTS line port (labeled Line) at
the rear of the router. Press the cable
firmly into the receptacle.
Step 3 Connect the other end of the cable to the
telephone wall jack.

9
Initialize the Router
View Initialization
When the router is connected and powered on, it executes automatic self-diagnostic and installation procedures.
For this to occur, a number of actions must be performed at the headend. Refer to the “Prepare for Installation”
section of this guide. The initialization process follows:
• All LEDs on the front of the router light (except for the ACT LED and LEDs 1 through 4) when the router
first powers on.
• Different LEDs light to indicate diagnostic progress and turn off after all checks are successful.
• The OK LED then blinks as the router completes self-test and boots a Cisco IOS image.
• The router, in accordance with DOCSIS, acquires a downstream channel, establishes communications with
the headend, and downloads a configuration file (and an optional updated image if set).
• When the download is complete, the following LEDs light and remain solid to indicate the router is
operational:
—DS LED reveals the router is locked to a downstream channel.
—US LED reveals the upstream channel is operational.
—LINK LED reveals the cable interface is operational.
—DSNR LED reveals the router is receiving a good downstream signal-to-noise ratio.
18216
Cisco uBR900
SERIES
OK ACT
LINK V OK V1 V2
1234 MSG
DS US DSNR
CATV

10
Initialize the Router (continued)
LED
Label Description
OK On = Power-on and self-test have completed successfully, the system image has been booted, and the
system is operational.
Blink = After power-on and self-test have completed successfully, LED blinks as the system image is
booted.
Off = No power
ACT On = Cable activity
Off = No activity
1, 2, 3 or 4 On = Ethernet link up for the port
Blink = Activity on Ethernet link for the port
Off = Ethernet link down for the port
V OK On = Healthy VoIP system for a Cisco uBR924 cable access router configured to support voice
Off = VoIP system problem or the router has switched over to the PSTN
V1 On = Call in progress on the voice port for a router configured to support voice
Off = No call
V2 On = Call in progress on the voice port for a router configured to support voice
Off = No call
LINK On = Cable (RF) connection up
Blink = Router searching for a downstream frequency
Off = Cable (RF) connection down
DS On = Router locked to a downstream frequency
Off = Router not locked to a downstream frequency or the router has not yet located a digital signal
US On = Router has established communications with the CATV headend per DOCSIS
Off = Router has not completed secondary ranging
DSNR On = Receiving quality, downstream signal 5 dB above the downstream lock threshold
Off = Receiving low downstream signal strength or quality

11
Verify Installation
Verify Connections
Internet
Step 1 From a PC connected to the router, start the Internet browser program installed on the PC.
Step 2 In the appropriate area of the web browser screen, enter a URL of your choice.
Note: If a URL is not known, try using http://www.cisco.com.
If the selected web page displays, the Ethernet network installation is successful.
Step 3 Watch the appropriate Ethernet LED (1 through 4) on the front of the router blink as data is
transmitted on the link.
Step 4 Repeat steps 1 through 3 for each PC connected to the router.
VoIP Telephone
Step 1 Pick up a telephone connected to one of the router’s VoIP (V1+V2 or V2) rear ports.
Note: The router must be configured to support voice.
Step 2 Dial a telephone number.
The Cisco uBR924 cable access router is able to implement multiple classes of service (CoS) on the
cable interface.
Note: Separate CoS streams are only available when the router is connected to a headend that supports
multiple classes of service per Cisco uBR924 cable access router. In addition, the configuration file downloaded
to the router must specify use of multiple classes of service.
Caution The Cisco uBR924 cable access router interoperates with a DOCSIS 1.0 CMTS that does not
support multiple classes of service per router. Because voice and data will be mixed, however, voice
traffic will be transmitted on a best effort basis. This can cause poorer voice quality and lower data
throughput when calls are made from the router’s telephone ports.
Voice qualityis also affected by users transmitting or downloading largefiles, as well asother significant
network traffic.

12
Verify Installation (continued)
Step 3 Watch the appropriate VoIP LED (V1 or V2) on the front of the router light when data is transmitted
on the link.
Any call-progress indications and other signals that can be carried inband (for example, remote
telephone ringing) are cut through the voice path as soon as an end-to-end audio channel is up. As
applicable, class reservations are put in place to achieve the desired CoS over the cable interface.
Step 4 Ensure the call is picked up before hanging up.
VoIP Fax
Step 1 Place a document in the document feeder of a fax machine connected to the router, referencing
instructions appropriate to the fax device.
Note: The router must be configured to support voice and you must be using Cisco IOS Release 12.0(5)T or
higher.
Step 2 Enter a destination number to receive the fax and press Dial or Start on most fax machines.
The protocol appropriate to fax is turned on and the fax proceeds. Any call-progress indications and
other signals that can be carried inband (for example, remote telephone ringing) are cut through the
voice path as soon as an end-to-end audio channel is up.
Step 3 Watch the appropriate VoIP LED (V1 or V2) on the front of the router light as data is transmitted on
the link.
Step 4 Listen for a fax tone on the other end and verify that the fax is transmitted.
Step 5 Verify completion of the fax transmission at the destination.

13
Verify Installation (continued)
Troubleshoot Connections
General
LED Status Possible Problem Suggested Action
OK System LED is off. Power cord not properly seated.
Power outlet not operating.
Power supply has failed or you have a
faulty router.
Check power connections.
Check the outlet.
Contact field service dispatch to
replace the power supply or router.
1, 2, 3, or
4Ethernet LEDs are off when data is
transmitted to/from
the device.
PC/device not powered on.
Bad Ethernet connection.
Incorrect cable between the router, the
hub if applicable, or the PC.
Faulty Ethernet card.
Verify PC/device powered on.
Reseat the Ethernet cable at both
ends. Make sure TCP/IP and DHCP
are enabled.
Replace the cable, reviewing the hub
user guide or Ethernet user guide.
Notify the subscriber to replace the
Ethernet card.
LINK Cable RF LED is
off.
Cable RF LED is
blinking.
Router searching for a signal; RF levels
wrong.
Cable is out.
Router is locked to a signal and
connecting to the headend per DOCSIS.
Check for a DOCSIS system signal
and verify the nearby analog video
signal is within the correct range—0
to +15 dBmV for most CATV
systems.
Check if the cable TV is working if
the subscriber also subscribes to
broadcast TV services.
Wait until the router completes
initialization. The router can pause
on a digital video signal during
installation, but will time out and
then locate the DOCSIS system
signal.
DS DownstreamLEDis
off. RF coaxial cable is not properly connected to the router. Reconnect the cable.

14
Verify Installation (continued)
LED Status Possible Problem Suggested Action
US Upstream LED is
off. Upstream signal is not reaching the headend; router is unable to
communicate with the remote end.
Systematic RF noise problem or other
outage.
Verify continuity back to the
headend using the standard
procedures for your system.
Temporarily locate the router closer
to the ground block, the tap, or
another tap closer to the
headend—ensuring correct RF input
levels at all times.
DSNR Downstream
signal-to-noise ratio
LED is off.
Systematic RF noise problem or other
outage. Verify correct RF input to the router. Temporarily locate the router closer
to the ground block, the tap, or
another tap closer to the
headend—ensuring correct RF input
levels at all times.
Do not install the router unless your
system management expressly states
this is the procedure to follow. This
is an early indication of low quality
cable signals and indicates a high
likelihood of intermittent router
operation.

15
Verify Installation (continued)
IP Telephony
Note: The router must be configured to support voice and use Cisco IOS Release 12.0(5)T or higher to support
fax.
LED Status Possible Problem Suggested Action
V OK Voice status LED is
off for a router
configured to
support voice.
VoIP system configuration problem. Contact your provisioning or billing
administrator or customer service
department. If your provisioning or
billing system is designed to support
automatic feature upgrades, and the
router’s cable MAC address is
already in the billing system and
configured for use with voice, ask to
have the router refreshed with the
correct voice configuration.
Note: This procedure can take
several minutes.
V1 or V2 Voice port LED is
off when a call on
the port is initiated
for a router
configured to
support voice.
Bad telephone or fax machine
connection.
Bad cable.
Problem with equipment configuration
Reseat the RJ-11 to RJ-11 cable at
both ends.
Use a different cable.
For a telephone, make sure a
pushbutton dial set is used.
For an external fax machine, make
sure the device is on. If fax software
is used, make sure the data mode is
not used. For fax, also make sure
you are using Cisco IOS Release
12.0(5)T or higher.
If a two-line telephone is connected
to the router, make sure it is
connected to the V1+V2 rear
connector.
If multiple telephones or fax
machines are connected to a
telephone line, make sure the sum of
the REN of all devices on the
telephone line does not exceed five.

16
Reconfigure the Router
Note: Cisco uBR924 cable access routers are typically configured at the headend. Most subscriber sites do not
permit local configuration. Remote configuration is either disabled or routinely reset to settings in the
provisioning or billing systems.
Caution Before attempting to reconfigure a Cisco uBR924 cable access router at a subscriber site,
contact your network management, provisioning, or billing system administrator to ensure remote
configuration is allowed. If remote configuration is disabled, settings you make and save at the local site
will not remain in effect after the router is powered off and on. Instead, settings will return to the
previous configuration.
Connect the Console Port
Step 1 Configure the terminal to support:
• 9600 baud
• 8 data bits
• No parity
• 1 stop bit (8N1)
Step 2 Connect the terminal to the Cisco uBR924 cable access router’s console port.
Note: The console port is configured as DCE and uses an RJ-45 connector. The port is wired the same as all
other Cisco products.
Caution After you connect a laptop to a Cisco uBR924, perform all actions, and save configuration
changes, power cycle the router if that laptop will not be used at the subscriber site. This is particularly
important when the Cisco uBR924 is configured to operate in a DOCSIS-compliant bridging mode.
Power cycling the Cisco uBR924 ensures the laptop computer does not remain in the list of CPE devices
at the subscriber site for the Cisco uBR924 to support. Only reinitialization of the cable interface clears
out the bridge table and resets the counter that specifies the number of CPE devices being bridged. Refer
to the “Basic Internet Access Bridging Example” section of this document.
Note: This behavior is in accordance with DOCSIS. For configurations including Cisco Series 7200 CMTS
equipment, issuing the clear cable modem host <mac address> command may be required to clear the laptop
from the headend security access control tables.

17
Reconfigure the Router (continued)
Understand the Command Line Interface
Note: If you are having trouble entering commands, check the prompt and then enter a question mark (?) for
a list of available commands. You might be in the wrong command mode or using the wrong syntax.
Timesaver Entering exit at the prompt returns you to the previous mode. Entering Ctrl-z immediately
returns you to the enable mode.
View Current Router Configuration
To view the current configuration, enter the show running-config command in the global configuration mode. A
response displays based on the configuration set up for the router. Review the examples that follow.
Note: For descriptions of configuration file settings defined by DOCSIS 1.0, refer to the DOCSIS 1.0 Radio
Frequency (RFI) specifications, section C.3 “Configuration File Settings.”
Command Purpose
uBR924 enable
Password: < password>
uBR924#
Enters enable mode.
Enters the enable password.
You have entered enable mode when
the prompt changes to uBR924#.
uBR924# config terminal
Enter configuration commands, one per line. End with
CNTL/Z.
uBR924(config)#
Enters global configuration mode
and the prompt changes to
uBR924(config)#.
uBR924(config)# ?
interface Select an interface to configure Displays the configuration
commands available for your router.
uBR924(config)# interface ? Displays the interface configuration
commands for your router.
uBR924(config)# interface cable-modem0 Enters the interface configuration
mode for your router.
uBR924(config-if)# cable-modem ? Displays the router interface
parameters you can set.
12
6
93

18
Reconfigure the Router (continued)
Basic Internet Access Bridging Example
A configuration file to support a typical residential, Internet-access (data only) subscriber appears below:
Current configuration:
!
! No configuration change since last restart
!
version 12.0
service config
no service pad
service timestamps debug uptime
service timestamps log uptime
no service password-encryption
!
hostname Router
!
!
clock timezone - 4
ip subnet-zero
no ip routing
!
!
!
!
voice-port 0
!
!
voice-port 1
!
!
interface Ethernet0
ip address 10.1.0.25 255.255.0.0
no ip directed-broadcast
no ip route-cache
bridge-group 59
bridge-group 59 spanning-disabled
!
interface cable-modem0
ip address 10.1.0.25 255.255.0.0
no ip directed-broadcast
no ip route-cache
cable-modem downstream saved channel 477000000 56
bridge-group 59
bridge-group 59 spanning-disabled
!
ip classless
no ip http server
!
