This Feature Module describes the support provided by the Cisco BTS 10200 Softswitch software in
Release 3.2 and 3.3 for ITU-T recommendation T.38 Fax Relay, T.38 Fax Relay is used for transporting
real-time Group 3 Fax documents over the Internet Protocol (IP), commonly used in packet networks.
This feature module includes the following sections:
•Introduction, page 2
– Fax Basics, page 2
– Fax Relay Basics, page 3
– Fax Modes, page 4
•T.38 Benefits, page 4
•External Interfaces, page 7
– Billing Interface, page 7
– Alarms/Events, page 7
– Measurements, page 7
– Provisioning, page 8
•Related Features, page 11
•Supported Platforms, page 11
•Supported Standards, page 12
•Prerequisites, page 13
•Configuration Tasks, page 13
•Command Reference, page 13
•Troubleshooting Fax Relay, page 17
•Glossary, page 24
•Copyright Notice, page 27
Release Modification
900.03.02.00 This feature was initially introduced on the Cisco BTS 10200 Softswitch
in Release 3.2.

Cisco BTS 10200 Softswitch T.38 Fax Relay
Introduction
2
Cisco BTS 10200 Softswitch T.38 Fax Relay Support
Introduction
Most current fax devices are Group 3 compliant. Fax Group 3 is a standards-based technology that
consists primarily of International Telecommunications Union (ITU) T.4 and T.30 recommendations.
ITU T.4 pertains to how the fax image is encoded by a fax device, and ITU T.30 details the facsimile
negotiations and communication protocol. T.30 is the standard procedure for fax transmission in the
public switched telephone network (PSTN).
Group 3 fax devices were originally designed for use in the PSTN; however, the PSTN itself was
designed for human speech (35 Hz to 3,500 Hz), so Group 3 fax devices use analog encoding or
modulated signals. Fax machines are digital devices that use a modulated analog signal (audio tones)
to pass digital information through the PSTN.
Gateways in packet networks initially treat voice and fax calls the same. Both types of calls cause the
gateway to load a pre-configured voice compression codec in the digital signal processor (DSP). Voice
compression codecs are usually high compression codecs, such as G729 and G723, so less bandwidth is
used for voice calls. High compression codecs are optimized for voice and do a good job of conserving
bandwidth while maintaining voice quality. However, G.729 and other high compression codecs are not
optimized for fax transmissions. In fact, modulated fax signals usually do not pass correctly when high
compression codecs are used, and fax calls fail as a result.
Faxes can be transmitted successfully when codecs with lower compression ratios or no compression are
used, such as G.726 and G.711 with no echo cancellation or voice activity detection. This method of
sending faxes through voice codecs is referred to as inband faxing or fax passthrough. The initial analog
modulated signal is encoded and compressed by the codec on the originating gateway and passed across
the packet network as if it were a voice sample. The terminating gateway uncompresses and decodes the
sample and plays it out to the terminating fax machine.
Another technique, known as upspeeding, allows the originating gateway to initially load the configured
voice compression codec into the DSP for voice calls, and changes to a low compression codec if fax
tones are detected.
Fax Basics
Fax calls can be divided into two parts: fax negotiation and page transmission:
•Half-duplex fax negotiation occurs at the beginning of a fax call. V.21 modulated high-level data
link control (HDLC) data frames are passed at a speed of 300 bps. These data frames are sent in a
standard sequence between the originating and terminating fax devices. During this exchange, the
two fax devices exchange capabilities and both agree on the fax session characteristics before page
transmission takes place.
Some capabilities that are exchanged and negotiated are page transmission speed (called “training”),
error correction mode (ECM), resolution, page coding, and scan time. Page transmission speed is
the speed at which the fax is going to send its information. Fax devices always try to “train” at the
highest transmission speed possible based on the parameters initially exchanged. The fax devices
retrain to a lower speed if training fails at a higher speed.
•Page transmission occurs after the training part of the fax negotiation phase is complete using the
previously agreed upon parameters. The page information is coded into scan lines with a standard
resolution of 203 horizontal (H) dots per inch by 98 vertical (V) dots per inch. Fax images are
typically compressed and encoded using Modified Huffman (MH) encoding or Modified Read (MR)
encoding. MH encoding usually compresses fax transmission at a 20:1 ratio. MR encoding typically
provides a 20 percent compression improvement over MH, but is slightly less resistant to error.

Cisco BTS 10200 Softswitch T.38 Fax Relay
Introduction
3
Cisco BTS 10200 Softswitch T.38 Fax Relay Support
When page transmission occurs, a bit rate is used that is substantially higher than the initial 300 bps
used in the call setup negotiation. The bit rate used for the page transmission is confirmed during
training. Following are some of the common rates used in fax page transmission:
– V.27ter – 2400/4800 bps
– V.29 – 7200/9600 bps
– V.17 – 14400 bps
Note The specifications used for page transmission (V.27ter, V.29, V.17) and fax negotiation (V.21) define
how digital data is sent over analog telephone lines in the PSTN. Data modems are also able to use these
specifications even though most data modems have migrated to much faster speeds.
Fax Relay Basics
Fax relay is an important toll-bypass capability that can produce significant cost savings to end users of
packet telephony networks. As more services transition from the PSTN to packet networks, standards
are emerging to ensure interoperability between different vendors’ equipment. Support of ITU-T.38 Fax
Relay in the Cisco BTS 10200 Softswitch is a move toward true voice-data convergence where the end
user can use the same lines for voice and data (fax) in heterogeneous (multi-protocol) networks.
The ITU-T.38 Fax Relay recommendation specifies the messages and data exchanged for facsimile
transmission in real-time between two Group 3 fax terminals communicating over Internet Protocol (IP)
networks based on the H.323 protocol. The fax transmission method prescribed in the ITU T.38
recommendation can best be described as a demodulation/remodulation procedure (demod/remod).
Fax relay is a technique used to overcome the deficiency in high compression voice codecs, such as
G729 or G723, when these codecs try to pass fax traffic. Since a fax call is treated as a regular speech
call, the DSP in each gateway is put into voice mode after which human speech is expected to be received
and processed. If a fax answer tone (CED) or calling tone (CNG) is heard during the call, the DSP does
not interfere with speech processing. It simply allows the tone to continue across the packet network call
leg as if it were a voice transmission.
A fax machine, after generating a CED or hearing a CNG, transmits a T.30 Digital Information Signal
(DIS) as part of fax handshaking. DIS is the initial message stating the capabilities of the terminating
fax machine. The terminating gateway's DSP detects the HDLC flag sequence at the start of the DIS
message and initiates a fax relay switchover. It unloads the high compression voice codec and loads a
lower compression fax codec to run the fax call.
Notification is also sent to the DSP on the other side of the packet network so that both DSPs on the fax
call are using the same fax codec. Notification mechanisms differ depending on the fax relay protocol
used. With the lower compression fax codecs loaded, the DSPs demodulate the T.30 HDLC frames,
extract the fax information, and pass it between the gateways using the standard T.38 fax relay protocol.
It is important to note that unlike inband faxing or fax passthrough, fax relay breaks down (demodulates)
the T.30 fax tones into specific HDLC frames, transmits the information across the packet network using
the T.38 fax relay protocol, then converts (re-modulates) the bits back into tones at the far side. The fax
machines on either end simply send and receive tones; neither terminal is aware that the fax relay process
is occurring or that part of the transmission is over the PSTN and part is over a packet network.
The information that follows can be difficult to understand if you aren't familiar with the messaging that
occurs during a typical fax transmission.

Cisco BTS 10200 Softswitch T.38 Fax Relay
T.38 Benefits
4
Cisco BTS 10200 Softswitch T.38 Fax Relay Support
Fax Modes
Existing H.323-based VoIP networks cannot interoperate with MGCP-controlled media gateways.
Starting in this release, the Cisco BTS 10200 Softswitch software provides a gateway interface that
supports the H.323 protocol. This allows MGCP-controlled gateways to interwork with H.323 VoIP ports.
In the Call Agent (CA)-controlled mode the Cisco BTS 10200 Softswitch can mediate fax control
signaling using T.38 fax relay attributes between two dissimilar gateways; one an MGCP-controlled
gateway, the other an H.323-controlled gateway. The CA drives T.38 media changes through MGCP
command interaction with the gateways involved in the call. This requires that the CA be upgraded with
the functionality provided in this release to support the T.38 media change protocol inherent in the T.38
fax relay feature.
For the CA-controlled mode of operation, the following approach applies:
•The call is initially established as a voice call.
•When a V.21 preamble is detected at the terminating fax machine the CA receives an MGCP NTFY
message:
– if both gateways support T.38, the CA initiates an H.323 Mode Request procedure to switch
both of the media gateways to T.38 fax relay mode for the connection.
To minimize additional delay in switching to T.38, the existing voice port is reused instead of
establishing a new connection through the network. The process of switching from voice to T.38
fax relay includes shutting down RTCP and using the RTP port for the UDP transport of T.38.
– if both gateways do not support T.38, or an attempt to switch modes fails, the connection is lost
and the call is cleared.
•On completion of the fax image transfer, the connection remains established until one of the two
endpoints goes on-hook, then the call is cleared.
The following assumptions are made for the CA-controlled mode of operation:
•When a V.21 preamble is detected, the T.30 protocol is persistent enough to handle the delays added
by the MGCP messaging necessary to accomplish the fax switchover.
•Detection of V.25 ANS or V.8 ANSam indicates the presence of a non-voice call.
A modem call is assumed and an attempt is made to enable modem passthrough. If a V.21 preamble
is then detected on the terminating fax, an attempt is made to enable T.38 processing, provided both
endpoints involved support T.38 fax relay.
Because the T.38 Fax Relay protocol is standards based, Cisco media gateways and gatekeepers can also
interoperate with third-party T.38-enabled gateways and gatekeepers in mixed vendor networks where real
time fax relay capabilities are required.
H.323 is just one of several native signaling protocols supported by the Cisco BTS 10200 Softswitch.
The H.323 interface allows the Cisco BTS 10200 Softswitch to function as a switching platform for
heterogeneous networks. The Cisco BTS 10200 Softswitch can be used without restricting the network
to any single protocol, such as MGCP, SIP, or H.323.
T.38 Benefits
The Call Agent-controlled mode for T.38 fax relay provided in Release 3.3 also offers several benefits:
•Support of sending Empty Capability Set (ECS)—Cisco BTS 10200 Softswitch deployment in
heterogeneous networks mandates that various CA features, like Call Forwarding No Answer
(CFNA), work seamlessly in H.323 networks. Most of these features require that H3A modify the

Cisco BTS 10200 Softswitch T.38 Fax Relay
T.38 Benefits
5
Cisco BTS 10200 Softswitch T.38 Fax Relay Support
connection parameters on the remote H.323 gateway after the logical channels are established. For
modifying the connection parameters, H3A implements a mechanism called “sending Empty
Capability Set (ECS).” In prior releases of the Cisco BTS 10200 Softswitch software, H3A
supported this capability only for IVR applications.
Note Any gateway that requires closure of both logical channels after sending ECS is not
supported by the Cisco BTS 10200 Softswitch.
•Clearing the call once the T.38 fax relay is completed—after the fax image transfer, the
connection remains established until one of the endpoints goes onhook, then the call is cleared.
•Clearing the call if an H245 request mode rejection is received—if an H245 request mode
rejection is received from the remote media gateway, the call is cleared.
•Seamless integration of various features—connection parameters on the remote H.323 gateway
can be modified after the connection is established by sending empty capability set (ECS).
The CA-controlled mode for T.38 fax relay provided by this feature also imposes several restrictions:
•Only partial support of MGCP fax package (fax start, fax stop, fax failure events only).
•No voice fall back is supported—
– when the fax call completes the call is cleared.
– if the T.38 fax invocation fails, the call is cleared.
•CA-controlled mode feature cannot function for H.323-to-H.323 calls transiting the CA.
Capability Negotiation
For the CA-controlled media change, capabilities supported by the gateway are advertised in the SDP
exchange during connection establishment. This provides knowledge early and prevents unnecessary
messaging to switch to a media or voice format that is not supported by both gateways.
During the initial bearer path setup, the Cisco BTS 10200 Softswitch negotiates the T.38 Fax Relay
capabilities of both the originating and terminatinggateways (endpoints).
•If there are no common T.38 Fax Relay capabilities, the inband method is chosen.
•If both sides have more than one capability in common, the common preferred T.38 mode is used.
•If there is a common preferred mode, which is also present among the common capabilities, that
mode is chosen.
•If no common preferred T.38 mode is available, then one of the common T.38 mode capabilities is
chosen.
Since the H.323 stack in the version 3.2 software does not support T.38 capability exchange during
Fast-start information exchanges, the Cisco BTS 10200 Softswitch initiates a Terminal Capability Set
(TCS) procedure to exchange T.38 Fax Relay capabilities along with DTMF capabilities.
MGCP Gateway Capabilities
The Cisco BTS 10200 Softswitch provides default provisioning parameters in the MGW-PROFILE table
for MGCP-controlled media gateways. The MGWs are also provisioned with static capabilities showing
the types of T.38 Fax Relay supported by the MGW.

Cisco BTS 10200 Softswitch T.38 Fax Relay
T.38 Benefits
6
Cisco BTS 10200 Softswitch T.38 Fax Relay Support
The negotiated fax mode is provided in an extension to the LocalConnectionOption (LCO) parameter
of the CRCX message that the CA sends to MGCP-controlled gateways, which allows the CA to give
the gateway up front instructions on how to handle fax for any given connection. This reduces the
number of messages required between the CA and the gateway, which reduces the time to switch to the
T.38 media format.
The syntax of the fx: option is a preferenced list. The possible values for the fx: option are:
•t38—The gateway is to use CA-controlled T.38 media change for fax relay on the connection.
The gateway should use this option if both gateways involved in the connection support T.38.
This is the only mode supported if the gateway needs to interoperate with H.323-based gateways.
•pt—Use the existing MGCP fax passthrough functionality to process the fax transmission. Fax
passthrough is used if T.38 is not supported by both of the involved gateways, but fax passthrough
is. The manner in which fax passthrough functions for MGCP is not altered by this feature.
•off—This option means that no special handling for fax is performed at the MGW. This involves no
upspeeding, no alteration of silence suppression or echo cancellation settings for the connection.
The fax payload is transported using an inband bearer path.
If the CA does not provide an fx: LCO for the connection, the gateway provisioning makes the decision
on the fax transmission method to use, the default being the CA-controlled mode. This setting for fx:
remains in place for the duration of the connection unless explicitly altered by another fx: setting
transmitted to the gateway.
H.323 Network Capabilities
In the absence of dynamic capability exchange, capabilities are provided by current H.323 networks
during the call setup time. Due to protocol complexities, the Cisco BTS 10200 Softswitch currently has
static provisioning per logical H.323 network cloud. They are provisioned in the H.323-TG-PROFILE
table that can be associated with certain H.323-GW (or H.323-endpoint) entries.
Should the Cisco BTS 10200 Softswitch have to provide an interface to H.323 networks that have
H.323 gateways (or endpoints) with different capabilities, multiple H.323-TG-PROFILEs can be
provisioned and all of them can use the same H.323-GW entry.
The only capability of H.323-TG-PROFILE that is currently supported is the T.38 CA-controlled mode.
The H.323-TG-PROFILE can also be provisioned with a preferred mode, the default value being the
CA-controlled mode.
H.323 Adapter Enhancements
The enhancements made to implement T.38 Fax Relay and the “modify connection” feature in the H.323
adapter (H3A) in Release 3.3 include the following:
•Implementation of H.245 request mode procedures (refer to the call flowdiagram, Figure 1).
•Handling of the ModifyCx command from the basic call module (BCM) when the channels are already
established required implementation of the H.245 sending Empty Capability Set (ECS) messages.
•State machine changes required in H3A for H.245 OLC/CAPs for T.38 fax relay and sending ECS
messages.
•Implementation of the pass through media case for H.323 to H.323 calls, where any H.245 message
results in “media/connection pass through” messages on the other H.323 side.
•Addition of new fields in existing data structures, specifically the new parameters added to the
H323_TRUNK_GRP_PROFILE table.

Cisco BTS 10200 Softswitch T.38 Fax Relay
External Interfaces
7
Cisco BTS 10200 Softswitch T.38 Fax Relay Support
External Interfaces
This section contains information about the external operational, management, and administrative
interfaces for the T.38 Fax Relay feature, which include the following:
•Billing Interface
•Alarms/Events
•Measurements
•Provisioning
Billing Interface
Three new fields have been added to the Call Data Blocks (CDBs) to support the T.38 fax relay feature:
•Fax Indicator—The value of this indicator is dependent on whether or not the call involved any fax
transmissions. This indicator can have one of the following values:
– Not Fax = 1
– Fax Only = 2
– Vo i c e & F a x = 3
Not Fax (1) indicates that no fax transmissions occurred, the other two values (2 or 3) indicate that
faxes were sent or received. If faxes were sent, the number of pages is indicated by the next field.
If faxes were received, the number of pages is indicated by the third field.
•Fax Pages Sent—The number of fax pages that were sent during this call (0 through 999).
•Fax Pages Received—The number of fax pages that were received during this call (0 through 999).
Alarms/Events
Table 1 details the alarms and events that can be generated by the T.38 Fax Relay feature.
For detailed information about Cisco BTS 10200 Softswitch alarms and events refer to the
Cisco BTS 10200 Softswitch Event Messages Reference.
Measurements
Table 2 lists the T.38 specific traffic counter values reported by the Cisco BTS 10200 Softswitch.
For detailed information about Cisco BTS 10200 Softswitch measurements refer to the Cisco BTS 10200
Softswitch Operations Guide.
Table 1 T.38 Fax Relay Alarms and Events
Alarm or Event
FAX_T38_START
FAX_T38_STOP
FAX_FAILURE

Cisco BTS 10200 Softswitch T.38 Fax Relay
External Interfaces
8
Cisco BTS 10200 Softswitch T.38 Fax Relay Support
Provisioning
This section describes provisioning changes that resulted from the addition of the T.38 Fax Relay feature
to the Cisco BTS 10200 Softswitch software. For more information on provisioning commands, refer to
the “Command Reference” section on page 13.
H323_GW—This table defines the capabilities of each H.323 protocol gateway. The parameters added
for T.38 fax relay include:
•FAX-RELAY-CAP—the T38 fax relay option for this gateway. The value is one of the following:
– T38_CA_FAX—CA-controlled fax mode. This is the default value.
– INBAND—Inband fax mode.
H323_TRUNK_GRP_PROFILE—This table is responsible for providing information that is used on
a per-call basis for any H.323 trunk group. The parameters added for T.38 fax relay include:
•FAX_T38_CAMODE_SUPP—if set to "Y." CA-controlled mode is supported for T38 fax relay
•FAX_INBAND_SUPP—if set to "Y," the inband mode is supported for T38 fax relay
•FAX_PREF_MODE—this is the preferred mode for T38 fax relay. The value is one of the following:
– FAX_T38_CAMODE—CA-controlled mode is the preferred mode (This is the default value.)
– FAX_INBAND—Inband mode is the preferred mode
MGW_PROFILE—This table provides templates for defining a Media Gateway by hardware vendor.
It identifies the specifications and settings necessary for communications between the Call Agent and
each type of Media Gateway. The parameters added for T.38 fax relay include:
•FAX_T38_CAMODE_SUPP—if set to "Y" (the default value), the CA-controlled mode is
supported for T38 fax relay
•FAX_INBAND_SUPP—if set to "Y" (the default value), the inband mode is supported for
T38 fax relay
•FAX_PREF_MODE—this is the preferred mode for T38 fax relay. The value is one of the following:
– FAX_T38_CAMODE—CA-controlled mode is the preferred mode (This is the default value.)
– FAX_INBAND—Inband mode is the preferred mode
Table 2 T.38 Fax Relay Traffic Counters
Measurement Name Measurement Description
FAX_PAGES_SENT Number of fax pages sent.
FAX_PAGES_RECV Number of fax pages received.

Cisco BTS 10200 Softswitch T.38 Fax Relay
External Interfaces
9
Cisco BTS 10200 Softswitch T.38 Fax Relay Support
Call Flow
The following call flow diagram (Figure 1) illustrates the interactions between the Cisco BTS 10200
Softswitch software modules for the CA-controlled T.38 Fax Relay implementation.
Figure 1 CA-Controlled T.38 Fax Relay
SAI CCM OOBINFO RE
Q
MGA
BCM
H3A
RTP Cut thru (H323 fast start)
N
TFY (fxr / t38(start))
Service feature Ind
(
fax-start
)
H245 Re
q
uest mode
(
t38
)
CNM API
RemoteModifyCL_ex (in active)
MDCX (inactive)
CNM API
RemoteModifyCL_ex (send recv, t.38
SDP)
MD
C
X
(
L
:
a:
im
age/t38,
Se
n
d
R
ecv
ACK/NACK
CNM API
p
repareResponse (ACK/NACK)
Fax transmission starts
N
TFY (fxr / t38(stop))
Service feature Ind
(
fax-sto
p)
Service feature Re
q(
fax-sto
p)
RQNT (fxr / t38())
Normal Call release
CRCX(PCMU, t38)
CNM API
EstablishCx_ex (PCMU, T38 )
Service feature Re
q(
fax-start
)
ÍÎ Fax information exchange

Cisco BTS 10200 Softswitch T.38 Fax Relay
External Interfaces
10
Cisco BTS 10200 Softswitch T.38 Fax Relay Support
The following steps describe in detail the T.38 Fax Relay functionality:
Step 1 The BCM checks the gateway profiles for their T.38 fax relay capabilites. It selects a common/preferred
capability supported by both the gateways.
Prior to establishing a connection, the BCM encodes the T.38 fax Local Connection Option (LCO) in the
SAI_CreateCxData_t . The t38fax LCO information is transmitted by the MGA in the CRCX.
Step 2 The BCM performs a check to ensure that the gateways are, in fact, MGA and H3A. The BCM initiates
an RQNT to the gateway by sending SAI_CCM_OOBINFO_REQ.
Based on these additional attributes in the RQNT, the MGA determines whether it can allow T.38 fax
calls. In order to detect whether T.38 fax calls are supported on the H3A, the BCM checks the trunk
group profile. In addition, the BCM checks the MGA static profile to ensure T.38fax is supported.
Step 3 The gateway detects fax transmission. It notifies the originating Signaling Adapter of the reception of
fax information. The Signaling Adapter in turn informs the BCM about the fax-start event in the
SAI_CCM_SVCFEATURE_IND primitive.
Step 4 The BCM upon reception of the SAI_CCM_SVCFEATURE_IND primitive looks for the
SAI_EI_FAX_START event. Then BCM checks to make sure that the passive_leg is in the
LEG_JOINED state; the remote BCSM state machine is in the active state. It then relays the T.38fax
information to the remote Signaling Adapter in the SAI_CCM_SVCFEATURE_REQ primitive. In the
case, where the passive_leg is not in the LEG_JOINED state, a FAX_FAILURE event is sent in the
SAI_CCM_SVCFEATURE_REQ towards the gateway.
Note Since T.38 fax is handled only in the ACTIVE state, the passive legs are in the LEG_JOINED
state and a valid bcsm_id exists for the remote end.
Step 5 The Signaling Adapter upon receipt of the T.38 fax_start information, invokes the CNM API
RemoteModifyCL_ex inorder to initiate a ModifyConnection request to the other Signaling Adapter
with the new SDP information. Two consecutive RemoteModifyCL_ex is sent to the peer Signaling
Adapter; one of them initiates the MDCX in the inactive mode while the other initiates an MDCX with
modified codec.
Step 6 The Signaling Adapter's CNM upon receipt of the RemoteModifyCL_ex from the remote CNM modifies
the SDP information. The codec information is also modified.The ACK/NACK that is received from the
originating gateway is then sent all the way back to the CNM of the terminating Signaling Adapter. This
is accomplished by retaining a copy of the remote Signaling Adapters identification.
Step 7 The gateway detects an end of fax and transmits it to the other Signaling Adapter. The Signaling Adapter
in turn transmits the fax stop information in the SAI_CCM_SVCFEATURE_IND primitive to the BCM.
Step 8 The BCM upon reception of the SAI_CCM_SVCFEATURE_IND primitive looks for the
SAI_EI_FAX_STOP event. It then relays the fax information to the other Signaling Adapter in the
SAI_CCM_SVCFEATURE_REQ. Following this, the call is cleared in a normal manner upon the receipt
of SAI_REL_IND from the H3A.

Cisco BTS 10200 Softswitch T.38 Fax Relay
Related Features
11
Cisco BTS 10200 Softswitch T.38 Fax Relay Support
Related Features
The T.38 Fax Relay feature is directly related to the H.323 features introduced in Release 3.1 and 3.2.
Note For more information on the H.323 features, refer to the Cisco BTS 10200 Softswitch System Description.
Related Documents
This Release 3.2 T.38 Fax Relay Feature Module should be used in conjunction with the following
Cisco BTS 10200 Softswitch Release 3.1 and 3.2 documents:
•Cisco BTS 10200 Softswitch Physical and Network Site Surveys and Data Sheets
•Cisco BTS 10200 Softswitch Cabling Procedures
•Cisco BTS 10200 Softswitch Release Notes for Release 3.2
•Cisco BTS 10200 Softswitch System Description
•Cisco BTS 10200 Softswitch Application Installation Procedures
•Cisco BTS 10200 Softswitch Command Line Interface Reference Guide
•Cisco BTS 10200 Softswitch CORBA Installation and Programmer's Guides
•Cisco BTS 10200 Softswitch Operations Manual
•Cisco BTS 10200 Softswitch Billing Interface Guide
Supported Platforms
The T.38 Fax Relay features provided in Release 3.3 of the Cisco BTS 10200 Softswitch are available
on a wide variety of Cisco platforms, including the following:
•Cisco AS5300
•Cisco AS5350
•Cisco AS5400
•Cisco AS5800
•Cisco AS5850
Note Not all features provided in Releases 3.2 and 3.3 are available on all Cisco platforms. Consult the Cisco
Feature Navigator web site (http://www.cisco.com/go/fn) to determine what platforms and IOS software
images can accommodate the Cisco BTS 10200 Softswitch features that you require.

Cisco BTS 10200 Softswitch T.38 Fax Relay
Supported Standards
12
Cisco BTS 10200 Softswitch T.38 Fax Relay Support
Determining Platform Support Through Cisco Feature Navigator
Cisco IOS software is packaged in feature sets that support specific platforms. To get updated
information regarding platform support for this feature, access Cisco Feature Navigator. Cisco Feature
Navigator dynamically updates the list of supported platforms as new platform support is added for the
feature.
Cisco Feature Navigator is a web-based tool that enables you to determine which Cisco IOS software
images support a specific set of features and which features are supported in a specific Cisco IOS image.
You can search by feature or release. Under the release section, you can compare releases side by side
to display both the features unique to each software release and the features in common.
To access Cisco Feature Navigator, you must have an account on Cisco.com. If you have forgotten or
lost your account information, send a blank e-mail to [email protected]. An automatic check
verifies that your e-mail address is registered with Cisco.com. If the check is successful, account details
with a new random password is e-mailed to you. Qualified users can establish an account on Cisco.com
by following the directions at http://www.cisco.com/register.
Cisco Feature Navigator is updated regularly when major Cisco IOS software releases and technology
releases occur. For the most current information, go to the Cisco Feature Navigator home page at the
following URL:
http://www.cisco.com/go/fn
Availability of Cisco IOS Software Images for Media Gateways
Support for the features available in the Cisco BTS 10200 Softswitch Release 3.3 software is dependent
on the availability of the appropriate Cisco IOS software images for the supported platforms (media
gateways). IOS software images for some Cisco platforms may be deferred, delayed, or changed without
notice. For updated information about platform support and availability of software images for each
Cisco IOS software release, refer to the online release notes or, if supported, Cisco Feature Navigator.
Supported Standards
The T.38 Fax Relay feature is compliant with the following ITU standards:
Standards
•ITU-T.4 Standardization of Group 3 facsimile terminals for document transmission
•ITU-T.30 Procedures for document facsimile transmission in the general switched telephone
network
•ITU-T.38 Procedures for real-time Group 3 facsimile communication over IP networks
The T.38 Fax Relay feature utilizes the following Management Interface Bases (MIBs):
MIBs
•SNMP MIB v2c
To obtain lists of supported MIBs by platform and Cisco IOS release, and to download MIB modules,
go to the Cisco MIB website on Cisco.com at the following URL:
http://www.cisco.com/public/sw-center/netmgmt/cmtk/mibs.shtml
RFCs
•(to be determined)

Cisco BTS 10200 Softswitch T.38 Fax Relay
Prerequisites
13
Cisco BTS 10200 Softswitch T.38 Fax Relay Support
Prerequisites
The T.38 Fax Relay feature requires that the following prerequisites be completed prior to sending or
receiving fax transmissions:
•(to be supplied)
Configuration Tasks
The T.38 Fax Relay feature requires that the following configuration tasks be completed prior to sending
or receiving fax transmissions. Each task in the list is identified as either required or optional.
•Configure the H.323 Gateway
•Configure the H.323 Trunk Group profile
•Configure the Media Gateway profile
See the “Command Reference” section for configuration examples.
Command Reference
This section documents new or modified Cisco BTS 10200 Softswitch commands associated with the
T.38 Fax Relay feature. All other commands used with this feature are documented in the Cisco BTS
10200 Softswitch Release 3.2/3.3 Command Reference Guide or in the Cisco user documentation for the
gateway(s) you are using.
New Commands
There are no new commands associated with the T.38 Fax Relay feature.
Modified Commands
This section documents modified commands associated with the T.38 Fax Relay feature.
H.323 Gateway
The H.323 Gateway (h323-gw) table defines the capabilities of each H.323 protocol gateway. There can
be four instances of an H.323 gateway running on the Call Agent at any one time.
Table Name: H323-GW
Table Containment Area: Call Agent
Command Types Show, add, change, and delete
Examples •show h323-gw id=[e-mail];
•add h323-gw [email protected]; fax-relay-cap=t38-ca-fax;

Cisco BTS 10200 Softswitch T.38 Fax Relay
H.323 Gateway
14
Cisco BTS 10200 Softswitch T.38 Fax Relay Support
•change h323-gw id=[email protected]m; fax-relay-cap=t38-ca-fax;
•delete h323-gw id=gw[email protected]om;
Usage Guidelines Primary Key Token(s): id;
Add Rule: status=OOS
Change Rule: status=OOS
Delete Rules: FK constraints, status must be OOS.
Token Properties Table 3 lists the token properties that were added to this command for T.38 Fax Relay.
Table 3 T.38 Fax Relay Tokens
Token Values
FAX-RELAY-CAP
Specifies FAX Relay
Option for this gateway.
INBAND—Possible only for G.711 and G.726, supported by MGX 8260.
T38-CA-FAX—CA-controlled issuing RequestMode relay in real time.
This is the default value.

Cisco BTS 10200 Softswitch T.38 Fax Relay
H.323 Trunk Group Profile
15
Cisco BTS 10200 Softswitch T.38 Fax Relay Support
H.323 Trunk Group Profile
The H.323 Trunk Group Profile (h323-tg-profile) table defines the characteristics of each H.323 trunk.
A h323-tg-profile id must be created in this table before H.323 trunk group entries can be added.
Table Name: H323-TG-PROFILE
Table Containment Area: Call Agent
Command Types Show, add, change, and delete
Examples •show h323-tg-profile id[email protected]m
•add h323-tg-profile id= ras-tg; ras=n;
•change h323-tg-profile id= ras-tg; ras=y;
•delete h323-tg-profile id= ras-tg;
Usage Guidelines Primary Key Token(s): id
Add Rules: FK constraints.
•If fax-pref-mode=FAX-T38-CAMODE, then fax-t38-camode-supp=Y;
•If fax-pref-mode=FAX-INBAND, then fax-inband-supp=Y;
Change Rules: FK constraints.
Delete Rules: FK constraints.
Token Properties Table 3 lists the token properties that were added to this command for T.38 Fax Relay.
Table 4 T.38 Fax Relay Tokens
Token Values
FAX-T38-CAMODE-SUPP
CA-controlled T.38 fax relay in
real time (CA instructs GW
when to switch to T.38 mode).
Y/N (Default = Y)
FAX-INBAND-SUPP Y/N (Default = N)
FAX-PREF-MODE
Designates preferred mode of
T.38 fax relay for this gateway.
FAX-T38-CAMODE—This is the default value.
FAX-INBAND—Possible only for G.711 and G.726. supported by
MGX 8260.

Cisco BTS 10200 Softswitch T.38 Fax Relay
Media Gateway Profile
16
Cisco BTS 10200 Softswitch T.38 Fax Relay Support
Media Gateway Profile
The Media Gateway Profile (mgw-profile) table provides templates for defining a Media Gateway by
hardware vendor. It identifies the specifications and settings necessary for communications between the
Call Agent and each type of Media Gateway. An ID must be created in this table before entries can be
added to the Media Gateway table.
Several tokens have values that can be overwritten after the Call Agent queries the Media Gateway for
supported capabilities. If the Media Gateway returns a value different from the value originally
provisioned, the returned value automatically replaces the originally provisioned value.
Table Name: MGW-PROFILE
Table Containment Area: Call Agent
Command Types Show, add, change, and delete
Examples •show h323-mgw-profile id=resgw2000;
•add h323-mgw-profile id= resgw2000; fax-inband-supp=N; fax-pref-mode=fax-t38-camode
•change h323-mgw-profile id= resgw2000; fax-inband-supp=N;
•delete h323-wgw-profile id= resgw2000;
Usage Guidelines Primary Key Token(s): id
Add Rules:
•If fax-pref-mode=FAX-T38-CAMODE, then fax-t38-camode-supp=Y;
•If fax-pref-mode=FAX-INBAND, then fax-inband-supp=Y;
Change Rules: none
Delete Rules: id does not exist in any mgw::mgw-profile-id.
Token Properties Table 3 lists the token properties that were added to this command for T.38 Fax Relay.
Table 5 T.38 Fax Relay Tokens
Token Values
FAX-T38-CAMODE-SUPP
CA-controlled T.38 fax relay in
real time (CA instructs GW
when to switch to T.38 mode).
Y/N (Default = Y)
FAX-INBAND-SUPP
Specifies whether inband mode
of fax relay is supported.
Y/N (Default = Y)
FAX-PREF-MODE
Designates preferred mode of
T.38 fax relay for this gateway.
FAX-T38-CAMODE—This is the default value.
FAX-INBAND—Possible only for G.711 and G.726,
supported by MGX 8260.

Cisco BTS 10200 Softswitch T.38 Fax Relay
Troubleshooting Fax Relay
17
Cisco BTS 10200 Softswitch T.38 Fax Relay Support
Troubleshooting Fax Relay
The purpose of this section is to provide basic troubleshooting procedures for anyone trying to resolve
Cisco BTS 10200 Softswitch T.38 fax relay issues. The technical intricacies of faxing and fax relay are
not covered in detail, but you will get a basic understanding and be able to perform troubleshooting for
a majority of common fax relay issues.
It is important to know the following information:
•Phase in which the fax transmission error occurred.
•Whether the gateways or fax machines terminated the connection, and if it was a fax machine, which
one.
•What fax protocol events took place prior to the connection being terminated.
The following steps have been shown to resolve the majority of issues involving T.38 fax relay over
packet networks.
Step 1 Identify and isolate the problem.
The first step to take when you troubleshoot any fax relay issue is to reduce the problem to its simplest
form. Many issues arise in situations where multiple fax machines are not able to pass fax traffic. It is
easier to isolate two fax machines that are having problems and concentrate on a simple topology. First,
determine how these two machines are connected to one another and resolve the issue between this pair.
In addition, you should draw a complete picture of the network topology and determine how all the fax
machines are interconnected.
Troubleshooting one issue at a time minimizes confusion and allows for methodical troubleshooting.
It is also possible that the solution for this problem will resolve other fax relay problems in the network.
Most fax relay problems result from poor packet network configuration or network design. These lead
to basic connectivity problems and physical line or packet loss and jitter problems.
After you have identified and isolated the problem, the next steps relate to verifying the basic voice over
packet network configuration and monitoring the health of the network.
Step 2 Check basic network connectivity.
Basic fax connectivity issues can be the result of the following factors:
•Normal voice connectivity problems—Confirm that normal voice calls can be completed before
investigating fax connectivity. If there is no telephone attached to the fax machine, unplug it and
connect a regular telephone. If normal voice calls do not connect, the issue may be network-related
and you should troubleshoot the problem as a connectivity issue before fax troubleshooting.
•Configuration problems related to dial peers, such as:
– Wrong dial peer being matched—
After ensuring that voice calls can be successfully completed in both directions through the
network, issue the show call active voice brief command and note the dial peers that are being
matched with each voice call.
When you have VoIP trunks, you should be able to see all the call legs with the show call active
voice brief command. Ensure that the configured dial peer is the peer that is being matched.
A common cause of fax relay problems is that the correctly configured dial peer is not the one
being matched. It is also common that there is no particular incoming VoIP dial-peer configured
on the terminating gateway and the Cisco IOS software selects the first appropriate (including
default) VoIP dial peer as the incoming dial peer. Hence the parameters for this incoming dial
peer may not match those of the outbound dial peer on the originating gateway.

Cisco BTS 10200 Softswitch T.38 Fax Relay
Troubleshooting Fax Relay
18
Cisco BTS 10200 Softswitch T.38 Fax Relay Support
It is not always required that you have identical configurations on the outgoing and incoming
VoIP dial-peers. When you have a fax relay problem though, make sure you have a dedicated
incoming VoIP dial-peer on the terminating gateway and that its configuration matches the
configuration of the outgoing VoIP dial-peer on the originating gateway.
Another method you can use to check dial peer matching is to issue the debug voip ccapi inout
command. The debug output from this command will show an ssaSetupPeer message that lists
all the dial-peers matching the called number. A ccCallSetupRequest message follows with the
outbound peer option indicating the outgoing VoIP dial-peer selected. When multiple VoIP dial
peers are configured for the same destination, it is possible that the initial call setup could fail
and another dial peer tried. In this case another ccCallSetupRequest will appear in the debug.
On the terminating voice gateway the first line of the debug voip ccapi inout call trace will be
a cc_api_call_Setup_ind message with a peer_tag option that refers to the incoming VoIP dial
peer on the terminating gateway.
– Incorrectly configured dial peers on one or both sides—
After you confirm that the correct dial peer is being matched (in this case dial-peer 100 for the
originating gateway and dial peer 400 for the terminating router), confirm in the configuration
that the dial-peer is configured correctly for fax. Some common errors to check for on both sides
of the call are:
•Fax relay is disabled (that is, the fax rate disable command has been issued on the dial
peer) while a low bandwidth codec has been in use.
•The dial peer on one gateway is configured for T.38 fax relay but the other gateway is
configured for Cisco proprietary fax relay, so the negotiation will fail.
•The default dial peer is used inbound on the terminating gateway and these parameters do
not match with the parameters set for the outbound dial peer on the originating gateway.
– Incorrect compand type—
The companding type for the US is µ-law, for EMEA it is a-law. The show voice call command
dispolays which value is currently configured. If, on a BRI or E1 port, the companding type on
the gateway does not match the one on the connected device, calls will sometimes fail and
sometimes connect. When a connection is made the voice becomes heavily distorted, the person
becomes unrecognizable, and a high volume low-pitch noise level is heard.
•Other basic connectivity problems not relating to dial peers, including:
– Cisco IOS Software incompatibilities on gateway pairs.
It is not always required that Cisco IOS Software releases on the gateways match, but it is
recommended to check releases for compatability when fax relay problems occur.
– Compressed Real-Time Transport Protocol (cRTP) problems.
There are several known problems associated with cRTP. Fixes are available for these problems
and it makes sense to disable cRTP when fax relay problems occur and to check whether a Cisco
IOS Software upgrade is an appropriate course of action.
– Ensure that the VCWare and Cisco IOS Software are compatible.
On Cisco AS5300 series voice gateways, the Cisco IOS software might be incompatible with
the VCWare software.
•Fax connectivity problems across the PSTN—

Cisco BTS 10200 Softswitch T.38 Fax Relay
Troubleshooting Fax Relay
19
Cisco BTS 10200 Softswitch T.38 Fax Relay Support
If voice calls work in both directions, but fax calls are failing in at least one direction, check that
normal faxing between these two machines works across the PSTN. In other words, ensure the fax
machines successfully transmit faxes to each other using the PSTN without traversing the packet
network. If they do not, one or both fax machines may have problems that need to be addressed
before you consider fax relay problems.
Step 3 Check for slips and other errors on the interfaces.
If any T1 (or E1) digital connections are used by the gateways performing T.38 fax relay, make sure that
they are error free. T.38 fax relay is very sensitive to errors on digital interfaces, especially slips. The
errors may not be noticeable on voice calls, but they can cause fax calls to fail.
The T1 (or E1) controllers at both the originating and terminating gateways should be error free. If errors
occur, repeat the show controller (T1, E1, and 1/0 will vary) command several times during a fax call
to see if the number of errors increases. The most common problem with slips is timing synchronization
resulting in clocking errors.
In packet voice networks, confirming that the router is clocking from the line is usually sufficient. If it
isn't, ensure that the clock source line command is entered at the controller level. However, in VoATM
or TDM networks where a clocking hierarchy is established and the gateways might need to pass clock
signals through the network, additional considerations need to be made.
Step 4 Check fax interface type.
On some Cisco media gateways, including the Cisco 3660, 5300, 5350, 5400, and 5800, the gateway
defaults to fax interface-type modem. The fax interface-type modem global configuration command
forces fax calls to a modem (usually for T.37 Store and Forward fax) and not to a DSP. For T.38 fax relay
to work, the fax call must be sent to a DSP, which means it must be configured by issuing the
fax interface-type t38 command.
Make sure you reload the Cisco media gateway; otherwise the fax interface-type t38 command won't
take effect. Fax calls will fail on some Cisco media gateways with T.38 fax relay, so this is an important
command to check. This problem is seen when a gateway is upgraded to Cisco IOS Release 12.2 or later.
Step 5 Make sure that the fax codec is loaded during the fax call.
Each fax machine displays the remote fax machine ID on its LCD screen at the completion of the fax
negotiation phase. It is unlikely that the fax machines could complete negotiation if the fax codec had
not been successfully downloaded. On the other hand, if no remote fax machine ID is displayed, further
debugging in this area is appropriate.
There are two ways to ensure the gateways detect the fax transmission and successfully load the fax codec.
•Issue the debug vtsp all command and the debug voip ccapi inout call trace.
Voice Telephony Service Provider (VTSP) is an architecture that defines the interface between the
Cisco call control and a DSP end point connected to standard telephony equipment such as a PBX,
fax or central office via analog or digital interfaces.
The debug vtsp all output does not contain a lot of information from a T.30 protocol perspective,
but it does provide useful state information from the router such as:
– Confirmation that the gateway entered fax mode
– Fax rate and codec used
– Confirmation that the terminating gateway received a fax tone from the terminating fax machine
•Issue the show voice trace command.
Show commands use less resources than debug commands and are preferable in production networks.

Cisco BTS 10200 Softswitch T.38 Fax Relay
Troubleshooting Fax Relay
20
Cisco BTS 10200 Softswitch T.38 Fax Relay Support
Step 6 Disable T.38 fax relay and change codec for passthrough.
In the previous troubleshooting steps you established that voice calls work, faxes work through PSTN,
and all digital interfaces in the fax relay path are free from errors. This step determines whether faxes
can go through with T.38 fax relay disabled.
Under the dial-peers, enter the following commands on both media gateways:
gateway-name(config)#voice-port 2/0:15
gateway-name(config-voiceport)#no echo-cancel enable
gateway-name(config)#dial-p voice 3
gateway-name(config-dial-peer)#fax rate disable
gateway-name(config-dial-peer)#codec g711ulaw
gateway-name(config-dial-peer)#no vad
These commands disable fax relay, disable echo cancellation, and force the call to use a high bandwidth
codec without voice activity detection (VAD). The gateway samples the fax tones like a normal voice
call. With the high bandwidth codec (G.711), the most precise sample possible is captured and the tone
replayed on the other side is as accurate as possible. Be aware that the G.711 is a 64 kbps bandwidth
codec, so each call consumes up to 80 kbps when the additional transport protocol overhead is added.
If this test is positive, two things have been accomplished:
•First, if per call bandwidth consumption is not a major issue for the network, there is now a potential
fax passthrough workaround for the fax relay problem.
•Secondly, and more significantly if bandwidth consumption is an issue, the problem has been
isolated to the T.38 fax relay software and you should open a case with the Cisco TAC.
If this test fails, it is very likely that whatever is causing the fax calls to fail with T.38 fax relay is also
causing the failures with this test. The network may have a large amount of jitter or packet loss.
Step 7 Check for packet loss on the network.
The easiest and most accurate way to determine if there is packet loss is to do the following:
a. Disable VAD on the packet network dial-peers.
b. Make a voice call between the same ports where the fax machines are connected. (Fax machines may
be able to serve as ordinary phones or you might need to connect handsets to the fax ports).
c. When the call is connected:
1Issue the show voice dsp command. You can see in the output that one of the DSP channels has
the configured codec loaded. Usually the column "TX/RX-PAK CNT" shows that the transmit
and receive packet counters are equal, meaning no packets are being lost.
If the counters are not equal, packets might be getting lost. Type the show voice dsp command
several times at 30-second intervals to determine if the difference increases. If so, then packets
are being lost.
2Issue the show voice call summary command to see which port (and timeslot if applicable) is
allocated to the voice call. Type terminal monitor then issue the show voice call command
with the voice port (and timeslot if applicable) specified to get the detailed DSP statistics. In
the "***DSP VOICE VP_ERROR STATISTICS***" section of the output, look for the
counters. They are usually 0 or below 20. If the counter(s) is higher than 20, investigate the
packet loss.
If the network appears to be lossy, it is not reasonable to expect T.38 fax relay to work reliably. Further
investigation is probably needed to ensure that QoS is provisioned end-to-end so that the voice and T.38
fax relay traffic has priority and is never lost during congestion.
