APPENDIX
D
Chassis and Module Power and Heat Values
This appendix provides the power and heat numbers for the Catalyst 6500 series chassis and modules.
The following power requirements and heat dissipation tables are provided:
•Chassis and fan trays—Table D-1
•IP phones—Table D-2
•Supervisor engines—Table D-3
•Policy Feature Cards (PFCs)—Table D-4
•Distributed Forwarding Cards (DFCs)—Table D-5
•Switch fabric modules—Table D-6
•10-Gigabit Ethernet modules—Table D-7
•Gigabit Ethernet modules—Table D-8
•10/100/1000 Ethernet modules—Table D-9
•Fast Ethernet switching modules—Table D-10
•10/100 Ethernet switching modules—Table D-11
•10BASE Ethernet switching modules—Table D-12
•FlexWAN and Enhanced FlexWAN modules—Table D-13
•Service modules—Table D-14
•Miscellaneous modules—Table D-15
Unless otherwise noted, the information in the following tables is measured under fully loaded
conditions (transceivers installed). Typical numbers are approximately 20 percent below the numbers
listed in these tables.
Note Module power is the output from the power supply (internal to the system). The AC-input power is the
input from the outlet to the power supply. The percentage difference between the two values is the
efficiency of the power supply.

D-2
Catalyst 6500 Series Switches Installation Guide
OL-5781-08
Appendix D Chassis and Module Power and Heat Values
Table D-1 Power Requirements and Heat Dissipation—Chassis and Fan Trays
Model Number/
Module Type
Module
Current (A)
Module
Power
(Watts)
AC DC
AC-Input
Power
(Watts)
Heat Diss.
(BTU/HR)
DC-Input
Power
(Watts)
Heat Diss.
(BTU/HR)
Catalyst 6503 chassis
FAN-MOD-3 fan tray 0.80 34.00 43.00 145.00 46.00 156.00
FAN-MOD-3HS fan tray 2.98 125.16 156.45 534.28 168.23 574.49
Catalyst 6503-E chassis
WS-C6503-E-FAN fan tray11.37
3.10
57.54
130.20
71.93
162.75
245.62
555.79
77.34
175.00
264.11
597.63
Catalyst 6504-E chassis
FAN-MOD-4HS fan tray11.43
2.17
60.06
91.14
75.08
113.93
256.38
389.05
80.73
122.50
275.68
418.34
Catalyst 6506 chassis
WS-C6K-6SLOT-FAN fan tray 0.71 30.00 37.48 128.00 40.00 136.88
WS-C6K-6SLOT-FAN2 fan tray 2.00 84.00 105.00 359.00 113.00 386.00
Catalyst 6506-E chassis
WS-C6506-E-FAN fan tray12.35
3.35
98.70
140.70
123.40
175.88
421.33
600.61
132.66
189.11
453.04
645.82
Catalyst 6509 chassis
WS-C6K-9SLOT-FAN fan tray 1.10 46.00 58.00 196.00 62.00 212.00
WS-C6K-9SLOT-FAN2 fan tray 3.04 127.68 159.60 545.03 171.70 586.06
Catalyst 6509-E chassis
WS-C6509-E-FAN fan tray13.58
5.00
150.36
210.00
187.95
262.50
641.85
896.44
202.10
282.26
690.16
963.91
Catalyst 6509-NEB chassis
WS-C6K-NEB-FAN fan tray 7.00 294.00 368.00 1255.00 395.00 1349.00

D-3
Catalyst 6500 Series Switches Installation Guide
OL-5781-08
Appendix D Chassis and Module Power and Heat Values
Catalyst 6509-NEB-A chassis
FAN-MOD-092fan tray 5.75 242.00 302.00 1031.00 325.00 1108.00
Catalyst 6509-V-E chassis3
WS-C6509-V-E-FAN fan tray 5.75 242.00 302.00 1031.00 325.00 1108.00
Catalyst 6513 chassis
WS-C6K-13SLOT-FAN fan tray 1.58 73.00 146.00 499.00 157.00 536.00
WS-C6K-13SLOT-FAN2 fan tray 7.10 298.20 372.75 1272.94 400.81 1368.75
Catalyst 6513-E chassis
WS-C6513-E-FAN 7.10 298.20 372.75 1272.94 400.81 1368.75
1. Two sets of values are given for these fan trays. The Catalyst 6500-E series fan trays are designed to provide two levels of cooling. The lower
set of values shown are for chassis where modules that do not require the additional cooling capacity are installed. The higher set of values shown
are for chassis where either the WS-X6708-10G-3C or -3CXL, or the WS-X6716-10G-3C or -3CXL Ethernet modules are installed. Both of these
Ethernet modules require the fan tray’s additional cooling capacity.
2. Values given are per fan tray. The Catalyst 6509-NEB-A switch chassis ships with one fan tray installed by default. A second fan tray can be
installed in the chassis. The power and heat numbers for a chassis equipped with two fan trays are double the values listed.
3. Values given are per fan tray. The Catalyst 6509-V-E switch chassis ships with one fan tray installed by default. A second fan tray can be installed
in the chassis. The power and heat numbers for a chassis equipped with two fan trays are double the values listed.
Table D-2 Power Requirements and Heat Dissipation—IP Phones
Model Number/
Module Type
Module
Current (A)
Module
Power
(Watts)
AC DC
AC-Input
Power
(Watts)
Heat Diss.
(BTU/HR)
DC-Input
Power
(Watts)
Heat Diss.
(BTU/HR)
Cisco IP Phone [phone].89 8.47 28.92
Cisco IP Phone [phone].89 8.47 28.92
Cisco IP Phone [phone].31 7.34 25.06
Table D-1 Power Requirements and Heat Dissipation—Chassis and Fan Trays (continued)
Model Number/
Module Type
Module
Current (A)
Module
Power
(Watts)
AC DC
AC-Input
Power
(Watts)
Heat Diss.
(BTU/HR)
DC-Input
Power
(Watts)
Heat Diss.
(BTU/HR)

D-4
Catalyst 6500 Series Switches Installation Guide
OL-5781-08
Appendix D Chassis and Module Power and Heat Values
The module power values are based on 42 VDC. Power is distributed to each slot in the chassis from the
power supply’s 42 VDC output. Each module has DC-to-DC power supplies that convert the 42 VDC
into +2.5 VDC, +3.3 VDC, and +5 VDC to power the module. The 42 VDC is independent of the power
supply’s input voltage, either 110 VAC or 220 VAC.
Table D-3 lists the power and the heat numbers for the supervisor engines.
Table D-3 Power Requirements and Heat Dissipation—Supervisor Engines
Model Number/
Module Type
Module
Current (A)
@ 42 VDC
Module
Power
(Watts)
AC DC
AC-Input
Power
(Watts)
Heat Diss.
(BTU/HR)
DC-Input
Power
(Watts)
Heat Diss.
(BTU/HR)
WS-X6K-SUP1A-2GE
Supervisor Engine 1A
1.70 71.40 89.25 304.79 95.97 327.73
WS-X6K-SUP1A-PFC
Supervisor Engine 1A with PFC
daughter card
2.50 105 131.25 448.22 141.13 481.96
WS-X6K-SUP1A-MSFC
Supervisor Engine 1A with PFC
and MSFC daughter cards
3.30 138.60 173.25 519.65 186.29 559.18
WS-X6K-SUP1A-MSFC2
Supervisor Engine 1A with PFC
and MSFC2 daughter cards
2.90 121.80 152.25 519.93 163.71 559.07
WS-X6K-S2-PFC2
Supervisor Engine 2 with PFC2
daughter card
3.06 128.52 160.65 548.62 172.74 589.91
WS-X6K-S2-MSFC2
Supervisor Engine 2 with PFC2
and MSFC2 daughter cards
3.46 145.32 181.65 620.33 195.32 667.03
WS-X6K-S2U-MSFC2
Supervisor Engine 2 with PFC2
and MSFC2 daughter
cards—Has 512 MB of DRAM
3.46 145.32 181.65 620.33 195.32 667.03

D-5
Catalyst 6500 Series Switches Installation Guide
OL-5781-08
Appendix D Chassis and Module Power and Heat Values
Model Number/
Module Type
Module
Current (A)
@ 42 VDC
Module
Power
(Watts)
AC DC
AC-Input
Power
(Watts)
Heat Diss.
(BTU/HR)
DC-Input
Power
(Watts)
Heat Diss.
(BTU/HR)
WS-SUP32-10GE-3B
Supervisor Engine 32 with
PFC3B and MSFC2A daughter
cards
4.19 175.98 219.98 751.21 236.53 807.76
WS-SUP32-GE-3B
Supervisor Engine 32 with
PFC3B and MSFC2A daughter
cards
3.69 154.98 193.73 661.57 208.31 711.37
WS-S32-GE-PISA
Supervisor Engine 32 with
PFC3B and Programmable IP
Services Accelerator (PISA)
daughter cards.
2.96 124.32 155.40 530.69 167.10 570.64
WS-S32-10GE-PISA
Supervisor Engine 32 with
PFC3B and Programmable IP
Services Accelerator (PISA)
daughter cards
2.97 124.74 155.93 532.48 167.66 572.56
WS-SUP720
Supervisor Engine 720 with
PFC3A daughter card and
integrated MSFC3 and switch
fabric
7.50 315.0 393.75 1344.66 423.39 1445.87
WS-SUP720-3B
Supervisor Engine 720 with
PFC3B daughter card and
integrated MSFC3 and switch
fabric
6.72 282.24 350.80 1204.81 379.35 1295.5
WS-SUP720-3BXL
Supervisor Engine 720 with
PFC3BXL daughter card and
integrated MSFC3 and switch
fabric
7.82 328.44 410.55 1402.03 441.45 1507.56
VS-S720-10G-3C
Supervisor Engine 720-10GE
with PFC3C daughter card and
integrated MSFC3 and switch
fabric
8.05 338.10 422.63 1443.26 454.44 1551.90
VS-S720-10G-3CXL
Supervisor Engine 720-10GE
with PFC3CXL daughter card
and integrated MSFC3 and
switch fabric
8.65 363.30 454.13 1550.84 488.31 1667.57
Table D-3 Power Requirements and Heat Dissipation—Supervisor Engines (continued)

D-6
Catalyst 6500 Series Switches Installation Guide
OL-5781-08
Appendix D Chassis and Module Power and Heat Values
Table D-4 lists the power and the heat numbers for the Policy Feature Cards (PFCs).
Table D-5 lists the power and the heat numbers for the Distributed Forwarding Cards (DFCs).
Table D-4 Power Requirements and Heat Dissipation—Policy Feature Cards (PFCs)
Model Number/
Module Type
Module
Current (A)
Module
Power
(Watts)
AC DC
AC-Input
Power
(Watts)
Heat Diss.
(BTU/HR)
DC-Input
Power
(Watts)
Heat Diss.
(BTU/HR)
WS-F6K-PFC3A
Policy Feature Card 3A
2.25 94.50 118.13 403.40 127.02 433.76
WS-F6K-PFC3B
Policy Feature Card 3B
1.47 61.74 77.18 263.55 82.98 283.39
WS-F6K-PFC3BXL
Policy Feature Card 3BXL
2.57 107.94 134.93 460.77 145.08 495.45
VS-F6K-PFC3C
Policy Feature Card 3C
1.90 79.80 99.75 340.65 107.26 366.29
VS-F6K-PFC3CXL
Policy Feature Card 3CXL
2.50 105.00 131.25 448.22 141.13 481.96
Table D-5 Power Requirements and Heat Dissipation—Distributed Forwarding Cards (DFCs)
Model Number/
Module Type
Module
Current (A)
Module
Power
(Watts)
AC DC
AC-Input
Power
(Watts)
Heat Diss.
(BTU/HR)
DC-Input
Power
(Watts)
Heat Diss.
(BTU/HR)
WS-F6K-DFC
Distributed Forwarding Card
2.10 88.20 110.25 376.50 118.55 404.84
WS-F6K-DFC3A
Distributed Forwarding Card 3A
2.57 107.94 134.93 460.77 145.08 495.45
WS-F6K-DFC3B
Distributed Forwarding Card 3B
1.67 70.14 87.68 299.41 94.27 321.95
WS-F6K-DFC3BXL
Distributed Forwarding
Card 3BXL
2.38 99.96 124.95 426.70 134.35 458.82
WS-F6700-CFC
Centralized Forwarding Card
0.75 31.5 39.38 134.47 42.34 144.59

D-7
Catalyst 6500 Series Switches Installation Guide
OL-5781-08
Appendix D Chassis and Module Power and Heat Values
Table D-6 lists the power and the heat numbers for the switch fabric modules.
WS-F6700-DFC3A
Distributed Forwarding Card 3A
3.0 126 157.5 537.86 169.35 578.35
WS-F6700-DFC3B
Distributed Forwarding Card 3B
2.7 113.40 141.75 484.08 152.42 520.51
WS-F6700-DFC3BXL
Distributed Forwarding
Card 3BXL
3.3 138.60 173.25 591.65 186.29 636.18
WS-F6700-DFC3C
Distributed Forwarding Card 3C
for use on CEF720 modules.
Supported only with Supervisor
Engine 720 and Supervisor
Engine 720-10GE
1.65 69.30 86.63 295.82 93.15 318.09
WS-F6700-DFC3CXL
Distributed Forwarding
Card 3CXL for use on CEF720
modules. Supported only with
Supervisor Engine 720 and
Supervisor Engine 720-10GE.
2.35 98.70 123.38 421.33 132.66 453.04
Table D-5 Power Requirements and Heat Dissipation—Distributed Forwarding Cards (DFCs) (continued)
Model Number/
Module Type
Module
Current (A)
Module
Power
(Watts)
AC DC
AC-Input
Power
(Watts)
Heat Diss.
(BTU/HR)
DC-Input
Power
(Watts)
Heat Diss.
(BTU/HR)
Table D-6 Power Requirements and Heat Dissipation—Switch Fabric Modules
Model Number/
Module Type
Module
Current (A)
Module
Power
(Watts)
AC DC
AC-Input
Power
(Watts)
Heat Diss.
(BTU/HR)
DC-Input
Power
(Watts)
Heat Diss.
(BTU/HR)
WS-C6500-SFM
Switch Fabric Module
2.79 117.18 146.5 500.2 157.5 537.86
WS-X6500-SFM2
Switch Fabric Module 2
3.09 129.78 162.23 554 174.4 595.7

D-8
Catalyst 6500 Series Switches Installation Guide
OL-5781-08
Appendix D Chassis and Module Power and Heat Values
Table D-7 lists the power and the heat numbers for the 10-Gigabit Ethernet modules.
Note For the WS-X6502-10GE and WS-X6704-10GE Ethernet modules, the values shown are for the
baseboard only. When the baseboard has a CFC or DFC3 daughter card installed, you must add the
daughter card power to the baseboard power to get the total slot power. For the WS-X6708-10G-3C,
WS-X6708-10G-3CXL, WS-X6716-10G-3C , and the WS-X6716-10G-3CXL Ethernet modules, the
values shown include the factory installed WS-F6700-DFC3C or WS-F6700-DFC3CXL daughter cards.
Table D-7 Power Requirements and Heat Dissipation—10-Gigabit Ethernet Modules
Model Number/
Module Type
Module
Current (A)
Module
Power
(Watts)
AC DC
AC-Input
Power
(Watts)
Heat Diss.
(BTU/HR)
DC-Input
Power
(Watts)
Heat Diss.
(BTU/HR)
WS-X6502-10GE
2-port 10-Gigabit Ethernet
module
3.30 138.60 173.25 591.65 186.29 636.18
WS-X6704-10GE
4-Port 10-Gigabit Ethernet
module
6.28 263.76 329.70 1125.93 354.52 1210.67
WS-X6708-10G-3C
8-Port 10-Gigabit Ethernet
module with WS-F6700-DFC3C
daughter card.
10.58 444.36 555.45 1896.86 600.49 2050.66
WS-X6708-10G-3CXL
8-Port 10-Gigabit Ethernet
module with
WS-F6700-DFC3CXL daughter
card.
11.28 473.76 592.20 2022.36 640.22 2186.34
WS-X6716-10G-3C
16-Port 10-Gigabit Ethernet
module with WS-F6700-DFC3C
daughter card.
10.90 457.80 572.25 1954.23 615.32 2101.33
WS-X6716-10G-3CXL
16-Port 10-Gigabit Ethernet
module with
WS-F6700-DFC3CXL daughter
card.
11.60 487.20 609.00 2079.74 654.84 2236.27
WS-X6716-10T-3C
16-Port 10-Gigabit Ethernet
module with WS-F6700-DFC3C
daughter card.
11.53 484.26 605.33 2067.18 650.89 2222.78
WS-X6716-10T-3CXL
16-Port 10-Gigabit Ethernet
module with
WS-F6700-DFC3CXL daughter
card.
12.23 513.66 642.08 2192.69 690.40 2357.73

D-9
Catalyst 6500 Series Switches Installation Guide
OL-5781-08
Appendix D Chassis and Module Power and Heat Values
Table D-8 lists the power and the heat numbers for the Gigabit Ethernet modules.
Table D-8 Power Requirements and Heat Dissipation—Gigabit Ethernet Modules
Model Number/
Module Type
Module
Current (A)
Module
Power
(Watts)
AC DC
AC-Input
Power
(Watts)
Heat Diss.
(BTU/HR)
DC-Input
Power
(Watts)
Heat Diss.
(BTU/HR)
WS-X6316-GE-TX
16-port 1000BASE-T Gigabit
Ethernet module
5.15 216.3 270.38 923.33 290.73 992.83
WS-X6408A-GBIC
8-port 1000BASE-X Gigabit
Ethernet module
2.00 84.00 105.00 358.58 112.90 385.56
WS-X6416-GBIC
16-port 1000BASE-X Gigabit
Ethernet module
2.81 118.02 147.53 503.8 158.63 541.72
WS-X6416-GE-MT
8-port 1000BASE-SX Gigabit
Ethernet module
2.50 105.00 131.25 448.22 141.13 481.96
WS-X6516-GBIC
16-port 1000BASE-X Gigabit
Ethernet module
3.40 142.80 178.50 609.58 191.94 655.46
WS-X6516A-GBIC
16-port 1000BASE-X Gigabit
Ethernet module
3.62 152.04 190.05 649.02 204.35 697.87
WS-X6724-SFP
24-Port 1000BASE-X Ethernet
module
2.23 99.66 117.08 399.81 125.89 429.90
WS-X6748-SFP
48-Port 1000BASE-X Ethernet
module
5.32 223.44 279.30 953.81 300.32 1025.60
WS-X6816-GBIC
16-Port1000BASE-X Gigabit
Ethernet module
3.84 161.28 201.60 688.46 216.77 740.28

D-10
Catalyst 6500 Series Switches Installation Guide
OL-5781-08
Appendix D Chassis and Module Power and Heat Values
Table D-9 lists the power and the heat numbers for the 10/100/1000 Ethernet switching modules.
Table D-9 Power Requirements and Heat Dissipation—10/100/1000 Ethernet Switching Modules
Model Number/
Module Type
Module
Current (A)
Module
Power
(Watts)
AC DC
AC-Input
Power
(Watts)
Heat Diss.
(BTU/HR)
DC-Input
Power
(Watts)
Heat Diss.
(BTU/HR)
WS-X6148-GE-TX
48-port 10/100/1000 Ethernet
module
2.47 104.0 130.0 443.0 139.0 476.0
WS-X6148V-GE-TX
48-port 10/100/1000 Ethernet
module with
WS-F6K-VPWR-GE PoE
daughter card
2.89 121.38 151.72 518.14 163.15 557.14
WS-X6148-GE-45AF
48-port 10/100/1000 Ethernet
module with WS-F6K-GE48-AF
PoE daughter card
2.65 111.30 139.13 475.11 149.60 510.87
WS-X6148A-GE-TX
48-port 10/100/1000 Ethernet
module
2.5 105.0 131.25 448.22 141.13 481.96
WS-X6148A-GE-45AF
48-port 10/100/1000 Ethernet
module with WS-F6K-GE48-AF
PoE daughter card
2.68 112.56 140.70 480.49 151.29 516.66
WS-X6516-GE-TX
16-port 10/100/1000 Ethernet
module
3.45 144.90 181.13 618.54 194.76 665.10
WS-X6548-GE-TX
48-port 10/100/1000 Ethernet
module
2.98 125.16 156.45 534.28 168.23 574.49
WS-X6548V-GE-TX
10/100/1000 Ethernet module
with WS-F6K-VPWR-GE PoE
daughter card
3.40 142.80 178.50 609.58 191.94 655.46
WS-X6548-GE-45AF
48-port 10/100/1000 Ethernet
module with WS-F6K-GE48-AF
PoE daughter card
3.16 132.72 165.90 566.55 178.39 609.19
WS-X6748-GE-TX
10/100/1000 Ethernet module
7.00 294.00 367.50 1255.01 395.16 1349.48
