Cisco Nexus 93128TX User manual

Installing the Chassis
•Installation Options with Rack-Mount Kits, Racks, and Cabinets, on page 1
•Install a Rack, on page 2
•Unpacking and Inspecting a New Switch, on page 2
•Planning How to Position the Chassis in the Rack, on page 3
•Installing the Chassis in a Two-Post Rack, on page 4
•Installing the Chassis in a Four-Post Rack, on page 8
•Grounding the Chassis, on page 13
•Powering Up the Switch, on page 15
Installation Options with Rack-Mount Kits, Racks, and Cabinets
The rack-mount kit enables you to install the switch into racks of varying depths. You can position the switch
with easy access to either the port connections or the fan and power supply modules.
You can install the switch using the following rack-mount options:
• Rack-mount kit (N9K-C9300-RMK) which you can order from Cisco.
You can install the switch in the following types of racks:
• Open EIA rack
• Perforated EIA cabinet
The rack or cabinet that you use must meet the requirements listed the in General Requirements for Cabinets
and Racks section.
You are responsible for verifying that your rack and rack-mount hardware comply with the guidelines that
are described in this doc.
Note
Installing the Chassis
1

Install a Rack
Before you install the switch, you must install a standard two- or four-post, 19-inch EIA data center rack (or
a cabinet that contains such a rack) that meets the requirements listed in Overview of Racks.
Step 1 Bolt the rack to the concrete subfloor before moving the chassis onto it.
Statement 1048—Rack Stabilization
The rack stabilizing mechanism must be in place, or the rack must be bolted to the floor before installation or
servicing. Failure to stabilize the rack can cause bodily injury.
Warning
Step 2 If the rack has bonded construction, connect it to the earth ground. This action enables you to easily ground the switch
and its components and to ground your electrostatic discharge (ESD) wrist strap to prevent damaging discharges when
you handle ungrounded components before installing them.
Step 3 Include one or two power sources at the rack. For AC power, provide a power receptacle. For DC power, provide a circuit
breaker with terminals for connecting power cables.
Statement 1018—Supply Circuit
To reduce risk of electric shock and fire, take care when connecting units to the supply circuit so that wiring
is not overloaded.
Warning
If you are not using power redundancy or are using n+1 redundancy, you need only one power source. If you
are using n+nredundancy, you need two power sources.
Note
Unpacking and Inspecting a New Switch
Before you install a new chassis, you need to unpack and inspect it to be sure that you have all the items that
you ordered and verify that the switch was not damaged during shipment. If anything is damaged or missing,
contact your customer representative immediately.
When you handle the chassis or its components, you must follow ESD protocol at all times to prevent ESD
damage. This protocol includes but is not limited to wearing an ESD wrist strap that you connect to the earth
ground.
Caution
Do not discard the shipping container when you unpack the switch. Flatten the shipping cartons and store
them. If you need to move or ship the system in the future, you will need this container.
Tip
Step 1 Compare the shipment to the equipment list that is provided by your customer service representative and verify that you
have received all of the ordered items.
Installing the Chassis
2
Installing the Chassis
Install a Rack

The shipment should include the following:
• Switch chassis, which includes the following installed components:
• One uplink module:
• M4PC uplink module
• M6PQ uplink module
• M6PQ-E uplink module
• M12PQ uplink module
• Two power supplies (any combination of the following with the airflow direction being the same as for the fan
modules):
• 1200-W HVAC/HVDC power supply
• Dual-direction HVAC/HVDC power supply with white coloring (N9K-PUV-1200W)
• 930-W DC power supply
• Port-side exhaust airflow with gray coloring (UCS-PSU-6332-DC)
• Port-side intake airflow with green coloring (UCSC-PDU-930WDC)
• Three fan modules (all fan and power supply modules must have the same airflow direction)
• Port-side exhaust airflow with blue coloring (N9K-C9300-FAN2-B)
• Port-side intake airflow with burgundy coloring (N9K-C9300-FAN2)
• Switch accessory kit
• Rack mount kit
Step 2 Check the contents of the box for damage.
Step 3 If you notice any discrepancies or damage, send the following information to your customer service representative by
email:
• Invoice number of the shipper (see the packing slip)
• Model and serial number of the missing or damaged unit
• Description of the problem and how it affects the installation
Planning How to Position the Chassis in the Rack
The switch is designed so that you can have coolant air flow through the switch in one of the two following
directions:
• Enter the port side and exhaust out the power supply side (port-side intake airflow)
Installing the Chassis
3
Installing the Chassis
Planning How to Position the Chassis in the Rack

• Enter the power supply side and exhaust out the port side (port-side exhaust airflow)
For port-side intake airflow, the switch must have port-side intake fan and AC power supply modules with
one or more of the following colorings:
• Burgundy coloring on fan modules and AC power supplies
• Green coloring on DC power supplies
• White coloring on 1200-W HVAC/HVDC power supplies (dual-direction airflow power supplies with
their airflow direction set by the fan modules)
For port-side exhaust airflow, the switch must have port-side exhaust fan and AC power supply modules with
one or more of the following colorings:
• Blue coloring on fan modules and AC power supplies
• Gray coloring on DC power supplies
• White coloring on 1200-W HVAC/HVDC power supplies (dual-direction airflow power supplies with
their airflow direction set by the fan modules)
You can plan the positioning of the switch so that its ports are located close to ports on connected devices or
so that the fan and power supply modules are conveniently located in a maintenance aisle, and then order the
modules that move coolant air in the appropriate direction from the cold aisle to the hot aisle.
All fan and power supply modules in the same switch must operate with the same direction of airflow and
the air intake portion of the switch must be located in a cold aisle.
Note
Installing the Chassis in a Two-Post Rack
Before you install the chassis, be sure that the rack is fully secured to the data center floor.
You must attach mounting brackets to the chassis before mounting the chassis.
Attaching Center-Mount Brackets to the Chassis
You need to attach a right-angled bracket to each side of the chassis. This bracket centers the chassis and
secures it in place on a two-post rack.
Installing the Chassis
4
Installing the Chassis
Installing the Chassis in a Two-Post Rack

Statement 1006—Chassis Warning for Rack-Mounting and Servicing
To prevent bodily injury when mounting or servicing this unit in a rack, you must take special precautions to
ensure that the system remains stable. The following guidelines are provided to ensure your safety:
• This unit should be mounted at the bottom of the rack if it is the only unit in the rack.
• When mounting this unit in a partially filled rack, load the rack from the bottom to the top with the
heaviest component at the bottom of the rack.
• If the rack is provided with stabilizing devices, install the stabilizers before mounting or servicing the
unit in the rack.
Warning
Before you begin
• You must separately order the center-mount brackets if you are installing the chassis in a two-post rack.
These brackets do not ship with the chassis unless you specifically order them.
• You must have the following tools and equipment:
• Manual Phillips-head torque screwdriver
• Center-mount bracket kit
Step 1 Align one of the two center-mount brackets on the left or right side of the chassis and be sure that the angled portion is
facing the front of the chassis (see the following figure).
Be sure to align four of the screw holes on the larger side of the bracket with the four screw holes near the center of the
left or right side of the chassis.
Four M4 x 8 mm screws used to fasten the bracket to
the chassis.
2Center-mount bracket with its larger side facing the
chassis and the longer side facing the front (port side)
of the chassis. Align four screw holes in the bracket
to four screw holes in the side of the chassis.
1
Step 2 Use four M4 x 8 mm screws to attach the bracket to the chassis. Tighten each screw to 11 to 15 in-lb (1.2 to 1.7 N·m).
Step 3 Repeat Steps 1 and 2 to attach the second center-mount bracket to the other side of the chassis.
Installing the Chassis
5
Installing the Chassis
Attaching Center-Mount Brackets to the Chassis

What to do next
You are ready to mount the chassis to the two-post rack.
Installing the Chassis in a Two-Post Rack
You need to position the chassis near the top of the rack with the power supply and fan modules in the
appropriate aisle for their required airflow. If the fan modules have a blue coloring for port-side exhaust
airflow, then you must position the modules by the cold aisle. If the fan modules have a burgundy coloring
for port-side intake airflow, you must position the modules by the hot aisle.
Power supply modules must have the same airflow direction as the fan modules.
Note
Power supply modules must have the same airflow direction as the fan modules but might have different
coloring if they use DC power (green coloring for port-side intake airflow or gray coloring for port-side
exhaust airflow). HVAC/HVDC power supplies with white coloring use the same direction of airflow as used
by the fan modules.
Note
Statement 1074—Comply with Local and National Electrical Codes
To reduce risk of electric shock or fire, installation of the equipment must comply with local and national
electrical codes.
Warning
Statement 1032—Lifting the Chassis
To prevent personal injury or damage to the chassis, never attempt to lift or tilt the chassis using the handles
on modules (such as power supplies, fans, or cards); these types of handles are not designed to support the
weight of the unit.
Warning
Before you begin
• Make sure that the two-post rack is properly installed and secured to the concrete subfloor.
• Make sure that two center-mount brackets are securely fastened to the middle of each side of the chassis.
• Make sure that you have six customer-supplied rack-mount screws (typically M6 x 10 mm or the
appropriate screw for the vertical mounting rails on the rack).
• You have at least two people to install the chassis.
Installing the Chassis
6
Installing the Chassis
Installing the Chassis in a Two-Post Rack

Statement 1006—Chassis Warning for Rack-Mounting and Servicing
To prevent bodily injury when mounting or servicing this unit in a rack, you must take special precautions to
ensure that the system remains stable. The following guidelines are provided to ensure your safety:
• This unit should be mounted at the bottom of the rack if it is the only unit in the rack.
• When mounting this unit in a partially filled rack, load the rack from the bottom to the top with the
heaviest component at the bottom of the rack.
• If the rack is provided with stabilizing devices, install the stabilizers before mounting or servicing the
unit in the rack.
Warning
Step 1 Use one person to position the chassis so that it is near the top of the rack with the fan and power supply modules in the
appropriate aisle and the center-mount bracket has its screw holes aligned to screw holes on the two-post rack.
If these modules have a blue or gray coloring for port-side exhaust airflow, then you must position the modules by the
cold aisle. If the modules have a burgundy or green coloring for port-side intake airflow, you must position the modules
by the hot aisle.
Three customer-supplied screws (typically M6 x 10
mm screws or the appropriate screws for the rack) to
hold each side of the chassis to the two-post rack.
1
Step 2 Use the second person to secure the three customer-supplied rack-mount screws (typically M6 x 10 mm or other appropriate
screws for the rack) on each center-mount bracket to attach the chassis to the rack. Tighten each screw to the appropriate
torque setting for the screws (for M6 x 10 mm screws, use 40 in-lbs [4.5 N·m] of torque).
Installing the Chassis
7
Installing the Chassis
Installing the Chassis in a Two-Post Rack

Installing the Chassis in a Four-Post Rack
Before you install the chassis, be sure that the rack is fully secured to the data center floor.
Installing the Switch using the N9K-C9300-RMK Rack-mount Kit
Attaching the Bottom-Support Rails to the Rack
The switch chassis that you are installing ships with two adjustable bottom-support rails that you can attach
to a four-post rack to hold the chassis. Each of these bottom-support rails has two pieces—one that slides into
the other so that you can adjust them to fit racks with front and rear mounting posts that are spaced less than
36 inches (91 cm). On each bottom-support rail, the rail half that slides into the other rail includes a chassis
stop that fits into the module end of the chassis. Depending on direction of the chassis airflow, you need to
position the rail half with the chassis stop so that the fan and power supply modules end up in the appropriate
aisle as follows:
• Port-side intake (burgundy coloring for fan modules) airflow requires that the bottom-support rail with
the chassis stop be located on the hot aisle side of the rack.
• Port-side exhaust (blue coloring for fan modules) airflow requires that the bottom-support rail with the
chassis stop be located on the cold aisle side of the rack.
Statement 1074—Comply with Local and National Electrical Codes
To reduce risk of electric shock or fire, installation of the equipment must comply with local and national
electrical codes.
Warning
Before you begin
Before you can install the bottom support rails for the chassis, you must do the following:
• Verify that a four-post rack or cabinet is installed.
• If any other devices are stored in the rack or cabinet, verify that the heavier switches are installed below
lighter switches.
• Verify that the bottom-support rails kit is included in the switch accessory kit.
• Verify that you have 8 screws for attaching the bottom support brackets to the racks (typically M6 x 10
mm screws or the screw appropriate for the vertical mounting rails on the rack.
Installing the Chassis
8
Installing the Chassis
Installing the Chassis in a Four-Post Rack

Statement 1006—Chassis Warning for Rack-Mounting and Servicing
To prevent bodily injury when mounting or servicing this unit in a rack, you must take special precautions to
ensure that the system remains stable. The following guidelines are provided to ensure your safety:
• This unit should be mounted at the bottom of the rack if it is the only unit in the rack.
• When mounting this unit in a partially filled rack, load the rack from the bottom to the top with the
heaviest component at the bottom of the rack.
• If the rack is provided with stabilizing devices, install the stabilizers before mounting or servicing the
unit in the rack.
Warning
Step 1 Look at the fan and power supply modules installed in the chassis to determine how you must position the bottom-support
rails on the rack.
• If the fan modules have blue coloring (port-side exhaust modules), you must position the bottom support rails so
that the chassis stop is positioned by the cold aisle.
• If the fan modules have burgundy (port-side intake modules), you must position the bottom support rails so that the
chassis stop is positioned by the hot aisle.
Step 2 Separate the two sliders that make up one bottom-support rail and position the half with the chassis stop by the appropriate
aisle for the fan and power supply modules. Also make sure that there is at least 1 rack unit open above the bottom-support
rails so that you can easily install the chassis.
Step 3 Use two customer-supplied screws (typically M6 x 10 mm screws) to attach the bottom-support rail half to the vertical
mounting rails on the rack post. Tighten each screw to the appropriate torque setting for the screws (for M6 x 10 mm
screws, use 40 in. lbs [4.5 N·m] of torque).
Step 4 Slide the other half of the bottom-support rail onto the attached half of the rail set and use two customer supplied screws
(typically M6 x 10 mm screws) to secure that portion to the vertical mounting rails on the rack. Tighten each screw to
the appropriate torque setting for the screws (for M6 x 10 mm screws, use 40 in. lbs [4.5 N·m] of torque).
Installing the Chassis
9
Installing the Chassis
Attaching the Bottom-Support Rails to the Rack

Figure 1: Positioning an Expanding Bottom-Support Rail Set
2 screws holding the front
end of the bottom-support
bracket to the front side of
the rack
32 screws holding one end of
the bottom-support bracket
to the rear of the rack
1
Chassis stop on the
expanding bottom-support
bracket
2
Step 5 Repeat Steps 2 and 3 to attach the other expanding bottom-support rails to the other side of the rack.
Check the two installed bottom support rails to be sure that both have their chassis stops by the same aisle
(either both by the hot aisle or both by the cold aisle) and that both rails are level and level with each other. If
they are not level, adjust the higher rail down to the level of the lower rail.
Note
What to do next
You are ready to install two front-mount brackets on the chassis.
Attaching Front-Mount Brackets to the Chassis
You need to attach a right-angled bracket to each side of the chassis. This bracket holds the chassis in place
on a four-post rack.
Installing the Chassis
10
Installing the Chassis
Attaching Front-Mount Brackets to the Chassis

Before you begin
• You must have the following tools and equipment:
• Manual Phillips-head torque screwdriver
• Front-mount brackets (2) and screws (4) (found inside the switch accessory kit)
Step 1 Align the two holes in one side of one of two front-mount brackets to two holes on the left or right side of the chassis
(see the following figure).
Be sure that the other side of the bracket is facing toward the front (port end) of the chassis.
Two M4 x 6 mm screws used to fasten the bracket to
the chassis.
2Front-mount bracket with two screw holes aligned to
two screw holes in the chassis and one screw hole
facing the front (port side) of the chassis.
1
Step 2 Use two M4 x 6 mm screws to attach the bracket to the chassis. Tighten each screw to 11 to 15 in-lb (1.2 to 1.7 N·m).
Step 3 Repeat Steps 1 and 2 to attach the second center-mount bracket to the other side of the chassis.
What to do next
You are ready to mount the chassis to the four-post rack.
Installing the Chassis in a Four-Post Rack
You need to slide the chassis onto the bottom-support rails so that the power supply end locks onto the chassis
stops at the end of the rails and so that the front-mount brackets on the chassis come into contact with the
front-mount rails on the rack.
Statement 1074—Comply with Local and National Electrical Codes
To reduce risk of electric shock or fire, installation of the equipment must comply with local and national
electrical codes.
Warning
Installing the Chassis
11
Installing the Chassis
Installing the Chassis in a Four-Post Rack

Statement 1032—Lifting the Chassis
To prevent personal injury or damage to the chassis, never attempt to lift or tilt the chassis using the handles
on modules (such as power supplies, fans, or cards); these types of handles are not designed to support the
weight of the unit.
Warning
Before you begin
• Make sure that the four-post rack is properly installed and secured to the concrete subfloor.
• Make sure that the bottom-support rails are installed so that the fan modules will be in the appropriate
aisle as follows:
• Burgundy (port-side intake airflow) fan modules are positioned in a hot aisle (the chassis stop on
the bottom-support rails is positioned by the hot aisle).
• Blue colored (port-side exhaust airflow) fan modules are positioned in a cold aisle (the chassis stop
on the bottom-support rails is positioned by the cold aisle).
• Make sure that two front-mount brackets are securely fastened to the sides of the chassis at the port end.
• Make sure that you have two customer-supplied rack-mount screws (M6 x 10 mm or appropriate screw
for the vertical mounting rails on the rack).
Statement 1006—Chassis Warning for Rack-Mounting and Servicing
To prevent bodily injury when mounting or servicing this unit in a rack, you must take special precautions to
ensure that the system remains stable. The following guidelines are provided to ensure your safety:
• This unit should be mounted at the bottom of the rack if it is the only unit in the rack.
• When mounting this unit in a partially filled rack, load the rack from the bottom to the top with the
heaviest component at the bottom of the rack.
• If the rack is provided with stabilizing devices, install the stabilizers before mounting or servicing the
unit in the rack.
Warning
Step 1 Slide the power supply end of the chassis onto the bottom-support rails that are installed on the rack.
Be sure that the sides of the chassis by the power supplies clips into the chassis stops on the bottom-support rails and the
front-mount brackets come in contact with the rack (see the following figure).
If the bottom-support rails are extended a long distance, they can bend outwards slightly when you install the
chassis and the chassis stops at the far end of the rails might not fit into the end of the chassis. If this happens,
press the side rails toward the sides of the chassis so that the chassis stops can go inside the chassis and hold
it in place on the rack.
Note
Installing the Chassis
12
Installing the Chassis
Installing the Chassis in a Four-Post Rack

Receiving hole on each side of the chassis for the
chassis stops on the bottom-support rails.
3Slide the power-supply end of the chassis onto the
bottom-support rails so that the chassis locks onto the
chassis stops at the end of the rails.
1
Customer-supplied rack-mount screw (M6 x 10 mm
screw or other screw appropriate for the rack) used to
secure each side of the chassis to the rack.
4Chassis stops for holding the chassis (positioned by
the aisle required for the fan and power supply
modules).
2
Step 2 Use a customer-supplied rack-mount screw (an M6 x 10 mm screw or other appropriate screw for the rack) to attach each
of the two mounting brackets on the chassis to the rack and tighten each screw to the appropriate torque setting for the
screw (for M6 x 10 mm screws, use 40 in-lbs [4.5 N·m] of torque).
Grounding the Chassis
The switch chassis is automatically grounded when you properly install the switch in a grounded rack with
metal-to-metal connections between the switch and rack.
You can also ground the chassis, which is required if the rack is not grounded, by attaching a customer-supplied
grounding cable. Attach the cable to the chassis grounding pad and the facility ground.
Installing the Chassis
13
Installing the Chassis
Grounding the Chassis

Statement 1024—Ground Conductor
This equipment must be grounded. To reduce the risk of electric shock, never defeat the ground conductor or
operate the equipment in the absence of a suitably installed ground conductor. Contact the appropriate electrical
inspection authority or an electrician if you are uncertain that suitable grounding is available.
Warning
Statement 1046—Installing or Replacing the Unit
To reduce risk of electric shock, when installing or replacing the unit, the ground connection must always be
made first and disconnected last.
Warning
Before you begin
Before you can ground the chassis, you must have a connection to the earth ground for the data center building.
Step 1 Use a wire-stripping tool to remove approximately 0.75 inch (19 mm) of the covering from the end of the grounding
wire. We recommend 6-AWG wire for the U.S. installations.
Step 2 Insert the stripped end of the grounding wire into the open end of the grounding lug. Use a crimping tool to crimp the
lug to the wire, see the following figure. Verify that the ground wire is securely attached to the grounding lug by attempting
to pull the wire out of the crimped lug.
2 M4 screws are used to
secure the grounding lug to
the chassis
3Chassis grounding pad1
Grounding cable, with 0.75
in. (19 mm) of insulation that
is stripped from one end,
which is inserted into the
grounding lug and crimped
in place
2
Step 3 Secure the grounding lug to the chassis grounding pad with two M4 screws, see the previous figure. Tighten the screws
to 11 to 15 in-lb (1.24 to 1.69 N·m) of torque.
Installing the Chassis
14
Installing the Chassis
Grounding the Chassis

Step 4 Prepare the other end of the grounding wire and connect it to the facility ground.
Powering Up the Switch
To power up the switch, you must connect the power supplies to one or two power sources. The number of
power sources used depends on the type of power redundancy that you require as follows:
• For no power redundancy, connect only the power supplies to one power source.
• For n+1 redundancy, connect the power supplies to one or two power sources.
•For n+nredundancy, connect each power supply to a different power source (two power sources required).
Statement 7012—Equipment Interfacing with AC Power Ports
This equipment shall be connected to AC mains provided with a surge protective device (SPD) at the service
equipment complying with NFPA 70, the National Electrical Code (NEC).
Statement 1004—Installation Instructions
Read the installation instructions before using, installing or connecting the system to the power source.
Warning
Statement 1018—Supply Circuit
To reduce risk of electric shock and fire, take care when connecting units to the supply circuit so that wiring
is not overloaded.
Warning
Before you begin
• Switch installed in a rack and connected to an earth ground
• Recommended power cable for your nation or region
• Power source with the required amperage located within reach of the power cable being used
Connect each power supply to a power source as follows:
• Connecting a DC power supply:
1. Verify that the circuit breaker for the DC power source you are connecting is turned off.
2. Remove the DC power connector block from the power supply by doing the following:
1. Push the orange plastic button on the top of the connector block inward toward the power supply.
2. Pull the connector block out of the power supply.
Installing the Chassis
15
Installing the Chassis
Powering Up the Switch

3. Strip 0.6 inches (15 mm) of insulation off the DC wires that you are using.
4. Orient the connector as shown in the following figure with the orange plastic button on top.
Figure 2: Wiring a 930W -48VDC Power Supply Connector Block
-48V (-DC) cable4Wire retainer lever1
Grounding cable (8 AWG recommended)5Orange plastic button on top of the connector2
-48V Return (+DC) cable3
5. Use a small screwdriver to depress the spring-loaded wire retainer lever on the lower spring-cage wire connector.
Insert your green (ground) wire into the aperture and then release the lever.
6. Use a small screwdriver to depress the spring-loaded wire retainer lever on the middle spring-cage wire connector.
Insert your black (DC negative) wire into the aperture and then release the lever.
7. Use a small screwdriver to depress the spring-loaded wire retainer lever on the upper spring-cage wire connector.
Insert your red (DC positive) wire into the aperture and then release the lever.
8. Insert the connector block back into the power supply. Make sure that your red (DC positive) wire aligns with
the power supply label, "+ DC".
If you require n+nredundancy, be sure that each power supply is powered by a different power source.
Note
• Connecting an HVAC/HVDC power supply:
1. Using the recommended power cable for your country or region (see Power Cable Specifications), insert the
Saf-D-Grid connector on the power cable to the power receptacle on the power supply until it clicks in place.
2. Connect the other end of the power cable to the power source.
• If connecting to an AC power source, plug the cable into the receptacle for the power source.
• If connecting to a DC power source, do the following:
1. Verify that the power source is turned off at the circuit breaker located between the power source and
the terminals where you will connect the power cable.
2. Connect each of the three wires in the power cable to the three terminals for the power source and
secure them with the terminal nuts. Make sure that the positive wire is attached to the positive terminal,
the negative wire is attached to the negative terminal, and the ground wire is attached to the ground
terminal.
Installing the Chassis
16
Installing the Chassis
Powering Up the Switch

3. If there is a safety cover for the terminals, place it over the terminals to prevent people from accidentally
touching the terminals when the power is on.
4. Turn the power on at the circuit breaker.
3. Verify that the LED is on and green.
If the LED is off, check the AC power source circuit breaker to be sure that it is turned on.
Installing the Chassis
17
Installing the Chassis
Powering Up the Switch

Installing the Chassis
18
Installing the Chassis
Powering Up the Switch
