Cisco WAP121 User manual

Quick Start Guide
Cisco Small Business
WAP121 Wireless-N Access Point with PoE
and
WAP321 Wireless-N Selectable-Band Access
Point with PoE
Versión en Español para México en el CD
Version en français sur CD
Versione italiana sul CD
Deutsch Version auf CD

2 Cisco Small Business WAP121 and WAP321 Wireless-N Access Point with PoE
Welcome
Thank you for choosing the Cisco Small Business WAP121 or WAP321
Wireless Access Point. The Cisco WAP321 is a single radio, selectable-
band, 2.4 GHz or 5.0 GHz 802.11n access point, and the Cisco WAP121 is a
single-band 2.4 GHz variant of the Cisco WAP321.
This guide is designed to familiarize you with the general layout of the
access point, describe how to deploy the device in your network, and
describe how to configure the device. Your access point has more features
and functionality than what is described in this guide. For additional
information, see the Administration Guide. A link to the Administration
Guide is found in “Where to Go From Here” on page 11.
Package Contents
•Wireless Access Point
•Mounting kit
•Power Adapter for the Cisco WAP121 (for the Cisco WAP321 the
power adaptor is sold separately)
•This Quick Start Guide
•Product CD
•Ethernet Cable
Before You Begin
Before you begin the installation, make sure that you have the following
equipment and services:
•A computer with Browser support for:
– Internet Explorer v7.0 or later
– Chrome v5.0 or later
– Firefox v3.0 or later
–Safariv3.0orlater
•Tools for installing the hardware
•One or more Ethernet network switches
•Uninterruptible Power Supply (UPS) to provide backup power to
essential devices
1

Cisco Small Business WAP121 and WAP321 Wireless-N Access Point with PoE 3
Cisco WAP121 and WAP321 Wireless-N
Access Point Features
Front Panel
The front panel of the devices consists of three lights: Power, WLAN, and
LAN. For full descriptions of the colors of the lights and their indications,
see “Verifying the Hardware Installation”. A Kensington lock slot is found
under the lights.
Back Panel
The back panel of the devices consists of:
•Power Button—Use this button to turn the power on and off. It is not
applicable when using PoE.
•Power Jack—Use this jack if you are not using PoE.
•Kensington Lock Slot—Use to attach a cable and lock to the device.
•Reset—See “Rebooting the Devices or Returning them to their
Factory Default Settings” for information on the Reset button.
•RJ-45 Ethernet Port—Use this auto-sensing, Gigabit Ethernet (802.3)
port to connect to network devices, such as computers, routers, or
switches. Cisco strongly recommends using Cat5 or better cable for
Gigabit connectivity. You may use the Ethernet port to power your
device using PoE.
Default Settings
If you are using a Cisco Small Business RV Series router, the default range
for the DHCP assigned address is from 192.168.1.100 to 192.168.1.254. Any
device connecting to the same LAN will be assigned an IP address in this
range.
Parameter Default Value
Username cisco
Password cisco
LAN IP Address DHCP address assigned
by server
Fallback LAN IP 192.168.1.245
Subnetwork Mask 255.255.255.0
2

4 Cisco Small Business WAP121 and WAP321 Wireless-N Access Point with PoE
Mounting the Cisco WAP121 and WAP321
Wireless-N Access Points
You can place your access point on a desktop, or mount it on a wall or
ceiling.
Placement Tips
• Ambient Temperature—To prevent the access point from overheating,
do not operate it in an area that exceeds an ambient temperature of
104°F (40°C).
•AirFlow—Both side panels have vents which must be unobstructed to
prevent overheating.
• Mechanical Loading—The device should be level, stable, and secure
to prevent it from sliding or shifting out of position.
Wall and Ceiling Mounting
The Cisco WAP121 and WAP321 can be wall or ceiling-mounted.
There is a mounting kit packed with your device. The kit is designed to
install your device to the wall or the ceiling. The dimensions for the mount
kit screws are as follows:
WARNING Insecure mounting might damage the device or cause injury.
Cisco is not responsible for damages incurred by insecure wall
or ceiling mounting.
17.8 to 8.3 mm/
.31 to .33 in
221.8 to 22.3 mm/
.86 to .88 in
35.5 to 6.0 mm/
.22 to .24 in
417.5 to 18.2mm/
.69 to .72 in
3
1
2
4
3
196243

Cisco Small Business WAP121 and WAP321 Wireless-N Access Point with PoE 5
To mount the WAP device to a wall or ceiling:
STEP 1Determine where you want to mount the device. Verify that the
surface is smooth, flat, dry, and sturdy.
STEP 2Drill two pilot holes into the surface 1.85 inches (47 mm) apart for
the Cisco WAP121. For the WAP321, drill the holes 2.75 inches
(70 mm) apart.
STEP 3Insert a screw into each hole, leaving a gap between the surface
and the base of the screw head.
STEP 4Place the upper slots of the bracket over the screws, adjust the
screws accordingly, and slide the bracket down until the screws fit
snugly into the slots.
STEP 5Using the bracket as a template, drill two more holes for the lower
screws.
STEP 6Insert a screw into each lower hole.
STEP 7Slide the WAP device into the bracket, placing the cables or cords
through the break-out tab found in the back of the bracket.
Connecting the Cisco WAP121 and
WAP321 Wireless-N Access Points
To connect the device to the network:
STEP 1Connect the Ethernet cable to the Ethernet port of a switch or a
router.
STEP 2Connect the other end of the network Ethernet cable to the
Ethernet port of the wireless access point.
STEP 3If PoE is not provided, for the Cisco WAP121 plug in the power
adaptor to provide power to the device. For the Cisco WAP321, the
power adaptor is sold separately.
After installation, all lights should be active. Refer to Verifying the
Hardware Installation, page 6 for details about the different lights on each
switch.
4

6 Cisco Small Business WAP121 and WAP321 Wireless-N Access Point with PoE
Verifying the Hardware Installation
To verify the hardware installation, complete the following tasks:
•Check the cable connections.
•Check the state of the indicator lights.
NOTE If you need help resolving a problem, visit the Cisco Small Business
Support Community at www.cisco.com/go/smallbizsupport.
Label Activity Description
Power Off Power is off
Solid Green Power is on. Normal operation using an
external power adaptor.
Solid Amber Power is on. Normal operation using PoE.
Flashing Booting/Firmware upgrade
WLAN Off Wireless is disabled, for both 2.4 GHz and
5GHzwirelessnetworks
Solid Green Wireless 2.4 GHz band is enabled.
Solid Amber Wireless 5 GHz band is enabled.
Flashing Transmitting/Receiving Data
Flashing Fast (2x
Flashing rate)
Wi-Fi Protected Setup (WPS) is synchronizing
LAN Off No Ethernet Link
Solid Green Ethernet link is active.
•FE link is detected for Cisco WAP121
•GE link is detected for Cisco WAP321
Solid Amber Ethernet link is active.
•FE link is detected for Cisco WAP321
Flashing Transmitting/Receiving Data
5

Cisco Small Business WAP121 and WAP321 Wireless-N Access Point with PoE 7
Getting Started with the Configuration
To configure the wireless access points, follow these steps to access the
Wizard and then the web-based configuration utility from your computer.
STEP 1Connect the wireless access point to the same network (IP subnet)
as your computer. The factory default IP address configuration of
the access points is DHCP. Make sure your DHCP server is running
and can be reached.
See “Incorrect IP Address” on page 9 for troubleshooting
information, or if you do not have a DHCP server.
STEP 2Locate the IP address of the wireless access point.
a. The wireless access points can be accessed and managed by
Cisco Small Business network tools and services including the
Cisco FindIT Network Discovery Utility that enables you to
automatically discover all supported Cisco Small Business
devices in the same local network segment as your computer.
You can get a snapshot view of each device or launch the
product configuration utility to view and configure the settings.
For more information, see www.cisco.com/go/findit.
b. The wireless access points are Bonjour-enabled and
automatically broadcast their services and listen for services
being advertised by other Bonjour-enabled devices. If you
have a Bonjour-enabled browser, such as Microsoft Internet
Explorer with a Bonjour plug-in, or the Apple Mac Safari
browser, you can find the wireless access point on your local
network without knowing its IP address.
You can download the complete Bonjour for Internet Explorer
browser from Apple’s Web site by visiting
http://www.apple.com/bonjour/.
c. Locate the IP address assigned by your DHCP server by
accessing your router/DHCP Server; see your DHCP server
instructions for information.
STEP 3Launch a web browser, such as Internet Explorer or Mozilla Firefox.
STEP 4In the Address field enter the default DHCP address and press the
Enter key.
STEP 5Enter the default user name of cisco and password of cisco in the
User Name and Password fields.
STEP 6Click Login. The Wireless Access Point Setup Wizard appears.
6

8 Cisco Small Business WAP121 and WAP321 Wireless-N Access Point with PoE
STEP 7Follow the Setup Wizard instructions to finish the WAP device
installation. For more advanced configurations, see the
Administration Guide. A link to the Administration Guide is found in
“Where to Go From Here” on page 11.
Congratulations, you can now start using your wireless access point.
Suggested Next Steps
In case of an error while installing, try the following troubleshooting
procedures:
Troubleshooting
If you cannot display the configuration utility, you can test the ability of the
computer to communicate with the device by using ping. To use ping on a
computer running Windows:
STEP 1Verify that the Cisco WAP121 or WAP321 is powered on and the
lights indicate the appropriate links.
STEP 2Locate the device’s IP address. While there are different ways to
locate your device’s IP address, this procedure uses Cisco FindIT.
a. If you have previously downloaded Cisco FindIT, open Mozilla
Firefox and launch Cisco FindIT. For more information on
downloading Cisco FindIT, see www.cisco.com/go/findit.
b. In the Cisco FindIT display, place your mouse over the device’s
name. The device IP address is displayed along with other
device information.
STEP 3Open a command window by using Start > Run and enter cmd.
STEP 4At the Command window prompt enter ping and the device IP
address. In this example, we pinged 192.0.2.10.
If successful, you should get a reply similar to the following:
Pinging 192.0.2.10 with 32 bytes of data:
Reply from 192.0.2.10: bytes=32 time<1ms TTL=128
If it fails, you should get a reply similar to the following:
Pinging 192.0.2.10 with 32 bytes of data:
Request timed out.
7

Cisco Small Business WAP121 and WAP321 Wireless-N Access Point with PoE 9
Possible Cause of Failure
No Power
•Power up the switch and your computer if they are turned off.
•If your access point is using PoE, make sure your PoE switch is powered
on and the lights indicate that you have a link. See “Verifying the
Hardware Installation” on page 6.
•Verify that the power button is on; only applicable if you are not using
PoE.
•Verify that the devices on your network are not plugged into a
switchable outlet.
Bad Ethernet Connection
•Check the state of the indicator lights. See “Verifying the Hardware
Installation” on page 6.
•Check the connectors of the Ethernet cable to ensure they are firmly
plugged into the switch and your computer.
•Verify the connected switch has auto-negotiation enabled. The access
point and the switch need the same negotiation parameters set.
Bad Image
After a new firmware installation, if the Power light is flashing quickly,
contact system support; see “Where to Go From Here” on page 11.
Incorrect IP Address
The most likely cause of connectivity failure is an incorrect IP address. The
Web browser may be pointed to the wrong IP address, or your computer
may be configured with an IP address that is not in the same subnet as the
device.
Because the factory default IP address configuration is DHCP, make sure
that your DHCP server is running and can be reached. You may need to
disconnect and reconnect the devices for them to discover their new IP
addresses from the DHCP server. You can then query the DHCP server for
the new IP address. See Step 2 of “Getting Started with the
Configuration” on page 7 for more information on how to find the DHCP
address.
If the wireless access points do not receive a DHCP response (there is no
DHCP server on your network) after 60 seconds, the access points will
fallback to the following default static IP address: 192.168.1.245 and a
default mask of 255.255.255.0. To reach that IP address, be sure that your
computer is on the 192.168.1.xxx network.

10 Cisco Small Business WAP121 and WAP321 Wireless-N Access Point with PoE
Rebooting the Devices or Returning them
to their Factory Default Settings
To reboot your device:
•If your device uses a power adaptor, use the Power button to reboot
your device. The Power button only functions when the device uses a
power adaptor.
•Unplug your Ethernet connection for three seconds and plug it back in.
• If your devices uses PoE, with the power on, press the Reset button with
a bent paperclip for less than three seconds, or until the lights go off.
– When all the lights go off, release the Reset button.
– Release the Reset button as soon as the lights go off, or you will
restore the device to factory default settings and lose your
configurations.
To reset the device to factory default settings:
•To restore the device to the factory default settings, with the power on,
press-and-hold the Reset button with a bent paperclip for more than 10
seconds.
– All of the lights will go off.
– Release the Reset button when power light turns on.
8

Cisco Small Business WAP121 and WAP321 Wireless-N Access Point with PoE 11
Where to Go From Here
Support
Cisco Small Business
Support Community
www.cisco.com/go/smallbizsupport
Cisco Small Business
Support and Resources
www.cisco.com/go/smallbizhelp
Phone Support Contacts www.cisco.com/en/US/support/
tsd_cisco_small_business
_support_center_contacts.html
Cisco Small Business
Firmware Downloads
www.cisco.com/go/smallbizfirmware
Select a link to download firmware for Cisco
Small Business Products. No login is
required.
Downloads for all other Cisco Small Business
products, including Network Storage
Systems, are available in the Download area
on Cisco.com at www.cisco.com/go/
software (registration/login required).
Cisco Small Business
Open Source Requests
www.cisco.com/go/
smallbiz_opensource_request
Product Documentation
Cisco Small Business
WAP121 and WAP321
Administration Guide
www.cisco.com/go/100_wap_resources
www.cisco.com/go/300_wap_resources
Cisco Small Business
Cisco Partner Central
for Small Business
(Partner Login Required)
www.cisco.com/web/partners/sell/smb
Cisco Small Business
Home
www.cisco.com/smb
9

Americas Headquarters
Cisco Systems, Inc.
170 West Tasman Drive
San Jose, CA 95134-1706
USA
www.cisco.com
Small Business Support, Global: www.cisco.com/go/sbsc
Cisco and the Cisco Logo are trademarks of Cisco Systems, Inc. and/or its affiliates in the U.S.
and other countries. A listing of Cisco's trademarks can be found at www.cisco.com/go/
trademarks. Third party trademarks mentioned are the property of their respective owners.
The use of the word partner does not imply a partnership relationship between Cisco and any
other company. (1005R)
© 2011 Cisco Systems, Inc. All rights reserved.
78-20370-01
