!IPSO!-!LSG!!n.v.
Programming
manual
Operating!instructions
Nieuwstraat!146!-!B-8560!Wevelgem!(Belgium)
Tel.!056/41!20!54!-!Fax!056/41!86!74
70288601
December!2002
Contents
1 Safety!instructions .......................................................................... 5
2 Connection....................................................................................... 6
Connection!of!the!central!panel!for!coin!operated!dryers ................ 6
Connection!of!the!serial!communication ......................................... 6
3 Setting!mode .................................................................................... 7
Setting!menu .................................................................................. 7
Setting!the!Entry!Code ................................................................... 9
Opl-dryer ........................................................................................ 11
Coin-operated!dryer ....................................................................... 19
4 Operating!instructions .................................................................... 28
Opl-dryer ........................................................................................ 28
Coin-operated!dryer ....................................................................... 30
5 Technical!remarks ........................................................................... 32
Gas!failure ...................................................................................... 32
Electronic!temperature!protection ................................................... 32
Sail!switch ...................................................................................... 32
Rotation!sensor .............................................................................. 32
6 Repair!and!after-sales!service ........................................................ 33
Content
Code:!249/00258/00
!!!!!!!!!!!!!!!!!12/12/2002
4
5
Ë
ËThese!instructions!won't!automatically!prevent!all!risks!of!accidents.!!It!is!up!to!the!user!to!act!with
utmost!care.
Do!not!hesitate!to!contact!the!dealer!in!case!of!a!probem.
Remark:
Ignoring!any!of!the!safety!instructions!can!cause!serious!perso-
nal!injury!and!can!also!cause!damage!to!the!linen!and!the!dryer.
Carefully!read!the!installation!and!operating!instructions!before!connecting!the
machine.
It!is!recommended!to!have!the!machine!installed!by!qualified!technicians.
The!installation!needs!to!be!executed!according!to!the!Installation!manual.
The!grounding!instructions!must!be!followed!in!order!to!avoid!the!risk!of
electrocution.
The!machine!may!not!be!exposed!to!high!humidity,!nor!to!extreme!high!or!low
temperatures.
The!dryer!may!not!be!used!in!a!closed-off!room!with!insufficient!air!supply.!If
necessary,!the!doors!or!windows!should!be!provided!with!a!ventilation!grate.
Cut!off!all!main!gas,!steam!and!electrical!supplies!at!the!end!of!each!operating
day.
Before!repairing!or!maintaining!the!dryer,!wait!until!the!machine!is!sufficiently
cooled!down!and!cut!off!all!supply!lines.
To!prevent!fire!and!explosion!:
-Keep!the!area!around!the!dryer!free!from!inflammable!or!combustible!products.
-Clean!the!piled-up!dust!in!and!around!the!dryer!and!fan!regularly.
If!you!detect!a!gas!smell!:
-!Immediately!cut!off!the!gas!supply!and!ventilate!the!room.
-!Do!not!switch!on!electrical!appliances!and!do!not!switch!on!any!electrical
switches.
-!Don't!ever!use!matches!or!lighters.
-!Don't!ever!use!a!telephone!in!the!same!building.
-!Notify!the!installer!as!soon!as!possible!and!the!gas!company,!if!necessary.
Always!take!into!account!the!instructions!on!the!labels!of!the!linen.
Never!allow!children!to!play!near!a!machine.
Ë
Ë
Ë
Ë
Ë
Ë
Ë
Ë
Ë
Ë
Ë
Ë
-Do!not!use!the!dryer!to!dry!material!with!a!low!melting!temperature!(PVC,!rubber,.....).
-Do!not!dry!any!products!that!still!contain!solvents!or!other!inflammable!substances.
1
Safety!instructions
6
A
230V!AC 24V!AC 24V!DC
+
_
Connection!of!the!central!operating
panel!for!coin!operated!dryers!(option)
At!right!in!the!wiring!box,!you!find!a!plate!(209/00438/00)!with!the!clamps!(A),!to
where!the!central!operating!panel!has!to!be!connected.!There!are!three!possible
versions!as!the!departure!voltage!of!the!operating!panel.
If!the!dryer!is!connected!to!a!payment!system!with!serial!communication,!this
connection!should!be!fixed!on!this!printboard!(209/00540/00)!by!means!of!an!RJ11.
Connect!the!cable!to!the!free!connector!on!the!printboard.
Connection!of!the!serial!communication!(option)
2
Connections
7
+
3
Setting!mode
The!following!buttons!have!a!specific!function!in!the!setting!menu:
-!Left!button!:!decreases!a!value.
-!Middle!button!:!confirms!a!value!and/or!continues.
-!Right!button!:!increases!a!value.
The!setting!menu!is!different!for!a!dryer!with!or!without!coinmeter.
Setting!menu
8
3
9
3
Setting!the!Entry!Code
Cod!(entry!code)
!!!Simultaneously!select!the!central!key!and!the!right!key "+".
!!!Confirm!the!selection!with!the!central!key.
When!the!machines!are!used!for!the!first!time,!the!entry!code!is!factory-set!to!123
X
Set!the!code!(first!display)!with!the!+!or -!key.!(from!0!to!9!and!from!A!to!Z,!except!for!Q-!S-!W-!X-!Z).
Confirm!the!selection!with!the!central!key.
-!Each!time!these!keys!are!pressed!and!released,!the!setting!is!increased!or!decreased!with!ONE!unit.!By!keeping!the!keys!pressed,
!!the!value!is!changed!continuously.
-!These!rules!apply!to!all!other!settings.
XX
Set!the!code!(second!display)!with!the!+!or -!key.!(from!0!to!9!and!from!A!to!Z,!except!for!Q-!S-!W-!X-!Z).
Confirm!the!selection!with!the!central!key.
XXX
Set!the!code!(second!display)!with!the!+!or -!key.!(from!0!to!9!and!from!A!to!Z,!except!for!Q-!S-!W-!X-!Z).
Confirm!the!selection!with!the!central!key.
SEt!!(Modify!the!entry!code)
Confirm!the!selection!with!the!central!key.
XXX
If!so!needed,!modify!the!code!(first!display)!with!the!+!or -!key!(from!0!to!9!and!from!A!to!Z,!except!for!Q-!S-!W-!X-!Z).
Confirm!the!selection!with!the!central!key.
XXX
If!so!needed,!modify!the!code!(second!numerical!code)!with!the!+!or -!key!(from!0!to!9!and!from!A!to!Z,!except!for!Q-!S-!W
- X-!Z).
Confirm!the!selection!with!the!central!key.
XXX
If!so!needed,!modify!the!code!(third!display)!with!the!+!or -!key!(from!0!to!9!and!from!A!to!Z,!except!for!Q-!S-!W-!X-!Z).
Confirm!the!selection!with!the!central!key.
Adr!(address)
When!the!dryer!is!connected!to!a!coin!system!in!which!the!dryers!are!put!in!a!computer!network,!enter!here!the!!dryer!address,!in
other!events,!this!parameters!does!not!have!to!be!modified.
10
3
11
oPL!of!Coin!(coin-operated!dryer)
Select!oPL!with!the!+!key!(right!key).
Confirm!the!selection!with!the!central!key.
Pnd!(type!machine)
Confirm!the!selection!with!the!central!key.
XXX
Set!the!type!of!machine!with!the!"+!key"!(right!key).
Confirm!the!setting!with!the!central!key.
HEA!(heating)
Confirm!the!selection!with!the!central!key.
StM!(steam)!or!ELE!(electrical)!or!GAS
Set!the!type!of!heating!(steam,!electrical!or!gas)!with!the!"+!key"!(right!key).
Confirm!the!setting!with!the!central!key.
°C!or °F
With!the!"+key"!(right!key),!select °C!or °F.
Confirm!the!setting!with!the!central!key.
rEV!(reversing)
Confirm!the!selection!with!the!central!key.
YES!or!no
With!the!"+!key"!(right!key),!set!Yes!or!no.
Confirm!the!setting!with!the!central!key.
3
Dryer!without!Coin!System
12
3
13
3
TE!I!(Temperature!program!1)
Press!the!middle!button!to!continue.
XX
If!necessary,!change!this!value!(default!40°C/104°F)!by!means!of!the!+!or!-!button!between!25°C/77°F!and!90°C/194°F.
-!By!pressing!and!releasing!these!buttons,!the!adjustment!is!increased!or!decreased!with!1!unit.!By!keeping!these!buttons!pressed,
the!value!is!continuously!changed.
-!These!standards!prevail!for!all!adjustments,!which!need!to!be!changed.
Value!"0"!can!be!adjusted!here!as!well!but!is!only!valid!in!case!of!dryers,!where!the!temperature!adjustment!is!being!made
by!means!of!a!knob.
Confirm!the!adjustment!by!means!of!the!middle!button.
Ti!I!(Dry!cycle!program!1)
Press!the!middle!button!to!continue.
XX
If!necessary,!change!this!value!(default!30)!by!means!of!the!+!or!-!button!between!1!and!120!minutes.
Confirm!the!adjustment!by!means!of!the!middle!button.
For!dryers!without!reversing,!the!program!goes!immediately!to!"TE2".
St!1!(Stop!time!between!left!-!right!movement!of!the!drum)
Press!the!middle!button!to!continue.
XX
Change!if!necessary!this!value!(default!5!seconds)!by!means!of!+!or!-!button!between!0!and!10!seconds.
Confirm!the!adjustment!by!means!of!the!middle!button.
When!"O"!is!filled!in,!the!program!goes!immediately!to!"TE2".!!Because!of!this,!the!program!will!be!executed!without
reversing.
AC!1!(!Action!time!of!the!drum)
Press!the!middle!button!to!continue.
XX
Change!if!necessary!this!value!(default!5!seconds)!by!means!of!the!+!or!-!button!between!5!and!120!seconds.
Confirm!the!adjustment!by!means!of!the!middle!button.
TE!2!(temperature!program!2)
Press!the!middle!button!to!continue.
XX
If!necessary,!change!this!value!(default!60°C/140°F)!by!means!of!the!+!or!-!button!between!25°C/77°F!and!90°C/194°F.
Press!the!middle!button!to!continue.
14
3
15
3
Ti!2!(dry!cycle!program!2)
Press!the!middle!button!to!continue.
XX
If!necessary,!change!this!value!(default!30)!by!means!of!the!+!or!-!button!between!1!and!120!minutes.
Confirm!the!adjustment!by!means!of!the!middle!button.
For!dryers!without!reversing,!the!program!goes!immediately!to!"TE3".
St!2!(Stop!time!between!left!-!right!movement!of!the!drum)
Press!the!middle!button!to!continue.
XX
Change!if!necessary!this!value!(default!5!seconds)!by!means!of!the!+!or!-!button!between!0!and!10!seconds.
Confirm!the!adjustment!by!means!of!the!middle!button.
When!"0"!is!filled!in,!the!program!goes!immediately!to!"TE3".!!Because!of!this,!the!program!will!be!executed
without!reversing.
AC!2!(!Action!time!of!the!drum)
Press!the!middle!button!to!continue.
XX
Change!if!necessary!this!value!(default!5!seconds)!by!means!of!the!+!or!-!button!between!0!and!120!seconds.
Confirm!the!adjustment!by!means!of!the!middle!button.
TE!3!(temperature!program!3)
Press!the!middle!button!to!continue.
XX
If!necessary,!change!this!value!(default!80°C/176°F)!by!means!of!the!+!or!-!button!between!25°C/77°F!and!90°C/194°F.
Confirm!the!adjustment!by!means!of!the!middle!button.
Ti!3!(dry!cycle!program!3)
Press!the!middle!button!to!continue.
XX
If!necessary,!change!this!value!(default!30!minutes)!by!means!of!the!+!or!-!button!between!1!and!120!minutes.
Confirm!the!adjustment!by!means!of!the!middle!button.
!For!dryers!without!reversing,!the!program!goes!immediately!to!"Cd".
St!3!(Stop!time!between!left!-!right!movement!of!the!drum)
Press!the!middle!button!to!continue.
XX
Change!if!necessary!this!value!(default!5!seconds)!by!means!of!the!+!or!-!button!between!0!and!10!seconds.
Confirm!the!adjustment!by!means!of!the!middle!button.
When!"0"!is!filled!in,!the!program!goes!immediately!to!"Cd".!!Because!of!this,!the!program!will!be!executed
without!reversing.
16
3
17
3
AC!3!(Action!time!of!the!drum)
Press!the!middle!button!to!continue.
XX
Change!if!necessary!this!value!(default!5!seconds)!by!means!of!the!+!or!-!button!between!5!and!120!seconds.
Confirm!the!adjustment!by!means!of!the!middle!button.
Cd!(Cool!down)
This!is!the!cool!down!cycle,!which!needs!to!be!executed!after!the!dry!cycle.
Press!the!middle!button!to!continue.
XX
If!necessary,!change!this!value!(default!2!minutes)!by!means!of!the!+!or!button!between!1!and!30!minutes.
Confirm!the!adjustment!by!means!of!the!middle!button.
FLS!(Flash:!alternate!description!of!the!remaining!dry!time!and!the!dry!temperature).
Press!the!middle!button!to!continue.
YES!or!no
Select!by!means!of!the!+!button.
no:!The!remaining!dry!time!will!appear!during!operation.
YES:!Besides!the!remaining!dry!time,!also!the!dry!temperature!is!appearing!alternately!during!operation.
Confirm!the!adjustment!by!means!of!the!middle!button.
TMP!(temperature!sensor!test)
Press!the!middle!button!to!continue.
XX°
The!drum!temperature!is!appearing!now!as!sensor!test.
Meanwhile!the!3!leds!are!lighting!alternately.
Press!the!middle!button!to!continue.
!!!!!in-
!!!Here!the!entries!are!checked.
!!When!coin!switch!1!is!closed,!2!will!be!displayed!on!the!screen.
!!When!coin!switch!2!is!closed,!4!will!be!displayed!on!the!screen.
!!When!the!door!is!opened,!1!will!be!displayed!on!the!screen.
!!If!the!dryer!is!equipped!with!a!sensor!measuring!the!drum!number!of!revolutions,!8!will!be!displayed!on!the!screen!if!the!drum!is
!!!rotated!!manually.
!!!When!the!sail!switch!is!closed,!16!will!be!displayed!on!the!screen.
!!!If!the!door!is!opened!and!coin!switch!1!is!closed,!(1+2=3)!3!will!be!displayed!on!the!screen.
!!!If!coin!switches!1!and!2!are!closed,!(2+4=6)!6!will!be!displayed!on!the!screen,!etc.
!!Press!the!middle!button!to!continue.
!!Now!End!is!displayed.!This!is!the!end!of!the!setting!menu.
!!!The!program!automatically!returns!to!the!beginning.
18
3
19
3
Coin-operated!dryer
oPL!or!Coin!(coin!switch)
!!!Select!Coin!with!the "+"!key.
!!!Confirm!the!selection!with!the!central!key.
C1L!(Coin!1!Low)
Press!the!middle!button!to!continue.
XX
This!is!the!drying!time!which!will!be!added!each!time!a!coin!is!inserted!in!coin!1.
Change!this!value!if!necessary!(default!10!minutes)!between!1!and!30!minutes!by!means!of!the!+!or -!button.
Confirm!the!setting!by!means!of!the!middle!button.
Remark
If!the!dryer!is!connected!to!a!system!on!which!it!is!possible!to!determine!a!different!rate!according!to!the!period!of!time!(e.g.!Sigma
explorer),!3!rates!(happy!hour)!can!be!programmed.!(Low,!Medium,!High).!!In!this!case!the!time!value!of!the!lowest!rate!is!put
in.
Press!the!middle!button.
Then!give!in!the!values!for!C1M!(coin!meter!1,!middle!rate),!C1H!(coin!meter!1,!highest!rate),!C2L!(coin!meter!2,!lowest
rate),!C2M!(coin!meter!2,!middle!rate),!C2H!(coin!meter!2,!highest!rate).
If!the!dryer!!is!equipped!with!a!double!coin!meter,!but!is!not!connected!to!a!system!that!can!determine!different!rates,!then!it!is
only!necessary!to!put!in!the!value!for!C2L!(coin!meter!2,!lowest!rate).
Add!(minimum!drying!time)
Press!the!middle!button!to!continue.
20
3
This manual suits for next models
1
Table of contents
Other Cissell Controllers manuals
