Supplied parts
EVO 1.5" / EVO 2"
1Outlet O-ring
2Outlet
3Outlet washer
4Stem washer with boss
5Outlet nut
6Cap seal
7Cap washer
8Cap nut
9Flush valve
10 IR Sensor unit
11 Sensor gasket
12 Sensor nut
13 Clamp plate
14 Screw packer
15 IR activation label
walk & wave
16 Mains transformer
17 Clamp plate fixing screw
18 Mains transformer
fixing screws
19 Battery case
20 Sticky pad
1. Introduction
EasyflushEVO is an infrared activated non-touch siphon WC flushing valve.
Available as a flush valve with a 1.5" or 2" outlet and as a flushing cistern. Non-touch activation via wave
(default) or walkaway is configurable during installation.
1
5
3
2
4
10
11
6
8
7
9
14
12
13
16
17
15
18
19
20 x4
x4
inn
) ) ) )
i
) )
nn
))
)
j
>
pp
Cistermiser
^
p
Cistermiser

Have a question? Call our customer support team on 0118 969 1611 cistermiser.co.uk | 3
EVO CISTERN
1Outlet O-ring
2Outlet
3Outlet washer
4
5
Outlet nut
6
Cap seal
7
Cap washer
8
Cap nut
9
Flush valve
10
Cistern
11
Cistern lid
12
Flush pipe
13
Inlet Valve
14
IR Sensor unit
15
Sensor gasket
16
Sensor nut
17
Clamp plate
18
Screw packer
19
IR activation label
walk & wave
20
Mains transformer
21
Clamp plate fixing screw
22
Mains transformer fixing screws
23
Battery case
Sticky pad
1
5
3
2
4
6
8
7
98
10
11
14
12
15
13
16
17
18
22
21
20
23
19
Optional extras
Infrared Configuration Unit (ICU)
Multi Product Power Supply Unit (PSUC)
Side Front Adaptor (SFA)
Extension cable (IFS/10)
x4
x4

4 | cistermiser.co.uk Have a question? Call our customer support team on 0118 969 1611
2. Valve Operation
EasyflushEVO is a siphonic flushing valve. When a flush is activated the spill over level is lowered below the
water line initiating a siphon and flushing the cistern.
Idle position Flush position
water level: 6 litre
The flush is activated by the IR Sensor unit. This can be configured to flush on a wave (default) or flush
when the user walks away:
Wave (default): Walk Away:
Memory Flush:
If a flush is activated while the cistern is refilling, the sensor will remember the flush request and only
activate when the cistern is full (to set refill time see page 12).
This is indicated by three rising green LEDs.
To Flush
1 sec Wave = Half Flush
Presence >45 sec = Full Flush
2 sec Wave = Full Flush
Auto Flush
Presence <45 sec = Half Flush
1
r
a
:
>
C
<
>
<
E
1
T
T
/

Have a question? Call our customer support team on 0118 969 1611 cistermiser.co.uk | 5
WARNING:
Cistern must be level!
3. Valve Installation
Before commencing installation, isolate mains power supply and water supply.
Fit Cistern (Cistern supplied with
EVO CISTERN only). Ensure
cistern is mounted level.
Install Outlet fitting into Cistern. Fit EVO Flush Valve to Outlet
in cistern. Secure by rotating
clockwise.
✗ ✗ ✔✔

6 | cistermiser.co.uk Have a question? Call our customer support team on 0118 969 1611
4. EasyflushEVO Valve Set up
Ensure the fill valve is adjusted so the water shuts off at the indicated water level on the flush valve. This is
your full flush volume.
The height of the EasyflushEVO flush valve water level and the filling valve float level must be at the
same height.
To adjust EasyflushEVO Fill Valve rotate
the adjuster at top of valve
EasyflushEVO Flush
Valve water level
Unlock
To adjust height of EasyflushEVO
Flushing Valve rotate upper body
clockwise to release.
Adjust
Lift or lower upper body to adjust
height.
Lock
Rotate anticlockwise to lock.
T
\
p
^
r
¥
c
¥
&
P
,

Have a question? Call our customer support team on 0118 969 1611 cistermiser.co.uk | 7
NOTES:
Do not position sensor near toilet roll holder
or disabled bar.
Reflective surfaces and materials such as
hi-vis jackets may cause the sensor to
activate unexpectedly.
Walkaway version only. Minimum distance
applies.
If x (see diagram) is less than 12cm it
is recommended that the Hand Activation is
disabled. Refer to section 9.
5. Sensor Positioning
EasyflushEVO can be operated by Wave activation (default) or Walkaway activation. The installed position of
the sensor will depend on your flush activation setting (see below).
Wave activation is the default setting and the WC will flush when the user’s hand is placed in front of the sensor.
Alternatively, with the Walkaway activation setting, the WC will automatically flush when the user leaves the cubicle.
See Config in section 12 to change the sensor activation from Wave to Walkaway.
Top
WC
Front
Side
WCWC
300 – 400mm
700 – 900mm
Exposed installation
Cistern mounted sensor
(Wave activation only, default)
Concealed installation
Panel mounted sensor
(Wave activation only, default)
Concealed installation
Panel mounted sensor
(Walkaway activation only)
x
Drill hole to the required
diameter (refer to page 8).
s
\
/
N
/
/
\
\
/
\
/
/
t
I
t
'
>
I
I
+
«
I
I
1
1
1
I
\
I
\
s
\
\
\
L
'
I
I
1
\
\
'
V
\
f
/
/
I
1
1
.
\
(
cI
5
>
l
I
l
'
I
y
y
y
I
I
I
I
l
I
I
I
I
I
I
k
'
l
1
1
I
.
I
)
:
f
i
i
i
I
'
y
,
'
i
t
\
'
V
'
v
\
\
\
s
'
/
\
/
f
\
tt
/
i
’
!
:
k
\
l
i
J
k
\
\
(
s
\
\
y
\\
\
v
y
V
\\
\
y
y
\
\
\
\
y
v
y
i
y
-
i
i
t
i
/
i
*
-
s
s
\
\
'
/
\
s
V
\
\
S
s
\
I
k
k
\
\
i
J
/
£
X
s
I
\
I
k
I
X
1
I
I
1
/
£
!
'
I
5
v
HI
\
s
s
s
/
y
/
y
i
i
i
-
i
&
i
1
>
l
1
/
i
X
I
y
i
1
i
i
i
i
y
k
i
k
1
|
i
i
\
*
V
.
