Task Force Tips YE-RF-900 Programming manual

©Copyright Task Force Tips, Inc. 2008-2014 LIY-500 May 12, 2014 Rev10
MANUAL: Remote Control (RC)
Monitor Electrical Controls
Supplemental Instructions for use with RC Monitor Manual
INSTRUCTIONS FOR INSTALLATION, SAFE OPERATION AND MAINTENANCE
DANGER Understand manual before use. Operation of this device without understanding the manual and
receiving proper training is a misuse of this equipment. Obtain safety information at www.tft.
com/serial-number
TASK FORCE TIPS, INC.
MADE IN USA • www.tft.com 3701 Innovation Way, IN 46383-9327 USA
800-348-2686 • 219-462-6161 • Fax [phone]
SECTION 4.1
Monitor Mounted
Operator Station
SECTION 4.2
Panel Mount
Operator Station
(Y4E-RP)
SECTION 4.3
Panel Mount With Display
Operator Station
(Y4E-RP-D)
SECTION 4.4
Tethered
Operator Station
(Y4E-CT-##)
SECTION 4.5
Tethered Operator Station
With Display
(Y4E-CT-##-D)
SECTION 4.6
Wireless
Operator Station
(YE-RF-##)
SECTION 4.7
Wireless Operator Station
With Display
(YE-RF-900-D)
SECTION 3.0
General Information and Specifications
SECTION 4.0
Electrical Controls Installation and Operation
SECTION 4.11
Monitor Position Display
(Y4E-DISP)
SECTION 4.12
Remote Auxiliary Function
Interface Control
(YE-REMAUX)
SECTION 4.13
Electric RC Monitor Aerial
Truck Installation
SECTION 4.16
Electric Nozzle Actuator
SECTION 4.17
Valve Kits
(YE-VK-PH)
SECTION 5.0
Troubleshooting
SECTION 4.14
Multiplex Interface Control (YE-CAN#)
SECTION 4.15
Ethernet Interface Control
SECTION 4.9
Toggle Switch Monitor
Operator Station
(Y4E-TS)
SECTION 4.10
Monitor Communication
Interface Control
(Y4E-COMM)
SECTION 4.8
Joystick
Operator Station
(Y4E-JS)

©Copyright Task Force Tips, Inc. 2008-2014 LIY-500 May 12, 2014 Rev10
2
This page intentionally left blank

©Copyright Task Force Tips, Inc. 2008-2014 LIY-500 May 12, 2014 Rev10
3
DANGER
PERSONAL RESPONSIBILITY CODE
The member companies of FEMSA that provide emergency response
equipment and services want responders to know and understand the
following:
1. Firefighting and Emergency Response are inherently dangerous activities
requiring proper training in their hazards and the use of extreme caution
at all times.
2. It is your responsibility to read and understand any user’s instructions,
including purpose and limitations, provided with any piece of equipment
you may be called upon to use.
3. It is your responsibility to know that you have been properly trained in
Firefighting and /or Emergency Response and in the use, precautions, and
care of any equipment you may be called upon to use.
4. It is your responsibility to be in proper physical condition and to maintain
the personal skill level required to operate any equipment you may be
called upon to use.
5. It is your responsibility to know that your equipment is in operable
condition and has been maintained in accordance with the manufacturer’s
instructions.
6. Failure to follow these guidelines may result in death, burns or other
severe injury.
FEMSA
Fire and Emergency Manufactures and Service Association
P.O. Box 147, Lynnfield, MA 01940 • www.femsa.org/prc.cfm
©2009 FEMSA, All Rights Reserved

©Copyright Task Force Tips, Inc. 2008-2014 LIY-500 May 12, 2014 Rev10
4
1.0 Meaning of Safety Signal Words......................................................5
2.0 Safety .................................................................................................5
3.0 General Information and Specifications.........................................5
3.1 Electrical Specifications
3.2 Electrical Controls
3.2.1 Motor Control Board (MCB)Auto Configure
3.2.2 Motor Current Limiting
3.2.3 Motor Soft Stops
3.2.4 Motor Slow/Fast Speed
3.2.5 Communication Protocol
3.2.6 Oscillate and Park Features
3.2.7 Smart Stream Technology
3.2.8 Monitor Disable Interlock
3.2.9 Monitor Sit-N-Stay Feature
3.2.10 Monitor Deploy Feature
4.0 Electrical Controls Installation and Operation...............................7
4.0.1Operator Stations
4.0.2Setting Up AMaster Operating Station
4.0.3Park Feature
4.0.3.1 Programming
4.0.3.2 Park Programming Example
4.0.3.3 Selecting Nozzle Direction During Park
4.0.4Oscillate Feature
4.0.4.1 Programming
4.0.4.2 Oscillate Pattern Retain Feature (DIP #4)
4.0.5Override Knobs
4.1 Monitor Mounted Operator Station...........................................11
4.1.1 Mounting
4.1.2 Electrical Wiring
4.1.3 Connecting Directly to Protected Power Supply
4.1.4 Operation
4.1.5 Button Overlay
4.2 Panel Mount Operator Station .................................................12
4.2.1 Mounting
4.2.2 Electrical Wiring
4.2.3 Inputs Signal Configuration
4.2.4 Panel Mount Operator Station WithAT PARK Relay
4.2.5 Operation
4.3 Panel Mount Operator Station With Display ............................15
4.3.1 Mounting
4.3.2 Electrical Wiring
4.3.3 Panel Mount Operator Station With DisplayAt Park Relay
4.3.4 ControllerArea Network (CAN) Communication Bus
2.3.4.1 CAN Wiring Configuration
2.3.4.2 CAN Bus Termination
4.3.5 Basic Operation
4.3.6 Display Controlled Operation
4.4 Tethered Operator Station .......................................................18
4.41 Mounting Storage Bracket
4.4.2 Receptacle Mounting
4.4.3 Electrical Wiring
4.4.4 Operation
4.5 Tethered Operator Station With Display ..................................20
4.51 Mounting Storage Bracket
4.5.2 Receptacle Mounting
4.5.3 Electrical Wiring
4.5.4 ControllerArea Network (CAN) Communication Bus
2.5.4.1 CAN Wiring Configuration
2.5.4.2 CAN Bus Termination
4.5.5 Basic Operation
4.5.6 Display Controlled Operation
4.6 Wireless Operator Station .......................................................23
4.6.1 Mounting Storage Bracket
4.6.2 Installing Radio/Antenna
4.6.3 Teaching ID Code
4.6.4 Changing Batteries
4.6.5 Operation
4.7 Wireless Operator Station With Display ..................................26
4.7.1 Mounting Storage Bracket
4.7.2 Installing Radio/Antenna
4.7.3 Basic Operation
4.7.4 Display Controlled Operation
4.7.5 Teaching ID Code
4.7.6 Configuration of Multiple Monitor Control
4.7.6.1 Teaching ID Code To Multiple Monitors and
Wireless Unit
4.7.6.2 Monitor Group Configuration
4.7.7 Changing Batteries
4.8 Joystick Operator Station.........................................................31
4.8.1 Mounting Storage Bracket
4.8.2 Operation
4.8.2.1 Proportional Speed Control
4.8.2.2 Monitor Deploy Feature
4.8.2.3 RC Extend-a-gun Control
4.8.3 Joystick Board Configuration
4.8.4 Gateable Valve Control
4.9 Toggle Switch Monitor Operator Station...................................34
4.9.1 Enclosure Mounting
4.9.2 Electrical Wiring
4.9.3 Operation
4.10 Monitor Communication Interface Control ...............................34
4.10.1 Enclosure Mounting
4.10.2 Electrical Wiring
4.10.3 Inputs Signal Configuration
4.10.4 Communication Interface Box WithAT PARK Relay
4.11 Monitor Position Display...........................................................35
4.11.1 Enclosure Mounting
4.11.2 Electrical Wiring
4.11.3 Programming Display
4.12 RemoteAUXiliary Function Interface Control ..........................37
4.12.1 Enclosure Mounting
4.12.2 Electrical Wiring
4.12.3 Configuration
4.13 Electric RC MonitorAerial Truck Installation............................38
4.13.1 Electronics Enclosure Mounting
4.13.2 Electrical Wiring
4.13.2.1 Ladder Installation Electrical Wiring
4.13.2.2 Platform Installation Electrical Wiring
4.13.3 Electrical Enclosure WithAT PARK Relay
4.13.3.1 Electric Connections
4.13.4 Electrical Enclosure With Inhibit Input
4.14 Multiplex Interface Control (YE-CAN#).....................................41
4.15 Ethernet Interface Control........................................................41
4.15.1 Interface Enclosure Mounting
4.15.2 Electrical Wiring
4.15.3 Default Nerwork Settings
4.16 Electric Nozzle Actuator ..........................................................43
4.16.1 Wiring
4.16.2 Operation of Flush, Fog, Stream
4.17 Valve Kits ................................................................................44
4.17.1 Valve Mounting
4.17.2 Interface Enclosure Mounting
4.17.3 Electrical Wiring
4.17.4 Configuration
5.0 Troubleshooting..............................................................................46
6.0 Warranty............................................................................back cover
Table Of Contents

©Copyright Task Force Tips, Inc. 2008-2014 LIY-500 May 12, 2014 Rev10
5
1.0 MEANING OF SAFETY SIGNAL WORDS
Asafety related message is identified by a safety alert symbol and a signal word to indicate the level of risk involved with a particular
hazard. Per ANSI standard Z535.6-2011, the definitions of the four signal words are as follows:
DANGER DANGER indicates a hazardous situation which, if not avoided, will result in death or serious
injury.
WARNING WARNING indicates a hazardous situation which, if not avoided, could result in death or serious
injury.
CAUTION CAUTION indicates a potentially hazardous situation which, if not avoided, could result in minor
or moderate injury.
NOTICE NOTICE is used to address practices not related to physical injury.
3.0 GENERAL INFORMATION AND SPECIFICATIONS
3.1 ELECTRICAL SPECIFICATIONS
Nominal operating voltage: 12 or 24 VDC (auto sense)
Motor current: Nominal* Limit
@ 12 VDC @24 VDC @ 12 VDC @24 VDC
Elevation motor: 6 amps 3 amps 15 amps 7.5 amps
Horizontal rotation motor: 6 amps 3 amps 10 amps 5 amps
Nozzle motor: 1 amp 0.5 amps 5 amps 2.5 amps
*with rated water pressure applied
At rest current: .25 amps @ 12 VDC
Recommended fuse size: 15 amps @ 12 volts, 7.5 amps @ 24 volts
Operating temperature range: -30F to +120F (-34C to +49C)
Environmental Rating: All components designed to meet minimum rating of NEMA 4 (IP65) except the Joystick which
is intended for dry service within the interior of a cab.
WIRELESS OPERATOR STATION (YE-RF-##) YE-RF-900 & YE-RF-900-D, 900 MHz YE-RF-2400, 2.4 GHz
Handheld Unit Batteries Four (AA) Batteries, Lithium Recommended
Transmitting Power 100mW 50mW
Operating Range 500 ft (152m)
Operating Frequency 900 MHz
(902-928 MHz) 2.4GHz (2.4000-2.4835 GHz)
Agency Approvals
FCC MCQ-XBPS3B OUR24XSTREAM
Industry Canada (IC) 1846A-XBPS3B 4214A-12.008
Europe N/A ETSI
YE-RF-900 & YE-RF-900-D CONTAINS FCC ID: MCQ-XBPS3B THE ENCLOSED DEVICE COMPLIES WITH PART 15 OF THE FCC RULES. OPERATION IS
SUBJECT TO THEFOLLOWING TWO CONDITIONS: (1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE AND (2) THIS DEVICE MUST ACCEPT ANY
INTERFERENCE RECEIVED, INCLUDING INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION.
YE-RF-2400 CONTAINS FCC ID: OUR-24XSTREAM THE ENCLOSED DEVICE COMPLIES WITH PART 15 OF THE FCC RULES. OPERATION IS SUBJECT TO THE
FOLLOWING TWO CONDITIONS: (1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE AND (2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE
RECEIVED, INCLUDING INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION.
2.0 SAFETY
WARNING The RC monitor control boxes and motors are not rated as ignition proof, explosion proof, or
intrinsically safe. Install in locations with adequate ventilation and no hazard of flammable vapor
buildup.
WARNING Disconnect power before installing or servicing the monitor to avoid electrical shock or injury
from moving parts.
WARNING Remote controlled equipment moves without warning placing nearby persons at risk of pinch
points, loss of footing, or stream impact. Assume command of remote operation only after safe
zones are established. Keep clear of powered equipment when the controls are energized.

©Copyright Task Force Tips, Inc. 2008-2014 LIY-500 May 12, 2014 Rev10
6
3.2 ELECTRICAL CONTROLS
The electric TFT RC monitor is controlled by a very powerful, state-of-the-art electronics system. The key components of the system
are the motor control boards and a communication board. Each motor control board has its own microprocessor and a sophisticated
motor control chip. The communication board also has a microprocessor, which handles the interface to the operator stations. All the
components on these boards are solid state; there are no relays or electromechanical devices to wear out over time. The hardware
and software have been designed with several key features:
3.2.1 MOTOR CONTROL BOARD (MCB) AUTO CONFIGURE
Each monitor has three MCBs, one for each motor.The MCB controls motor movement and direction for horizontal rotation, elevation,
and nozzle pattern. In the unlikely event of a MCB failure, the failed board can be removed and one of the other two remaining MCBs
can be moved into that position. This MCB will then auto configure itself to take over the control of that axis, so that the monitor can
continue to be used, with two of the three motors. This is also a helpful benefit when troubleshooting and requires fewer spare parts
to be stocked.
3.2.2 MOTOR CURRENT LIMITING
The microprocessor on the MCB continuously monitors the motor current. As the motor reaches an end stop or if there is an
obstruction, the motor current rises very quickly and the motor control chip automatically shuts down the motor in a few milliseconds.
This eliminates the need for any type of external limit switches and the associated wiring. The microprocessor also locks the operator
from moving in the stopped direction again, until the operator first moves in the opposite direction.
3.2.3 MOTOR SOFT STOPS
The horizontal and vertical motors are equipped with feedback encoders which allow the microprocessor to know the motor position
at all times. The first time a motor reaches an end stop or strikes an obstruction, the microprocessor sets a new soft stop position just
before the end stop. From that point on, when the axis approaches the stop, the MCB automatically slows down the motor until the
end stop is reached. This significantly reduces the wear on the motor, gearbox, and gear drives.
3.2.4 MOTOR SLOW/FAST SPEED
When an operator presses one of the buttons, the associated motor starts in low speed mode for accurate control of the water
stream. For Tornado Monitors, after approximately ½ second the motor automatically ramps up to high speed, for quickly moving into
position. For all other monitors, the speed ramps up after 2 seconds. When quickly changing directions, monitor remains at speed of
prior move. If low speed is selected, monitor does not ramp to high speed but remains in low speed.
3.2.5 COMMUNICATION PROTOCOL
The communication from the monitor to the operator stations is performed over two wires using RS-485 serial protocol. Multiple
operator stations can be added with only two wires for power and two wires for the RS-485 protocol between each station.
3.2.6 OSCILLATE AND PARK FEATURES
The OSCILLATE feature allows the user to program up to 65 points of continuous movement of the horizontal and vertical axes. The
OSCILLATE pattern can be programmed from any operator station that has the OSC button.
The PARK feature allows the user to move the monitor, with one touch of a button, to a safe position before moving the fire truck.
The monitor will always move to two end stops to verify the correct position. During the programming procedure, the user has the
ability to select which axis moves first. This is helpful to avoid lights, hoses, obstructions, etc. The user can program up to 10 points
of movement to reach the final park position. The PARK pattern can be programmed from any operator station that has low profile
keypad buttons. A relay contact is available for connection to the truck alarm
3.2.7 SMART STREAM TECHNOLOGY
This technology, only available with TFT RC nozzles, utilizes a position encoder in the nozzle actuator to give the user greater control
on the stream pattern, especially at FOG position. Nozzles equipped with a FLUSH position are programmed to stop and pause at
full FOG position when moving towards the FLUSH position, preventing unwanted water flow.Asecond press on the button will cause
the nozzle shaper to continue to move to FLUSH position for removing debris from the nozzle.
3.2.8 MONITOR DISABLE INTERLOCK
This feature, only available with TFT RC Extend-A-Guns and Ladder/Platform versions of monitors, provides an interlock for RC
monitors that are installed on trucks in extremely confined spaces. This interlock can also be used to prevent a RC monitor from
moving and potentially damaging surrounding equipment. TFT RC Extend-A-Guns are shipped with the Monitor Disable Interlock
feature enabled. This feature prevents the monitor from moving when the RC Extend-A-Gun is in the retracted position. Ladder/
Platform versions of monitors require a signal wired to an inhibit input in the aerial electronics interface box. Once active this interlock
will prevent the monitor from damaging the apparatus that the monitor is installed on and prevent operator error from causing costly
damage.
3.2.9 MONITOR SIT-AND-STAY FEATURE
Once the PARK pattern has been performed, the monitor will enter an active state of checking axis positions. If road vibration causes
the axes to move or an operator tries to move the manual override knob, the motor control boards will command the motors back to
the PARK axis position. This feature can be cancelled by hitting any of the movement buttons on the membrane switch. This feature
is not disabled by the INHIBIT interlock feature. Power must be applied to the RC monitor for this feature to remain active.

©Copyright Task Force Tips, Inc. 2008-2014 LIY-500 May 12, 2014 Rev10
7
3.2.10 MONITOR DEPLOY FEATURE
This feature available through YE-CAN1 Multiplex Interface Control, Y4E-JS Joystick Operator Station, Y4E-RP-D Panel Mount
Operator Station with Display, Y4E-CT-##-D Tether Operator Station with Display, and YE-RF-##-D Wireless Operator Station with
Display, will move the RC monitor horizontal & vertical axes to a predetermined position. This feature is useful to quickly move the
monitor from a PARK position into an attack position, ready for water flow. Initiating a DEPLOY movement will command each axis
to 50% of their overall travel limits.
IMPORTANT Review these sections and decide on locations before starting installation process.
4.0 Electrical Controls Installation
4.1 Monitor Mounted Operator Station
4.2 Panel Mount Operator Station (Y4E-RP)
4.3 Panel Mount Operator Station with Display
(Y4E-RP-D)
4.4 Tether Operator Station (Y4E-CT-##)
4.5 Tether Operator Station with Display(Y4E-CT-##-D)
4.6 Wireless Operator Station (YE-RF-##)
4.7 Wireless Operator Station with Display (YE-RF-##-D)
4.8 Joystick Operator Station (Y4E-JS)
4.9 Toggle Switch Monitor Operator Station (Y4E-TS)
4.10 Communication Interface Control (Y4E-COMM)
4.11 Monitor Position Display (Y4E-DISP)
4.12 Remote Auxiliary Function Interface Control
(YE-REMAUX)
4.13 Aerial (Ladder & Platform) Controls
4.14 Multiplex Interface Control (YE-CAN#)
4.15 Ethernet Interface Control (YE-ETHER)
4.16 Electric Nozzle Actuator
4.17 Valve Kits (YE-VK*)
4.0 ELECTRICAL CONTROLS INSTALLATION AND OPERATION
The electric RC monitor is supplied with a monitor mounted operator station. The wiring on the monitor and for this operator station
is factory installed. The assembly is supplied with a cable for connection to the operator control stations as shown in Figure 4.0 or
directly to a protected voltage supply. This cable has 4-conductors which supply power and the communications from the operator
stations to the monitor. To complete the installation, the installer will need to mount and wire the selected operator stations. The
power supply for the monitor will need to be connected to a protected circuit from the truck’s power distribution center. Refer to the
specifications section 3.1 for nominal current draw.
For installations where the customer would like to turn off the voltage to the monitor independent of the truck master switch, the
installer needs to install a SPST (single-pole single-throw) toggle switch. Install this toggle switch in a location that can quickly be
accessed before using the RC monitor. The toggle switch needs to be wired between the protected voltage supply and the red wire
feeding the RC monitor.
NOTICE INSTALLATION AND SERVICE PRACTICES
• Disconnect power before installing or servicing the electrical components to avoid electrical shock hazard or injury due to moving
parts.
• Provide adequate power supply for all electrical controls and motors taking into account voltage drops on wiring. See section 3.1
for electrical specifications.
• Careful selection of wiring is critical to avoid excessive voltage drop.
• Good mechanical connections on the wires are absolutely necessary and should be checked periodically. Poor electrical
connections can cause power loss to the electric RC monitor and be a fire hazard.
• Be careful to route cables and controls in protected areas away from high heat sources.
• Use grommets whenever wires pass through holes to prevent damage due to snags, abrasions, etc.
• Secure cables close to control box with plastic wire ties or cable clamps to relieve stress on the cables.
• Observe precautions for electrostatic sensitive devices when installing or servicing controls. Touch fingers to bare metal surface
before handling control boards to dissipate static electricity.
• Make sure that all control covers and gaskets are restored to their original condition after installation or servicing to maintain
weather tight seal.
Recommended Tool List - 11/32” nut driver - Wire cutter/stripper - Terminal crimping tool - Utility knife - 20mm open-end box wrench
- 17mm open-end box wrench - 5/32” drill bit - 25/32” drill bit - #2 Phillips screwdriver - Small flat blade screwdriver
IMPORTANT - When mechanical installation and electrical connections are complete, perform the following test to verify voltage
supply is adequate and the current limiting feature is functioning.
1) Apply power to monitor control box.
2) Press LEFT or RIGHT button and hold until monitor reaches its stop position. Continue to hold button down.
3) Once movement is stopped, manually turn override knob in opposite direction while continuing to hold button down. If knob can
be turned, then voltage supply is adequate. If knob cannot be turned and motor continues to operate, then the voltage supply or
wiring is not adequate. Check connections and voltage connection point, rewire if necessary. NOTE: Override knob will only
turn in one direction.

©Copyright Task Force Tips, Inc. 2008-2014 LIY-500 May 12, 2014 Rev10
8
12VDC
Nominal System 24VDC
Nominal System
Minimum voltage @ Monitor 9 volts 18 volts
Monitor current draw 10 amps 5 amps Factory supplied cable drop 1 ½ volts ¾ volt
Recommended Cable Gauge
Max Length of Installer Power Cable
In Addition to TFT Supplied Power Cable
Gauge 12VDC
Nominal System
14AWG 37ft (11m) 200ft (61m)
12AWG 61ft (18m) 328ft (100m)
2-14AWG 75ft (23m) 400ft (122m)
10AWG 97ft (30m) 522ft (159m)
2-12AWG 122ft (37m) 657ft (200m)
24VDC
Nominal System
To avoid excessive voltage drop at monitor operator station, do not lengthen factory supplied monitor cable. Power cable selection is critical. Voltage supplied to MONITOR should not fall below value listed in table when monitor is in operation.
NOTICE
2/C-14, 2/C-20
30 ft (9 m) supplied
INSTALLER SUPPLIED
TERMINAL BOX
RED RED
BLACK BLACK
BLUE BLUE
WHITE WHITE
RED
BLACK
TYPICAL TERMINAL BOX
CONNECTIONS
INSTALLER SUPPLIED
POWER CABLE
**See Note
TOGGLE SWITCH OPERATOR
STATION (sec 4.9)
COMMUNICATION INTERFACE BOX (sec 4.10)
MULTIPLEX INTERFACE CONTROL (sec 4.14)
ETHERNET INTERFACE CONTROL (sec 4.15)
JOYSTICK OPERATOR
STATION (sec 4.8)
POSITION DISPLAY
(sec 4.11)
TETHER OPERATOR
STATION (sec 4.4 & sec 4.5)
PANEL MOUNT OPER.
STATION (sec 4.2 & sec 4.3)
WIRELESS OPERATOR
STATION (sec 4.6 & sec 4.7) BLUE
WHITE
- or -
MULTIPLE OPERATOR STATIONS MAY BE INSTALLED.ALL
COMMUNICATION PAIRS (BLUE & WHITE) AND POWER
PAIRS (RED & BLACK) MUST BE CONNECTED IN TERMINAL
BOX OR ANOTHER OPERATOR STATION.
INSTALLER SUPPLIED
AUXILIARY FUNCTIONS:
WATER VALVE
LIGHTS
REMOTE AUX FUNCTION RELAY INTERFACE
(sec 4.12)
* * * * * *
* 2/C-14, 2/C 20 CABLE
NO WIRING REQUIRED
RC HURRICANE RC MONSOON RC TORNADO RC TYPHOON
INSTALLER SUPPLIED INPUTS:
J1939 CANBUS
SWITCHES
ETHERNET
Fig. 4.0
ELECTRICAL COMPONENTS
(non-aerial installation)

©Copyright Task Force Tips, Inc. 2008-2014 LIY-500 May 12, 2014 Rev10
9
4.0.1 OPERATOR STATIONS
The electric RC monitor has five different styles of operator stations for use in various locations on the fire truck or fire ground.
The design of the operator station communications allows users to override commands on other stations. The “last” button pressed
has control. The overridden user can regain control by releasing his/her button and pressing again.
Platform and ladder electronics enclosures are pre-configured for one set of inputs to have a master override feature. The operator
station connected to these inputs, typically at the base of the ladder, will override any other operator station.
Any operator station with a communication board or connected to a communication board can be field configured with the master
override feature. This allows the user to setup an operator station on the fire truck or fire ground as the master override station.
4.0.2 SETTING UP A MASTER OPERATING STATION
Any remote operator station or interface board can be re-configured to override
all other operator stations. These stations include the Y4E-RP, Y4E-RP-D,
Y4E-CT-##, Y4E-CT-##-D, Y4E-TS, Y4E-JS, YE-RF-##, YE-RF-##-D, or any
inputs connected to an interface box such as Y4E-COMM or ladder/platform
enclosures.
Note: A master station will override another master station.
To enable the master override feature, follow these steps:
1. Ensure power is OFF to the unit.
2. Remove lid from enclosure.
3. Locate configuration DIP switches on circuit board.
4. Slide DIP switch #1 to the ON position for a master station.
5. Replace lid. Verify rubber seal is clean and undamaged. Verify that no
wires are caught between lid and box.
1 2 3 4
ON
Figure 4.0.2
Master Override Setup
4.0.3 PARK FEATURE
The PARK position needs to be programmed during installation. The monitor needs to “find” two (2) hard stops, one for each axis,
before the monitor can move to the PARK position. When programming, the first two commands teach the monitor where to find the
hard stops. This guarantees that the position is accurate. From that point, the programmer can program the move to the final PARK
position.
During normal operation, each time the PARK button is pressed, the monitor moves the nozzle to the full straight stream position,
moves to each programmed hard stop, and then moves to the PARK position. While the monitor is performing the PARK feature,
pressing any button will stop the monitor. If the installer prefers to have the nozzle move to the full fog position during the PARK
pattern, see section 4.0.3.3.
RECOMMENDED PARK POSITION: For truck mounted applications, it is recommended that the monitor be parked in a position
such that the monitor’s nozzle rests against a bracket or support surface. This will minimize bouncing of the nozzle when the
apparatus is traveling. Always be sure the monitor is properly parked before moving the truck and know the overall height to avoid
damage from overhead obstructions such as doors or bridges.
NOTE: Depending on the manufactured date, it may be necessary to deploy the Extend-A-Gun in order to enter PARK programming
mode.
4.0.3.1 PROGRAMMING PARK PROGRAMMING MUST BE INITIATED
WITHIN 1 MINUTE OF APPLYING POWER TO MONITOR.
After 1 minute, programming access is blocked. Power must then be cycled to reset 1 minute timer.
Press and hold PARK button (~10 seconds) until light blinks. Release button. Light will continue to blink while in program mode.
FIRST AXIS TO MOVE:
Press and release LEFT/RIGHT or UP/DOWN button of axis that will move to first hard stop. Light will blink rapidly when hard stop
is reached.
SECOND AXIS TO MOVE:
Press and release LEFT/RIGHT or UP/DOWN button of axis that will move to second hard stop. Light will blink rapidly when hard
stop is reached.
MOVE TO PARK POSITION:
Press and hold the LEFT/RIGHT or UP/DOWN buttons to move monitor to first point of park routine, press and release PARK button.
Light will blink rapidly to acknowledge position.
Repeat until pattern is complete (up to 10 points).
Press and hold PARK button until light turns off. Release button.

©Copyright Task Force Tips, Inc. 2008-2014 LIY-500 May 12, 2014 Rev10
10
4.0.3.2 PARK PROGRAMMING EXAMPLE
- Press and hold PARK button until light blinks.
- Press and release UP button, monitor will move until hard stop reached. (light blinks rapidly.)
- Press and release RIGHT button, monitor will move until hard stop reached. (light blinks rapidly.)
- Press LEFT button to move 45 degrees, Press and release PARK button. (light blinks rapidly.)
- Press DOWN button to move 90 degrees, Press & release PARK button. (light blinks rapidly.)
- Press and hold PARK button until light turns off.
4.0.3.3 SELECTING NOZZLE DIRECTION DURING PARK
By default, the nozzle will move to the full straight stream position.
To select nozzle movement to the full fog position during PARK pattern, do the following:
- Enter PARK programming mode as indicated in section 4.0.3.1.
- Once PARK light is flashing, Press FOG button for 1 second and release.
- Continue with PARK pattern programming as outlined in section 4.0.3.1.
To change back to the full straight stream position during PARK pattern, do the following:
- Enter PARK programming mode as indicated in section 4.0.3.1.
- Once PARK light is flashing, Press STRAIGHT STREAM button for 1 second and release.
- Continue with PARK pattern programming as outlined in section 4.0.3.1.
4.0.4 OSCILLATE FEATURE
The OSCILLATE feature allows the user to program a repeating pattern to control the horizontal and vertical axes of the monitor.
While in the OSCILLATE pattern, the monitor will pause while the user changes the stream pattern. Pressing any other button will
stop the OSCILLATE pattern.
A label is supplied with each operator station that can be mounted on or near the station as a reminder of how to program the
OSCILLATE pattern. The OSCILLATE pattern needs to be programmed before use. The pattern will be cleared each time power
is cycled to the monitor. For fixed monitors, the monitor may be configured to store the program permanently. See Section 4.0.4.2.
NOTE: Depending on the manufactured date, it may be necessary to deploy the Extend-A-Gun in order to enter OSCILLATE
programming mode.
4.0.4.1 PROGRAMMING
- Move monitor to starting point of pattern.
- Press and hold OSC button (~5 seconds) until light
blinks. Release button. Light will continue to blink while
in program mode.
- Move monitor to second point, press and release OSC
button. Light will blink rapidly to acknowledge position.
- Repeat until pattern is complete (up to 65 points).
- Press and hold OSC button until light turns off. Release
button.
OSCILLATE PATTERN PROGRAMMING:
1)
2)
3)
4)
5)
Move monitor to starting point of pattern.
Press & hold OSC button until LED blinks. LED will continue to blink in program mode.
Move monitor to 2nd point, press OSC button. LED will blink rapidly to acknowledge position.
Repeat until pattern is complete.
Press & hold OSC button until LED turns off.
NOTE: PATTERN WILL BE CLEARED UPON POWER LOSS.
TO OSCILLATE:
Pattern must be programmed first.)
Press & release OSC button.
(
TO PARK:
Press & release PARK button.
(Programmable, refer to manual.)
Y5705
800-348-2686
www.tft.com
Æ
TASK FORCE TIPS
FIRE FIGHTING EQUIPMENT
Figure 4.0.4.1
Oscillate Programming Label
4.0.4.2 OSCILLATE PATTERN RETAIN FEATURE (DIP #4)
The monitor can be configured so that upon power down,
the OSCILLATE pattern is retained. The OSCILLATE
pattern must be programmed at least one time (see section
4.0.4.1). To enable the OSCILLATE pattern retain feature
follow these steps:
1. Ensure power is OFF to the unit.
2. Remove lid from monitor operator station.
3. Locate DIP switches on communication board.
4. Slide DIP switch #4 to the ON position.
5. Verify rubber seal is clean and undamaged. Verify that
no wires are caught between lid and box. Replace lid.
6. Program OSCILLATE pattern.
1 2 3 4
ON
Figure 4.0.4.2
Oscillate Pattern Retain Setup
4.0.5 OVERRIDE KNOBS
In the event of electrical system failure on the monitor or fire apparatus, the TFT RC Monitor is factory supplied with override knobs
so the monitor may be manually operated. If desired, the override knobs may be removed. The drive shafts have a hex so a wrench
or socket may be used for manual override.

©Copyright Task Force Tips, Inc. 2008-2014 LIY-500 May 12, 2014 Rev10
11
4.1 MONITOR MOUNTED
OPERATOR STATION
This operator station is factory installed and wired to the monitor. It allows the monitor to be controlled at the monitor location.
4.1.1 MOUNTING
Operator station is factory installed on the monitor and requires no additional mounting.
4.1.2 ELECTRICAL WIRING
See fig. 4.0 for typical connections. The wiring on the monitor and for this operator station is factory installed. The assembly is
supplied with a cable for connection to the other operator control stations. The cable has 4-conductors which supply power and the
communications from the operator stations to the monitor.
4.1.3 CONNECTING DIRECTLY TO PROTECTED POWER SUPPLY
The electric RC monitor has an operator station, which is fully functional, mounted on the monitor. If no other operator stations are
selected, with the exception of the wireless radio remote, the installer will only need to connect power to complete the installation.
Route cable from monitor and connect to a protected circuit from the truck’s power distribution center. Connect the red wire to positive
and the black wire to negative (ground). Cut and discard blue and white wires.
4.1.4 OPERATION
This operator station is factory installed on the monitor and is used by personnel at the monitor.
OSCILLATE button used to
initiate monitor movement
through stored sequence
(pattern) or to program a
sequence (pattern).
Read manual before use.
WARNING
800-348-2686
Y5700
FLASHING = LOW BATT
®
ON
FLOW
OFF
OSCILLATE PARK
UP
MONITOR
DOWN www.tft.com
POWER
NO COMMUNICATION LINK
WHENALTERNATING P
PARK button used to initiate
monitor storage sequence
or to program storage
movements.
FOG button used to move
nozzle pattern to wide and
short reach.
STRAIGHT STREAM button
used to move nozzle pattern
to narrow and long reach.
LEFT button used to rotate
(sweep) water stream from
right to left from starting
point.
UP button used to move
water stream vertically up
from starting point.
DOWN button used
to move water stream
vertically down from
starting point.
RIGHT button used to rotate
(sweep) water stream from
left to right from starting
position.
MONITOR UP/DOWN
button typically used to
control RC Extend-AGun.
Also known as the AUX1
button. Could also be used
with YE-REMAUX relay
interface box to control
other devices.
FLOW ON/OFF button
typically used to control
RC Valve Kit or VUM. Also
known as the AUX2 button.
Could also be used with YE-
REMAUX relay interface box
to control other devices.
Fig. 4.1.4
Operator Station Control Pad
4.1.5 BUTTON OVERLAY
Each monitor and operator station is shipped with several button overlays with adhesive that can be used to cover the button text
on the lower two buttons. This can be done in applications that do not have either an RC Extend-A-Gun or RC valve kit. If additional
overlays are needed, contact the factory.
Clean operator station surface to remove any oils or residues. Carefully peel off overlay and place on top of AUX button, just inside
blue border of the button.

©Copyright Task Force Tips, Inc. 2008-2014 LIY-500 May 12, 2014 Rev10
12
4.2 PANEL MOUNT
OPERATOR STATION
(Y4E-RP)
This operator station allows the monitor to be controlled from a remote location. The installer will need to mount the operator station
and connect the cable to the monitor and power. The enclosure is designed to be recessed mounted in a panel.
This operator station has extra power and communication terminal blocks available and can be used as a central location for
terminating wires. In this type of installation the monitor cable, the power cable, and possibly other operator station cables could be
installed into this operator station. On the back of this enclosure are extra strain relief fittings.
In many installations this operator station will also include the wiring connections for the joystick, Canbus output module or installer
supplied toggle switches. A terminal block is available for “UP, DOWN, LEFT, RIGHT, FOG, SS, PARK” inputs. The circuit board in
this operator station is factory configured to accept +12/24 volt DC inputs input signals but can be field changed to accept ground
input signals. Before January 1, 2011 After January 1, 2011
5-1/8
(130 mm)
7-7/16
(190 mm)
4-5/8” [135.9mm]
PANEL
CUT-OUT
DIMENSIONS
Ø 7/32" [5.6mm]
(4) PLACES
OR TAP FOR
10-24 UNC THREAD
6-3/8” [172.0mm]
4-1/2” [128.6mm]
6-3/4” [192.9mm]
Figure 4.2
Panel Mount Operator Station Cutout Dimensions
4.2.1 MOUNTING
Select proper operator location. Select proper operator location. Panel space required will be 5” x 7-1/4” (127 x 185mm). A depth of
2” (50mm) will be required behind the panel. Refer to Figure 4.2 for cutout dimensions. Allow at least 6” of slack in cable for future
repairs.
4.2.2 ELECTRICAL WIRING
See figure 4.0 for typical connections. The 4-conductor cable from the operator station needs to be connected to power (red & black)
and to the communication link (blue & white) from the monitor. Refer to Figure 4.2.2 for typical cable preparation. Be sure to tighten
all terminal block screws securely.
TIGHTEN DOME NUT
TO 37 IN-LBS (4.2 N-M) STRIP 1/4" (6mm)
OF INSULATION
REMOVE 6" (150mm) OF
JACKETAND TEFLON TAPE
1/8" (3mm) OF CABLE JACKET
PAST FITTING NOTE:
CABLE IS GEL FILLED TO PREVENT MOISTURE WICKING
INTO ENCLOSURE. GEL IS NON-HAZARDOUS AND
SHOULD BE WIPED OFF CONDUCTORS WITHA RAG.
Fig 4.2.2
Typical Cable Preparation

©Copyright Task Force Tips, Inc. 2008-2014 LIY-500 May 12, 2014 Rev10
13
4.2.3 INPUTS SIGNAL CONFIGURATION
The Panel Mount Operator Station is shipped from the factory configured to accept +12/24 volt DC input signals, but can be field
changed to accept ground input signals. To change the configuration:
1. Ensure power is OFF to the unit.
2. Remove lid from enclosure.
3. Locate DIP switches on communication board.
4. Slide DIP switch #4 to the OFF position to select GROUND inputs or slide to the ON position to select VOLTAGE inputs.
5. Verify rubber seal is clean and undamaged. Verify that no wires are caught between lid and box. Replace lid.
Figure 4.2.3
Panel Mount Operator Station
VOLTAGE
INPUTS GROUND
INPUTS
Figure 4.2.4
Relay / Terminal Location
AT PARK RELAY
USER TERMINALS
AT
PARK
PARK
INPUTS
ON
1 2 3 4
ON
1 2 3 4
4.2.4 PANEL MOUNT OPERATOR STATION WITH AT PARK RELAY (Y4E-RP)
The Panel Mount Operator Station provides feedback for the user that the monitor is in the AT PARK position. The Operator station
contains a circuit board that is equipped with a relay that is energized when the monitor is in use and de-energized when the monitor
reaches its final PARK location. The contact rating of the relay is 1 amp @ 30VDC for resistive loads and 0.2 amps @ 30VDC for
inductive loads.
The AT PARK relay has one Form-C contact (common, normally open, normally closed) that can be used. The figure above shows
the terminal blocks available for user wiring.

©Copyright Task Force Tips, Inc. 2008-2014 LIY-500 May 12, 2014 Rev10
14
4.2.5 OPERATION
This operator station is installed on the truck, for example the pump operator’s panel. It is used to operate the monitor from a location
on the truck.
OSCILLATE button used to
initiate monitor movement
through stored sequence
(pattern) or to program a
sequence (pattern).
Read manual before use.
WARNING
800-348-2686
Y5700
FLASHING = LOW BATT
®
ON
FLOW
OFF
OSCILLATE PARK
UP
MONITOR
DOWN www.tft.com
POWER
NO COMMUNICATION LINK
WHENALTERNATING P
PARK button used to initiate
monitor storage sequence
or to program storage
movements.
FOG button used to move
nozzle pattern to wide and
short reach.
STRAIGHT STREAM button
used to move nozzle pattern
to narrow and long reach.
LEFT button used to rotate
(sweep) water stream from
right to left from starting
point.
UP button used to move
water stream vertically up
from starting point.
DOWN button used
to move water stream
vertically down from
starting point.
RIGHT button used to rotate
(sweep) water stream from
left to right from starting
position.
MONITOR UP/DOWN
button typically used to
control RC Extend-AGun.
Also known as the AUX1
button. Could also be used
with YE-REMAUX relay
interface box to control
other devices.
FLOW ON/OFF button
typically used to control
RC Valve Kit or VUM. Also
known as the AUX2 button.
Could also be used with YE-
REMAUX relay interface box
to control other devices.
Fig. 4.2.5
Operator Station Control Pad

©Copyright Task Force Tips, Inc. 2008-2014 LIY-500 May 12, 2014 Rev10
15
4.3 PANEL MOUNT
OPERATOR STATION
WITH DISPLAY
Y4E-RP-D
This operator station allows the monitor to be controlled from a remote location. The installer will need to mount the operator station
and connect the cable to the monitor and power. The enclosure is designed to be mounted on top of a panel control station.
This operator station has an extra power and communication connection point available and can be used as a central location for
terminating wires from the monitor. In this type of installation the monitor cable and the power cable could be installed into this
operator station. On the back of this enclosure are extra strain relief fittings.
4.3.1 MOUNTING
Select proper operator location. Panel space required will be 5” x 7-1/4” (127 x 185mm).Adepth of 2” (50mm) will be required behind
the panel. Refer to Figure 4.3.1 for cutout dimensions. Allow at least 6” of slack in cable for future repairs.
4-5/8” [135.9mm]
PANEL
CUT-OUT
DIMENSIONS
Ø7/32" [5.6mm]
(4) PLACES
OR TAP FOR
10-24 UNC THREAD
6-3/8” [172.0mm]
4-1/2” [128.6mm]
6-3/4” [192.9mm]
Figure 4.3.1
Panel Mount Operator Station with Display Cutout Dimensions
4.3.2 ELECTRICAL WIRING
See Figure 4.0 for typical connections. The 4-conductor cable from the operator station needs to be connected to power (red & black)
and to the communication link (blue & white) from the monitor. Be sure to tighten all terminal block screws securely.
TIGHTEN DOME NUT
TO 37 IN-LBS (4.2 N-M) STRIP 1/4" (6mm)
OF INSULATION
REMOVE 6" (150mm) OF
JACKETAND TEFLON TAPE
1/8" (3mm) OF CABLE JACKET
PAST FITTING NOTE:
CABLE IS GEL FILLED TO PREVENT MOISTURE WICKING
INTO ENCLOSURE. GEL IS NON-HAZARDOUS AND
SHOULD BE WIPED OFF CONDUCTORS WITHA RAG.
Fig 4.3.2
Typical Cable Preparation

©Copyright Task Force Tips, Inc. 2008-2014 LIY-500 May 12, 2014 Rev10
16
4.3.3 PANEL MOUNT OPERATOR STATION WITH DISPLAY AT PARK RELAY
The Panel Mount Operator Station provides feedback for the user that the monitor is in the AT PARK position. The Operator station
contains a circuit board that is equipped with a relay that is energized when the monitor is in use and de-energized when the monitor
reaches its final PARK location. The contact rating of the relay is 1 amp @ 30VDC for resistive loads and 0.2 amps @ 30VDC for
inductive loads.
The AT PARK relay has one Form-C contact (common, normally open, normally closed) that can be used. The figure below shows
the terminal blocks available for user wiring.
AT PARK RELAY
USER TERMINALS
Figure 4.3.3
Relay Terminal Block Location
4.3.4 CONTROLLER AREA NETWORK (CAN) COMMUNICATION BUS
This operator station includes a connection header to communicate across a J1939 CAN bus system and allows control of TFT RC
Monitors and TFT RC Valve Under Monitors when a YE-CAN# Multiplex Interface Control is installed (refer to section 4.14).
4.3.4.1 CAN WIRING CONFIGURATION
The Y4E-RP-D operator station needs to have the communication bus wiring relocated from the RS-485 communication bus terminal
block to the CAN communication bus terminal block. Refer to Figure 4.3.4.1
WHITE WIRE
BLUE WIRE
CAN BUS
TERMINATION
HEADER
CAN BUS
TERMINAL
BLOCK
Figure 4.3.4.1
Operator Station CAN bus wiring configuration
4.3.4.2 CAN BUS TERMINATION
The CAN communication bus must be terminated as per the ISO 11898-2 ControllerArea Network Standard. Optionally, the bus can
be terminated inside the Y4E-RP-D operator station by shorting the CAN BUS TERMINATION HEADER, refer to Figure 4.3.4.1 for
the location of the header. There are many standard shunts that can be used to short the Termination Header. TE Connectivity part
number 881545-2 is one example of a compatible shunt for this Termination Header.

©Copyright Task Force Tips, Inc. 2008-2014 LIY-500 May 12, 2014 Rev10
17
4.3.5 BASIC OPERATION
This operator station is installed on the truck, for example, on the pump operator’s panel. It is used to operate a TFT RC monitor
from a location directly mounted on the truck. This operator station gives the user full control of the monitor including the PARK,
OSCILLATE, and any AUXILIARY functions.
RIGHT button used to rotate
(sweep) water stream from
left to right from starting
position.
UP button used to move
water stream vertically up
from starting point.
STRAIGHT STREAM button
used to move nozzle pattern
to narrow and long reach.
RIGHT DISPLAY COMMAND
button used to initiate RIGHT
display area command.
FLOW ON/OFF button typically
used to control RC Valve Kit or
VUM. Also known as the AUX2
button. Could also be used with
YE-REMAUX relay interface
box to control other devices.
LEFT DISPLAY COMMAND
button used to initiate LEFT
display area command.
DISPLAY MENU SELECT/ENTER
used to control command menu
selection and initiate configuration
options.
MONITOR UP/DOWN button
typically used to control RC
Extend-A-Gun. Also known as
the AUX1 button. Could also
be used with YE-REMAUX
relay interface box to control
other devices.
LEFT button used to rotate
(sweep) water stream from
right to left from starting
point.
FOG button used to move
nozzle pattern to wide and
short reach.
DOWN button used to move water stream
vertically down from starting point.
®
UP
MONITOR
DOWN
Figure 4.3.5
Operator Station with Display Control Pad
4.3.6 DISPLAY CONTROLLED OPERATION
This operator station includes 3 buttons that are located just below the display screen that initiate control and configuration options
of the operator station based on the display screen text located in the bottom area of the screen. Detailed information on this display
driven control of the operator station can be found in the Remote Monitor Operator Station with Display User’s Guide (LIY-425) that
is included with the operator station. This User’s Guide is also located on TFT’s website.

©Copyright Task Force Tips, Inc. 2008-2014 LIY-500 May 12, 2014 Rev10
18
4.4 TETHERED
OPERATOR STATION
(Y4E-CT-##)
This operator station will have a factory installed 4-conductor cable, which will act as a tether, with a plug on the end. The installer
will need to mount the storage bracket and receptacle.
4.4.1 MOUNTING STORAGE BRACKET
The storage bracket is supplied with (3) 1/4-20 stainless steel self-tapping screws. Make sure the material beneath the bracket is
substantial and thick enough to hold self-tapping screws. Make sure the area on the backside of the mounting surface is clear of
obstructions. We recommend a minimum thickness of 3/32” (.093” - 2.4 mm) in aluminum and 5/64 (.078”-2mm) in steel See the
chart in Figure 4.3.1 to determine the correct pilot hole size.
Select proper location for mounting storage bracket. Panel space required will be 6.0“ x 11.2“ (152 x 285mm). Refer to Figure 4.4.1
for hole dimensions. Bracket can be used as a template. Be sure spring is in position.
Material Use Material Use
Thickness Drill Thickness Drill
5/64-3/32 .206 5.2 #5 3/32 .213 5.4 #3
1/8 .213 5.4 #3 1/8 .221 5.6 #2
3/16 .221 5.6 #2 3/16 .228 5.8 #1
Inches mm Inches mm
ALUMINUM STEEL
Hole Size Chart For Self Tapping Screws
Hole Size Hole Size
5"
[127mm]
6"
[152mm]
Drill (3) Pilot Holes
(refer to hole size chart)
Mount Bracket with (3)
1/4-20 Self-Tapping Screws.
Tighten Securely.
Spring
Figure 4.4.1
Tethered Operator Station Storage Bracket Hole Dimensions
4.4.2 RECEPTACLE MOUNTING
Select proper location for mounting receptacle. Receptacle is 1-1/4” x 1-1/4” and ½” deep. (32 mm x 32 mm x 13 mm) Allow extra
room behind receptacle for wires. Refer to Figure 4.4.2 for hole dimensions.
Drill (4) .098”
(#40) Holes
7/8”
(22 mm)
7/8”
(22 mm)
25/32”
(20 mm)
HOLE LAYOUT
MOUNT RECEPTACLE WITH
#4 SELF-TAPPING SCREWS.
TIGHTEN SECURELY. INSTALL
CHAIN CONNECTOR
UNDER SCREW HEAD
Y5310 TETHER RECEPTACLE
Y5320 CLOSURE CAP
Fig 4.4.2
Tether Operator Station Receptacle Hole Dimensions

©Copyright Task Force Tips, Inc. 2008-2014 LIY-500 May 12, 2014 Rev10
19
4.4.3 ELECTRICAL WIRING
See figure 4.0 for typical connections. The 4-conductor cable from the receptacle needs to be connected to power (red & black) and
to the communication link (blue & white) from the monitor. Refer to Figure 4.2.2 for typical cable preparation.
4.4.4 OPERATION
This operator station is tethered to the truck with a 10 foot (3 meter), 30 foot (9 meter), or 100 foot (30 meter) cable. It is used to
move slightly away from the truck to get a better view for redirecting the monitor. This operator station gives the user full control of
the monitor including the PARK, OSCILLATE, and any AUXILIARY functions.
OSCILLATE button used to
initiate monitor movement
through stored sequence
(pattern) or to program a
sequence (pattern).
Read manual before use.
WARNING
800-348-2686
Y5700
FLASHING = LOW BATT
®
ON
FLOW
OFF
OSCILLATE PARK
UP
MONITOR
DOWN www.tft.com
POWER
NO COMMUNICATION LINK
WHENALTERNATING P
PARK button used to initiate
monitor storage sequence
or to program storage
movements.
FOG button used to move
nozzle pattern to wide and
short reach.
STRAIGHT STREAM button
used to move nozzle pattern
to narrow and long reach.
LEFT button used to rotate
(sweep) water stream from
right to left from starting
point.
UP button used to move
water stream vertically up
from starting point.
DOWN button used
to move water stream
vertically down from
starting point.
RIGHT button used to rotate
(sweep) water stream from
left to right from starting
position.
MONITOR UP/DOWN
button typically used to
control RC Extend-A-Gun.
Also known as the AUX1
button. Could also be used
with YE-REMAUX relay
interface box to control
other devices.
FLOW ON/OFF button
typically used to control
RC Valve Kit or VUM. Also
known as the AUX2 button.
Could also be used with YE-
REMAUX relay interface box
to control other devices.
Fig. 4.4.4
Operator Station Control Pad

©Copyright Task Force Tips, Inc. 2008-2014 LIY-500 May 12, 2014 Rev10
20
4.5 TETHERED OPERATOR
STATION WITH DISPLAY
(Y4E-CT-##-D
This operator station will have a factory installed 4-conductor cable, which will act as a tether, with a plug on the end. The installer
will need to mount the storage bracket and receptacle.
4.5.1 MOUNTING STORAGE BRACKET
The storage bracket is supplied with (3) 1/4-20 stainless steel self-tapping screws. Make sure the material beneath the bracket is
substantial and thick enough to hold self-tapping screws. Make sure the area on the backside of the mounting surface is clear of
obstructions. We recommend a minimum thickness of 3/32” (.093” - 2.4 mm) in aluminum and 5/64 (.078”-2mm) in steel See the chart
in Figure 4.5.1 to determine the correct pilot hole size.
Select proper location for mounting storage bracket. Panel space required will be 6.0“ x 11.2“ (152mm x 285mm). Refer to Figure
4.5.1 for hole dimensions. Bracket can be used as a template. Be sure spring is in position.
Material Use Material Use
Thickness Drill Thickness Drill
5/64-3/32 .206 5.2 #5 3/32 .213 5.4 #3
1/8 .213 5.4 #3 1/8 .221 5.6 #2
3/16 .221 5.6 #2 3/16 .228 5.8 #1
Inches mm Inches mm
ALUMINUM STEEL
Hole Size Chart For Self Tapping Screws
Hole Size Hole Size
5"
[127mm]
6"
[152mm]
Drill (3) Pilot Holes
(refer to hole size chart)
Mount Bracket with (3)
1/4-20 Self-Tapping Screws.
Tighten Securely.
Spring
Figure 4.5.1
Tethered Operator Station Storage Bracket Hole Dimensions
4.5.2 Receptacle Mounting
Select proper location for mounting receptacle. Receptacle is 1-1/4” x 1-1/4” and ½” deep. (32 mm x 32 mm x 13 mm) Allow extra
room behind receptacle for wires. Refer to Figure 4.5.2 for hole dimensions.
Drill (4) .098”
(#40) Holes
7/8”
(22 mm)
7/8”
(22 mm)
25/32”
(20 mm)
HOLE LAYOUT
MOUNT RECEPTACLE WITH
#4 SELF-TAPPING SCREWS.
TIGHTEN SECURELY. INSTALL
CHAIN CONNECTOR
UNDER SCREW HEAD
Y5310 TETHER RECEPTACLE
Y5320 CLOSURE CAP
Figure 4.5.2
Tether Operator Station with Display Receptacle Hole Dimensions
