KHADAS BT Magic User manual

Quicksta | 入门指南

Inteace Diagram
RGB LED Indicator
RGB LED Indicator Illustrate
Status Motion
Bluetooth
Disconnected
Blue
(Flashing)
Bluetooth
Connected
Blue
(Breathing)
SBC Yellow
(Breathing)
AAC Green
(Breathing)
aptX / aptX LL Turquoise
(Breathing)
aptX HD Purple
(Breathing)
LDAC White
(Breathing)
USB-C
Erase
Paring Record
White
(Triple Flash)
Color

Setup Guide
Power On
1
Plug BT Magic into the USB-C (I2S) po, then turn on the
Tone2/Tone2 Pro. BT Magic will automatically turn on.
Bluetooth Pairing
2
(1) Set Tone2/Tone2 Pro’s input mode to ‘I2S’.
(2) Look for ‘BT Magic’ in your smaphone or tablet’s
Bluetooth pairing list. Tap on it to pair.
Music Playback3
After pairing with your device, the RGB indicator will show a
blue breathing light. BT Magic is now ready for music playback.
Power O
4
When Tone2/Tone2 Pro is turned o, BT Magic will turn o too.
In this case, the RGB indicator light will turn o.
Wireless
BT Magic
Wireless
BT Magic

RGB LED Indicator
USB-C
部件说明
RGB 指示灯说明
状态 显示状态
蓝牙未连接 蓝灯快闪
蓝牙连接成功 蓝灯呼吸
SBC 黄灯呼吸
AAC 绿灯呼吸
aptX
or aptX LL 青灯呼吸
aptX HD 紫灯呼吸
LDAC 白灯呼吸
清除蓝牙配对记录 白灯闪烁3下
颜色

(1) Tone2/Tone2 Pro输入源模式需要选择“I2S”。
(2) BT Magic连接Tone2/Tone2 Pro并开机后，在音乐播放设
备的蓝牙列表中搜索BT Magic进行配对连接。
Wireless
BT Magic
Wireless
BT Magic
连接步骤
开机
1
将BT Magic插入到Tone2/Tone2 Pro的USB-C (I2S) 接口，
再将Tone2/Tone2 Pro开机后，BT Magic会自动开机。
连接蓝牙
2
播放音乐3
蓝牙连接好后，即可播放音乐，此时BT Magic的RGB LED会有
对应指示。
关机4
当Tone2/Tone2 Pro关机时，BT Magic也同步会关机，关机后
BT Magic指示灯会关闭。

Bluetooth Chip：Qualcomm QCC5125
Bluetooth Standard：Bluetooth 5.1
Sample Rate：Up to 24bit 96KHz
LED：RGB LED
Connectivity：USB-C
Bluetooth Formats：SBC/AAC/aptX/aptX-LL/aptX-HD/LDAC
Compatibility：Khadas Tone2/Khadas Tone2 Pro
蓝牙芯片：高通 QCC5125
蓝牙标准：蓝牙5.1
采样率：高达24bit 96KHz
LED：RGB LED指示灯
连接性： USB-C
蓝牙编码格式：SBC/AAC/aptX/aptX-LL/aptX-HD/LDAC
兼容性：兼容适配Khadas Tone2/Khadas Tone2 Pro
Specications | 规格参数
FAQ | 常见疑问
How to erase Bluetooth pairing histo?
With BT Magic plugged-in and Tone2/Tone2 Pro powered o (USB
cable with 5V power still plugged-in), long-press the volume knob
for 5 seconds to Clear Bluetooth Paring Record. BT Magic’s RGB
indicator will ash white 3 times during this process.
如何清除BT Magic的蓝牙配对记录?
当Tone2 & Tone2 Pro关机且处于供电状态下插入BT Magic，长按旋钮
5秒清除蓝牙配对记录，清除记录时BT Magic会闪烁3下白灯。

What’s In The Box | 包装清单
BT Magic * 1pcs
Instruction Manual * 1pcs
说明书 * 1pcs
保修卡 * 1pcs
Warranty Card * 1pcs

www.khadas.com
生产商：哈哒科技（深圳）有限公司
电话：[phone] 邮箱: suppo@khadas.com
地址：深圳市宝安区西乡街道海城路5号前城商业中心2709
Manufacturer: Khadas Technology Co., Ltd.
Tel: [phone] E-mail: suppo@khadas.com
Address: Room 2709, Floor 27, Qiancheng Center, Haicheng Road,
Xixiang Street, Bao'an District, Shenzhen
