Cistermiser Easyflush Direct User manual

Please leave this booklet with
the user for future reference.
Easyflush Direct
Installation Guide
^
Cistermiser
gl
( (
^
WRAS

2 | cistermiser.co.uk Have a question? Call our customer support team on 0118 969 1611
1. Introduction
The Easyush Direct valve provides electronic ushing of the WC without the need for a WC cistern. There
are two versions:
Easyush Wave is operated by the user bringing their hand towards the infrared sensor. A part ush is
triggered by holding the user’s hand in place for 1 second; a full ush is triggered by a hand pass of over 1
second. The dual ush setting is a factory default but can be changed by the installer.
Easyush Direct Walkaway is activated when the user stands up or leaves the cubicle but it can also be
activated by the user bringing their hand toward the sensor. The dual ush setting is a factory default but
can be changed by the installer. A part ush is triggered by short user occupancy and a full ush by long
user occupancy (over 45 seconds).
With Easyush Direct there is no cistern to be relled; this means a second ush can be activated without
a delay. The product includes a hygiene rinse function.
Supplied parts
1 Sensor unit
2 Valve unit
3 Sensor nut
4 Sensor rubber gasket
5 Clamp plate
6 DC pipe interrupter
inc. ow regulator
7 Valve rubber seal
8 Cap seal
9 Cap washer
10 Cap nut
11 Long screws
12 Short screws
13 Sticky pad
14 6mm screw packer
15 Extension cable
16 Mains adapter
1
5
3
2
4
11
12
6
8
7
915
13
14
16
10
Optional extras
1.5" brass ush pipe tting (DWC/4)
X
1
x
4
x
2

Have a question? Call our customer support team on 0118 969 1611 cistermiser.co.uk | 3
2. Installation
IMPORTANT: Read this before tting the WC valve.
Flushing directly from the mains water supply
When ushing WCs or urinals directly from the mains, the Water Regulations require that the water supply
be protected by a suitable category 5 protection method or device.
In the case of WCs, this can be achieved in three ways:
1 The use of a dedicated supply for ushing use only, supplied from a break tank that protects the mains
supply with a type AA, AB or AD air gap.
2 The use of a specic type of WC bowl which has been tested and shown to incorporate the equivalent
of a type AB air gap.
3 The use of a type DC pipe interrupter (supplied with all Cistermiser Direct Flushing products).
A note about type DC pipe interrupters
These devices have an integral air gap; it is therefore important that pipework design and WC bowl
selection are appropriate to ensure sucient ow to ush the WC while preventing water owing back up
and out of the air gap.
The DC pipe interrupter must be installed not less than 150mm above the spill over level of the WC pan.
Ensure you follow these key design & installation points
• Install the valve as high as possible above the WC bowl.
• Install a free-owing, low restriction connection from the valve to the WC bowl. Ensure the water system
can deliver min. 90 lpm.
• Use a large pipe size in the pipework between the DC pipe interrupter and the WC.
• The DC pipe interrupter is tted with a 100 lpm ow regulator to control the ow of water; if you still have
issues with the DC pipe interrupter overowing, it may be necessary to install a further ow restricting
device upstream of the valve.
NOTE:
For grey water/rain harvesting. Ensure
adequate ltering is tted, a 10μm lter is
recommended. NOTE:
For chemical water treatment. If the water
system had been treated with chemical dosing,
ensure the system is thoroughly ushed before
tting any Cistermiser products. Concentrated
chemicals in dead legs can damage the
product and result in failure. If the water is
treated with Chlorine Dioxide (ClO2), ensure
concentration levels are maintained below
5ppm.Ensure adequate ltering is tted, a
10μm lter is recommended.
NOTE:
As with all water containing products, limescale
in hard water areas can aect the products
performance. This can result in maintenance
to remove the limescale when required.Ensure
adequate ltering is tted, a 10μm lter is
recommended.

4 | cistermiser.co.uk Have a question? Call our customer support team on 0118 969 1611
3. Installation schematic
The valve must be installed at least
150mm above the spill over level to
comply with Water Regulations.
When installing the valve it is good
practice to ensure there is an
accessible isolating valve upstream of
the valve.
Ensure ow rate at valve
A
does
not exceed the ow rate to the WC
bowl
B
to prevent water backing-up
to the DC pipe interrupter.
A 1.5m extension cable is supplied if
required for placement of sensor.
NOTE:
Flush pipework prior to installation.
Do not install opposite a mirror. When
installed opposite a shiny surface, the
range may require adjustment. See
section 8 Advanced settings guide.
DC pipe
interrupter
Water supply
Not less than 150mm
B
A
X
Pipework diagram
suggestion only
X– Walkaway version only
If this distance is less than 12cm it is recommended
that the Hand Activation is disabled. Refer to
Section 9. (ICU required; not supplied.)
DMA55 power supply included
with Easyush Direct (Requires 1A
fused spur)
4
a
\
f
K
ik
p
\
\
s
s
w
’
1
—
T
>
O
y
—
t
1

Have a question? Call our customer support team on 0118 969 1611 cistermiser.co.uk | 5
Panel mounted sensor
WC
300 – 400mm
700 – 900mm
WAVE only WALKAWAY only
NOTE:
Sensor should be located outside body
shape for WAVE only.
NOTE:
Sensor should be located inside
body shape for WALKAWAY only.
WC
500 – 700mm
(Lower position
may be required
for schools)
N
\
I
/
k
/
/
\
\
t
t
I
I
1
\
\ \
yy
\
k
L
L
>
I
'
V
\
\
t t
\
\
I
1
l
I
I
k
k
\
I
I
.
I
'
1
I
.
I
.
I
I
1
1
)
I
\
\
I I
I
I
\
l
1
N N
\ \
k
/
/ /
I
k k
,
U
-
\ \
i
'
.
\ \
\
k
k
'
\
k
\
\
k k
I
I
t
I
I
I
I
( (
s
V
s
\\
\
kk
\
s
t
l

6 | cistermiser.co.uk Have a question? Call our customer support team on 0118 969 1611
Sensor gasket
Ø38mm
Apply
sanitary
silicone
sealant
Sensor nut
3 – 15mm
Ø44mm
Apply
sanitary
silicone
sealant
Sensor
gasket
Sensor nut
15 – 30mm

Apply
sanitary
silicone
sealant
M4
screw
Clamp plate
(reversible)
6mm packer
(See note*)
30 – 38mm
NOTE:
*If wall thickness is under 32mm use packer to prevent screw causing damage to sensor
Thin wall Medium thickness wall Thick wall
h
+
*
>
1
IDOUT
)
<
M
3
f
i
.
^
Wr
p
MQSIU
mm
Si
r
at
-
5
=
>
,
5
L
>
58
>
C
—
o
eggs

Have a question? Call our customer support team on 0118 969 1611 cistermiser.co.uk | 7
NOTE:
Removing the DC pipe interrupter may
contravene the Water Regulations (see page 3).
NOTE:
If you wish to connect to a 2" ush pipe, an
adapter can be purchased from your local
plumbing merchant.
Easyush Direct is supplied with a DC pipe interrupter. Fit the DC pipe interrupter to the valve outlet
ensuring the rubber seal is in place.
Rubber seal
1” BSP
connesction
Easyush
Direct valve
Rubber seal
DC pipe
interrupter
Flush pipe
ttings
NOTE:
To connect to supply pipework you will require
a 1" female BSP to 22mm or 28mm (copper)
connection (not supplied).
If the DC pipe interrupter is not required
(see ‘Flushing directly from the mains water
supply’ in Section 2), t a 1.5
" ush pipe tting
to the pipe outlet in place of the DC pipe
interrupter. Available as a spare part from
Cistermiser - DWC/4

8 | cistermiser.co.uk Have a question? Call our customer support team on 0118 969 1611
4. Power Connections
Fasten the mains adapter into place on the panel in a dry location using the screws or adhesive pads
provided and connect the un-terminated mains cable to a 50Hz 230V AC single phase supply via a 1A
fused spur (not supplied).
Connect the spade connectors from the sensor to the solenoid terminals; take care to connect the wires
according to the colour coding on the label. If the wires are not long enough they can be extended by up
to 1.5 metres with the cable supplied.
NOTE:
Remove the label from the sensor BEFORE
connecting to the power. When the power is rst
connected the LED in the sensor ashes amber.
This is normal and lasts only a few seconds.
Power connector
DMA55 power supply included with Easyush
Direct (Requires 1A fused spur)
Additional conguration options
With the Infrared conguration unit (ICU) remote control (sold separately).
• Hygiene rinse on/o. The installer is able to switch the 12 hr hygiene rinse function on or o.
• Clean mode. The Easyush Direct can be disabled for a short period to allow for cleaning.
• Siphonic trap rell mode. When activated this allows a small ush after every ush to rell the siphonic trap.
• Toggle wave feature on/o.
Electrical connection
Connect the power connector from
the sensor to the
mains adapter.
Alternative power options
For multiple connections the Cistermiser
power supply unit (PSUC) can be
used to power up to 20 units
(not supplied).
NOTE:
When using a Cistermiser power supply unit
(PSUC), ensure that when connecting correct
polarity is ensured.
Brown wire = positive Grey wire = negative

Have a question? Call our customer support team on 0118 969 1611 cistermiser.co.uk | 9
5. Configuration
IMPORTANT: Water Flow Rate Requirement
To achieve an eective and ecient ush, the water system needs to deliver at least 90 lpm. Typically this
would require that the dynamic/working water pressure, measured before the valve, is at least 2 bar.
To comply with the water regulations the full ush volume must not exceed 6 litres.
The Easyush Direct is tted with a 100 lpm ow regulator* that will limit the ow through the valve to
100 lpm.
The ush duration is set by default to 3.5 seconds, this ensures the ush volume will be below 6 litres.
The part ush will automatically be set to 0.6 x the full ush duration. This will ensure the part ush
volume is less than 2/3rd the full ush volume as specied in the Water Regulations.
To adjust the ush duration and therefore the ush volume see Section 8 ‘Advanced settings guide’
The ow rate can also be reduced by turning the adjuster screw in the middle of the valve (clockwise to
reduce ow) or by tting a third party pressure reducing valve above the Easyush Direct.
Ensure that the dynamic water pressure (pressure measured while the valve is open and water is owing)
is sucient to achieve the required ow rate.
*Alternative ow regulators are available. Please contact Cistermiser.
WARNING:
The use of several other appliances from the
same water supply simultaneously may reduce
the ow rate below 90 lpm.
NOTE:
On smaller pipe sizes please pay particular
attention that you achieve 90 lpm at the valve
outlet for an eective ush.

10 | cistermiser.co.uk Have a question? Call our customer support team on 0118 969 1611
6. Usage advice and specification
Minimum working pressure: An eective and ecient ush is achieved with a ow rate of >90
lpm. A typical installation will require 2bar dynamic pressure,
measured before the Easyush Direct, to achieve 90 lpm.
Maximum working pressure: 5 bar
Back siphonage protection: Class 5, Type DC
Factory settings
Range: EFD Wave – circa 18cm
EFD Walkaway – circa 65cm (9cm for hand activation)
Full ush duration: 3.5 seconds
Part ush duration: 2 seconds
Power requirements: 6V DC regulated from mains adapter (1A fused spur required)
Cleaning: Clean with soap and water only
Lens care: Infrared lens can be polished with a soft cloth
Electronic specication
Control classication: Independent
Maximum load: 2W, 0.33A (6VDC)
Rated temperature range: 0-40 deg C
Ingress protection: IP65
NOTE:
When using the Easyush Direct valve from a mains water supply, the pressure may be higher than is
suitable for the design of the bowl which can cause splashing to occur. In such cases t a ow regulator
(supplied) as indicated in Section 5.

Have a question? Call our customer support team on 0118 969 1611 cistermiser.co.uk | 11
7. Component dimensions
67mm126mm
163mm
48mm 27mm
37mm
1 BSP
H
-
W
IMF
w
K
W
\
1
<
5
"
1
i
}
I
)
]
2
c
|
WW
>
MM
|
)
7
D
t

12 | cistermiser.co.uk Have a question? Call our customer support team on 0118 969 1611
Wait for double red
ashing LED to
enter full ush time.
During double red ashing, briey
place your hand in front of the sensor.
The valve will ush and the cistern
will rell. A green ashing LED will be
seen. Hold hand steady.
A B
8. Advanced settings guide
Easyush Direct Walkaway Carry out only if default settings need to be changed.
1Disconnect power, wait for 5 seconds and reconnect.
Solid amber while ambient light detected.
When ashing amber.
If a hand is not placed over the sensor, it will go into normal operation mode.
Place hand 4-6cm from sensor until
constant green, then remove hand.
You are now in conguration mode
2
3
Stand at the distance from the sensor you would
like to set as maximum range. Wait 8 seconds
until constant green LED shows.
Sensor distance
is now set.
C
Wait for single red
ashing LED to enter
sensing range mode.
Briey place your hand in front of
the sensor until the green LED
ashes slowly. Range conguration
mode will then be ready.
A B
Sensing range of adjustment
NOTE:
Part ush duration will be automatically set at 0.6 x full ush duration.
Full ush duration adjustment
When the ush has run for the desired time, move your hand out of the line of sight of the
sensor. The water will cease and the ush duration will be set to a maximum of 4 seconds.
C
After conguration the unit will ash amber, giving opportunity to re-enter.
4
X2

Have a question? Call our customer support team on 0118 969 1611 cistermiser.co.uk | 13
Easyush Direct Wave Carry out only if settings need to be changed.
NOTE:
Part ush duration will be automatically set at 0.6 x full ush duration.
1Disconnect power, wait for 5 seconds and reconnect.
Solid amber while ambient light detected.
When ashing amber.Place hand 4-6cm from sensor until
constant green, then remove hand.
2
Wait for double red
ashing LED to
enter full ush time.
During double red ashing, briey
place your hand in front of the sensor.
The valve will ush and the cistern
will rell. The valve will ush while the
green ashing will be seen. Hold
hand steady.
A B
If a hand is not placed over the sensor, it will go into normal operation mode.
You are now in conguration mode
3
Move your hand to the distance from the sensor you would
like to set as maximum range. Wait 8 seconds until constant
green LED shows.
Sensor distance
is now set.
C
Wait for single red
ashing LED to enter
sensing range mode.
Briey place your hand in front of
the sensor until the green LED
ashes slowly. Range conguration
mode will then be ready.
A B
Sensing range of adjustment
Full ush duration adjustment
When the ush has run for the desired time, move your hand out of the line of sight of the
sensor. The water will cease and the ush duration will be set to a maximum of 4 seconds.
C
After conguration the unit will ash amber, giving opportunity to re-enter.
4
X2

14 | cistermiser.co.uk Have a question? Call our customer support team on 0118 969 1611
9. Easyflush Direct configuration
Entering conguration mode
Point the ICU towards the Easyush Direct sensor
and push the conguration button. Activation is
most eective when the conguration button is held
down as the ICU is brought close to the sensor.
Sensor blinks red when ICU is detected. It can take
up to three seconds for the product to sense the ICU.
The Easyush Direct will return to normal operation if
there are no button presses for 30 seconds.
Conguring sensor range
Point the ICU at the Easyush Direct sensor and
press the 1 sensor range button (the sensor
blinks green).
Decrease or increase the sensor range by pressing
the and buttons respectively. The sensor blinks red
when the min or max value is reached.
Press the button to check the sensor range
setting - the sensor displays the current setting by
ashing green, as indicated in the table.
Save setting and exit the ICU conguration mode
by pressing the button.
Exit without saving by pressing the button.
Button descriptions
For Wave version
Number of ashes 1 2 34 5
Range (cm approx) 69 11 15 17
For Walkaway version
Number of ashes 1 2 34 5
Range (cm approx) 45 50 53 56 58
Activates cleaning mode
Activates ICU conguration mode
Decreases setting
Increases setting
Checks the setting being altered
Saves changes and exits ICU conguration mode
Quits ICU conguration mode without saving changes
1 Congures sensor range
2Congures full ush duration
3 No function
4 Congures hand wave
5 12-hour hygiene cycle activation
6 Dual ush activation
7 Autorange setting of sensor range
8 No function
9Resets to default factory settings
c
clean
config
©
+
OK
SAVE
(
^
QUTT
^
>
QUIT
©
§§
©
4
)
d
7
8 9
*
ffl
)
KSJ
@
Cistermiser
o

Have a question? Call our customer support team on 0118 969 1611 cistermiser.co.uk | 15
Conguring the full ush duration
Point the ICU at the Easyush Direct sensor and
press the 2 ush duration button (the sensor
blinks green).
Decrease or increase the full ush duration by
pressing the and respectively. The sensor
blinks red when the min or max value is reached.
Press the button to check the full ush duration
setting - the sensor displays the current setting by
ashing green; see table.
Part ush duration will be automatically set at 0.6 x
full ush duration.
Save setting and exit the ICU conguration mode
by pressing the button.
Exit without saving by pressing the button.
Activating and de-activating the hand
wave ushing (Walkaway version only)
Point the ICU at the Easyush Direct sensor and
press the 4 button (the sensor blinks green). By
default the hand wave function is on.
Pressing the and buttons switches the hand
wave function on or o respectively.
Press the button to check the setting - the
sensor ashes green once if the function is o or
twice if it is on.
Save setting and exit the ICU conguration mode
by pressing the button.
Exit without saving by pressing the button.
Activating the 12 hour hygiene
ush cycle
Point the ICU at the Easyush Direct sensor and
press the 5 hygiene cycle button (the sensor
blinks green).
Pressing the and buttons switches the
hygiene ush function on or o respectively.
Press the button to check the setting - the
sensor ashes green once if the function is o or
twice if it is on.
Save setting and exit the ICU conguration mode
by pressing the button.
Exit without saving by pressing the button.
Activating the dual ush function
Point the ICU at the Easyush Direct sensor and
press the 6 dual ush button (the sensor
blinks green).
Pressing the and buttons switches the dual
ush function on or o respectively.
Press the button to check the setting - the
sensor ashes green once if the function is o or
twice if it is on.
Save setting and exit the ICU conguration mode
by pressing the button.
Exit without saving by pressing the button.
Conguring sensor range using the
autorange function
If the cubicle door is opposite the sensor, ensure
that the cubicle door is closed or ajar, but not fully
open.
Point the ICU at the Easyush Direct sensor and
press the 7 button.
Immediately stand clear of the sensor. Sensor
blinks green for 5 seconds, then a steady green
when setting complete. The sensor measures the
background reections and sets the sensor range
to an appropriate setting.
Save setting and exit the ICU conguration mode
by pressing the button.
Exit without saving by pressing the button.
Reset to factory settings
Enter into conguration mode. Point the ICU at the
Easyush Direct sensor and press the 9 button
(the sensor blinks green once). This returns all
settings to the default factory settings.
To save the setting and exit ICU conguration
mode press the button. The sensor will blink
green for one second and then constant amber
for three seconds.
To exit without saving press the button. The
sensor will blink red for one second and then
constant amber for three seconds.
Number of ashes 123
Full  ush time (sec) 2 34
0
8
<
gur
<
ur
5
0
<
®
’
<
^
ur
5
0
<
&
>
<
jiun
^

16 | cistermiser.co.uk Have a question? Call our customer support team on 0118 969 1611
10. Frequently asked questions
Indicators for normal sensor function after user activation
Wave:
• Single green ash once a second (if part ush)
• Double green ash once a second (if full ush)
Walkaway:
• 3 seconds between green ashes
(if a presence is detected)
• Single green ash once a second (if part ush)
• Double green ash once a second (if full ush)
No water is entering the bowl
No obvious indicator
Ensure that the water supply is reaching the valve.
Blockage. Ensure the lter on the inlet of the valve is clear.
Ensure water pressure >0.5 bar <5 bar for valve to operate. Typically 2
bar for eective ush.
The sensor is obscured
This occurs when an object/debris blocks or covers the sensor, the
object/debris needs to be removed from the sensor and Easyush
Direct will resume normal functionality.
The valve is not working at all
The sensor light does
not ash when a hand is
placed in front of it
Ensure the power supply is connected and wired correctly.
Sensor is ashing red
slowly or not at all when
hand is placed in front of it
Low or no power. Ensure spur is live and 6v DC from DMA55 power
adapter. Check connection for damp.
No obvious indicator
Ensure water pressure >0.5 bar <5 bar for valve to operate. Typically 2
bar for eective ush.
Continuous ow into the WC bowl from the valve
No obvious indicator
Ensure water pressure is min 0.5 bar. Flush any potential debris out
of the valve.
Sensor is ashing red slowly
Low or no power. Contact Cistermiser.

Have a question? Call our customer support team on 0118 969 1611 cistermiser.co.uk | 17
WC ushes when in use
Working as normal otherwise
Ensure that the sensor is mounted in the correct position. Refer to the
Sensor positioning (section 3).
Ensure the sensor range is correctly congured. Refer to the advanced
setting guide (Section 8) or Infrared Conguration Unit (ICU) guide.
Cistermiser product warranty and extended warranty
Cistermiser products are guaranteed for 12
months from the date of manufacture. The
guarantee is for faulty products and parts only:
there is no labour warranty. If you believe your
product is faulty, please either contact
Cistermiser directly on 0118 969 1611 or at
[email protected], with a
photograph and the serial number, to help
diagnose the cause of the problem.
The warranty on Cistermiser products can be
extended, at no cost within one year of date of
manufacture, to three years from the date of
installation by completing the enclosed warranty
card or at www.cistermiser.co.uk/warranty.
Please make a note of the serial number and
take a photograph of the installation before you
leave site.
Flush is ineective
Working as normal otherwise
Ensure the ow rate of the water supply is 90 lpm.
Blockage
Ensure the lter on the inlet of the valve is clear.
Other issues
Double red ash
Faulty wiring. Check wiring carefully.
Faulty solenoid. Call Cistermiser for advice.
Red ash once every second
Low power. Check batteries or power supply connections.
Red ash twice every
three seconds
Sensor covered or heavily scratched.
Uncover or polish out scratches.

18 | cistermiser.co.uk Have a question? Call our customer support team on 0118 969 1611
Notes

Have a question? Call our customer support team on 0118 969 1611 cistermiser.co.uk | 19
Commissioning check-list
Easyflush Direct
Cistermiser products are guaranteed for 12 months from the date of manufacture.
Product serial number
Installation address
No Activity
1. Flush pipework prior to installation.
2. Check valve orientation: valve should normally be mounted more than 150mm
from spill over level of toilet pan.
3. Install an isolation valve upstream of solenoid valve.
4. Check all connections for leaks.
5. Ensure water supply pressure is above 2 bar dynamic, to give a minimum of 90
litres per minute at valve entry.
6. Check sensor is mounted in correct position for type of sensor.
(See installation instructions)
7. Ensure label is removed from sensor before connecting power.
8. Check electrical connections: To the solenoid orange to orange, blue to blue.
Ensure either mains or battery power or multi product power supply is connected.
9. Check operation: adjust sensor range and ush time if necessary.
10. Test operation.
a Wave: Place hand within 10 cm of sensor for 1 second valve will part ush; sensor
will ash once per second. Place hand within 10cm of sensor for 2 seconds valve
will full ush, sensor will ash twice per second.
b Walkaway: If presence is detected sensor ashes green once every 3 seconds.
Sensor detects a presence for less than 40 seconds, valve will part ush. Sensor
detects a presence for over 40 seconds valve will full ush.
Checked Date
The warranty on Cistermiser products can be extended within one year of
date of manufacture, at no cost, to three years from the date of installation by
completing online registration at www.cistermiser.co.uk/product-registration
and completing and returning the commissioning checklist below.
3YEAR
warranty
extended

DWC/6 C-03
Salamander is one of the UK’s leading
manufacturers of pumps for boosting
water pressure for showers, bathrooms
and whole house supply in domestic and
small commercial tank-fed systems.
salamanderpumps.co.uk
Kerao manufacture delayed action oat
valves, which provide an accurate and
eective method of controlling the level
of stored cold water in tanks both with
and without raised oat valve chambers.
The range is used in domestic, commercial
and industrial applications worldwide.
kerao.co.uk
Combimate is a domestic limescale
prevention device that prevents limescale
build-up and soft water corrosion in
combination boilers and other domestic
hot water appliances.
combimate.co.uk
Talon is the UK market leader in the
manufacture and supply of plastic pipe
clips, pipe collars and xing plugs, plus
a range of cover proles for concealing
pipework.
talon.co.uk
Cistermiser Limited
Unit 1, Woodley Park Estate, 59-69 Reading Road,
Woodley, Reading, Berkshire RG5 3AN
t: [phone]
f: [phone]
e: [e-mail]
cistermiser.co.uk
A Davidson Holdings company
Davidson Holdings’ brands
df
r
7
alon
Salamander
Pumps
A
Keraflo
OUR WORLD
IS
WATER
Combimate
'
vJiX
GUARANTEED
LIMESCALE
PREVENTION
CIPHE
®
1
C
i
CR
X
