INSTRUCTION MANUAL
FOR
DIGITAL BLOOD PRESSURE MONITOR
REF CH-403C
TM
English
CH-403C
MEMORY START POWER
SELECT
IDENTIFICATION OF PARTS
Systolic blood pressure
display section
Diastolic blood pressure/
Pulse display section
Cuff
Rubber cuff hose
Hose plug
Hose socket
Memory reset switch
Battery cover
Power switch
Start switch
Memory recall switch
Pressure setting switch
- Eng 1 -

- Eng 2 -
SPECIFICATIONS
Measuring method:
Indication:
Measuring range:
Accuracy:
Inflation:
Pressurization setting:
Deflation:
Exhaust:
Memory function:
Power source:
Battery life:
Rated voltage:
Working temp. & humidity:
Storage temp. & humidity:
Outside dimensions:
Weight:
Electric shock protection:
Accessories:
*Specifications may be changed without notice in the event of improvements being made.
Oscillometric system
Digital display, Height: 19mm
Pressure; 0 ⬃280mmHg, Pulse; 40 ⬃200 beat/min.
Pressure; ±3mmHg, Pulse; ±5%
Automatic inflation by internal pump
4 stage: 130, 160, 200, 250mmHg
Automatic constant speed deflation system
Quick exhaust by electromagnetic valve
7 data
4 “AA” (R6P, LR6) batteries
Approx. 400 times/LR6 Approx. 200 times/R6P
(once a day, 160mmHg, room temp. 22°C)
6V DC
+10°C ⬃+40°C, 30% ⬃85%RH
–20°C ⬃+60°C, 10% ⬃95%RH
135mm(W) ×130mm(D) ×50.5mm(H)
Approx. 360g (Apparatus and batteries)
Type B equipment
Cuff, 4 “AA” (R6P) batteries, Instruction manual

After cleaning the cuff with a neutral detergent, lightly rinse it
with water and let it dry in the air. Hard rubbing or washing
in a washing machine will cause air leakage. Also, be careful
not to get water into the air hose.
General Remarks on blood pressure
measurement
• If the cuff is to be deflated quickly, depress “POWER” switch.
• The attached cuff is suited for an arm circumstance of 22cm to
32cm.
• When attaching the cuff, rubber cuff hose should be placed
on the inside of your arm on top of the arterial.
• Self measurement is no therapy! In no case may you change
the dosage of medication prescribed by your physician.
• In operation for blood pressure measurement, you should
urinate and should remain relatively still for 10 to 15 min-
utes prior to measurement.
• Exercise, eating and drinking, smoking, etc., prior to mea-
surement may affect the results.
• The blood pressure varies constantly throughout the day. Mea-
surement should be made regularly at the same time each day.
• Do NOT be impressed by the results of one measurement.
Keep a record of blood pressure variations. Many readings
tell a story.
• Emotional stress may tend to cause pressure to rise.
For proper measurement of blood pressure
• Take a deep breath five or six time and then relax before
measuring blood pressure. If you are tense when taking
the measurement, you will not get a valid reading.
• Blood pressure will be elevated when you are in a worri-
some or irritated state, suffering from lack of sleep or con-
stipation, or after exercise or a meal.
• Putting on the cuff is one of the most important tasks for
ensuring proper measurement of blood pressure. Wind the
cuff around the arm and tighten it so that one finger may
be inserted between the cuff and arm.
• Do NOT measure blood pressure after bathing or drinking.
• When you feel like relieving yourself, you should do so be-
fore measuring blood pressure.
• Measure blood pressure where the room temperature is
about 20˚C. Do NOT measure blood pressure when it is too
cold (below 10˚C) or too hot (above 40˚C) in the room.
• Do NOT measure blood pressure immediately after drink-
ing coffee or tea or smoking.
CLEANING METHOD OF CUFF
GENERAL REMARKS
English
- Eng 3 -

• Measure blood pressure with a relaxed and quiet posture.
Keep the center of the cuff at the level of your heart, and do
NOT move your arm or talk during measurement.
Precautions for use
• If you suffer from heart disease, high blood pressure or
other circulatory disease, please consult your doctor first.
• If you feel abnormal pressure of the cuff during use or any
other irregularity, reduce the pressure by immediately
switching off the power or removing the batteries and con-
sult the sales outlet where purchased.
• If you think the measured value is abnormal or if measur-
ing makes you feel unwell, discontinue use and consult your
doctor.
• Measurement of blood pressure may not be possible for
someone with a weak pulse or arrhythmia.
• Congestion, swelling, etc. may occur in some people.
• If blood pressure is measured repeatedly, an accurate re-
sult will not be achieved. An interval of about 10 minutes
should be allowed.
• The memory is erased if the batteries are removed for re-
placement, etc. and a record should be kept of any neces-
sary data.
• Do NOT keep on measuring so many times, as your arm
will have built up congestion of blood, and you will not get
a valid reading.
PRECAUTION FOR USE AND MAINTENANCE
Precautions for maintenance
• Do NOT store the blood pressure monitor where it will be
exposed to direct sunlight, high temperature (over 60˚C),
low temperature (below –20˚C), high relative humidity (over
95%) or in a dusty place.
• Do NOT expose the blood pressure monitor to under force
or vibration, or drop it.
• Remove the battery/batteries when not in use for a long pe-
riod.
• Do NOT disassemble the apparatus.
• Do NOT bend the cuff or air hose unnecessarily.
• NEVER wipe the blood pressure monitor with thinner or
benzene, as they may damage it.
• When the monitor is very dirty, wipe it clean with a cloth
moistened with Sterilizing alcohol or a neutral detergent,
and then wipe it with a dry cloth. Do NOT use thinner or
benzene.
Nature and frequency of maintenance:
This products is designed for use over an extended period of
time; however, it is generally recommended that it be inspected
every two years to ensure proper function and performance.
- Eng 4 -

Protect the nature environment:
Please help protect natural environment by respecting na-
tional and/or local recycling regulations when disposing of
the batteries and the products at the end of their useful lives.
Reference European standard:
This products complies with EC instructions 93/42/EEC (Medi-
cal Device Directive) and with the following standards: EN
1060-1: 1995 “Noninvasive Sphygmomanometers, Part 1
General Requirements” and EN 1060-3: 1997 “Noninvasive
Sphygmo-manometers, Part 3 Supplementary Requirements
for Electromechanical Blood-Pressure Measuring Systems”.
Manufacturer:
Name: Premier Precision Ltd.
Address: Block E, G-H, 6th floor,
Phase 2, Yip Fat Factory Building,
73-75 Hoi Yuen Road,
Kwun Tong, Kowloon, Hong Kong
European Representative:
Name: WvW elektronische Geräte Vertrieb GmbH.
Address: Robert-Koch-Straße 20,
D-80538 München,
GERMANY
MEASUREMENTS
1. Turn power ON
CH-403C
MEMORY START POWER
SELECT
Press the “Power switch” for power ON.Insert the Hose plug from the cuff into the hose socket at
the mainframe until it is tightly connected.
English
- Eng 5 -

All display marks appear for approx. 1
second and buzzer beeps.
After all display marks are disappeared,
deflation mark “▼” appears for approx.
1 second (three short beeps notify you
of ready for measurement) then the last
pressure setting value appears for
approx. 3 seconds. Then the “
0 ”appears
at the display.
Ready for measurement
2. Attaching of arm cuff and posture during
measurement
Unfasten and open the cuff as figure.
SYSTOLIC mmHg DIASTOLIC mmHg
PULSE/min
AVE. 12 34567
SYSTOLIC mmHg DIASTOLIC mmHg
PULSE/min
AVE. 12 34567
- Eng 6 -
SYSTOLIC mmHg DIASTOLIC mmHg
PULSE/min
AVE. 12 34567
SYSTOLIC mmHg DIASTOLIC mmHg
PULSE/min
AVE. 12 34567

Wind the arm cuff around the left upper arm tightly so that
the bottom edge of the cuff is positioned about 1-2 cm (about
1 inch) above the elbow joint.
•When you wind the cuff, please wind the cuff next to the
skin as possible. (If measurement is made by rolling the
shirts or jacket up over the arm, this will constrict the up-
per arm and prevent accurate measurement)
Rubber cuff hose should be placed on the inside of your
arm as figures.
The cuff should be wound so that one finger can be in-
serted under the cuff. Note that uneven cuff winding will
prevent proper measurements.
Rest the elbow on a table so that the section of the upper
arm is at the height of the heart. Relax the lower arm across
the table and remain still.
Make measurements in either a seated or reclining pos-
ture.
1 –2cm
English
- Eng 7 -

3. Select the value for pressure for mea-
surement
Press the “Pressure Setting Switch”and set the value to a
value approximately 20~30mmHg above your normal systolic
blood pressure.
There are 4 settings; 130, 160, 200 and 250mmHg.
After press on the “Pressure Setting Switch”, the set pres-
sure value will be displayed at the left and the right side of
the display.
CH-403C
MEMORYSTARTPOWER
SELECT
Press the “Start Switch”.
The arm cuff pressurizes when the “Start Switch”is pressed.
4. To start the measurement
SYSTOLIC mmHg DIASTOLIC mmHg
PULSE/min
AVE. 12 34567
When the pressurization is reached to the set value, air infla-
tion is stopped automatically.
SYSTOLIC mmHg DIASTOLIC mmHg
PULSE/min
AVE. 12 34567
When pressurization is completed, the automatic exhaust
mechanism will gradually reduce arm cuff pressure, and the
mark “Q”appears indicating that measurement is in progress.
- Eng 8 -

SYSTOLIC mmHg DIASTOLIC mmHg
PULSE/min
AVE. 12 34567
SYSTOLIC mmHg DIASTOLIC mmHg
PULSE/min
AVE. 12 34567
When a pulse is detected, the pressure value moves to the
right side of the display. At this time the mark “Q”flashes
and buzzer sounds.
When the diastolic pressure value is detected, the measure-
ment is completed and buzzer sounds.
Systolic pressure is displayed on the left and diastolic pres-
sure on the right side of the display.
2 or 3 seconds later, pressure value and pulse appear alter-
nately on the display.
SYSTOLIC mmHg DIASTOLIC mmHg
PULSE/min
AVE. 12 34567
CH-403C
MEMORYSTARTPOWER
SELECT
6. Subsequent measurements
When a measurement need to be made again, just press the
“Start Switch”again.
5. Turn power off
Press the “Power Switch”to turn OFF.
2 to 3 seconds after completion of measurements, the mark
“▼”appears and air will deflate immediately.
CH-403C
MEMORYSTARTPOWER
SELECT
When the pressure setting is needed to be changed, press
the “Pressure Setting Switch”and select optimum value.
7. Change of the pressure-setting value
English
- Eng 9 -

8. Memory recall
CH-403C
MEMORY START POWER
SELECT
This blood pressure monitor has a function which is able to
display last measured value.
SYSTOLIC mmHg DIASTOLIC mmHg
PULSE/min
AVE. 12 34567
•By a first depressing of “Memory Recall Switch”, averaged
blood pressure is displayed and “]”mark flashes to no-
tify that the displayed value is averaged value.
SYSTOLIC mmHg DIASTOLIC mmHg
PULSE/min
AVE. 12 34567
•By a second depressing of “Memory Recall Switch”, the
value for latest (last measured value) blood pressure is dis-
played. The “]”mark shifts to right (from “Ave.”to “1”)
and notify that the value is the last measured (newest one)
value.
•Press the “Memory Recall Switch”to recall the last mea-
sured blood pressure.
The last measured systolic and diastolic blood pressure are
displayed (Value of the pulse is not memorized nor dis-
played).
SYSTOLIC mmHg DIASTOLIC mmHg
PULSE/min
AVE. 12 34567
•As per the same above-mentioned method, you may recall
7 last measured values by depressing of “Memory Recall
Switch”.
SYSTOLIC mmHg DIASTOLIC mmHg
PULSE/min
AVE. 12 34567
•By a third depressing of “Memory Recall Switch”, the value
for next later blood pressure is displayed. The “]”mark
shifts to right (from “1”to “2”) and notify that the value is
the next later one.
- Eng 10 -
