Citizen 19CL705 User manual

USER MANUAL
19CL705
19” LCD Television
Easy PC Connection
Customize your Picture and Sound
www.citizen-electronics.com

Table of Contents
Important Safety Instructions……………………………………… 1
Packing List…………………………………………………………. 4
Batteries for Remote Control……………………………………… 5
Remote Control……………………………………………………... 7
Product Overview…………………………………………………… 8
Installation…………………………………………………………… 10
Menu Operation…………………………………………………….. 10
(1) Picture Setting Menu……………………………………….. 10
(2) Sound Setting Menu………………………………………... 12
(3) Channel Setting Menu……………………………………… 13
(4) Timer Setting Menu…………………………………………. 13
(5) Function Setting Menu……………………………………… 14
Parental Controls…………………………………………………… 14
Sleep Timer…………………………………………………………. 17
Trouble Shooting……………………………………………………. 18
Warranty Information……………………………………………….. 19
Note: All images in this manual are for example only. Actual product may
differ from these images.

1
PAGE 1
injuries and property damage if improperly handled. This product has been engineered and
manufactured with the highest priority on safety. But IMPROPER USE CAN RESULT IN
POTENTIAL ELECTRICAL SHOCK OR FIRE HAZARD. In order to prevent potential danger,
please adhere to the following instructions when installing,operating and cleaning this product.
To ensure your safety and prolong the service life of your LCD TV product, please read the
following precautions carefully before using this product.
wide slot of the wall power outlet, and fully insert. Refer to the
1、Read these instructions---All operating instructions must be read and understood before
the product is operated.
2、Keep these instructions---These safety and operating instructions must be kept in a safe
place for future reference.
3、Heed all warnings--- All warnings on the product and in the instructions must be observed
closely.
4、Follow all instructions---All operating instructions must be followed.
5、Attachments---Only use attachments/accessories specified by the manufacturer. Do not
use attachments not recommended by the manufacturer. Use of improper attachments can
result in malfunction or injury.
6、Groundingconnection---This apparatus shall be connected to a MAINS socket with properly
grounded outlets.
7、Power source---This products power consumption information is located on the rear Rating
Label. If you are not sure of the type of power supply to your home, consult your product
dealer or local power company. For added protection for this product during a
8、Power cable protection --- Protect the power cable from being walked on or pinched
apparatus.
Caution: To reduce the risk of
electric shock, do not remove
cover (or back). No user
serviceable parts inside.
Refer servicing to qualified
service personnel.
This symbol indicates
“DANGEROUS VOLTAGE”
inside the product that
presents a risk of electric
shock or personal injury.
This symbol
indicates
important
instructions
accompanying
product.
Important Safety Instructions
CAUTION
RISK OF ELECTRIC
SHOCK.
DO NOT OPEN.
Electrical energy can perform many useful functions, but it can also cause personal
Caution:To prevent electric shock,match wide blade of the power plug to
lightning storm,
or when it is left unattended and unused for long periods of time,unplug it from the wall outlet
and disconnect the cable connection.
particularly at the plugs, convenience receptacles, and the point where they exit from
the
WARNING
moisture.
To reduce the
risk of fire or
electric shock, do
not expose this
product to rain or
identification/rating label located on the back panel of your product for its
proper operating voltage.
Do not expose this
damage.
apparatus to
dripping, splashing,
or liquid filled
objects such as
vases. Doing so
may cause potential

2
PAGE 2
9、Power plug
product for its proper operating voltage.
11、Overloading---Do not overload wall outlets, extension cables, or convenience receptacles
on other equipment as this can result in a risk of fire or electric shock.
so may cause electric shock and/or damage to the television
13、Damage requiring service--- Refer all servicing to a qualified service technician. Servicing
is required when the apparatus has been damaged in any way. Possible conditions of
damage are as follows:
a. When the power cable or plug is damaged.
b. When a liquid is spilled on the product or when objects have
fallen into the product.
c. When the product has been exposed to rain or water.
Improper adjustment of controls not described in the instructions can cause damage,
which often requires extensive adjustment work by a qualified technician.
e. If the product has been dropped or the cabinet has been damaged in any way.
f. When the product displays an abnormal condition or exhibits a distinct change in
performance. Any noticeable abnormality in the product indicates that the product
needs servicing.
Warning: This unit should only be serviced by an authorized and properly trained
technician.
Opening the cover or other attempts by the user to service this unit may result in serious
injury or death from electrical shock, and may increase the risk of fire.
14、Replacement parts---In case the product needs replacement parts, make sure that the
same characteristics and performance as the original parts. Use of unauthorized parts
can result in fire, electric shock and/or other danger.
15、Safety checks---Upon completion of service or repair work, request the service
technician to perform safety checks to ensure that the product is in proper operating
condition.
16、Wall mounting---To ensure proper safety when mounting this television, be sure to
install the product according to the method recommended by the manufacturer.
17、Stand--- Do not place the product on an unstable trolley, stand,
tripod or table. Placing the product on an unstable base can
cause the product to fall, resulting in serious personal injury
as well as damage to the product. When mounting the product
Refer to the identification/rating label located on the back panel of your
12、Entering of objects and liquids---Never insert any objects or liquids into the ventilation
---
The disconnect device shall remain readily operable.
10、The MAINS plug or appliance coupler of this apparatus is used as the disconnect device.
holes or openings on this television. High voltage flows through this television,and doing
d. When the product does not operate properly as described in the
operating instructions.
Do not touch the controls other than
those described in the operating instructions.
on a wall, be sure to follow the manufacturer’s instructions.
service technician uses replacement parts specified by the manufacturer, or those with the

3
PAGE 3
18、Careful move--- Use only the cart, stand, tripod, bracket, or table
specified by the manufacturer, or sold with the apparatus. When a cart
is used, use caution when moving the cart/apparatus combination to
avoid injury from tip-over. Sudden stops, excessive force and uneven
floor surfaces can cause the product to fall from the trolley.
19. Lightning---Unplug this apparatus during lightning storms or when
unused for long periods of time.
For added protection for this television equipment during a lightning
storm, or when it is left unattended and unused for long periods of
time, unplug it from the wall outlet and disconnect the antenna. This
will prevent damage to the equipment due to lightning and power-line
surges.
20. Do not use this apparatus near water---for example, near a
bathtub, washbowl, kitchen sink, or laundry tub, in a wet
basement, or near a swimming pool.
Do not use immediately after moving from a low temperature to
high temperature environment, as this causes condensation,
which may result in fire, electric shock, or other hazards.
flame sources (such as candles) on this television. Doing so
may cause electrical damage and or fire.
22. Clean only with a dry cloth---Unplug this product from the wall
outlet before cleaning. Do not use liquid cleaners or aerosol
cleaners. Use only a dry cloth for cleaning.
23. Ventilation---Do not block any ventilation openings. Install in
accordance with the manufacturer's instructions. The vents and
other openings in the cabinet are designed for ventilation. Do not
cover or block these vents and openings since insufficient
ventilation can cause overheating and/or shorten the life of the
product. Do not place the
product on a bed, sofa, rug or other similar surface, since they can block ventilation
openings. This product is not designed for built-in installation; Do not place the product in
an enclosed space such as a bookcase or rack, unless proper ventilation is provided or the
manufacturer’s instructions are followed.
24. Heat sources---Do not install near any heat sources such as
radiators, heat registers, stoves, or other apparatus (including
amplifiers) that produce heat.
25. Using video games or any external accessory with fixed images for 10
minutes can cause them to be permanently imprinted on the screen.
Also, some network/program logos, phone numbers, teletext and images in 4:3 format
etc. may cause similar damage. This damage is not covered by your warranty.
26. Panel protection---The LCD panel used in this product is made
of glass. Therefore, it can break when the product is dropped or
impacted upon by other objects. Be careful not to be injured by broken
glass pieces in case the LCD panel breaks.
27. Pixel defect---The LCD panel is a very high technology product, giving
you finely detailed pictures. Occasionally, a few non-active pixels may appear on the screen
as a fixed point of blue, green or red. Please note that this does not affect the performance
of your product.
21. Do not place heavy foreign objects, liquid containers, or open

4
PAGE 4
28. When the LCD TV reaches its end of life and needs to be disposed. Please contact your
local waste disposal facility to arrange proper disposal procedures.
29. Working condition of the product: Temperature: 0℃~40℃
Storage condition of the product: Temperature: -20℃~50℃
Notes:
①Please note that the menus and illustrations in this manual may differ from those in your
actual television.
②Upon initial setup, please make sure that all equipment is powered off.
LCD TV 1
Operation Manual 1
Inf rared Remote Cont rol 1
AC Power Cable 1
AAA Batt er ies 2
Note:
Please keep all packaging materials for future convenient use when transporting this item.
PACKING LIST

5
PAGE 5
BATTERIES FOR REMOTE CONTROL
If the remote control fails to operate the LCD TV functions, replace the batteries in the
remote control.
1. Push down to open the battery
cover.
2. Insert two AAA-size batteries. 3. Close up the cover until the
lock clicks.
●Place the batteries with their
terminals corresponding to the (+)
and (-) indications in the battery
compartment.
Precaution on battery use
Improper use of batteries can result in a leakage of chemicals and/or explosion.
Be sure to follow the instructions below.
●Place the batteries with their terminals corresponding to the (+) and (-) indications in the
battery compartment.
●Different types of batteries have different characteristics. Do not mix batteries of different
types.
●Do not mix old and new batteries. Mixing old and new batteries can shorten the life of new
batteries and/or cause old batteries to leak chemicals.
●Remove batteries as soon as they are non-operable. Chemicals that leak from batteries
can cause a rash. If chemical leakage is found, wipe with a damp cloth.
●The batteries supplied with the product may have a shorter life expectancy due to storage
conditions.
If the remote control is not used for an extended period of time, remove the batteries from the
remote control.
Radio Frequency input; support CATV
It can store 181 TV channels
AV input
Used to connect a DVD Player, VCR, or Video Camera.
Y/C component signal input (same as S-VIDEO input)
Convenient for hooking up a DVD Player to receive better picture quality.
GENERAL INFORMATION

6
PAGE 6
YPBPR input
MTS Stereo Decoding Function
Enjoy stereo, bilingual and mono programs.
VGA input
a. This television can be used as a monitor by connecting it to a computer.
By connecting the 3.5mm audio cord from your computer into this television, you will be
able to listen to audio from your computer on this television.
Blue background without signal
When no signal is detected in the TV, AV, S-VIDEO, and YPBPR modes, a soft blue
background is displayed. This is not a malfunction. Please ensure that all the appropriate
cables are connected.
Multi Language On-Screen Display menu
Ordinary and graphical user interface makes the menu operation user-friendly
Power Energy Saving Mode (Power management mode)
power off within 30 seconds and enter into the Power Energy Saving Mode. It will
automatically work again when it receives a signal from the PC. In addition, you can press
the number buttons or【】/【CH+】/【CH-】/【】/【】on the remote control.
Plug and Play
Adjust the picture’s quality automatically
No flicker, no radiation, or greenness.
Auto on as time is set

Legerity, convenient, low power consumption
Headphone output
MACROVISION auto identification function
CCD Function
Zoom mode
There is no need to equip any installation software when the product is used as a
computer monitor.
When used as a PC display terminal without a PC signal output,the LCD TV will automatically
b.
Use as the
display terminal
576P,
Capable of receiving high definition Component video signal in 480i, 480P, 576i,
720P, 1080i formats.

7
PAGE 7
Remote Control

8
PAGE 8
Front Panel
PRODUCT OVERVIEW
POWER INDICATOR / INFRARED SENSOR
POWER ON / OFF
RECALL :Return to the last viewed program
P.MODE : Select different modes of picture settings
S.MODE : Select different modes of sound settings
MENU : To go to the On Screen Display (OSD) menus
【】：Channel Up/Up
【】: Channel Down/Down
【】: Volume Down/Left
【】: Volume Up/Right
CH+ : Scroll to next channel
CH- : Scroll to previous channel
VOL- :Decrease audio volume
VOL+ : Increase audio volume
OK : Select or confirm menu item
DISPLAY : Show info of current program
CCD : Press to display the closed caption
POWER ON/OFF : Power the television on/off
0-9 Channel Keys : Key in the numeric digits to switch to the designated channel directly
SLEEP : Select TV's off (sleep) time
MUTE : Mute sound
AV/TV: Toggle between different signal sources available
MTS: Switch between Mono/Stereo/SAP.
ZOOM : Adjust displayable aspect ratio

9
PAGE 9
The button names and functions are as follows:
Panel buttons
Button Description
【TV/AV】To switch between TV, AV, S-VIDEO, YPBPR, and PC signal sources.
The same function as【AV/TV】on the remote control.
【MENU】To enter or quit from the OSD (On Screen Display) menu.
The same function as【MENU】on the remote control
【VOL-】function as【】on the remote control
【VOL+】function as【】on the remote control
【CH-】
1. In TV mode, decrease the channel number
2. To select functions in menu operation.
The same function as【】on the remote control
【CH+】
1. In TV mode, increase the channel number
2.To select functions in menu operation.
【】To turn the LCD TV to STANDBY mode or press again to exit STANDBY mode.
The same function as【】on the remote control .
Note:
In this operation manual, 【】symbol means Button.
Illustration of Signal Input Ports
To decrease the sound volume. Adjust functions in menu operation.
The same
To increase the sound volume. Adjust functions in menu operation.
The same
The same function as【】on the remote control

10
PAGE 10
1. Remove the LCD TV from the box and place it on a flat surface in a well ventilated
location.
2.
RF Cables.
3. Connect the output terminal of the AV devices such as a DVD/VCR to the corresponding
terminal on the LCD TV.
4. Connect one end of the PC terminal to the corresponding signal source terminal, and
connect the other end to the corresponding LCD TV terminal. Screw down the screws on
both sides to secure it.
Caution: When connecting, plug directly but cautiously to the interface, otherwise you will
damage the pins.
5. Ensure that every AV signal cable is correctly connected to the corresponding interface.
6. Connect one end of the power cord to the power input jack of the LCD TV, then plug the
other end to the nearest wall outlet.
1. Use the On Screen Display menu to set and adjust functions.
2. Use 【
/【】to enter the corresponding menu option and use【】/【】to choose from the options;
【MENU】again. Note: The menu will disappear without any operation within 60 seconds.
Menu Operation in TV, AV, S-VIDEO, YPBPR and PC modes
(1) Picture Setting Menu
zIn TV mode
Item Function Description
Contrast To adjust the picture’s contrast.
Brightness To adjust the picture’s brightness.
Tint To adjust the picture’s tint. (For NTSC signal only)
Saturation To adjust the picture’s saturation.
Sharpness To adjust the picture’s sharpness.
Color Temp. To adjust the color temperature
Picture Mode Normal, Soft, Vivid and User (four picture modes are provided)
Installation
Menu Operation
Connect the output terminal of the RF cable to the corresponding TV RF signal input terminal.
The LCD TV is a high-tech digital product. To obtain optimal results,please use quality
】/【】to select the desired menu after pressing【MENU】, then press 【】
Use 【】/【】to adjust the options value and return to the previous menu by pressing

11
PAGE 11
Advance There are three built-in functions for enhancing the quality of the
Press【】and【】to enter into the sub-menu of Color Temp for picture control, the
display is as follows:
Only when the Color Temp is set as User mode, you can change the value of Red, Green
or Blue.
Press 【】and【】to enter into the sub-menu of Advance for picture control, the display
is as follows:
Press【】and【】to select the item in cycle, and then press 【】and【】to set the
selected item.
zIn PC mode
Item Function Description
LTI Luminance Transient Improvement
CTI Chroma Transient Improvement
Black Stretch Improves gradation of picture
picture, LTI (Luminance Transient Improvement), CTI (Chroma
Transient Improvement) and Black Extend.

12
PAGE 12
Item Function Description
Contrast To adjust the picture’s contrast.
Brightness To adjust the picture’s brightness.
H Position To adjust the picture’s Horizontal Position
V Position To adjust the picture’s Vertical Position.
Clock To adjust the picture’s sampling frequency
Phase To adjust the picture’s sampling phase.
Color Temp. To adjust the color temperature
Auto Adjust To automatically adjust the picture’s Horizontal and
Press【】and【】to enter into the sub-menu of Color Temp for picture control, the
display is as follows:
Only when the Color Temp is set as User mode, you can change the value of Red, Green
or Blue.
(2) Sound Setting Menu
Item Function Description
Bass To adjust the accompanying sound’s bass
Treble To adjust the accompanying sound’s treble
Balance To adjust the balance between right and left track
Sound Mode User, Music, News and Theatre (four sound modes are provided)
Vertical
Position

13
PAGE 13
(3) Channel Setting Menu
Item Function Description
Source Switch the TV input mode between cable and air.
Channel Display the current channel number, you can switch between the
channels through the 【】or【】
Add/Erase Erase or add the channel.
Color System Select this item, and then press【】or 【】to select one of the
Buttons.
color modes.
Auto Search Press【】and【】to enter into Auto Search, if【MENU】is pressed
during searching, the system will quit from automatic searching mode
and go back to the previous channel setting menu.
】
buttons to select the color system of signal sources.
Note: There is no channel menu in S-VIDEO, YPBPR or PC mode.
(4)Timer Setting Menu
In AV mode, there is only the Color System option under the Channel menu, use the【】【/

14
PAGE 14
(5)Function Setting Menu
◆Language
OSD language selection, the TV has English and other OSD languages.
◆Transparency
Menu transparency selection, you can select menu transparency according to the different
background pictures, there are nine options for menu transparency (0, 1, 2, 3, 4, 5, 6, 7 and
8)
◆Reset
Select this item, and restore to the original setting by pressing【
◆Blue Screen
The on and off modes of blue Screen are as follows:
When there is no TV signal When there is no other signals
On Blue Screen Blue Screen
Off Pictures spotted with snowflake Black Screen
◆Closed Caption
You can select Closed Caption, if available,
to be displayed on screen.
◆Parent Ctrl
You may prevent children from watching programs not suitable for them, such as adult or
violent programs.
Press【】/【】to enter the Parent Control Menu. The default password is “0000”.
】/【】, after this
Item Function Description
Current
Time Set the current time by pressing 【】/【】to change the time
parameter (hour:minute ).
Off Time Set the time to turn off the TV by pressing【】/【】to change the time
parameter (hour:minute ).
On Time Set the time to turn on the TV by pressing【】/【】to change the time
parameter (hour:minute ).
On Channel Set the channel for turning on the TV by pressing 【】/【】.
On Source Set the source for turning on the TV by pressing 【】/【】.
Timer Mode Set the timer mode, there are modes of “Off”, “Once” and “Always”.
operation, all of the settings made by the user will be replaced by the original setting
parameters.

15
PAGE 15
◆Change Passwords
In Parent Control mode, press【】/【】to see the password submenu. Press the
number button to enter the password. The default password is “0000”.
Press the number button on the remote control to set the new password. When the new
menu.
◆Parent Ctrl (ON/OFF)
When Parent Ctrl is OFF, no programs are blocked from viewing.
TV Ratings
TV-Y: All children Fv: Fantasy Violence
TV-Y7: Directed to older children D: Suggestive Dialogue
TV-G: General Audience L: Strong Language
TV-14: Parents Strongly Cautioned V: Violence
TV-MA: Mature Audience only
◆English Rating
For Canadian English Language Rating System, the following seven ratings are available:
E : Exempt
C : Children
C8+ : Children eight years and older
G : General programming, suitable for all audience
PG : Parental Guidance
※After a password correction has been confirmed, please remember it for entering into
the Parent Ctrl menu, all functions can not be activated until the correct password is
entered. If you forget your password, the master password of “8888” is still valid.
TV-PG: Parental Guidance suggested S: Adult situation
password has been inputted twice, the setting has finished successfully. The TV will go back
to the previous
14+ : Viewers 14 years and older
18+ : Adult Programming

16
PAGE 16
◆French Rating
For Canadian French Language Rating System, the following six ratings are available:
E : Exempt
G : General programming, suitable for all audience
: Children 13 years and older
: Children 16 years and older
: Adult Programming
zSound Mode Selection
Press 【S.MODE】to select between User, News, Theater and Music modes. The last
three modes are default settings that cannot be adjusted. Entering the User mode allows
the settings to be adjusted to the users preference.
Sound Mode Sound Quality
User For the user’s preference
Music For general music programs
News For general programs of conversations and news report
Theater For better audience effect as soft, magnificent and vivid
Note: The operation and setting of the Volume Control are applicable to all signal
sources.
zPicture Mode Selection
Press【P.MODE】to Switch among User, Soft, Normal and Vivid modes.
Picture Mode Picture Quality
User For the user’s preference
Normal For general programs
Soft For more mellow pictures
Vivid For better visual effect such as magnificent and vivid
Note: Picture Mode Selection settings are the same for all video input source modes.
zBacking Out Function
Press 【RECALL】on the remote control, the TV will quickly go back to the previous
channel if the last operation is selecting channel. If the last operation is switching the signal
source, the TV can quickly go back to the previous signal source by pressing 【RECALL】
on the remote control.
zMTS
① Capable of identifying MTS with the control status: the TV will memorize SAP after it
is identified: the TV will memorize Stereo after it is identified;
② There is an OSD display to show the changes in broadcasting signals:
: Children 8 years and older
③ Press 【MTS】to switch between MONO,STEREO and SAP.
E, G, 8 ANS +, 13 ANS +, 16 ANS +, 18 ANS +
8 ANS +
13 ANS +
16 ANS +
18 ANS +
