Citrocasa 8000 XB Advance User manual

Instruction Manual & Documentation
Version: 17.05.2018
Citrocasa 8000 XB Advance Art.No.: 80.002 Version 11-ADV
Citrocasa 8000 SB Advance Art.No.: 90.002Version 11-ADV
Citrocasa 8000 SB-ATS Advance Art.No.: 90.002/ATS Version 12-ADV
When ordering spare parts, be sure to mention machine type, article and serial number.
Industriezeile 47, 4020 Linz, Austria
Tel.: [phone]
Fax: [phone]
E-mail: [e-mail]
8000 XB Advance
8000 SB-ATS Advance
Original Instruction Manual
8000 SB Advance

2
Contents
1. IMPORTANT GENERAL INFORMATION ........................................................... 3
1.1. IMPORTANT INFORMATION ............................................................................................................5
2. TECHNICAL SPECIFICATIONS........................................................................... 5
3. GUARANTEE................................................................................................... 6
4. OPERATING INSTRUCTIONS............................................................................ 7
4.1. FIRST STEPS ......................................................................................................................................7
4.2. CHOICE OF THE DISPLAY LANGUAGE ............................................................................................ 10
4.3. OPERATING THE MACHINE ........................................................................................................... 11
4.3.1. Operation of the 8000 XB Advance....................................................................................... 12
4.3.2. Operation of the 8000 SB & 8000 SB-ATS Advance .............................................................. 14
4.4. CLEANING INSTRUCTION .............................................................................................................. 21
5. TROUBLESHOOTING..................................................................................... 31
6. ZERTIFICATES ............................................................................................... 33
7. MOST IMPORTANT SPARE PARTS................................................................. 44

3
1. IMPORTANT GENERAL INFORMATION
This manual refers to the following model from Citrocasa:
Art.No.: 80.002 8000 XB Advance Version 11 ADV
Art.No.: 90.002 8000 SB Advance Version 11 ADV
Art.No.: 90.002/ATS 8000 SB-ATS Advance Version 12 ADV
The technical data of the Citrocasa commercial Orange juicers (tension, frequency and other data)
is located on the identification plate, which is both on the back page of this operating/instruction
manual as well as on the equipment itself.
• For all technical questions, please refer to your official dealer or official customer service
representative and mention the article and serial number of your machine which can be found
on the rear side of the machine.
• Clean all areas and parts of the machine which come into contact with fruit or juice before
initial operation as shown in the cleaning instruction.
• Before cleaning the machine, making any repairs or maintenance, it is obligatory to follow these
instructions:
1. Operate machine until no more fruits are left in the pressing area.
2. Switch off machine according to specification of the instruction manual (depending on the
machine type: by automatically stop, by pushing ON/OFF button of the machine or by
releasing SB tap) and remove all remaining fruits or parts of the fruits manually of the
pressing area and/or machine.
3. Finally switch off main power of the machine and unplug machine from power supply.
• Citrocasa meets the necessary measures for a selective disposal of the devices brought on the
market and provides for an environmentally friendly subsequent treatment. Please dispose of
your machine in a proper way by contacting your official dealer/supplier.
• Our machines are certified and in accordance with the CE, GS, NSF and TUV safety standards.
• Before operating the machine for the first time, we ask you to please read the instruction manual
carefully.
• For safety reasons, only authorized personal is allowed to make any repairs or changes on the
machine. Also, no protection or safety equipment is to be changed, removed or tampered with.
• Due to the fact that no adjustments on the machine are necessary, we ask you to not open the
inside of the machine at any time.

4
• Only authorized service technicians are permitted to make any repairs to the inside of the
machine.
• In case of damage to the machine, we ask you to either contact CITROCASA directly or contact
your dealer who supplied you with the machine.
• Before cleaning the machine, always unplug the machine from its power supply
• Only use original spare parts and accessories from Citrocasa.
• We give our best effort to provide you with a maximum amount of information in this document.
Should you need further information, we ask you to contact us or your dealer. We will be glad
to answer any questions you may have.
• In our constant efforts to better our products, we reserve the right to make any changes to this
instruction manual without prior notice.
• Should you have any suggestions to improvement, questions or comments, please feel free to
contact us with the contact information provided below:
Industriezeile 47, 4020 Linz, Austria
Tel.: [phone]
Fax: [phone]
E-mail: [e-mail]
This unit can be used by children aged 8 years and above and persons with reduced
physical, sensory or mental capabilities or lack of experience and knowledge when they
have been given supervision or instruction concerning the safe use of the device and
understand the resulting risks. Do not let children play with this device. Cleaning and
user maintenance must not be carried out by children without supervision.
If the supply cord is damaged, it must be replaced by the manufacturer, its service agent
or similarly qualified persons in order to avoid a hazard.
Care is needed when handling cutting blade during cleaning.
The machine does not be cleaned with a water jet.
Correct Disposal of this product: …………………………………
This marking indicates that this product should not be disposed with
other household wastes throughout the EU. To prevent possible harm
to the environment or human health from uncontrolled waste disposal,
recycle it responsibly to promote the sustainable reuse of material
resources. To return your used device, please use the return and
collection systems or contact the retailer where the product was
purchased. They can take this product for environmental safe recycling.

5
1.1. IMPORTANT INFORMATION
In order to ensure a proper functioning of the machine and in order to avoid injury, we
ask you to please follow the following points:
1. The fastening screws of the cross holder cannot be loose or missing. ……………………
2. Do not place any foreign objects in the machine as this may cause unnecessary damage.
3. Should machine blockage occur, it is important to disconnect the machine from its power
supply, only then is the front cover to be removed in order to remove orange peels.
4. Never try to remove blockages while the machine is operating. This could lead to serious
injury.
5. Due to the fact that the peel removers and the knife are important functional parts of the
machine, ensure that these parts are mounted carefully and correctly.
2. TECHNICAL SPECIFICATIONS
MODEL
8000 XB
8000 SB
8000 SB-ATS
Oranges per minute
40 pieces
40 pieces
40 pieces
Measurements
100x60x55 cm
s
Counter unit:
177,5x677,5x66,3 cm
100x60x63,5 cm
Counter unit:
177,5x67,5x66,3 cm
100x60x63,5 cm
Counter unit:
177,5x67,5x66,3 cm
Net weight (in kg)
72 kg
75,5 kg
78,5 kg
Gross weight (in kg)
77 kg
81 kg
84 kg
Power supply
230V/50-60Hz
230V/50-60Hz
230V/50-60Hz
Power
028 kW
0,28 kW
0,28 kW
Fuse Protection
IPx1
IPx1
IPx1
Optimum fruit size
65 to 78 mm
65 to 78 mm
65 to 78 mm

6
3. GUARANTEE
- Our quality and examination controls ensure that the machine was supplied in perfect
condition.
- The guarantee covers all complaints caused by construction or material defects which
influence the optimal operation of the machine.
- The guarantee does not cover any damages caused by improper usage of the machine.
- Any changes to the identification plate nullify all possibilities of any guarantee claims.
- Only qualified service personal is allowed to make any repairs or changes on the
machine, should a 3rd person work on the machine, this will make any guarantee claims
invalid.
- Should you need service or spare parts, always mention the correct article number or
serial number of the machine.
GUARANTY DURATION: One (1) year from the time of installation.
EXCEPTIONS: LABOR COSTS, DRIVING COSTS, DELIVERY COSTS AND PARTS WHICH
ARE USED BY NATURAL WEAR AND TEAR.

7
4. OPERATING INSTRUCTIONS
4.1. FIRST STEPS
Before operating the machine for the first time, please observe the following:
8000 XB-ADV, 8000 SB-ADV, 8000 SB-ATS-ADV
- After unpacking the machine, ensure that the machine is placed on a flat ground.
- Ensure that the MTS-System (and self service tap with the 8000 SB+SB-ATS) are mounted
properly as shown in Picture 1 and Picture 2. Ensure that the front cover is closed and
mounted properly. Take care that at the 8000 SB-ATS machine the ATS-System has to be
installed instead of the fruit MTS-System.
- Install the splash protector at the machine.
- Make sure that the electrical power is available as indicated on the serial plate.
- Plug the machine into a standard grounded outlet. Switch on the machine on the rear side of
the machine. See Picture 3:
Fruit sieve holder
SB tap
MTS system
ATS system
Splash protector
Picture 1
Picture 2
Main switch
Picture 3

8
If the Citrocasa 8000 Advance is to be operated with the Cabinet 8000 Advance, please observe
the following points:
1. Leave enough room for the cabinet door to be opened, allowing access for the waste
container to be removed.
2. Place the rolling stand on a flat and even surface. Engage the brakes on the front wheels.
(see Picture 4)
3. Put the machine on the Cabinet 8000 Advance.
4. Mount the machine to the cabinet by screwing it into place as shown in Picture 5.
- Place the drip tray, drip plate (see Picture 6) and waste container (Picture 7) in its proper
place.
For the 8000XB Advance, place the juice tank, mix arm and cover in the foreseen pins on the
rolling stand. (see Picture 8)
Drip tray
Juice tank pins
Drip plate
Waste container
Picture 5
Picture 4
Picture 6
Picture 7
Picture 8

9
- Insert the peel chutes (left and right) in the cut-outs (see Picture 9) next to the juice tank.
Attention:
Use only the special ATS side chutes and drip plate for the 8000 ATS machines!
- Use the mix arm before releasing any juice out of the tank in order to mix the pulp with the
juice.
- By not using the mix arm accordingly, pulp can accumulate in the tap and cause
blockage.
Peel chutes
Picture 9

10
4.2. CHOICE OF THE DISPLAY LANGUAGE
It is possible to choose between 5 different display languages:
• English
• German
• Spanish
• French
• Italian
Please follow the points below, to choose your required display language:
- Picture 10: Switch on the main power switch located at the side of the machine. The control
lamp lights up.
- Picture 11: No. 1: Select with the FUNC-Button the menu item “Choose language”
- Picture 11: Nr. 2 & 3: Select your required language by pressing the ON and OFF-Button / +
and - Orange button together.
- Picture 11: Nr. 1: Afterwards select with the FUNC-Button the required menu item. Due to
this fact the display language is stored.
Picture 10
Picture 11
8000 SB/SB-ATS Advance
8000 XB Advance
1
3
2
1
3
2

11
4.3. OPERATING THE MACHINE
- Fill the fruit basket with oranges. Do not use fruits larger than 80mm in size. To make sure
that the machine works properly, use fruits between 65 – 8 mm in diameter.
(Picture 12)
Picture 12

12
4.3.1. Operation of the 8000 XB Advance
Place a glass or another container under the juice outlet. To begin the pressing procedure, follow
the instructions mentioned below:
Digi-Mode
- Picture 13: Switch on the main power switch located at the side of the machine.
The red control lamp lights up.
- Picture 20: No. 1 FUNC button: Select the Digi mode by pressing this button.
„push “ON”“ is indicated on the display.
- Picture 15: No. 3/4/5: Select with the ▲/▼ orange button the amount of oranges which
should be pressed. (0-99 oranges)
- Picture 14 & 15: No. 6: Start the machine with the ON/OFF-button. The machine stops
automatically a soon the indicated amount of oranges was pressed. The current amount of
pressed oranges is shown at the display (no. 6).
- Picture 15: No. 2: With the +1 button one more orange will be pressed.
Picture 13
Picture 14
1
3
2
4
5
6
Picture 15

13
Continuous Mode:
- Picture 16: Switch on the main power switch located at the side of the machine.
The red control lamp lights up.
- Picture 18: No. 1 FUNC button: Select the continuous mode by pressing this button.
„Continuous Push “ON”“ is indicated on the display.
- Picture 17: Start and stop pressing with the ON/OFF button.
Picture 17
Picture 16
Picture 18
1

14
4.3.2. Operation of the 8000 SB & 8000 SB-ATS Advance
Place a glass or another container under the juice outlet. To begin the pressing procedure, follow
the instructions mentioned below:
Self-Service Mode:
- Picture 19: Switch on the main power switch located at the side of the machine.
The red control lamp lights up.
- Picture 20: No. 1 FUNC button: Select the self-service mode by pressing this button.
„Self service Push “Press”“ is indicated on the display.
- Picture 21: Stop and start the machine by pressing the self-service button. (SB-tap)
Picture 19
Picture 21
Picture 20
1
Self Service Tap

15
Continuous Mode:
- Picture 22: Switch on the main power switch located at the back of the machine. The red
control lamp lights up.
- Picture 23: No. 4: Activate switch to position AUTO.
- Picture 23: No. 1: Select the continuous mode by pressing the FUNC-Button. „Continuous
Push “ON”“ is indicated on the display.
- Picture 23: No. 2 ON button: Start pressing the fruits (continuous mode)
- Picture 23: No. 3 OFF button: Stop pressing the fruits (continuous mode)
Picture 22
Picture 23
1
3
2

16
Automatic stop function
It is possible to adjust the machine that it stops after a certain amount of oranges → Peel bucket
full! Please find the description below:
- Picture 24: Switch on the main power switch located at the side/rear of the machine. The
control lamp lights up.
- Picture 25: No.1: Select the function “Empty bucket after “xx” oranges” with the FUNC-button
- Picture 25: No.2/3: Adjust the amount of oranges after the machine should stop with the ON-
button + and OFF-Button -.
- Start the machine in the desired mode.
- As soon as the machine has reached the adjusted amount of oranges, it stops, peeps 5 times
and will be locked!
- Picture 25: No.3: To unlock the machine empty the peel bucket and press the OFF-Button
/▼-Button for 5 sec.
- Afterwards the machine can be started again.
Picture 24
8000 SB/SB-ATS Advance
8000 XB Advance
Picture 25
1
3
2
1
3
2

17
Attention
- Switch off intelligent stop function
To switch off the intelligent stop function please adjust to 00 oranges!
- Switch on intelligent stop function (adjusted orange changed from 00 – XX)
Adjust the amount of pressed oranges – start the machine and press one orange –
Machine stops automatically – Press OFF-button 5 sec – amount of oranges is saved!
Recommended adjustment regarding the intelligent stop function:
8000 Series
Peel bucket
Recommended adjustments
Peel bucket
40 oranges
Cabinet / Countertop installation kit
150 oranges

18
Lock/Unlock function of the display
It is possible to lock the display that the adjusted mode cannot be changed unintentionally. Please
find the description below:
- Picture 26: Switch on the main power switch located at the side/rear of the machine. The
control lamp lights up.
Lock display
- Picture 27: No.2: Adjust the desired display function
- 8000 SB & 8000 SB-ATS Advance
Picture 27: No.1+2: Press the OFF-Button + FUNC-Button → Display locked
- 8000 XB Advance
Picture 27: No.1+2: Press the FUNC-Button + +1-Button → Display locked
The display is locked and the adjusted mode cannot be changed unintentionally. If the FUNC-
button is pressed the display shows how to unlock the display - “Unlock key panel Push OFF &
FUNC” or “Unlock key panel Push FUNC & <+1>”!!
Picture 26
1
2
1
2
Picture 27
8000 SB/SB-ATS Advance
8000 XB Advance

19
Unlock display
- 8000 SB & 8000 SB-ATS Advance
Picture 27: No.1+2: Press the FUNC-Button + OFF-Button → Display unlocked
- 8000 XB Advance
Picture 27: No.1+2: Press the FUNC-Button + +1-Button → Display unlocked
Display Function – Amount of pressed oranges
- Picture 29: No. 1 FUNC button: Press this function button to indicate the total number of
pressed fruits.
8000 SB/SB-ATS Advance
8000 XB Advance
Picture 29
1
1
8000 SB/SB-ATS Advance
8000 XB Advance
Picture 28
2
2
1
1

20
Display Function – Operation time
- Picture 30: No. 1 FUNC button: Press this function button to indicate the total operating time.
Factory mode (Only for technician)
The factory mode is used to adjust different parameters of the machine. This function should only
be used from technician and is locked with a password.
- Picture 31: No.1: To skip the factory mode press the FUNC-Button
Picture 30
1
1
8000 SB/SB-ATS Advance
8000 XB Advance
8000 SB/SB-ATS Advance
8000 XB Advance
Picture 31
1
1
