croydon ES4EA User manual

ES4EA-160001-A4
JUICER - MODEL ES4EA-160001-A4
-PLEASE read these instructions carefully before operating this appliance.
IMPORTANT
-This unit is designed to operate on alternative current (A.C.) only.
-DO NOT CONNECT TO DIRECT CURRENT (D.C.)
-Do not leave unit in operation without an attendant.
-When not in use for long period unplug the appliance.
INSTALLATION AND OPERATION
-Check if voltage of your power system corresponds to the same specified on the
appliance label.
-Assembly the Unit Top (Bowl) on the Juicer.
-Place the desired juicer implement on the drive shaft (the large implement for orange
and the small for lemon).
-Put the strainer in the juicer cup and position near the outlet of the top unit drain to catch
the juice.
-Turn on the appliance switch and place the fruit (orange or lemon cut in half) on the
spinning implement and carefully press down.
-To turn off the appliance turn off the switch.
CLEANING PROCEDURE
-Immediately after having been used, to avoid change of juice taste, wash with water the
juicer cups, strainer, implement and top unit (Bowl).
-Unplug Juicer and clean body and base, using only a damp cloth.
-Never use water jet or immerse appliance in water.
-Wipe off appliance with a dry cloth.
INSTRUCTION MANUAL
CROYDON
CROYDON
C
R
N
O
O
Y D
CROYDON
The pictures/drawings are illustrations. All data can be changed without notification.
CROYDONMAQ INDUSTRIAL LTDA.
Estrada São Lourenço, 891 - Capivari
Duque de Caxias - RJ / Brasil - CEP 25243-150
Phone: [phone]
e-mail: [email protected]

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
37.106-3
4.029-3
4.028-3
4.064-3
4.060-3
4.006-3
534
4.007-3
4.205-3
4.057-3
265
643
Under Consult
4.063-3
4.306-3
14.033-3
4.405-3
4.406-3
4.044-3
Lid
Orange Implement
Lemon Implement
Unit Top Protector
Unit Top(bowl)
Shaft
Screw
Motor Protection
Electric Motor
Body
Switch
Washer (3/16")
Nut
Bottom Cover Plate
Big Foot
Cord Connection
Strainer
Cup
Foot
18
17
12
13
15
14
12
13
16
10
9
1
2
3
5
4
6
7
8
11
JUICER (ES4EA) JUICER (ES4EA)
Item Code Description
Wiring diagram
G
L2L1
SWITCH
1 2 34
Voltage (V)
Power (HP)
Amperage (A)
Speed (rpm)
Capacity (l/h)
Weight (kg/lbs)
Dimensions W x H x D (cm/in)
110
1/4
4.8
1700
50
7.6/16.7
25/9.9 x 39/15.4 x 22/8.7
Technical Data
