Citrocasa Fantastic ECO Operator's manual

Instruction Manual & Documentation
Version: 28.05.2018
Citrocasa Fantastic ECO Art.Nr.: 60.500 Version 00
When ordering spare parts, be sure to mention machine type, article and serial number!
Industriezeile 47, 4020 Linz, Austria
Tel.: [phone]
Fax: [phone]
e-mail: [email protected]
Original Instruction Manual

2
Contents
1. IMPORTANT GENERAL INFORMATION ............................................................ 3
1.1. IMPORTANT INFORMATION ..................................................................... 5
2. TECHNICAL DETAILS............................................................................................ 5
3. GUARANTEE .......................................................................................................... 5
4. OPERATING INSTRUCTIONS ............................................................................... 6
4.1. FIRST STEPS ................................................................................................... 6
4.2. OPERATING THE MACHINE ........................................................................... 8
4.3. CLEANING INSTRUCTIONS ............................................................................ 9
5. CERTIFICATES .................................................................................................... 18
6. MOST IMPORTANT SPARE PARTS .................................................................... 23

3
1. IMPORTANT GENERAL INFORMATION
This manual refers to the following model from Citrocasa:
Art.No.: 65.500 Fantastic ECO Version 00
The technical data of the Citrocasa commercial Orange juicers is located on the identification plate,
which is both on the back page of this operating/instruction manual as well as on the equipment itself.
• For all technical questions, please refer to your official dealer or official customer service
representative and mention the article and serial number of your machine which can be found on
the rear side of the machine.
• Clean all areas and parts of the machine which come into contact with fruit or juice before initial
operation as shown in the cleaning instruction.
• Before cleaning the machine, making any repairs or maintenance, it is obligatory to follow these
instructions:
1. Operate machine until no more fruits are left in the pressing area.
• Citrocasa meets the necessary measures for a selective disposal of the devices brought on the
market and provides for an environmentally friendly subsequent treatment. Please dispose of your
machine in a proper way by contacting your official dealer/supplier.
• Our machines are certified and in accordance with the NSF safety standards.
• Before operating the machine for the first time, we ask you to please read the instruction manual
carefully.
• For safety reasons, only authorized personal is allowed to make any repairs or changes on the
machine.
• Due to the fact that no adjustments on the machine are necessary, we ask you to not open the
inside of the machine at any time.
• Only authorized service technicians are permitted to make any repairs to the inside of the machine.
• In case of damage to the machine, we ask you to either contact CITROCASA directly or contact
your dealer who supplied you with the machine.
• Before cleaning the machine, always unplug the machine from its power supply
• Only use original spare parts and accessories from Citrocasa.
• We give our best effort to provide you with a maximum amount of information in this document.
Should you need further information, we ask you to contact us or your dealer. We will be glad to
answer any questions you may have.
• In our constant efforts to better our products, we reserve the right to make any changes to this
instruction manual without prior notice.

4
• Should you have any suggestions to improvement, questions or
comments, please feel free to contact us with the contact information provided below:
Industriezeile 47, 4020 Linz, Austria
Tel.: [phone]
Fax: [phone]
E-mail: [e-mail]
This unit can be used by children aged 8 years and above and persons with
reduced physical, sensory or mental capabilities or lack of experience and
knowledge when they have been given supervision or instruction concerning the
safe use of the device and understand the resulting risks. Do not let children play
with this device. Cleaning and user maintenance must not be carried out by
children without supervision.
Care is needed when handling cutting blade during cleaning.
The machine must not be cleaned with a water jet.
Correct Disposal of this product: …………………………………
This marking indicates that this product should not be disposed with other
household wastes throughout the EU. To prevent possible harm to the
environment or human health from uncontrolled waste disposal, recycle it
responsibly to promote the sustainable reuse of material resources. To return
your used device, please use the return and collection systems or contact the
retailer where the product was purchased. They can take this product for
environmental safe recycling.

5
1.1. IMPORTANT INFORMATION
In order to ensure a proper functioning of the machine and in order to avoid injury,
we ask you to please follow the following points:
1. The fastening screws of the cross holder must not be loose or missing.
………………
2. Do not place any foreign objects in the machine as this may cause unnecessary
damage.
3. Should machine blockage occur, it is important to stop the machine, only then is the
front cover to be removed in order to remove orange peels.
4. Never try to remove blockages while the machine is operating. This could lead to
serious injury.
5. Due to the fact that the peel removers and the knife are important functional parts
of the machine, ensure that these parts are mounted carefully and correctly.
2. TECHNICAL DETAILS
MODEL
Fantastic
Measurements (in cm)
61,3x57,5x56cm
Weight (in kg)
57kg
Drive
Manual drive
Optimum fruit size
65 to 78 mm
3. GUARANTEE
- Our quality and examination controls ensure that the machine was supplied in perfect
condition.
- The guarantee covers all complaints caused by construction or material defects which
influence the optimal operation of the machine.
- The guarantee does not cover any damages caused by improper usage of the machine.
- Any changes to the identification plate nullify all possibilities of any guarantee claims.
- Only qualified service personal is allowed to make any repairs or changes on the machine,
should a 3rd person work on the machine, this will make any guarantee claims invalid.
- Should you need service or spare parts, always mention the correct article number or
serial number of the machine.
GUARANTY DURATION: One (1) year from the time of installation.
EXCEPTIONS: LABOR COSTS, DRIVING COSTS, DELIVERY COSTS AND PARTS WHICH ARE
USED BY NATURAL WEAR AND TEAR.

6
4. OPERATING INSTRUCTIONS
4.1. FIRST STEPS
In order to achieve an optimum operation of the machine, please follow the below-mentioned steps
carefully.
1. After unpacking and positioning the machine on a level surface, remove the front cover by
unscrewing the 2 fastening screws shown in Picture 1. Lift the front cover out of its anchoring to
expose the pressing system.
Picture 1
2. Check that the supply tunnel is mounted properly and that the fixation lever is fixed
(see Picture 2).
Picture 2

7
3. Place peel basket and drip cup as shown in Picture 3 & Picture 4
Picture 3 Picture 4
4. Make sure that the MTS-System is in its proper position and that the front cover is closed
(see Picture 5 and Picture 6).
Picture 5 Picture 6
5. Install the Inlet in the colour of your choice and the handle (left handed thread) at the flywheel.
1. Clean the surface of the lever to improve the adhesive bond.
2. Remove the protective film from one side of the double-sided tape and place it at the lever.
3. Remove the protective film from the second side and put the inlet onto it.
4. Use an Allen key (3mm) to install the handle at the lever.
For more detailed instructions please see Troubleshoot No. 63
Picture 7 Picture 8
Drip cup
Peel basket
MTS-System

8
4.2. OPERATING THE MACHINE
1. Fill the fruit basket with oranges. Do not use fruits larger than 80mm in size. To make sure that
the machine works properly, use fruits between 65 – 78 mm in diameter.
(Picture 9&10)
Picture 9 Picture 10
2. Turn the flywheel until you have squeezed the desired amount of fruits.
3. Place a bottle or glass underneath the tap.
4. Use the tap to pour the juice into the glass.
Attention: Take care that the fruit sieve support may overflow if you squeeze more juice than you
pour.

9
4.3. CLEANING INSTRUCTION
In order to clean the machine properly, please follow the instructions below:
The below-mentioned cleaning steps are to be completed at least twice every 24 hours.
1. Either press the oranges remaining in the fruit
basket or remove them by hand.
2. Take care that the lower pressing elements
are in a horizontal position.
3. Loosen the front cover screws (left and right).
4. Remove the front cover:
Pull the lower part of the front cover slightly
towards the front. Then lift the cover away
from the retaining bolts.
Clean the hood with water (30 – 50°C) and a
cleaning cloth to remove any juice and fruit
pulp residues. Rinse thoroughly with water (30
– 50°C). Dry with disposable tissues.
CAUTION: Do not clean in a dishwasher!

10
5. Unscrew the cross holder screw
6. Pull off the cross holder.
7. Separate the knife guide from the cross
holder by pulling out the cross holder
screw.
(3 individual parts: cross holder, knife
guide, screw)

11
Caution: When reinstalling the knife
make sure that it rests in the correct
position and that the screw is properly
tightened by hand.
In case of disregard, either the blade
system or the upper pressing units of the
machine might get damaged.
8. Remove the peel removers (right and
left).
9. Remove the lower pressing units (right
and left

12
10. Remove the lower pressing units (right
and left).
11. Lift the knife and pull it out.
11. Unclamp the fixation lever of the feeder
and remove the supply tunnel
12. Remove the front plate / double cover.

13
13. Pull out the MTS-System.
14. Remove the MTS-Pusher. Press the
fixation clip and pull out the pusher
15. Press the lifting lever to Remove the fruit
sieve from the fruit sieve supporter.
16. Remove the peel basket.

14
17. Remove the drip cup
18. Remove the sieve from the cup
Clean all parts (with the exception of the acrylic front cover) in the dishwasher.

15
19. Clean the housing. The machine must
not be cleaned by means of a water
jet but with a wet cloth and clear water
only. Wipe clean with a cleaning cloth
and dry with a disposable tissue
Re-Mount all parts after cleaning in the opposite order of removal.
Ensure that all parts are correctly mounted and tightened!
We recommend cleaning the machine twice within 24 hours.
PLEASE NOTE:
• DO NOT clean the acrylic front cover in the dishwasher. Cleaning the front cover is to be
done by hand with warm water and disposable drying tissues.
• DO NOT use any abrasive materials or decalcifying agents.

16
Cleaning the Self-Service Tap
Disassembly of the self-service tap
1. Press the supporter of the tap
upwards, accordingly push it
towards the front
2. Pull the tap bottom downwards.
3. Press the supporter upwards,
accordingly push the supporter
towards the back to disassemble
the supporter.
4. Clean the fruit juice passage of the
fruit sieve and the tap bottom
properly.
5. Clean the complete tap (upper part
removed from the bottom part) in a
dishwasher or, alternatively,
thoroughly rinse the tap in a sink.

17
Assembly of the self-service tap
6. Re-Mount all parts after cleaning in
the opposite order of removal.
Ensure that all parts are correctly
mounted and tightened!
Caution:
Make sure that the guide bolt of
the tap bottom faces the rear
when assembling the tap.
Guide bolt

18
