BOROSIL BSJU13WB01 User manual
140 (W) X 215 (H) MM CLOSE SIZE
USER MANUAL
EASYJUICE COLD PRESS SLOW JUICER
Maximum nutrition, minimum effort
BSJUWB
Congratulation on your purchase of
BOROSIL EASYJUICE COLD PRESS SLOW JUICER!
• Do not let power cord hang over the edge of the table or counter, or touch hot surfaces.
• This appliance is not intended for use by persons (including children) with reduced physical,
sensory or mental capabilities, or lack of experience and knowledge, unless under supervision
or given instructions concerning the usage of the appliance by a person responsible for their
safety. Children should be supervised to ensure that they do not play with the appliance.
• Use only. V, Hz AC power supply.
• Do not operate the appliance if it has malfunctioned or has been damaged in any manner.
Never try to repair the product by yourself. Contact our Customer Care Toll free no.
1800 224 552 or e-mail us at [email protected] for examination and repair.
• The product is applicable for household and not for commercial purpose. Outdoor use can
be dangerous.
• Before using, place the appliance on an even, stable surface; operate according to the
instructions given.
When using electrical appliances, basic safety precautions should always be followed
including the following:
• To prevent accident, do not immerse the machine into water. You may scrub with soft cloth.
SAVE THESE INSTRUCTIONS
• Do not operate the product without being watched.
• Use the original product provided by manufacturer. Never use other objects instead of the
material pusher. To prevent accidents, keep eyes out of the feeder tube.
• Before dismantling or installing any part of the product, disconnect the power supply.
• To prevent product damage during use, do not add hard object (such as nuts), fiber-rich foods
(such as sugar cane), less-juice foods (such as banana) and non-food object from feeder tube.
Do not put frozen fruit or ice.
• To prevent injury and damage, use pusher instead of hand if foods are stuck at the feeder tube
• Keep fingers or hard objects out of feeder unit during operation. Contact with the squeezing
gear would cause injury or product may get damaged.
• When not in use, remove the plug and shut off the power supply. Store the product at a dry
place away from direct sunlight.
• After juicing, turn switch to "O" and do not dismantle product accessory until the motor is
completely stopped.
INTRODUCTION
IMPORTANT SAFEGUARDS
DESCRIPTION OF PRODUCT
Rated Frequency : Hz
Household Use Only
Rated Power : W
Rated Voltage : VAC
Product : SLOW JUICER
Model Name : EASYJUICE COLD PRESS SLOW JUICER
Item Code : BSJUWB
TECHNICAL SPECIFICATIONS
7
) Juice & Pulp Separator
PART DESCRIPTION:
) Motor Unit
) ml Juicer Jug
) Pusher
) Feeder Unit
) Juice Gear Cum Filter
) Pulp Collector Jug
) Power On Reverse Switch
) Cleaning Brush
9
1
2
3
4
8
6
5
BEFORE USING
REMARK:
. Assemble the feeder onto the separator bowl (Fig ).
• Do not operate this unit without any load
• Do not use with wet hands.
. Twist the feeder clockwise to align the slot on the feeder with the lock-unlock mark, and then
fix it till the feeder gets locked. (Fig ).
. Place Juicer bowl under the juice outlet and pulp collector bowl under the pulp outlet. Put
the power plug into the main socket and switch on the main supply. (Fig ).
• Before startup, take out all accessories, reinstall the machine before trial operation.
HOW TO ASSEMBLE:
• Read all instructions carefully and keep them for future reference.
• Dismantle package and place all parts on a flat table.
• Immerse all removable parts and accessories in warm water and dry them. To prevent electric
shock and machine damage, do not immerse the main machine in water.
• Before assembly, make sure the cord is not connected to a power source and the switch is
at "O" position.
• Use only the accessories recommended by the manufacturer.
• It is recommended to stand on a rubber mat/insulated surface or with wear rubber slippers
while using the appliance to avoid electric shock in case the product malfunctions.
• After every use, turn off the switch and before dismantling make sure the motor has stopped
rotating and, then pull out the plug.
. Assemble the pulp and juice separator onto the motor unit, the separator bowl must be fixed
to the same point as the motor unit (Fig. & ).
• Before use, assemble all parts as per drawing, otherwise the normal operation would be affected.
. Assemble the squeezer and the strainer into one part (Fig ).
. Place the squeezer unit inside the separator bowl and rotate until it falls into the right
place (Fig ).
. Insert the small pieces of fruits from the top and push them down with the help of the
pusher. (Fig ).
HOW TO USE
. Ensure all accessories are correctly installed and the juice collector and pulp collector are
properly placed.
JUICING
. In order to insert fruits in the feeder unit easily, cut fruits into small pieces.
. Put the power plug into the main socket and switch ON the main supply.
. To start the juicing process select the switch from O to I position; the juicer will
start operating.
. Put the fruit pieces into the feeder tube and slowly push it down with the pusher, in order to
avoid the fruit pieces from getting stuck in the feeder tube.
. Make sure the juice outlet cap is in open position in order to collect the juice into the juice jug
and ensure that the pulp is getting collected into the pulp collector.
. To clean the filter / to remove the stuck pulp shift the switch to II position. The motor will
rotate in reverse direction and the stuck pulp will get resolved.
a) Fruits with less juice such as banana, apricot, etc. are not recommended to be used in the
Slow Juicer.
c) Make sure to run the appliance for a maximum of minutes in case of soft fruits, such as apple
or pear. For tough fruits and vegetables, like carrots, the maximum time is minutes . It has an
intelligent safety feature to sense overheat, so If suddenly it turns off due to long use, please
wait until it resumes. Depending on the circumstance and the temperature of the
motor, it can take time (approx. 40 mins) to resume.
. Place on a flat surface and wipe the surface with a cloth
. Before cleaning, unplug the power plug from the main socket and let the machine
stop completely.
. Remove all the parts in a reverse procedure. Rinse with clean water.
. Clean all the accessories with water except the motor unit
b) To prevent product damage during use, do not add hard objects or hard food material like
sugarcane, nuts, the core of pineapple or raw fruits like unpeeled lemon
. After juicing, remove all parts as per reverse procedure
. Use the brush to wash the squeezer, filter and juicing jug with running tap water.
. After cleaning, dry the product with a dry cloth, install and store it in a dry and safe place.
. Before flushing the outlet of feeder tube, pull out the bottom silicone sheet and,
after cleaning, install silicone sheet correctly;
CLEANING AND MAINTENANCE
. Please close the lid every time before use
NOTE:
Warning: To prevent scratches, take care and properly clean the mesh of strainer.
65 7 8
Please remember to respect the local regulations:
Hand in the non-working electrical equipment to an appropriate
waste disposal center.
You can help protect the environment!
ENVIRONMENT FRIENDLY DISPOSAL
TROUBLESHOOTING
Problem Solution
Juicing failure /
no dry pulp
Operation stops in
between
Abnormal noise during
juicing
Unpleasant smell
is emitted
Be sure the assembly is correct. If food is stuck inside, switch
off the appliance, remove the power cord, dismantle and clean
the part before use. Check if fresh materials are selected;
Materials that have been stored in refrigerator for a long time
should be defrosted in clean water before use. Make sure the
fruits must be fresh and should not be dry. Fruits like Sugar
cane , Gooseberry are not recommended for the juicing.
Better in juicing the fruits & Vegetable as below - Carrot,
Green Apple, Citrus/Orange, Pomegranate,
Beetroot, Pine apple etc.
Check if too much food stuff is inserted in the Slow Juicer
Check if the fruit is not pitted. Press down O under standby
state for - sec, then press down II - sec to reversely
operate the product, and press down ON. If squeezing gear
does not work, check if the main unit is heated up, if yes, wait
for approx. mins till the motor cools down and it
automatically starts again. If still doesnt start, stop using the
product, switch off the mains and remove the plug, dismantle
the parts of feeder tube and clean the parts before use.
Check the following: Slow Juicer is running with no food
material inserted. Hard food material inserted.
Accessories are not properly installed.
This is a normal phenomenon when using the appliance
for the first time, the smell will disappear
after the appliance works for a while.
This product comes with a warranty of One Year on product from the date of purchase as specified on the
Warranty Card. This is against all defective material or workmanship. In the event of a defect, Borosil Limited at its
sole choice, will either repair or replace this product or any component of the product found to be defective free of
cost through the dealer from whom it has been purchased or at any of the Borosil Authorized Service Centre or at
Customer place during the warranty period.
. Repairs done by persons other than Borosil Authorized Service Centre.
. If the product is used in locations with different electrical specifications.
The warranty is not valid in case:
. Tampered serial number and incomplete warranty card after purchase.
. Product if used for commercial purpose (i.e. other than domestic use)
. This warranty does not cover damage or injury caused by accident, mishandling, misuse or normal wear and
tear or for loss of injury, directly or indirectly arising out of use of this product. The decision of the company in
this regard shall be final.
. Borosil is not responsible for accidents arising due to the use of accessories not designed for
the utilisation with this product.
. Defects caused by improper or reckless use.
. Product is not used according to user manual.
. If the product is used with any type of adapter or connector.
. Modifications of any nature made in the product.
. If the defects are caused by use of incorrect current or voltage or faulty electric power supply.
For any information or problem, contact Borosil Customer Care Toll free no. 1800 224 552 or e-mail us at
[email protected] or contact your local dealer or Borosil Authorized Service Centre and provide
information about the defect with the model number and the serial number of the product.
. Usage of parts not recommended by Borosil or those made by other manufacturers.
. The model no. on the invoice is different from the product to be repaired
. All consumables and parts susceptible to normal wear & tear are not covered under warranty.
. If the defects are caused by fire, flood and the other act of god.
WARRANTY FOR REPAIR & SERVICES
BSJUWB
1800 224 552
