City Theatrical DMX Vero Net User manual

The 7400-5708
SHoW DMX Vero NetTransceiver
User’s Manual
Rev 4
© 2012 City Theatrical, Inc.
SHoW DMX Vero Net Transceivers are covered by U.S. Patent # 7,432,803 and other
patents pending.

Radio Compliance Information..........................................................................3
Antennas..........................................................................................................4
5792 SHoW DMX Neo Radio CE Declaration of Conformity.........................7
System Compliance Information.......................................................................8
Safety Notices, Ratings and Power Requirements..........................................8
Introduction.......................................................................................................10
Setting up the 7400-5708 SHoW DMX Vero Net Transceiver.........................11
Installation......................................................................................................11
Warning..................................................................................................................11
Important use notes..............................................................................................11
Grounding..............................................................................................................11
Mounting Bracket..................................................................................................11
Surface Mounting..................................................................................................11
Mounting Orientation............................................................................................12
Pipe Mounting .......................................................................................................12
Cable or Conduit Entry.........................................................................................12
Mains Wire Installation and Termination ............................................................13
DMX512 Wire Termination....................................................................................13
Ethernet Cable entry......................................................................................13
Installing the Cover...............................................................................................14
The 7400-5708 SHoW DMX Vero Net Transceiver Settings...........................14
Configuration.........................................................................................................14
SHoW ID.................................................................................................................15
Classic Mode Operation .......................................................................................15
Classic SHoW ID Tables.......................................................................................15
Neo Mode Operation.............................................................................................17
Neo SHoW ID Tables.............................................................................................17
Neo Adaptive Mode Operation.............................................................................19
Neo Adaptive SHoW ID Table...............................................................................19
7400-5708 Configuration Options ................................................................20
Adjustable Output Power .....................................................................................20
Limited Burst DMX Output ...................................................................................20
RDM Operation ..............................................................................................20
Optional or Custom Antenna Accessories..................................................22
DMX512 / Art-Net / sACN Control Input .......................................................22
The Jese GetSet RDM Controller .................................................................22
Operating the Jese GetSet RDM Controller: ...............................................23
Notes on using RDM......................................................................................25
Check/Change IP address....................................................................................26
Check/Change IP of Subnet Mask .......................................................................26
Check/Change IP of Gateway Address ...............................................................26
Check/Change sACN Universe to Wireless or Wired.........................................27
Check/Change DMX Port Direction......................................................................28
Check/Change Adaptive Hopping........................................................................29
Check/Change DHCP Mode..................................................................................29
Page 2 of 29

Radio Compliance Information
5792 SHoW DMX Neo™ Radio Module
FCC ID: VU65792
IC ID: 7480A5792
FCC Part 15
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses and can
radiate radio frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a
particular installation.
If this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
• Consult the dealer or an experienced radio/ TV technician for help.
Radio Frequency Notifications
FCC Notifications
RF Radiation The Product is an intentional radiator of Radio Frequency (RF) energy. In order to
limit RF exposure to personnel in the immediate area, the Product should be located and installed
such that a separation of at least 20 centimeters is maintained between the Product’s antenna
and personnel in the vicinity of the device.
Modification Warning
Caution: changes or modifications to this equipment, not expressly approved by City Theatrical
Inc. could void the user’s authority to operate the equipment.
Industry Canada Notifications
This Class B digital apparatus complies with Canadian ICES-003. Operation is subject to the
following two conditions: (1) this device may not cause interference, and (2) this device must
accept any interference, including interference that may cause undesired operation of the device.
Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada.
Product Installation and Configuration Guide © City Theatrical Inc. 2007
5792 Approved Antenna
To reduce potential radio interference to other users, the antenna type and its gain should be so
chosen that the equivalent isotropically radiated power (e.i.r.p.) is not more than that permitted for
successful communication.
This device has been designed to operate with the antennas listed below. Antennas not included
in this list or having a gain greater than 5 dB are strictly prohibited for use with this device. The
required antenna impedance is 50 ohms.
Page 3 of 29

Antennas
The model: 5792 can be configured with any one of the approved antennas listed below
for fixed, point-to point one server and one client configuration. When the model: 5792 is
configured for point-to-multipoint one server and multiple clients’ configuration (client’s
talk to server only one at a time), client’s can use any of the approved antennas listed
below and the server can use any of the approved antennas listed below with the
exception of the 14dBi antenna.
5792 FCC/IC Approved Antennas:
Manufacturer Model Type Connector Gain
Nearson S151AH-2450S Omni whip SMA plug reverse polarity 5dBi
Nearson S141AH-2450 Omni whip SMA plug reverse polarity 2dBi
Nearson S131AH-2450 Omni whip SMA plug reverse polarity 2dBi
Nearson DG102N-2.4/5.25
Omni whip,
outdoor
use
SMA plug reverse polarity via
provided Antenna Cable 5dBi
Tekfun F40-N Omni whip, outdoor
use Male N 4.5dBi
Centurion WCP2400-
MMCX4 Omni whip MMCX jack on 4” coax pigtail 2.5dBi
Maxrad MP24008XFPT
Panel,
outdoor
use
SMA plug reverse polarity via
provided Antenna Cable 8dBi
Maxrad MYP24010PT
Yagi,
outdoor
use
SMA plug reverse polarity via
provided Antenna Cable 10dBi
Maxrad MYP24014PT
Yagi,
outdoor
use
SMA plug reverse polarity via
provided Antenna Cable 14dBi
5792 CE Approved Antennas:
Manufacturer Model Type Connector Gain
Nearson S151AH-2450S Omni whip SMA plug reverse polarity 5dBi
Nearson S141AH-2450 Omni whip SMA plug reverse polarity 2dBi
Nearson S131AH-2450 Omni whip SMA plug reverse polarity 2dBi
Nearson DG102N-2.4/5.25
Omni whip,
outdoor use SMA plug reverse polarity via provided Antenna Cable 5dBi
Tekfun F40-N Omni whip,
outdoor use Male N 4.5dBi
Centurion WCP2400-
MMCX4 Omni whip MMCX jack on 4” coax
pigtail 2.5dBi
Page 4 of 29

For installations governed by FCC and/or IC rules, any of the approved antennas listed
above may be used with the SHoW DMX Vero Transceiver (please note the special
installation requirements for use with the CTI # 5636 14 dBi Yagi Antenna).
Please note that some of the antennas listed are intended for indoor use only.
For use in locations governed by CE rules, some antenna restrictions apply. Antennas
from the 5792 CE Approved Antennas meet all requirements. Contact City Theatrical
for details.
ETSI power settings for all 5792 SHoW DMX Neo Radio module equipped products,
including the SHoW DMX Vero Transceiver, are based on use with the CTI 5630 5 dBi
Omni Antenna. ETSI power and range will vary with the antenna used. Contact your
dealer or City Theatrical for more information. CE Mark Conformity
City Theatrical Inc. declares that this product conforms to the specifications listed in this
manual, following the provisions of the European R&TTE directive 1999/5/EC:
CE Mark Conformity
City Theatrical Inc. declares that this product conforms to the specifications listed in this manual,
following the provisions of the European R&TTE directive 1999/5/EC:
City Theatrical Inc. vakuuttaa täten että dieses produkt tyyppinen laite on direktiivin 1999/5/EY
oleellisten vaatimusten ja sitä koskevien näiden direktiivien muiden ehtojen mukainen.
City Theatrical Inc. déclare que le produit est conforme aux conditions essentielles et aux
dispositions relatives à la directive 1999/5/EC.
• EN 301 489-1, 301 489-17 General EMC requirements for Radio equipment.
• EN 60950 Safety
• EN 300 328 Technical requirements for Radio equipment.
CAUTION—This equipment is intended to be used in all EU and EFTA countries.
Outdoor use may be restricted to certain frequencies and/or may require a license for operation.
Contact local Authority for procedure to follow.
Note: ESD precautions should be used when attaching or removing the antenna.
Note: Combinations of power levels and antennas resulting in a radiated power level of above
100 mW equivalent isotropic radiated power (EIRP) are considered as not compliant with the
above mentioned directive and are not allowed for use within the European community and
countries that have adopted the European R&TTE directive 1999/5/EC. For more details on legal
combinations of power levels and
antennas, contact City Theatrical Inc.
Do not use this product near water, for example, in a wet basement or near a swimming pool.
Avoid using this product during an electrical storm. There may be a remote risk of electric shock
from lightning.
Product Installation and Configuration Guide © City Theatrical Inc. 2011
Q52 Regulatory information
Radio Frequency Notifications
Belgique Dans le cas d'une utilisation privée, à l'extérieur d'un bâtiment, au-dessus d'un espace
public, aucun enregistrement n'est nécessaire pour une distance de moins de 300m. Pour une
distance supérieure à 300m un enregistrement auprès de l'IBPT est requise. Pour une utilisation
publique à l'extérieur de bâtiments, une licence de l'IBPT est requise. Pour les enregistrements et
licences, veuillez contacter l'IBPT.
France 2.4 GHz Bande : les canaux 10, 11, 12, 13 (2457, 2462, 2467, et 2472 MHz
respectivement) sont complétement libres d'utilisation en France (en utilisation intérieur). Pour ce
Page 5 of 29

qui est des autres canaux, ils peuvent être soumis à autorisation selon le départment. L'utilisation
en extérieur est soumis à autorisation préalable et très restreint. Vous pouvez contacter l'Autorité
de Régulation des Télécommunications
(http://www.art-telecom.fr) pour de plus amples renseignements.
Page 6 of 29

5792 SHoW DMX Neo Radio CE Declaration of Conformity
Page 7 of 29

System Compliance Information
The 7400-5708 SHoW DMX Vero Net Transceiver is ETL Listed,
Conforms to UL 508A
The 7400-5708 SHoW DMX Vero Net Transceiver is CE Certified
Standards Applied:
EN 55203-1: 2009, Environments E4 and E5
EN 55203-2: 2009, Environments E1, E2, E3, E4
EN 301 489-1 V1.8.1
EN 301 489-3 V1.4.1
EN 60950-1:2006 / A1:2010
FCC Rules, Part 15, Subpart B, Sections 15.107 and 15.109
Products Conform to CE Marking Directive 93/68/EEC
All SHoW DMX Neo models are RoHS compliant
Safety Notices, Ratings and Power Requirements
Please read this entire manual before using your new equipment. Please keep the
manual in a safe place so you can refer to it in the future as required.
The SHoW DMX Neo System is intended for use only by qualified professionals.
Connection, installation and hanging of this equipment must be performed in accordance
with all pertinent local, regional and national safety codes and regulations.
The 7400-5708 SHoW DMX Vero Net Transceiver is intended for indoor or outdoor use.
The unit enclosure is rated NEMA 4 / IP66.
Rated operating voltage; 100-240VAC 50/60 Hz, 1A max.
This device must be provided with a 20A branch circuit breaker or equivalent suitable
external disconnecting device.
Maximum operating temperature: 0°C - 40°C.
Warning: The 7400-5708 SHoW DMX Vero Net Transceiver must be mounted
exclusively in an upright mounting position with the cable entries on the bottom and
antenna connector on the top as shown in the Installation guide. See the Installation
Guide in this document for details.
Page 8 of 29

RF Exposure: The antenna(s) used for this transmitter must be installed to provide a
separation distance of at least 20cm from all persons and must not be collocated or
operating in conjunction with any other antenna or transmitter.
Page 9 of 29

Introduction
Thank you for using City Theatrical’s 7400-5708 SHoW DMX Vero Net Transceiver.
The 7400-5708 SHoW DMX Vero Net Transceiver features include:
NEMA 4 /IP 66 rated enclosure
Transceiver, fully configurable for Transmit or Receive
One model, FCC, IC and CE Certified
New DMX synchronized hopping structure with increased interference immunity,
reduced interference generation and extremely low latency
Selectable true Adaptive Spread Spectrum Frequency Hopping (ASSFH) in Neo
Modes
Ethernet Port via RJ 45 Jack, supports multiple Ethernet show control protocols
including sACN, Art-Net, and KiNet
USB Port for easy future firmware updates
Three Operating Modes:
Neo Mode
Fully configurable using RDM commands from an external RDM controller or the
host.
Replace missing packets with previously received data if any are lost
7mS typical latency
Selectable Output power (1-72mW ETSI)
Selectable Bandwidth
Selectable Burst Length (when used with full frame sources)
Allows for shortened frame data (less than 512 bytes from source)
Enhanced RDM Proxy performance
Neo-Adaptive Mode
Fully configurable using RDM commands from an external RDM controller or the
host.
Replace missing packets with previously received data if any are lost
7mS typical latency
Adaptive Hopping
Selectable Output power (1-72mW ETSI)
Allows for shortened frame data (less than 512 bytes from source)
SHoW DMX Classic Mode
Communicates with original SHoW DMX equipment
DMX Synchronized Hopping
User selectable Full or Limited Bandwidth
User selectable Full or Limited Burst
User selectable Output Power (1-72mW ETSI)
Every effort has been made to anticipate your questions in this manual, but if you have
any questions that are not answered here, or you want to discuss a special application,
please feel free to contact us directly at City Theatrical.
Page 10 of 29

Setting up the 7400-5708 SHoW DMX Vero Net Transceiver
Installation
Install the SHoW DMX Vero Net Transceiver in a suitable location, following the
instructions below. When selecting a mounting location, note that for best results the
antennas in your system must be within sight of each other.
Warning
To avoid electric shock, do not energize any circuits before all internal and external
electrical and mechanical clearances are checked to assure that all assembled
equipment functions safely and properly.
Important use notes
This unit must be used with voltages below 600V
This unit must be installed in accordance with the National Electrical Code, ANSI/NFPA
70, where the ambient temperature does not exceed 40°C (104°F) maximum.
Grounding
This enclosure has been provided with a ground bond jumper for ground connection
between the back box and the cover. This jumper must be installed as shown in the
drawing above, using the provided hardware.
Mounting Bracket
The provided mounting Bracket Base can be mounted on a surface or a vertical pipe.
For surface mounting, the Bracket base is provided with slots and holes suitable for #10
/ M4 screws or similar fasteners.
Surface Mounting
Mount the Mounting Bracket Base in the desired location using four x #10 / M4 screws
(by others, as above).
Slide the mating Mounting Bracket (attached to the Unit) into the Mounting Bracket Base
until the locking clip engages, and install the provided 8-18 x .500” SS Thread Forming
Torx Button Head Security Screw, in the hole on the left side of the Bracket assembly.
Page 11 of 29

Mounting Orientation
The 7400-5708 SHoW DMX Vero Net Transceiver must be mounted exclusively in an
upright mounting position with the cable entries on the bottom and antenna connector on
the top as shown in the drawing above.
Pipe Mounting
The SHoW DMX Vero can also be mounted on a pipe.
Attach the Mounting Bracket Base to a pipe using a stainless steel hose clamp as
shown:
Slide the mating Mounting Bracket (attached to the Unit) into the Mounting Bracket Base
until the locking clip engages, and install the retaining screw.
Cable or Conduit Entry
The unit enclosure is provided with ½” NPT entry holes fitted with liquid-tight cable grips
for use with outdoor use cables (by installer) for power, DMX, and Ethernet connection.
The recommended torque for these cable grips is as follows:
LockingNut40‐45inchpounds
SealingNut50‐55inchpounds
Page 12 of 29

If outdoor use conduit is used instead, it is recommended that the conduit be sealed
after installation to prevent moisture entry, including free air exchange, in order to
minimize the chance of condensation buildup.
Mains Wire Installation and Termination
Install the mains cable or conduit in the entry provided as shown in the drawing below.
A liquid tight cable grip is provided for use with suitable outdoor rated cable with
diameter range of .170”/4,3mm - .450”/11,4mm.
When cable is used, strip outer jacket 6.0”/150mm.
The mains connection is a 3 pos. plug/socket type terminal block which may be
disconnected for ease of assembly. Strip insulation from individual conductors .25”/7mm
and terminate in the provided screw terminal socket (see illustration above) Mains
terminations are ash shown and are marked on the unit.
DMX512 Wire Termination
The SHoW DMX Vero Net Transceiver is provided with a PCBA mount terminal block
for DMX connection (see illustration above). DMX Input / Output connections are as
shown and are marked on the unit.
Ethernet Cable entry
The unit is provided with an RJ45 Ethernet Jack for Ethernet connection. Install the
Ethernet cable using the entry provided. An RJ45 Ethernet Plug must be installed on the
Ethernet cable after the cable is pulled into the box, using the standard TIA-EIA T568B
Page 13 of 29

pin out.
Installing the Cover
The 7400-5707 SHoW DMX Vero Net Transceiver has a two part cover, with the outer
plastic cover connected to the inner metal cover with a hinge. Install the metal inner
cover using the eight provided 6- 32 x .375” SS Truss Head Machine Screws. Hand
install these screws until the screw threads are fully engaged with the mating PEM Nut,
then tighten to 4 inch pounds.
The outer cover is then closed and secured with the provided 8-18 x .500” SS Thread
Forming Torx Button Head Security Screw, installed in the provided hole on the left side
of the cover assembly.
The 7400-5708 SHoW DMX Vero Net Transceiver Settings
Configuration
You can configure the Vero Net Transceiver’s basic operating settings using the System
Settings switches shown in the detail above.
Configuration switches:
P5, DMX Term: DMX512 termination On or Off. Turn On for end-of-line
DMX512 connection.
P4, Rx/Tx: Receiver (Rx) On, or Transmitter (Tx) Off. Selects Receiver or
Transmitter operation
P3, Reset: On or Off. Switch On to Reset
P2 Bootloader: On or Off. Sets the unit to Bootloader mode to upload and install
Host and radio firmware upgrades from a connected USB Memory device.
Page 14 of 29

P1 Default: On or Off. To restore the system to factory default settings:
1. Set P1 Default to On
SHoW ID
Lik ssic system, the SHoW DMX Neo system uses SHoW
ick way to set RF configuration options. Each SHoW ID represents a
ommunicate.
Vero Net Transceiver is preset at the factory with SHoW ID 201 for
daptive Spread Spectrum Frequency Hopping and Neo Low Latency broadcast mode.
ethod is used last takes precedence.
t the SHoW ID BCD Switches to the desired
HoW ID.
e RDM, you will also need an RDM controller or a lighting control console
ith a built-in RDM controller. Your new SHoW DMX Vero Net Transceiver includes
Classic Mode, the SHoW DMX Vero Net Transceiver uses the original SHoW DMX
nd will communicate with Classic SHoW DMX devices such
es
ID de Hopping Pattern Bandwidth
2. Wait for PCBA LED to blink rapidly
3. Switch P1 to Off
e the original SHoW DMX Cla
IDs as a qu
combination of one of 16 hopping patterns and one of four bandwidth settings.
The Transmitter and Receiver SHoW IDs must match for the units to
c
The SHoW DMX
A
SHoW ID may be set manually using the SHoW ID BCDs or using RDM. Whichever
m
To set the SHoW ID manually, simply se
S
In order to us
w
CTI’s version of the Jese GetSet RDM Controller (see below for details).
Classic Mode Operation
In
Classic broadcast format a
as 5600/01 Transmitter, 5610/11 Receiver, etc. You can use this mode if you want to
combine SHoW DMX Vero Net and Classic equipment in the same system. Classic
Mode supports Adjustable Broadcast Power, Limited Bandwidth, Limited Burst, and us
64 original SHoW IDs, providing 16 hopping patterns in each Bandwidth setting.
Classic SHoW ID Tables
SHoW Mo
1 Classic 1 Full
2 Classic 2 Full
3 Classic 3 Full
4 Classic 4 Full
5 Classic 5 Full
6 Classic 6 Full
7 Classic 7 Full
8 Classic 8 Full
9 Classic 9 Full
Page 15 of 29

10 Classic 10 Full
11 Classic 11 Full
12 Classic 12 Full
13 Classic 13 Full
14 Classic 14 Full
15 Classic 15 Full
16 Classic 16 Full
SHoW Mode Hopping BandwidthID Pattern
17 CLimited Low, Wi-Fi 1-6
lassic 1
18 Classic 2 Limited Low, Wi-Fi 1-6
19 Classic 3 Limited Low, Wi-Fi 1-6
20 Classic 4 Limited Low, Wi-Fi 1-6
21 Classic 5 Limited Low, Wi-Fi 1-6
22 Classic 6 Limited Low, Wi-Fi 1-6
23 Classic 7 Limited Low, Wi-Fi 1-6
24 Classic 8 Limited Low, Wi-Fi 1-6
25 Classic 9 Limited Low, Wi-Fi 1-6
26 Classic 10 Limited Low, Wi-Fi 1-6
27 Classic 11 Limited Low, Wi-Fi 1-6
28 Classic 12 Limited Low, Wi-Fi 1-6
29 Classic 13 Limited Low, Wi-Fi 1-6
30 Classic 14 Limited Low, Wi-Fi 1-6
31 Classic 15 Limited Low, Wi-Fi 1-6
32 Classic 16 Limited Low, Wi-Fi 1-6
SHoW Mode Hopping BandwidthID Pattern
33 CLimited Mid, Wi-Fi 5-9
lassic 1
34 Classic 2 Limited Mid, Wi-Fi 5-9
35 Classic 3 Limited Mid, Wi-Fi 5-9
36 Classic 4 Limited Mid, Wi-Fi 5-9
37 Classic 5 Limited Mid, Wi-Fi 5-9
38 Classic 6 Limited Mid, Wi-Fi 5-9
39 Classic 7 Limited Mid, Wi-Fi 5-9
40 Classic 8 Limited Mid, Wi-Fi 5-9
41 Classic 9 Limited Mid, Wi-Fi 5-9
42 Classic 10 Limited Mid, Wi-Fi 5-9
Page 16 of 29

43 Classic 11 Limited Mid, Wi-Fi 5-9
44 Classic 12 Limited Mid, Wi-Fi 5-9
45 Classic 13 Limited Mid, Wi-Fi 5-9
46 Classic 14 Limited Mid, Wi-Fi 5-9
47 Classic 15 Limited Mid, Wi-Fi 5-9
48 Classic 16 Limited Mid, Wi-Fi 5-9
SHoW Mode Hopping BandwidthID Pattern
49 CLimited High, Wi-Fi 7-11
lassic 1
50 Classic 2 Limited High, Wi-Fi 7-11
51 Classic 3 Limited High, Wi-Fi 7-11
52 Classic 4 Limited High, Wi-Fi 7-11
53 Classic 5 Limited High, Wi-Fi 7-11
54 Classic 6 Limited High, Wi-Fi 7-11
55 Classic 7 Limited High, Wi-Fi 7-11
56 Classic 8 Limited High, Wi-Fi 7-11
57 Classic 9 Limited High, Wi-Fi 7-11
58 Classic 10 Limited High, Wi-Fi 7-11
59 Classic 11 Limited High, Wi-Fi 7-11
60 Classic 12 Limited High, Wi-Fi 7-11
61 Classic 13 Limited High, Wi-Fi 7-11
62 Classic 14 Limited High, Wi-Fi 7-11
63 Classic 15 Limited High, Wi-Fi 7-11
64 Classic 16 Limited High, Wi-Fi 7-11
eo Mode Operation DMX Vero Net Transceiver uses a new broadcast format that r
Mode Hopping Pattern Bandwidth
N
In Neo Mode, the SHoW
reduces latency to ~ 7mS and provides further resistance to interference susceptibility o
creation.
Neo Mode supports Adjustable Broadcast Power, Limited Bandwidth, Limited Burst, and
provides 64 new SHoW IDs, providing 16 hopping patterns in each Bandwidth setting.
Neo SHoW ID Tables
SHoW ID
101 Neo 1 Full
102 Neo 2 Full
103 Neo 3 Full
104 Neo 4 Full
105 Neo 5 Full
106 Neo 6 Full
Page 17 of 29

107 Neo 7 Full
108 Neo 8 Full
109 Neo 9 Full
110 Neo 10 Full
111 Neo 11 Full
112 Neo 12 Full
113 Neo 13 Full
114 Neo 14 Full
115 Neo 15 Full
116 Neo 16 Full
SHoW ID Mode Hopping Pattern Bandwidth
117 Neo 1 Limited Low, Wi-Fi 1-6
118 Neo 2 Limited Low, Wi-Fi 1-6
119 Neo 3 Limited Low, Wi-Fi 1-6
120 Neo 4 Limited Low, Wi-Fi 1-6
121 Neo 5 Limited Low, Wi-Fi 1-6
122 Neo 6 Limited Low, Wi-Fi 1-6
123 Neo 7 Limited Low, Wi-Fi 1-6
124 Neo 8 Limited Low, Wi-Fi 1-6
125 Neo 9 Limited Low, Wi-Fi 1-6
126 Neo 10 Limited Low, Wi-Fi 1-6
127 Neo 11 Limited Low, Wi-Fi 1-6
128 Neo 12 Limited Low, Wi-Fi 1-6
129 Neo 13 Limited Low, Wi-Fi 1-6
130 Neo 14 Limited Low, Wi-Fi 1-6
131 Neo 15 Limited Low, Wi-Fi 1-6
132 Neo 16 Limited Low, Wi-Fi 1-6
SHoW ID Mode Hopping Pattern Bandwidth
133 Neo 1 Limited Mid, Wi-Fi 5-9
134 Neo 2 Limited Mid, Wi-Fi 5-9
135 Neo 3 Limited Mid, Wi-Fi 5-9
136 Neo 4 Limited Mid, Wi-Fi 5-9
137 Neo 5 Limited Mid, Wi-Fi 5-9
138 Neo 6 Limited Mid, Wi-Fi 5-9
139 Neo 7 Limited Mid, Wi-Fi 5-9
140 Neo 8 Limited Mid, Wi-Fi 5-9
Page 18 of 29

141 Neo 9 Limited Mid, Wi-Fi 5-9
142 Neo 10 Limited Mid, Wi-Fi 5-9
143 Neo 11 Limited Mid, Wi-Fi 5-9
144 Neo 12 Limited Mid, Wi-Fi 5-9
145 Neo 13 Limited Mid, Wi-Fi 5-9
146 Neo 14 Limited Mid, Wi-Fi 5-9
147 Neo 15 Limited Mid, Wi-Fi 5-9
148 Neo 16 Limited Mid, Wi-Fi 5-9
SHoW ID Mode Hopping Pattern Bandwidth
149 Neo 1 Limited High, Wi-Fi 7-11
150 Neo 2 Limited High, Wi-Fi 7-11
151 Neo 3 Limited High, Wi-Fi 7-11
152 Neo 4 Limited High, Wi-Fi 7-11
153 Neo 5 Limited High, Wi-Fi 7-11
154 Neo 6 Limited High, Wi-Fi 7-11
155 Neo 7 Limited High, Wi-Fi 7-11
156 Neo 8 Limited High, Wi-Fi 7-11
157 Neo 9 Limited High, Wi-Fi 7-11
158 Neo 10 Limited High, Wi-Fi 7-11
159 Neo 11 Limited High, Wi-Fi 7-11
160 Neo 12 Limited High, Wi-Fi 7-11
161 Neo 13 Limited High, Wi-Fi 7-11
162 Neo 14 Limited High, Wi-Fi 7-11
163 Neo 15 Limited High, Wi-Fi 7-11
164 Neo 16 Limited High, Wi-Fi 7-11
eo Adaptive Mode Operation eiver can be configured to operate in the new Neo
des 4 new Adaptive
SHoW ID Mode Hopping Pattern Bandwidth
N
The SHoW DMX Vero Net Transc
Adaptive (AFHSS) Mode. Neo Adaptive Mode uses an Adaptive Spread Spectrum
Frequency Hopping broadcast format in which the system detects interference and
adapts its frequency hopping channel set automatically to avoid it.
Neo Adaptive Mode supports Adjustable Broadcast Power and provi
Mode SHoW IDs. Latency is also reduced to ~7mS max in Adaptive Mode.
Neo Adaptive SHoW ID Table
201 Neo iveAdapt Adaptive Full
202 Neo Adaptive Adaptive Full
Page 19 of 29

203 Neo Adaptive Adaptive Full
204 Neo Adaptive Adaptive Full
400-5708 Configuration Options BCD switches as described, or via RDM. All other
iver is adjustable to allow the
e number of DMX channels and the amount of radio
ur
Neo Limited Burst mode, the user may select a contiguous group of 51 slots or more
any
channels and increase
emote Device Management. RDM is a lighting control protocol s
e 68 available Neo SHoW IDs, adjust the broadcast
he SHoW DMX Vero Net Transceiver is fully enabled as an RDM proxy system, so you
PIDs:
7
You can set SHoW ID either with the
configurations settings must be set via RDM.
Adjustable Output Power SHoW DMX Vero Net TransceThe broadcast power of the
user to calibrate the system’s broadcast power to match the requirements of the
application.
Limited Burst DMX Output
Limited Burst mode reduces th
energy that is broadcast by the Transmitter.
If you don’t need all 512 DMX values and you need to control the radio energy in yo
system as much as possible, then you can use Limited Burst to target only the DMX
channels you need, and reduce your radio footprint even further.
In
DMX slots in multiples of 52 slots (51+52, 51+104, etc.). Limited Burst slot counts
include: 51, 103, 155, 207, 259, 311, 363, 415, and 467. These may be assigned to
starting address that will not exceed the total 512 slot count when added to the
remaining slots in the selected Burst size (e.g. with 467 slots, the highest allowed
starting address is 46, as 46+466 = 512).
Classic Limited Burst Mode, burst options begin with 30 DMXIn
in increments of 32, so the options are 30, 62, 94, 126, etc. to 478.
DM OperationR
RDM stands for R
enhancement to DMX512 specified by PLASA (formerly ESTA); the official name i
ANSI/ESTA E1.20, Entertainment Technology - Remote Device Management over
USITT DMX512.
sing RDM, you can select one of thU
power, configure for limited burst transmission, edit the RDM Device Label, and enable
or disable RDM traffic.
T
can use RDM to manage your SHoW DMX Vero Net Transceiver system and any
connected RDM responders that are downstream of the system.
he SHoW DMX Vero Net Transceiver supports the following RDMT
Get
Allowed Set Reduce RDM Parameter PID Comment Allowed d RDM
X DISC_UNIQUE_BRANCH 010x00
X DISC_MUTE 0x0002
X DISC_UN_MUTE 0x0003
Page 20 of 29
