clair K1M12 User manual

USER MANUAL
English
Read this user manual carefully before using the Clair K air purifier.
Save this manual for future reference. MADE IN KOREA

Model Name K1M12
Power Supply Input Output
Power Consumption
Size
Weight
AC 100-240V / 50/60Hz DC 12V / 1.5A
260 x 247 x 355 mm
2.6 kg
Coverage
45㎡
Min 2W ~ Max 24W
Contents and Specifications
Contents
Suggested Applications
Main Body (separable lower and upper body)
Three-Stage-Filter
(Pre-filter + Embossing HEPA filter [CEPA] + Deodorizing filter)
Power Adapter User Manual
※ CEPA (Clair's Embossed HEPA) :
Specifications
※ Product size may differ. The product design and specifications can be modified for product quality without warning.
Bedroom Living
room
Child’s
room Office Hotel room
Hospital
room
Clair’s proprietary filter technology which, by applying electret charging- and
embossing surface technology, achieves a 10% improvement in air purifying performance
compared to HEPA filters.[KIMM, Korea Institute of Machinery & Materials]
School
Kitchen

Product Overview and User Instructions
Make sure to properly install the filter before switching on the air purifier.
Using the air purifier in proximity to a cooking place can shorten the filter lifespan and accelerate the filter replacement time.
(During cooking, open the windows to ensure ventilation. For a better filter result, air purifiers should be operated after
cooking, when windows are closed.)
Always place the air purifier on a stable, horizontal, and level surface to prevent vibration, noise or damages.
Do not block the air inlet and outlet by placing items on the air outlet or in front of the air inlet. Do not place any objects
on the device and do not cover it.
This device is not intended for use by children or by persons who are unable to operate it safely. Children should always
be supervised to ensure that they do not play with the device.
Product Overview
User Instructions
Front
08
09
06
10
05
07
03
Back
11
12
13
04
01
02
01
02
03
04
05
06
07
Child-Lock Button
Child-Lock LED
Fan Speed LED
Fan Speed Button
Air Quality Indicator
Power LED
Power, Auto-mode Button
08
09
10
11
12
13
Night-mode LED
Night-mode, Filter Replacement Button
Air Inlet
Air Outlet
Air Quality Sensor
Power Jack

Installation and Filter Cleaning
2. Plug in the power cord and press the power button
to turn on the device.
1. Connect the power adapter to the main body.
3. Be careful not to block the air inlet and outlet with
any foreign objects.
1. Place a soft fabric on the floor, and
separatethe product upper body from
the bottom body.
Installation
Filter Cleaning
Filter Cleaning
Pre-filter Replacement
2.1. Remove the filter seated in the
bottom body and vacuum the dust
on the filter. (Recommended cycle:
once a month)
Grasp the attachment part of the
pre-filter and remove it carefully to
prevent dust from falling off. Replace
it with a new pre-filter if necessary.
3. After removing the dust from the
filter, assemble the upper and
bottom body by aligning the rear
adapter part of the product.

CAUTION!
Always unplug the device before cleaning, replacing the filters or carrying out other maintenance.
Always clean your hands thoroughly after replacing the filter.
After replacing the filter, reassemble the product and make sure it fits properly.
If the device is assembled incorrectly, it will not work.
The filter has a maximum life span of 12 months. The life span may vary depending on intensity of usage, installation
places and environmental conditions.
Never clean the filter with water, detergent or any other liquid.
Never use abrasive, aggressive, or flammable cleaning agents such as bleach or alcohol to clean the filter or
any part of the air purifier.
The Clair K uses an intelligent Filter replacement system. When the LED of the filter replacement button lights up,
the filter needs to be changed.
Filter cleaning and replacement intervals may vary, depending on the environment where the purifier is used.
If the device is used in a dusty environment, the filter may need to be cleaned and replaced more often.
3. After replacing the filter with a new, clean filter,
reassemble the air purifier and properly align the upper
and the bottom body.
Filter Replacement
Replacing the Filter
1. Place a soft fabric on the floor, and detach the
product upper body from the bottom body.
2. Hold the handles on both sides of the filter and
remove it from the bottom body.
Filter Maintenance!

Power Button / Auto Mode
Press and hold the power button for 1~2 seconds to turn on the air purifier.
- As soon as the device is turned on, it automatically starts running in auto mode.
(GREEN LED)
- In auto mode a smart air quality sensor will adjust the fan speed of the purifier
according to the air quality. The fan speed will increase until the target air quality has
been reached.
Operating instructions
Fan Speed
Clair K has three different fan speed levels and a turbo mode.
- Press the fan speed button to select the desired fan intensity.
- In turbo mode, the air purifier operates at maximum capacity. Press and hold the
button for 3 seconds to activate the turbo mode (LED-WHITE)
Night Mode / Filter Replacement Reset
When the night mode is activated, the air purifier operates quietly on the lowest
fan speed.
- Press the night mode button to activate the night-mode. (RED LED lights up).
- When the filter needs to be replaced, the GREEN LED lights up.
- After replacing the filter, press and hold the button for 3 seconds to turn off the LED
and reset the filter life time.
Child Lock
This function locks the control panel to prevent accidental operation by children.
- Press and hold the child lock button for 3 seconds to activate the lock mode.
- When the child-lock mode is activated, all other buttons are locked and cannot be used.
- Press and hold the child lock button for 3 seconds to unlock the child lock mode.
Clair K is equipped a highly sensitive air quality sensor which continuously measures pollution levels and provides
immediate visual feedback.
The air quality light automatically turns on when the air purifier is switched on, and lights up all colors in sequence.
After approximately 30 seconds, the air quality sensor selects the color that corresponds to the surrounding air quality.
Green = good air quality
Yellow = moderate air quality
Orange = poor air quality
Clean the air quality sensor every 2-3 months with a soft brush to ensure optimal performance of the purifier
Air Quality Indicator

• Do not make change/manipulate the power adapter
or the power cable.
• Do not stretch, bend, or put tension on the cable.
• Switch off the device by pressing the power button before
disconnecting it from the power supply
• Do not use the purifier if the plug, the power adapter, or
the device itself is damaged.
• Do not use multiple devices at the same time when using
a multi outlet.
• Do not use the purifier near gas appliances, heating
devices or other heat sources such as fireplaces.
• Only use the original 12V/1.5A Clair-adapter provided with
the product.
• Make sure to unplug the power plug from the outlet before
cleaning or replacing the filter.
• Do not touch the power plug with wet hands.
• Unplug the plug when the product is not in use.
• Keep the device away from children and infants.
※ Failure to observe these precautions can result in electric
shock or fire and may lead to potential injury.
• Do not place the device where there is oil, smoke, gas,
or metallic dust. This product is designed for indoor use only.
Do not use outdoors or on wet surfaces.
• Do not expose the purifier to direct sunlight, heat sources or
water.
• Always place and use the device on a dry, firm and horizontal
surface
• Leave at least 20cm free space behind and on both sides of
the purifier and leave at least 30cm free space above the Purifier.
• Make sure that there are no obstructions on the air inlet or
outlet of the product
※ Failure to observe these precautions can result in electric
shock or fire and may lead to potential injury.
Power-related Precautions
• Do not move the purifier while it is connected to the power.
• Do not block the air inlet and outlet with foreign objects.
• Never use the device near heat sources or in places where
there is a risk of fire
• Do not lay the device on its side or place anything on top of it.
• Do not remove the filter from the housing while the device is
in operation and plugged in.
※ Failure to observe these precautions can result in electric
shock or fire and may lead to potential injury.
Operation-related Precautions
Installation-related Precautions
• Avoid direct skin contact with the filter. Do not smell the filter
or touch it with your bare hands. If the filter is polluted or
clogged, open the housing and the pre-filter with a vacuum
cleaner.
• Never clean the filter with water, detergent or any other liquid.
• Due its natural characteristics, the filter can attract dust or
polluted particles even when it is not in operation. Therefore,
keep unused spare filters in their sealed packaging.
• Dispose of used filters with household waste.
※ Failure to observe filter-related precautions can cause
health problems or reduce the performance of the filter.
Filter-related Precautions
!Safety Precautions

• The warranty period for Clair products is 1 year from the date of purchase.
• Keep the original purchase receipt and present it to the point of sale in the event of a warranty claim.
• In the following cases, the guarantee is no longer valid:
- When using non-original parts and spare parts.
- In the case of improper and careless use and independent repairs or manipulations.
- If the operating instructions are not observed.
- Wearing parts and filters are excluded from the guarantee.
- In the case of a repair request, the guarantee certificate must be presented.
CLAIR, Inc.
Customer Service
Bahnhofstrasse 134, CH-8957 Spreitenbach
TEL [phone]
E-MAIL [e-mail] WEB www.myclair.ch
Warranty
CLAIR, Inc. implements the warranty of the product as below according to the
consumer indemnification regulation.
Customer Service Center
[phone]
