Clam Stealth Spearfisher User manual

M o d e l N o .
–10947 –
S p e c i f i c a t i o n s
▪
CenterH e ig ht - 82 inches
▪
Footprint–9’ Diameter
▪
Weight –48 lbs.
Stealth Spearfisher
p/n 110947
I n s t r u c t i o n N o . 105567
- Clam Customer Service Information -
NOTICE: Please contact Clam Customer Service for any quality issues with your JM5000
Thermal shelter.
Customer Service Hrs: 9am to 4pm, Monday –Friday CST
Phone: [phone]
Fax: [phone]
Email: [e-mail]
** Warrantycannot be honored without an original,dated receipt** IMPORTANT! PLEASE
READ: Warranty Information
This product is warranted to the original retail purchaser ( n o t t r a n s f e r a b l e ) to be free from
manufacturers defects for one (1) year from the date of the original purchase. W a r r a n t y d o e s n o t
c o v e r c r a c k e d w i n d o w s , t e n t t e a r s , b r o k e n o r b e n t p o l e s d u e t o h i gh w i n d w e a t h e r
c o n d i t i o n s o r u n a t t e n d e d u s e . T h e p a r t will be replaced or repaired (manufacturer’s option) i f
found defective within the one (1) year time frame. Warranty will be void if product has been subject to
neglect, misuse, improper installation, misapplication, alteration, or accident including, but not limited to,
improper maintenance or use of unauthorized parts or attachments. Please read this entire owner’s manual
to ensure proper installation, use, storage, and care for your Clam shelter.
To submit a Warranty Claim Request, please use one of the following methods:
• Email: [e-mail] (Preferred Method)
• Call: 763-231-4120
• Write: Customer Service –Warranty Department
12135 Brockton Lane N.
Rogers, MN, MN 55369
Information needed to submit a warranty claim: If you need to submit a warranty claim, please e- mail
Clam’s Customer Service Department at [e-mail]. In your e-mail, please include your
full name, address, phone number, a copy of your receipt, a brief description of the problem, and pictures to
clearly show the area(s) of concern. Clam’s warranty department will review your request and a Clam
representative will contact you regarding your claim status. If instructed by warranty department, all returns
must be returned with postage pre-paid.
- L i m i ta ti o n o f L i a b i li t y -
It is expressly understood that Clam Corporation’s liability for its products, whether due to breach of warranty, negligence, strict liability, or
otherwise, is limited to the repair of the product as stated above. ClamCorporationisnotliable for anyinjury, loss, damage, or expense, whether
direct or consequential, including but not limited to loss of use, income, profit, or damage to material arising in connection with the sale,
installation, use of, inability to use, or the repair or replacement of Clam Corporation products. Clam Corporation reserves the right to make
alterations or modifications in its products at any time, which in its opinion, may improve the performance and efficiency of the product.Clam
shall not beobligated to make such alterations or modificationsto products already in service.
J
M
5
0
0
T
H
E
R
M
A
L

Page 2
Photo 1
Anchor pouch
SAFETY INSTRUCTIONS
Please fully understand and follow all safety instructions
outlined in this booklet. Failure to do so could result in
severe injury.
• Do not use open flame heaters in your ice shelter.
Open vents for cross ventilation.
• Ice Armor fabric will melt when contact is made with
hot surfaces (i.e.,heaters).
• Never leave shelter unattended when set up.
• Due to the increase in traffic (snowmobiles, autos,
etc.) on area lakes, ice fishing can be hazardous at
night. If you choose to fish at night or in poor visibility
conditions, be sure to take precautions with lights or
reflectors to show drivers your whereabouts.
• Use external anchors during excessive wind (15+mph)
PARTS LIST
ITEM #
DESCRIPTION
QTY.
PART NO.
Customer service hours:
1
HUB & POLE KIT(5 POLES & 1 HUB)
1
109864
9am –4pm, (CST) Monday-
2
ICE ANCHOR
5
102457
Friday.
3
EXTERNAL ANCHOR STRAP
5
104042
4
HUB & POLE KIT (4 POLES & 1 HUB)
5
109078
[email protected]
5
CARRY BAG
1
105558
6
BUCKLE ASSY W ITH STRAP
5
103244
7
INSTRUCTIONS/OWNER’S MANUAL
1
105567
Ice Anchors included in small carry pouch
SET-UP INSTRUCTIONS
BEFORE ATTEMPTING TO USE THIS PRODUCT ON THE ICE go t o www. cl a m c orp.com ,
click on your shelter model, and watch the set-up video provided. Then practice setting
up and taking down at home in the comfort of a heated area such as a garage or basement. Repeat
several times until comfortable. This will make your on-ice set-up much easier.
NO TOOLS ARE NEEDED FOR SET-UP OF
YOUR CLAM HUB S HELTER.
1. Unzip the storage bag completely and remove
the shelter. Use care not to misplace the anchor
pouch (Photo 1). It is advised to store your
anchors and pouch in the storage pocket of
your carry bag.
Replacement parts can be ordered on-line at www.clamcorp.com
Death from asphyxiation may result from use of
oxygen depleting heaters Open all vents for fresh
air ventilation.
Injury or death may result from fire if tent fabric is
exposed to open flame.
Tentfabric is not fireproof. Fabric will burn with
extended exposure to open flame. Do not bur n
f
open flame products inside tent. Tent fabric is
treated with fire retardant. Application of any fo -
eign substance may render the flame retardant
properties ineffective.
Night time: exterior reflectors must be visible to
reduce risk of collisions.
This tent is made with flame resistant fabric
which meets CPAI-84 specifications.

Page 3
3. Stand on the skirt of the shelter, grasp the roof
hub pull sewn onto the eyelet in the center of the roof
panel-which is all black. Pull upward on the loop until
the roof section pops up (Photo 3).
NOTE: The roof hub gets deployed
FIRST on set-up and collapsed LAST on take-down.
Photo 3
SET-UP INSTRUCTIONS
2. Open the shelter so that the gray top is facing
upward. Lay the shelter as flat on the ice as you
can, making sure that the tent is not twisted or
overlapping any of the poles (Photo 2). Do NOT
force the shelter while unfolding.
5. Walk around the entire shelter and pull each loop
sewn onto the eyelet in the center of the wall until all
sides are popped out-5X, as this is a 5 sided shelter.
(Photo 5).
Photo 2
4. Grasp the loop sewn onto the eyelet in the center
of one of the walls and pull outward until the wall
pops out (Photo 4).
Photo 4
Photo 5

Page 4
SET-UP INSTRUCTIONS
6. Your shelter should be standing up completely (Photo6).
Anchor the shelter to the ice by using ice anchors and
straps.
Screw ice anchors into the ice near the corners of the
shelter using Clam’s Ice Anchor Installation Tool PN
108348 (not included). Feed the adjustable strap grommet
onto the ice anchor and cinch the strap tight (Photo 7).
Repeat for each anchor drilled into the ice. In windy
condition, screw an anchor outside the shelter several feet
away from the hub on the windward side and attach a
strap found in the pockets under each side panel hub from
the hub eye bolt to the remote anchor. Adjust strap so it is
snug between hub and anchor. This will help keep the
shelter in place and the walls from collapsing. If more
anchors are needed, order PN 108064 (pack of two) via
www.clamcorp.com.
.
Photo 7
Ice Anchors in corners. Shelter is
secured to the ice by hooking the
grommet on the strap to the anchor and
cinching the strap tight.
Photo 6

Page 5
TAKE-DOWN INSTRUCTIONS
TAKE-DOWN INSTRUCTIONS
1. Close all windows. Leave one or both doors open
to allow air toescape.
2. Remove all internal ice anchors and store them in
the provided pouch or in the carrybag side pocket. In
windy conditions, remove ice anchor straps from
anchors and store back in hub pockets prior to
collapsing the roof and walls. Gather outside anchors
and place back inpouch.
3. Push the center hub on any wall until it collapses
inward (Photo 8). Continue pushing each wall
inward until all the walls are collapsed. The shelter
will fall to the ice on its own.
4. Push the hub of the roof down until it collapses.
NOTE: The roof hub gets deployed FIRST on
set-up and collapsed LAST on take- down.
5. The shelter will now be flat. Gather all corners of
the shelter and fold together (Photo 9). Do NOT
force the shelter when folding! W atch for
entanglement of poles (Photo 10).
6. Place the folded shelter and the ice anchor
pouch back into the carrying case with the hubs
toward the bottom end of the bag.
Make sure your ice shelter is completely dried out
after each use and before storing. Store your ice
shelter in a cool, dry place. Keep away from
rodents.
Photo 10
Untangled
Tangled
Photo 8
Photo 9

- S a f e t y I n s t r u c t i o n s -
Please fully understand and follow all safety instructions as outlined. Failure to do so could result in severe injury or death.
▪
Do not use open flame heaters in your ice shelter. Injury or death may result from fire if tent fabric is exposed to open flame. The
tent is not fireproof, but the fabric is treated with a fire retardant that meets CPAI-84 specifications. Application of any foreign
substance may render the flame retardant properties ineffective. Ice Armor fabric will melt when contact is made with hot surfaces
(i.e., heaters).
▪
Death from asphyxiation may result from use of oxygen depleting heaters. Open all vents for fresh air ventilation.
▪Never leave shelter unattended when set up.
▪Due to the increase in traffic (snowmobiles, autos, etc.) on area lakes, ice fishing can be hazardous at night. If you choose to
fish at night or in poor visibility conditions, be sure to take precautions with lights or reflectors to show drivers your
whereabouts. Night time: exterior reflectors must be visible to reduce risk of collisions.
*For replacement parts, frequently asked questions, shelter information, videos, and all of your ice fishing needs visit our web
site at www.clamcorp.com.
Due to Clam’s continued product development, Clam reserves the right to change specifications without notice. For complete details,
see the assembly and/or operating instructions that are provided and packaged with the purchased product.
Page 6
Death from asphyxiation may result from use of oxygen depleting heaters. Open all vents for fresh air
ventilation.
Injury or death may result from fire if tent fabric is exposed to open flame.
Tentfabric is not fireproof. Fabric will burn with extended exposure to open flame. Do not use
open flame products inside tent. Tent fabric is treated withfireretardant. Application of any foreign
substance may render the flame retardant properties ineffective.
Night time: exterior reflectors must be visible to reduce risk of collisions.
This tent is made with flame resistant fabric which meets CPAI-84 specifications.

FREQUENTLY ASKED QUESTIONS
Q: How do I set-up my hubshelter?
A: Go to www.clamcorp.comto watch an instructional video on the proper & simplest way to set-up and take-down a
hub style shelter.
Q: I can see pin holes in myfabric:
A: There are a few explanations as to why those pin holes exist.
 Simplythe color and/or black-out coatingbeingworn off the fabric due exposure in the elements and wear
due to friction.
 The fabric used is a woven material and these pin holesare parts of the thread that the coating did not attach
to. Either waythis has no effect on the function of the fabric and is simplyan appearance issue.
Q: There are cracks on the inside finish of thefabric:
A: This is normal, when you fold up your shelter, lines develop in the fabric. The inside coating may even appear to be
peeling. This is normal and will not affect the overall function of the ice house.
Q: Will my Fish House leakbecause Ican see pin holes in the fabric?
A: Quite the opposite, as you heat your house and the snow and ice begin to melt, the vapors can better escape the
shelter through an uncoatedfabric. Whenit snows or rains, the water molecules are larger than the vapor molecules
and cannot pass through the fabric and into thehouse.
Q: Are patch kits available for my Fish Trap and Clamshelter?
A: Patch kits are available theycan be purchased online www.clamcorp.comunder “Parts/Info”
Q: How do Iapplythe patch material?
A: When applyinga patch it works best to spray some adhesive (we recommend using 3M #77 or 3M #90 spray
adhesive) on to both surfaces; the part of the tent where the patch is goingto be applied and the patch itself. Wait
until the adhesive begins to dry and becomes tacky, then place the patch on the tent, and they will stick together.
Q: Is there anythingcan be put on outside of the tent to prevent water fromcomingthrough, when we are usingit? A:
Customers have been known to spray or apply water repellant on the outside of the shelter that you would use for
camping tents or boots.(Camp Dry would be an example of this type of product). These products will not damage
your tent in anyway.
Q: What will help keep mice or rodents from eating myClamHub shelter?
A: Some of our customers have had success with the following ways to keep miceout.
 Keep your tent in a sealed plastic tote with DRYER SHEETS and or MOTH BALLS
Q: The zipper on my tent freezes up and or sticks; is there anything I can use to help prevent this fromhappening?
A: Yes, there are a couple of zipper lubricants out there that our customers and pro staff have had good luckwith.
 Zipper Lube -A gel that you can applyjust by squeezingit onto the zipper and movingthe zipper back
and forth. This brand can be found in the campingsection of most sporting goods store.
 Silicone spray may also be used aswell.
Q: Wouldit be best to completely dry my shelter out everytime it gets used?
A: It is recommended to dry your tent out completelyafter each use, if not dried completelymoisture left in the house
may cause damage to your tent.
Q: How do I wash my sheltertent?
A: You can use a bleach and water solution (10 parts water to 1 part bleach) to get rid of themildew smell. Ifyou want
to wash the tent you can use a standard soap to wash it.
*** Please note - We do not recommend placing your shelter tent into a washing machine for cleaning.
Q: Am Iable to order parts and accessories fromyour website?
A: Absolutely, if you would like to order parts you can go to www.clamcorp.comunder “Parts/Info”
Page 7
