KING CANOPY GOLIATH Manual

King Canopy Brand Products
1730 Five Points Lane
Fuquay-Varina, NC 27526
Phone: [phone]
www.kingcanopy.com
GOLIATH™
10ft x 10ft / 3m x 3m
SETUP INSTRUCTIONS
It is recommended to use two people when setting up the Goliath.
1. Standing towards your partner,
grasp the corner legs and extend out to
arms length while stepping back. Insure
that bottom truss elbows are free and not
overlapping prior to opening.
2. Next, grasp the lower“V” of the truss that
you are facing. Lift up the shelter slightly
and step back until the unit is halfway
open.
3. Place fabric top on frame. Match up the
hook and loop on the corners of the cover
with the hook and loop at the top of legs.
Make sure the center peak of canopy
fabric is centered over the peak pole.
4. Pull the frame completely out until all
sliders are engaged at each corner on
each leg. You will have to push up on
sliders to get buttons to lock in place.
You may need to move around unit
pulling and opening until completely
open and locked.
5. With a helper, one should go to opposite
legs on one side of the canopy and extend
the legs by pressing the leg release
button and pulling out the lower leg. Use
your foot on bottom of leg to start the
extension, then use your hands. This will
allow the leg to extend smoothly. Repeat
this step on the other side.
6. To secure and tighten top on frame
attach the adjustable loop straps sewn to
top in the center on each side around the
bottom truss bar.
7. Adjust the legs to the desired setting by
pressing the release buttons and pull out
lower part of leg raising canopy.
8. Use the large nail stakes to secure the
feet at each leg position. To anchor the
unit using the stakes and rope enclosed,
tie the rope through the D-Ring on the
top at each corner.
TAKE DOWN INSTRUCTIONS
1. Unhook the loop straps holding top on.
2. Lower the legs by pressing leg release buttons and allowing the lower
part of leg to slide into upper part.
3. Press the top release button to release the framework top at each
corner. Failure to release this button may damage frame when you
attempt to close.
4. Remove and fold top. Remove the top after each use and store in the
pocket provided on the carry bag. Never store wet.
This is recommended to prevent small rips and tears.
Make sure the canopy top is dry before storing.
5. Grasp the top “V” and fold in completely. Move from side to side as
necessary. Careful, Watch Your Fingers.
6. Insert the legs into carry bag rst then close with zippers.
SEE REVERSE SIDE FOR CARE AND WARRANTY.
Specify unit size when ordering parts.
Call 1-800-800-6296
A. GOLALLL-A Lower leg, aluminum 40mm (4)
B. GOLALUL-B Upper leg, aluminum 50mm (4)
C. GOLALTB-C Truss bar, aluminum 35x15mm (24)
D. GOLALLP-D Lower peak pole, aluminum (1)
E. GOLALUP-E Upper peak pole, aluminum (1)
F. GOLALF-F Foot Pad (4)
G. GOLHA-G Leg height adjustment (4)
H. GOLLS-H Corner leg slider (4)
I. GOLLC-I Corner leg cap (4)
J. GOLTC-J Truss connector (12)
K. GOLTJ-K Truss junction connector (8)
L. GOLLPC-L Lower peak connector (1)
M. GOLPS-M Peak pole slider (1)
N. GOLUPC-N Upper peak pole cap (1)
O. GOLTBEC-O Truss bar endcap (48)
P. GOLLPC-P Lower peak cap (1)
GOLALPPA Peak pole assembly, includes parts: D, E, L, M, N & P
GOL10RB 10’ roller bag (1)
GOLT10WH 10’ white cover, 500 denier (1)
GOLT10104PKW 4-Pack Sidewalls for Goliath Shelter
GOL-SPRING Peak pole spring, in Part D (1)
STAKE-INST Ground stakes for instant (8)
ROPE-INST Rope for instant (8)
A
D
B
C
F
E
G
H
I
J
K
L
M
N
O
P

King Canopy Brand Products
1730 Five Points Lane
Fuquay-Varina, NC 27526
Phone: [phone]
www.kingcanopy.com
GOLIATH™
10ft x 10ft / 3m x 3m
WARRANTY INFORMATION
Please do not return canopy to store during
warranty period.
For assistance please call our Service Department
at: 1-800-800-6296 between the hours of
8:00am – 5:00pm EST, Monday – Friday.
King Canopy warrants canopy to be free of any
defects in materials and workmanship for a
period of 1 year from date of original purchase.
All warranty claims require proof of purchase and
may be prorated. King Canopy is not responsible
for any damage due to wind, rain, snow or any act
of nature. Under NO circumstances shall manu-
facturer or authorized representative be liable for
any personal loss, injury, or direct consequential
damage resulting from use of this product.
Non-Warranty Replacement Parts
If after expiration of the warranty period, you
require replacement parts please contact us at
1-800-800-6296. We stock replacement parts and
make them available to you at discounted prices.
Our customer service department will be pleased to
assist you in any way possible.
Certain regions of the country are extremely hard
on covers of any kind. Normal wear and tear is
not covered under the warranty, and should be
expected.
In order to receive a discounted or free replacement
part, you may be asked to return the part, freight
prepaid, to our warehouse for inspection before
we will send a replacement. You must, in all cases,
provide a copy of your receipt showing the date of
purchase, model number and price.
Replacement parts and customer service is also
available through our website.
Please visit us at www.kingcanopy.com
Keep all ame and heat sources away from
this tent fabric.This tent is made with fabric
that meets CPAI-84 Section 6 specications
for ame resistance. It is not re proof. The
fabric will burn if left in continuous contact
with any ame source.
WARNING!
SAFETY AND CARE INFORMATION
1Always use common sense.
2Do not use your canopy as a permanent cover.
3It is designed for temporary use only. Damages due to
weather conditions are not warranted.
4Do not set up on a steep incline. Do not leave unattended.
5Never set up in windy, rainy, or snowy conditions. Canopy is
not intended to serve as protection from such conditions.
Use for shade only. Disassemble and properly store your
Canopy after each use.
6Do not let snow or rain accumulate on top. It will collapse.
7Always us an anchoring system. Your canopy will take ight in
windy conditions. Anchoring is your responsibility. Damage
due to weather conditions are not warranted.
8Keep your canopy away from all re sources, such as grills or
re pits.
9Do not machine wash your top. Wash with mild soap and
water with a brush while the Instant Canopy is open without
the legs extended. Do not use harsh detergents, abrasives or
bleach.
10 Do not put your Instant Canopy away while wet or damp.
This promotes mildew and rust. Always store completely dry.
11 For best results in keeping your top clean and to avoid small
rips and tears, it is recommended that the top be removed
and stored in the carry bag after each use.
12 Never leave your canopy unattended!
Please read instructions completely before setting up your instant canopy.
