Clare Controls ClareOne Assembly instructions

© 18SEP20 Clare Controls, LLC. 1 / 4 DOC ID –1944 • Rev 05
ClareOne Door Window Sensor with Shock
Installation Sheet
Last modified: 09/18/20
Model number:
CLR-C1-DWSHK (White)
CLR-C1-DWSHK-B (Brown)
Description
The CLR-C1-DWSHK is a wireless window sensor designed
for dual protection; open/close and to detect vibrations made
by an intruder attempting to break a window. The sensor
contains a piezo detection device that detects vibrations when
mounted on a window frame. The detection circuit can be
adjusted for sensitivity during installation to ensure maximum
coverage. The device also has a built-in reed switch to monitor
the open and close of the door or window. When activated, the
sensor transmits a signal to the control panel. These are the
signals the unit provides: supervisory, tamper, and low battery
(as needed). The sensor is powered by (2) replaceable 3-VDC,
lithium coin-cell batteries.
Note: The sensor has 2 alarm zones:
•Alarm zone 1- reed switch
•Alarm zone 2- shock/glass break
Installation
When installing the door window shock sensor, follow the
below guidelines.
•Mounting the sensor on metal can affect the transmitting
range performance. Therefore, test the sensor from the
desired location using the installer sensor test in the
ClareOne panel, before permanently mounting it.
•Mount the sensor on the frame of the door or window.
•Mount to either wood or metallic surfaces.
•After mounting the sensor, test the sensor using the
procedure in the section “Testing the Sensor”.
Figure 1: Door window sensor placement
Mounting the sensor
Mount the sensor using the supplied mounting screws for
permanent mounting installations or using the supplied double-
sided tape is optional.
Note: The gap between the sensor and magnet should not
exceed .38 in (9.65 mm).
Mounting screws
1. Remove the sensor base from the sensor.

2 / 4 DOC ID –1944 • Rev 05
2. Place the sensor base in desired location and mount the
base with the supplied screws.
3. Reattach the base to the sensor.
4. Mount the magnet into the desired location using the
supplied screws, making sure the alignment mark lines up
with the sensor mark.
Shock test mode
•Test mode is entered automatically when the cover is
removed. The LED activates on shock activation and goes
out upon shock restoral.
•LED is functional only in test mode.
•Test mode is active as long as the cover is removed.
Shock sensor sensitivity setting
An LED test mode (see above) is included to aide in setting
sensitivity to desired level
1. Mount sensor in intended location and tap mounting
surface with desired level of activation impact
2. Adjust potentiometer until correct sensitivity is obtained
The potentiometer adjusts shock sensitivity from
minimum “Low”(CCW) to maximum “Hi”(CW).
These setting are marked on the PCB.
In maximum sensitivity mode, the least amount of shock is
required to activate a shock alarm. If the potentiometer is set
all the way Low (CCW) the shock portion of the device is
turned off and only the internal reed switch is active
Programming
To add the sensor to your panel and for detailed programming
instructions, use the steps below and refer to the ClareOne
Wireless Security and Smart Home Panel User Manual (DOC
ID 1871).
Note: The Door Window Sensor with Shock has a 2-part
addition process. You must add the door window sensor and
the shock sensor to the ClareOne panel.
To add the door window sensor:
1. Put the ClareOne panel in “add mode” and follow the
displayed instructions for adding the sensor.
2. Remove the battery tabs, and then trip the sensor using
magnet or enter the ID number.
3. Exit “add mode.”
To add the shock sensor:
1. Open the sensor body, and then locate the tamper switch.
2. Put the ClareOne panel in “add mode,” and then press the
tamper switch.
Testing and adjusting the sensor
Take the sensor and magnet to the desired mounting location,
making sure to line up the magnet alignment marks with each
other. Trip the sensor by pulling the magnet away from the
sensor. Monitor the system after tripping the sensor.
Battery replacement
Note: If a low battery alarm occurs, replace the battery within 7
days.
•The low battery detected LED flashes until the battery is
replaced. The sensor sends a low battery signal to the
ClareOne panel.
•The CLR-C1-DWSHK requires (2) 3-VDC, lithium coin-cell
batteries (Varta or Panasonic, Model CR2032). Both
batteries should be replaced at the same time.
1. Remove the sensor cover by pressing on the latch and
pulling the cover off.
2. Do not remove the circuit board, slide the old batteries out
as shown.
3. Slide the batteries out from under the circuit board and
note the polarity.
4. Insert new batteries, noting the polarity.
5. Replace sensor cover.
CAUTION: Battery may explode if mistreated. Do not recharge,
disassemble, or dispose of in fire.
Specifications
Compatible panel
ClareOne (CLR-C1-PNL1)
Transmitted frequency
433MHz
Encrypted
Yes
Operating gap
0.38 in (9.96 mm)
Transmitted indications
Tamper, low battery, supervisory, alarm 1,
and alarm 2
Supervisory keep-alive
60 to 70 minutes
Shock sensitivity adjust
Yes
Battery type
(2x) CR2032
Battery life
5 to 7 years
Operating environment
Temperature
Relative humidity
32 to 120°F (0 to 49°C)
95% non-condensing
Dimensions
(W × H × D)
2.25 × 1.0 × 0.50 in.
(57.15 × 25.4 × 12.7 mm)
Water resistant
No
Certifications
FCC: 15.109 Class B 15.231, Industry
Canada: ICES-003, RSS-210

DOC ID - 1944 • Rev 05 3 / 4
Regulatory information
Manufacturer
Clare Controls, LLC.
7519 Pennsylvania Ave, Suite 104
Sarasota, FL 34243
FCC compliance
This equipment has been tested and found
to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide
reasonable protection against harmful
interference in a residential installation.
This equipment generates, uses and can
radiate radio frequency energy and, if not
installed and used in accordance with the
instructions, may cause harmful
interference to radio communications.
However, there is no guarantee that
interference will not occur in a particular
installation.
If this equipment does cause harmful
interference to radio or television reception,
which can be determined by turning the
equipment off and on, the user is
encouraged to try to correct the interference
by one or more of the following measures:
•Reorient or relocate the receiving
antenna.
•Increase the separation between the
equipment and receiver.
•Connect the equipment into an outlet
on a circuit different from that to which the
receiver is connected.
•Consult the dealer or an experienced
radio/TV technician for help.
This device complies with Industry Canada
license-exempt RSS standard(s). Operation
is subject to the following two conditions: (1)
this device may not cause interference, and
(2) this device must accept any
interference, including interference that may
cause undesired operation of the device.
Cet appareil est conforme avec Industrie
Canada exempts de licence standard RSS
(s). Son fonctionnement est soumis aux
deux conditions suivantes: (1) cet appareil
ne doit pas provoquer d'interférences et (2)
cet appareil doit accepter toute interférence,
y compris celles pouvant causer un
mauvais fonctionnement de l'appareil.
In accordance with FCC requirements of
human exposure to radio frequency fields,
the radiating element shall be installed such
that a minimum separation distance of 20
cm is maintained from the general
population.
FCC: 2ABBZ-RF-SHK-433
IC: 11817A-RFSHK433
This Class B digital apparatus complies with
Canadian ICES-3B.
Cet appareil numérique de la classe B est
conforme à la norme NMB-003 du Canada.
MANUFACTURER HEREBY DISCLAIMS
ALL WARRANTIES AND
REPRESENTATIONS, WHETHER
EXPRESS, IMPLIED, STATUTORY OR
OTHERWISE INCLUDING (BUT NOT
LIMITED TO) ANY WARRANTIES OF
MERCHANTABILITY OR FITNESS FOR A
PARTICULAR PURPOSE WITH RESPECT
TO THESE PRODUCTS AND ANY
RELATED SOFTWARE.
MANUFACTURER FURTHER DISCLAIMS
ANY OTHER IMPLIED WARRANTY
UNDER THE UNIFORM COMPUTER
INFORMATION TRANSACTIONS ACT OR
SIMILAR LAW AS ENACTED BY ANY
STATE.
(USA only) SOME STATES DO NOT
ALLOW THE EXCLUSION OF IMPLIED
WARRANTIES, SO THE ABOVE
EXCLUSION MAY NOT APPLY TO YOU.
THIS WARRANTY GIVES YOU SPECIFIC
LEGAL RIGHTS AND YOU MAY ALSO
HAVE OTHER LEGAL RIGHTS THAT
VARY FROM STATE TO STATE.
MANUFACTURER MAKES NO
REPRESENTATION, WARRANTY,
COVENANT OR PROMISE THAT ITS
ALARM PRODUCTS AND/OR RELATED
SOFTWARE (I) WILL NOT BE HACKED,
COMPROMISED AND/OR
CIRCUMVENTED; (II) WILL PREVENT, OR
PROVIDE ADEQUATE WARNING OR
PROTECTION FROM, BREAK-INS,
BURGLARY, ROBBERY, FIRE; OR (III)
WILL WORK PROPERLY IN ALL
Environmental
class
UL: Indoor dry
IEC: 3K5
EU compliance
EN 54
EN 54-00:0000
European Union
directives
1999/5/EC (R&TTE directive): Hereby, Clare
Controls declares that this device is in
compliance with the essential requirements and
other relevant provisions of Directive 1999/5/EC.
2002/96/EC (WEEE directive): Products marked
with this symbol cannot be disposed of as
unsorted municipal waste in the European Union.
For proper recycling, return this product to your
local supplier upon the purchase of equivalent
new equipment, or dispose of it at designated
collection points. For more information see:
www.recyclethis.info.
2006/66/EC (battery directive): This product
contains a battery that cannot be disposed of as
unsorted municipal waste in the European Union.
See the product documentation for specific
battery information. The battery is marked with
this symbol, which may include lettering to
indicate cadmium (Cd), lead (Pb), or mercury
(Hg). For proper recycling, return the battery to
your supplier or to a designated collection point.
For more information see: www.recyclethis.info.

4 / 4 DOC ID –1944 • Rev 05
Warranty information
Clare Controls offers a two (2) year limited warranty on original
Clare Controls components, from the date of shipment from
Clare Controls.
Contact information
Clare Controls, LLC.
7519 Pennsylvania Ave, Suite 104
Sarasota, FL 34243
General: 941.328.3991
Fax: 941.870.9646
www.clarecontrols.com
Integrator/Dealer Support: 941.404.1072
Homeowner Support (ClareCare): 941.315.2273 (CARE)
