clare CS-WWT-10 User manual

Features
• Expansion Card that plugs into the Clare Security
PanelSupports button combinations
• Enables system to receive signals from Honeywell,
2GIG, GE, Napco & DSC sensorsSecure encrypted
wireless transmissions
• All sensor alarm, supervisory and trouble
signals are reported
• Dual antennas for reliable range
Installation
• Power down the Panel:
• Open cover
• Unplug battery cord
• Unplug power cord
• Insert the CS-WWT-10 into expansion slot 3 of the
Control Panel, gently inserting the connector and
snapping the stand-offs into place
• Connect battery cord, plug the power, and close
the cover to the panel
Use the panel installation guide to verify proper system setup.
I
N
S
T
A
L
L
G
U
I
D
E
I
CS-WWT-10 Wireless
Translator Module
Battery
Cord
Plug
Power
Cord
Plug
RE934ZT
Installed
in Panel
Expansion
Slot
3

01
Enrollment
With the translator, sensors are enrolled into the panel via RF transmission. Once
enrolled, the zones are congured in the panel the same way as Clare zones. It is
important to follow enrollment instructions carefully, and execute the steps in order, so
that devices are enrolled properly. Before enrollment, the panel will rst need to be set
to the proper translator protocol and save the panel settings. This is set via the dealer
portal or installer app.
Enrolling GE Devices
• Place panel in sensor enrollment mode.
• Activate particular GE sensor as follows:
o DWS: Open the cover of the sensor
o PIR & Glass break: Open the cover of the sensor
o Key fobs: Press the Lock and Unlock buttons simultaneously for 3 seconds
o Panic: Press the panic button
Enrolling DSC Devices
• Place panel in sensor enrollment mode.
• Activate particular DSC sensor as follows:
o DWS: Open and close the cover of the sensor
o PIR & Glass break: Open and close the cover of the sensor
o Key fobs: Press the panic button (lower right)
o Panic: Press the panic button
Enrolling DSC Devices
• Remove batteries on all PIR motion detectors
• Place panel in sensor enrollment mode.
• NOTE: Honeywell sensor types must be enrolled in the following order.
Activate particular Honeywell sensor as follows:
o PIR with Tamper: Press and hold tamper button and insert battery
o PIR without Tamper: Insert battery
o DWS: Cycle the door or window contact three times, either open-close-open or
close-open-close. Allow no more than 3 seconds between actions
o Panic: Open panic and remove the battery. Press and hold the panic button and
insert battery with button pressed. Release button within 3 seconds
Enrolling Napco Devices
Place panel in sensor enrollment mode.
Activate particular Napco sensor as follows:
o DWS: Open and close the cover of the sensor
o PIR & Glass break: Open and close the cover of the sensor
o Key fobs: Press the AUX2 (Panic) button
o Panic: Napco Panic is not supported by the translator
01
Enrolling 2GIG Devices
• Place panel in sensor enrollment mode.
• Activate particular 2GIG sensor as follows:
o DWS: Cycle the door or window contact three times, either open-close-open or
close-open-close. Allow 2 or 3 seconds between actions.
o PIR: Press and hold tamper button and insert battery
o Glassbreaks: Open and closer cover of sensor
o Key fobs: Press and hold Arm Away and DIsarm buttons simultaneosly
o Panic: Press the panic button
Testing
• Verify in the web portal or installer app that the device shown, device type, and
setting are correct for each zone.
• Verify that the correct number of zones were enrolled into the panel.
• Test each zone to verify proper operation.
Z-Wave
Z-Wave devices can be controlled via the Interactive function.
Green LED:
ON - When panel is AC powered
OFF - When panel does not have
AC power
Flickers - With Each sensor
packet received
Red LED:
Normally off, ashes with each
Zwave message received from
panel

01
2019-02-1847-01
941.238.3991
www.ClareControls.com
Original document below
https://bit.ly/2SpvS0b
Specications
Temperature Range: 0F to 120F
Board dimensions: 1.8 x 1.7 x .1 inches
Specifcations subject to change without notice
