Orbit Research Reader 40 User manual

1
Orbit Research
Confidential and Proprietary Information
Orbit Reader 40 Commands
Quick Reference Guide
1 Power On/Off
Device
Key
Orbit Reader 40
Press and hold the POWER key for two seconds to
turn On the unit.
2 Hot Keys to Switch to Remote mode from Stand-alone Mode
Description
Onboard Keypad
Connect via HID
Space + Dot 2 + Dot 7
Connect via Serial
Space + Dot 3 + Dot 7
Connect via Bluetooth
Space + Dot 4 + Dot 7
Connect via Mass Storage
Space + Dot 5 + Dot 7
Connect via HID Braille
Space + Dot 6 + Dot 7
3 Hot Keys to Switch to Remote mode from Stand-alone Mode
Description
Onboard Keypad
Switch to Remote mode from Stand-alone mode
Select + Right
4 Hot Keys to Stand-alone Mode from active/Inactive Remote mode
Description
Onboard Keypad
Switch to Stand-alone mode from active/Inactive
Remote mode
Select + Left
5 Hot Keys to Stand-alone Mode from Inactive Remote mode
Description
Onboard Keypad
Switch to Stand-alone mode from Inactive Remote
mode
Dot 7
6 Preference Menu Navigation
Description
Onboard Keypad
Opens menu
Select + Up
Open context menu of the editor
Select
Move to the next menu item
Down Arrow
Move to the previous menu item
Up Arrow
Move to the Previous menu choice for current item
Left Arrow
Move to the Next menu choice for current item
Right Arrow
Exit the menu
Dot 7
Selects the item/Dismiss the alert
Select or Dot 8
Top of the menu
Space + Dots 1 2 3
End of the menu
Space + Dots 4 5 6

2
Orbit Research
Confidential and Proprietary Information
7 File Manager Commands
Description
Onboard Keypad
Move to next file property
Right Arrow or Left or Right
front panning key
Move to previous file property
Left Arrow or Left or Right
back panning key
Move to next file property
Pan Right(front)
Move to previous file property
Pan Right(back)
Move to Next folder/File
Down Arrow
Move to previous folder/File
Up Arrow
Move to previous file property
Left Arrow
Move to next file property
Right Arrow
Move to a file starting with letter
Dot 3
Move to a file starting with letter
Dot 6
Move to a file starting with letter
Dot 2
Move to a file starting with letter
Dot 5
Moves focus back one level in to the file manager,
if at the root does nothing, if in one of the columns
returns to the filename
Dot 7
Open current file/folder
Dot 8
Move to a file starting with letter
Space
Open current file/folder
Select
Move to first file
Space + Dots 1 2 3
Move to last file
Space + Dots 4 5 6
Edit current file
Space + Dots 1 5
Edit Last File
Space + Dots 1 2 4 6
Mark current file
Space + M (Dots 1 3 4)
Create New file
Space + N (Dots 1 3 4 5)
Create New Folder
Space + O (Dots 1 3 5)
Delete File
Space + D (Dots 1 4 5)
Rename File
Space + R (Dots 1 2 3 5)
Cut File
Space + X (Dots 1 3 4 6)
Copy File
Space + C (Dots 1 4)
Paste
Space + V (Dots 1 2 3 6)
Protect (or unprotect) file
Space + P (Dots 1 2 3 4)
Jump to a file starting with the letter
Any alpha numeric character
8 File reader Navigation command
Description
Onboard Keypad
Moves to the next set of characters that fit on the
display
Left or Right front panning
key

3
Orbit Research
Confidential and Proprietary Information
Moves to the previous set of characters that fit on
the display
Left or Right back panning
key
Moves to next paragraph
Down Arrow
Moves to previous paragraph
Up Arrow
Scrolls the previous character into view
Space + Dot 3 or Left Arrow
Scrolls the next character into view
Space + Dot + 6 or Right
Arrow
Moves back in the file to the next form feed
character (Ctrl+l) or 60 lines whichever comes first
Dot 3
Moves forward in the file to the next form feed
character (Ctrl+l) or 60 lines whichever comes first
Dot 6
Move to previous bookmark
Dot 2
Move to Next bookmark
Dot 5
Moves to the top of the file
Dot 1
Moves to the bottom of the file
Dot 4
Exits the file and shows the folder contents again
at the properties column where it was previously
Dot 7
Scrolls the previous word into view
Space + Dot 2 or Space + Left
Arrow
Scrolls the next word into view
Space + Dot 5 or Space +
Right Arrow
Previous binary search
Dot 8 + up arrow
Next binary search
Dot 8 + down arrow
Back Search Result
Dot 8 + left arrow
Next Search Result
Dot 8 + right arrow
Scrolls the next word into view
Space + Dot 5
Scrolls the previous word into view
Space + Dot 2
Moves to the back Paragraph
Space + Dot 1
Moves to the next Paragraph
Space + Dot 4
Scrolls the previous character into view
Space + Dot 3
Scrolls the next character into view
Space + Dot 6
Start or stop auto scroll
Space
Change the auto-scroll speed by a second
Space + Up/Down Arrow
Change the auto-scroll speed by 0.1 second
Space + Dot 7+Up/Down
Arrow
Top of File
Space + Dots 1 2 3
End of File
Space + Dots 4 5 6
Edit current file
Space + Dots 1 5
Return to last Edit file
Space + Dots 1 2 4 6
Set/Clear Bookmark
Space + M (Dots 1 3 4)
Open New File
Space + N (Dots 1 3 4 5)
Open Find edit box
Space + F (Dots 1 2 4)

4
Orbit Research
Confidential and Proprietary Information
9 Edit Box Commands
Description
Onboard Keypad
Down Paragraph
Down Arrow
Up Paragraph
Up Arrow
Move cursor to left
Left Arrow
Move cursor to right
Right Arrow
Move cursor to previous word
Space + Left Arrow
Move cursor to next word
Space + Right Arrow
Backspace
Dot 7
Enter
Dot 8
Typing input
Space
Exit Edit Box
select
10 File Editor Commands
Description
Onboard Keypad
Moves to the next set of characters that fit on the
display
Left or Right front panning
keys
Moves to the previous set of characters that fit on
the display
Left or Right back panning
keys
Moves to next paragraph
Down Arrow
Moves to previous paragraph
Up Arrow
Move cursor to left
Left Arrow
Move cursor to right
Right Arrow
Backspace
Dot 7
Enter
Dot 8
Typing input
Any alpha numeric character
Enter into the editor context menu
select
Moves cursor to the start of previous word
Space + Left Arrow
Moves cursor to start of the next word
Space + Right Arrow
Back Search Result
Dot 8 + left arrow
Next Search Result
Dot 8 + right arrow
Start of Paragraph
Space + 7 + left
End of Paragraph
Space + 7 + right
Back Page
Space + 7 + up arrow
Next Page
Space + 7 + down arrow
Insert a character at cursor
Any alpha numeric character

5
Orbit Research
Confidential and Proprietary Information
11 Calculator Command
Description
Onboard Keypad
Open/Close Calculator
Space+ Dots 1,4,7
Backspace
Dot 7
Clear Entry
Space + Dot 7
All clear
Space + Dots 7,8
Display answer
Dot 8
Pi key: Displays the value of pi
P (Dots 1,2,3,4)
M+ (Memory Plus)
Space + Up Arrow
M- (Memory minus)
Space + Down Arrow
MR (Memory recall)
Space + Left Arrow
MC (Memory clear)
Space + Right Arrow
History navigation
Space + Panning key
Open context menu
Select
12 Calendar Command
Description
Onboard Keypad
Open/Close Calendar
Space + Dots 1,4,8
Navigate to Next Week
Down Arrow
Navigate to Previous Week
Up Arrow
Move between days
Left/Right Arrow
Create New Appointment
Space + N (Dots 1,3,4,5)
Add Appointment
Dot 8
Go to Date
Space+ G (Dots 1,2,4,5)
Go to Date after entering the date
Select
Move through list of appointments
Up/Down Arrow
Delete Appointment
Space + D (Dots 1,4,5)
Stop ringing alarm
Dot 7
13 Context menu Commands
Description
Onboard Keypad
Opens Context menu
Select
Move to the next menu item
Down Arrow
Move to the previous menu item
Up Arrow
Exit the Context menu
Dot 7
Selects the item
Select

6
Orbit Research
Confidential and Proprietary Information
14 UID File Command
Description
Onboard Keypad
Generate the UID file on the SD card
Space + Dots 1 3 6 7
15 Auto Scroll Command
Description
Onboard Keypad
Start/Stop auto scroll
Space + S (Dot 2 3 4)
Pause/Resume auto scroll
Space
16 Show Current Date and Time Command
Description
Onboard Keypad
Show current date and time
Space + T (Dot 2 3 4)
17 Bluetooth Command
Description
Onboard Keypad
Activate Bluetooth device
Space + Dot 8 + Dot 1 to 5
Scan nearby Bluetooth devices
Space + Dots 2,4,7
Delete selected connection
Space + d (Dots 1,4,5)
Delete all connections
Space + x (Dots 1,3,4,6)
Send file (file transfer)
Space + Dots 2,3,4,5,7
Accept file transfer/Pairing request
Dot 8
Reject file transfer/Pairing request
Dot 7
18 Language Profile Switching Commands
Description
Onboard Keypad
Select Profile 1
Select + Dot 1
Select Profile 2
Select + Dot 2
Select Profile 3
Select + Dot 3
Select Profile 4
Select + Dot 4
19 Key Lock/Unlock
Device
Onboard Keypad
Orbit reader 40
Dot7 + Dot8 for two or more than two
seconds

7
Orbit Research
Confidential and Proprietary Information
20 Firmware Upgrade
Device
Onboard Keypad
Firmware Upgrade mode via USB
Press and hold down “Right Pan key(Down)”
and “Dot 5” key simultaneously, while pressing
these two keys, press and release “Dot 8” key
Firmware Upgrade mode via SD Card
Press and hold down dot 4 + Right Forward
Panning key, then press the power button, then
release all keys
21 System Reset
Device
Onboard Keypad
Orbit reader 40
Right Pan key (Down) +Dot 8
22 System Soft Reset
Device
Onboard Keypad
Orbit reader 40
Press and hold Dot 3 + Power key for 10 seconds
23 Sleep Mode Command in Local Mode
Device
Onboard Keypad
Orbit reader 40
Short press power key
