Thank you for purchasing this Clarion product.
*Please read this owner's manual in its entirety before operating this equipment.
*Check the contents of the enclosed warranty card and keep it carefully with this manual.
Contents
1. FEATURES...................................................................•..................................................................3
2. PRECAUTIONS 4
3. CONTROLS 5
Names of the Buttons and Their Main Functions 5
4. DCP (DETACHABLE CONTROL PANEL) 6
5. REMOTE CONTROL 7
Functions of Remote Control Unit Buttons 7
Inserting the Battery 8
6. OPERATIONS 9
Basic Operations 9
Radio Operations
11
CD/MP3IWMAlAAC Operations 12
Operations Common to Each Mode 16
7. ACCESSORIES
19
USB/MTP Operations 19
iPod Operations
21
Satellite Radio Operations 23
CD Changer Operations 25
DVD Changer Operations 26
TV Operations 26
8. TROUBLESHOOTING 27
9. ERROR DISPLAYS 29
10. SPECIFICATIONS 30
11. OTHERS 30
1. FEATURES
~NET
IAAcl
IU
s
1:t
DI
~
'i:'A.~I~,.I
READY
IG1 Madefor
@J iPod
",,.~
ID3TAG
•USB Audio for iPod
•SAT Ready via CeNET
•6ch/2V RCA Output with Built-in LPF/HPF
CZ309 3

THIS PRODUCTION COMPLIES WITH DHHS RULES 21 CFR
SUBCHAPTER JAPPLICABLE AT DATE OF MANUFACTURE.
12V e GROUND
AM 530-1710kHz/FM 87.9-107.9MHz
2. PRECAUTIONS
CHANGES OR MODIFICATIONS TO THIS
PRODUCT NOT APPROVED
BY THE
MANUFACTURER
WILL VOID THE
WARRANTY AND
WILL VIOLATE FCC
APPROVAL.
Handling Compact Discs
•Compared to ordinary music CDs, CD-R and
CD-RW discs are both easily affected by high
temperature and humidity and some of CD-R
and CD-RW discs may not be played.
Therefore, do not leave them for along time
in the car.
•Never stick labels on the surface of the
compact disc or mark the surface with a
pencil or pen.
ACAUTION
INFORMATION FOR USERS:
USE OF CONTROLS, ADJUSTMENTS, OR
PERFORMANCE OF PROCEDURES OTHER
THAN THOSE SPECIFIED HEREIN, MAY
RESULT IN HAZARDOUS RADIATION
EXPOSURE.
THE COMPACT DISC PLAYER SHOULD NOT
BE ADJUSTED OR REPAIRED BY ANYONE
EXCEPT PROPERLY QUALIFIED SERVICE
PERSONNEL.
CHANGES OR MODIFICATIONS NOT
EXPRESSLY APPROVED
BY THE
MANUFACTURER FOR COMPLIANCE
COULD VOID THE USER'S AUTHORITY TO
OPERATE THE EQUIPMENT.
I Clarion
MODEL I
MANUFACTURED'
THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES.
OPERATION
IS SUBJECT TO THE FOLLOWING TWO CONDITIONS:
Il) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE, AND
(2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED,
INCLUDING INTERFERENCE THAT MAY CAUSE UNDESIRED
OPERATION.
CLARION CO.,L
TO
7-2, SHINTOSHIN,CHUO-KU,SAITAMA-s,HI,SAITAMA 330-0081,JAPAN
This product includes technology owned by
Microsoft Corporation and cannot be used or distributed
without alicense from MSLGP.
This equipment has been tested and found to
comply with the limits for aClass Bdigital
device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable
protection against harmful interference in a
residential installation.
This equipment generates, uses, and can
radiate radio frequency energy and, if not
installed and used
in accordance with the
instructions, may cause harmful interference to
radio communications. However, there is no
guarantee that interference will not occur
in a
particular installation.
If this equipment does cause harmful
interference to radio or television reception,
which can be determined by turning the
equipment off and on, the user is encouraged to
consult the dealer or an experienced radiolTV
technician for help.
SERIAL No.
PE-~
276-c::::J
Clarion Co., Ltd.
MADE IN c=::J
DisplayScreen
In extreme cold, the screen movement may slow
down and the screen may darken, but this is
normal.
The screen will recover when it returns to
normal temperature.
CJ
Bottom View of Source Unit
4CZ309

3. CONTROLS
i
Names of the Buttons and Their Main Functions
--:+--+-[USB SLOT]
~;---;- [SOUND]
-;.:--:- [AUX]
[~] (EJECT)~-:-:-~
[RELEASE] button
•Press the [RELEASE] button to unlock the DCP.
[rr-:~] button
•Perform preset scan and auto store while in
the radio mode.
•Play or pause atrack while
in the CD/MP31
WMAJAAC mode.
[.] (UP), [T] (ON) buttons
•Select the folder while in the MP3IWMAIAAC
mode.
[IR RECEIVER]
•Receiver for remote control unit. (Operating
range: 30° in all directions)
[CD SLOT]
•CD insertion slot.
[USB SLOT]
•USB memory/MTP/iPod devices insertion slot.
[SOUND] button
•Use the button to switch to the sound adjust
mode.
[AUX] input jack
•The input jack for connecting an external
device.
[DIRECT] buttons
•Store astation into memory or recall it directly
while in the radio mode.
[ROM] button
•Perform random play while in the CD/MP31
WMAlAAC mode.
[RPT] button
•Perform repeat play while in the CD/MP31
WMAlAAC mode.
[SCN] button
•Perform scan play while in the CD/MP31
WMAlAAC mode.
[ISR] button
• RecalliSR radio station in memory.
•Press and hold the button for 2seconds or
longer: Store current station into ISR memory
(radio mode only).
[DISP] button
•Switch the display indication.
[ROTARY] knob
•Adjust the volume by turning the knob
clockwise
or counterclockwise.
[BND] button
•Switch the band, or seek tuning or manual
tuning while in the radio mode.
•
Playa first track while in the CD/MP3IWMAI
AAC mode.
[SRC] button
•Turn on or off the power.
•Switch the operation mode among the radio
mode, etc.
[~], [~] buttons
•Enter the fast-forward or fast-backward mode.
[~] (EJECT) button
•Eject adisc when it is loaded into the unit.
CZ309 5

DCP Rear Panel
Note:
• If the DCP is dirty, wipe off the dirt with asoft, dry
cloth only.
DCP
connector
•The DCP can easily be damaged by
shocks. After removing it, be careful not to
drop it or subject it to strong shocks.
•When the Release button is pressed and
the
DCP is unlocked, the car's vibrations
may cause
it to fall. To prevent damage to
the DCP, always store it in its case after
detaching it.
•The connector connecting the main unit
and the DCP is an extremely important
part. Be careful
not to damage it by
pressing on it with fingernails, pens,
screwdrivers, etc.
Storing the DCP in the DCP Case
Hold the OCP, in the orientation as shown in the
figure below, and put it into the supplied OCP
case. (Ensure the DCP is
in the correct
orientation.)
Attaching the DCP
1. Insert the right side of the OCP into the main
unit.
2. Insert the left side of the OCP into the main
unit.
4. DCP (DETACHABLE CONTROL PANEL)
* The OCP is unlocked
3. Remove the OCP.
Removing the DCP
1. Press the [SRC] button for 1second or
longer to switch off the power.
2. Press in the [RELEASE] button.
[RELEASE] button
The control panel can be detached to prevent
theft. When detaching the control panel, store it
in the OCP (DETACHABLE CONTROL PANEL)
case to prevent scratches.
We recommend taking the OCP with you when
leaving the car.
6 CZ309

5. REMDTE CONTROL
Functions of Remote Control Unit Buttons
* Some buttons on the remote control unit have different functions from the corresponding buttons on the main
unit.
[A],[']
;- Signal transmitter
[SRCl_--4-~:O=SR=C ===a=No==l (BND]
II~- ~(.1I1
II
[~l,[~l
II':'':'=~~ ,
[MUTE] -----+;II-€?R@II[DISP]
[ISR]~J II 8Q~G [ROM]
seN RPT ROM II
I"S/,I,S TVlYl. [RPT]
[SCN]
Clarion
•Shared modes
[SRC] button
•Press the button to turn on the power.
Press and hold the button for 1second or
longer to turn off the power.
•Use to alternate operation mode among the
various modes.
t"], [~] buttons
•Increases and decreases volume.
[MUTE] button
•Turns mute function on and off.
[ISR] button
•Recalls ISR radio station stored in memory.
•Press and hold the button for 2seconds or
longer to store current station in ISR memory
(radio mode only).
[DISP] button
•Press to select the desired display.
•Radio/Satellite Radio modes
[BND] button
•Switches reception band.
[~], [~] buttons
•Moves preset channels up and down.
[SCN] button
•Press to perform preset scan.
•Press and hold the button for 2seconds or
longer to perform auto store.
•
In the Satellite Radio mode, press once to
perform category scan; hold depressed for 1
second
or longer to perform preset scan.
•CD/MP3/WMA/AAC and USB/MTP
modes
[BND] button
•Press to play the first track.
[~], [~] buttons
•Press to move the tracks up and down.
•Press and hold the button for 1second or
longer to perform fast-forward/fast-backward
(Except DRM file).
[~II] button
•Switches between playback and pause.
[SCN] button
•Press to perform scan play.
•When
in MP3IWMAlAAC and USB/MTP
modes, press and hold the button for 1
second or longer to perform folder scan play.
[RPT] button
•Press to perform repeat play.
•When
in MP3IWMAlAAC and USB/MTP
modes, press and hold the button for 1
second
or longer to perform folder repeat
play.
[ROM] button
•Press to perform random play.
•When
in MP3IWMAlAAC and USB/MTP
modes, press and hold the button for 1
second or longer to perform folder random
play.
CZ309 7

Owner's manual
Mode d'emploi
Manual de instrucciones
CZ309
CD/USB/MP3IWMAJAAC RECEIVER WITH CeNET CONTROL
AUTORADIO CD/USB/MP3IWMAlAACIAVEC COMMANDE CeNET
RECEPTOR CDIUSBIMP3IWMAlAAC CON CONTROL CeNET

CLARION PRODUCTREGISTRATION INFORMATION
For USA and Canada only
www.clarion.com
Dear Customer:
Congratulations
on your purchase of aClarion mobile electronic products. We are confident
that you'll enjoy your Clarion experience.
There are many benefits to registering your product.
We invite you to visit our website at
www.clarion.com to register your Clarion product.
We have made product registration simple with our easy to use website. The registration form
is short and easy to complete. Once you're registered, we can keep you informed of important
product information.
Register at www.clarion.com -it's easy to keep your Clarion product up to date.
INFORMATIONS DE L'ENREGISTREMENT DE PRODUITS CLARION
Pour les Etas Unis et Ie Canada seulement
www.clarion.com
Cher client:
Nous vous remercions d'avoir achete ce produit electronique mobile Clarion. Nous sommes
confiants que vous apprecierez votre experience Clarion.
II yabeaucoup d'avantage aenregistrer votre produits. Nous vous invitons avisiter notre site
Web www.clarion.com pour enregistrer votre produit Clarion.
Nous avons facilite la tache d'enregistrement de produit simple et facile grace anotre site Web.
Le formulaire d'enregistrement est court et facile acompleter. Lorsque vous etes enregistrer,
nous pouvons vous tenir informe des informations important de produits.
Enregistrer awww.clarion.com -c'est facile de meUre ajour votre produit Clarion.
INFORMACION DEL REGISTRO DE PRODUCT 0 DE CLARION
Para USA Y Canada nomas
www.clarion.com
Querido Cliente:
Felicitaciones por
su compra de producto electr6nico m6vil de Clarion. Estamos seguros que
usted gozara de su experiencia con
el producto de Clarion.
Hay muchas ventajas al registrar
,su producto. Le invitamos aque visite nuestro sitio en internet
www.clarion.com para registrar su producto de Clarion.
Hemos hecho
el registro de producto facil en nuestro sitio. La forma de registro es corta yfacil
de completar. Una vez que
10 registre, podremos proporcionarle la informaci6n de su producto.
Registrese
en www.clarion.com -es facil mantener su producto de Clarion actualizado.
2 CZ309

Thank you for purchasing this Clarion product.
*Please read this owner's manual in its entirety before operating this equipment.
*Check the contents of the enclosed warranty card and keep it carefully with this manual.
Contents
1. FEATURES...................................................................•..................................................................3
2. PRECAUTIONS 4
3. CONTROLS 5
Names of the Buttons and Their Main Functions 5
4. DCP (DETACHABLE CONTROL PANEL) 6
5. REMOTE CONTROL 7
Functions of Remote Control Unit Buttons 7
Inserting the Battery 8
6. OPERATIONS 9
Basic Operations 9
Radio Operations
11
CD/MP3IWMAlAAC Operations 12
Operations Common to Each Mode 16
7. ACCESSORIES
19
USB/MTP Operations 19
iPod Operations
21
Satellite Radio Operations 23
CD Changer Operations 25
DVD Changer Operations 26
TV Operations 26
8. TROUBLESHOOTING 27
9. ERROR DISPLAYS 29
10. SPECIFICATIONS 30
11. OTHERS 30
1. FEATURES
~NET
IAAcl
IU
s
1:t
DI
~
'i:'A.~I~,.I
READY
IG1 Madefor
@J iPod
",,.~
ID3TAG
•USB Audio for iPod
•SAT Ready via CeNET
•6ch/2V RCA Output with Built-in LPF/HPF
CZ309 3

THIS PRODUCTION COMPLIES WITH DHHS RULES 21 CFR
SUBCHAPTER JAPPLICABLE AT DATE OF MANUFACTURE.
12V e GROUND
AM 530-1710kHz/FM 87.9-107.9MHz
2. PRECAUTIONS
CHANGES OR MODIFICATIONS TO THIS
PRODUCT NOT APPROVED
BY THE
MANUFACTURER
WILL VOID THE
WARRANTY AND
WILL VIOLATE FCC
APPROVAL.
Handling Compact Discs
•Compared to ordinary music CDs, CD-R and
CD-RW discs are both easily affected by high
temperature and humidity and some of CD-R
and CD-RW discs may not be played.
Therefore, do not leave them for along time
in the car.
•Never stick labels on the surface of the
compact disc or mark the surface with a
pencil or pen.
ACAUTION
INFORMATION FOR USERS:
USE OF CONTROLS, ADJUSTMENTS, OR
PERFORMANCE OF PROCEDURES OTHER
THAN THOSE SPECIFIED HEREIN, MAY
RESULT IN HAZARDOUS RADIATION
EXPOSURE.
THE COMPACT DISC PLAYER SHOULD NOT
BE ADJUSTED OR REPAIRED BY ANYONE
EXCEPT PROPERLY QUALIFIED SERVICE
PERSONNEL.
CHANGES OR MODIFICATIONS NOT
EXPRESSLY APPROVED
BY THE
MANUFACTURER FOR COMPLIANCE
COULD VOID THE USER'S AUTHORITY TO
OPERATE THE EQUIPMENT.
I Clarion
MODEL I
MANUFACTURED'
THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES.
OPERATION
IS SUBJECT TO THE FOLLOWING TWO CONDITIONS:
Il) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE, AND
(2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED,
INCLUDING INTERFERENCE THAT MAY CAUSE UNDESIRED
OPERATION.
CLARION CO.,L
TO
7-2, SHINTOSHIN,CHUO-KU,SAITAMA-s,HI,SAITAMA 330-0081,JAPAN
This product includes technology owned by
Microsoft Corporation and cannot be used or distributed
without alicense from MSLGP.
This equipment has been tested and found to
comply with the limits for aClass Bdigital
device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable
protection against harmful interference in a
residential installation.
This equipment generates, uses, and can
radiate radio frequency energy and, if not
installed and used
in accordance with the
instructions, may cause harmful interference to
radio communications. However, there is no
guarantee that interference will not occur
in a
particular installation.
If this equipment does cause harmful
interference to radio or television reception,
which can be determined by turning the
equipment off and on, the user is encouraged to
consult the dealer or an experienced radiolTV
technician for help.
SERIAL No.
PE-~
276-c::::J
Clarion Co., Ltd.
MADE IN c=::J
DisplayScreen
In extreme cold, the screen movement may slow
down and the screen may darken, but this is
normal.
The screen will recover when it returns to
normal temperature.
CJ
Bottom View of Source Unit
4CZ309

3. CONTROLS
i
Names of the Buttons and Their Main Functions
--:+--+-[USB SLOT]
~;---;- [SOUND]
-;.:--:- [AUX]
[~] (EJECT)~-:-:-~
[RELEASE] button
•Press the [RELEASE] button to unlock the DCP.
[rr-:~] button
•Perform preset scan and auto store while in
the radio mode.
•Play or pause atrack while
in the CD/MP31
WMAJAAC mode.
[.] (UP), [T] (ON) buttons
•Select the folder while in the MP3IWMAIAAC
mode.
[IR RECEIVER]
•Receiver for remote control unit. (Operating
range: 30° in all directions)
[CD SLOT]
•CD insertion slot.
[USB SLOT]
•USB memory/MTP/iPod devices insertion slot.
[SOUND] button
•Use the button to switch to the sound adjust
mode.
[AUX] input jack
•The input jack for connecting an external
device.
[DIRECT] buttons
•Store astation into memory or recall it directly
while in the radio mode.
[ROM] button
•Perform random play while in the CD/MP31
WMAlAAC mode.
[RPT] button
•Perform repeat play while in the CD/MP31
WMAlAAC mode.
[SCN] button
•Perform scan play while in the CD/MP31
WMAlAAC mode.
[ISR] button
• RecalliSR radio station in memory.
•Press and hold the button for 2seconds or
longer: Store current station into ISR memory
(radio mode only).
[DISP] button
•Switch the display indication.
[ROTARY] knob
•Adjust the volume by turning the knob
clockwise
or counterclockwise.
[BND] button
•Switch the band, or seek tuning or manual
tuning while in the radio mode.
•
Playa first track while in the CD/MP3IWMAI
AAC mode.
[SRC] button
•Turn on or off the power.
•Switch the operation mode among the radio
mode, etc.
[~], [~] buttons
•Enter the fast-forward or fast-backward mode.
[~] (EJECT) button
•Eject adisc when it is loaded into the unit.
CZ309 5

DCP Rear Panel
Note:
• If the DCP is dirty, wipe off the dirt with asoft, dry
cloth only.
DCP
connector
•The DCP can easily be damaged by
shocks. After removing it, be careful not to
drop it or subject it to strong shocks.
•When the Release button is pressed and
the
DCP is unlocked, the car's vibrations
may cause
it to fall. To prevent damage to
the DCP, always store it in its case after
detaching it.
•The connector connecting the main unit
and the DCP is an extremely important
part. Be careful
not to damage it by
pressing on it with fingernails, pens,
screwdrivers, etc.
Storing the DCP in the DCP Case
Hold the OCP, in the orientation as shown in the
figure below, and put it into the supplied OCP
case. (Ensure the DCP is
in the correct
orientation.)
Attaching the DCP
1. Insert the right side of the OCP into the main
unit.
2. Insert the left side of the OCP into the main
unit.
4. DCP (DETACHABLE CONTROL PANEL)
* The OCP is unlocked
3. Remove the OCP.
Removing the DCP
1. Press the [SRC] button for 1second or
longer to switch off the power.
2. Press in the [RELEASE] button.
[RELEASE] button
The control panel can be detached to prevent
theft. When detaching the control panel, store it
in the OCP (DETACHABLE CONTROL PANEL)
case to prevent scratches.
We recommend taking the OCP with you when
leaving the car.
6 CZ309

5. REMDTE CONTROL
Functions of Remote Control Unit Buttons
* Some buttons on the remote control unit have different functions from the corresponding buttons on the main
unit.
[A],[']
;- Signal transmitter
[SRCl_--4-~:O=SR=C ===a=No==l (BND]
II~- ~(.1I1
II
[~l,[~l
II':'':'=~~ ,
[MUTE] -----+;II-€?R@II[DISP]
[ISR]~J II 8Q~G [ROM]
seN RPT ROM II
I"S/,I,S TVlYl. [RPT]
[SCN]
Clarion
•Shared modes
[SRC] button
•Press the button to turn on the power.
Press and hold the button for 1second or
longer to turn off the power.
•Use to alternate operation mode among the
various modes.
t"], [~] buttons
•Increases and decreases volume.
[MUTE] button
•Turns mute function on and off.
[ISR] button
•Recalls ISR radio station stored in memory.
•Press and hold the button for 2seconds or
longer to store current station in ISR memory
(radio mode only).
[DISP] button
•Press to select the desired display.
•Radio/Satellite Radio modes
[BND] button
•Switches reception band.
[~], [~] buttons
•Moves preset channels up and down.
[SCN] button
•Press to perform preset scan.
•Press and hold the button for 2seconds or
longer to perform auto store.
•
In the Satellite Radio mode, press once to
perform category scan; hold depressed for 1
second
or longer to perform preset scan.
•CD/MP3/WMA/AAC and USB/MTP
modes
[BND] button
•Press to play the first track.
[~], [~] buttons
•Press to move the tracks up and down.
•Press and hold the button for 1second or
longer to perform fast-forward/fast-backward
(Except DRM file).
[~II] button
•Switches between playback and pause.
[SCN] button
•Press to perform scan play.
•When
in MP3IWMAlAAC and USB/MTP
modes, press and hold the button for 1
second or longer to perform folder scan play.
[RPT] button
•Press to perform repeat play.
•When
in MP3IWMAlAAC and USB/MTP
modes, press and hold the button for 1
second
or longer to perform folder repeat
play.
[ROM] button
•Press to perform random play.
•When
in MP3IWMAlAAC and USB/MTP
modes, press and hold the button for 1
second or longer to perform folder random
play.
CZ309 7

Functions of Remote Control Unit
Buttons
•CD changerlDVD changer modes
[BNO] button
•Press to switch to next disc in ascending order.
[~], [~] buttons
•Press to move the tracks up and down.
•Press and hold the button for 1second or
longer to perform fast-forward/fast-backward.
[~II] button
•Switches between playback and pause.
[SCN] button
•Press to perform scan play.
•Press and hold the button for 1second or
longer to perform disc scan play.
[RPn button
•Press to perform repeat play.
•Press and hold the button for 1second or
longer to perform disc repeat play.
[ROM] button
•Press to perform random play.
•Press and hold the button for 1second or
longer to perform disc random play.
•iPod mode
[~], [~] buttons
•Press to move the tracks up and down.
•Press and hold the button for 1second or
longer to perform fast-forward/fast-backward.
[~II] button
•Switches between playback and pause.
[RPT] button
•Press to perform repeat play.
[ROM] button
•Press to perform random play.
•Press and hold the button for 1second or
longer to perform all random play.
• TV mode
[BNO] button
•Switches reception band.
[~], [~] buttons
•Moves preset channels up and down.
[SCN] button
•Press to perform preset scan.
•Press and hold the button for 2seconds or
longer to perform auto store.
[ROM] button
•Press to alternate between TV and VTR.
8CZ309
Inserting the Battery
CD Turn over the remote control unit and slide
the cover
in the direction indicated by the
arrow in the illustration.
®Insert the battery (CR2025) into the insertion
guides, with the printed side (+) facing
upwards.
®Pressthe battery in the direction indicated by
the arrow so that it slides into the
compartment.
@Replace the cover and slide in until it clicks
into place.
Insertion guide
Notes:
Misuse may result in rupture of the battery,
producing leakage
of fluid and resulting in
personal injury or damage to surrounding
materials. Always follow these safety precautions:
•
Use only the designated battery.
•
When replacing the battery, insert properly, with
+/- polarities oriented correctly.
•Do not subject battery
to heat, or dispose of in
fire or water. Do not attempt to disassemble the
battery.
•Dispose
of used batteries properly.

6. OPERATIONS
Note:
•Be sure
to read this chapter referring to the front diagrams of chapter "3. CONTROLS" on page 5.
Basic Operations
Be sure to lower the volume before
switching off the unit power or the ignition
key. The unit remembers its last volume
setting.
Turning on/off the power
1. Press the [SRC] button to turn on the power.
2. Press and hold the [SRC] button for 1
second
or longer to turn off the power for the
unit.
Note:
•System check
The first time this unit is turned on after the wire
connections are completed, it must be checked
what equipmentis connected.
When the power
is turned on, the "S-CHECK" appears in the
display, then the unit returns
to the clock display
mode.
The system check starts within the unit.
Then press the {SRCj button again, the unit turn
to the radio mode.
Selecting a mode
1. Press the [SRC] button to change the
operation mode.
2. Each time you press the [SRC] button, the
operation mode changes in the following
order:
Radio
~ (Satellite radio) ~ CD/MP3IWMAI
AAC
~ USS/MTP/iPod ~ (CD changer) ...
(DVD changer) ~ (TV) ~ AUX ~ Radio .
*External equipment not connected with
CeNET
is not displayed.
*iPod/MTP can connect to this unit via USB
SLOT.
Adjusting the volume
1. Turning the [ROTARY] knob clockwise
increases the volume; turning it
counterclockwise decreases the volume.
*The volume level is from 0(minimum) to 33
(maximum).
Switching the display
Press the [DISP] button to select the desired
display.
Sound Adjustment
You can adjust asound effect or tone quality to
your preference.
To change sound setting
1. Press the [SOUND] button to switch to the
sound adjustment selection display.
*The factory default sound setting is "Z-
EHCR".
2. Then press the [~] or [~] button to
select the sound adjustment mode.
Each time you press the
[~] or [~]
button, the sound adjustment mode
changes as following order:
"Z-EHCR"
~ "BASS" ~ ''TREBLE'' ~
"BALANCE" ~ "FADER" ~ "S-W LPF' ~
"S-W VOL" ~ "HPF'
* In the case of display blinking "ENT', you
can press the [~~~] button to adjust the
setting value.
*The sound adjustment mode will be
displayed for 2seconds before showing the
sound setting.
3. Press the L ... ]or [T] button to adjust the
selected audio mode.
4. After completing settings, press the
[SOUND] button to return to the previous
mode.
•Setting the Z-Enhancer Plus
This unit is provided with 4types of sound tone
effects stored in memory.
Select the one you prefer.
*The factory default setting is "OFF'.
2-1. Select "Z-EHCR".
CZ309 9

Basic Operations
3-1. Each time you press the [A.] or [T] button,
the tone effect changes
in the following
order:
"Z+FLAT"
+-+ "CUSTOM" +-+ "EXCITE" +-+
"IMPACT" +-+ "B-BOOST" +-+ "OFF"
Z+FLAT : userZ+FLAT
CUSTOM :user custom
EXCITE :bass and treble emphasized
mid emphasized
IMPACT :bass and treble emphasized
B-BOOST :bass emphasized
OFF :no sound effect
When "Z+FLAT" is set:
3-2. Press and hold the [~J~] button for 1second
or longer, bass/treble characteristics
become flat and switch to the
"CUSTOM"
mode.
When "CUSTOM" is set:
3-1. Press the [~] or [~] button to select the
"BASS"
or "TREBLE" mode to adjust.
When "EXCITElIMPACT/B-BOOST" is set:
3-2. Press the [~J~] button.
3-3. Press the
[A.] or [T] button to adjust the
setting
in the range of -3 to +3.
*The factory default setting is "0".
3-4. Press the [~J~ ]button to return to the
previous mode.
• Adjusting the bass
This adjustment can be performed only when
the Z-Enhancer Plus is set to "CUSTOM
".
2-1. Select "BASS".
3-1. Press the
[A.] or [T] button to select as
following order.
"BASS<G>"
+-+ "BASS<F>" +-+ "BASS<Q>"
*The factory default setting is "BASS<G>".
3-2. Press the
[~J~] button.
3-3. Press the
[A.] or [T] button to adjust the
gain, the F(center frequency) and the
Q.
BASS<G>
:The factory default setting is "0".
(Adjustment range: +7 to
-7)
BASS<F>
:The factory default setting is "60".
(Adjustment range: 60/80/100/200)
BASS<Q>
:The factory default setting is "1".
(Adjustment range: 1/1.25/1.5/2)
10 CZ309
3-4. Press the [~J~ ]button to return to the
previous mode.
• Adjusting the treble
This adjustment can be performed only when
the Z-Enhancer Plus is set to "CUSTOM
It.
2-1. Select 'TREBLE".
3-1. Press the
[A.] or [T] button to select as
following order.
"TREB<G>"
+-+ "TREB<F>"
*The factory default setting is "TREB<G>".
3-2. Press the
[~r-:~ ]button.
3-3. Press the [A.] or [T] button to adjust the
gain, the F(center frequency) and the
Q.
TREB<G>:The factory default setting is "0".
(Adjustment range: +7 to
-7)
TREB<F>: The factory default setting is
"10k".
(Adjustment range:
10k/12.5k/15k/17.5k)
3-4. Press the
[~r-:~] button to return to the
previous mode.
• Adjusting the balance
2-1. Select "BALANCE".
3-1. Press the [A.] or [T] button to adjust the
balance of the right and left speakers.
*The factory default setting is "CENTER"
(center). (Adjustment range: RIGHT12
to
LEFT12 (right 12 to left 12))
• Adjusting the fader
2-1. Select "FADER".
3-1. Press the
[A.] or [T] button to adjust the
balance of the rear and front speakers.
*The factory default setting is "CENTER"
(center). (Adjustment range: FRONT12
to
REAR12 (front 12 to rear 12))
•Setting the subwoofer
You can set the low pass filter of subwoofer.
2-1. Select "S-W LPF".
3-1. Each time press the [A.] or [T] button to
select the setting, the setting changes
in
the following order:
"THROUGH" +-+ "LPF 50" +-+ "LPF 80" +-+
"LPF 120"
*The factory default setting is "THROUGH".

Basic Operations
• Adjusting the subwoofer output
volume
You can adjust the volume output from the unit's
subwoofer output terminal.
This adjustment can be performed only when
the "S-W LPF" is set to
"LPF 120", "LPF 80" or
"LPF 50".
2-1. Select "S-W VOL".
3-1. Press the
LA] or [T] button to increases
or decreases the subwoofer volume.
*The factory default setting is "0".
(Adjustment range: +6
to --6)
*When the volume level is more than 30, the
subwoofer volume adjustment value can not
reach
+6 .
• Adjusting the high pass filter
2-1. Select "HPF'.
3-1. Each time you press the [.] or [T] button
to select the setting.
The setting changes in the following order:
"120" B''THROUGH''
*The factory default setting is "THROUGH"
(through).
*This is supported only with amplifiers
equipped with this function. Output
is not
supported from RCA cables.
Note:
•During SOUND adjustmentmode,
if no operation
is performed for more than 10seconds, this
mode can be cancelled
and return to previous
mode.
Setting the MAGNA BASS EXTEND
The MAGNA BASS EXTEND does not adjust
the low frequencies like the normal sound
adjustment function, but emphasizes the deep
bass frequencies to provide you with adynamic
sound.
*The factory default setting is "OFF' (off).
1.. Press and hold the [SOUND] button for 1
second
or longer to turn on the MAGNA
BASS EXTEND effect. "M-B EX" appears in
the display for 2seconds.
2. Press and hold the [SOUND] button for 1
second
or longer to turn off the MAGNA
BASS EXTEND effect.
Radio Operations
Listening to the radio
1. Press the [SRC] button and select the radio
mode.
2. Press the [BND] button and select the radio
band. Each time the button is pressed, the
radio reception band changes in the
following order:
F1 (FM1) ~ F2 (FM2) ~ F3 (FM3) ~ AM ~
F1 (FM1)...
Tuning
There are 3types of tuning mode available,
seek tuning, manual tuning and preset tuning.
Seek tuning
1. Press the [BND] button and select the
desired band (FM
or AM).
*If "MANU" is lit in the display, press and hold
the [BND] button for 1second or longer.
"MANU"
in the display goes off and seek
tuning is now available.
2. Press the [~] or [~] button to
automatically seek astation.
Manual tuning
There are 2ways available: Quick tuning and
step tuning.
• Quick tuning
Press and hold the [~] or [~] button for 1
second
or longer to tune in astation.
• Step tuning
Press the [~] or [~] button to manually tune
in astation.
Recalling apreset station
Atotal of 24 preset positions (6-FM1, 6-FM2, 6-
FM3, 6-AM) exists to store individual radio
stations
in memory. Press the corresponding
[DIRECT] button
or the [.] / [T] button to
recall the stored radio frequency automatically.
Manual memory
1. Select the desired station with seek tuning or
manual tuning.
CZ309 11

Radio Operations
2. Press and hold one of the [DIRECT] buttons
for 2seconds or longer to store the current
station into preset memory.
Auto store
Auto store is afunction for storing up to 6
stations that are automatically tuned
in
sequentially. If 6receivable stations cannot be
received, apreviously stored station remains
unoverwritten at the memory position.
1. Press the [BND] button and select the
desired band (FM or AM).
2. Press and hold the [r~~] button for 2seconds
or longer. The stations with good reception
are stored automatically to the preset
channels.
Preset scan
Preset scan receives the stations stored in
preset memory in order. This function is useful
when searching for adesired station
in memory.
1. Press the [r~~] button.
2. When adesired station is tuned in, press the
[r~~] button again to continue receiving that
station.
Note:
• Be careful not to press and hold the {r~~ Jbutton
for 2seconds or longer, otherwise the auto store
function is engaged and the unit starts storing
stations.
Instant station recall (lSR)
Instant station recall is aspecial radio preset
that instantly accesses afavorite radio station at
atouch of abutton. The ISR function even
operates with the unit in other modes.
.ISR memory
1. Select the station that you wish to store in
ISR memory.
2. Press and hold the [ISR] button for 2
seconds or longer.
•Recalling astation with ISR
In any mode, press the [ISR] button to turn on
the radio function and tune the selected radio
station. "ISR" appears in the display. Press the
[ISR] button again to return to the previous
mode.
12 CZ309
CDIMP31WMAIAAC
Operations
MP31WMAIAAC
This unit can play back MP3IWMAJAAC files.
Notes:
•Ifyou playa file with DRM (Digital Rights
Management) for WMA remaining ON, no audio
is output (The WMA indicator blinks).
•Windows Media TM, and the Windows ®logo are
trademarks, or registered trademarks of
Microsoft Corporation in the United States and/or
other countries.
•To disable DRM (Digital Rights
Management)
1. When using Windows Media Player 9/10/11 ,
click on TOOL
~ OPTIONS ~ MUSIC
RECORD tab, then under Recording
settings, unclick the Check box for RECORD
PROTECTED MUSIC. Then, reconstruct
files.
Personally constructed WMA files are used
at your own responsibility.
Precautions when creating MP31
WMAlAAC file
•Usable sampling rates and bit rates
1. MP3: Sampling rate 8kHz-48 kHz,
Bit rate 8kbps-320 kbps /VBR
2. WMA: Bit rate 8kbps-320 kbps
3. AAC: Sampling rate 8kHz-48 kHz,
Bit rate 8kbps-320 kbps /VBR
•File extensions
1. Always add afile extension ".MP3", ".WMA"
or ".M4A" to MP3, WMA or AAC file by using
single byte letters. If you add afile extension
other than specified or forget to add the file
extension, the file cannot be played.
2. Files without MP3IWMAJAAC data will not
play. The indication "NO FILE" appears
in
the play time display if you attempt to play
files without MP3IWMAJAAC data.
* When VBR files are played, the play time display
may differ the play location.
*When MP3IWMAlAAC files are played, alittle no
sound part is caused between tunes.

CDIMP31WMAIAAC Operations
•Logical format (File system)
1. When writing MP3IWMAlAAC file on aCD-R
disc or CD-RW disc, please select "IS09660
level 1, 2 orJOLIET or Romeo" or APPLE
ISO as the writing software format. Normal
play may not be possible if the disc
is
recorded on another format.
2. The folder name and file name can be
displayed as the title during MP3IWMAlAAC
play but the title must be within 64 single
byte alphabetical letters and numerals
(including an extension).
3. Do not affix aname to afile inside afolder
having the same name.
•Folder structure
1. Adisc with afolder having more than 8
hierarchical levels will be impossible.
•Number of files or folders
1. Up to 255 files can be recognized per folder.
Up to 510 files can be played.
2. Tracks are played in the orderthat they were
recorded onto adisc. (Tracks might not
always
be played in the order displayed on
the PC.)
3. Some noise may occur depending on the
type of encoder software used while
recording.
Set the type of file to be played
(multi-session
function)
When asingle disc holds both normal CD type
tracks and MP3IWMAlAAC type tracks, use this
command to select which type of track to play.
*Default setting is "M-SESS CD".
•When only one type of track (either music CD
or MP3IWMAlAAC) is recorded on adisc,
selecting eithertype will allow playback of the
disc.
•When playing CCCD (copy-control CDs), set
to CD type.
1. Press and hold the [BND] button for 1
second or longer.
Each time the button
is held pressed in this
way, "M-SESS" will be displayed for 1
second, then "CD" or "MP3" appears
in the
display, the playback type alternates
between CD type and MP3IWMAlAAC type.
•"M-SESS CD"
When playing music CD only.
•"M-SESS MP3"
When playing music MP3IWMAlAAC only.
2. When setting is completed, remove the disc
and reinsert it.
Disc-In-Play function
As long as the ignition key is turned to the ON or
ACC position, this function allows you to turn the
power to the unit and start playing the disc
automatically when the disc
is inserted even if
the power
is not turned on.
ACAUTION
•Do not try to put your hand or fingers in
the disc insertion slot. Also never insert
foreign objects into the slot.
•Do
not insert discs where adhesive comes
out from cellophane tape or arental CD
label,
or discs with marks where
cellophane tape
or rental CD labels were
removed.
It may be impossible to extract
these discs from the unit and they may
cause
the unit to break down.
Backup Eject function
Just pressing the [~] button, ejects the disc
even if the power to the unit was not turned on.
1. Press the [~] button to eject the CD. Take it
out from the ejected position. "EJECT'
appears in the display.
Notes:
•IfaCD (12 cm) is left in the ejected position for
15 seconds, the CD is automatically reloaded
(Auto reload).
•Ifyou force aCD into before auto reloading, this
can damage the
CD.
CZ309 13
