Service Manual
Model
NISSANAutomobileGenuine
FM/AMRadio
With In-dash 6CD Changer
160W Stereo
PN-2714B-B
(Genuine No. 28185 EH10A)
theoriginalservicemanual.
DIFFERENCEFROMORIGINAL
This unit supports the 16-figure display of Satellite radio.
IC402 Audio CPU different.
Parts that have been described to this manual have changed
for the performance improvement.
MODEL
COMPONENTS
PN-2714B-B
1. Mainunit ----------- 1
2. Lock pin 966-0653-21 1
CAUTIONS
Use of controls,adjustment,or performance of procedures
other than those specified herein,may result in hazardous ra-
diationexposure.
Thecompact disc playershould not be adjustedor repaired by
anyone except properly qualified service personnel.
Thi s pr oduct i ncl udes t ec hnol ogy owned by Micr osof t Cor por at i on and
cannot be used or di st r i but ed wit hout a l i cense f r om MSLGP.
PA RT No .
THI S DEVI CE COMPL I ES WI T H PART 1 5 OF T HE F CC RUL ES. OPE
RATION IS SUBJECT TO THE FOLLOWING TWO CONDITIONS:(1)
T HI S DEV I CE MAY NOT CAUS E HA RMF UL I NT ERF ERENCE , AND( 2 )
THI S DEVI CE MUST ACCEPT ANY I NTERFERENCE RECEI VED, I NCL
UDI NG
Junda I ndust r i al Zone, Dong Keng I ndust r i al Road, Dong Keng Town Dongguan,
Guangdong Pr ovi nce 511734, The Peopl e' s Republ i c of Chi na
Dongguan Clarion Orient Electronics Co.,Ltd.
I NTERFERENCE THAT MAY CAUSE UNDESI RED OPERATI ON.
THI S PRODUCTI ON COMPLI ES WI T H DHHS RULES 21 CFR SUBCHAPTER J
APPL I CABL E AT DATE OF MANUFACTURE.
MADE IN CHINA
MANUF ACTURED
Top view of the unit Setplate
ORIGINALSERVICEMANUAL
This additional service manual is designed to be used
togetherwith Model PN-2714B-A
This manual has described only the difference point with
Originalmodel Manual No.
PN-2714B-A 298-6224-00
Look pin
NOTE
* IncasethatthemainunitortheCD
changermechanismistransported
for repair, the lock pin(966-0653-
21) must be set to fix the mecha-
nism assy.
* Wecannot supply PWBwith com-
ponent parts in principle. When a
circuit on PWB has failure, please
repair it by component parts base. Parts which are not
mentionedin service manual are not supplied.
* Thisproduct includes technology owned by Microsoft Cor-
poration and cannot be used or distributed without a li-
censefromMSLGP.
* Specifications and design are subject to change without
notice for further improvement.

PN-2714B-B -2-
EXPLANATIONOFIC
052-3188-83 M30853FHGP Audio CPU
Terminal Description
pin 1: CTRST : O : Contrast adjustment analogue output(DA).
pin 2: SPEED :IN: Speed Pulse input.
pin 3: EEP/ST DA :I/O:The serial data input/output for EEP and
Sub-tuner.
pin 4: EEP/ST CK : O : The serial clock output for EEP and Sub-
tuner.
pin 5: BU DET :IN: Backup detection signal input.
pin 6: GND : - : Ground.
pin 7: CN VSS :IN: Connect to VSS.
pin 8: ILL ON :IN: Illumination ON signal input.
pin 9: SYS ON : O : System ON signal output.
pin 10: RESET : IN: Reset signal input.
pin 11: X out : O : Crystal connection.
pin 12: VSS : - : Negative voltage supply.
pin 13: X IN :IN: Crystal connection.
pin 14: VDD : - : Positive voltage supply.
pin 15: NMI :IN: Connect to VDD.
pin 16: ACC IN :IN: ACC ON flag input.
pin 17: NC : O : Not in use.
pin 18: NC : O : Not in use.
pin 19: TB :IN: Time base input.
pin 20: NC : O : Not in use.
pin 21: M CAN RX :IN: M-CAN serial data input.
pin 22: M CAN TX : O : M-CAN serial data output.
pin 23: Power IC Stndb : O : The standby signal output to Power IC.
pin 24: BEEP/BUZ : O : BEEP out or the buz control.
pin 25: AMP ON : O : AMP ON signal output.
pin 26: DIMMER : O : PWM output.
pin 27: EEP/MT CK : O : The clock pulse output to EEP/Main-tuner.
pin 28: EEP/MT DA : O : The serial data output to EEP/Main-tuner.
pin 29: NDS TX : O : The serial data output for NDS.
pin 30: NDS RX :IN: The serial data input for NDS.
pin 31: NDS REQ 1 :IN: NDS request signal input.
pin 32: NDS CONT : O : NDS/Automatic-changer select.
pin 33: 1&6-CD TX : O : The serial data output for 1-CD & 6-CD-
Changer.
pin 34: 6-CD RX / CK :I/O:The serial data input for 6-CD-Changer. Or
clock pulse output for 1-CD.
pin 35: NDS REQ 2 :IN: NDS request signal input.
pin 36: NDS S-CHG : O : N-BUS audio signal select command out-
put.
pin 37: NC : O : Not in use.
pin 38: NC : O : Not in use.
pin 39: WRITE ONLY : - : WRITE ONLY.
pin 40: NC : O : Not in use.
pin 41: NC : O : Not in use.
pin 42: NC : O : Not in use.
pin 43: 1-CD RX :IN: The serial data input from 1-CD.
pin 44: 1&6-CD REQ :IN: The request signal input from 1-CD & 6-
CD-Changer.
pin 45: 1-CD CS : O : The chip select signal output.
pin 46: 1-CD WUP : O : The wakeup signal output.
pin 47: 1-CD RESET : O : The reset signal output.
pin 48: CD ON : O : CD ON signal output.
pin 49: Power IC Diag :IN: Power IC Diagnosis signal input.
pin 50: LCD ON : O: LCD ON signal output.
pin 51: KEY/LCD DO : O : Serial data output for KEY IC or LCD IC.
pin 52: KEY/LCD CLK : O : Clock output for KEY IC or LCD IC.
pin 53: KEY/LCD DI :IN: Serial data input for KEY IC or LCD IC.
pin 54: KEY/LCD CE : O : Chip Enable output for KEY IC or LCD IC.
pin 55: KEY/LCD S/R : O : KEY IC Standby output / LCD IC Reset
output.
pin 56: VOL-2 :IN: The volume pulse input.
pin 57: VOL-1 :IN: The volume pulse input.
pin 58: NC : O : Not in use.
pin 59: NC : O : Not in use.
pin 60: VDD : - : Positive voltage supply.
pin 61: POWER-ON : - : POWER-KEY.
pin 62: GND : - : Ground
pin 63: RTLY-VOL2/TH :IN: Rotary volume pulse input / temperature.
pin 64: RTLY-VOL1 :IN: Rotary volume pulse input.
pin 65: MD WP : O : MD wakeup, H = WAKE-UP, L = SLEEP.
pin 66: MD XCS : O : MD chip select , H = CS ON.
pin 67: MD XSCK : O : MD clock.
pin 68: CPU-MD : O : The serial data output to MD.
pin 69: MD RESET : O : L = RESET ON.
pin 70: MD XSRQ :IN: MD request.
pin 71: NC : O : Not in use.
pin 72: MD DI :IN: The serial data input from MD.
pin 73: MD LD/RDS CK:IN: MD loading start signal input, DISC load-
ing beginning of L. And RDS clock in-
put.
pin 74: MD ON/RDS DI : O : MD power supply control, H = Power ON.
pin 75: NC : O : Not in use. And RDS data input.
pin 76: ST/SD/TWEET :I/O:At AM station receiving, this port outputs
"L" by AM 900kHz receiving. At FM sta-
tion receiving, this port detects the ste-
reo signal. And at seeking or scanning,
this port detects the SD signal.
pin 77: DSP INT :IN: The interrupt command input from the
DSP IC.
pin 78: DSP RESET : O : Reset signal output to the DSP IC.
pin 79: S METER :IN: The input terminal of internal A/D convert-
er to monitor the radio field strength.
pin 80: PLL DI :IN: Serial data input from the PLL IC.
pin 81: VFM PLL CE : O : The chip enable signal output to the PLL
IC.
pin 82: VFM PLL DO : O : Serial data output to the PLL IC.
pin 83: VFM PLL CK : O : The clock pulse output to the PLL.
pin 84: VFM PLL DI :IN: Serial data input from the PLL IC.
pin 85: VFM SD :IN: Station detection signal input.
pin 86: VFM S METER :IN: The input terminal of internal A/D convert-
er to monitor the radio field strength.
pin 87: MD EJ/6-CD LD:IN: MD eject signal input. And 6-CD-Changer
loading start signal input.
pin 88: CD EJECT :IN: CD eject signal input.
pin 89: PLL CK :IN: PLL clock input.
pin 90: PLL DO : O : Serial data output to the PLL IC.
pin 91: PLL CE : O : The chip enable signal output to the PLL
IC.
pin 92: N REMO B :IN: The input terminal of internal ADC for N-
remote-controller signal.
pin 93: N REMO A :IN: The input terminal of internal ADC for N-
remote-controller signal.
pin 94: A GND : - : Analog ground.
pin 95: NC : O : Not in use.
pin 96: Vref : - : Reference voltage.
pin 97: A VCC : - :Positive voltage supply for the internal
analog section.
pin 98: DSP/PIC/RDS C:IN: The clock pulse input.
pin 99: DSP/PIC/RDS D:IN: The serial data input.
pin100: ANT ON : O : Antenna ON command output.
