Clarke Image 26B User manual

Form No. 70249B 5/06 Clarke®Printed in the U.S.A.
READ THIS BOOK
This book has important information for the use and safe operation of this machine. Failure to read this
book prior to operating or attempting any service or maintenance procedure to your Clarke machine
couldresultininjurytoyouortootherpersonnel;damagetothemachineortootherpropertycouldoccur
aswell. Youmusthavetrainingintheoperationofthismachinebeforeusingit. If youroperator(s)cannot
read English, have this manual explained fully before attempting to operate this machine.
Si Ud. o sus operadores no pueden leer el Inglés, se hagan explicar este manual completamente antes
de tratar el manejo o servicio de esta máquina.
All directions given in this book are as seen from the operator’s position at the rear of the machine.
For new books write to: Clarke®, 2100 Highway 265, Springdale, Arkansas 72764.
Operator's
Manual
26B
®

Page -2- Clarke®Operator's Manual IMAGE 26B
CONTENTSOFTHISBOOK
OperatorSafetyInstructions .................................................................................. 3
IntroductionandMachineSpecifications..................................................................5
TransportingtheMachine ........................................................................................6
MachineControls ....................................................................................................7
HowtoPreparetheMachineforOperation ..............................................................10
MachineOperatingInstructions ...............................................................................14
MaintenanceInstructions ........................................................................................17
SECTIONII PARTS ANDSERVICE
How to Correct Problems in the Machine.................................................................20
RecoveryTankandHoseAssembly ........................................................................21
HandleAssembly ....................................................................................................22
RearPanelAssembly..............................................................................................23
SolutionTankAssembly..........................................................................................24
SolutionDeliverySystem ........................................................................................25
FrameAssembly.....................................................................................................26
BatteryTray ............................................................................................................27
RecoveryToolAssembly .........................................................................................28
Brush Assembly......................................................................................................29
Transaxle Parts List ................................................................................................30
Vac Motor Assembly...............................................................................................31
BatteryCharger(40506A,40507A,40505A) ............................................................32
BatteryCharger(40512B,40506B) ..........................................................................33
AvailableAccessories .............................................................................................34
Wiring Schematic....................................................................................................35
ConnectionDiagram ................................................................................................36
FlowDiagram ..........................................................................................................37

Clarke®Operator's Manual IMAGE 26B Page -3-
OPERATOR SAFETY INSTRUCTIONS
WARNING AVERTISSEMENT ADVERTENCIA
DANGER: Failure to read and observe all DANGER statements could result in
severe bodily injury or death. Read and observe all DANGER
statements found in your Owner's Manual and on your machine.
WARNING: Failure to read and observe all WARNING statements could result
in injury to you or to other personnel; property damage could
occur as well. Read and observe all WARNING statements found in
your Owner's Manual and on your machine.
CAUTION: Failure to read and observe all CAUTION statements could result in
damage to the machine or to other property. Read and observe all
CAUTION statements found in our Owner's Manual and on your
machine.
DANGER: Failureto readthe Owner'sManual priorto operatingor attemptingany serviceor
maintenance procedure to your Clarke machine could result in injury to you or to
other personnel; damage to the machine or to other property could occur as well.
You must have training in the operation of this machine before using it. If your
operator(s)cannotreadEnglish,havethismanualexplainedfullybeforeattempting
to operate this machine.
DANGER: Operating a machine that is not completely or fully assembled could result in injury
or property damage. Do not operate this machine until it is completely assembled.
Inspectthemachinecarefullybeforeoperation.
DANGER: Machinescancauseanexplosionwhenoperatednearflammablematerialsand
vapors. Do not use this machine with or near fuels, grain dust, solvents, thinners,
orotherflammablematerials.This machine is not suitable forpickinguphazardous
dust.
DANGER: Lead acid batteries generate gases which can cause an explosion. Keep sparks
and flames away from batteries. Do not smoke around the machine. Charge the
batteries only in an area with good ventilation. Make sure that the AC charger plug
isunplugged fromthewallreceptaclebeforeconnectingordisconnectingtheDC
plug to or from the battery pack.
DANGER: Workingwithbatteriescanbe dangerous! Always wear eye protection and
protectiveclothingwhen workingnearbatteries. Removealljewelry. Do notput
tools or other metal objects across the battery terminals, or the tops of the
batteries.
DANGER: Using a charger with a damaged power cord could result in an electrocution. Do
not use the charger if the power cord is damaged.
WARNING: Operating this machine from anywhere other than the back of the machine could result in
injury or damage. Operate this machine only from the rear.
WARNING: This machine is heavy. Get assistance before attempting to transport or move it. Use
two able persons to move the machine on a ramp or incline. Always move slowly. Do
not turn the machine on a ramp. If operating machine on a gradient over 2%, do not stop,
turnor park. Readthe "ProceduresFor Transporting"in thismanual beforetransporting
asmachinemight toppleoverif notstrapped.
WARNING: Machinescantoppleover if guidedovertheedges of stairsorloadingdocks and cause
injury or damage. Stop and leave this machine only on a level surface. When you stop
the machine, put all switches into their "OFF" position.

Page -4- Clarke®Operator's Manual IMAGE 26B
WARNING: Thismachine isnotequippedwithaparkingbrake. Neverleavethemachineunattended.
Foraddedsafety,alwaysplacea chock in front of andbehindthedrivewheel.
WARNING: Maintenanceandrepairsperformedbyunauthorizedpersonnelcouldresultindamageor
injury. Maintenanceand repairsmust beperformed byauthorized Clarkepersonnelonly.
WARNING: Any alterations or modifications of this machine could result in damage to the machine or
injury to the operator or other bystanders. Alterations or modifications not authorized by
themanufacturervoidsanyandallwarrantiesandliabilities.
WARNING: Electrical components of this machine can "short-out" if exposed to water or moisture.
Keep the electrical components of the machine dry. Wipe the machine down after each
use. For storage, keep the machine in a dry building.
WARNING: Operatingamachinewithoutobservingalllabelsandinstructionalinformationcouldresult
in injury or damage. Read all machine labels before attempting to operate. Make sure all
of the labels and instructional information are attached or fastened to the machine. Get
replacementlabelsanddecalsfromyourClarkedistributor.
WARNING: Wet floor surfaces can be slippery. Water solutions or cleaning materials used with this
type of machine can leave wet areas on the floor surface. These areas can cause a
dangerousconditionforthe operator orotherpersons. Alwaysput "Caution" signs
around/neartheareayouarecleaning.
WARNING: Improperdischargeofwastewatermaydamagetheenvironmentandbeillegal.
TheUnitedStatesEnvironmentalProtectionAgencyhasestablishedcertainregulations
regarding discharge of waste water. Also, city and state regulations regarding this
discharge my be in effect in your area. Understand and follow the regulations in your
area. Beawareoftheenvironment hazards of chemicals that youdispose.
WARNING: Using water that is above 140°F can damage the machine. Do not use water where the
temperatureisabove140°F.
WARNING: Toavoidpersonalinjurytooperatorsor bystanders,donotoperatemachine atfull
traversespeeddown inclines. Machineisheavy and cancausepersonnel injuryand
propertydamage.
CAUTION: Yourmachine warrantywillbevoidedifanythingotherthangenuine Clarkepartsareused
on your machine. Always use Clarke parts for replacement.
CAUTION: Use of this machine to move other objects or to climb on could result in injury or damage.
Do not use this machine as a step or furniture. Do not ride on this machine.
CAUTION: Carpetdamagecanoccur if carpet has notadequatelydriedbefore traffic resumes. Stay
off the carpet until it is dry.

Clarke®Operator's Manual IMAGE 26B Page -5-
Solution Pump 100 psi Adjustable By-pass
Solution Tank 30Gallon
Capacity
Recovery Tank 30Gallon
Capacity
Water Lift 76" Functional WL 150/CFM
Vacuum 2Tangentialdischarge,
three-stage motors
Batteries 3 12V 195AH Batteries
SprayJets QuickChangeNozzles
Brush Size 4" x 23"
Dimensions 48" x 26" x 43"
Weight (w/batteries) 650 lbs.
Shipping Weight 922 lbs.
Dimensions 56" x 28" x 46" (41.7 cu. ft.)
INTRODUCTION AND MACHINE SPECIFICATIONS
TheIMAGE26B isaone-piece,self-propelledcarpetextractordesignedforcleaningcarpet. Themachineapplies
cleaning solution to the carpet and then removes the dirty solution and soil with a recovery tool.
IMAGE 26B, 36V
Features:
Easy to Operate
Interex cleaning system.
Brushpressuregauge.
Variablespeedtransaxle(forwardandreverse)
Adjustablebrushpressure.
Adjustabletraversespeed.
Rugged10-gaugemainframe.
Large capacity, compact size.
Easy access for serviceability.
Large recovery tank opening for easy cleaning.
Smooth10",nonmarking,tread-lessdrivewheels.
Accessory tool connection.
Nofatigue,deadmanswitch mountedoncontrol handle.
Dualtangentialdischargevacmotors
Circuitbreakerprotectionfortraverse,brush,pumpandvacmotors.
Automaticshut-off whenrecoverytankisfull.
Adjustablebypasspump.
Solutionlevelindicator.
Lowvoltagebattery protection (solutionandbrush stop whenlowvoltage conditionoccurs)

Page -6- Clarke®Operator's Manual IMAGE 26B
TRANSPORTING THE MACHINE
How to Put the Machine in a Van or Truck
WARNING: The machine is heavy. Make
sure you use two able persons
to help assist the machine up
the ramp.
1. Make sure the loading ramp is no less than eight
feetlongandstrongenough tosupportthe
machine.
2. Make sure the ramp is clean and dry.
3. Secure the ramp in position.
4. Lift the brush assembly into an upright position.
5. Align the machine on a level surface ten feet in
frontoftheramp.
6. Push the machine to the top of the ramp.
7. Tiedownthemachine.
How to Remove the Machine From A Van
Or Truck
1. Make sure there are no obstructions in the area.
2. Make sure the unloading ramp is no less than
eightfeetlong and strongenoughto supportthe
machine.
3. Make sure the ramp is clean and dry.
4. Secure the ramp in position.
5. Untiethe machine.
WARNING: The machine is heavy. Make
sure you use two able persons to
assist the machine down the
ramp.
6. Assisting the machine down the ramp, position
yourselftomaintainaslowdownwardspeed.

Clarke®Operator's Manual IMAGE 26B Page -7-
Key Switch (See figure 1, A)
The key switch is located on the control panel.
The key switch must be on before any
function of the machine will work. Turn to "O"
forOFFand"I" for ON.
Battery Meter (See figure 1,B)
Thebatterymeterindicatestherelativechargeon
the battery pack. Do not continue to run the
machine when the meter is in "red" area. This will
shorten the life of the battery. NOTE: Low voltage
will shut off solution and brush functions. Recover
remaining solution and return to charge station.
The Traverse Knob (See figure 2, A)
The traverse knob is located on the left side of the
controlpanel. Thetraverseknobcontrolsthespeedof
the machine. For faster speeds, turn the knob to the
right. For slower speeds, turn the knob to the left.
Light bars indicate traverse speed. Twenty feet per
minute is optimum cleaning speed.
The Traverse Meter (See figure 2, B)
The lights on the meter indicate the cleaning range.
Speeds in the 1 to 10 light range indicate cleaning
speeds for various conditions. Speeds above those
indicatedbythetenthlight areusedonlyfortraversing
to dumping, filling or charging locations.
Variable Pump Pressure (See figure 2, C)
The control knob is located on the right side of the
controlpanel.Thecontrolknobcanbeadjustedclock-
wise to increase flow and pressure or counterclock-
wise to decrease flow and pressure. If streaking
occurs increase pressure setting.
WARNING: Do not operate the pump if the
solutiontankisempty. Damageto
the pump could occur.
The Vacuum Switch
Thevacuumswitchisactivatedbytherecoverytoollift
handle. Thevacuummotorsareswitchedonwhenthe
toolislowered. Thevacmotorsareswitchedoffafter
a 10 second delay when the tool is raised.
Accessory Vac Switch (See figure 3,A)
The accessory vac switch is located on the lower left
sideofthe control panel.Thisswitch turns onthevac
motorswhentherecoverytoolisraised. Thisallowsthe
useofaccessorytoolswhenconnectedtotherecovery
hose.
Pump Switch (See figure 3,B)
Thepumpswitchallowsthepumptobeturnedoffwhen
solution application is not required.
Figure 1
Figure 2
Figure 3
THE CONTROLS
A
AC
A
B
B
B

Page -8- Clarke®Operator's Manual IMAGE 26B
The Brush Adjustment Control Knob (See
figure 4, A)
The brush lift control knob is located at the rear of the
machine. The knob is adjustable for many types of
carpet. This setting need not be adjusted between
uses. The settings are retained.
BrushPressureMeter
Thebrushpressuremeterindicatestherelative
amount of pressure the brush is putting on the floor.
To maximize run time on a battery charge, keep the
light bars towards the center of the green area. To
avoiddamagetothebrush motors, do not runthe
machine in the "red" area.
The Recovery Tool Handle (See figure 5, A)
The recovery tool handle is located on the back of
the machine. This handle lowers the recovery tool
andbrush.
Accessory Hose Connector (See figure 6, A)
The accessory hose connector is used to hook-up
optional auxiliary floor tools and to redirect the
solution flow. Use hose coupler (P.N. 30108A) to
connect accessory hose to recovery shoe hose.
THE CONTROLS (cont.)
Figure 4
Figure 5
Figure 6
A
A
A

Clarke®Operator's Manual IMAGE 26B Page -9-
The Traverse Switch (See figure 7, A)
Thetraverseswitchis located onthecontrolhandle.
Lightpressurewiththe thumb or handactivatesthe
traverseforforwardmovement.
The Reverse Switch (See figure 7, B)
The reverse switch is the white button located on top
ofthehandle. Reversetraverseisachievedby
simultaneouslypressingthetraverseandreverse
buttons.
Solution Tank (See figure 8, A)
The solution tank is top center of the machine. The
solution tank fill opening is located in the center of
the tank at the front of the machine.
Solution Tank Drain Hose and Solution Level
Indicator (See figure 8,B)
The solution drain hose is on the lower left at the
back of the machine. To drain, pull the clear hose
free of the top hosebarb and lay the hose into drain.
Reconnectwhenfinished.
.Recovery Tank (See figure 8, C)
Therecoverytank ismountedin therearcenter
position on the machine.
Recovery Tank Drain Hose (See figure 8, D)
Therecoverydrainhose is locatedatthe center
right at the back of the machine.
Battery Tray (See figure 9, A-C))
The battery tray must be pulled out of the machine on
the front bridge in order to change batteries or check
electrolyte. Tolowerbridge, grasphandleand pullup
firmly to insure handle is extended fully (A). Lower
bridge (B). Release lever on left side of battery tray
(C) and pull tray out slowly until latch arm engages in
slot on bridge (D) . To return battery tray to operating
position, release lever and slide tray back into
machineuntil leverengages inframe. Raiseand
latch bridge. Close front.
THE CONTROLS
Figure 7
Figure 8
AA
B
A
B
C
D
Figure 8
A
B
D
C

Page -10- Clarke®Operator's Manual IMAGE 26B
HOW TO PREPARE THE MACHINE FOR
OPERATION
The Image 26B uses three 12-Volt batteries. The
batteries are located on a battery tray that can be
accessed by opening the front cover and lowering the
frontbridge. Toinstallthebatteries,followthisprocedure:
1. Turnkeyswitch off.
2. Make sure both tanks are empty.
3. Placethebatteriesinthebatterytrayasshownin
figure10.
WARNING: Liftingbatterieswithouthelpcould
result in an injury. Get help to lift
the batteries. The batteries are
heavy.
WARNING: Working with batteries can be
dangerous. Always wear eye
protectionandprotectiveclothing
when working near batteries. NO
SMOKING!
4. Connectthebatterycablesbetweenbatteriesand
install long battery cable assembly as indicated.
Seefigure10.
5. Join the connector from the battery pack to the
connectoronthefrontofthemachine.Raiseand
latchfrontbridgeandclosefrontcover. Seefigure
11, A.
NOTE:Chargethebatteriesbeforeusingthemachine.
Battery Maintenance
Theelectricalpowertooperatethemachinecomesfrom
thestoragebatteries. Storagebatteriesneedpreventative
maintenance.
Tomaintainthebatteriesingoodcondition,followthese
instructions:
1. Keep the electrolyte at the correct level. The
correctlevelisbetween1/4"belowthebottomof
the tube in each cell and above the tops of the
plates. Check the level of the electrolyte each
time you charge the batteries. See figure 12.
NOTE: Checkthelevelofelectrolyteprior tocharging
thebatteries. Besuretheplatesineachcell
arecoveredwithelectrolyte. Do not topoff
the cells prior to charging the battery.
Electrolyte expands during charging. As a
result,theelectrolytecouldoverflowformthe
cells. Always top off the cells with distilled
wateraftercharging.
Figure 10
Figure 11
Figure 12
A
Correct fill level

Clarke®Operator's Manual IMAGE 26B Page -11-
HOW TO PREPARE THE MACHINE FOR
OPERATION
CAUTION: Irreversible damage will occur to
the batteries if the electrolyte
level does not cover the plates.
Keep the electrolyte at the
correct level.
CAUTION: Machine damage and discharge
across the tops of the batteries
can occur if the batteries are
filled above the bottom of the
tube in each cell. Do not fill the
batteries up to the bottom of the
tube in each cell. Wipe any acid
from the machine or the tops of
the batteries. Never add acid to
a battery after installation.
CAUTION: Tap water may contain contami-
nants that will damage batteries.
Batteries must be re-filled with
distilled water only.
2. Keep the tops of the batteries clean and dry.
Keep the terminals and connectors clean. To
clean the top of the batteries, use a damp cloth
with a weak solution. To clean the terminals
andconnectors,usea terminal and connector
cleaning tool. Do not allow ammonia or bicar-
bonate of soda to get into batteries.
3. Keepthebatteriescharged.
How to Charge the Batteries
WARNING: Charging the batteries in an area
without adequate ventilation
could result in an explosion. To
prevent an explosion, charge the
batteries only in an area with
good ventilation.
WARNING: Lead acid batteries generate
gases which could explode.
Keep sparks and flames away
from batteries. NO SMOKING!
WARNING: Failure to disconnect the AC
plug from the wall receptacle
before connecting or disconnect-
ing the DC connector on the
charger could result in an
explosion. Always disconnect
the AC plug from the wall recep-
tacle before connecting or
disconnectingtheDCconnector
on the charger.

Page -12- Clarke®Operator's Manual IMAGE 26B
4. Turn the key switch to the "ON" position.
5. Press either of the traverse switches to activate
spray.
6. Allowthesolutiontorunthroughthemachineover
the floor drain until the solution tank is empty.
CAUTION: Cleaning solution in the
machine and tools can leak
onto the carpet and cause
light spots or stains. Do not
leave the extractor or other
cleaning machines or tools
on the carpet when not in
use.
Tochargethebatteries,followthisprocedure:
1. Put the charger on a flat surface. Make sure
the vents on the side are at least two inches
away from walls and other objects. Make sure
there are no objects near the vents on the
bottom of the charger.
2. Make sure the key switch is in the "OFF"
position.
3. Disconnect the battery pack connector from the
control housing connector. See figure 13, A.
4. Connect the DC connector on the charger to the
battery pack connector. See figure 14.
5. Connectthechargertoaproperlygrounded
singlephase(3-wire)wallreceptaclehavingthe
voltage,frequency,andamperecapacity
specifiedonthenameplateofthecharger.
For more instruction on the use of the charger, read
the instruction book supplied with the charger.
DANGER: Failure to read the operator’s
manual before operating this
machine could result in injury to
you or to other personnel,
damage to the machine or to
other property as well.
CAUTION: The antifreeze solution that is
shipped in your machine will
damage carpet. Flush the
antifreeze solution from the
system before using the machine.
Your new machine has been shipped with antifreeze
solution in the machine's system. This antifreeze must
be flushed out prior to using the machine the first time.
Toflushtheantifreezesolutionfollowthisprocedure:
1. Movemachineto a non-carpetedarea witha floor
drain.
2.Positionthemachineoverthedrain.
NOTE: Drive wheels must be lifted off the
groundforthisstep.
3.Addaminimumoffive(5)gallonsofcleanwatertothe
solution tank.
NOTE:Donotusewaterthatishotterthan140°F.
A
Figure 13
Figure 14
HOW TO PREPARE THE MACHINE FOR
OPERATION

Clarke®Operator's Manual IMAGE 26B Page -13-
MACHINEOPERATINGINSTRUCTIONS
Figure 15a
Figure 15b
10 7 6 5 4 3 2 1
9
8
11
12
Finish Start
3
7
11
13
9
5
1
4 8 12
10 6 2
Finish
Start
DANGER: Failure to read the operator’s
manual before operating this
machine could result in injury to
you or to other personnel, damage
to the machine or to other property
as well.
CAUTION: Pump damage can occur if the
pump is operated without water in
the solution tank. Do not activate
the pump if the solution tank is
empty.
1. Put water and cleaning solution into the solution
tank. Clarke recommends using Clarkare®
ExtractorConcentrate asacleaningsolution. For
everygallonofwater,add betweentwoand ten
ouncesof Clarkare®. Theamountofcleaning
solutionused dependsontheconditionof thecarpet.
DANGER: Electrocution could occur if
machine is connected to an
electrical outlet that is not properly
wired or grounded. Always use a
3-wire electrical system connected
to electrical ground. For maximum
protection, use a circuit that is
protected by a ground fault circuit
interrupter (GFCI). Consult your
electrical contractor.
2. Make sure battery pack is plugged into machine.
3. Turnthe keyswitchtothe"ON" position.
4. Turnthetraversespeed controltothe desired
position.
5. Turn pumppressureknobtodesiredsetting.
6. Lowertherecoverytool.
7. Applypressuretoeithertraverseswitch onthe
controlhandle.
8. Adjustthe brushtothepropercarpet heightsetting.
9. Guidingthemachinebythecontrolhandle,move
acrossthefloor inthe forwarddirection.
10. Followthepathsequence.
NOTE: Byproperly planningthe cleaningpattern, a
minimumnumber ofturnswillneedto bemade.
See figures 15a and 15b.
Low Voltage Condition:
NOTE: Verify battery condition under use. If batteries
aredischarged,pumpandbrushmotorwillnotfunction.
Vacuumandtraversecontiueto allowwaterrecoveryand
abilitytoreturntochargingstation.

Page -14- Clarke®Operator's Manual IMAGE 26B
MACHINE OPERATING INSTRUCTIONS
11. When cleaning in a corner, raise thebrush,maneu-
verthemachineas illustrated infigure16. Lower
therecoverytoolandproceedwithcleaning.
NOTE: Iftheextractor removes anexcessamount of
foamfromthecarpet,addadefoamer suchasClarkare
®DefoamerConcentratetotherecoverytank. The
amountneededwillvaryaccordingtotheamountof
detergentalready inthecarpet.
Tostopthemachinefollowtheseprocedures:
1. Releasepressurefromthetraverseswitchonthe
controlhandle.
2. Raise the recovery tool handle to the “storage”
position.
3. After a 10 second delay to allow all dirty solution to
reachtherecoverytank,the vacuummotorswill
automaticallyshutoff.
WARNING: Failure to turn all switches to
the “OFF” position could result
in injury or machine damage.
Always position all of the
switchesinto their"OFF"
position when not in use.
WARNING: Machine can roll if left parked
or unattended on an un-level
surface and cause damage or
injury. This machine is not
equipped with a parking brake.
Never leave the machine
unattended. For added safety,
always place a chock in front of
and behind the drive wheel.
Figure 16
12
34

Clarke®Operator's Manual IMAGE 26B Page -15-
After Each Use of the Machine
1. Turnmain powerswitch tooffposition.
2. Drainandrinseouttherecoveryandthesolutiontank
followingthisprocedure:
ForRecoveryTank
a. Positionthe machinecloseto afloordrain oran
appropriatelysizedbucketorcontainer.
b. Removethehosefrom the fitting on the back of
themachine.
c. Put the end of the hose over a drain or bucket.
d. Twist drain plug cap to release and drain tank.
ForSolutionTank
a. Removeclearhosefromtopconnector.
b. Positioninappropriatecontainerorfloordrain.
c. Draintank.
NOTE: Draining process can be expedited by
removingvachosefromrecoverytoolandinserting
solution drain hose. Start vac motor after inserting
hose. (See figure 17)
NOTE: Make sure to drain both the recovery tank
and the solution tank.
3. Usea cleandry clothtowipeoutbothtanksandthe
recoverytool,both insideandout.
4. Leavethetanksanddrainhosesopentodryintheair.
5. Inspect and clean the filter screen between the
solution tank and pump.
After Cleaning the Carpet
1. Do notwalkorplaceheavyobjectsonthecarpetfor
at least four hours or until the carpet is dry to the
touch.
2. Vacuum right after the carpet is dry and vacuum at
least once a week, or as often as needed.
CAUTION: YouareresponsibleforOperator
error. Clarke will not be held
liable for damage to the carpet
orforpoorresultsbecauseofthe
operator'serrors.
3. TospeeddryingtimeofthecarpettryaClarkeDirect
Aircarpetdryer.
MACHINE OPERATING INSTRUCTIONS
Figure 17

MAINTENANCE
WARNING: Machine damage or injury could
occur if maintenance and repairs
are performed by unauthorized
personnel. Maintenance and
repairs must be done by
authorized personnel only. Use
only genuine Clarke parts.
NOTE: For maintenance of optional tools, read the
manual that is supplied with the tools.
Always empty the solution and recovery tanks
beforeperforminganymaintenancetothemachine.
After Each Use of the Machine
1. Topreventdamagetothevalvesandtothe jets,flush
onegallonofcleanwaterthroughthesolutionsystem.
2. Iftheauxiliarytools havebeenused,be suretoflush
them out with clean water.
3. Turnmain powerswitch tooffposition.
4. Drainand rinseouttherecoverytank.
5. Use a dry cloth to wipe the recovery tank, and the
tools both inside and out.
6. Inspect and clean the filter screen in the inlet hose
to the pump.
How to Prevent Freezing Temperature Damage
Topreventdamagefromfreezingtemperatures,follow
thisprocedure:
1. Removeanysolutionremaininginthesolutiontank.
2. Make sure that the machine and the pump are
completely dry.
3. Make sure the machine is at room temperature
beforeusingit.
Electrical
NOTE: For electrical repairs, return this machine to a
Clarkeauthorizedrepaircenter.
Page -16- Clarke®Operator's Manual IMAGE 26B

MAINTENANCE
Figure 18
Figure 19
Recovery Tool (See figure 18)
Therecoverytoolisfactoryadjustedforoptimum
performance. Iffurtheradjustmentisnecessary,
removeadjustmentassembly. Loosen locknuts and
lengthenorshortendimension"A" asrequired.
Vacuum Motor
Thismachinehasavacuummotor that uses carbon
brushes. The carbon brushes in the motor must be
checkedeverythreemonths,orevery500hoursof
operation,whichevercomesfirst.
Changingthe Brush
The machine comes with one brush (PN 30167A):
1. Black-foreveryday,routinecarpetmaintenance
(Part No. 30167A). This brush is supplied with
themachine.
2. Black with white bristles on end - for heavy-
duty restoration carpet cleaning (Part No.
30166A). This brush must be purchased
separately.
Thesebrushesarereversible. Afterbristlesareworn
reversethedirection thebrushwas placedonthe
machine.
Tochangethebrushfollowthisprocedure:
(The brush can be changed or rotated by using the
quick change brush door, see figure 19.)
1. Removeclampingknob.
2. Raisebrush housingdoorapproximately¼inch
and pull out.
3. Swingdooruptoremovebrush.
4. Removethespacerandbrushfromthebrush
housing.
5. Place brush onto the shaft. Slide brush in and
rotate until the pins catch. Slide spacer onto
shaft.
6. Swingdoor downandslide ontoshaft.
7. Replaceclampingknob.
A
Clarke®Operator's Manual IMAGE 26B Page -17-

Page -18- Clarke®Operator's Manual IMAGE 26B
MAINTENANCE
Nozzles
To remove the nozzles to clean or change nozzles,
followthisprocedure:
RecoveryTool
1. Grasp the nozzle cap assembly and twist
counterclockwisetoremoveassemblyfrom
the spray bar.
2. Pull the nozzle out of the cap.
3. Cleanorreplace thenozzle.
4. Replace nozzle back into cap.
5. Twist nozzle cap assembly back onto the
spraybar.
BrushHousing
1. Graspspray barandpushtowardsbrush motor
to compress spring.
2. Swing out end of spray bar to remove it.
3. Pull nozzle assembly out to side of machine.
4. Firmly push nozzle in and turn 1/4 turn.
5. Pull nozzle out.
6. Clean and replace into nozzle assembly.
7. Replace nozzle assembly in brush housing.

Clarke®Operator's Manual IMAGE 26B Page -19-
IMAGE 26B
Section II
Parts and Service Manual
(70249B)
®

Page -20- Clarke®Operator's Manual IMAGE 26B
The machine does not move. The Power switch is off. Turn on the "Power" switch.
The traverse switch is defective. Contact an authorized Clarke
service person
There is no solution flow. Solutioncontroldialinwrongposition. Turn dial toposition formore flow.
Thesolutiontankisempty. Fillthesolutiontank.
There is an obstructionin the Remove the obstruction from the hose
solutionhoseorfilter. orfilter.
Solenoid is defective. Contact an authorized Clarke
Service person
Pump is defective. Contact an authorized Clarke
Service person.
Batteries are too low. Chargeunit.
The machine doesn't extract Therecoverytankisfull. Draintherecoverytank.
solution from the floor.
The recovery tool is not Lower and/oradjust the tool.
restingonthefloor.
Filterscreenplugged Clean screenand replace.
The cleaning is not even. The brush is worn. Replacethebrush.
There is damage to the brush Contact an authorized Clarke
module or spray assembly. Service person.
service person.
Thesolutionlevelislow. Fillthesolutiontank.
Batteriesare toolow. Rechargebatteries.
Uneven or no spray from nozzles. Dirtyor plugged spray nozzles. Clean the spray assembly or nozzles.
Worn spray nozzles. Replace spray assembly or nozzles.
Water leaks from the spray Debris in the check valve. Contact an authorized Clarke
service person.
nozzleswith the pump"OFF". Defective check valve. Contact an authorized Clarke
service person.
There is no suction. The vac motor is not running. Turn vac motor switch on.
Vacuumhoseobstruction. Removetheobstruction.
Vac hose damaged. Replace the hose.
The dome gasket worn or damaged. Replace the gasket.
Motorbrushesareworn. Replace motor brushes.
Loose motor connection. Contact an authorized Clarke
service person.
Vac motor switch defective. Contact an authorized Clarke
service person.
Brush does not run or runs Batteriesare toolow. ChargeBatteries.
intermittently.
How to Correct Problems in the Machine
Action
Problem Cause
